370-5482
LED 1200Lumens COB LED
Rechargeable
batteries
Charging time
of the batteries
2 x 3.7V 1200MAH 18650
Lithium-ion batteries (included)
Or 3 x AA batteries (sold separately)
4-5h
Light output
1200 Lumen(100%), 600 Lumen(50%)
Runtime
3-1/2H (100%), 5-1/2H（50%）
Power bank
5V 1A
Material
ABS plastic and rubberized corners
Dimensions
101 x 139 x 35 mm
1200 LUMEN RECHARGEABLE WORK LIGHT WITH FOCUSING LENS
Thanks for choosing MENARDS LED work light, please read
this user guide carefully before the installation and keep it
for future reference.
Caution
1. For safety reasons, do not look directly into the light source.
2. Do not immerse the product in water.
3. Do not place near a fire or any other source of intense heat.
Safety instructions for rechargeable batteries
1. If you notice that the work light is starting to dim, recharge the
rechargeable batteries to prevent deep discharge.
2. If you do not use the work light for a prolonged period, take out the
battery and keep it in a dry place.
First use - Charging the working lamp
1. Please check the product carefully prior to usage.
2. Connect the USB cable.
3. When charging begins, the led will flash red, After the battery is fully
charged, the led keep on in red.
4. Before first use, the battery should be fully charged.
How to use
1. Install the battery according to mark + and -
2. Push switchX1: 100% light output
3. Push switchX2: 50% light output
4. Twist the lens for flood and spot beam.
5. Charge the worklight by USB cabel when power off
6.Take out the battery after using
Power bank
1. To use as a power bank, put the USB charging cable into the USB port.
2. The power bank can charge your phone and other devices
3. Ensure the work light is fully charged before using the power bank.
Twist the lens for
flood and spot beam
7-Position Swivel Stand
Switch
Charging Input Port
Charging Output Port
Indicator Light
