The Adopted Trademarks HDMI,HDMI High-Definition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks of HDMI
Licensing Administrator,Inc.in the United States and other countries.
SC-2450GTV
Connections
D C D
Initial Setup
Google Play
Settings
Tv Source Settings
Home
6
6
10
11
5
16
On Screen Display
TV Bracket assemble
5
17
1
2
AC receptacle
open
This apparatus should not be used at temperatures exceeding 113 degrees.
Connections
Note:The following are the various connections available.The position and
arrangement of connections differ by model.
3
Connections
Connect the antenna/cable TV input.
Connect a USB device here to play
its media files or to record programs
via the PVR function.
Please discontinue use of any device using the USB mode before connecting, disconnecting or adjusting
the HDMI or USB terminal ports.
Failure to do so can result in an electrostatic discharge that could cause damage to the TV and/or its operation.
One key: Seven keys:
/
/
4
tighten
(AC 100-240V~ 50/60Hz).
TV ANT
FM ANT
TV signal output
1
3
2
Fix the TV on the wall
1. First, put the TV and put some soft cloth on the table to avoidon a smooth table
.getting the screen scratched
2. Use a screwdriver to take off the screws which are fixed on the bottom stand
(the direction of the arrow, refer to the photo1). Please be careful when taking off the
bottom stand.
3. Depending on the size of the wall mount, make a bracket that can be attached to the wall.
4. Drill four holes properly on the wall (the size only for reference) and put into four
screws (optional parts) .
5. According to step 4, use the screwdriver to lock the screw on the back of the TV.
Then hang the TV on the wall.
Note:
1. The bracket fixed on the wall is an optional part.
2. , When assembling the TV there should be no other articles around it
.and please keep it distant from other articles
3. , please ask the professional worker to fix it in order to avoid When assembling the TV
danger.
4. The fixing picture is only for reference.
5. Please follow the user’s manual about bracket assemble to fix the TV.
6. Attach the mounting bracket with the VESA compatible wall mounting kit.
A
B
D
C
quantity
4
Product family Inches Standard screw
(C*D)
Specifications
VESA(A*B)
LED TV 24 10cm x 10cm M4*L18
Wallmounting Installation
Note: "D" is the effective length of the screw in the mounting hole.
The figures and illustrations in this manual are provided for reference only
and may differ from their actual appearance. The product design and
specifications may change without notice.
5
TV Bracket assemble
6
Skip
Skip
Initial Setup
Initial Setup
1.
TM
7
Initial Setup
Initial Setup(Cont.)
Use your remote:
Android TV
Initial Setup
8
BACK
BACK
Informational screens will not appear, you can scroll through steps by pressing the “RIGHT” navigation
button to continue.
9
Initial Setup
Skip
Initial Setup(Cont.)
Select TV mode
This unit has been preset to “STORE” brightness, to reduce brightness and energy consumption,
change to “HOME” setting to qualify under ENERGY STAR.
10
Once you have completed the initial setup, you will now enter the home screen
or press button to display the homepage.
Home
Home
Use your voice to jump to shows,control devices, and more – just ask Google.
.
.
.
.
8
2
3
7
.
8
Quick access to frequently used apps. You can create your favorite list.
Favorite Apps
Manage apps and TV controls, change preferences, sounds, and your Google account information.
11
Settings
Settings
Allows you to set various preferences of your TV
12
EXIT
Press button to return to the previous menu.
Press button to exit the menu.
BACK
Settings
factory
13
Tv Source Settings
Tv Source Settings
Google Play
14
Google Play
Once you have signed in, the below page will be displayed, scroll through the list
15
HDMI
16
WARNING
Never place a television set in an unstable location. A television set may fall, causing serious personal injury or death.
Many injuries, particularly to children, can be avoided by taking simple precautions such as:
1.Using cabinets or stands recommended by the manufacturer of the television set.
2.Only use furniture that can safely support the television set.
3.Ensure the television set is not ove
rhanging the edge of the supporting furniture.
4.Do not place the television set on tall furniture (for example, cupboards or bookcases).without ancho
ring both the
furniture and the television set to a suitable support.
5.Do not place the television set on cloth or other materials that may be located between the television set and
supporting furniture,
6.Educate children about the dangers of climbing on furniture to reach the television set or its controls.
If your existing television set is being retained and relocated, the same considerations as above should be ap
plied.
Note:don't hang at an angle to avoid the risk of falling off.
Wall-mounted screw:22-24inch M4, 28-70inch M6, 75inch M8
Google Assistant is not available in certain languages and countries. Availability of services
varies by country and language.
Google, Google Play, YouTube,Android TV and Chromecast built-in are trademarks of Google LLC.
LIFE TIME
: 60,000 Hrs
power Consumption
30W/36W
40W/56W
60W/70W/90W
Screen Size
24”
32”
39 /40””
Main accessories
User's manual x1
Remote controller x1
Power cord x1
AAA Batteries x2 (Optional)
65W/70W/90W
70W/80W/90W
100W/108W/120W
118W/135W
42”
43”
50”
55”
160W/165W/190W
65”
17
Switches the TV between on and standby mode.
Indicator light.
Mute or restore your TV sound.
Enter “-” for Sub-channel symbol.（Ex:11-1）
Displays the EPG Electronic Program Guide.
INFO:Displays the present channel information
such as the current time and channel name.
Menu:Displays the OSD (On Screen Display) menu.
Inputs:Display/Select signal source options.
Navigation buttons:Cursor UP/LEFT/RIGHT/DOWN.
Back:Press to move back through menus.
Exit:Exit the OSD menu.
YouTube:
Connects to YouTube.(internet connection required)
NETFLIX:
Connects to NETFLIX for viewing online TV shows
and films. (internet and NETFLIX account required)
Google Play:Connects to Google Play.
Prime video:Connects to Prime Video.
(internet and Prime Video account required)
Media control
Fast forward/back
Play the last/next program
Play/Pause/Stop program
USB:Open Multi Media Player.
Audio:Displays the Audio Language list and select an audio language or
audio format if available. (only applicable when the TV program has this feature)
CC:Closed Caption.
Google Assistant:
Talk to Google to control your TV using your voice.
HOME:Displays the home screen.
WARRANTY
Supersonic Inc. ("Supersonic") warrants this product to the original purchaser ONLY, to be free from defects in materials and
workmanship under normal use, for ninety (90) DAYS from the date of original purchase. Proof of purchase (receipt) required.
Please visit https://www.supersonicinc.com/pages/warranty for additional information.
