Installaon Steps and Precauons:
Nominal Impedance
Frequency Response (-3dB)
Power Handling (RMS)*
Power Handling (Peak)*
Recommended Power (RMS)*
Recommended High Pass Filter
Free Air Resonance (Fs)
*With Recommended High Pass FIlter
Specificaons and Recommendaons:
Dimensions:
Fitment Informaon:
Limited Warranty (USA): Audiofrog GS Series products sold in the USA through authorized
Audiofrog dealers are warranted to the original purchaser against defects in materials and
workmanship for one year aer the date of original purchase. They are warranted for an addional
year if they are installed by an authorized Audiofrog dealer. Please save your receipt. A valid receipt
from an authorized Audiofrog dealer is required for warranty service. If you purchased your GB
Series products outside the USA, please consult your local distributor for warranty terms and
condions.
Audiofrog and the Audiofrog logo are trademarks of Audiofrog, Inc, registered in the United States
and/or other countries. Audiofrog et le logo sant des marques est une marque commerciale de
Audiofrog, Inc déposée aux Étas-Unis et/ou dans d’autres pays.
Audiofrog, Inc. 419 S. Mission Dr. San Gabriel, CA 91776 +1 (707) 600-FROG
www.audiofrog.com
GS10OE-0004
4Ω
1.8kHz - 20kHz
70W
200W
15W - 75W
3500Hz, 24dB/Oct
1500Hz
16.8 mm
11.5 mm
43 mm
43 mm
Removal of OE tweeter:
• Gently pull on both sides of the Tesla sail
panel to spread open the tabs and remove
the tweeter.
Installaon of Audiofrog OE tweeter:
• Align the Audiofrog tweeter so that the
bevel is pointed towards the rear side tab.
• Angle the tweeter so that the front side and
top tabs are over OE tweeter, but the rear
tab is not.
• Then spread the rear most side of the sail
panel and press the tweeter into place so
that the rear side tab slips onto the bevel.
Verified Fit:
• All Tesla models aer 2016 with tweeters in the sail
panel locaon
Unverified but May Fit:
• Unknown
Please check your car’s tweeter locaon and housing
dimensions to confirm that the GS10OE-0004 will fit.
Front
Rear
