Owner’s Manual
Blu-ray Disc
TM
Player
Model No. DMP-BD90
Thank you for purchasing this product.
Please read these instructions carefully before using this product, and save this manual for future use.
If you have any questions, visit :
http://shop.panasonic.com/support
Register online at http://shop.panasonic.com/support
(U.S. customers only)
Firmware updates
Panasonic is constantly improving the unit’s firmware to ensure
that our customers are enjoying the latest technology.
Panasonic recommends updating your firmware as soon as you
are notified.
For details, refer to “Firmware updates” (> 11) or
http://panasonic.jp/support/global/cs/ (This site is in English only.)
P
DMP-BD90_TQBS0470_eng.book 1 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 2 -
IMPORTANT SAFETY
INSTRUCTIONS
Read these operating instructions carefully before using the unit.
Follow the safety instructions on the unit and the applicable safety
instructions listed below. Keep these operating instructions handy for
future reference.
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8 Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9 Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding-type plug has two blades and
a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the
obsolete outlet.
10 Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11 Only use attachments/accessories specified by the
manufacturer.
12 Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
13 Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14 Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
CAUTION
CAUTION : TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE SCREWS.
NO USER-SERVICEABLE PARTS
INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
RISK
OF
ELECTRIC
SHOCK
DO
NOT
OPEN
FCC Note:
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
≥ Reorient or relocate the receiving antenna.
≥ Increase the separation between the equipment and receiver.
≥ Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
≥ Consult the dealer or an experienced radio/TV technician for
help.
FCC Caution: To assure continued compliance, follow the attached
installation instructions and use only shielded interface cables when
connecting to peripheral devices.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
this equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Supplier’s Declaration of Conformity
Trade Name: Panasonic
Model No.: DMP-BD90
Responsible Party: Panasonic Corporation of North America
Two Riverfront Plaza, Newark,
NJ 07102-5490
Support Contact: http://shop.panasonic.com/support
Conforms to UL STD 62368-1.
DMP-BD90_TQBS0470_eng.book 2 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 3 -
Precautions
Unit
To reduce the risk of fire, electric shock or product damage,
≥ Do not expose this unit to rain, moisture, dripping or splashing.
≥ Do not place objects filled with liquids, such as vases, on this unit.
≥ Use the recommended accessories.
≥ Do not remove covers.
≥ Do not repair this unit by yourself. Refer servicing to qualified
service personnel.
AC adaptor
≥ The power plug is the disconnecting device. Install this unit so that
the power plug can be unplugged from the socket outlet
immediately.
Small object
≥ Keep the batteries out of reach of children to prevent swallowing.
Unit
≥ This unit utilizes a laser. Use of controls or adjustments or
performance of procedures other than those specified herein may
result in hazardous radiation exposure.
≥ Do not place sources of naked flames, such as lighted candles, on
this unit.
≥ Some portions of this unit may become hot during use. When
moving or cleaning this unit, disconnect the AC adaptor and wait
for 3 minutes or longer.
Placement
To reduce the risk of fire, electric shock or product damage,
≥ Do not install or place this unit in a bookcase, built-in cabinet or in
another confined space. Ensure this unit is well ventilated.
≥ Do not obstruct this unit’s ventilation openings with newspapers,
tablecloths, curtains, and similar items.
≥ Do not place the unit on amplifiers/receivers or equipment that
may become hot. The heat can damage the unit.
Batteries
Mishandling of batteries can cause electrolyte leakage and may
cause a fire.
≥ Danger of explosion if battery is incorrectly replaced. Replace only
with the type recommended by the manufacturer.
≥ When disposing of the batteries, please contact your local
authorities or dealer and ask for the correct method of disposal.
≥
Do not mix old and new batteries or different types at the same time.
≥ Do not heat or expose to flame.
≥ Do not leave the battery(ies) in a car exposed to direct sunlight for
a long period of time with doors and windows closed.
≥ Do not take apart or short circuit.
≥ Do not recharge alkaline or manganese batteries.
≥ Do not use batteries if the covering has been peeled off.
Remove batteries if you do not intend to use the remote control for a
long period of time. Store in a cool, dark place.
Avoid the use in the following conditions
≥ High or low extreme temperatures during use, storage or
transportation.
≥ Replacement of a battery with an incorrect type.
≥ Disposal of a battery into fire or a hot oven, or mechanically
crushing or cutting of a battery,that can result in an explosion.
≥
Extremely high temperature and/or extremely low air pressure that
can result in an explosion or the leakage of flammable liquid or gas.
AC adaptor
This AC adaptor operates on AC between 110 V and 240 V.
But
≥ In the U.S.A. and Canada, the AC adaptor must be connected to a
120 V AC power supply only.
≥ When connecting to an AC supply outside of the U.S.A. or
Canada, use a plug adaptor to suit the AC outlet configuration.
This unit adopts the following technology for copyright protection.
Cinavia Notice
This product uses Cinavia technology to limit the use of unauthorized
copies of some commercially-produced film and videos and their
soundtracks. When a prohibited use of an unauthorized copy is
detected, a message will be displayed and playback or copying will be
interrupted.
More information about Cinavia technology is provided at the Cinavia
Online Consumer Information Center at http://www.cinavia.com
. To
request additional information about Cinavia by mail, send a postcard
with your mailing address to:
Cinavia Consumer Information Center, P.O. Box 86851, San Diego,
CA, 92138, USA.
The unit may keep the user settings information in the unit. If you
discard this unit either by disposal or transfer, then follow the
procedure to return all the settings to the factory presets to delete the
user settings. (> 22, “To return all settings to the factory preset.”)
≥ The operation history may be recorded in the memory of this unit.
(Inside of product）
WARNING
CAUTION
Restriction on use of
unauthorized copied content
To dispose or transfer this unit
DMP-BD90_TQBS0470_eng.book 3 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 4 -
Table of contents
IMPORTANT SAFETY
INSTRUCTIONS . . . . . . . . . . .2
Precautions . . . . . . . . . . . . . . . .3
Getting started
Accessories . . . . . . . . . . . . . . . .5
Unit and media care . . . . . . . . . .5
Playable media. . . . . . . . . . . . . .6
Control reference guide . . . . . . .8
Connections and settings
Connecting to a TV . . . . . . . . .10
Connecting to an
amplifier/receiver . . . . . . . . . .10
Settings . . . . . . . . . . . . . . . . . .11
Playback
Inserting or removing media. . .12
HOME menu . . . . . . . . . . . . . .13
Playback. . . . . . . . . . . . . . . . . .14
“HDMI CEC” . . . . . . . . . . . . . . .16
Settings
Option menu . . . . . . . . . . . . . . 16
Setup menu. . . . . . . . . . . . . . . 18
Reference
Troubleshooting guide . . . . . . 22
Specifications . . . . . . . . . . . . . 26
Licenses . . . . . . . . . . . . . . . . . 28
Limited Warranty. . . . . . . . . . . 29
Referencia rápida en español
(Spanish Quick Reference) . . . . 30
Index . . . . . . . . . . . . . Back cover
DMP-BD90_TQBS0470_eng.book 4 ページ ２０２２年１月２０日 木曜日 午後２時５６分
Getting started
- 5 -
¨Getting started
Accessories
Check the supplied accessories before using this
unit.
1 Remote control
(N2QAYA000217)
2 Batteries for remote control
1 AC adaptor
(TXH0018AA)
≥ Product numbers are provided in this Owner’s Manual
correct as of January 2022.
These may be subject to change.
≥ Do not use AC adaptor with other equipment.
≥ Do not use any other AC adaptors except the supplied one.
∫ Using the remote control
Insert the batteries to the terminal so that it (i
and j) matches those in the remote control.
Point it at the remote control signal sensor on this
unit. (> 9)
Unit and media care
∫ Clean this unit with a soft, dry
cloth
≥ Never use alcohol, paint thinner or benzine to
clean this unit.
≥ Before using chemically treated cloth, carefully
read the instructions that came with the cloth.
∫ This unit’s lens
Use the lens cleaner (not supplied) to clean the
unit’s lens.
∫ Clean discs
Wipe with a damp cloth and then wipe dry with a
dry cloth.
∫ Disc handling precautions
≥ Handle discs by the edges to avoid inadvertent
scratches or fingerprints on the disc.
≥ Do not attach labels or stickers to discs.
≥ Do not use disc cleaning sprays, benzine,
thinner, static electricity prevention liquids or
any other solvent.
≥ Do not use the following discs:
– Discs with exposed adhesive from removed
stickers or labels (rented discs, etc.).
– Discs that are badly warped or cracked.
– Irregularly shaped discs, such as heart
shapes.
1
2
R03/LR03, AAA
3
(Alkaline or manganese batteries)
DO
DO NOT
DMP-BD90_TQBS0470_eng.book 5 ページ ２０２２年１月２０日 木曜日 午後２時５６分
Getting started
- 6 -
Playable media
≥ See pages 7 and 26 for more information on the types of content that can be played.
Device
Media
markings
Device types Contents format
BD-Video Video
BD-RE
Video,
JPEG,
AAC, ALAC, DSD,
FLAC, MP3, WAV, WMA
BD-R
Video, MKV,
AAC, ALAC, DSD,
FLAC, MP3, WAV, WMA
DVD-Video Video
DVD-R
Video, AVCHD, MKV,
JPEG,
AAC, ALAC, DSD,
FLAC, MP3, WAV, WMA
DVD-R DL
DVD-RW
Video, AVCHD
— +R/+RW/+R DL
Music CD Music [CD-DA]
—
CD-R
CD-RW
MKV,
JPEG,
AAC, ALAC, FLAC,
MP3, Music [CD-DA],
WAV, WMA
—
USB devices
(up to 4 TB)
MKV, MP4, MPEG2,
JPEG,
AAC, ALAC, DSD,
FLAC, MP3, WAV, WMA
BD
DVD
CD
USB
DMP-BD90_TQBS0470_eng.book 6 ページ ２０２２年１月２０日 木曜日 午後２時５６分
Getting started
- 7 -
∫ Types of discs that cannot be
played in this unit
Any other disc that is not specifically
supported or previously described.
≥ DVD-RAM
≥ Super Audio CD
≥ Photo CD
≥ DVD-Audio
≥ Video CD and Super Video CD
≥ HD DVD
≥ 4K Video content is not supported
∫ Region management information
The unit can play back BD-Video/DVD-Video
discs of the following regions codes, including
“ALL”:
≥ The unit cannot playback discs in PAL format.
∫ Finalize
Any DVD-R/RW/R DL, +R/+RW/+R DL and
CD-R/RW that are recorded by a recorder need to
be finalized by the recorder to play on this unit.
Please refer to the recorder’s owner’s manuals.
∫ BD-Video
≥ This unit supports high bit rate audio (Dolby
®
Digital Plus, Dolby
®
TrueHD, DTS-HD High
Resolution Audio
TM
and DTS-HD Master
Audio
TM
) adopted in BD-Video.
≥ If “DD/DD +/DTHD” is set to “PCM” and “DTS
Neo:6” is set to “Off”, the maximum possible
number of Dolby
®
sound is 2ch PCM. (> 19)
∫ Music CD
≥ Operation and sound quality of CDs that do not
comply with CD-DA specifications (copy control
CDs, etc.) cannot be guaranteed to work.
≥ The digital audio content side of a DualDisc
does not meet the technical specifications of
the Compact Disc Digital Audio (CD-DA) format
so playback may not be possible.
∫ USB device
≥ This unit does not guarantee connection with all
USB devices.
≥ This unit does not support USB device
charging.
≥ FAT12, FAT16, FAT32, and NTFS file systems
are supported.
≥ This unit supports USB2.0 High Speed.
≥ This unit supports an HDD formatted in FAT32
and NTFS. If the HDD is not recognized, the
power to the HDD may not be supplied. Supply
power from an external source.
≥ 4K Video content is not supported.
≥ It may not be possible to play the above media in some
cases due to the type of media, the condition of the
recording, the recording method, and how the files were
created.
≥ The producers of the disc can control how discs are
played, so you may not always be able to control play as
described in this Owner’s Manual. Read the disc’s
instructions carefully.
1
BD-Video
DVD-Video
Example:
DMP-BD90_TQBS0470_eng.book 7 ページ ２０２２年１月２０日 木曜日 午後２時５６分
Getting started
- 8 -
Control reference guide
∫ Remote control
1 Turn the unit on and off
2 Select title numbers, etc./Enter numbers
3 Show Closed Caption setup screen
4 Show Top menu/Pop-up menu (> 14)
5[3, 4, 2, 1] : Move the highlight for
selection
[OK] : Confirm the selection
(;1) : Frame-by-frame (> 14)
6 Show Option menu (> 16)
7 Basic playback control buttons (> 14)
8 Show the status messages (> 15)
9 Colored buttons (red, green, yellow, blue)
Used for various purposes depending on the
screen
10 Transmit the remote control signal
11 Open or close the disc tray (> 9)
12 Show HOME menu (> 13)
13 Return to previous screen
≥ When other Panasonic devices respond to this remote
control, change the remote control code of other
Panasonic devices to other than code 1.
1
2
3
7
5
6
9
8
4
13
11
12
10
∫ Available keys for HDMI CEC (> 16)
2 Number keys
5[3, 4, 2, 1]/[OK] button
6 Option button
7 Basic playback control buttons
9 Colored buttons (red, green, yellow, blue)
13 Return button
DMP-BD90_TQBS0470_eng.book 8 ページ ２０２２年１月２０日 木曜日 午後２時５６分
Getting started
- 9 -
∫ Front
1 Disc tray (> 12)
2 USB port ( DC 5 V 500 mA) (> 12)
This port supports USB 2.0 High Speed.
3 POWER LED
The LED lights when the unit is turned on,
and flashes when error occurs. (> 25)
4 Remote control signal sensor
Distance: Within approx. 7 m (23 feet)
Angle: Approx. 20e up and down, 30e left and
right
5 Open or close the disc tray (> 12)
6 Standby/on switch (Í/I) (> 11)
Press to switch the unit from on to standby
mode or vice versa. In standby mode, the unit
still consumes a small amount of power.
Rear panel terminals (> 10)
CAUTION
Do not place objects in front of the unit. The disc tray may collide with objects when it is opened, and
this may cause malfunction.
≥ When inserting a media item, ensure that it is facing the correct way, which is the right side facing up.
≥ If you connect a Panasonic product with a USB connection cable, the setup screen may be displayed
on the connected equipment. For details, refer to the instructions for the connected equipment.
The symbols on this product (including the accessories) represent the following.
65
1
234
AC
DC
Class II equipment (The construction
of the product is double-insulated.)
DMP-BD90_TQBS0470_eng.book 9 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 10 -
Connections and settings
Connections and settings
Connecting to a TV
Connect the power supply cord after making all connections.
≥ Before making any connections, we recommend that you temporarily disconnect all the units from AC
power outlet.
≥ Use the High Speed HDMI cables. Non-HDMI-compliant cables cannot be utilized. It is recommended
that you use Panasonic’s HDMI cable. When outputting 1080p, please use HDMI cables 5.0 meters
(16.4 ft.) or less.
≥ This unit consumes a small amount of AC power (> 26) even when turned off in standby mode. For
the purpose of energy conservation, the unit should be disconnected if you will not be using it for
extended period of time.
Connecting to an amplifier/receiver
≥ Set “Digital Audio Output” (> 19).
≥ When using the TV or amplifier/receiver that does not have the indication of “(ARC)”
(non-ARC-compatible) on the HDMI terminal, the amplifier/receiver and TV must also be connected
using an optical digital cable in order to enjoy the TV’s sound through the amplifier/receiver.
HDMI IN
HDMI cable
AC adaptor (supplied)
To an AC outlet
HDMI IN
(ARC)
HDMI OUT
(ARC)
HDMI IN
Amplifier/receiver
HDMI cable
HDMI cable
DMP-BD90_TQBS0470_eng.book 10 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 11 -
Connections and settings
Settings
The following settings can be performed anytime
in the Setup menu (> 20, 21).
After connecting your new player for the first time
and pressing [Í], the basic settings screen will
appear.
Preparation
Turn on the TV and select the appropriate
video input.
1 Press [Í].
Setup screen appears.
2 Follow the on-screen instructions to
continue with the settings.
Occasionally, Panasonic may release updated
firmware for this unit that may add or improve the
way a feature operates. These updates are
available free of charge.
You can download the latest firmware from the
following website and store it to a USB device to
update the firmware.
http://panasonic.jp/support/global/cs/
(This site is in English only.)
You cannot operate the unit until the update is
complete. Don't remove the AC adaptor during
the update. Removing the AC adaptor while the
update is in progress may damage the unit. After
the firmware is installed, unit will restart and the
following screen will be displayed.
e.g.,
≥ To show the firmware version on this unit.
(> 21, “Firmware Version Information”)
≥ Downloading will require several minutes. It may take
longer or may not work properly depending on the
connection environment.
* “X.XX” represents the firmware version number.
Easy Settings
Firmware updates
The firmware was updated.
Current Version
: x.xx
RETURN
*
DMP-BD90_TQBS0470_eng.book 11 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 12 -
Connections and settings
Playback
Inserting or removing
media
Notes
≥ When inserting a media item, ensure that it is
facing the correct way, which is the right side
facing up.
≥ If you connect a Panasonic product with a USB
connection cable, the setup screen may be
displayed on the connected equipment. For
details, refer to the instructions for the
connected equipment.
CAUTION
Do not place objects in front of the unit. The disc
tray may collide with objects when it is opened,
and this may cause malfunction.
DMP-BD90_TQBS0470_eng.book 12 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 13 -
Playback
HOME menu
Major functions of this unit can be operated from
the HOME menu.
Preparation
Turn on the TV and select the appropriate video
input.
1 Press [Í] to turn on the unit.
≥ It may take some time until the HOME
menu is displayed.
2
Press [
3
,
4
,
2
,
1
] to select the item.
≥ If there are any other items, repeat this
step.
Videos/Photos/Music
Setup
To show the HOME
menu
Press [HOME].
≥ Items to be displayed may vary with the media.
Videos
MusicPhotos
Setup
HOME
Blu-ray Disc Player
Disc
Play back the contents. (> 14)
≥ When multiple contents are
recorded, select the types of
contents or the title.
USB
Player
Settings
(> 18)
Wallpaper
Changes the background of
HOME menu.
DMP-BD90_TQBS0470_eng.book 13 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 14 -
Playback
Playback
1 Insert the media.
Playback starts depending on the media.
2 Select the item to play and press [OK].
Repeat this step if necessary.
≥ DISCS CONTINUE TO ROTATE WHILE MENUS ARE
DISPLAYED. Press [∫] when you have finished playback
to protect the unit’s motor, your TV screen and so on.
≥ It is not possible to play back AVCHD and MPEG2 videos
which have been dragged and dropped or copied and
pasted to the media.
The following functions may not work depending
on the media and contents.
Press [∫].
The stopping point is memorized.
Resume play function
Press [1] to restart from this point.
≥ The point is cleared if the media is removed.
≥ On BD-Video discs including BD-J, the
resume play function does not work.
Press [;].
≥ Press [;] again or [1] to restart play.
Search
While playing, press [6] or [5].
Slow motion
While paused, press [5].
≥ MKV, MP4 and MPEG2: Not effective.
The speed increases up to 5 steps.
≥ Music, MP3, etc.: The speed is fixed to a single
step.
≥ Press [1] to revert to normal playback speed.
While playing or paused, press [:] or
[9].
Skip to the title, chapter or track.
While paused, press [1] (;1).
≥ Press and hold to fast forward.
≥ Press [1] to revert to normal playback speed.
≥ MKV, MP4 and MPEG2: Not effective.
Press [POP-UP MENU/TOP MENU].
≥ Select the item and press [OK].
Operations during playback
Stop
Pause
Search/Slow motion
Skip
Frame-by-frame
Show top menu/pop-up
menu
DMP-BD90_TQBS0470_eng.book 14 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 15 -
Playback
While playing, press [STATUS].
The status messages give you information about
what is currently being played. Each time you
press [STATUS], the display information may
change or disappear from the screen.
≥ Depending on media and contents, the display
may change or not appear.
e.g., BD-Video
A T: Title, C: Chapter, PL: Playlist
B Elapsed time in the title
C Current position
D Tota l t i me
e.g., JPEG
Play a slideshow of photos and adjust various
settings during the playback.
1 Insert the media.
2 Select “Photos”.
3 Select an item and press the green button.
The following items can be set.
≥ Still pictures displayed as “ ” cannot be played back
with this unit.
Show the status messages
Play
BD-Video
T1 C1 0:05.14
0:20.52
A
C D
B
Date
Size
Manufacturer
Equipment
1 / 26
11/12/2007
500 X 375
Slideshow
Start
Slideshow
Start the slideshow.
You can display still pictures in
the selected folder one by one at
a constant interval.
Display
Interval
Change the display interval.
Transition
Effect
Select the effect when sliding
pictures.
Repeat Play
Set whether to repeat the slideshow.
DMP-BD90_TQBS0470_eng.book 15 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 16 -
Playback
“HDMI CEC”
This unit supports “HDMI CEC” (Consumer
Electronics Control) function.
You can use this function by connecting the
equipment that supports “HDMI CEC”. See the
owner’s manuals for connected equipment for
operational details.
Preparation
1 Set “HDMI CEC” to “On” (> 21). (The default
setting is “On”.)
2 Set the “HDMI CEC” operations on the
connected equipment (e.g., TV).
3 Turn on all “HDMI CEC” compatible
equipment and select this unit’s input channel
on the connected TV so that the “HDMI CEC”
function works properly.
Repeat this procedure when the
connections or settings are changed.
When the unit starts playback, the TV will
automatically switch the input channel and the
screen of the unit will be displayed.
Additionally when the TV is off, the TV will
automatically turn on.
All connected equipment compatible with “HDMI
CEC”, including this unit, automatically turns off
when you switch the TV off.
By using the TV remote control, you can perform
the same operations as you use the remote
control of this unit. (> 8)
≥ This unit supports the “HDMI CEC” (Consumer Electronics
Control) function. However, operation cannot be
guaranteed on all HDMI CEC devices.
Settings
Option menu
A variety of playback operations and settings can
be performed from this menu.
Available options differ depending on the playing
contents and the condition of the unit.
1 Press [OPTION].
≥ When playing music, select “Playback
Settings” and press [OK].
e.g., BD-Video
2 Select an item and change the settings.
To exit the screen
Press [OPTION].
Regarding Language: (> 27)
∫ Soundtrack
Show or change the soundtrack.
∫ Audio channel
Select the audio channel number.
∫ Subtitle
Change the subtitle settings.
∫ Angle
Select the number of the angle.
∫ Repeat Play
Select the item that you want to repeat.
≥ You can repeat the playback of a chapter,
playlist, the entire disc, etc., but the items
displayed will differ depending on the type of
the media.
≥ Select “Off” to cancel.
Automatic input switching
Power on link
Power off link
Easy control only with TV
remote control
Operation Menu
Operation Menu
Pop-up Menu
Zoom
Closed Caption
Top Menu
Secondary Video
Primary Video
Status
Repeat Play
Angle
Subtitle
Soundtrack
Off
1MPEG-4 AVC
1ENG DTHD 3/2/2.1ch
DMP-BD90_TQBS0470_eng.book 16 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 17 -
Settings
∫ Shuffle
Select whether or not to play random.
∫ Start Slideshow
Start the slideshow.
∫ Status
Show the status messages.
∫ Rotate Right
∫ Rotate Left
Rotate the still picture.
∫ Wallpaper
Set the still picture to the wallpaper of HOME
menu. (> 13)
∫ Video
The recording method of original video appears.
∫ Primary Video
The recording method of original primary video
appears.
∫ Secondary Video
∫ Zoom
Videos and pictures are magnified.
∫ Top Menu
Display Top Menu.
∫ Pop-up Menu
Display Pop-up Menu.
∫ Menu
Display Menu.
∫ Closed Caption (> 20)
You can only set “Manual setting” and “CC Reset”
in the Setup menu.
∫ Picture Mode
Select the picture quality mode during play.
≥ If you select “User”, you can change settings in
“Picture Adjustment”.
∫ Picture Adjustment
Specific picture quality settings can be changed.
∫ Progressive
Select the method of conversion for progressive
output to suit the type of material being played.
≥ When the content is distorted, change the
settings from “Auto” to “Video”.
∫ 24p
Movies and other material recorded on
DVD-Video at 24p are output at 24p.
≥ Only when you have selected “On” in “24p
Output” (> 18).
∫ Reset to Default Video Settings
Return video settings to the factory defaults.
Video
Select on/off for images. The
recording method of original
video appears.
≥
During search/slow motion, only
the primary video is displayed.
Soundtrack
Select on/off for audio and the
language.
Video Settings
DMP-BD90_TQBS0470_eng.book 17 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 18 -
Settings
Setup menu
Change the unit’s settings if necessary. The
settings remain intact even if you switch the unit
to standby.
Some items are common to the Option menu. You
can get the same effect with both menus.
1 Press [HOME].
2 Press [3] to select “Setup”.
3 Press [3] to select “Player Settings”.
4 Select an item and change the settings.
To exit the screen
Press [HOME].
∫ Picture Mode (> 17)
∫ Picture Adjustment (> 17)
∫ HDMI Output
Press [OK] to show the following settings:
¾ HDMI Resolution
The items supported by the connected devices
are indicated on the screen as “¢”. When any
item without “¢” is selected, the images may be
distorted.
≥ If “Auto” is selected, the best suited output
resolution to the connected TV is
automatically selected.
≥ To enjoy high-definition video up-converted to
1080p, you need to connect the unit directly
to 1080p compatible HDTV (High Definition
TV). If this unit is connected to an HDTV
through other equipment, the other equipment
must also be 1080p compatible.
¾ 24p Output
When this unit is connected to a TV supporting
1080/24p output, movies and other material
recorded at 24p* are output at 24p.
≥ When playing DVD-Video, set to “On” and
then set “24p” in “Video Settings” (> 17) to
“On”.
≥ When BD-Video/DVD-Video images other
than 24p are played, images are output at
60p.
* A progressive image recorded at a rate of 24 frames per
second (motion-picture film). Many BD-Video movie
contents are recorded in 24 frames/second in
accordance with the film materials.
¾ Deep Color Output
This setting is for selecting whether to use Deep
Color Output when a TV that supports Deep
Color is connected.
¾ Contents Type Flag
Depending on the playback content, the TV will
output adjusting to the optimal method when a
TV that supports this function is connected.
OK
RETURN
System
Ratings
Player Settings
Language
Audio
Video
HDMI Output
Picture Adjustment
Picture Mode Normal
Video
DMP-BD90_TQBS0470_eng.book 18 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 19 -
Settings
∫ Dynamic Range Compression
You can listen at low volumes but still hear
dialogue clearly.
(Dolby Digital, Dolby Digital Plus and Dolby
TrueHD only)
≥ “Auto” is effective only when playing Dolby
TrueHD.
∫ Digital Audio Output
Press [OK] to show the following settings:
¾ Dolby Audio (DD/DD+/DTHD)
¾ DTS/DTS-HD
Select the audio signal to output.
≥ Select “PCM”, when the connected
equipment cannot decode the respective
audio format. This unit decodes the audio
format and transmits to the connected
equipment.
≥ If you do not make proper settings the audio
may be static or noisy.
¾ BD-Video Secondary Audio
Select whether or not to mix the primary and
secondary audio (including the button click
sound).
If “Off” is selected, the unit outputs the primary
audio only.
∫ Downmix
Select the downmix system of multi-channel to
2-channel sound.
≥ Select “Surround encoded”, when the
connected equipment supports the virtual
surround function.
≥ The downmix effect is not available when
“Digital Audio Output” is set to “Bitstream”.
≥ The audio will be output in “Stereo” in the
following cases:
– AVCHD playback
– Playback of secondary audio (including the
button click sound).
∫ DTS Neo:6
2ch (2.1ch) audio is expanded to 7ch (7.1ch).
≥ This function works when the following
conditions are met:
– Audio recorded at 96 kHz or lower is output.
– “Digital Audio Output” is set to “
PCM
” when
audio other than PCM is output.
∫ Voice Guidance Setting
Voice Guidance reads aloud currently-selected
items. (It is also possible to display the “Voice
Guidance Setting” screen by pressing and holding
the [OPTION] button for at least 5 seconds while
the HOME menu is displayed.).
≥ Voice guidance is only available in HOME menu
and Player Settings.
Audio
DMP-BD90_TQBS0470_eng.book 19 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 20 -
Settings
∫ Audio Language
Choose the language for audio.
≥ If “Original” is selected, the original language of
each disc will be selected.
≥ When the selected language is not recorded on
the disc, or depending on how the navigation is
created on the disc, it may playback in a
different language than the selected language.
≥ Enter a code (> 27) when you select “Other
¢¢¢¢”.
∫ Subtitle Language
Choose the language for the subtitle.
≥ When “Auto” is selected, a subtitle for the
language selected in the “Audio Language” is
displayed only when the language other than
the language selected in the “Audio Language”
is played back.
≥ When the selected language is not recorded on
the disc, or depending on how the navigation is
created on the disc, it may playback in a
different language than the selected language.
≥ Enter a code (> 27) when you select “Other
¢¢¢¢”.
∫ Menu Language
Choose the language for the disc menus.
≥ Enter a code (> 27) when you select “Other
¢¢¢¢”.
∫ Subtitle Text
Select a desired item according to the language
used for MKV subtitles text.
≥ This item is displayed only after playing back a
file.
∫ On-screen Language
Choose the language for menus and on-screen
messages.
∫ Closed Caption
Closed captioning services are dependent on
contents, and the unit can display closed captions
of both digital and analog types.
Press [OK] to show the following settings:
¾ Closed Caption Display
Set whether or not to display closed captions.
¾ Closed Caption Type
Select the closed caption type that matches the
one of the content to be played back.
¾ Analog CC
Select the channel of analog closed captions.
¾ Digital CC
Select the channel of digital closed captions.
¾ Manual setting
Set the display style of closed captions.
¾ CC Reset
Restore the default “Closed Caption” settings.
Language
DMP-BD90_TQBS0470_eng.book 20 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 21 -
Settings
The following items use the same password.
Don’t forget your password.
∫ DVD-Video Ratings
Set a ratings level to limit DVD-Video play.
∫ BD-Video Ratings
Set an age limit of BD-Video play.
∫ Easy Settings
You can execute basic settings.
∫ Display Settings
Press [OK] to show the following settings:
¾ TV Aspect
Set to match the type of TV connected.
When connected to a 4:3 aspect TV and playing
16:9 ratio image:
When connected to a 16:9 widescreen TV and
playing 4:3 ratio image:
¾ Screen Saver Function
This is to prevent image retention on the
screen.
≥ When this is set to “On”:
If a list of playback content is displayed and
there is no operation for 10 minutes or more,
the screen switches to HOME menu
automatically.
≥ While playing and pausing, etc., this function
is not available.
¾ Status Messages
Choose whether to show status messages
automatically.
¾ HDMI CEC
Set to use “HDMI CEC” function when
connected to a device that supports “HDMI
CEC”.
≥ Select “Off” when you do not want to use
“HDMI CEC”.
∫ Quick Start
Speed of start-up from standby mode is
increased.
≥ When set to “On”, the internal control unit will be
powered and the idle power consumption will
increase so compared to when set to “Off”.
(Power consumption > 26)
∫ System Information
Press [OK] to show the following settings:
¾ License
Information about the software used by this unit
is displayed.
¾ Firmware Version Information
Display firmware version of this unit.
∫ Restore Default Settings
This returns all values in the Setup menu and the
Option menu to the default settings, except for
some settings, ratings, remote control code,
on-screen language, etc.
Ratings
System
4:3 Pan &
Scan
The sides are cut
off so the picture
fills the screen.
When playing
BD-Video, video is output as “4:3
Letterbox”.
4:3
Letterbox
Black bands
appear at the top
and bottom of the
picture.
16:9
Video is displayed as a 4:3 ratio
image in the center of the screen.
16:9 Full
Video is displayed as a
horizontally stretched 16:9 image.
DMP-BD90_TQBS0470_eng.book 21 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 22 -
Settings
Reference
Troubleshooting guide
Before requesting service, please perform the
following steps.
∫ Unit does not respond to remote
control or unit’s buttons.
Disconnect AC adaptor, wait 1 minute, then
reconnect AC adaptor.
The following do not indicate a problem with
this unit:
– Regular disc rotating sounds.
– Image disturbance during search.
∫ Cannot eject disc.
1 While the unit is on
Press and hold
[] on the main unit and the
[0] on the remote control at the same time for
more than 5 seconds.
– POWER LED starts to flash, and “00 RET”
is displayed on the screen.
2 Press [1] (right) repeatedly on the remote
control until “06 FTO” is displayed on the
screen.
3 Press [OK].
To return to the factory defaults.
¾ Select “Yes” in “Restore Default Settings” in
the Setup menu. (> 21)
To return all settings to the factory preset.
¾ Reset the unit as follows:
1 While the unit is on
Press and hold
[] on the main unit and the
[0] on the remote control at the same time for
more than 5 seconds.
– POWER LED starts to flash, and “00 RET”
is displayed on the screen.
2 Press [1] (right) repeatedly on the remote
control until “08 FIN” is displayed on the
screen.
3 Press and hold [OK] for more than 5 seconds.
The remote control does not work properly.
¾ Change the batteries in the remote control.
(> 5)
Other Panasonic products respond to this
remote control.
¾ Change the remote control code of other
Panasonic products to other than code 1.
The TV tuner mode is not displayed when the
TV is turned on.
¾ This phenomenon may occur, depending on
the TV setting, when “Quick Start” is set to
“On”.
¾ Depending on the TV, this phenomenon may
be prevented by reconnecting the HDMI cable
to a different HDMI input terminal or by
changing the HDMI auto connection setting.
This unit is turned off automatically.
¾ To save on electricity, this unit is turned off
automatically if there is no button operation
for about 20 minutes when not playing back
(such as when paused or displaying the
menu, displaying still pictures, etc.).
Do you have the latest firmware installed?
Panasonic is constantly improving the unit’s
firmware to ensure that our customers are
enjoying the latest technology. (> 11)
4
Make the following checks and visit our
website for more information.
http://shop.panasonic.com/support
4
Or visit our website to find a service center.
You can find a service center near you easily
on our website.
Other support information:
“Limited Warranty” (
>
29).
General operation
DMP-BD90_TQBS0470_eng.book 22 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 23 -
Settings
You have forgotten your ratings password.
You want to cancel the ratings level.
¾ The ratings level returns to the factory
defaults.
1 While the unit is on
Press and hold
[] on the main unit and the
[0] on the remote control at the same time for
more than 5 seconds.
– POWER LED starts to flash, and “00 RET”
is displayed on the screen.
2
Press
[1]
(right) repeatedly
on the remote
control
until “
03 VL
” is displayed on the screen.
3 Press [OK].
The TV screen turns black.
¾ In the following cases, HDMI authentication
takes place and a black screen is displayed:
– When “24p Output” is set to “On”.
This unit does not recognize the USB
connection correctly.
¾ Disconnect and re-connect the USB cable. If
it still does not recognize the connection, turn
this unit off and on again.
¾ USB devices may not be recognized by this
unit when connected using the following :
– a USB hub
– a USB extension cable
¾ If you connect USB HDD to this unit, use the
USB cable that is supplied with the HDD.
¾ If the USB HDD is not recognized, the power
to the USB HDD may not be supplied. Supply
power from an external source.
The images from this unit do not appear on
the TV.
Picture is distorted.
¾ An incorrect resolution is selected in “HDMI
Resolution”. Reset the setting as follows:
1 Turn the unit on.
2 Press and hold
[] on the main unit and the
[8] on the remote control at the same time for
more than 5 seconds.
3 Set the item again. (> 18)
– When Dolby Digital Plus, Dolby TrueHD,
and DTS-HD
®
audio are not output properly,
select “Yes” in “Restore Default Settings”
(> 21) and make proper settings.
Video is not output in high-definition.
¾ Confirm that “HDMI Resolution” in the Setup
menu is set properly. (> 18)
DMP-BD90_TQBS0470_eng.book 23 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 24 -
Reference
No subtitles.
¾ When progressive output is on, closed
captions/subtitles cannot be displayed.
The subtitles overlap closed captions
recorded on discs.
¾ Turn off the subtitles or the closed captions.
(> 16, 20)
Closed captions are not displayed.
¾ Confirm that the source content supports CC.
¾ Confirm the “Closed Caption Display” is set to
“On”. (> 17, 20)
¾ Change the “Closed Caption Type” setting.
(> 17, 20)
¾ Confirm the “Analog CC” or “Digital CC” is set
properly (> 17, 20).
A black band is displayed around the edge of
the screen.
The aspect ratio of the screen is abnormal.
¾ Confirm the “TV Aspect” is set properly.
(> 21)
¾ Adjust the aspect setting on the TV.
Cannot switch audio.
¾ The audio cannot switch, if “Digital Audio
Output” is set to “Bitstream”. Set “Digital
Audio Output” to “PCM”. (> 19)
Cannot hear the desired audio type.
¾ Check the connections and the “Digital Audio
Output” settings. (> 10, 19)
Disc cannot be played.
¾ The disc is dirty. (> 5)
¾ The disc is not finalized. (> 7)
Still pictures (JPEG) do not play back
normally.
¾ The images that were edited on the PC, such
as Progressive JPEG, etc., may not be played
back.
Audio
Playback
DMP-BD90_TQBS0470_eng.book 24 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 25 -
Reference
Cannot play.
¾ You inserted an incompatible disc (Discs
recorded in PAL video, etc.).
Cannot display on this unit.
¾ You tried to play a non-compatible image.
¾ Re-insert the media.
No disc inserted.
¾ The disc may be upside down.
$ This operation is not available.
¾ Some operations are unsupported by the unit.
(For example, reverse slow motion, etc.)
When the POWER LED is flashing other than
during power up or down of this unit, check the
message on the TV screen. If a message is not
displayed on the TV screen, determine the type of
the error by checking the way the POWER LED is
flashing.
(Flashes)
¾ The copyright protected disc cannot be
played back.
One of the devices connected to this unit (TV,
amplifier, etc.) does not support copyright
protection.
(Flashes 3 times)
¾ The disc in use cannot be played back since
the copyright information is invalid.
Messages on the screen
POWER LED
Symbols indicate the following states:
Flash
No illumination
Repetition
DMP-BD90_TQBS0470_eng.book 25 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 26 -
Reference
Specifications
≥ Specifications are subject to change without notice.
≥ With certain recording states and folder structures, the play
order may differ or playback may not be possible.
General
Signal system NTSC
Operating
temperature range
i5 oC to i35 oC
(i41 oF to i95 oF)
Operating humidity
range
10 % to 80 % RH
(no condensation)
HDMI AV output
Output connector:
Type A (19 pin) 1 system
USB slot USB2.0:1 system
LASER
Specification
Class I LASER Product
Wave length: 790 nm (CDs)/
660 nm (DVDs)/405 nm (BDs)
Laser power: No hazardous
radiation is emitted with the
safety protection
Power supply
DC 12 V, 0.8 A (DC IN terminal)
Power
consumption
Approx. 11 W
Power
consumption in
standby mode
Approx. 0.5 W
(Quick Start: Off)
Power consumption
in quick start
standby mode
Approx. 3.5 W
(Quick Start: On)
Dimensions
(WkHkD)
245 mmk38.5 mmk175 mm
(Approx. 9 10/16zk1 8/16zk
6 14/16z)
Mass (Weight)
Approx. 0.8 k
g
(1.7 lbs)
File format
File format Extension Reference
MKV
“.MKV”, “.mkv”
≥ The video file and
subtitles text file are
inside the same folder,
and the file names are
the same except for the
file extensions.
≥ Some MKV files may
not be played back
correctly, depending on
the video resolution,
frame rate condition,
subtitle format and so
on.
Subtitles text
file
“.SRT”, “.srt”,
“.SSA”, “.ssa”,
“.ASS”, “.ass”
mp4
(H.264+AAC)
“.MP4”, “.mov”
Some mp4/MPEG files
may not be played back
correctly, depending on
the video resolution,
frame rate condition and
so on.
MPEG
(TS/PS)
“.mpg”, “.mpeg”,
“.m2ts”, “.mts”,
“.ts”
JPEG
“.JPG”, “.jpg”,
“.jpeg”
≥ MOTION JPEG and
Progressive JPEG are
not supported.
≥ You may not be able to
play back the file if you
have edited the folder
structure or the file
name on a PC or other
device.
MP3 “.MP3”, “.mp3”
This unit supports ID3
tags, but only titles, artist
names and album names
can be displayed.
FLAC “.FLAC”, “.flac”
Maximum sampling rate:
192 kHz/24 bit
WAV “.WAV”, “.wav”
Maximum sampling rate:
192 kHz/24 bit
AAC
“.M4A”, “.m4a”,
“.AAC”, “.aac”
This unit supports ID3
tags.
Maximum sampling rate:
48 kHz/320 kbps
WMA “.WMA”, “.wma”
This unit supports ID3
tags.
Maximum sampling rate:
48 kHz/385 kbps
DSD
“.DSF”, “.dsf”,
“.DFF”, “.dff”
2.8 MHz (2 ch/5.1 ch)
ALAC “.M4A”, “.m4a”
Maximum sampling rate:
192 kHz/24 bit/2 ch
DMP-BD90_TQBS0470_eng.book 26 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 27 -
Reference
The audio output differs depending on the
settings on the unit. (> 19, “Digital Audio Output”)
≥ The number of channels listed is the maximum possible
number of output channels when connected to amplifier/
receiver compatible with the respective audio format.
*1
When “BD-Video Secondary Audio” is set to “On”, the
audio will be output as Dolby Digital, DTS Digital
Surround
TM
or 5.1ch PCM.
*2
The maximum possible number of Dolby sound is 2ch PCM.
*3
When “DTS Neo:6” is set to “Cinema” or “Music”, 2ch
(2.1ch) audio can be expanded to 7ch (7.1ch) and output.
(> 19)
Audio information
“Digital Audio Output”
“Bitstream”
“PCM”
*2
Output
channel
*3
Outputs using
original audio
*1
BD-Video :
7.1ch PCM
*1
DVD-Video :
5.1ch PCM
Display languages list
Language code list
ENG
FRA
DEU
ITA
ESP
NLD
SVE
NOR
DAN
POR
RUS
English
French
German
Italian
Spanish
Dutch
Swedish
Norwegian
Danish
Portuguese
Russian
JPN
CHI
KOR
MAL
VIE
THA
POL
CES
SLK
HUN
FIN
Japanese
Chinese
Korean
Malay
Vietnamese
Thai
Polish
Czech
Slovak
Hungarian
Finnish
ARA
HIN
PER
IND
MRI
BUL
RUM
GRE
TUR
Arabic
Hindi
Persian
Indonesian
Maori
Bulgarian
Romanian
Greek
Turkish
Others
Display Language Display Language Display Language
Abkhazian: 6566
Afar: 6565
Afrikaans: 6570
Albanian: 8381
Amharic: 6577
Arabic: 6582
Armenian: 7289
Assamese: 6583
Aymara: 6589
Azerbaijani: 6590
Bashkir: 6665
Basque: 6985
Bengali; Bangla:
6678
Bhutani: 6890
Bihari: 6672
Breton: 6682
Bulgarian: 6671
Burmese: 7789
Byelorussian: 6669
Cambodian: 7577
Catalan: 6765
Chinese: 9072
Corsican: 6779
Croatian: 7282
Czech: 6783
Danish: 6865
Dutch: 7876
English: 6978
Esperanto: 6979
Estonian: 6984
Faroese: 7079
Fiji: 7074
Finnish: 7073
French: 7082
Frisian: 7089
Galician: 7176
Georgian: 7565
German: 6869
Greek: 6976
Greenlandic: 7576
Guarani: 7178
Gujarati: 7185
Hausa: 7265
Hebrew: 7387
Hindi: 7273
Hungarian: 7285
Icelandic: 7383
Indonesian: 7378
Interlingua: 7365
Irish: 7165
Italian: 7384
Japanese: 7465
Javanese: 7487
Kannada: 7578
Kashmiri: 7583
Kazakh: 7575
Kirghiz: 7589
Korean: 7579
Kurdish: 7585
Laotian: 7679
Latin: 7665
Latvian, Lettish:
7686
Lingala: 7678
Lithuanian: 7684
Macedonian: 7775
Malagasy: 7771
Malay: 7783
Malayalam: 7776
Maltese: 7784
Maori: 7773
Marathi: 7782
Moldavian: 7779
Mongolian: 7778
Nauru: 7865
Nepali: 7869
Norwegian: 7879
Oriya: 7982
Pashto, Pushto:
8083
Persian: 7065
Polish: 8076
Portuguese: 8084
Punjabi: 8065
Quechua: 8185
Rhaeto-Romance:
8277
Romanian: 8279
Russian: 8285
Samoan: 8377
Sanskrit: 8365
Scots Gaelic: 7168
Serbian: 8382
Serbo-Croatian:
8372
Shona: 8378
Sindhi: 8368
Singhalese: 8373
Slovak: 8375
Slovenian: 8376
Somali: 8379
Spanish: 6983
Sundanese: 8385
Swahili: 8387
Swedish: 8386
Tagalog: 8476
Tajik: 8471
Tamil: 8465
Tatar: 8484
Telugu: 8469
Thai: 8472
Tibetan: 6679
Tigrinya: 8473
Tonga: 8479
Turkish: 8482
Turkmen: 8475
Twi: 8487
Ukrainian: 8575
Urdu: 8582
Uzbek: 8590
Vietnamese: 8673
Volapük: 8679
Welsh: 6789
Wolof: 8779
Xhosa: 8872
Yiddish: 7473
Yoruba: 8979
Zulu: 9085
Language
Code
Language
Code
Language
Code
DMP-BD90_TQBS0470_eng.book 27 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 28 -
Reference
Licenses
"AVCHD" and the "AVCHD" logo are trademarks of Panasonic
Corporation and Sony Corporation.
Java is a registered trademark of Oracle and/or its affiliates.
Manufactured under license from Dolby Laboratories.
Dolby, Dolby Audio, and the double-D symbol are trademarks of
Dolby Laboratories Licensing Corporation.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS, Inc.
DTS, DTS-HD Master Audio, DTS-HD, and the DTS-HD logo are
registered trademarks or trademarks of DTS, Inc. in the United
States and other countries.
© 2020 DTS, Inc. ALL RIGHTS RESERVED.
The terms HDMI and HDMI High-Definition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks of
HDMI Licensing Administrator, Inc. in the United States and other
countries.
<AVC>
This product is licensed under the AVC Patent Portfolio License for
the personal use of a consumer or other uses in which it does not
receive remuneration to (i) encode video in compliance with the
AVC Standard ("AVC Video") and/or (ii) decode AVC Video that
was encoded by a consumer engaged in a personal activity and/or
was obtained from a video provider licensed to provide AVC Video.
No license is granted or shall be implied for any other use.
Additional information may be obtained from MPEG LA, L.L.C.
See http://www.mpegla.com
<VC-1>
This product is licensed under the VC-1 Patent Portfolio License
for the personal and non-commercial use of a consumer to (i)
encode video in compliance with the VC-1 Standard ("VC-1
Video") and/or (ii) decode VC-1 Video that was encoded by a
consumer engaged in a personal and non-commercial activity and/
or was obtained from a video provider licensed to provide VC-1
Video. No license is granted or shall be implied for any other use.
Additional information may be obtained from MPEG LA, L.L.C.
See http://www.mpegla.com
MPEG Layer-3 audio coding technology licensed from Fraunhofer
IIS and Thomson.
“DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation.
Windows is a trademark or a registered trademark of Microsoft
Corporation in the United States and other countries.
Adobe is a trademark or registered trademark of Adobe Systems
Incorporated in the United States and/or other countries.
Android is a trademark of Google Inc.
This product incorporates the following software:
(1) the software developed independently by or for Panasonic
Corporation,
(2) the software owned by third party and licensed to Panasonic
Corporation,
(3) the software licensed under the GNU General Public License,
Version 2.0 (GPL V2.0),
(4) the software licensed under the GNU LESSER General Public
License, Version 2.1 (LGPL V2.1), and/or
(5) open source software other than the software licensed under
the GPL V2.0 and/or LGPL V2.1.
The software categorized as (3) - (5) are distributed in the hope
that it will be useful, but WITHOUT ANY WARRANTY, without
even the implied warranty of MERCHANTABILITY or FITNESS
FOR A PARTICULAR PURPOSE. Please refer to the detailed
terms and conditions thereof shown in the Player Settings menu.
At least three (3) years from delivery of this product, Panasonic will
give to any third party who contacts us at the contact information
provided below, for a charge no more than our cost of physically
performing source code distribution, a complete machine-readable
copy of the corresponding source code covered under GPL V2.0,
LGPL V2.1 or the other licenses with the obligation to do so, as
well as the respective copyright notice thereof.
Contact Information: oss-cd-requ[email protected]sonic.com
The source code and the copyright notice are also available for
free in our website below.
http://panasonic.net/avc/oss/
(1) MS/WMA
This product is protected by certain intellectual property rights of
Microsoft Corporation and third parties. Use or distribution of such
technology outside of this product is prohibited without a license
from Microsoft or an authorized Microsoft subsidiary and third
parties.
(2) FLAC
The software licenses are displayed when “License” in the Setup
menu is selected. (> 21)
* [HOME] > “Setup” > “Player Settings” > “System” > “System
Information” > “Licenses”
Copyright 2004-2014 Verance Corporation. Cinavia
TM
is a Verance
Corporation trademark. Protected by U.S. Patent 7,369,677 and
worldwide patents issued and pending under license from Verance
Corporation. All rights reserved.
DMP-BD90_TQBS0470_eng.book 28 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 29 -
Reference
Limited Warranty
Panasonic Products Limited Warranty
Limited Warranty Coverage (For USA Only)
If your product does not work properly because of a defect in
materials or workmanship, Panasonic Corporation of North
America (referred to as “the warrantor”) will, for the length of the
period indicated on the chart below, which starts with the date of
original purchase (“warranty period”), at its option either (a) repair
your product with new or refurbished parts, (b) replace it with a
new or a refurbished equivalent value product, or (c) refund your
purchase price. The decision to repair, replace or refund will be
made by the warrantor.
During the “Labor” warranty period there will be no charge for
labor. During the “Parts” warranty period, there will be no charge
for parts. This Limited Warranty excludes both parts and labor for
non-rechargeable batteries, antennas, and cosmetic parts
(cabinet). This warranty only applies to products purchased and
serviced in the United States. This warranty is extended only to the
original purchaser of a new product which was not sold “as is”.
Mail-In Service--Online Repair Request
Online Repair Request
To submit a new repair request and for quick repair status visit our
Web Site at http://shop.panasonic.com/support
When shipping the unit, carefully pack, include all supplied
accessories listed in the Owner’s Manual, and send it prepaid,
adequately insured and packed well in a carton box. When
shipping Lithium Ion batteries please visit our Web Site at http://
shop.panasonic.com/support as Panasonic is committed to
providing the most up to date information. Include a letter detailing
the complaint, a return address and provide a daytime phone
number where you can be reached. A valid registered receipt is
required under the Limited Warranty.
IF REPAIR IS NEEDED DURING THE WARRANTY PERIOD,
THE PURCHASER WILL BE REQUIRED TO FURNISH A
SALES RECEIPT/PROOF OF PURCHASE INDICATING DATE
OF PURCHASE, AMOUNT PAID AND PLACE OF PURCHASE.
CUSTOMER WILL BE CHARGED FOR THE REPAIR OF ANY
UNIT RECEIVED WITHOUT SUCH PROOF OF PURCHASE.
Limited Warranty Limits and Exclusions
This warranty ONLY COVERS failures due to defects in materials
or workmanship, and DOES NOT COVER normal wear and tear or
cosmetic damage. The warranty ALSO DOES NOT COVER
damages which occurred in shipment, or failures which are caused
by products not supplied by the warrantor, or failures which result
from accidents, misuse, abuse, neglect, mishandling,
misapplication, alteration, faulty installation, set-up adjustments,
misadjustment of consumer controls, improper maintenance,
power line surge, lightning damage, modification, introduction of
sand, humidity or liquids, commercial use such as hotel, office,
restaurant, or other business or rental use of the product, or
service by anyone other than a Factory Service Center or other
Authorized Servicer, or damage that is attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS
LISTED UNDER “LIMITED WARRANTY COVERAGE”.
THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE
USE OF THIS PRODUCT, OR ARISING OUT OF ANY
BREACH OF THIS WARRANTY.
(As examples, this excludes damages for lost time, travel to and
from the servicer, loss of or damage to media or images, data or
other memory or recorded content. The items listed are not
exclusive, but for illustration only.)
ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE
WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE
PERIOD OF THE LIMITED WARRANTY.
Some states do not allow the exclusion or limitation of incidental or
consequential damages, or limitations on how long an implied
warranty lasts, so the exclusions may not apply to you.
This warranty gives you specific legal rights and you may also
have other rights which vary from state to state. If a problem with
this product develops during or after the warranty period, you may
contact your dealer or Service Center. If the problem is not
handled to your satisfaction, then write to:
Panasonic Corporation of North America
Consumer Affairs Department 8th Fl.
Two Riverfront Plaza
Newark NJ 07102-5490
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS
LIMITED WARRANTY, ARE YOUR RESPONSIBILITY.
Product registration is not mandatory. Failure to complete the
form does not affect the consumer's warranty rights.
As of November 2021
User memo:
Product or Part Name Parts Labor
Blu-ray Disc Player 1 Year 90 Days
All included Accessories
(Except Non-Rechargeable
Batteries)
90 Days Not Applicable
Only Non-Rechargeable Batteries 10 Days Not Applicable
for all your Panasonic gear
Go to
http://shop.panasonic.com/support
Get everything you need to get the most out of
your Panasonic products
Accessories & Parts for your Camera, Phone, A/V
products, TV, Computers & Networking, Personal
Care, Home Appliances, Headphones, Batteries,
Backup Chargers & more...
Customer Services Directory
For Product Information, Operating Assistance,
Parts, Owner’s Manuals, Dealer and Service info
go to http://shop.panasonic.com/support
For the hearing or speech impaired TTY: 1- 877-833-8855
The model number and serial number of this product can be
found on either the back or the bottom of the unit.
Please note them in the space provided below and keep for
future reference.
MODEL NUMBER DMP-BD90
SERIAL NUMBER
DATE OF PURCHASE
DEALER NAME
DEALER ADDRESS
TELEPHONE NUMBER
DMP-BD90_TQBS0470_eng.book 29 ページ ２０２２年１月２０日 木曜日 午後２時５６分
- 30 -
Reference
Referencia rápida en español
(Spanish Quick Reference)
≥ Conéctelo cuando haya realizado el resto de conexiones.
Ahorro de energía
Esta unidad consume una pequeña cantidad de energía
aunque esté ajustada en el modo de espera (Accionamiento
rápido : Desactivado, aprox. 0,5 W). Para ahorrar energía
cuando no vaya a utilizar la unidad durante mucho tiempo,
desenchúfela de la toma de corriente.
Preparación
Encienda el televisor y seleccione la entrada de
vídeo adecuada en el televisor.
1 Pulse [Í] para encender la unidad.
Después de conectar su nuevo reprodutor y
pulsar el botón de encendido, aparecerá la
pantalla de la configuración básica.
2 Inserte el medio.
Pulse [1].
Pulse [∫].
La posición de detención se memoriza.
Función de reanudación de la reproducción
Pulse
[
1
] para reiniciar la reproducción desde
esta posición.
≥ El punto se anula si se extrae el medio.
≥ En los discos BD-Video incluidos los BD-J, la función
de reanudación de la reproducción no funciona.
Pulse [;].
≥ Pulsar [;] otra vez o [1] para reanudar la reproducción.
Búsqueda
Durante la reproducción, pulse [6] o [5].
Cámara lenta
Durante la pausa, pulse [5].
La velocidad aumenta hasta 5 pasos.
≥ Música y MP3, etc.: La velocidad está fija en un solo paso.
≥ Pulse [1] para volver a la velocidad de reproducción
normal.
Durante la reproducción o la pausa, pulse
[:] o [9].
Salta hasta el título, capítulo o pista que desee
reproducir.
Conexiones básicas
Conexión a un televisor
compatible con HDMI
Conexión a un televisor
compatible con HDMI y a un
amplificador/receptor
compatible con HDMI
Conecte el adaptador de
CA por último
HDMI IN
Cable HDMI
HDMI IN
(ARC)
HDMI OUT
(ARC)
HDMI IN
Amplificador/Receptor
Cable HDMI
A una toma de
corriente doméstica
Adaptador de CA
(incluido)
Reproducción básica
Inicia la reproducción
Parada
Pausa
Búsqueda/Cámara lenta
Salto
DMP-BD90_TQBS0470_eng.book 30 ページ ２０２２年１月２０日 木曜日 午後２時５６分
Index
A Audio
Language . . . . . . . .20, 27
C Closed Caption. . . . .17, 20
F File format. . . . . . . . . . . .26
Firmware update . . . . . . . 11
H HDMI CEC . . . . . . . . . . . .16
L Language
Audio . . . . . . . . . . . . . 19
Menu. . . . . . . . . . . . . . 20
On-screen. . . . . . . . . . 20
Soundtrack . . . . . . . . . 16
Subtitle . . . . . . . . . 16, 20
P
Pop-up menu . . . . . . . . . .
14
Q Quick Start . . . . . . . . . . 21
R Repeat play . . . . . . . . . . 16
Restore Default
Settings . . . . . . . . . . . . . . 21
Resume play function . . . 14
S Subtitle . . . . . . . . . . . . . 16
U USB device . . . . . . . . . . . 7
24p . . . . . . . . . . . . . . . . . . 17
USA Only: Disposal may be regulated in your community due to environmental considerations. For
disposal or recycling information, please visit Panasonic website:
http://www.panasonic.com/environmental/
or call 1-888-769-0149.
Panasonic Corporation of North America
Two Riverfront Plaza, Newark, NJ 07102-5490
http://shop.panasonic.com
TQBS0470
CH0122XZ0
C Panasonic Corporation 2022
pr
DMP-BD90_TQBS0470_eng.book 31 ページ ２０２２年１月２０日 木曜日 午後２時５６分
