OPENING SAFE WITH ACCESS KEY
1. To expose the key access, remove LOGO PLATE screws with
provided Allen wrench.
2. Insert emergency key into key access and turn key clockwise.
Hold the key to open position and turn the handle clockwise
to open the door.
NOTE: Store keys in a secure place. NOT inside of the safe
BATTERIES
1. Remove battery cover on the inside of the safe door
2. Insert 4 new AA batteries into the battery compartment and
pay attention to the polarity of the batteries
3. Replace compartment cover
PIN CODE REGISTRATION
Safe retains TWO 3-8 digit pin codes
1st Personal Pin Code
1. With safe open, press and release the initialization button
located on the inside of the safe door. Yellow indicator light will
be on.
2. On the keypad input 3-8 digit new desired pin code and enter
either "A" or "B" to confirm. Yellow indicator light will turn off.
Pin code registration is completed.
2nd Personal Pin Code
1. On the keypad press "0" twice, then press and release the
initialization button located inside of the safe door. Yellow
indicator light will be on.
2. On the keypad input 3-8 digit new desired pin code and enter
either "A" or "B" to confirm. Yellow indicator light will turn off.
Pin code registration is completed.
TEST REGISTERED PIN CODE
1. With safe door open, and the handle/lock knob in the lock
position. Input 1st personal pin code and enter either "A" or
"B" to confirm.
Successful Registration
- You will hear 2 short beeps
- The green indicator light will flash
- Turn the handle clockwise to retract bolts
Unsuccessful Registration
- You will hear 9 short beeps
- Handle will not move and bolts will stay extended
- Repeat steps PIN CODE REGISTRATION
2. To test 2nd personal pin code, input 2nd registered personal
pin code and enter either "A" or "B" to confirm. See
"Successful Registration" and "Unsuccessful
Registration" above
3. Test a pin code that is not registered to make sure the safe
cannot be unlocked to complete the registration process.
OPENING & CLOSING SAFE WITH PERSONAL PIN
CODES
OPEN:
1. Input 3-8 registered pin code and enter either "A" or "B"
to confirm.
2. Turn the handle to the unlock position and pull the safe
door open
NOTE
After entering pin code, you have 5 seconds to turn the handle
before the mechanism re-lock automatically.
CLOSE:
To close safe, close door and turn handle to the lock position
LOCK OUT
Lock out mode is activated when the wrong personal pin code is
entered
- 3 consecutive times, Lock out mode will last 20 seconds
- 6 consecutive times, Lock out mode will last 5 minutes
CHANGING REGISTERED PIN CODE
Follow steps in "PIN CODE REGISTRATION "
LOW BATTERY WARNING
After entering correct personal pin code, the green and red
indicator lights are flashing this indicates the batteries are low.
NOTE
Safe may still be opened in low battery state depending on
battery voltage. If safe cannot be opened please use
emergency key.
All registered pin codes remain stored
CARE AND MAINTENANCE
- If necessary use a damp cloth to clean the safe. DO NOT use
chemicals or cleaning agents
- Keep liquids away from the control panel. Spills on the control
panel will cause damage and possibly electric shock
- Secure safe in a proper area to prevent it from falling and
causing damage or injury
- DO NOT over stuff the contents of the safe, it can damage the
motor mechanism or the contents
- DO NOT disassemble the product. For all repairs and
maintenance, contact BARSKA Customer Service
- DO NOT place emergency keys inside of safe
Parts of the Inside of the Safe Door
E. Initialization Button F. Battery Compartment
F
E
WARNING: Avoid leaving door open and unattended; it will
allow unauthorized individuals to reprogram the safe,
gaining full access to the safe and contents.
User Manual For
1.10 Cubic Ft. Depository Safe
See reverse side for more information
5/23
BC768
C D
1 2 3 A
4 5 6 0
7 8 9 B
A
L
o
c
k
P
o
s
i
t
i
o
n
U
n
l
o
c
k
P
o
s
i
t
i
o
n
Parts of the Control Panel
C. Indicator Lights
D. Keypad
A. Handle
B. Logo Plate and Key Access
Note: All information, feature, and specification displayed herein
are based on the data available at the time of publishing, thus
they are subject to change without notice. All product pictures
displayed herein are for illustration purposes only. The actual
product may vary due to different circumstances.
B
©2023 BARSKA
®
BARSKA warrants this new safe/lock box to be free of defects in
material and/ or workmanship under normal use for a period of
twelve (12) months from the date product is purchased. This
limited warranty is delimited to repair or replacement only. This
warranty does not cover damage caused by improper installation
or maintenance. BARSKA disclaims all liability for incidental or
consequential damages resulting from misuse, abuse, accident
(such as dropping), fire, flood, service or repairs other than those
performed by BARSKA, acts of nature, or arising out of any breach
of this warranty. Altering the product under any circumstances will
automatically void the warranty.
For service under this limited warranty, please have available the
proof of purchase and the purchase date and location as well as a
detailed description of the problem. This warranty is not
transferable and only applies to the original purchaser with a proof
of purchase from BARSKA or from an authorized dealer. This
warranty applies only to products purchased within the United
States, excluding Alaska, the Hawaiian Islands and all U.S.
territories in the Caribbean and the Pacific.
BARSKA will examine and go through troubleshooting procedures,
product repair or replacement of defective part(s) or units with new
part(s) or provide a new unit, if necessary, during the warranty
period. Reasonable shipping/handling charges may apply and are
based on Barska sole discretion. Purchaser shall be required to
prepay Shipping/handling charges with a check or money order to
BARSKA at time product is returned. The Return Merchandise
Authorization Number (RMA#) and shipping/handling charge
MUST be obtained from BARSKA in advance of return. BARSKA
shall not be liable for damages or loss occurring during shipping.
Please visit via www.barska.com or call 909.445.8168 to obtain
the RMA#, Shipping/handling amount, and for more information.
BARSKA reserves the right to modify or discontinue, without prior
notice to the purchaser, any model or style of the product.
BARSKA will determine, at its sole discretion, whether a product
will be repaired or replaced. BARSKA reserves the right to
discontinue or change any feature of its products at any time. If an
exact replacement or product is not available, BARSKA reserves
the right to provide a part or product that matches as closely as
possible.
LIMITATION OF REMEDIES
BARSKA disclaims any warranties, express or implied, whether of
merchantability or fitness for a particular use, except as expressly
set forth herein. The sole obligation of BARSKA under this limited
warranty shall be to repair or replace the covered product, in
accordance with the terms set forth herein. BARSKA expressly
disclaims any lost profits, general, special, indirect or
consequential damages which may result from breach of any
warranty, or arising out of the use or inability to use any BARSKA
product. Any warranties which are implied and which cannot be
disclaimed shall be limited in duration to a term of one year from
the date of original retail purchase.
Some states do not allow the exclusion or limitation of incidental or
consequential damages or limitation on how long an implied
warranty lasts, so the above limitations and exclusions may not
apply to you.
BARSKA
855 Towne Center Drive, Pomona, CA 91767
SAFE/LOCK BOX
1 YEAR LIMITED WARRANTY
BC767
