Unpacking and Installation Guide
Guide de déballage et d’installation
Guía de desembalaje e instalación
Manual de desempacotamento e instalação
Auspacken und Installationsanleitung
Guida al disimballaggio e all’installazione
x 4
(M4 x L12)
x 4
(M4 x L12)
x 4
(M4 x L12)
x 4
(M4 x L12)
x 2
85″75″
8
9 10
75QN7**C
65.7 inches
(1668.3 mm)
(166.83 cm)
37.6 inches
(955.6 mm)
(95.56 cm)
0.7 inches
(18.3 mm)
(1.83 cm)
40.3 inches
(1023.8 mm)
(102.38 cm)
11.3 inches
(286.4 mm)
(28.64 cm)
74.5 inches
(189 cm)
69.7 lbs
(31.6 kg)
95.7 lbs
(43.4 kg)
75QN8**C
65.7 inches
(1668.3 mm)
(166.83 cm)
37.6 inches
(955.6 mm)
(95.56 cm)
0.7 inches
(17.6 mm)
(1.76 cm)
40.3 inches
(1023.8 mm)
(102.38 cm)
11.3 inches
(286.4 mm)
(28.64 cm)
74.5 inches
(189 cm)
70.3 lbs
(31.9 kg)
96.3 lbs
(43.7 kg)
85QN8**C
74.5 inches
(1893.4 mm)
(189.34 cm)
42.6 inches
(1083.0 mm)
(108.30 cm)
0.7 inches
(17.6 mm)
(1.76 cm)
45.4 inches
(1153.4 mm)
(115.34 cm)
12.0 inches
(303.7 mm)
(30.37 cm)
84.5 inches
(214 cm)
97.9 lbs
(44.4 kg)
127.2 lbs
(57.7 kg)
75QN9**C
65.1 inches
(1654.8 mm)
(165.48 cm)
37.2 inches
(945.6 mm)
(94.56 cm)
0.6 inches
(15.4 mm)
(1.54 cm)
40.0 inches
(1016.9 mm)
(101.69 cm)
11.3 inches
(286.4 mm)
(28.64 cm)
74.5 inches
(189 cm)
68.8 lbs
(31.2 kg)
94.8 lbs
(43.0 kg)
85QN9**C
73.9 inches
(1876.6 mm)
(187.66 cm)
42.2 inches
(1071.5 mm)
(107.15 cm)
0.6 inches
(15.4 mm)
(1.54 cm)
45.1 inches
(1146.8 mm)
(114.68 cm)
12.0 inches
(303.7 mm)
(30.37 cm)
84.5 inches
(214 cm)
96.3 lbs
(43.7 kg)
125.7 lbs
(57.0 kg)
* : 0~9, A~Z
VESA
x (mm) (mm) x 4
75QN7**C
400 x 400
5-6 M8
75QN8**C
85QN8**C 600 x 400
75QN9**C 400 x 400
85QN9**C 600 x 400
* : 0~9, A~Z
15 cm
6 inches
x 2
85″
