Microwave
Oven
Instruction Manual
Read these instructions carefully before using
your microwave oven, and keep it carefully.
If you follow the instructions, your oven will
provide you with many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY
CMO-MMP01M2NDPF(WH)
CONTENTS
01 PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
Specifications
2
3
02 IMPORTANT SAFETY INSTRUCTIONS
03 TO REDUCE THE RISK OF INJURY TO PERSONS GROUNDING INSTALLATION
04 CLEANING
05 UTENSILS
4
7
8
9
Materials you can use in microwave oven
Materials to be avoided in microwave oven
11
06 SETTING UP YOUR OVEN
12
Names of Oven Parts and Accessories
Turntable Installation
12
12
07 INSTALLATION
Countertop Installation
08 OPERATION
Control Panel and Features
09 TROUBLE SHOOTING
13
13
15
16
10
15
2
01
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open
since this can result in harmful exposure to microwave
energy. It is important not to break or tamper with the
safety interlocks.
(b) Do not place any object between the oven front face
and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the
oven must not be operated until it has been repaired by
a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of
cleanliness, its surface could be degraded and affect
the lifespan of the apparatus and lead to a dangerous
situation.
Model
Power supply voltage
Frequency
20 L
230-240 V
50 Hz
CMO-MMP01M2NDPF(WH)
Protection Against Electric Shock Class
I
Cavity volume
Rated power input
Microwave power output
Microwave frequency
Weight
Dimension
1020 W
700 W
2450 MHz
6.1 kg
SPECIFICATIONS
3
434 x 329 x 241 mm
4
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electric shock, injury to
persons or exposure to excessive microwave oven
energy when using your appliance, follow basic
precautions, including the following:
Read and follow the specific:"PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY".
1. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance.
2. Cleaning and user
maintenance shall not be made
by children without
supervision.
3. Keep the appliance and its cord out of reach of children
less than 8 years.
4. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
5. WARNING: Ensure that the appliance is switched off
before replacing the lamp to avoid the possibility of
electric shock.
02
5
7. WARNING: Liquids and other foods must not be heated
in sealed containers since they are liable to explode.
8. When heating food in plastic or paper containers, keep
an eye on the oven due to the possibility of ignition.
9. Only use utensils that are suitable for use in microwave
ovens.
10. If smoke is emitted, switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
11. Microwave heating of beverages can result in delayed
eruptive boiling, therefore care must be taken when
handling the container.
12. The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature checked
before consumption, in order to avoid burns.
13. Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended.
14. The oven should be cleaned regularly and any food
deposits removed.
15. Failure to maintain the oven in a clean condition could
lead to deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a
hazardous situation.
6. WARNING: It is hazardous for anyone other than a
competent person to carry out any service or repair
operation that involves the removal of a cover which
gives protection against exposure to microwave energy.
16. The appliance must not be installed behind a decorative
door in order to avoid overheating. (This is not applicable
for appliances with decorative door.)
6
17. Only use the temperature probe recommended for this
oven. (for ovens provided with a facility to use a
temperature-sensing probe.)
18. The microwave oven shall not be placed in a cabinet
unless it has been tested in a cabinet.
19. The microwave oven must be operated with the
decorative door open. (for ovens with a decorative door.)
20. This appliance is intended to be used in household and
similar applications such as:
- staff kitchen areas in shops, offices and other working
environments;
- by clients in hotels, motels and other residential type
environments;
- farm houses;
- bed and breakfast type environments.
21. The microwave oven is intended for heating food and
beverages. Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth and similar
may lead to risk of injury, ignition or fire.
22. Metallic containers for food and beverages are not
allowed during microwave cooking.
23. The appliance shall not be cleaned with a steam cleaner.
24. The appliance is intended to be used freestanding.
25. The rear surface of appliances shall be placed against a
wall.
Peel off the transparent protective film from the PET door before use.
READ CAREFULLY AND KEEP
FOR FUTURE REFERENCE
an external timer or remote control system.
26. This electrical appliance is not designed to operate with
7
TO REDUCE THE RISK OF INJURY TO
PERSONS
GROUNDING INSTALLATION
DANGER
Electric Shock Hazard
Touching some of the internal components can cause serious
personal injury or death. Do not disassemble this appliance.
WARNING
Electric Shock Hazard
· Improper use of the grounding can result in electric shock.
· Do not plug into an outlet until appliance is properly installed
and grounded.
· This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electric current.
· This appliance is equipped with a cord having a grounding
wire with a grounding plug. The plug must be plugged into
an outlet that is properly installed and grounded.
· Consult a qualified electrician or serviceman if the grounding
instructions are not completely understood or if doubt exists
as to whether the appliance is properly grounded.
· If it is necessary to use an extension cord, use only a 3-wire
extension cord.
1. A short power-supply cord is provided to reduce the risks
resulting from becoming entangled in or tripping over a longer
cord.
2. If a long cord set or extension cord is used:
1) The marked electrical rating of the cord set or extension
cord should be at least as great as the electrical rating of
the appliance.
2) The extension cord must be a grounding-type 3-wire cord.
3) The long cord should be arranged so that it will not drape
over the counter top or tabletop where it can be pulled on
by children or tripped over unintentionally.
03
8
CLEANING
1. Clean the cavity of the oven after using with a slightly
damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must
be cleaned carefully with a damp cloth when they are
dirty.
4. Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of
the glass.
5. Cleaning Tip—For easier cleaning of the cavity walls that
the food cooked can touch: Place half a lemon in a bowl,
add 300ml (1/2 pint) water and heat on 100% microwave
power for 10 minutes. Wipe the oven clean using a soft,
dry cloth.
Be sure to unplug the appliance from the power supply.
04
9
UTENSILS
CAUTION
Personal Injury Hazard
It is hazardous for anyone other than a competent
person to carry out any service or repair operation that
involves the removal of a cover which gives protection
against exposure to microwave energy.
See the instructions on "Materials you can use in
microwave oven or to be avoided in microwave oven.
" There may be certain non-metallic utensils that are
not safe to use for microwaving. If in doubt, you can
test the utensil in question following the procedure
below.
1. Fill a microwave-safe container with 1 cup of cold water
(250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
Utensil Test:
3. Carefully feel the utensil. If the empty utensil is warm, do
not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
05
10
Materials you can use in microwave oven
Dinnerware
Glass jars
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment paper
Plastic
Glassware
Utensils
Browning dish
Plastic wrap
Thermometers
Wax paper
Remarks
Follow manufacturer’s instructions. The bottom of browning
dish must be at least 3/16 inch (5mm) above the turntable.
Incorrect usage may cause the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do
not use cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most
glass jars are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no
metallic trim. Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie.
Make slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven
unattended while cooking.
Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions.
Should be labeled "Microwave Safe". Some plastic containers
soften, as the food inside gets hot. "Boiling bags" and tightly
closed plastic bags should be slit, pierced or vented as
directed by package.
Microwave-safe only. Use to cover food during cooking to
retain moisture. Do not allow plastic wrap to touch food.
Microwave-safe only (meat and candy thermometers).
Use as a cover to prevent splattering and retain moisture.
11
Materials to be avoided in microwave oven
Food carton with
metal handle
Metal or
metaltrimmed
utensils
Paper bags
Plastic foam
Wood
Metal twist ties
Utensils
Aluminum tray
Remarks
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
Metal shields the food from microwave energy. Metal trim
may cause arcing.
May cause arcing and could cause a fire in the oven.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
Wood will dry out when used in the microwave oven and may
split or crack.
12
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Turntable Installation
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
In case of any differences between the appliance and the
pictures in this manual, the product shall prevail.
Peel off the transparent protective film from the PET door before use.
A
C B HD
F
G
E
a. Never place the glass tray upside down.
The glass tray should never be restricted.
b. Both glass tray and turntable ring assembly
must always be used during cooking.
c. All food and containers of food are always
placed on the glass tray for cooking.
d. If glass tray or turntable ring assembly
cracks or breaks, contact your nearest
authorized service center.
Turntable ring assembly
Hub (underside)
Glass tray
Turntable shaft
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
H) Waveguide cover
06
13
INSTALLATION
COUNTERTOP INSTALLATION
Remove all packing material and accessories. Examine the oven
for any damage such as dents or broken door. Do not install if
oven is damaged.
Cabinet:
Remove any protective film found on the microwave oven cabinet
surface. Do not remove Waveguide cover that is attached to the
oven cavity to protect the magnetron.
1. Select a level surface that provide enough open space
for the intake and/or outlet vents.
1 ) The minimum installation height is 85cm.
2) The rear surface of appliance shall be placed against a wall. Leave
a minimum clearance of 30cm above the oven. A minimum
clearance of 20cm is required between the oven and any adjacent
walls.
3) Do not remove the legs from the bottom of the oven.
20 cm
30 cm
20 cm
MIN 85 cm
0 cm
07
14
WARNING
Do not install oven over a range cooktop or other heat-producing
appliance. If installed near or over a heat source, the oven could
be damaged and the warranty would be void.
4) Blocking the intake and/or outlet openings can damage the oven.
5) Place the oven as far away from radios and TV as possible.
Operation of microwave oven may cause interference to your
radio or TV reception.
2. Plug your oven into a standard household outlet. Be
sure the voltage and the frequency is the same as the
voltage and the frequency on the rating label.
The accessible surface may be hot during
operation.
15
NOTICE
When removing food from the oven, please ensure that the oven
power is switched off by turning the timer switch to 0 (zero).
Failure to do so, and operating the microwave oven without food
in it, can result in overheating and damage to the magnetron.
OPERATION
Control Panel and Features
Operation Instructions
1. To set cooking power by turning the power
knob to desired level.
2. To set the time of cooking by turning the
timer knob to desired time per your food
cooking guide.
3. The microwave oven will automatically
start cooking after power level and time
are set.
4. When the cooking time is up, the unit will
"Dong" to stop.
5. If the unit is not in use, always set time to “0”.
Timer
Power
Function/Power Output
17% micro.
33% micro.
55% micro.
77% micro.
100% micro.
Application
Soften ice cream
Soup stew, soften butter or defrost
Stew, fish
Rice, fish, chicken, ground meat
Reheat, milk, boil water, vegetables, beverage
08
16
Normal
Microwave oven interfering
TV reception
Dim oven light
Steam accumulating on
door, hot air out of vents
Oven started accidentally
with no food in
Radio and TV reception may be interfered when
microwave oven operating. It is similar to the
interference of small electrical appliances, like mixer,
vacuum cleaner, and electric fan. It is normal.
In low power microwave cooking, oven light may
become dim. It is normal.
It is forbidden to run the unit without any food inside.
It is very dangerous.
In cooking, steam may come out of food. Most will
get out from vents. But some may accumulate on
cool place like oven door. It is normal.
Trouble
Possible Cause
(1) Power cord is not
plugged in tightly.
Remedy
Unplug. Then plug again after 10
seconds.
Replace fuse or reset circuit breaker
(repaired by professional personnel
of our company)
Oven cannot be
started.
(2) Fuse blowing or
circuit breaker works.
Test outlet with other electrical
appliances.
(3) Trouble with outlet.
Oven does not
heat.
(4) Door is not closed
well.
Close door well.
TROUBLE SHOOTING
According to Waste of Electrical and Electronic Equipment
(WEEE) directive. WEEE should be separately collected
and treated. It at any time in future you need to dispose
of this product please do NOT dispose of this product with
household waste. Please send this product to WEEE
collecting points where available.
09
Contact Information
Customer service: 025117888
