5V-1A SINGLE WIRELESS CHARGING BASE
MODEL NO: WCB3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! To reduce the risk of electric shock, burns or re:
8 DO NOT attempt to open, disassemble, modify or service the charging base.
8 DO NOT crush, puncture, or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
9 Recycle or dispose of used charger as stipulated by local regulation.
2. INTRODUCTION
Single wireless charging base tted with two strong magnets for attaching to a metal surface. Two recessed locking slots on the back for
permanent xture to non-metallic surface or wall. Charges both Model No’s LEDWC03 and LEDWC04 Wireless Rechargeable Inspection
Lamps. Supplied with Type C USB charging cable.
3. SPECIFICATION
Model No.:...................................................................WCB3
Input voltage ................................................................ 5V-1A
Output .......................................................................... 5V-1A
4. OPERATION
NOTE: The wireless charging pad is not compatible with other wireless devices / smart phones etc.
4.1. CHARGING TORCHES
4.1.1. If required, either place the charging base on a metallic surface using the magnets (on underside) to hold it in position or
permanently x it to a non-metallic surface or wall using the two keyhole slots on the rear face.
4.1.2. Place rear face of torch onto the front face of charge base.
4.1.3. Connect charging base to power supply using the cable supplied. Turn on the power source and the LED on the pad will light
blue indicating that the device is charging the torch.
4.1.4. Once the torch indicates full charge, remove from base and disconnect base power supply.
5. MAINTENANCE.Keep
5.1. Keep the charging base clean by wiping with a slightly damp cloth.
5.2. Store charging base in a dry childproof area.
WCB3 Issue 1 14/04/21
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Input and
Charge Indicator
Output
Charge Pad
Magnet Magnet
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
