IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT
CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL
INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions
and maintained properly, give you years of trouble free performance.
Refer to
instruction
manual
Wear eye
protection
Wear a
breathing
mask
Wear protective
clothing
PREMIER INDUSTRIAL DETERGENT
PRESSURE SPRAYER
MODEL NO: SCSG07
1. SAFETY
9 Be aware of the safety requirements for the fluids contained in the vessel, and wear personal protective equipment appropriate to those
fluids.
9 Read and follow all the fluid manufacturers instructions for application and safe use.
9 Label vessel with chemical used, even if water. It is recommended that individual vessels should be used for individual chemicals. Cross
contamination can give unexpected results.
8 DO NOT spray at people, animals or protected insect species.
8 DO NOT spray in high winds, at naked flames or sources of heat.
8 DO NOT use the pressure sprayer for any purpose other than for which it is designed.
8 DO NOT use whilst eating, drinking, smoking; under the influence of drugs, alcohol, intoxicating medication, or if fatigued.
9 DO NOT use to spray flammable liquids, solvents etc.
9 DO NOT allow children to use the sprayer without supervision.
2. INTRODUCTION
Premium quality 1L hand pump sprayer. Manufactured for use with detergents, and
acids. Safety valve with depressurization option. Large 60mm opening for easy relling
and reduced spillage. Translucent tank allows easy measurement of contents using the
side level indicator. Supplied with adjustable ‘cone’ as well as standard ‘fan’ nozzles,
allowing easy and precise application of liquid. Can t other types of nozzles. Robust
composite construction, with ergonomic pump and handle.
3. SPECIFICATION
Model No: ......................................................... SCSG07
Total Capacity: ......................................................... 1.5L
Working Capacity: ....................................................... 1L
4. OPERATION
4.1. Grip the handle and rotate the vessel to separate (fig.1).
4.2. Fill to a maximum of 1L (observe the graduated scale moulded into the vessel).
4.3. Re-attach vessel keeping vertical, rotate until hand tight against neck seal. Pressurise unit by operating pressure pump handle until the
safety valve stars to blow.
4.4. Press the trigger to spray.
4.5. The spray pattern can be changed by unscrewing one nozzle and replacing with the other.
4.6. After use, or before removing vessel, lift the pressure relief valve to vent the pressure.
5. MAINTENANCE
5.1. After use, vent the pressure (see section 4.6.) and rinse out with clean water.
5.2. If the fan nozzle becomes blocked, remove and rinse out with water. DO NOT use a metal object to clear.
5.3. Apply a little light oil to the pump stem periodically.
5.4. Clean the sprayer with a damp cloth: DO NOT use abrasive or solvent cleaners.
5.5. When not in use, store in a cool, dry, childproof location.
g.1
SCSG07 Issue 2 (H,F) 12/07/23
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
