Roadside Parking ANPR Bullet Camera
User Manual
Iniaves on the Use of Video Products
Thank you for choosing Hikvision products.
Technology aects every aspect of our life. As a high-tech company, we are increasingly aware of
the role technology plays in improving business eciency and quality of life, but at the same me,
the potenal harm of its improper usage. For example, video products are capable of recording
real, complete and clear images. This provides a high value in retrospect and preserving real-me
facts. However, it may also result in the infringement of a third party's legimate rights and
interests if improper distribuon, use and/or processing of video data takes place. With the
philosophy of "Technology for the Good", Hikvision requests that every end user of video
technology and video products shall comply with all the applicable laws and regulaons, as well as
ethical customs, aiming to jointly create a beer community.
Please read the following iniaves carefully:
●
Everyone has a reasonable expectaon of privacy, and the installaon of video products should
not be in conict with this reasonable expectaon. Therefore, a warning noce shall be given in
a reasonable and eecve manner and clarify the monitoring range, when installing video
products in public areas. For non-public areas, a third party's rights and interests shall be
evaluated when installing video products, including but not limited to, installing video products
only aer obtaining the consent of the stakeholders, and not installing highly-invisible video
products.
●
The purpose of video products is to record real acvies within a specic me and space and
under specic condions. Therefore, every user shall rst reasonably dene his/her own rights in
such specic scope, in order to avoid infringing on a third party's portraits, privacy or other
legimate rights.
●
During the use of video products, video image data derived from real scenes will connue to be
generated, including a large amount of biological data (such as facial images), and the data could
be further applied or reprocessed. Video products themselves could not disnguish good from
bad regarding how to use the data based solely on the images captured by the video products.
The result of data usage depends on the method and purpose of use of the data controllers.
Therefore, data controllers shall not only comply with all the applicable laws and regulaons and
other normave requirements, but also respect internaonal norms, social morality, good
morals, common pracces and other non-mandatory requirements, and respect individual
privacy, portrait and other rights and interests.
●
The rights, values and other demands of various stakeholders should always be considered when
processing video data that is connuously generated by video products. In this regard, product
security and data security are extremely crucial. Therefore, every end user and data controller,
shall undertake all reasonable and necessary measures to ensure data security and avoid data
leakage, improper disclosure and improper use, including but not limited to, seng up access
Roadside Parking ANPR Bullet Camera User Manual
i
control, selecng a suitable network environment (the Internet or Intranet) where video
products are connected, establishing and constantly opmizing network security.
●
Video products have made great contribuons to the improvement of social security around the
world, and we believe that these products will also play an acve role in more aspects of social
life. Any abuse of video products in violaon of human rights or leading to criminal acvies are
contrary to the original intent of technological innovaon and product development. Therefore,
each user shall establish an evaluaon and tracking mechanism of their product applicaon to
ensure that every product is used in a proper and reasonable manner and with good faith.
Roadside Parking ANPR Bullet Camera User Manual
ii
Legal Informaon
©2022 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
Roadside Parking ANPR Bullet Camera User Manual
iii
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Roadside Parking ANPR Bullet Camera User Manual
iv
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instrucon manual, may cause harmful
interference to radio communicaons. Operaon of this equipment in a residenal area is likely to
cause harmful interference in which case the user will be required to correct the interference at his
own expense.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the EMC Direcve 2014/30/EU, the LVD Direcve 2014/35/EU, the RoHS
Direcve 2011/65/EU.
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the European Union. For proper
recycling, return this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated collecon points. For
more informaon see: www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the baery to your supplier or to a
designated collecon point. For more informaon see: www.recyclethis.info
Roadside Parking ANPR Bullet Camera User Manual
v
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.
Roadside Parking ANPR Bullet Camera User Manual
vi
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
Roadside Parking ANPR Bullet Camera User Manual
vii
Safety Instrucon
Regulatory Informaon
This is a class A product and may cause radio interference in which case the user may be required
to take adequate measures.
Laws and Regulaons
Use of the product must be in strict compliance with the local laws and regulaons. Please shut
down the device in prohibited area.
Power Supply
●
Use of the product must be in strict compliance with the local electrical safety regulaons.
●
Use the power adapter provided by qualied manufacturer. Refer to the product specicaon for
detailed power requirements.
●
It is recommended to provide independent power adapter for each device as adapter overload
may cause over-heang or a re hazard.
●
Make sure that the power has been disconnected before you wire, install, or disassemble the
device in the authorized way according to the descripon in the manual.
●
To avoid electric shock, DO NOT directly touch exposed contacts and components once the
device is powered up.
●
DO NOT use damaged power supply devices (e.g., cable, power adapter, etc.) to avoid electric
shock, re hazard, and explosion.
●
DO NOT directly cut the power supply to shut down the device. Please shut down the device
normally and then unplug the power cord to avoid data loss.
●
The socket-outlet shall be installed near the equipment and shall be easily accessible.
●
Make sure the power supply has been disconnected if the power adapter is idle.
●
Connect to earth before connecng to the power supply.
●
The power source should meet limited power source or PS2 requirements according to IEC
60950-1 or IEC 62368-1 standard.
Transportaon, Use, and Storage
●
To avoid heat accumulaon, good venlaon is required for a proper operang environment.
●
Store the device in dry, well-venlated, corrosive-gas-free, no direct sunlight, and no heang
source environment.
●
Avoid re, water, and explosive environment when using the device.
●
Install the device in such a way that lightning strikes can be avoided. Provide a surge suppressor
at the inlet opening of the equipment under special condions such as the mountain top, iron
tower, and forest.
●
Keep the device away from magnec interference.
●
Avoid device installaon on vibratory surfaces or places. Failure to comply with this may cause
device damage.
Roadside Parking ANPR Bullet Camera User Manual
viii
●
DO NOT touch the heat dissipaon component to avoid burns.
●
DO NOT expose the device to extremely hot, cold, or humidity environments. For temperature
and humidity requirements, see device specicaon.
●
No naked ame sources, such as lighted candles, should be placed on the equipment.
●
DO NOT touch the sharp edges or corners.
●
To prevent possible hearing damage, DO NOT listen at high volume levels for long periods.
Maintenance
●
If smoke, odor, or noise arises from the device, immediately turn o the power, unplug the
power cable, and contact the service center.
●
If the device cannot work properly, contact the store you purchased it or the nearest service
center. DO NOT disassemble or modify the device in the unauthorized way (For the problems
caused by unauthorized modicaon or maintenance, the company shall not take any
responsibility).
●
Keep all packaging aer unpacking them for future use. In case of any failure occurred, you need
to return the device to the factory with the original packaging. Transportaon without the
original packaging may result in damage to the device and the company shall not take any
responsibility.
Network
●
Please enforce the protecon for the personal informaon and the data security as the device
may be confronted with the network security problems when it is connected to the Internet.
Contact us if network security risks occur.
●
Please understand that you have the responsibility to congure all the passwords and other
security sengs about the device, and keep your user name and password.
Lens
●
DO NOT touch the lens with ngers directly in case the acidic sweat of the ngers erodes the
surface coang of the lens.
●
DO NOT aim the lens at the strong light such as sun or incandescent lamp. The strong light can
cause fatal damage to the device.
Baery
●
DO NOT charge the baery connuously more than one week. Overcharging may shorten the
baery life.
●
Baery will discharge gradually if it is not used for a long me. It must be recharged before
using.
●
If the device contains dismountable baery, store the device and baery separately if it is not
used.
●
The baery must be charged and discharged every three months if it is not used, and recharged
to 60% to 70% power percentage to store.
●
The scrapped baery should be discarded in compliance with the local laws and regulaons. If
there are no corresponding laws or regulaons, throw it in a hazardous trash can.
Roadside Parking ANPR Bullet Camera User Manual
ix
●
DO NOT pierce the baery or shorten the electrodes, or it may cause explosion or re hazard.
●
DO NOT dispose of the baery into re or a hot oven, or mechanically crush or cut the baery,
which may result in an explosion.
●
CAUTION: Please use the specic baery supported by the device, or it may cause explosion. If
the baery is damaged and needs to be changed, contact the device manufacturer or local
distributor.
●
If the device contains buon baery, keep it far away from children.
●
DO NOT expose the baery pack or baery combinaon to sunlight, re, or similar overheated
environment. DO NOT leave the baery in an extremely high temperature surrounding
environment or subject the baery to extremely low air pressure, which may result in an
explosion or the leakage of ammable liquid or gas.
●
Keep new and used baeries away from children. If the baery compartment does not close
securely, stop using the product and keep it away from children.
Data
DO NOT disconnect the power during formang, uploading, and downloading. Or les may be
damaged.
Roadside Parking ANPR Bullet Camera User Manual
x
Contents
Chapter 1 Introducon ............................................................................................................... 1
1.1 Product Introducon .............................................................................................................. 1
1.2 Key Feature ............................................................................................................................ 1
Chapter 2 Acvaon and Login ................................................................................................... 2
2.1 Acvaon ............................................................................................................................... 2
2.1.1 Default Informaon ...................................................................................................... 2
2.1.2 Acvate via SADP .......................................................................................................... 2
2.1.3 Acvate via Web Browser ............................................................................................. 3
2.2 Login ...................................................................................................................................... 4
Chapter 3 Parking Space Detecon ............................................................................................. 5
3.1 Set Parking Detecon ............................................................................................................. 5
3.2 Set Capture Parameters ......................................................................................................... 7
3.2.1 Set Captured Image Parameters ................................................................................... 7
3.2.2 Set License Plate Recognion Parameters .................................................................... 8
3.2.3 Set Supplement Light Parameters ................................................................................. 9
3.2.4 Set Picture Composion .............................................................................................. 10
3.2.5 Set Capture Overlay .................................................................................................... 11
3.2.6 Set Composite Picture Overlay .................................................................................... 12
3.2.7 Set Image Encoding Parameters .................................................................................. 13
3.2.8 Set Violaon Diconary .............................................................................................. 14
3.3 Search Picture ...................................................................................................................... 14
Chapter 4 Live View and Local Conguraon ............................................................................ 16
4.1 Live View .............................................................................................................................. 16
4.1.1 Start/Stop Live View .................................................................................................... 16
4.1.2 Select Image Display Mode ......................................................................................... 16
4.1.3 Select Stream Type ...................................................................................................... 16
Roadside Parking ANPR Bullet Camera User Manual
xi
4.1.4 Capture Picture Manually ........................................................................................... 16
4.1.5 Record Manually ......................................................................................................... 16
4.1.6 Enable Digital Zoom .................................................................................................... 17
4.1.7 Enable Regional Focus ................................................................................................. 17
4.1.8 Control Lens ................................................................................................................ 17
4.2 Local Conguraon .............................................................................................................. 18
Chapter 5 Record and Capture .................................................................................................. 21
5.1 Set Storage Path ................................................................................................................... 21
5.1.1 Set Memory Card ........................................................................................................ 21
5.1.2 Set FTP ........................................................................................................................ 22
5.1.3 Set Listening Host ........................................................................................................ 23
5.1.4 Set Cloud Storage ........................................................................................................ 23
5.2 Set Quota ............................................................................................................................. 24
5.3 Set Record Schedule ............................................................................................................ 25
5.4 Set Timed Capture ............................................................................................................... 26
Chapter 6 Encoding and Display ................................................................................................ 27
6.1 Set Video Encoding Parameters ........................................................................................... 27
6.2 Set Image Parameters .......................................................................................................... 28
6.3 Set ICR .................................................................................................................................. 31
6.4 Set ROI ................................................................................................................................. 32
6.5 Set OSD ................................................................................................................................ 34
Chapter 7 Network Conguraon ............................................................................................. 36
7.1 Set IP Address ...................................................................................................................... 36
7.2 Connect to ISUP Plaorm .................................................................................................... 37
7.3 Set DDNS .............................................................................................................................. 39
7.4 Set Port ................................................................................................................................ 39
Chapter 8 Serial Port Conguraon ........................................................................................... 41
8.1 Set RS-485 ............................................................................................................................ 41
Roadside Parking ANPR Bullet Camera User Manual
xii
8.2 Set RS-232 ............................................................................................................................ 41
Chapter 9 Excepon Alarm ....................................................................................................... 43
Chapter 10 Safety Management ............................................................................................... 44
10.1 Manage User ...................................................................................................................... 44
10.2 Set IP Address Filtering ...................................................................................................... 44
10.3 Enable User Lock ................................................................................................................ 45
10.4 Set HTTPS ........................................................................................................................... 45
10.4.1 Create and Install Self-signed Cercate .................................................................. 45
10.4.2 Install Authorized Cercate ..................................................................................... 46
10.5 Set SSH ............................................................................................................................... 46
Chapter 11 Maintenance .......................................................................................................... 47
11.1 View Device Informaon .................................................................................................... 47
11.2 Log ..................................................................................................................................... 47
11.2.1 Enable System Log Service ........................................................................................ 47
11.2.2 Search Log ................................................................................................................. 47
11.3 Upgrade ............................................................................................................................. 48
11.4 Reboot ............................................................................................................................... 48
11.5 Restore Parameters ............................................................................................................ 48
11.6 Synchronize Time ............................................................................................................... 49
11.7 Set DST ............................................................................................................................... 49
11.8 Export Parameters ............................................................................................................. 50
11.9 Import Conguraon File ................................................................................................... 50
11.10 Export Violaon Type File ................................................................................................ 51
11.11 Export Debug File ............................................................................................................. 51
Appendix A. Communicaon Matrix and Device Command ...................................................... 52
Roadside Parking ANPR Bullet Camera User Manual
xiii
Chapter 1 Introducon
1.1 Product Introducon
Roadside Parking ANPR Bullet Camera (hereinaer referred to as "device") supports capture and
recognion of vehicle entering and exing parking spaces, parking over spaces alarm, and parking
over line alarm.
1.2 Key Feature
●
HD camera.
●
H.265/H.264 encoding with high compression rao and exibility. Captured pictures adopt JPEG
encoding and Smart JPEG compression, and the quality of pictures can be set.
●
Built-in TF card. Automac network replenishment of captured pictures.
●
Motor-driven vari-focal lens.
●
Supports capture and recognion of vehicle entering and exing parking spaces, and supports
text overlay (capture me, license plate number, entry and exit status, parking space No., etc.).
●
Supports parking over spaces alarm, and parking over line alarm.
●
Dustproof, waterproof, an-surge protecon, and other funcons.
Roadside Parking ANPR Bullet Camera User Manual
1
Chapter 2 Acvaon and Login
2.1 Acvaon
For the rst-me access, you need to acvate the device by seng an admin password. No
operaon is allowed before acvaon. The device supports mulple acvaon methods, such as
acvaon via SADP soware, web browser, and iVMS-4200 Client.
Note
Refer to the user manual of iVMS-4200 Client for the acvaon via client soware.
2.1.1 Default Informaon
Device default informaon are as follows.
●
Default IP address: 192.168.1.64
●
Default user name: admin
2.1.2 Acvate via SADP
SADP is a tool to detect, acvate, and modify the IP address of the devices over the LAN.
Before You Start
●
Get the SADP soware from the supplied disk or the ocial website ( hps://
www.hikvision.com/ ), and install it according to the prompts.
●
The device and the computer that runs the SADP tool should belong to the same network
segment.
The following steps show how to acvate one device and modify its IP address. For batch acvaon
and IP address modicaon, refer to User Manual of SADP for details.
Steps
1.
Run the SADP soware and search the online devices.
2.
Find and select your device in online device list.
3.
Enter a new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4.
Click Acvate to start acvaon.
Roadside Parking ANPR Bullet Camera User Manual
2
Figure 2-1 Acvate via SADP
Status of the device becomes Acve aer successful acvaon.
5.
Modify IP address of the device.
1) Select the device.
2) Change the device IP address to the same network segment as your computer by either
modifying the IP address manually or checking Enable DHCP.
3) Enter the admin password and click Modify to acvate your IP address modicaon.
2.1.3 Acvate via Web Browser
Use web browser to acvate the device. For the device with the DHCP enabled by default, use
SADP soware or client soware to acvate the device.
Before You Start
Ensure the device and the computer connect to the same LAN.
Steps
1.
Change the IP address of your computer to the same network segment as the device.
2.
Open the web browser, and enter the default IP address of the device to enter the acvaon
interface.
3.
Create and conrm the admin password.
Roadside Parking ANPR Bullet Camera User Manual
3
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4.
Click OK to complete acvaon.
5.
Go to the network sengs interface to modify IP address of the device.
2.2 Login
You can log in to the device via web browser for further operaons such as live view and local
conguraon.
Before You Start
Connect the device to the network directly, or via a switch or a router.
Steps
1.
Open the web browser, and enter the IP address of the device to enter the login interface.
2.
Enter User Name and Password.
3.
Click Login.
4.
Download and install appropriate plug-in for your web browser. Follow the installaon prompts
to install the plug-in.
5.
Reopen the web browser aer the installaon of the plug-in and repeat steps 1 to 3 to login.
6.
Oponal: Click Logout on the upper right corner of the interface to log out of the device.
Roadside Parking ANPR Bullet Camera User Manual
4
Chapter 3 Parking Space Detecon
3.1 Set Parking Detecon
Set parking detecon to detect the parking status of the parking spaces, and capture license plates.
Steps
1.
Go to Conguraon → Device Conguraon → Applicaon Mode .
Figure 3-1 Set Parking Detecon
2.
Select scene according to the actual condion.
Parallel Area
Select it for parallel parking. Vehicles from bidirecons can be captured.
Vercal Area
Select it for backing into a parking space or pulling in head. You need to set the direcon for
capture.
3.
Select Number of Captured Parking Picture.
4.
For parallel parking, set the following parameters.
1) Oponal: Select the following funcons if needed.
Roadside Parking ANPR Bullet Camera User Manual
5
Monitor Opposite Parking Space
Check it if the camera is constructed on the opposite side of the parking spaces. Uncheck it
if the camera is constructed on the same side with the parking spaces.
Inspecon Alarm
Check it to enable the funcon. If the camera is tampered when a vehicle is entering into
the parking space, then the capture will be missed. Aer the camera is not tampered and
the license plate is exposed, a picture will be captured and the alarm will be uploaded.
Close-to-Camera Mode
Check it if the camera is constructed close to the parking spaces.
2) Select Not Parking Space No.
Not Parking Space No.
The space is not used for parking.
3) Oponal: Check the parking violaon behaviors to be detected and set the corresponding
parameters.
Illegal Parking
Check it to capture the illegal parking vehicles.
Sensivity
The higher the sensivity is, the more easily the illegal parking vehicles can be
recognized. Set an appropriate value according to the actual needs to avoid mistaken
capture.
Duraon
If the parking duraon exceeds the set value, it is considered as illegal parking.
Driving on the Lane Line
Check it to capture the vehicle if it is parked over the lane line. Set the sensivity.
Parking over Space Borders
Check it to capture the vehicle if it is parked over the border lines of the parking space. Set
the sensivity.
5.
For vercal parking, set the following parameters.
Lane Direcon
Select Front to capture the license plates on the vehicle head. Select Behind to capture the
license plates on the vehicle tail.
6.
Select the parking space sum to link and enter the lined parking space No. for each parking
space according to the actual needs.
7.
Click Draw Lane Line to adjust the lines on the live view image to make them overlap with the
lines in the actual scene.
8.
Click Save.
Roadside Parking ANPR Bullet Camera User Manual
6
3.2 Set Capture Parameters
3.2.1 Set Captured Image Parameters
Set the parameters of captured images to raise the image quality.
Steps
1.
Go to Conguraon → Device Conguraon → Image Parameters → Picture .
Figure 3-2 Set Captured Image Parameters
2.
Set the captured image parameters.
Window Enhancement
In front light or back light scene, the ash light may not pass through the vehicle window, or
the image eect of the window is bad caused by the light. In this condion, you can check
Window Enhancement. The higher the Brightness Enhancement Level is, the brighter the
window image is. The higher the Defog Level is, the beer the permeability of the window
image is.
Contrast Enhancement
Check Contrast Enhancement to capture clearer images. Select Contrast Enhancement
Mode, and set corresponding parameters.
Roadside Parking ANPR Bullet Camera User Manual
7
Contrast Enhancement Mode Descripon
On The contrast enhancement mode is always enabled.
Time The contrast enhancement mode is enabled during the set
start me and end me. In other me, it is disabled.
Brightness The contrast enhancement mode is enabled according to the
brightness of the surroundings. In this case, you can set
Brightness Level.
Contrast Enhancement Level
The higher the level is, the more the contrast is enhanced.
Halo Suppression Level
Halo suppression is to suppress the halo of the vehicle headlights. The higher the level is,
the more the halo is suppressed.
White Balance Level
It is the white rendion funcon of the device used to adjust the color temperature according
to the environment.
3.2.2 Set License Plate Recognion Parameters
When there are vehicles of dierent types passing from dierent direcons, set the license plate
recognion parameters.
Steps
1.
Go to Conguraon → Device Conguraon → Capture Parameters → License Parameters .
Figure 3-3 Set License Plate Recognion Parameters
2.
Select License Plate Recognion.
-
Select Front Plate when license plates of vehicles from the approaching direcon need to be
recognized.
-
Select Back Plate when license plates of vehicles from the leaving direcon need to be
recognized.
3.
Select Country/Region.
4.
Click Save.
Roadside Parking ANPR Bullet Camera User Manual
8
3.2.3 Set Supplement Light Parameters
Supplement light can enhance the image stabilizaon and adjust the brightness and color
temperature. You can use supplement light to supplement light at night or when the light is dim.
Steps
Note
Only when the constant light is connected, can the set parameters take eect.
1.
Go to Conguraon → Device Conguraon → Capture Parameters → Supplement Light .
Figure 3-4 Set Supplement Light Parameters
2.
Set Duty Rao/Brightness.
Duty Rao/Brightness
It is the me occupaon of the high level in a certain period. The higher the duty rao, the
brighter the supplement light. High duty rao will cut life span of the supplement light.
3.
Set constant light control mode.
-
Check Control Constant Light by Brightness when you want the constant light to be controlled
by detecng the surroundings brightness automacally. Set Brightness Threshold. The higher
the threshold is, the harder the constant light can be enabled.
-
Check Control Constant Light by Schedule when you want the constant light to be enabled
during xed me period. Set the start me and end me.
Note
Controlling constant light by brightness and schedule conict with each other.
4.
Oponal: Check the other I/O to copy the same sengs.
5.
Click Save.
Roadside Parking ANPR Bullet Camera User Manual
9
3.2.4 Set Picture Composion
You can enable the picture composion to composite several pictures into one to make it
convenient to view the violaon captured pictures.
Steps
Note
Funcons and parameters vary with dierent models. The actual device prevails.
1.
Go to Conguraon → Device Conguraon → Capture Parameters → Image Composion .
Figure 3-5 Set Picture Composion
2.
Check Enable Composion.
3.
Set composion types for dierent picture quanes.
4.
Set other composion parameters.
Close-up Zooming Rao
The higher the value is, the larger the close-up is.
Close-up Picture No.
It is the picture where the close-up comes from.
Plate Close-up Oset
The default value is 0, which is recommended to be adopted. The device can capture close-up
pictures according to the set oset when no license plate is recognized.
5.
Oponal: Check Output Close-up Independently to output close-up pictures independently
when the picture composion is not enabled.
Note
Enabling composion and outpung close-up independently funcons conict with each other.
You can only enable one.
6.
Click Save.
Roadside Parking ANPR Bullet Camera User Manual
10
3.2.5 Set Capture Overlay
If you want to overlay informaon on the captured pictures, set capture overlay.
Steps
1.
Go to Conguraon → Device Conguraon → Text Overlay → Capture Overlay Conguraon .
2.
Check Capture Picture Overlay.
Figure 3-6 Set Capture Overlay
3.
Set the font size, color, overlay posion, etc.
Percentage
It is the percentage that the overlaid informaon occupies on the picture.
Overlay Number Zeroizing
When the overlaid number digits are smaller than the xed digits, 0 will be overlaid before
the overlaid number. E.g., the xed digits for lane No. is 2. If the lane No. is 1, 01 will be
overlaid on the picture.
Overlay Plate Close-up
Check it, and a license plate close-up picture will be overlaid on the upper le corner of the
captured picture.
4.
Select the overlay informaon from the list.
Note
The overlay informaon may vary with dierent models. The actual device prevails.
Roadside Parking ANPR Bullet Camera User Manual
11
5.
Set the overlay informaon.
Type You can edit the type.
Overlay Informaon For some informaon types, you can edit the detailed informaon.
Overlay Posion Check it, and the current informaon will be displayed from a new line.
Space Edit the number of space between the current informaon and the
next one from 0 to 255. 0 means there is no space.
Line Break
Characters
Edit the number of characters from 0 to 100 between the current
informaon line and the previous informaon line. 0 means no line
break.
/ Adjust the display sequence of the overlay informaon.
6.
Click Save.
3.2.6 Set Composite Picture Overlay
If you want to overlay informaon on the composite pictures, set composite picture overlay.
Steps
1.
Go to Conguraon → Device Conguraon → Text Overlay → Composite Picture Overlay
Conguraon .
2.
Check Picture Overlay Text.
Figure 3-7 Set Composite Picture Overlay
3.
Set the font size, color, overlay posion, etc.
Roadside Parking ANPR Bullet Camera User Manual
12
Percentage
It is the percentage that the overlaid informaon occupies on the picture. For example, if you
set the percentage to 50, the overlaid informaon in a row will occupy up to half of the image
width, and the excess content will be overlaid from a new line.
4.
Select the overlay informaon from the list.
Note
The overlay informaon varies with dierent models. The actual device prevails.
5.
Set the overlay informaon.
Set Type You can edit the type.
Set Overlay
Informaon
For some informaon types, you can edit the detailed informaon.
Set Overlay Posion If you check it, the current informaon will be displayed from a new
line.
Set Space Edit the number of space between the current informaon and the
next one from 0 to 255. 0 means there is no space.
Set Line Break
Characters
Edit the number of characters from 0 to 100 between the current
informaon line and the previous informaon line. 0 means no line
break.
Adjust overlay
sequence
Click
/ to adjust the display sequence of the overlay
informaon.
6.
Click Save.
3.2.7 Set Image Encoding Parameters
If the captured pictures are not clear, set the resoluon of the captured pictures and the picture
size.
Steps
1.
Go to Conguraon → Device Conguraon → Encoding and Storage → Image Encoding .
Figure 3-8 Set Image Encoding Parameters
2.
Select Capture Resoluon.
3.
Enter the picture size.
JPEG Picture Size
Roadside Parking ANPR Bullet Camera User Manual
13
The size of the compressed captured picture. The actual size is related to the scene
complexity.
Composite Picture Size
The size of the compressed composite picture. The actual size is related to the scene
complexity.
4.
Click Save.
3.2.8 Set Violaon Diconary
Violaon diconary denes corresponding codes of violaon types. You can set the violaon code,
violaon type, and violaon descripon in this secon. The default parameters are recommended.
Steps
Note
Funcons and parameters vary with dierent models. The actual device prevails.
1.
Go to Conguraon → Device Conguraon → System Conguraon → Violaon Diconary .
2.
Set Violaon Code, Violaon Type, and Violaon Descripon according to the actual needs.
3.
Click Save.
Result
The violaon code and descripon will be displayed on the captured picture when the
corresponding violaon happens.
3.3 Search Picture
You can search the captured pictures stored in the storage card and export the pictures you need.
Before You Start
Install the storage card, and ensure the storage status is normal.
Steps
1.
Click Picture.
2.
Set the search condions such as Lane No., Vehicle Type, etc.
3.
Click Search.
The searched pictures informaon will be displayed in the picture list.
Note
You can go to Conguraon → Local Conguraon to get the saving path.
4.
Oponal: Click to preview the selected picture.
You can view the captured picture and the related informaon such as the capture me, lane
No., license plate number, etc.
Roadside Parking ANPR Bullet Camera User Manual
14
5.
Oponal: Check a picture or several pictures and click Export Picture to export it/them to the
saving path you have set.
The downloaded picture(s) will be marked as "Downloaded". You can go to Conguraon →
Local Conguraon to get the saving path of downloaded pictures.
Roadside Parking ANPR Bullet Camera User Manual
15
Chapter 4 Live View and Local Conguraon
4.1 Live View
4.1.1 Start/Stop Live View
Click to start live view. Click to stop live view.
4.1.2 Select Image Display Mode
Click to display the image in 4:3/16:9/original/self-adapve display mode.
4.1.3 Select Stream Type
Click / / to select the stream type. It is recommended to select the main
stream to get the high-quality image when the network condion is good, and select the sub-
stream to get the uent image when the network condion is not good enough. The third stream is
the custom stream.
Note
The supported stream types vary with dierent models. The actual device prevails.
4.1.4 Capture Picture Manually
You can capture pictures manually on the live view image and save them to the computer.
Steps
1.
Click to start live view.
2.
Click to capture a picture.
3.
Oponal: Click Conguraon → Local Conguraon to view the saving path of snapshots in live
view.
4.1.5 Record Manually
You can record videos manually on the live view image and save them to the computer.
Steps
1.
Click
to start live view.
2.
Click to start recording.
3.
Click to stop recording.
Roadside Parking ANPR Bullet Camera User Manual
16
4.
Oponal: Click Conguraon → Local Conguraon to view the saving path of record les.
4.1.6 Enable Digital Zoom
You can enable digital zoom to zoom in a certain part of the live view image.
Steps
1.
Click to start live view.
2.
Click to enable digital zoom.
3.
Place the cursor on the live view image posion which needs to be zoomed in. Drag the mouse
rightwards and downwards to draw an area.
The area will be zoomed in.
4.
Click any posion of the image to restore to normal image.
5.
Click to disable digital zoom.
4.1.7 Enable Regional Focus
Steps
1.
Click .
2.
Drag the cursor from the upper le corner to the lower right corner to select the area that needs
to be focused.
Result
The selected area is focused.
4.1.8 Control Lens
Click
to show/hide the lens control interface.
Figure 4-1 Control Lens
The buon descripons are as follows:
Roadside Parking ANPR Bullet Camera User Manual
17
Table 4-1 Buon Descripon
Buon Descripon
Zoom + and Zoom –
●
Hold to zoom in the scene.
●
Hold to zoom out the scene.
Focus + and Focus –
●
Hold under the manual focus mode to make near objects
become clear and distant objects become vague.
●
Hold to make distant objects become clear and near
objects become vague.
Iris + and Iris –
●
Hold to increase the iris diameter when in a dark
environment.
●
Hold to decrease the iris diameter when in a bright
environment.
Auxiliary buons: one-touch focus and lens inializaon.
Note
Unmenoned buons are all reserved buons.
4.2 Local Conguraon
Go to Conguraon → Local Conguraon to set the live view parameters and change the saving
paths of videos, captured pictures, scene pictures, etc.
Roadside Parking ANPR Bullet Camera User Manual
18
Figure 4-2 Local Conguraon
Protocol
Select the network transmission protocol according to the actual needs.
TCP
Ensures complete delivery of streaming data and beer video quality, yet the real-me
transmission will be aected.
UDP
Provides real-me audio and video streams.
Live View Performance
Least Delay
The video is real-me, but the video uency may be aected.
Balanced
Balanced mode considers both the real me and uency of the video.
Best Fluency
When the network condion is good, the video is uent.
Rule Informaon
If you enable the rule informaon, tracking frames will be displayed on the live view interface
when there are vehicles passing.
Feature Informaon
Roadside Parking ANPR Bullet Camera User Manual
19
If you enable the feature informaon, informaon of the lane, trac ow, speed, etc. will be
displayed on the live view interface.
Record File Size
Select the packed size of the manually recorded video les. Aer the selecon, the max. record
le size is the value you selected.
Save record les to
Set the saving path for the manually recorded video les.
Save snapshots in live view to
Set the saving path of the manually captured pictures in live view mode.
Save downloaded pictures to
Set the saving path for the downloaded pictures.
Save scene picture to
Set the saving path of the captured pictures in the Real-Time Status and Trac Flow Stascs
interface.
Note
The parameters vary with dierent models. The actual device prevails.
Roadside Parking ANPR Bullet Camera User Manual
20
Chapter 5 Record and Capture
5.1 Set Storage Path
5.1.1 Set Memory Card
If you want to store the les to the memory card, make sure you insert and format the memory
card in advance.
Before You Start
Insert the memory card to the device.
Steps
1.
Go to Conguraon → Device Conguraon → Encoding and Storage → Storage Management .
Figure 5-1 Set Memory Card
2.
Format the memory card in two ways.
-
Check the memory card, and click Format to format it manually.
Note
For the newly installed memory card, you need to format it manually before using it normally.
-
If you want to format the memory card automacally when the card is abnormal, check Auto-
Inialize Redundant Storage.
3.
Oponal: If the device has been connected to the plaorm, and you want to upload the
memory card informaon automacally, check Auto-Upload Data in Redundant Storage.
4.
Click Save.
Roadside Parking ANPR Bullet Camera User Manual
21
5.1.2 Set FTP
Set FTP parameters if you want to upload the captured pictures to the FTP server.
Before You Start
Set the FTP server, and ensure the device can communicate normally with the server.
Steps
1.
Go to Conguraon → Device Conguraon → Encoding and Storage → FTP .
Figure 5-2 Set FTP
2.
Oponal: Check Upload Addional Informaon to FTP, and then the related informaon can be
aached when uploading.
3.
Enable the FTP server.
4.
Set FTP parameters.
1) Enter Server Address and Port.
2) Enter User Name and Password, and conrm the password.
3) Select Directory Structure.
Note
If mulple directories are needed, you can customize the directory name.
5.
Oponal: Check Not Upload Plate Close-up if the license plate close-up pictures are not needed
to upload.
6.
Set the name rule and separator according to the actual needs.
7.
Oponal: Edit OSD informaon which can be uploaded to the FTP server with the pictures to
make it convenient to view and disnguish the data.
8.
Click Save.
Roadside Parking ANPR Bullet Camera User Manual
22
5.1.3 Set Listening Host
The listening host can be used to receive the uploaded informaon and pictures of the device
arming alarm.
Before You Start
The listening service has been enabled for the listening host, and the network communicaon with
the device is normal.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → Network Parameters .
Figure 5-3 Set Listening Host
2.
Set ANPR IP Address/Domain and ANPR Port if you need to upload the alarm informaon and
pictures.
3.
Set Listening Host IP Address and Listening Host Port, and check Enable Picture Uploading
Listening if you need to upload the alarm informaon and pictures.
Note
ANPR and listening conict with each other. When you enable listening host, pictures will be
uploaded via listening host in priority. When you disable listening and have set ANPR IP address
and port, pictures will be uploaded via ANPR protocol.
4.
Click Save.
5.1.4 Set Cloud Storage
Cloud storage is a kind of network storage. It can be used as the extended storage to save the
captured pictures.
Before You Start
Arrange the cloud storage server.
Steps
1.
Go to Conguraon → Device Conguraon → Encoding and Storage → Cloud Storage .
Roadside Parking ANPR Bullet Camera User Manual
23
Figure 5-4 Set Cloud Storage
2.
Check Enable.
3.
Select Version.
4.
Set the server parameters.
1) Enter Access Server IP Address and Port No.
2) If you select V2.0, enter accessKey and secretKey of the resource pool.
Note
If you select V1.0, enter User Name and Password.
3) Enter the ID according to the storage area No. of the server.
5.
Click Save.
5.2 Set Quota
Set the video and picture rao in the storage.
Before You Start
Install the memory card.
Steps
1.
Go to Conguraon → Device Conguraon → Encoding and Storage → Storage Management .
2.
Set Capture Quota Rao and Video Quota Rao according to the actual needs.
Note
The percentage sum of the capture and video quota rao should be 100%.
3.
Click Save.
What to do next
Format the memory card aer the sengs.
Roadside Parking ANPR Bullet Camera User Manual
24
5.3 Set Record Schedule
Set record schedule to record video automacally during congured me periods.
Before You Start
Install the memory card, and you are recommended to set the video quota rao as not 0.
Steps
1.
Go to Conguraon → Device Conguraon → Encoding and Storage → Record Schedule .
Figure 5-5 Set Record Schedule
2.
Oponal: Check Enable Recording Overwring.
When the storage is full, the earliest videos will be overwrien.
3.
Check Enable Record Schedule.
4.
Click Edit to edit the record schedule.
1) Select Customize.
2) Set the start me and end me.
3) Oponal: Select the other days and click Copy to copy the sengs to other days.
4) Click OK.
5.
Click Save.
Roadside Parking ANPR Bullet Camera User Manual
25
5.4 Set Timed Capture
You can enable med capture of the device. Then the device will capture a picture every the set
interval.
Steps
1.
Go to Conguraon → Device Conguraon → Encoding and Storage → Timing Capture .
2.
Check Enable Timed Capture.
3.
Enter Capture Interval.
4.
Click Save.
Result
The device will capture a picture every the set interval.
Roadside Parking ANPR Bullet Camera User Manual
26
Chapter 6 Encoding and Display
6.1 Set Video Encoding Parameters
Set video encoding parameters to adjust the live view and recording eect.
●
When the network signal is good and the speed is fast, you can set high resoluon and bitrate to
raise the image quality.
●
When the network signal is bad and the speed is slow, you can set low resoluon, bitrate, and
frame rate to guarantee the image uency.
●
When the network signal is bad, but the resoluon should be guaranteed, you can set low
bitrate and frame rate to guarantee the image uency.
●
Main stream stands for the best stream performance the device supports. It usually oers the
best resoluon and frame rate the device can do. But high resoluon and frame rate usually
means larger storage space and higher bandwidth requirements in transmission. Sub-stream
usually oers comparavely low resoluon opons, which consumes less bandwidth and storage
space. Third stream is oered for customized usage.
Steps
1.
Go to Conguraon → Device Conguraon → Encoding and Storage → Video Encoding .
2.
Set the parameters for dierent streams.
Stream Type
Only video stream is selectable.
Bitrate
Select relavely large bitrate if you need good image quality and eect, but more storage
spaces will be consumed. Select relavely small bitrate if storage requirement is in priority.
Frame Rate
It is to describe the frequency at which the video stream is updated and it is measured by
frames per second (fps). A higher frame rate is advantageous when there is movement in the
video stream, as it maintains image quality throughout.
Resoluon
The higher the resoluon is, the clearer the image will be. Meanwhile, the network
bandwidth requirement is higher.
SVC
Scalable Video Coding (SVC) is an extension of the H.264/AVC and H.265 standard. Enable the
funcon and the device will automacally extract frames from the original video when the
network bandwidth is insucient.
Bitrate Type
Select the bitrate type to constant or variable.
Roadside Parking ANPR Bullet Camera User Manual
27
Video Quality
When bitrate type is variable, 6 levels of video quality are selectable. The higher the video
quality is, the higher requirements of the network bandwidth.
Prole
Under the same bitrate, the higher the prole is, the higher the image quality is, and the
higher the requirement of the network bandwidth is.
I Frame Interval
It refers to the number of frames between two key frames. The larger the I frame interval is,
the smaller the stream uctuaon is, but the image quality is not that good.
Video Encoding
The device supports mulple video encoding types, such as H.264, H.265, and MJPEG.
Supported encoding types for dierent stream types may dier. H.265 is a new encoding
technology. Compared with H.264, it reduces the transmission bitrate under the same
resoluon, frame rate, and image quality.
3.
Click Save.
6.2 Set Image Parameters
You can adjust the image parameters to get clear image.
Steps
Note
The supported parameters may vary with dierent models. The actual device prevails.
1.
Go to Conguraon → Device Conguraon → Image Parameters → General Parameters /
Conguraon → Device Conguraon → Image Parameters → Video .
Roadside Parking ANPR Bullet Camera User Manual
28
Figure 6-1 Set General Parameters
Figure 6-2 Set Video Image Parameters
2.
Adjust the parameters.
Saturaon
Roadside Parking ANPR Bullet Camera User Manual
29
It refers to the colorfulness of the image color.
Sharpness
It refers to the edge contrast of the image.
White Balance
It is the white rendion funcon of the device used to adjust the color temperature according
to the environment.
WDR Mode
Wide Dynamic Range (WDR) can be used when there is a high contrast of the bright area and
the dark area of the scene.
Select WDR Switch and set corresponding parameters according to your needs.
On
Set WDR Level. The higher the level is, the higher the WDR strength is.
Time
Enable WDR according to the me.
Brightness
Set Light Threshold. When the brightness reaches the threshold, WDR will be enabled.
Iris Mode
Only manual iris mode is supported.
Brightness Enhancement at Night
The scene brightness will be enhanced at night automacally.
Enable Defog
Enable defog to get a clear image in foggy days.
Light Compensaon on License Plate
Check it. The light compensaon on license plates can be realized, and various light
supplement condions can be adapted via seng license plate expectant brightness and
supplement light correcon coecient. The higher the sensivity is, the easier this funcon
can be enabled.
Enable Gamma Correcon
The higher the gamma correcon value is, the stronger the correcon strength is.
Enable Black and White Mode at Night
When ICR is in night mode, you can check it to keep the video in black and white mode.
Brightness
It refers to the max. brightness of the image.
Contrast
It refers to the contrast of the image. Set it to adjust the levels and permeability of the image.
Shuer Speed
Roadside Parking ANPR Bullet Camera User Manual
30
If the shuer speed is quick, the details of the moving objects can be displayed beer. If the
shuer speed is slow, the outline of the moving objects will be fuzzy and trailing will appear.
Gain
It refers to the upper limit value of liming image signal amplicaon. It is recommended to
set a high gain if the illuminaon is not enough, and set a low gain if the illuminaon is
enough.
3D DNR
Digital Noise Reducon (DNR) reduces the noise in the video stream.
In Normal Mode, the higher the 3D DNR Level is, the stronger the noise will be reduced. But
if it is too high, the image may become fuzzy.
In Expert Mode, set Spaal Intensity and Time Intensity. If the special intensity is too high,
the outline of the image may become fuzzy and the details may lose. If the me intensity is
too high, trailing may appear.
2D DNR
The higher the 2D DNR Level is, the stronger the noise will be reduced. But if it is too high,
the image may become fuzzy.
Video Standard
Select the video standard according to the actual power supply frequency.
6.3 Set ICR
ICR adopts mechanical IR lter to lter IR in the day to guarantee the image eect, and to remove
the IR lter at night to guarantee full-spectrum rays can get through the device.
Steps
1.
Go to Conguraon → Device Conguraon → Image Parameters → ICR .
2.
Select ICR Mode.
Auto-switch Switches to ICR mode automacally at night or in dark light condions.
Manual Switch Switches to the day or night manually.
Scheduled Switch Set day/night mode, start me, and end me to switch to ICR mode only
during the set me period.
Do not switch Disable ICR mode.
3.
Click Save.
Roadside Parking ANPR Bullet Camera User Manual
31
6.4 Set ROI
ROI (Region of Interest) encoding helps to assign more encoding resources to the region of
interest, thus to increase the quality of the ROI whereas the background informaon is less
focused.
Before You Start
Please check the video encoding type. ROI is supported when the video encoding type is H.264 or
H.265.
Steps
1.
Go to Conguraon → Device Conguraon → Encoding and Storage → ROI .
Roadside Parking ANPR Bullet Camera User Manual
32
Figure 6-3 Set ROI
2.
Select Stream Type.
3.
Set ROI region.
1) Check Enable.
2) Select Area Code.
3) Click Draw Area.
4) Drag the mouse on the live view image to draw the xed area.
5) Select the xed area that needs to be adjusted and drag the mouse to adjust its posion.
6) Click Stop Drawing.
4.
Enter Area Name and select ROI Level.
Roadside Parking ANPR Bullet Camera User Manual
33
Note
The higher the ROI level is, the clearer the image of the detected area is.
5.
Click Save.
6.
Oponal: Select other area codes and repeat the steps above if you need to draw mulple xed
areas.
6.5 Set OSD
You can customize OSD informaon on the live view.
Steps
1.
Go to Conguraon → Device Conguraon → Text Overlay → OSD Sengs .
Figure 6-4 Set OSD
2.
Set OSD aribute, font size, alignment, etc.
3.
Oponal: Set the display content.
1) Enter Display Name.
2) Check Display Date, and set the me and date format.
3) Check Display Week.
4) Check Millisecond.
4.
Oponal: Check the display item(s) and enter the informaon in the text eld(s).
Roadside Parking ANPR Bullet Camera User Manual
34
5.
Drag the red frames on the live view image to adjust the OSD posions.
6.
Click Save.
Result
The set OSD will be displayed in live view image and recorded videos.
Roadside Parking ANPR Bullet Camera User Manual
35
Chapter 7 Network Conguraon
7.1 Set IP Address
IP address must be properly congured before you operate the device over network. IPv4 and IPv6
are both supported. Both versions can be congured simultaneously without conicng to each
other.
Go to Conguraon → Device Conguraon → System → Network Parameters .
Figure 7-1 Set IP Address
NIC Type
Select a NIC (Network Interface Card) type according to your network condion.
IPv4
Two IPv4 modes are available.
DHCP
The device automacally gets the IPv4 parameters from the network if you check DHCP. The
device IP address is changed aer enabling the funcon. You can use SADP to get the device IP
address.
Roadside Parking ANPR Bullet Camera User Manual
36
Note
The network that the device is connected to should support DHCP (Dynamic Host
Conguraon Protocol).
Manual
You can set the device IPv4 parameters manually. Enter IPv4 Address, IPv4 Subnet Mask, and
IPv4 Default Gateway.
IPv6
Three IPv6 modes are available.
Route Adversement
The IPv6 address is generated by combining the route adversement and the device Mac
address.
Note
Route adversement mode requires the support from the router that the device is connected
to.
DHCP
The IPv6 address is assigned by the server, router, or gateway.
Manual
Enter IPv6 Address, IPv6 Subnet Mask, and IPv6 Default Gateway. Consult the network
administrator for required informaon.
MTU
It stands for maximum transmission unit. It is the size of the largest protocol data unit that can
be communicated in a single network layer transacon.
The valid value range of MTU is 1280 to 1500.
Mulcast
Mulcast is group communicaon where data transmission is addressed to a group of
desnaon devices simultaneously. Aer seng the IP address of the mulcast host, you can
send the source data eciently to mulple receivers.
DNS
It stands for domain name server. It is required if you need to visit the device with domain
name. And it is also required for some applicaons (e.g., sending email). Set Preferred DNS
Server properly if needed.
7.2 Connect to ISUP Plaorm
ISUP is a plaorm access protocol. The device can be remotely accessed via ISUP plaorm.
Roadside Parking ANPR Bullet Camera User Manual
37
Before You Start
●
Create the device ID on ISUP plaorm.
●
Ensure the device can communicate with the plaorm normally.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → ISUP .
Figure 7-2 Connect to ISUP Plaorm
2.
Check Enable.
3.
Select Address Type.
Domain Name
When the server is in extranet, and the IP address is dynamic, you can select it.
IP Address
When the server IP address is stac, you can select it.
4.
Enter the parameters below.
Plaorm IP Address/Plaorm Domain Name
Enter the stac IP address or domain name of ISUP plaorm.
Plaorm Port
The default value is 7660.
Camera No.
The ID of the device registered on the ISUP plaorm. If you leave it empty, the device will be
logged in to the plaorm with serial No.
Encrypon Key
The device password registered on the plaorm.
5.
Click Save.
Roadside Parking ANPR Bullet Camera User Manual
38
7.3 Set DDNS
You can use the Dynamic DNS (DDNS) for network access. The dynamic IP address of the device can
be mapped to a domain name resoluon server to realize the network access via domain name.
Before You Start
●
Register the domain name on the DDNS server.
●
Set the LAN IP address, subnet mask, gateway, and DNS server parameters. Refer to "Set IP
Address" for details.
●
Complete port mapping. The default port is 80, 8000, and 554.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → DDNS .
Figure 7-3 Set DDNS
2.
Check Enable DDNS.
3.
Enter the server address and other informaon.
4.
Click Save.
5.
Access the device.
By Browsers Enter the domain name in the browser address bar to access the device.
By Client Soware Add domain name to the client soware. Refer to the client soware
manual for specic adding methods.
7.4 Set Port
The device port can be modied when the device cannot access the network due to port conicts.
Roadside Parking ANPR Bullet Camera User Manual
39
Cauon
Do not modify the default port parameters at will, otherwise the device may be inaccessible.
Go to Conguraon → Device Conguraon → System Conguraon → Port for port sengs.
Figure 7-4 Set Port
HTTP Port
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.168.1.64:81 in the browser for login.
RTSP Port
It refers to the port of real-me streaming protocol.
SDK Port
It refers to the port through which the client adds the device.
SADP Port
It refers to the port through which the SADP soware searches the device.
Roadside Parking ANPR Bullet Camera User Manual
40
Chapter 8 Serial Port Conguraon
8.1 Set RS-485
Set RS-485 parameters if the device has been connected to a vehicle detector or other RS-485
devices.
Before You Start
The corresponding device has been connected via the RS-485 serial port.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → Serial Ports .
Figure 8-1 Set RS-485
2.
Set Baud Rate, Data Bit, Stop Bit, etc.
Note
The parameters should be same with those of the connected device.
3.
Select Working Mode.
Applicaon Mode Trigger
Select it if the vehicle detector has been connected via the RS-485 serial port.
Transparent Transmission
Select it, and the network command can be transmied to RS-485 control command via the
RS-485 serial port.
GPS
The GPS devices are connected to the RS-485 serial port of the device for receiving locaon
data.
4.
Click Save.
8.2 Set RS-232
Set RS-232 parameters if you need to debug the device via RS-232 serial port, or peripheral devices
have been connected.
Before You Start
The corresponding device has been connected via the RS-232 serial port.
Roadside Parking ANPR Bullet Camera User Manual
41
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → Serial Ports .
2.
Click Advanced Sengs.
Figure 8-2 Set RS-232
3.
Set Baud Rate, Data Bit, Stop Bit, etc.
Note
The parameters should be same with those of the connected device.
4.
Select Working Mode.
Console
Select it when you need to debug the device via RS-232 serial port.
Transparent Channel
Select it, and the network command can be transmied to RS-232 control command via the
RS-232 serial port.
Narrow Band
Reserved.
5.
Click Save.
Roadside Parking ANPR Bullet Camera User Manual
42
Chapter 9 Excepon Alarm
Set excepon alarm when the network is disconnected, the IP address is conicted, etc.
Steps
Note
The supported excepon types vary with dierent models. The actual device prevails.
1.
Go to Conguraon → Device Conguraon → Events → Excepon Event .
2.
Select the excepon type(s) and the linkage method.
3.
Click Save.
Roadside Parking ANPR Bullet Camera User Manual
43
Chapter 10 Safety Management
10.1 Manage User
The administrator can add, modify, or delete other accounts, and grant dierent permissions to
dierent user levels.
Steps
1.
Go to Conguraon → Device Conguraon → User Management .
2.
Add a user.
1) Click Add.
2) Enter User Name and select Level.
3) Enter Admin Password, Password, and conrm the password.
Cauon
To increase security of using the device on the network, please change the password of your
account regularly. Changing the password every 3 months is recommended. If the device is
used in high-risk environment, it is recommended that the password should be changed every
month or week.
4) Assign remote permission to users based on needs.
User
Users can be assigned permission of viewing live video and changing their own passwords,
but no permission for other operaons.
Operator
Operators can be assigned all permission except for operaons on the administrator and
creang accounts.
5) Click OK.
3.
You can do the following operaons.
-
Select a user and click Modify to change the password and permission.
-
Select a user and click Delete to delete the user.
10.2 Set IP Address Filtering
You can set the IP addresses allowable and not allowable to access the device.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → Service .
2.
Check Enable IP Address Filtering.
3.
Set Filtering Mode.
Blocklist Mode
Roadside Parking ANPR Bullet Camera User Manual
44
The added IP addresses are not allowed to access the device.
Allowlist Mode
The added IP addresses are allowed to access the device.
4.
Click Add, enter the IP address, and click Add.
Figure 10-1 Set IP Address Filtering
5.
Oponal: Edit, delete, or clear the added IP addresses.
6.
Click Save.
10.3 Enable User Lock
To raise the data security, you are recommended to lock the current IP address.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → Service .
2.
Check Enable User Lock.
3.
Click Save.
Result
When the mes you entered incorrect passwords have reached the limit, the current IP address
will be locked automacally.
10.4 Set HTTPS
10.4.1 Create and Install Self-signed Cercate
HTTPS is a network protocol that enables encrypted transmission and identy authencaon,
which improves the security of remote access.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → HTTPS .
2.
Select Create Self-signed Cercate.
3.
Click Create.
4.
Follow the prompt to enter Country/Region, Hostname/IP, Validity, and other parameters.
5.
Click OK.
Roadside Parking ANPR Bullet Camera User Manual
45
Result
The device will install the self-signed cercate by default.
10.4.2 Install Authorized Cercate
If the demand for external access security is high, you can create and install authorized cercate
via HTTPS protocol to ensure the data transmission security.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → HTTPS .
2.
Select Create cercate request rst and connue the installaon.
3.
Click Create.
4.
Follow the prompt to enter Country/Region, Hostname/IP, Validity, and other parameters.
5.
Click Download to download the cercate request and submit it to the trusted authority for
signature.
6.
Import cercate to the device.
-
Select Signed cercate is available, start the installaon directly. Click Browse and Install to
import the cercate to the device.
-
Select Create the cercate request rst and connue the installaon. Click Browse and
Install to import the cercate to the device.
7.
Click Save.
10.5 Set SSH
To raise network security, disable SSH service. The conguraon is only used to debug the device
for the professionals.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → Service .
2.
Uncheck Enable SSH Service.
3.
Click Save.
Roadside Parking ANPR Bullet Camera User Manual
46
Chapter 11 Maintenance
11.1 View Device Informaon
Basic Informaon and Algorithms Library Version
Go to Conguraon → Device Conguraon → System Conguraon → Device Informaon to
view the basic informaon and algorithms library version of the device.
You can edit Device Name and Device No. The device No. is used to control the device. It is
recommended to reserve the default value.
Device Status
Go to Conguraon → Device Status to view the device status.
11.2 Log
11.2.1 Enable System Log Service
The security audit logs refer to the security operaon logs. You can search and analyze the security
log les of the device so as to nd out the illegal intrusion and troubleshoot the security events.
Security audit logs can be saved on device internal storage. The log will be saved every half hour
aer device boong. Due to limited storage space, you are recommended to save the logs on a log
server.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → Service .
2.
Check Enable System Log Service.
3.
Enter IP Address and Port No. of the log server.
4.
Click Save.
Result
The device will upload the security audit logs to the log server regularly.
11.2.2 Search Log
Log helps to locate and troubleshoot problems.
Steps
1.
Click Log.
2.
Set search condions.
Roadside Parking ANPR Bullet Camera User Manual
47
3.
Click Search.
The matched log les will be displayed on the log list.
4.
Oponal: Click Save Log to save the log les to your computer.
11.3 Upgrade
Upgrade the system when you need to update the device version.
Before You Start
Prepare the upgrade le.
Steps
1.
Go to Conguraon → Device Conguraon → System Maintenance → Upgrade .
2.
Click Browse to select the upgrade le.
3.
Click Upgrade.
4.
Click OK in the popup window.
Note
The upgrade process will take 1 to 10 minutes. Do not cut o the power supply.
Result
The device will reboot automacally aer upgrade.
11.4 Reboot
When the device needs to be rebooted, reboot it via the soware instead of cung o the power
directly.
Steps
1.
Go to Conguraon → Device Conguraon → System Maintenance → Reboot .
2.
Click Reboot.
3.
Click OK to reboot the device.
11.5 Restore Parameters
When the device is abnormal caused by the incorrect set parameters, you can restore the
parameters.
Steps
1.
Go to Conguraon → Device Conguraon → System Maintenance → Default .
2.
Select the restoraon mode.
-
Click Restore to restore the parameters except the IP address, subnet mask, gateway, and port
No. to the default sengs.
Roadside Parking ANPR Bullet Camera User Manual
48
-
Click Restore Factory Sengs to restore all the parameters to the factory sengs.
3.
Click OK.
11.6 Synchronize Time
Synchronize the device me when it is inconsistent with the actual me.
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → Time Sengs .
2.
Select Time Zone.
3.
Select Synchronizaon Mode.
NTP Synchronizaon
Select it to synchronize the device me with that of the NTP server. Set Server Address, NTP
Port, and Interval. Click NTP Test to test if the connecon between the device and the server
is normal.
Manual Synchronizaon
Select it to synchronize the device me with that of the computer. Set me manually, or
check Sync. with computer me.
Satellite Time Sync
Select it to synchronize the device me with that of the satellite. Set Interval.
SDK
If the remote host has been set for the device, select it to synchronize me via the remote
host.
ONVIF
Select it to synchronize me via the third-party device.
No
Select it to disable me synchronizaon.
All
Select it, and you can select any mode above.
Note
The me synchronizaon modes vary with dierent models. The actual device prevails.
4.
Click Save.
11.7 Set DST
If the region where the device is located adopts Daylight Saving Time (DST), you can set this
funcon.
Roadside Parking ANPR Bullet Camera User Manual
49
Steps
1.
Go to Conguraon → Device Conguraon → System Conguraon → DST .
2.
Check Enable DST.
3.
Set Start Time, End Time, and DST Bias.
4.
Click Save.
11.8 Export Parameters
You can export the parameters of one device, and import them to another device to set the two
devices with the same parameters.
Steps
1.
Go to Conguraon → Device Conguraon → System Maintenance → Export Parameters .
2.
Click Export Parameters.
3.
Set a password, and click OK.
Note
The password is used for imporng the conguraon le of the current device to other devices.
4.
Select the saving path, and enter the le name.
5.
Click Save.
11.9 Import Conguraon File
Import the conguraon le of another device to the current device to set the same parameters.
Before You Start
Save the conguraon le to the computer.
Steps
Cauon
Imporng conguraon le is only available to the devices of the same model and same version.
1.
Go to Conguraon → Device Conguraon → System Maintenance → Import Cong. File .
2.
Select Imporng Method.
Note
If you select Import Part, check the parameters to be imported.
3.
Click Browse to select the conguraon le.
4.
Enter the password which is set when the conguraon le is exported, and click OK.
5.
Click Import.
6.
Click OK on the popup window..
Roadside Parking ANPR Bullet Camera User Manual
50
Result
The parameters will be imported, and the device will reboot.
11.10 Export Violaon Type File
You can export the violaon type le to check the violaon types of the vehicles.
Steps
Note
The funcon vary with dierent models. The actual device prevails.
1.
Go to Conguraon → Device Conguraon → System Maintenance → Export Violaon Type
File .
2.
Click Export Violaon Type File.
3.
Select the saving path and enter the le name.
4.
Click Save.
11.11 Export Debug File
The technicians can export the debug le to troubleshoot and maintain the device.
Steps
1.
Go to Conguraon → Device Conguraon → System Maintenance → Export Debug File .
2.
Click Export Debug File.
3.
Select the saving path, and enter the le name.
4.
Click Save.
Roadside Parking ANPR Bullet Camera User Manual
51
Appendix A. Communicaon Matrix and Device
Command
Scan the QR code below to get the communicaon matrix of the device.
Figure A-1 Communicaon Matrix
Scan the QR code below to get the device command.
Figure A-2 Device Command
Roadside Parking ANPR Bullet Camera User Manual
52
UD24972B
