1
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Coffee Percolator.
• Before plugging your coffee percolator into the mains,
visually check that the appliance is intact and has not
suffered any transit damage.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• This coffee percolator is only to be used with the stand
provided.
• Close supervision is required when using this appliance
near children.
• Never leave this appliance within reach of children.
• This appliance can be used by children aged from 8 years
and above if they have been given supervision or
instruction concerning use if the appliance in a safe way
and if they understand the hazards involved. Cleaning and
user maintenance shall not be made by children unless
they are older than 8 and supervised. Keep the appliance
3
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
and its cord out of reach of children aged less than 8
years. This appliance can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
to the mains supply.
• Always use this appliance on a solid, level, non-flammable
surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• If the supply cord is damaged, it must be replaced by the
manufacturer, service agent or similarly qualified person
in order to avoid hazard.
• Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place user at
serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• DO NOT run the mains cable under carpets, rugs, etc.
• Allow the unit to cool before storage.
4
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Never place the appliance near to flammable material or
high-pressure containers.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
• DO NOT immerse the appliance, base or its cord in water
or any other liquids.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Ensure appliance is situated in an open area, do not allow
it to come in contact with cupboards, curtains, wall
coverings, clothing or other flammable materials.
• Unplug after each use. Grasp the plug, not the cord.
• DO NOT cover this appliance.
• Never place this appliance on an electric, gas, or any other
type of hob.
• WARNING: DO NOT open lid whilst the water is boiling.
• DO NOT fill the coffee percolator more than its capacity –
ensure the water level is between the min and max marks.
If the coffee percolator is overfilled, boiling water may be
ejected.
• Always close the lid during use and do not open the lid
whilst the water is boiling.
• CAUTION: The outside surface of the coffee percolator
will get hot during use.
• Ensure the coffee percolator has switched off before
removing it from the base.
5
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Please note, it is recommended that you don’t use this in
conjunction with any other appliances on a multi socket
extension lead.
THIS APPLIANCE MUST BE EARTHED
6
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
WARNING!
This designates a hazard with moderate risk, which may result
in severe injury or damage to the product if not adhered to.
7
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Before first use of Your Coffee Percolator
Please read these operating instructions thoroughly and keep them in a safe place
for future reference.
Before using the percolator for the first time, thoroughly wash all parts of the
percolator.
Fill with water to the 12 cups mark on the Water Gauge (8) inside and allow the
water to boil. Pour away the boiled water. If a slight taste or odour remains repeat
the process once more.
Ensure that the Lid (2) fits snugly and is not loose. DO NOT use the percolator if
the lid is loose and/or does not fit correctly.
1. Lid Handle
2. Lid
3. Spout
4. Pump Tube
5. Spring
6. Coffee Basket Lid
7. Coffee Basket
8. Water Gauge (Inside)
9. Handle
10. On/Off Button
11. Base
12. Silicone Seal
13. Heat Insulating Disc
14. Square Nut
1
2
3
5
6
7
8
4
10
11
1
12
13
2
14
9
8
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Using Your Coffee Percolator
Whilst filling the percolator, ensure that the
water level is above the 6 Cup mark and
below the 12 Cup mark using the Water
Gauge (8) inside the percolator.
WARNING! Do not overfill the
percolator above the 12 Cup mark
(arrowed) as this will risk boil over and
scalding and may damage the appliance.
•
2
1
• Pull the Lid (2) off using the Lid Handle (1).
Remove the Coffee Basket Lid (6), the Coffee
Basket (7) and the Pump Tube (4) being
careful not to lose the Spring (5).
•
• Fill the percolator with water to the desired
number of cups using the scale on the inside
as shown below:
Replace the Lid (2).
Place the coffee percolator Base
(11) on a Solid, level, non-
flammable surface:
Ensure that the appliance is
disconnected from the
mains supply.
3
4
5
9
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Table of Coffee Quantity – Cups vs Strength
No. Cups of Coffee
(Water Gauge Level)
Mild Cup of
Coffee
(Teaspoons)
Medium Cup of
Coffee
(Teaspoons)
Strong Cup of Coffee
(Teaspoons)
12
6
8
10
10
5
7
9
8
4
6
8
6
3
4
6
5
Place the Coffee Basket (7)
onto the Pump Tube (4)
(being careful not to lose
the Spring (5)) and back
into the percolator as
shown left:
Ensure that the base of the
Pump Tube (4) fits into the
‘well’ at the bottom of the
percolator.
Do not replace the Coffee
Basket Lid (6) at this stage.
6
Add the desired amount of
ground coffee to the Coffee
Basket (7) according to the
number of cups the
percolator has been filled to
and the strength of coffee
required. See table below.
Never fill the Coffee Basket
(7) with more than 12 cups
(spoonful’s) of coffee.
Once the coffee has been
added, place the Coffee
Basket Lid (6) onto the
Coffee Basket (7).
10
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
The use of Ground Coffee is recommended for this Percolator.
Fine/powdered coffee is not recommended as it will block the holes in the Coffee
Basket (7) and prevent the Percolator from working.
Insert the Mains plug into the
nearest socket:
Left: Once the desired amount
of coffee has been dispensed,
replace the Lid (2) back onto the
Percolator.
7
8
Right: Whilst replacing the Lid (2), ensure
that the vent holes (arrowed right) in the
lid are positioned away from the Handle
(9) to direct scalding from steam away
from the user.
11
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Boil dry protection
Should you accidentally let the appliance operate without water; the boil-dry
protection will automatically switch off the power. If this occurs, allow the
appliance to cool and reset before use.
9
Place the Percolator onto the Base (11).
Press the On/Off Button (10 – arrowed
right) which will illuminate red and the
percolating cycle will begin.
At the end of the cycle the On/Off Button (8) will
illuminate blue indicating that the Percolator has
switched to ‘Keep warm’ mode as shown left:
The Percolator has now finished and can be
removed from the Base (11) and the coffee
served.
The coffee will be kept warm for thirty minutes –
after which the Percolator will switch off.
Left: During use, the
coffee being percolated
can be viewed through
the transparent Lid
Handle (1).
12
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Important – Descaling your Coffee Percolator/Reducing Limescale Build up
• To prolong the life of your coffee percolator it is imperative that it is descaled
regularly.
• The frequency of the descaling depends on the hardness of the water in your
area and how often the appliance is used.
• In extreme hard water areas, descaling your coffee percolator at least once a
month is highly recommended also the use of filtered water in your coffee
percolator will increase the life expectancy and help prevent excessive lime scale
build up.
• If the percolator switches off before it boils or has a white deposit building up
inside then it will need to be descaled.
• Do not use vinegar but a commercially available descaling agent; carefully follow
the quantities recommended in the instructions of the agent:
4
3
2
1
Fill your coffee percolator to the
‘12 Cup’ mark on the Water
Gauge (8) or the water quantity
recommended by the descaling
product.
Add a descaling agent to the percolator
according to the descaling products
instructions.
Allow the percolator to boil and allow it to go into keep warm mode.
Stand and allow to soak for approximately 15 – 20 minutes, (if necessary,
adjust the standing time to the descaling products instructions).
Finally, empty the percolator and repeat the above process. Your coffee
percolator is now descaled and cleaned.
13
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Care and Use of Your Coffee Percolator
• Ensure the mains plug is removed from the socket
outlet before cleaning.
• Do not immerse the percolator or the base in water
or any other liquids.
• Wipe the percolator clean with a clean damp cloth.
• Do not use harsh or abrasive scouring pads, powders
or cleaners.
• Do not clean any part of your Percolator in a
dishwasher.
Dismantling the Lid Assembly for Cleaning
To dismantle the Lid Assembly for
cleaning, hold the Handle (1) and
unscrew the Square Ring (14) anti-
clockwise and carefully dismantle
ensuring no parts are lost:
During Re-assembly, ensure the
Silicone Seal (12) and the Heat
Insulating Disc (13) are fitted in the
correct order as in the diagram right:
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse
cover missing. If in doubt, consult a qualified electrician.
If you need to remove the plug -DISCONNECT FROM THE MAINS- and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Technical Specification
Model Number
SDA2614
Rated Voltage
220-240V~ 50Hz
Rated Power
900-1100W
Protection Class
I (This appliance must be Earthed)
Capacity
1.8 Litre
1
2
12
13
14
14
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Troubleshooting Guide
Problem
Possible Cause
Possible Fix
Coffee percolator not
working.
On/Off Button (10) not
pressed.
Press the On/Off Button (10).
Plug not inserted into the
mains socket and/or not
switched on.
Ensure the mains plug is plugged
into the mains socket and the socket
is switched on.
Coffee percolator not
seated on the base
correctly.
Ensure the Coffee percolator is
seated correctly on the Base (11).
Fuse blown in plug.
Check fuse by substitution.
Coffee percolator
switches off before
boiling.
Not enough water in the
Coffee percolator.
Ensure the Coffee percolator is filled
with sufficient water and the water
level is above the ‘6’ mark on the
Water Gauge (8).
Coffee percolator requires
descaling.
Follow ‘Descaling your Coffee
percolator’ above.
Coffee percolator boils
over
Coffee percolator is
overfilled.
Ensure that the Coffee percolator is
not filled above the ‘12’ mark on the
Water Gauge (8).
Coffee too strong
Percolator has been filled
with too little water
Ensure that the Coffee percolator is
filled to the correct mark on the
Water Gauge (8), - see ‘Table of
Coffee Quantity’ on page 9 above.
Too much coffee added to
the Coffee Basket (7)
Ensure the correct amount of coffee
is added to the Coffee Basket (7),
- see ‘Table of Coffee Quantity’ on
page 9 above.
Coffee too weak
Percolator has been filled
with too much water.
Ensure that the Coffee percolator is
filled to the correct mark on the
Water Gauge (8), - see ‘Table of
Coffee Quantity’ on page 9 above.
Too little coffee added to
the Coffee Basket (7).
Ensure the correct amount of coffee
is added to the Coffee Basket (7),
- see ‘Table of Coffee Quantity’ on
page 9 above.
Percolator seems to be
working but no or very
little coffee is produced.
Powered or fine coffee
added to the Coffee
Basket (7) and blocked
the holes.
Ensure Ground Coffee is used in the
Percolator.
15
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
16
1.8L Coffee Percolator
Model No. SDA2614
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
