User Manual

This is the main product document for model DV90T6240LB/S1. Series: Serie 7
Additionally, the document applies to other Samsung models: DV90T******, DV80T******, DV90T6240LB

The file format is pdf, 28 pages, you can download this manual here .

background
Heat Pump Dryer
Models: DV90T******, DV80T******
• CongratulationsonyournewSamsungdryer.Thismanualcontainsimportantinformationon
theinstallation,use,andcareofyourappliance.Pleasetakesometimetoreadthismanualto
takefulladvantageofyourdryer’smanybenetsandfeatures.
• Fordetailedinstructionsoninstallationandcleaningofthedryer,visittheSamsungwebsite
(http://www.samsung.com),gotoSupport>SupportHome,andthenenterthemodelname.
• Tochecktheproduct’smodelname,seethelabelenclosedwiththeproductorattachedtothe
product.
What’s included
Carefullyunpackthedryer.Keepallpackagingmaterialsawayfromchildren.Thepartsand
locationofpartsshownbelowmaydifferfromyourdryer.Beforeinstallation,makesurethe
dryerhasallthepartslistedhere.Ifthedryerand/orpartsaredamagedormissing,contactthe
nearestSamsungcustomerservicecenter.
Dryer at a glance
01
02
03
04
05
06
07
01 Topcover 02 Watertank
03 Door 04 Heatexchanger
05 Controlpanel 06 Lintlter
07 Levellingfeet
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 1 2021/7/19 14:48:44
background
English2
Accessories (supplied)
Hoseguide Cabletie Hoseconnector Longdrainhose(2m)
Dryingrack(applicable
modelsonly)
Cleaningbrush
Accessories (not supplied)
Bracket-Stackingkit
(Part#SK-DH;SK-DA;
SKK-DF)
NOTE
• Forstackinginstructionswiththedryer,seetheinstallationmanualincludedinthestacking
kit.
• Forinformationonwhichstackingkitmodelyoucanusetostackyourdryeronthewashing
machine,seetheusermanualincludedinyourSamsungwashingmachine.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 2 2021/7/19 14:48:45
background
English 3
Safety information
Important safety symbols
What the icons and signs in this user manual mean:
WARNING
Hazardsorunsafepracticesthatmayresultinsevere personal injury, death and/or property
damage.
CAUTION
Hazardsorunsafepracticesthatmayresultinpersonal injury and/or property damage.
NOTE
Indicatesthatariskofpersonalinjuryormaterialdamageexists.
Read the instructions
These warning signs are here to prevent injury to yourself and others.
Please follow them explicitly.
After reading this manual, store it in a safe place for future reference.
Readallinstructionsbeforeusingtheappliance.
Aswithanyequipmentthatuseselectricityandmovingparts,potentialhazardsexist.Tosafely
operatethisappliance,familiarizeyourselfwithitsoperationandexercisecarewhenusingit.
WARNING - Risk of Fire
• Clothesdryerinstallationmustbeperformedbyaqualiedtechnician.
• Installtheclothesdryeraccordingtothemanufacturer’sinstructionsandlocalcodes.
• Toreducetheriskofsevereinjuryordeath,followallinstallationinstructions.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 3 2021/7/19 14:48:46
background
English4
Important safety precautions
WARNING
To reduce the risk of re, electric shock, or injury
to persons when using your appliance, follow basic
precautions, including the following:
1. Thisapplianceisnottobeusedbypersons(including
children)withreducedphysical,sensoryormental
capabilities,orlackofexperienceandknowledge,
unlesstheyhavebeengivensupervisionorinstruction
concerninguseoftheappliancebyapersonresponsible
fortheirsafety.
2. For use in Europe:Thisappliancecanbeusedby
childrenagedfrom8yearsandaboveandpersons
withreducedphysical,sensoryormentalcapabilities
orlackofexperienceandknowledgeiftheyhavebeen
givensupervisionorinstructionconcerninguseofthe
applianceinasafewayandunderstandthehazards
involved.Childrenshallnotplaywiththeappliance.
Cleaningandusermaintenanceshallnotbemadeby
childrenwithoutsupervision.
3. Childrenshouldbesupervisedtoensurethattheydo
notplaywiththeappliance.
4. Ifthesupplycordisdamaged,itmustbereplacedby
themanufacturer,itsserviceagentorsimilarlyqualied
personsinordertoavoidahazard.
5. Thenewhose-setssuppliedwiththeappliancearetobe
usedandthatoldhose-setsshouldnotbereused.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 4 2021/7/19 14:48:46
background
English 5
6. Forapplianceswithventilationopeningsinthebase,
thatacarpetmustnotobstructtheopenings.
7. For use in Europe:Childrenoflessthan3yearsshould
bekeptawayunlesscontinuouslysupervised.
8. CAUTION:Inordertoavoidahazardduetoinadvertent
resettingofthethermalcut-out,thisappliancemustnot
besuppliedthroughanexternalswitchingdevice,such
asatimer,orconnectedtoacircuitthatisregularly
switchedonandoffbytheutility.
9. Thetumbledryerisnottobeusedifindustrial
chemicalshavebeenusedforcleaning.
10. Thelinttraphastobecleanedfrequently,ifapplicable.
11. Lintmustnottobeallowedtoaccumulatearoundthe
tumbledryer.(notapplicableforappliancesintendedto
beventedtotheexteriorofthebuilding)
12. Adequateventilationhastobeprovidedtoavoidthe
backowofgasesintotheroomfromappliances
burningotherfuels,includingopenres.
13. Donotdryunwasheditemsinthetumbledryer.
14. Itemsthathavebeensoiledwithsubstancessuchas
cookingoil,acetone,alcohol,petrol,kerosene,spot
removers,turpentine,waxesandwaxremoversshould
bewashedinhotwaterwithanextraamountof
detergentbeforebeingdriedinthetumbledryer.
15. Itemssuchasfoamrubber(latexfoam),showercaps,
waterprooftextiles,rubberbackedarticlesandclothes
orpillowsttedwithfoamrubberpadsshouldnotbe
driedinthetumbledryer.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 5 2021/7/19 14:48:46
background
English6
16. Fabricsofteners,orsimilarproducts,shouldbeusedas
speciedbythefabricsoftenerinstructions.
17. Thenalpartofatumbledryercycleoccurswithout
heat(cooldowncycle)toensurethattheitemsareleft
atatemperaturethatensuresthattheitemswillnotbe
damaged.
18. Removeallobjectsfrompocketssuchaslightersand
matches.
19. WARNING:Neverstopatumbledryerbeforetheendof
thedryingcycleunlessallitemsarequicklyremoved
andspreadoutsothattheheatisdissipated.
20. Exhaustairmustnotbedischargedintoauewhichis
usedforexhaustingfumesfromappliancesburninggas
orotherfuels.
21. Theappliancemustnotbeinstalledbehindalockable
door,aslidingdoororadoorwithahingeonthe
oppositesidetothatofthetumbledryer,insucha
waythatafullopeningofthetumbledryerdooris
restricted.
22. WARNING:Theappliancemustnotbesuppliedthrough
anexternalswitchingdevice,suchasatimer,or
connectedtoacircuitthatisregularlyswitchedonand
offbyautility.
Heat pump model only:Theinstructionsshallalso
includethesubstanceofthefollowing:
WARNING:Intheapplianceenclosureorinthebuilt-in
structure,keepventilationopeningsclearofobstruction.
WARNING:Donotdamagetherefrigerantcircuit.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 6 2021/7/19 14:48:46
background
English 7
Critical installation warnings
WARNING
Theinstallationofthisappliancemustbeperformedbyaqualiedtechnicianorservice
company.
Failuretodosomayresultinelectricshock,re,anexplosion,problemswiththeproduct,or
injury.
Plugthepowercordintoawallsocketandusethesocketforthisapplianceonly.Inaddition,do
notuseanextensioncord.
Sharingawallsocketwithotherappliancesusingapowerstriporextendingthepowercordmay
resultinelectricshockorre.
Ensurethatthepowervoltage,frequencyandcurrentarethesameasthoseoftheproduct
specications.Failuretodosomayresultinelectricshockorre.FailurePlugthepowerplug
intothewallsocketrmly.
Removeallforeignsubstancessuchasdustorwaterfromthepowerplugterminalsandcontact
pointsusingadryclothonaregularbasis.
Unplugthepowerplugandcleanitwithadrycloth.
Failuretodosomayresultinelectricshockorre.
Keepallpackagingmaterialswelloutofthereachofchildren,aspackagingmaterialscanbe
dangeroustochildren.
Ifachildplacesabagoveritshead,itmayresultinsuffocation.
Thisappliancemustbeproperlygrounded.
Donotgroundtheappliancetoagaspipe,plasticwaterpipe,ortelephoneline.
Thismayresultinelectricshock,re,anexplosion,orproblemswiththeproduct.
Neverplugthepowercordintoasocketthatisnotgroundedcorrectlyandmakesurethatitisin
accordancewithlocalandnationalcodes.
Donotinstallorkeeptheproductexposedtotheoutdoorelements.
Donotuseadamagedpowerplug,damagedpowercordorloosewallsocket.
Thismayresultinelectricshockorre.
Iftheplug(powersupplycord)isdamaged,itmustbereplacedbythemanufacturerorits
serviceagentorasimilarqualiedtechnicianinordertoavoidahazard.
Thisapplianceshouldbepositionedtobeaccessibletothepowerplugafterinstallation.
Donotpullorexcessivelybendthepowercord.
Donottwistortiethepowercord.
Donothookthepowercordoverametalobject,placeaheavyobjectonthepowercord,insert
thepowercordbetweenobjects,orpushthepowercordintothespacebehindtheappliance.
Thismayresultinelectricshockorre.
Donotpullthepowercord,whenunpluggingthepowerplug.
Unplugthepowerplugbyholdingtheplug.
Failuretodosomayresultinelectricshockorre.
Thisappliancemustbeproperlygrounded.Neverplugthepowercordintoareceptaclethat
isnotgroundedadequatelyandinaccordancewithlocalandnationalcodes.Seeinstallation
instructionsforgroundingthisappliance.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 7 2021/7/19 14:48:46
background
English8
Installthisapplianceinalocationwithsolid,leveloor.
Failingtodosomayresultinabnormalvibrations,noiseorproblemswiththeproduct.
Sinceaningredientinhairspraymaydegradethehydrophilepropertyoftheheatexchanger
sothatdewmayappearontheoutersurfaceoftheappliancewhenthecoolingoperationis
running,donotinstalltheapplianceinabeautysalon.
Thisapplianceshouldbepositionedsothatthepowerplug,thewatersupplytaps,andthedrain
pipesareaccessible.
Critical usage warnings
WARNING
Donotletchildrenorpetsonorintotheproduct.Inaddition,whendisposingofthisproduct,
disassemblethedoorlock(lever).
Thismayresultinchildrenfallingandinjuringthemselves.
Ifchildrenbecomelockedintheproduct,thereisadangerofsuffocation.
Donottrytoaccesstheinsideoftheproductwhenthedrumisrotating.
Donotsitontheproductorleanagainstthedoor.
Thismayresultintheproductturningoverandresultingininjury.
Drythelaundryonlyafteritwasspunbyanappropriatewashingmachine.
Donotdryunwasheditemsinthetumbledryer.
Donotdrinkthecondensedwater.
Neverstopatumbledryerbeforetheendofthedryingcycleunlessallitemsarequickly
removedandspreadoutsothattheheatisdissipated.
Donotdrylaundrycontaminatedbyinammablematerialssuchasgasoline,kerosene,benzene,
thinner,alcohol,etc.
Thismayresultinelectricshock,reorexplosion.
Donotletpetscheworplaywiththedryer.
Thismayresultinelectricshockorinjury.
Whendisposingoftheproduct,separatethedoorandthepowercordbeforedisposingofthe
product.
Failingtodosomayresultindamagetothepowercodeoraninjury.
Donottouchthepowerplugwithwethands.
Thismayresultinelectricshock.
Whengas(citygas,propanegas,LPgas)leaks,donottouchthisapplianceorthepowercord,
ventilateimmediately.
Atthistime,donotusetheventilatingfan.
Asparkmaycauseanexplosionorre.
Donotrepair,replace,orattempttoserviceanypartoftheapplianceunlessspecically
recommendedintheuser-repairinstructions.Youmustalsohavetheskillsnecessarytoservice
thisappliance.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 8 2021/7/19 14:48:46
background
English 9
Donotattempttorepair,disassemble,ormodifytheapplianceyourself.
Donotuseanyfuse(suchascooper,steelwire,etc.)otherthanthestandardfuse.
Whenrepairingorreinstallingtheapplianceisrequired,contactyournearestservicecenter.
Failuretodosomayresultinelectricshock,re,problemswiththeproduct,orinjury.
Theproductyouhavepurchasedisdesignedfordomesticuseonly.
Theuseforbusinesspurposesqualiesasproductmisuse.Inthiscase,theproductwillnotbe
coveredbythestandardwarrantyprovidedbySamsungandnoresponsibilitycanbeattributed
toSamsungformalfunctionsordamagesresultingfromsuchmisuse.
Iftheproductgeneratesstrangenoise,smellsofsomethingburning,orgeneratessmoke,
immediatelycut-offthepowerandcontacttheservicecenter.
Otherwise,itmaycauseanelectricshockorreasaresult.
Donotletchildren(orpets)playinoronyourproduct.Theproductdoordoesnotopeneasily
fromtheinsideandchildrenmaybeseriouslyinjurediftrappedinside.
Usage cautions
CAUTION
Donotstandontopoftheapplianceorplaceobjects(suchaslaundry,lightedcandles,lighted
cigarettes,dishes,chemicals,metalobjects,etc.)ontheappliance.
Thismayresultinelectricshock,re,problemswiththeproduct,orinjury.
Donottouchtheglassdoorandinsideofthedrumduringorjustafterdryingasitishot.
Thismayresultinburns.
Thedoorglassbecomeshotduringanddrying.Therefore,donottouchthedoorglass.
Also,donotallowchildrentoplayaroundthedryerortouchthedoorglass.
Thismayresultinburns.
Donotpressthebuttonsusingsharpobjectssuchaspins,knifes,ngernails,etc.
Thismayresultinelectricshockorinjury.
Donotdrylaundrycontainingformingrubber(latex)orsimilarrubbertextures.
Ifformingrubberisheated,itmaystartare.
Donotdrylaundrycontaminatedbyvegetableoilorcookingoilasalargeamountoftheoilwill
notberemovedwhenwashingthelaundry.Inaddition,usetheunheateddrycyclesothatthe
laundryisnotheated.
Theoxidizationheatoftheoilmaystartare.
Donotdrylaundrycontaminatedbyforeignsubstancessuchasoil,cream,lotion,orother
chemicalsthatareusedinplacessuchasskincareroom,massageparlor,beautysalon,or
hospital.
Thismayresultinelectricshock,re,malfunction,andinjury.
Makesurethatthepocketsofallclothingtobedriedareempty.
Hard,sharpobjects,suchascoins,safetypins,nails,screws,orstonescancauseextensive
damagetotheappliance.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 9 2021/7/19 14:48:46
background
English10
Donotdryclothingwithlargebuckles,buttons,orotherheavymetal(zippers,hooksandeyelets,
button-upcovers).
Ifnecessary,usethelaundrynetforsmallandlightweightlaundrysuchasfabrictiebelt,apron
strings,andunderwirebraswhichcandissolveorbreakduringacycle.
Dryersheetsarecompatiblewiththismodel,andarerecommendedforbetterdrying
performance.
Dryersheetsarealsobenecialinreducingthestaticelectricitygeneratedduringadryingcycle.
Staticelectricitycouldleadtodamageoflaundryitemsandpotentiallytheappliance.
Donotusethedryerneardangerouspowderssuchascoaldust,wheatour,etc.
Thismayresultinelectricshock,reoranexplosion.
Donotplaceinammablematerialsneartheproduct.
Thismayresultintoxicgasesfromtheproduct,damagetoparts,electricshock,reoran
explosion.
Theapplianceshouldnotbeplacedbehindlockabledoorsetc.
Donottouchtherearsideoftheapplianceduringorimmediatelyafterdryingiscomplete.
Theapplianceremainshotandmaycauseburns.
Critical cleaning warnings
WARNING
Donotcleantheappliancebysprayingwaterdirectlyontoit.
Donotusebenzene,thinneroralcoholtocleantheappliance.
Thismayresultindiscoloration,deformation,damage,electricshockorre.
Beforecleaningorperformingmaintenance,unplugtheappliancefromthewallsocket.
Failuretodosomayresultinelectricshockorre.
Cleantheltercasebeforeandafterusingthedryer.
Cleantheinsideoftheproductonaregularbasisbyaskinganauthorizedserviceengineer.
Cleantheheatexchangerwithasoftbrushorvacuumcleaneronceamonth,Donottouchthe
heatexchangerwithyourhand.Otherwise,itmaycauseaninjury.
Theinteriorofthedryershouldbecleanedperiodicallybyqualiedservicepersonnel.
Care for preventing freezing
• InstallthedryerinanareawherethetemperaturedoesnotdropbelowzerodegreeCelsius.
• Ifdrainingdirectlyusingalongdrainhose,waterremaininginsidethehosecanfreezein
winter.Makesurethereisnowaterleftinsidethehoseafteruse.
• Ifthedrainhosehasfrozen,wrapthehosewithatowelsoakedinwarmwaterfor
approximatelytenminutestothawit.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 10 2021/7/19 14:48:46
background
English 11
Instructions about the WEEE
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicableincountrieswithseparatecollectionsystems)
Thismarkingontheproduct,accessoriesorliteratureindicatesthattheproduct
anditselectronicaccessories(e.g.charger,headset,USBcable)shouldnotbe
disposedofwithotherhouseholdwasteattheendoftheirworkinglife.To
preventpossibleharmtotheenvironmentorhumanhealthfromuncontrolled
wastedisposal,pleaseseparatetheseitemsfromothertypesofwasteand
recyclethemresponsiblytopromotethesustainablereuseofmaterialresources.
Householdusersshouldcontacteithertheretailerwheretheypurchasedthis
product,ortheirlocalgovernmentofce,fordetailsofwhereandhowtheycan
taketheseitemsforenvironmentallysaferecycling.
Businessusersshouldcontacttheirsupplierandcheckthetermsandconditions
ofthepurchasecontract.Thisproductanditselectronicaccessoriesshouldnot
bemixedwithothercommercialwastesfordisposal.
ForinformationonSamsung’senvironmentalcommitmentsandproductregulatoryobligations,
e.g.REACH,WEEEorBatteries,visitoursustainabilitypageavailableviawww.samsung.com
Declaration of conformity
Hereby,SamsungdeclaresthatthisradioequipmentisincompliancewithDirective2014/53/
EUandwiththerelevantstatutoryrequirementsintheUK.ThefulltextoftheEUdeclarationof
conformityandtheUKdeclarationofconformityisavailableatthefollowinginternetaddress:
TheofcialDeclarationofconformitymaybefoundathttp://www.samsung.com,gotoSupport>
SupportHomeandenterthemodelname.
Wi-Fimaxtransmitterpower:20dBmat2.412GHz–2.472GHz
Turning on Wi-Fi (for network models only)
NOTE
TurningonWi-Ficonsumesmoreenergy.UnderanenvironmentwhereWi-Fiisfrequentlyturned
on,actualenergyconsumptioncanbegreaterthanthevaluesinthespecicationsheetsection.
1. Tapandhold
toturnonthedryer.
2. Tapandhold
.
2-1. ThedryerentersAPmodeandconnectstoyoursmartphone.
2-2. Tap
toauthenticateyourdryer.
2-3. Oncetheauthenticationprocessiscomplete,yourdryerissuccessfullyconnectedtothe
app.
NOTE
Tapandhold
for3secondstoentertheSystem Functionsmenu,turntheNavigationdialto
selectWi-Fi,andtap toturnitoff.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 11 2021/7/19 14:48:47
background
English12
Installation
Followtheseinstructionscarefullytoensureproperinstallationofthedryerandprevent
accidentswhendoinglaundry.
Installation requirements
Electrical and grounding requirements
• ThedryerrequiresanAC220-240V/50Hzelectricalsupply.
• Thedryermustbeproperlygrounded.Ifthedryermalfunctionsorbreaksdown,grounding
reducestheriskofelectricshockbyprovidingapathofleastresistancefortheelectric
current.Thedryercomeswithapowercordthathasa3-pronggroundingplug.Theplug
mustbepluggedintoanappropriateoutletthatisproperlyinstalledandgroundedin
accordancewithalllocalcodesandordinances.
• Ifyouhaveanyquestionsregardingtheelectricalorgroundingrequirements,pleasecontact
Samsungoraqualiedelectrician.
WARNING
• Plugintoagrounded,3-prongoutlet.
• Donotuseadamagedpowerplug,cord,orlooseordamagedwalloutlet.
• Donotuseanadapteroranextensioncord.
• Improperconnectionoftheequipment-groundingconductormayresultinelectricshock.If
youareunsureifthedryerisproperlygrounded,checkwithaqualiedelectrician.
• Donotmodifythepowerplug,powercord,orpoweroutletinanyway.
• Donotconnectthegroundwiretoplasticplumbinglines,gaslines,orhotwaterpipes.
Alcove installation
Minimumclearanceforstableoperation:
• Sides:25mm,Top:25mm,Rear:50mm,Front:490mm
Ifinstallingthedryerwithawashingmachine,thefrontofthealcoveorclosetmusthavean
unobstructedairopeningofatleast550mm.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 12 2021/7/19 14:48:47
background
English 13
Step-by-step installation
STEP 1 Select a location
Locationrequirements:
Selectalevel,well-constructedsurfacethatwillwithstandvibrations.Selectalocationwherea
grounded,3-prongoutletiseasilyaccessible.
WARNING
• Installthedryerindoorsonly.
• Donotinstallthedryerinareasexposedtotheweather.
• Donotinstallthedryerwherethetemperaturemayfallbelow5°Corriseabove35°C.
• Donotinstallthedryerwheregasmayleak.
• Donotblockthecoolinggrill’sairinletlocatedatthedryerfront.
STEP 2 Adjust the levelling feet
A
B
1. Gentlyslidethedryerintothedesiredlocation.
2. Usealevel (A)andcheckthelevelnessofthe
dryerfromsidetosideandfronttoback.
3. Ifthedryerisnotlevel,turnthelevelling feet (B)
leftorrighttoadjusttheheight.
4. Oncethedryerislevel,makesurethedryer
standsrmlyontheoor.
5. Pluginthedryer.
C D
NOTE
• Tosetthedryertothesameheightasthe
washingmachine,turnthelevellingfeettothe
rightuntilitfullyretracts(C).Then,turnthe
levellingfeettothelefttoextend(D)ituntilthe
dryerandthewashingmachinearethesame
height.
• Extendthelevellingfeetonlyasmuchas
necessary.Extendingthelevellingfeetmorethan
necessarycancausethedryertovibrate.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 13 2021/7/19 14:48:47
background
English14
STEP 3 Drain hose
A
B
• Westronglyrecommendconnectingthedrain
hosetoyourdrainagesystem.
• Ifthedrainhoseconnectedonthedryeristoo
shorttoreachthedrainagesystem,usethe
providedaccessoryhose(longdrainhose).
• Usethebuilt-inwatertankonlyifyoucannot
connectthedrainhosetoadrainagesystem.
NOTE
Asafactorydefault,thisdryerissettousethebuilt-
inwatertanktodraincondensedwater.
B
A
1. Removethedrainhosefromhole (A),andinsert
itintopart (B).
A
2. Insertoneendoftheaccessoryhose(longdrain
hose)intohole (A).
3. Inserttheotherend(outlet)oftheaccessory
hosetothedrainagesysteminoneofthe
followingways:
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 14 2021/7/19 14:48:47
background
English 15
Over a wash basin:
A
CB
1. Makesuretoplacetheendoftheaccessoryhose
lowerthan90 cm (*)fromthebottomofdryer.
2. Tobendsomepointoftheaccessoryhose,use
thesuppliedplastichose guide (B)andsecurethe
guidetothewallwithahookortothetapwitha
pieceofstring.Assemblethedrain hose (A)and
thehose guide (B)andxthemwiththecable-tie
(C).
3. Youcandrainthecondensedwaterby
connectingtheaccessoryhose(longdrainhose)
tothedrain-outletdirectly.
CAUTION
Donotextendthedrainhose.Watermayleakfrom
theconnectedarea.Usealongdrainhose.
By using the drain pipe of the wash basin:
A
1. Assemblethehose connector (A),andattachitto
theendoftheaccessoryhoseasshown.
CAUTION
Topreventwaterleak,makesuretoconnectthe
hoseandtheconnectorrmly.
2. Connectthehoseadapterdirectlytothedrain
pipeofthewashbasin.
STEP 4 Power on
Plugthepowercordintoawallsocketprotectedbyafuseorcircuitbreaker.Then,tap
toturn
onthedryer.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 15 2021/7/19 14:48:48
background
English16
Operations
Cycle overview
Cotton
Forgeneralcottonclothes
Mixed Load Foramixofcottons&synthetics
Synthetics Fordryingsyntheticfabrics
Iron Dry Makeironingeasier
Air Wash * Deodorize&refresh
Hygiene Care * Forafresh,morehygienicclean
Bedding Forcomforters&bedding
Wool Fordryingwoolgarments
Towels Keeptowelsuffy
Delicates Forunderwear&delicateitems
Outdoor Careforwaterproofitems
Shirts Toquicklydryafewshirts
Time Dry Setacustomdryingtime
Warm Air Gentledrybeforehangingoutside
Cool Air Dryatroomtempforsettime
Quick Dry 35’ Forcotton&otherquickitems
• (*) applicable models only (DV9*T62****/DV8*T62****)
NOTE
Thecycleandfunctionnamesthatappearedinthismanualmaydifferfromyourproduct.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 16 2021/7/19 14:48:48
background
English 17
Rack Dry (applicable models only)
Setthedryingtimeupto150minutesaccordingtothemoistureandweightoftheitemstodry.
Whendryinglaundryusingthedryingrack,theTime Drycycleisrecommended.
1. Positionthedryingrackinthedrum,inserting
thefrontlipsoftherackintotheholesofthe
doordiaphram.
A
A. Rackdry
2. Placeitemsontherack,leavingenoughspace
whereaircancirculate.Forclothingitems,fold
andplaceatontherack.
3. Tapandhold
.
4. Closethedoorandtap
.TurntheNavigation
dialtoselectTime Dry,andthentap
repeatedlytoselectthedryingtime.
Drying suggestions
Items (max 1.5 kg) Description
Washablesweaters(blocktoshapeand
layatonrack)
Whendryingthelaundryusingtherack,foldand
placetheclothesontheracktopreventtheclothing
frombecomingwrinkled.
Stuffedtoys(cottonorpolyesterber
lled)
CAUTION
• Dryingfoamrubber,plastic,orrubberonaheatsettingmaycausedamagetotheitemsand
leadtoarehazard.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 17 2021/7/19 14:48:48
background
English18
Maintenance
WARNING
• Donotcleanthedryerbydirectlysprayingwaterontothedryer.
• Donotcleanthedryerwithbenzene,thinner,alcohol,oracetone.Thismayresultin
discoloration,deformation,damage,electricshock,orre.
• Beforecleaningthedryer,besuretounplugthepowercord.
Lint lter
Cleanthelintlteraftereachload.
1. Openthedoorandpullthelintlterupwardto
remove.
A
2. Opentheouterlterandremovetheinner lter
(A).
3. Unfoldboththeinnerlterandtheouterlter.
4. Removethelintfrombothlters,andthenclean
thelterswiththecleaningbrush.
NOTE
Tocleantheltersthoroughly,cleantheltersin
runningwater,andthendrythemcompletely.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 18 2021/7/19 14:48:49
background
English 19
5. Puttheinnerlterintotheouterlter,andthen
reinsertthelintlterintotheoriginalposition.
CAUTION
• Cleanthelintlteraftereachload.Otherwise,thedryingperformancemaydecrease.
• Donotoperatethedryerwithouttheinnerlterinsidetheouterlter.
• Usingthedryerwithawetlintltermaycausemold,badodors,oradecreaseindrying
performance.
Water tank
Toavoidleaks,emptythewatertankaftereveryload.
A
1. Usingbothhands,pullthewater tank (A)
forwardtoremove.
B
2. Emptythewaterthroughthedrain hole (B)and
placethewatertankbackintoplace.
NOTE
Ifyouemptythewatertankandtapandhold
,the
correspondingindicatorturnsoff.
CAUTION
Thewatertankcanbeheavy.Pulloutthewatertankslowlyandatlevelusingbothhands.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 19 2021/7/19 14:48:49
background
English20
Heat exchanger
Cleantheheatexchangeratleastonceamonth.(orWhentheBuzzerringsandtheheat
exchangerindicatorlightsuponthedisplay.)
A
1. Gentlypressthetoppartoftheouter cover (A)
toopen.
B
2. Unlockthexers (B).
C
3. Removetheinner cover (C).
4. Cleantheheatexchangerwiththeprovided
cleaningbrushoravacuumcleanerwithabrush
attachment.Takecarenottobendordamage
theheatexchangernswhencleaning.Thismay
leadtoadecreaseindryingperformance.
CAUTION
• Toavoidphysicalinjuryandburns,donottouch
orcleantheheatexchangerwithbarehands.
• Donotusewatertocleantheheatexchanger.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 20 2021/7/19 14:48:49
background
English 21
5. Cleantheinnercoverwithasmooth,dampcloth.
6. Reinserttheinnercovertoitsoriginalposition,
andthenlockthexers.
7. Closetheoutercover.
NOTE
Aftercleaning,makesurethexersarelocked.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 21 2021/7/19 14:48:50
background
English22
Troubleshooting
Ifthereisanyproblem,checktheinformationmessageontheLCDscreenandfollowtheon-
screeninstructions.
Iftheproblempersists,pleasecontacttheservicecenter.
Checkpoints
Ifyouencounteraproblemwiththedryer,rstcheckthetablebelowandtrythesesuggestions.
Symptom Action
Dryerdoesnotrun
• Makesurethedooriscompletelyclosed.
• Makesurethepowercordispluggedin.
• Checkthehome’scircuitbreakerandfuses.
• Emptythewatertank.
• Cleanthelintlter.
Dryerdoesnotheat
• Checkthehome’scircuitbreakerandfuses.
• SelectaheatsettingotherthanCool Air.
• Checkthelintlterandheatexchanger.Cleanthemifnecessary.
• Dryermaybeinthecool-downphaseofthecycle.
Dryerdoesnotdry
Checktheabove,plus…
• Makesurethedryerisnotoverloaded.
• Sortlightandheavyitemsseparately.
• Repositionlarge,bulkyitemstoensureevendrying.
• Checkthatthedryerisdrainingproperly.
• Forsmallloads,addafewdrytowels.
• Cleanthelintlterandheatexchanger.
Dryerisnoisy
• Checkforcoins,buttons,lighters,etc.
• Makesurethedryerislevelandstandingrmlyontheoor.
• Thedryermayhumduetoairmovingthroughthedrumandfan.
Thisisnormal.
Driesunevenly
• Seams,pockets,andotherpartsofclothingarehardertodry
thanothers.Thisisnormal.
• Sortheavyandlightitemsseparately.
Dryeremitsanodor
• Thedryermaydrawhouseholdodorsinfromthesurroundingair
andthenexhaustthem.Thisisnormal.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 22 2021/7/19 14:48:50
background
English 23
Symptom Action
Dryerturnsoffbefore
theloadisdry
• Dryerloadistoosmall.Addmoreitemsandrestartthecycle.
• Dryerloadistoolarge.Removeitemsandrestartthecycle.
Lintonclothes
• Makesurethelintlteriscleanbeforeeveryload.
• Drylint-producingitems(fuzzytowels)separatefromlint
trappers,suchasblacklinenpants.
• Dividelargerloadsintosmallerloads.
Itemsstillwrinkled
afterWrinklePrevent
• Smallloadsof1-4itemsworkbest.
• Loadfeweritems.Loadsimilartypeitems.
Odorsremaininitems
afterCoolAir
• Makesuretothoroughlywashitemswithstrongodors.
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 23 2021/7/19 14:48:50
background
English24
Specications
Protecting the environment
• Thisapplianceismanufacturedfromrecyclablematerials.Ifyoudecidetodisposeofthis
appliance,pleaseobservelocalwastedisposalregulations.Cutoffthepowercordsothatthe
appliancecannotbeconnectedtoapowersource.Removethedoorsothatanimalsandsmall
childrencannotgettrappedinsidetheappliance.
• Containsuorinatedgreenhousegases.
Hermeticallysealedequipment.
Donotventgasesintotheatmosphere.
Refrigerant(Type):R-134a(GWP=1430)
Refrigerant(Charging):0.43kg,0.615tCO
2e
Specication sheet
Inaccordancewithapplicableenergylabellingregulations.
NOTE
“*”Asterisk(s)meansvariantmodelandcanbevaried(0-9)or(A-Z).
Samsung
ModelName
DV90T6240**
DV90T5240**
DV8*T6220**
DV8*T5220**
Capacity kg 9.0 8.0
Type Condenser Condenser
Energy Efciency
A+++(highestefciency)toD(leastefcient) A+++ A+++
Energy Consumption
AnnualEnergyConsumption(AE_C)(Energyconsumptionis
basedon160dryingcyclesofthestandardcottonprogramme
atfullandpartialload,andtheconsumptionofthelow-power
modes.Actualenergyconsumptionpercyclewilldependon
howtheapplianceisused.)
kWh/yr 194.0 176.0
Automatictumbledrier Yes Yes
Energyconsumption(E_dry)standardcottonprogrammeatfull
load
kWh 1.54 1.41
Energyconsumption(E_dry.1/2)standardcottonprogrammeat
partialload
kWh 0.89 0.80
offmodeandleft-onmode
Thepowerconsumptionoff-mode(P_o)atfullload W 0.50 0.50
Thepowerconsumptioninleft-onmode(P_l)atfullload W 5.00 5.00
Durationoftheleft-onmode min 10 10
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 24 2021/7/19 14:48:50
background
English 25
ProgrammetowhichtheinformationonthelabelandtheSheetrelate(‘standard
cottonprogramme’usedatfullandpartialloadisthestandarddryingprogrammeto
whichtheinformationinthelabelandthecherelates.Thisprogrammeissuitablefor
dryingnormalwetcottonlaundryanditisthemostefcientprogrammeintermsof
energyconsumptionforcotton.Consumptiondatacanvaryfromthenominalvalues
givenabovedependingonthesizeoftheload,typesoftextiles,residualmoisture
levelsafterspinning,uctuationsintheelectricitysupplyandanyextraoptions
selected.)
Cotton+DryLevel2+(Wrinkle
PreventOff)
programmedurationofthestandardprogram
WeightedProgrammetimestandardcottonprogrammeatfull
loadandpartialload
min 174 160
ProgrammeTime(T_dry)standardcottonprogrammeatfullload min 220 200
ProgrammeTime(T_dry.1/2)standardcottonprogrammeat
partialload
min 140 130
condensationefciencyclass
A(mostefcient)toG(leastefcient) B B
Averagecondensationefciencyatfullload % 87 87
Averagecondensationefciencyatpartialload % 87 87
Weightedcondensationefciency % 87 87
Airborne noise emissions
Dryatfullload dB(A)re1pW 63 63
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 25 2021/7/19 14:48:50
background
English26
Consumption data
Model Cycle Load (kg)
(1)
Energy (kWh)
Max. Duration
(Minutes)
DV90T6240**
DV90T5240**
Cotton
(2)
9.0 1.54 220
4.5 0.89 140
IronDry
(2)
9.0 0.95 140
Synthetics 4.5 0.7 98
DV80T6220**
DV80T5220**
Cotton
(2)
8.0 1.41 200
4.0 0.8 130
IronDry
(2)
8.0 0.9 130
Synthetics 4.0 0.6 90
(1)
:Weightofdrylaundry
(2)
:EN61121:2013testprogram
Alldatawithouta“star”againstitwascalculatedusingEN61121:2013
Consumptiondatacanvaryfromthenominalvaluesgivenabovedependinginthesizeofthe
load,typesoftextiles,residualmoisturelevelsafterspinning,uctuationsintheelectricity
supplyandanyextraoptionsselected.
Network standby power consumption
Power consumption
Network Standby mode 1.90 W
Time in networked standby mode
(Wi-Fi)
10 min
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 26 2021/7/19 14:48:50
background
Memo
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 27 2021/7/19 14:48:50
background
DC68-04169B-01
DV6000T_DV5000T_MANUAL_04169B-01_EN.indd 28 2021/7/19 14:48:50

Specifications

Indexed Terms: Heat Pump Dryer, Tumble Dryer

Samsung DV90T6240LB/S1 Questions and Answers

Find answers or ask new question.
See other models: WW11DG6B85LEU1 WW11DG6B85LBU1 DV90T6240LE/S1 DV90BB9545GBS1 RF24BB620EB1EU
Questions and Answers
