AXLE STANDS (PAIR) 20 TONNE CAPACITY PER

STAND

MODEL NO: AS20.V2

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

 WARNING! DO NOT overload Axle stands beyond rated capacity. Overloading can cause damage to, or failure of, the axle

stands. Position load on centre of crutch/saddle only. Always use stands in pairs on hard level surface capable of sustaining

the load. Use of stands on other than hard level surfaces can result in load instability and possible loss of load. DO NOT

use on tarmacadam. Failure to follow these instructions may result in damage to axle stands, loss of load resulting in

property damage, serious personal injury or loss of life.

▲ DANGER! Great care must be taken to ensure you lower the vehicle (or other load) slowly and carefully onto the centres of

the crutch/saddle of the axle stands.

9  Useonlyasspeciedbythemanufacturer.

9  Ensuretheloaddoesnotexceedthemaximumcapacityasmarkedontheaxlestand,perpair.

9  Usenomorethanasinglepairofstandseitheronthefront,rearoronesideofthevehicle.Useinpairs.

9  Noalterationsormodicationsshallbemadetothisproduct.

9  Useonahard,levelsurface,e.g.concrete.Donotuseonunevengroundortarmacadam.

9  Securelychockwheelsincontactwiththeground.Beforejackingandplacingthestands,applyvehiclehandbrake,andplaceingear.

 (Forautomaticsselectthe‘Park’mode).

9  Makesurethateachstandissecurelylocatedunderastrongpointonthevehicle;consultthevehiclemanufacturer’s 

 handbookforguidance.Ensurethatheightadjustlockingmechanismisfullylocatedbeforeapplyinganyloadtothe

 axlestand.

9  Ensurethattheloadislocatedcentrallyonthesaddle,andthattheweightisdirectedthroughtheverticalaxisofthe

 stand.

9  Exerciseextracarewhenusingwithathreewheeledvehicleoratrailer.Refertovehiclemanufacturer’sinstructions.

9  Oncevehicleissupported,ensurethatthevehicleandstandsarestablebeforestartingwork.Ensurethatitisnot

 possibleforthevehicletomovebeforecommencinganywork.

9  Inspectstandsbeforeeachuse.

8 DO NOTuseiftheyshowsignsofdamage.

8 DO NOTuseifitissuspectedthattheyhavebeenoverloaded.

9  Beforecommencinganyworkorgoingbeneaththevehicle,undertakeariskassessment.Ensurethataresponsiblepersonisaware

 oftheworkabouttobeundertaken.

9  Replaceanylabelsontheaxlestandshouldtheybecomeunreadable.Thisappliesinparticulartoanywarningoroperationinstruction

 labels.Ifreplacementlabelsarerequired,contactyourSealeystockist.

8 DO NOTuseaxlestandsonthehighway,oranywhereelseifitisdeemedtobeunsafe.

8 DO NOTpushortwistthevehicle/loadwhilstitissupportedonstands.

8 DO NOTmixcomponentsbetweenstands.Useonlyassupplied.

8 DO NOTallowchildrenoranimalsinthevicinityofavehiclesupportedonaxlestands.

8 DO NOTleaveavehicleonaxlestandsinanareathatcouldbeconsideredahazardtoothersorproperty.

9 Follow steps 1, 2 and 3 to correctly place vehicle/load onto axle stands.

AS20.V2Issue214/04/23

Original Language Version

©JackSealeyLimited

Referto

instructions

TAKE CARE;youmayknowthetotalweightoftheloadyouwanttosupportbutyoucannotcalculatetheexact

weightdistributionbetweensupportpoints.

Forthisreasonalwaysallowa40%marginforerror.

Forexample:aloadweighing40tonnecouldhaveasinglepointloadofmorethan20tonneandtwo20tonne

supportswouldnotbeadequate.

2. INTRODUCTION

Heavy-dutyaxlestandstosafelysupportvehiclesforextendedperiodsoftime.Largecrutchforevenloaddistribution.Heavygaugesteelframe

andbaseplatewithweldedconstructiongivessuperiorstrengthandsafety.Suppliedwithcaptive,multi-positionpinloadsupport.Soldinpairs.

3. SPECIFICATION

ModelNo:................................................................. AS20.V2

Capacity(each):........................................................ 20tonne

Capacity(pair):.......................................................... 40tonne

Minimumheight:......................................................... 332mm

Maximumheight:........................................................ 485mm

4. OPERATION

4.1. Familiariseyourselfwiththeproduct.Checkthatthestandsareingoodconditionandthatnodamagehasbeensustainedduring 

 transit.

4.2. Ensurethemaximumloaddoesnotexceed40tonneperpairofaxlestands,(20tonneforeachstand).

4.3. Refertovehiclemanufacturer’sinstructionsforrecommendedsupportpoints.Checkthatthepointsareingoodcondition.

4.4. Ensurethevehiclehasbeenplacedingearandthatthehandbrakehasbeenapplied.(Forautomaticsselectthe‘Park’mode).

4.5. Adjustheightofstandtocorrespondwiththeraisedvehicle.

4.6.  Checkthatthelockingpin(g1-3)iscorrectlypushedallthewaythroughthecentrecolumn(g1-1)andoutoftheotherside,then

 positionstandsundervehicleatpointsrecommendedbyvehiclemanufacturer.

4.7. Carefullyandslowlylowertheloadontostands.Ensuretheloadbearingpointssitinthecenterofthestandsaddleandcheckthat

 thestandsarestableandnotleaning.Alsoensurethattherearenoobjectsorpersonsthatcouldimpedethesafeloweringofthevehicle

 ontothestands.

4.8.  Toremovestands,jackvehicleslightlysothatstandcanberemoved.

4.9. Afteruse,holdthecentrecolumn(g1-1)rmlywhenremovingthelockingpin(g1-3).Failuretodosowillallowthecentercolumn

 tofallfreelythroughthemaincentertube(g1-2)withtheriskofpersonalinjury.

4.10.  Whennotinuseplacethelockingpin(g1-3)intoit’scircularholder(g2-1)andleavethecentrecolumn(g1-1)init’slowest 

 positiontominimisecorrosion.

 WARNING!Ensureyoufollowallinstructionscarefully.Failuretonotethesewarningsmaycausedamage,seriousinjuryorlossoflife.

5. MAINTENANCE

5.1.  Beforeeachusechecktoensurestandsandstandweldsarenotcracked,andthattherearenomissingand/ordamagedparts.

 WARNING!Anystandthatappearstobedamagedinanywaymustberemovedfromserviceimmediately.

5.1.1.  Ensurethelockingpinsareingoodorderandcondition.

5.1.2.  Duetothepotentialhazardsassociatedwiththesestands,donotmisuse,ormakeanymodicationtothestandsorcomponents.

5.1.3.  Itistheresponsibilityofthestandsownertoensuretheoperatorhasreadtheseinstructions,andthattheoperatorisfamiliarwith

 thestandsuseandlimitations.

ENVIRONMENT PROTECTION

Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento

arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely

unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids

accordingtolocalregulations.

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior

notice.Pleasenotethatotherversionsofthisproductareavailable.Ifyourequiredocumentationforalternativeversions,pleaseemailorcall

ourtechnicalteamontechnical@sealey.co.ukor01284757505.

Important:NoLiabilityisacceptedforincorrectuseofthisproduct.

Warranty:Guaranteeis3yearsfrompurchasedate,proofofwhichisrequiredforanyclaim.

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 sales@sealey.co.uk www.sealey.co.uk

g.1
