FLOOR STANDING METAL FOLDER 910MM
MODEL NO: DF910.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Wearapprovedsafetygogglesandprotectivegloveswhenoperatingthefolder.YourlocalSealeystockisto󰀨ersacompleterangeof
safetyequipment.
9 Use the tool only for its intended purpose.
9 Checkregularlyfordamagedparts.DO NOTuseifanycomponentsarebroken,wornordamaged.
9 UseoriginalSealeysparepartsandaccessories.Useofnon-recommendedsparepartsmaybedangerousandwillinvalidate
warranty.
8 DO NOToperatethistoolwhileundertheinuenceofdrugs,alcoholorotherimpairingmedication.
8 DO NOTallowunqualiedpersonstooperatethemetalfolder.Keepchildrenawayfromthetool.
2. INTRODUCTION
Floorstandingmetalfolderwith910mmcapacity.Manuallyoperatedandsuitableforfoldingupto0.8mmsheet.
3. SPECIFICATION
Model no: ............................................................... DF910.V2
Capacity: ...................910mmx22GaugeSheet,Ø2mmRod
Note:whenbending2mmstripor2mmdiametersteelrod,theymustbeplacedclosetooneofthesetscrews.
4. CONTENTS
Unpacktheunitandcheckthatallpartsareincludedandnotdamaged.Shouldyouexperienceaproblemcontactyoursupplier
immediately.
Contents:1xMainframe.2xCrossbars.1xFoldingplate.1xFootstand.1xBagofnuts/Boltsconsistingof:2xSetscrews
(L-shaped),6xBolts,6xNuts,6xWashers.
5. ASSEMBLY
Refer to Parts list
5.1. Laythefoldermainframe(g.1.A)ontheoorwiththetop
foldingplate(g.1.1)uppermost.
5.2. Attachthefootstand(3)tothelegsofthemainframe(A)
usingthenuts,boltsandwasherssupplied.Thefootstand
crossbar(3)mustbefacinguppermostwhenthemain
frameisontheoor.
5.3. Ensurethesupportbrackets(4)aresecuredtotheoutside
ofthemainframelegsandtheoutsideofthefootstand.
5.4. Fullytightenallnutsandbolts.
5.5. AttachthetopplateusingtheL-shapedsetscrews(2).
5.6. Raiseassembledfoldertouprightpositionsothefootstand
crossbar(3)andlifttopfoldingplate(1)aretothefrontofthe
unit.
Referto
instruction
manual
Wear eye
protection
Wear
protective
gloves
DF910.V2Issue:3(3,5)
Original Language Version
©JackSealeyLimited
Fig.1
background
6. OPERATION
6.1. Screwthetwoadjustingnuts(B)downtoensurethefoldingplates(C)areparallel.Thismyrequirefurtheradjustmentfromtimeto
time.
6.2. Insertatestpieceofsheetmetalinthefolder.
6.3. Securethemetalbetweenthefoldinglipsbytighteningthetwoclamps,whilstensuringthereisevenpressureonbothends.
6.4. Placeyourfootonthebasecrossbar(3).
6.5. Raisethetopfoldingplate(1)tocreatethefold.Fromthistest,youwillbeabletodeterminehowandwherethefoldappears.
6.6. Whensatisedwiththetestresults,proceedwiththeactualworkpiece.
6.7. Repeattheabovesteps6.2-6.5foreachnewworkpiece.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento
arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely
unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids
according to local regulations.
Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior
notice. Pleasenotethatotherversionsofthisproductareavailable.Ifyourequiredocumentationforalternativeversions,pleaseemailorcall
ourtechnicalteamontechnical@sealey.co.ukor01284757505.
Important:NoLiabilityisacceptedforincorrectuseofthisproduct.
Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
Original Language Version
©JackSealeyLimited
DF910.V2Issue:3(3,5)
