STAINLESS STEEL WORKBENCH
MODEL NO: AP1248SS.V2, AP1560SS.V2,
AP1872SS.V2, AP2184SS.V2.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this bench.
9 Locate bench in a suitable working area.
9 Keep the work area clean, uncluttered and ensure there is adequate lighting.
WARNING! Use bench on level and solid ground, preferably concrete. Avoid tarmacadam since the bench may sink into the surface.
9 Keep the bench clean and tidy in accordance with good workshop practice.
9 Keep children and unauthorised persons away from the working area.
8 DO NOT use the bench for any purpose other than that for which it is designed.
8 DO NOT exceed maximum capacity of workbench.
8 DO NOT undertake work on the bench without the work piece being adequately secured. Use clamps or a vice (not included) to secure the
work piece. Available from your Sealey stockist.
8 DO NOT use the bench out of doors.
8 DO NOT get the bench wet or use in damp or wet locations or areas where there is condensation.
2. INTRODUCTION
Galvanized steel frame with a 430 grade stainless steel worktop. Features an adjustable bottom shelf for added storage space.
Maximum capacity of 145kg on Model No’s AP1248SS and AP1560SS, and 170kg on Model No’s AP1872SS and AP2184SS.
Adjustable feet for levelling the workbench when placed on an uneven surface. Some simple assembly required.
3. SPECIFICATION
Model No: ................................................AP1248SS.V2
Size (W x D x H): ............................1220 x 760 x 890mm
Bench Top Capacity: ............................................. 100kg
Bottom Shelf Capacity: ............................................45kg
Model No: ................................................AP1560SS.V2
Size (W x D x H): ............................1530 x 760 x 890mm
Bench Top Capacity: ............................................. 100kg
Bottom Shelf Capacity: ............................................45kg
Model No: ................................................AP1872SS.V2
Size (W x D x H): ............................1830 x 760 x 890mm
Bench Top Capacity: ............................................. 120kg
Bottom Shelf Capacity: ............................................50kg
Model No: ................................................AP2184SS.V2
Size (W x D x H): ............................2135 x 760 x 890mm
Bench Top Capacity:: ............................................ 120kg
Bottom Shelf Capacity: ............................................50kg
4. CONTENTS
Item Description Qty.
1 Table top 1
2 Shelf 1
3 Legs 4
4 Socket screws 8
5. ASSEMBLY
5.1. Place the workbench top face down on the oor, use the packaging to avoid scratching, Step 1.
5.2. Insert legs into sockets, fasten screws, Step 2.
5.3. Pass the shelf over the legs and slide on for at least 230mm, so that the shelf will sit at least 150mm above the oor when completed,
Step 3.
5.4. Tighten the screws, step 4. Turn workbench over and adjust feet to level unit.
Refer to
Instructions
AP1248SS.V2, AP1560SS.V2, AP1872SS.V2, AP2184SS.V2 Issue 2 (H,3,F) 12/09/23
Original Language Version
© Jack Sealey Limited
Step 1 Step 2
Step 3
Step 4
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
AP1248SS.V2, AP1560SS.V2, AP1872SS.V2, AP2184SS.V2 Issue 2 (H,3,F) 12/09/23
Original Language Version
© Jack Sealey Limited
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please
email or call our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
