1
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
White Convector Heater with Turbo, Timer & LCD
Model No. HEA1812
User Manual
2
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
White Convector Heater with Turbo, Timer & LCD
Model No. HEA1812
User Manual
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Convector Heater.
• Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
• WARNING! In order to avoid overheating, DO NOT
COVER the heater.
• WARNING! To reduce the risk of fire, keep textiles,
curtains, or any other flammable material a minimum
distance of 1m from the air outlet.
• DO NOT locate the appliance immediately below an
electrical socket outlet.
• DO NOT use this heater with an extension cable.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• Close supervision is required when using this appliance
near children.
• DO NOT leave this appliance within reach of children.
• This appliance can be used by children aged from 8 years
3
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
White Convector Heater with Turbo, Timer & LCD
Model No. HEA1812
User Manual
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Children of less than 3 years should be kept away unless
continuously supervised.
• Children aged from 3 years and less than 8 years shall only
switch on/off the appliance provided that it has been
placed or installed in its intended normal operating
position and they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children aged from
3 years and less than 8 years shall not plug in, regulate
and clean the appliance or perform user maintenance.
• WARNING! Some parts of this product can become
very hot and cause burns. Particular attention has to be
given where children and vulnerable people are present.
• DO NOT use this heater in the immediate surroundings of
a bath, a shower or a swimming pool.
• DO NOT use this heater in small rooms when they are
occupied by persons not capable of leaving the room on
their own, unless constant supervision is provided.
• DO NOT immerse the appliance or its cord in water or any
other liquids.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
to the mains supply.
• Always use this appliance on a solid, level, non-flammable
surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
4
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
White Convector Heater with Turbo, Timer & LCD
Model No. HEA1812
User Manual
appliance has been used, before it is cleaned and whilst
being repaired.
• Repairs to electrical appliances should only be performed
by a qualified electrician. Improper repairs may place user
at serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• If the power cable is damaged, it should only be replaced
by the manufacturer or a suitable qualified after-sales-
service in order to avoid a hazard.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• DO NOT run the mains cable under carpets, rugs, etc.
• Allow the unit to cool before storage.
• Before cleaning, disconnect the appliance from the mains
supply and allow to cool.
• DO NOT place the appliance near to flammable material
or high pressure containers. (e.g., Paper, wood, petrol,
solvents, spray canisters etc.)
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• The appliance should not be installed in areas which have
a fire-risk, such as garages, stables or wooden sheds; this
5
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
White Convector Heater with Turbo, Timer & LCD
Model No. HEA1812
User Manual
is applicable also for rooms in which highly inflammable
gasses or dust can develop. Danger of fire!!
• Unplug after each use. Grasp the plug, not the cord.
CAUTION
Keep Hearth Rugs and other soft furnishings away
from the heater. They could obstruct the free flow
of air from the heater and damage both soft
furnishings and heater.
The heater must stand on a solid, level non-
flammable surface such as stone, slate, ceramic or
concrete.
DO NOT Stand the heater on a carpet, rug or other
soft floor covering.
DO NOT COVER THE HEATER
THIS HEATER MUST ONLY BE OPERATED IN THE
UPRIGHT POSITION WITH THE FEET FITTED.
THIS APPLIANCE MUST BE EARTHED
This appliance has been ERP classified as a portable space heater and should
only be used for supplementary, secondary or temporary heating. It should not
be considered for primary permanent heating in a room or dwelling.
During the first few minutes of initial use, you may notice a slight odour
and a little smoke. This is normal and will quickly disappear, It is the coating
applied to the heating elements to prevent any corrosion during transit.
6
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
White Convector Heater with Turbo, Timer & LCD
Model No. HEA1812
User Manual
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk enter your postcode to find out your
nearest recycling site.
This symbol provides useful additional information on the use of
this product.
This symbol indicates that the supply uses an alternating current
mains supply.
Before first use of Your Convector Heater
Remove all packing materials and discard responsibly.
Ensure that all parts are present before assembling your heater – see Description
of Parts below:
7
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
White Convector Heater with Turbo, Timer & LCD
Model No. HEA1812
User Manual
Description of Parts & Controls
1. Air Outlet
2. Control Panel
3. LCD Display
4. Remote Control Storage Tray
5. Carrying Handle
6. Air Outlet
7. Mains Switch
8. Temperature Sensor
9. Feet (x2)
10. Air Inlet
11. Self-Tapping Screws (x8)
12. Heat Level Mode
13. Fan Symbol
14. Frost Protect Symbol
15. Unit of Temperature
16. Power Level Button
17. ⁰F or ⁰C Button
18. Infra Red Receiver
19. On/Off (Standby) Button
20. Fan Button
21. Increase Temperature Button +
22. Decrease Temperature Button –
23. Timer Button
6
1
2
10
3
4
5
7
2
8
9
9
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
24. Room Temperature.
25. Set Temperature.
26. Timer Display.
8
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
White Convector Heater with Turbo, Timer & LCD
Model No. HEA1812
User Manual
Description of Parts – The Remote Control
Assembling your Convector Heater
Before using this heater, the feet (9) must be fitted to the unit. These are attached
to the base of the heater using the eight Self-tapping Screws (11) provided; take
care to ensure that they are located correctly in the holes at either end of the base
of the appliance:
1. Left: Turn the convector heater
upside down and locate the eight
feet fixing holes in the base of
the heater (arrowed left).
It is recommended that the
heater is placed on cardboard, or
a towel, etc. to prevent damage
to the finish of the heater.
2. Attach both the feet (9) using the
eight Self Tapping Screws (11)
provided using a suitable crosshead
screwdriver (not supplied).
1. On/Off Button
2. Fan Button
3. Increase Temperature Button +
4. Timer Button
5. Heat Level Mode
6. ⁰F or ⁰C Button
7. Decrease Temperature Button –
9
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
White Convector Heater with Turbo, Timer & LCD
Model No. HEA1812
User Manual
Operating Instructions – the heat settings
1. Place the heater upright on its feet (9) on a solid, level, non-flammable surface.
2. Insert the mains plug into the mains socket.
3. Press the Mains Switch (7) to the ON position (I). The switch will illuminate to
indicate the power is on and the LCD Display (3) will show the current room
temperature on the Room Temperature display (24).
4. Press the On/Off Standby button (19) on the Control Panel (2), the control
panel will illuminate and display the Room Temperature (24) and Set
Temperature (25).
Setting the Temperature
1. With the display showing the room temperature and the set temperature
as above, use the Increase Temperature + (21) and the Decrease
Temperature – (22) buttons to set the desired temperature on the Set
Temperature (25) display.
2. Press the Power Level button (16), to select the heating power level required,
(1000W, 1300W or 2300W – as shown on the Heat Level Mode (12) on the LCD
Display (3)).
3. The heater will now start to heat the room at the set temperature.
The set temperature range is 5-37⁰C, (41-99⁰F).
Press the ⁰F or ⁰C Button (17) to change the display between degrees
Centigrade or degrees Fahrenheit.
Using the Timer
This heater has a built in timer which switches the heater off after a maximum
time of 24 hours. Set the timer as follows:
1. First, set the heat settings up as above in ‘Setting the Temperature’ before
setting the timer.
2. Press the Timer button (23) once and the Timer Display (26) will flash.
3. Repeatedly press or hold down the Timer button (23) to select the desired
time (in hours) before the heater switches off is shown on the Timer Display
(26).
4. The timer will count down and then switch off the heater once the time has
elapsed. Press the On/Off Standby button (19) to switch the heater back on
again if required.
Cancelling the Timer
1. Repeatedly press the Timer button (23) until the time shows 24 hours on the
Timer Display (26).
2. Press the Timer button (23) once more and the Timer Display (26) will go out
showing that the timer is now cancelled. Press the Timer button (23) again to
enable the timer again if required.
10
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
White Convector Heater with Turbo, Timer & LCD
Model No. HEA1812
User Manual
Using the Frost Protection
This heater has a frost protection mode whereby the heater can be set to come
on should the temperature drop to 5⁰C (41⁰C) or lower. The heater will switch off
if the temperature rises to 9⁰C.
1. To enable the Frost Protection mode, press the On/Off Standby button (19)
and then press the Power Level button (16) until the Frost Protection Symbol
(14) is shown on the LCD Display (3).
Using the Turbo Fan
Press the Fan Button (20) to enable the Turbo Fan, to boost heating. The air will
be blown out of the Air Outlet (6).
For cool air, first press the On/Off Standby button (19) to power up the heater,
then press the Fan Button (20).
Using the Remote Control
The Remote Control duplicates the controls on the control panel allowing you to
control your convector heater remotely.
If using the Remote Control for the first time, pull
the tab from the battery compartment as shown
right:
Replacing the Battery in the Remote Control
If the Remote-Control range has become reduced or it has stopped working
altogether the battery will need replacing as shown below:
A Push the tab on the
battery compartment in
the direction of the arrow
as shown above.
B Slide out the battery
compartment and insert a new
CR2032 battery ensuring the
positive polarity marking is
uppermost.
C Slide the battery
compartment back into
the Remote Control.
11
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
White Convector Heater with Turbo, Timer & LCD
Model No. HEA1812
User Manual
• CAUTION: There is a danger of explosion if the battery is incorrectly fitted.
• Ensure that the battery is installed with the correct polarity.
• It is recommended that battery is removed if the remote if it is not to be used
for a long period of time or if the remote is to be disposed of.
• Replace only with the same or equivalent battery type.
• Store batteries in a cool dry place.
• Do not expose the battery to sunshine, fire, heat or similar, never dispose of
batteries in a fire.
• Do not charge non-rechargeable batteries.
• Do not short-circuit batteries.
• Exhausted batteries are to be removed from the product and safely disposed
of.
WARNING!
• Do not ingest the battery, Chemical Burn Hazard.
• The remote control supplied with this product contains a coin/button cell
battery.
• If the coin/button cell battery is swallowed, it can cause severe internal burns
in just 2 hours and can lead to death.
• Keep new and used batteries away from children and animals.
• If the battery compartment does not close securely, stop using the product and
keep it away from children.
• If you think batteries might have been swallowed or placed inside any part of
the body, seek immediate medical attention.
• If the batteries leak, remove them immediately to avoid damaging the product.
Do not remove the batteries with your bare hands or allow the battery fluid to
come into contact with your skin, eyes or mucous membranes. Wear normal
household gloves to do so. If, however, your skin has come into contact with
the battery fluid, wash your skin immediately, if necessary, seek medical
attention.
Care and Use of your Convector Heater
• Always disconnect the convector heater from the mains power supply and
allow to cool before cleaning.
• Clean outside of the convector heater with a clean damp cloth. Never clean
with harsh or abrasive cleaners.
• Do not submerge any part of the convector heater in water or any other liquids.
12
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
White Convector Heater with Turbo, Timer & LCD
Model No. HEA1812
User Manual
Technical Specification
Rated Voltage
220-240V AC ~ 50-60Hz
Rated Power
2000-2300W
Model Number
HEA1812
Protection Class
I (This Appliance Must Be Earthed)
Dimensions
415mm (H with feet) x 680mm (W) x 180mm (D with feet)
Weight
4.58kg
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). If in doubt, consult a qualified
electrician who will be pleased to do this for you. If you need to remove the plug
– DISCONNECT FROM THE MAINS – and then cut it off the mains lead and
immediately dispose of it safely. Never attempt to reuse the plug or insert it into a
socket outlet as there is a danger of electric shock.
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk enter your postcode to find out your
nearest recycling site.
13
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
White Convector Heater with Turbo, Timer & LCD
Model No. HEA1812
User Manual
14
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
White Convector Heater with Turbo, Timer & LCD
Model No. HEA1812
User Manual
ErP Data
Model
Item
Symbol
Value
Unit
Item
Unit
Heat output
Type of heat input, for electric storage local space
heaters only (select one)
Nominal heat
output
P
nom
2.3
KW
manual heat charge control, with
integrated thermostat
Not applicable
Minimum
heat output
(indicative)
P
min
1.0
KW
manual heat charge control with room
and/or outdoor temperature feedback
Not applicable
Maximum
continuous
heat output
P
max,c
2.3
KW
electronic heat charge control with room
and/or outdoor temperature feedback
Not applicable
Auxiliary electricity consumption
fan assisted heat output
Yes
At nominal
heat output
el
max
0
KW
Type of heat output/room temperature control (select
one)
At minimum
heat output
el
min
0
KW
single stage heat output and no room
temperature control
[no]
In standby
mode
el
SB
0
KW
Two or more manual stages, no room
temperature control
[no]
with mechanic thermostat room
temperature control
[no]
with electronic room temperature control
[yes]
electronic room temperature control plus
day timer
[no]
electronic room temperature control plus
week timer
[no]
Other control options (multiple selections possible)
room temperature control, with
presence detection
[no]
room temperature control, with open
window detection
[no]
with distance control option
[yes]
with adaptive start control
[no]
with working time limitation
[no]
with black bulb sensor
[no]
HEA1812
15
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
White Convector Heater with Turbo, Timer & LCD
Model No. HEA1812
User Manual
