Sealey AP5520SS Mobile Stainless Steel Tool Cabinet 10 User Manual

10 DRAWER & 2 WALL CUPBOARD STAINLESS STEEL

MOBILE TOOL CABINET WITH BACKBOARD

MODEL NO: AP5520SS

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

 WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this

product.

9 Locate in a suitable work area.

8 DO NOT let children near the cabinet.

8 DO NOT open more than one drawer at a time.

9  Fillfromthebottomdrawerup.Ifthetoolcabinetislledfromthetopdrawerdown,itwillbetopheavyandmayfallover.

8 DO NOTattempttoliftbythesidehandles,usechains,ropesorotherliftingdevices.

8 DO NOT step or climb on the product or on the drawers.

8 DO NOT alter the product in any way, e.g. do not weld on external lock bars or attach electrical equipment. This may cause damage to

the product or cause personal injury.

9  Keeponalevelsurface.

9  WhenmovingthecabinetDO NOTpullit.Pushthecabinettopreventinjury.

9  Closeandlockthedrawersbeforemovingthecabinet.Ifthedrawerscameopentheycouldmakethecabinetunstable.

9 Apply the brakes when in desired position.

8 DO NOTmountonatruckbedoranyothermovingobject.

8  Beawareofsharpedgesweargloves.

2. INTRODUCTION

Anti-ngerprintstainlesssteelconstruction.Suppliedwitha38mmthickwoodenworktop.10Drawerswitha45kgcapacityeach.Eachdrawer

featuresaluminiumpullhandlesandnon-slipliners.Fourlargecastorwheels,twoxedandtwoswivel,thatincludebrakes.Suppliedwitha

pegboardbackpanel-idealforhangingtools-andtwogasstrutwallcabinetsforaddedstorage.Cabinetsuppliedwithaheavy-dutyside

handleforcomfortandcontrolwhenmanoeuvring.Suppliedwithlocksandtwokeyseach.Somesimpleassemblyrequired.

3. SPECIFICATION

Model no: ............................................................ AP5520SS

Overallsize(WxDxH): ..................... 1475x505x1860mm

Medium1/2drawer(x3): ...........................375x395x65mm

Large1/2drawer(x1): ............................. 375x395x140mm

X-large1/2drawer(x1): ..........................375x395x220mm

Mediumdrawer(x3): .................................855x395x65mm

Largedrawer(x1): ...................................855x395x140mm

X-largedrawer(x1): ................................855x395x220mm

Wallcabinet(x2): ....................................645x300x410mm

AP5520SSIssue:2(HF)18/01/24

Original Language Version

Refer to

Instruction

Manual

Wear

Protective

gloves

4. ASSEMBLY (REFER TO PARTS LIST)

4.1. FIT HANDLE SEE STEP 1

4.1.1. Attachhandlewith6mmx12mmhexbolts,springandatwashers.

4.2. FIT CASTERS SEE STEP 2

 WARNING! Two or more people are required to lay down or stand up the cabinet. DO NOT stand in front or behind and lock drawers

 whilstturningover.

4.2.1. Carefully lay the cabinet upside down with a soft mat underneath for protection.

4.2.2. Fitthetwoswivel/brakedcastors,onthehandlesideusing10mmx25mmbolts,througheachcastorandintothebottomofthe 

cabinet. Tighten securely.

4.2.3. Repeat for the two rigid casters on the other side.

4.3. DRAWERS SEE STEP 3

4.3.1. Newdrawersslidesmaybestiffanddifculttoopenatrst.Agentleoutwardpullshouldreleasethesafetycatchthatpreventsthe

 drawerfromopeningwhilstthecabinetisbeingmoved.

4.3.2. Removedrawersfromtheirslidesasbelow(pullleftslidetabdownandpullrightsideslidetabup).

4.4. FIT UPRIGHTS SEE STEP 4 & STEP 5

4.4.1. Fitthetwouprightstothecabinetwithfour6mmx14mmhexbolts

to each.

4.4.2. Inserttheuppersectionoftheuprightsintothelowerone(Step5).

Step 3

Step 1

Step 2

Original Language Version

Step 4

Step 5

AP5520SSIssue:2(HF)18/01/24

Original Language Version

4.5. FIT BACKBOARD SEE STEP 6

4.5.1. Fitthebackboardtotheuprightswithsix6mmx14mmbolts.

4.6. FIT WALL CUPBOARDS SEE STEP 7

 WARNING! Two or more people will be required to hold the wall cupboard in position whilst it is being bolted to the uprights.

4.6.1. Fitwallcupboardtouprightswithsix6mmx14mmhexbolts.

5. MAINTENANCE

5.1. To clean use a soft cloth that will not scratch the surface.

8 DO NOTusesolventsofanykindtheymaydamagethesurface.

5.2.  Liquidspillsshouldberemovedimmediately,useasoftcleanclothtoblotthespillgently-avoidrubbing.

5.3. Grease the casters with good quality grease once a year.

5.4. Lubricate the drawer slides twice a year with light duty oil.

Step 6

Step 7

AP5520SSIssue:2(HF)18/01/24

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 sales@sealey.co.uk www.sealey.co.uk

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specicationsandcomponentpartswithoutpriornotice.

Important: No Liability is accepted for incorrect use of this product.

Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.

ENVIRONMENT PROTECTION

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be

sorted,takentoarecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.When

theproductbecomescompletelyunserviceableandrequiresdisposal,drainanyuids(ifapplicable)intoapproved

containersanddisposeoftheproductanduidsaccordingtolocalregulations.
