Sealey Premier AP7210SS Mobile Stainless Steel Tool Cabinet User Manual

INSTRUCTIONS FOR

MOBILE STAINLESS STEEL TOOL CABINET

10 DRAWER & CUPBOARD

MODEL NO: AP7210SS

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

 WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this

product.

9 Locate in a suitable work area.

8 DO NOT let children near the cabinet.

8 DO NOT open more than one drawer at a time.

9  Fillfromthebottomdrawerup.Ifthetoolcabinetislledfromthetopdrawerdown,itwillbetopheavyandmayfallover.

8 DO NOTattempttoliftbythesidehandles,usechains,ropesorotherliftingdevices.

8 DO NOT step or climb on the product or on the drawers.

8 DO NOT alter the product in any way, e.g. do not weld on external lock bars or attach electrical equipment. This may cause damage to

the product or cause personal injury.

9  Keeponalevelsurface.

9  WhenmovingthecabinetDO NOTpullit.Pushthecabinettopreventinjury.

9  Closeandlockthedrawersbeforemovingthecabinet.Ifthedrawerscameopentheycouldmakethecabinetunstable.

9 Apply the brakes when in desired position.

8 DO NOTmountonatruckbedoranyothermovingobject.

8  Beawareofsharpedgesweargloves.

2. INTRODUCTION

Anti-ngerprintstainlesssteelconstructionwitha38mmthickwoodenworktop.45kgcapacitydrawerswithaluminiumpullhandlesandnon-slip

liners.Fourlargecastorwheels,twoxedandtwoswivel(whichincludebrakes).Comeswithheavy-dutysidehandleforcomfortandcontrol

whenmanoeuvring.Suppliedwithlocksandkeys.

3. SPECIFICATION

Model no: ............................................................ AP7210SS

Overallsize(WxDxH): ....................... 1990x490x955mm

Medium1/2drawer(x3): ...........................375x395x65mm

Large1/2drawer(x1): ............................. 375x395x140mm

X-large1/2drawer(x1): ..........................375x395x220mm

Mediumdrawer(x3): .................................855x395x65mm

Largedrawer(x1): ...................................855x395x140mm

X-largedrawer(x1): ................................855x395x220mm

Cupboardsize(x1): ................................. 400x465x685mm

AP7210SS|Issue1-10/05/16

Original Language Version

Refer to

Instruction

Manual

Wear

Protective

gloves

4. ASSEMBLY

4.1. Fit handle

4.1.1. Attachhandlewith6mmx12mmhexbolts,springand

 atwashers.

4.2. Fit casters

 WARNING! Two or more people are required to lay down or stand up the cabinet. DO NOT stand in front or behind and lock drawers

 whilstturningover.

4.2.1. Carefully lay the cabinet upside down with a soft mat underneath for protection.

4.2.2. Fitthetwoswivel/brakedcastors,onthehandlesideusing10mmx25mmbolts,througheachcastorandintothebottomofthe 

cabinet. Tighten securely.

4.2.3. Repeat for the two rigid casters on the other side.

4.3. Drawers

4.3.1. Newdrawersslidesmaybestiffanddifculttoopenatrst.Agentleoutwardpullshouldreleasethesafetycatchthatpreventsthe

 drawerfromopeningwhilstthecabinetisbeingmoved.

4.3.2. Removedrawersfromtheirslidesasbelow(pullleftslidetabdownandpullrightsideslidetabup).

5. MAINTENANCE

5.1. To clean use a soft cloth that will not scratch the surface.

5.2. DO NOTusesolventsofanykindtheymaydamagethesurface.

5.3.  Liquidspillsshouldberemovedimmediately,useasoftcleanclothtoblotthespillgently-avoidrubbing.

5.4. Grease the casters with good quality grease once a year.

5.5. Lubricate the drawer slides twice a year with light duty oil.

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.

IMPORTANT: No liability is accepted for incorrect use of this product.

WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.

Sole UK Distributor, Sealey Group.

Kempson Way, Suffolk Business Park,

Bury St. Edmunds, Suffolk.

IP327AR

www.sealey.co.uk

sales@sealey.co.uk

01284757500

01284703534

Web

Environmental Protection

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be

sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.

When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)

into approved containers and dispose of the product and the fluids according to local regulations.

AP7210SS|Issue1-10/05/16

Original Language Version

For reference only.

Cabinet should be

turned upside down to

tcasters
