VTK101
VTK101N
1/3.2" CMOS Color square camera
* Outstanding true color reproduction
It shows how Color CMOS camera should perform its color reproduction. The unit includes the
new generation 1/3.2" CMOS sensor and it is successfully combined with our own image
processing technology in order to enhance the color reproduction to the close level of human
eye. It responses to all colors as natural and reproduce them extremely live.
* Remarkable low light sensitivity, Noise free
It is brighter than ever at dark illumination. Generally DSP color cameras performs very poor
sensitivity compared with monochrome cameras at low illumination. It marks a new
breakthrough how the color cameras woks so well at low light condition. Note for the real
feature of 0.1 lux at F2.0
* Compact Size (33mmx33mm)
The value of the camera is not in making the size as small as possible. It is just purposed to
meet the general demands of micro technology. The real value is in making the unit perform a
reliable functions & quality not loosing its principal purpose. It is successfully proved as being
the world's smallest size, used with 1/3.2" CMOS format, Incorporating all innovative features.
* Moisture free Weatherproof
The unit is completely sealed with strong metal housing. There is no condensation when it is
heated after a long time operation under rainy weather.
* Extremely Low Power Consumption & Wide working voltage tolerance
It covers DC12V ± 3V of power input and requires less than 60
㎃
. This is critical for the
reliability as it produce less heat and protect it from damage against bad power supply or
fluctuating AC power input.
* Easy Installation
Weatherproof applicable for outdoor security or car rear view vision
1/3.2" Super sensitive Color CMOS sensor (SONY)
Human eye level of true color reproduction
Ultra sensitive low light performance of 0.1 Lux at F2.0 fixed lens
World's smallest 1/3.2" Color CMOS camera with 33mmx33mm
650 TVL Horizontal Resolution
Extremely reliable operating power tolerance
Reverse Polarity Input protection circuit built-in
Audio with C-Mic
Reverse Image
Optional Features
Key Features
MODEL
Effective Pixels
H.Resolution
Image sensor
Synchronizing system
Scanning system
Video output
S/N ratio
Min. Illumination
White balance
Gain Control
Gamma correction
Smear effect
Shutter speed
MTBF
Power source
Operation current
Lens Standard
Operating
Temperature
Humidity
Output Terminal
Measurement (mm)
Weight(Approx.g)
Optional Function 1
Optional Function 2
VTK101 / VTK101N
1280(H) x 960(V) = 1.23M pixels
More than 650 TV Lines
1/3.2" Sony CMOS
Internal
Progressive scan
1.0Vp-p Composite. 75 Ohms
More then 52 dB (AGC Off)
0.1Lux at F2.0
1800˚K ∼10500˚K Auto
4dB~30dB Auto
r=0.45
0.01%
NTSC : 1/60∼1/67,500 sec
PAL : 1/50∼1/67,500 sec
80,000 hours
DC12V
90mA w / regulated 12VDC in
f=2.45(140')
14˚ F~122˚ F ( -10˚ C~ + 50˚ C )
Within 90% RH
4 Foot DIY cable with
RCA-Fe (BNC-Fe) for Video, DC Jack-Male for
Power
33(W)x33(V)x30(H)
150
External Audio with C-Microphone" - 35dB / mV
"
Infra-Red Light sensitive without loosing the true
coloration at day light
Specification
Key Features
33mm
33mm
Side view (with Bracket)
Front view
Dimension(mm)
