instructions for
drawer 100mm deep 75kg capacity
model no: apicd100/200
thank you for purchasing a Sealey product. manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SaFety
warNiNg! ensure Health & safety, local authority, and general workshop practice regulations are adhered to when using these drawers
and cabinets.
9 locate the cabinet in a suitable work area.
9 Keep the work area clean, uncluttered and ensure there is adequate lighting.
warNiNg! use the cabinet on level and solid ground, preferably concrete.
9 Keep the drawer clean and tidy in accordance with good workshop practice.
9 Keep children and unauthorised persons away from the work area.
8 dO NOt use the cabinet for any purpose other than that for which it is designed.
8 dO NOt use the cabinet outdoors.
8 dO NOt place the cabinet in a damp or wet location or an area where there is condensation.
8 dO NOt clean the cabinet or drawers with any solvents which may damage the surfaces or the protective coating.
8 dO NOt move the cabinet when there are items placed inside.
8 dO NOt step on the drawers.
8 dO NOt overload the drawers or cabinet.
2. in iNtrOductiONtroduction
drawer for model no’s APiccomB02, APiccomB05 and APiccomB07. Heavy duty ball bearing drawer slides with a load bearing of up to 75kg.
dimensions:
APicd100: (W x d x H): 777 x 330 x 100mm.
APicd200: (W x d x H): 777 x 330 x 200mm.
3. cONteNtS
unpack the contents of the box and check against the parts list/diagram. if there are any parts missing, contact your local sealey stockist.
APicd100, APicd200 | issue 2(sP) 09/12/16
Original Language Version
© Jack sealey limited
refer to
instruction
manual
apicd100
apicd200
part No. part Name No. of
A or B APicd100/APicd200 1
c or d APicd100/200 dividers 10
e screw 16
f Bracket 4
G sliders 2
4. aSSembly
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
impOrtaNt: no liability is accepted for incorrect use of this product.
warraNty: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
