CK60FXF
FIXED RANGEHOOD
Dear Customer,
If you follow the recommendations contained in this Instruction Manual, our
appliance will give you constant high performance and will remain efficient
for many years to come.
Product Specification & Technical Parameters
Model CK60FXF
Rated Voltage 230V
Rated Power Frequency 50Hz
Light Power 1x25W
Motor Power 120W
Total Power 145W
Diameter of Outlet Adapter 120mm
RECOMMENDATIONS AND SUGGESTIONS
INSTALLATION
* The manufacturer will not be held liable for any damages resulting from
incorrect or improper installation.
* Please read this instruction manual before installing and using this range
hood. Please keep this instruction manual in a safe place for future
reference.
* This range hood can be used either in the Ducted Mode (ducting fumes to
the outside) or in the Recirculation Mode (internal recycling). The choice of
modes can be left to t
he customers.
* On
ly a qualified and trained service technician can undertake the work of
installation and servicing.
* Check that the main voltage corresponds to the one indicated on the rating
plate fixed inside the hood.
* Do not connect the hood to exhaust ducts carrying combustion fumes
(boilers, fireplaces, etc.)
* If the hood is used in conjunction with non-electrical appliances (e. g. gas
burning appliances), a sufficient degree of ventilation must be
guaranteed
in
the room in order to prevent the backflow of exhaust gas. The kitchen must
have an opening directly with the open air in order to guarantee the entry of
clean air.
* The minimum distance is 750mm from the range hood to a gas hob, and is
650mm to an electric hob. If the installation instructions for gas hobs specify
a greater distance, this must be taken into account.
NOTICE: Two or more people are required to install or move this appliance.
Failure to do so can cause physical injuries.
USE
* The range hood has been designed only for domestic use to eliminate
kitchen fumes.
* Never use the hood for purposes other than what it has been designed for.
* Never leave high naked flames under the hood when it is in operation.
* Adjust the flame intensity to direct it onto the bottom of the pan only;
making sure that it does not engulf the pan sides.
* Deep fryer fat must be continuously monitored during use: overheated oil
can burst into flame.
* The hood should not be used by children or persons not instr
ucte
d in its
correct use.
MAINTENANCE
* Proper maintenance of the range hood will assure proper performance of
the unit.
* Disconnect the hood from the main supply before carrying out any
maintenance work.
* Clean and/or replace aluminum grease filters and activated charcoal filters
after specified period of time.
* Clean the hood using a damp cloth and a neutral liquid detergent.
* DISPOSAL: Do not dispose this product as unsorted municipal waste.
Collection of such waste separately for special t
reatment is ne
cessary.
WARNING!!
In certain circumstances electrical appliances may be a danger hazard.
* Do not check the status of the filters while the range hood is operating.
* Do not touch the light bulbs after appliance use.
* Do not disconnect the appliance with wet hands.
* Avoid free flame, as it is damaging for the filters and a fire hazard.
* Constantly check food frying. Overheated oil may become a fire hazard.
* Disconnect the electrical plug prior to any maintenance.
* Children don’t recognize the risks of electrical appliances. Therefore use or
keep the appliance only under supervision of adults and out of the reach
from
child
ren.
* Don’t use this product outdoors.
* This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction,
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
* There shall be adequate ventilation of the
room when the ran
ge hood is
used at the same time as appliances burning gas or other fuels.
* There is a fire risk if cleaning is not carried out in accordance with
instructions.
* Do not flambé under the range hood.
* The exhaust air must not be discharged into a flue which is used for
exhausting fumes from appliances burning gas or other fuels.
CHARACTERISTICS
DIMENSIONS
600
520
132
Ducting version
The hood draws the cooking fumes saturated
with fumes and odor, through the grease filters
and expels it to the outside through an outlet
pipe. With this version the charcoal filters are
not required.
Caution: To reduce the risk of fire, the use of
metal ductwork is preferred. Do not use
flammable material to convey exhaust air.
INSTALLATION & USE
DESCRIPTION / CONNECTIONS
The hood may be installed in the Ducting or the Recalculating version.
It depends on the which wind part is installed on the range hood.
There are two wind pads for each range hoods, A and B.
With wind part A installed, the range hood is in recirculation mode.
With wind part B installed, the range hood is in ducting mode.
The other one will be packed in the parts bag as spare parts
We recommend you: CHECK THAT THE WIND PAD IS CORRECT. The
wind pad is found on the motor unit and must be installed with wind pad A
in the case of RECIRCULATING mode.
The default mode of this hood is recirculating.
If change to exhaust way, disassemble the metal lamp board first, then
change the part A to part B, which is as spare in the manual bag. Take
away the air outlet cover and install the air outlet adapter with no-return
valve.
be replaced periodically.
Caution: No need for plastic or rigid metal ducting.
1. Install the charcoal filter.
2. Please note that the air is re-circulated into the room through the front
vents.
Decide from the outset on the type of installation (recirculation or
ducting). For greater efficiency, we recommend you install the hood
in the ducting version.
Electrical Connection
* Electrical wiring must be done by a qualified person(s) in accordance with
all applicable codes and standards. Turn off electrical power at service
1. Decide where the ductwork will run between the hood and the outside.
2. A straight, short duct run will allow the hood to perform most efficiently.
3. Long duct runs, elbows, and transitions will reduce the performance of
the hood. Use as few of them as possible. Larger ducting may be
required for best
performance wit
h longer duct runs.
4. Attach an adequate length of φ125mm round duct to the air outlet
adapter.
5. The air must not be discharged into a flue that is used for exhausting
fumes from appliances burning gas or other fuels Regulations
concerning the discharge of air have to be followed. Check with the local
authority and building codes for exhaust ducting requirements.
6. Install a roof/wall cap. Connect round metal ductwork to cap and work
back towards hood location.
Reca
lculating version
The hood draws cooking fumes saturated with
fumes and odor through the grease filters and
charcoal filters and returns clean air into the room.
For constant efficiency, the charcoal filters must
entrance before wiring.
* If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
* Do not use the plug and an extension cord other than the ones initially
supplied with the hood.
INSTALLATION
Before beginning installation, to better handle the hood, we advise removing
the aluminum filter.
Before fixing, the outlet exhaust duct for air evacuation to the outside must
be installed. Use an outlet exhaust duct with: -
minimum indispensable length; -Minimum
possible bends (maximum angle of bend: 90°);
-certified material (according to local, building
& fire regulations); and as smooth as possible
inside. It is also advisable to avoid any d
rastic changes in duct cross-section
(re
commended diameter: 125mm).
Decide on the position of the hole for the air outlet:
The hole may be in the wall or the ceiling,
according to your requirements, but must be in
vertical line with your hood. Select the type most
suited to your needs and proceed by mounting
the air outlet adapter(C)
Drill the hole in the wall for the air outlet (133 mm
diameter) referring to drawings here on the right where
the measurements for the various possibilities are
indicated.
Proceed with fixing the hood: Based on your
requirements, you can fit
the hood on the wall or on a
wall unit of your kitchen. IMPORTANT: Respect the
distance between the hob and lower part of the hood
which must be at least 650mm.
Notice:
-Exhaust air must not be discharged into a flue which is used for exhausting
fumes from appliance burning gas or other fuels.
Fitting under wall unit
1. Drill 4 holes in the wall unit, respecting the
distance indicated. Push the hood up against
the wall unit and insert the 4 screws operating
from inside the wall unit. Connect a flexible
tube to the hood flange, using a metal hose
clamp. Tube and hose clamps are not
provided.
2. Make the electrical connection.
d and insert them
, screwing them down
rom inside the
s. Connect a
Fixing to the wall
1. Draw a line on the wall in vertical line with your hob.
Mark the 4 holes to be drilled in the wall, respecting
the distances indicated; Make the 4 holes and fit the
4 screw anchors provided. Take 2 of the screws provide
in the topmost screw anchors without, however
completely. Hang the hood on the 2 screws; Working f
hood, tighten the 2 screws completely.
2. Now proceed with final fixing by fitting the other 2 screw
flexible exhaust duct to the
hood
flange, using a metal hose clamp. Tube
and hose clamps are not provided.
3. Make the electrical connection.
-If the instructions for installation for the gas hob specify a greater distance
than 650mm, this has to be taken into account.
-The regulations concerning the discharge of exhaust air have to be
followed.
OPERATION
OPERATION OF CONTROLS
The hood is operated using the push button on the front panel.
The light switch turns the lamps on and off.
The blower switch turns the blower on to three speed settings:
0 - OFF
1 - LOW SPEED
2 - MEDIUM SPEED
3 - HIGH SPEED
MAINTENANCE
GREASE FILTER
The grease filters should be cleaned frequently (every two months of
operation, or more frequently for heavy use). Use a warm detergent
solution.
Grease filters are washable.
RECIRCULATION CHARCOAL FILTER (RECIRCULATING VERSION)
The charcoal filter ( optional ) is not washable, cannot be regenerated, and
should be replaced approximately every 3 months of operation, or more
frequently in the case of heavy usage.
1. To install the charcoal filter by turning clockwise, lock it until the stop
click is heard.
2. Install the metal grid and grease filter after charcoal filter is installed.
3.
To remove the charcoal filters, remove the charcoal filter by turning
anti-clockwise.
LAMPS
(AC 230V, 25W Max)This range hood requires one normal lamp
�EMILIA GLEM
GLEM GAS AUSTS . L lD. PRODUCT R
Thank you for choosing an Emilia Glem Appliance, the purchase of this appliance is an important investment in your home and so to
protect your investment we urge you to complete the registration card attached, please return it immediately.
IT IS A WARRANTY REQUIREMENT THAT PROOF OF PURCHASE BE PROVIDED PRIOR TO REQUESTING A SERVICE CALL.
THIS WARRANTY SHALL NOT APPLY IF THE APPLIANCE WAS NOT INSTALLED BY A LICENSED TECHNICIAN AND PROOF IS NOT
SUPPLIED.
The benefits conferred by this warranty are in addition to all other conditions and warranties in respect of this product which the
consumer may have under the Trade Practices Act 187 4 of the Commonwealth of Australia and/or similar State or Territory Laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or
refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the
goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
Glem Gas Australasia Pty Ltd warrants, this appliance to be free from defects in workmanship and materials for a period of:
a) Where the appliance is intended to be used and is used for DOMESTIC USE - 24 MONTHS FROM DATE OF DELIVERY TO THE
ORIGINAL PURCHASER.
b) Where the appliance is intended to be used and is used for COMMERCIAL USE- 90 DAYS FROM DATE OF DELIVERY TO THE
ORIGINAL PURCHASER.
Glem Gas Australasia Pty Ltd, during the period of warranty, will at its option, and subject to the terms and conditions stated b"ow,
repair or replace free of charge this appliance or any component part, which upon examination by Glem Appliances P/L. is found to be
defective.
THIS WN SH N PLY:
a)
If the rating plate has been removed or the serial number or other details on it have been removed or rendered illegible.
b)
If the appliance is connected to any voltage other than shown on rating plate.
c) If the appliance has been subjected to misuse, abuse accident or want of care.
d)
If the appliance has been installed, operated or maintained contrary to the instructions supplied by Glem Gas Australasia P/L.
e)
If any defect or failure is due to connection to an inadequate or faulty power supply.
If damage is caused by foreign objects in or on the appliance or by reason of its use for purposes other than that for which it was
delivered.
g)
If a repair has been made or attempted by the purchaser.
h) Where the appliance is installed outside an 80km radius from the GPO of any Australian Capital City to freight and travel costs
beyond that radius.
This warranty does not cover any glass damage or replacement of light bulbs.
Parts covered under warranty that need replacing i.e.: seals, knobs or filters. These can be posted to customer to put on at their
discretion.
This Warranty is given by Glem Gas Australasia Pty Ltd and no other person or organisation is authorised to vary its provisions and
conditions.
Comple this ion d kp it r ur n rord.
Appliance type I
Pu,chased frnm ====
Model No.
Date of purchase
Serial no.
Please comple the sion bel d u to:
Glem Gas Australasia Pty. Ltd, PO Box 63 Blaxcell PO South Granville
WARRAN FORM
Appliance type
Purchased from
Customer Name
Installers Name
Installers Signature
Installers Compliance Number
Model No.
Serial no.
Date of purchase
Address
Installers licence no.
