Hikvision IDS-2SK8144IXS-D/J 8-inch 4 MP 40X DarkFighter IR Network Speed Dome

Product's Documents

Below are documents related to this product, you can read online or download:
User Manual Specification Installation Instruction
IDS-2SK8144IXS-D/J photo

User Manual

This is the main product document for model IDS-2SK8144IXS-D/J.

The file format is pdf, 122 pages, you can download this manual here .

background
Smart Linkage PTZ Camera
User Manual
background
Legal Informaon
©2020 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND “WITH
ALL FAULTS AND ERRORS. HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
Smart Linkage PTZ Camera User Manual
i
background
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.
Smart Linkage PTZ Camera User Manual
ii
background
Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Product Introducon .............................................................................................................. 1
1.2 Key Funcon .......................................................................................................................... 1
1.3 System Requirement .............................................................................................................. 2
Chapter 2 Device Acvaon and Accessing ................................................................................. 3
2.1 Acvate Device ...................................................................................................................... 3
2.1.1 Acvate Device via Web Browser .................................................................................. 3
2.1.2 Acvate via SADP .......................................................................................................... 4
2.2 Access Device via Web Browser ............................................................................................. 5
2.2.1 Plug-in Installaon ........................................................................................................ 5
2.2.2 Admin Password Recovery ............................................................................................ 6
2.2.3 Illegal Login Lock ........................................................................................................... 6
Chapter 3 Smart Funcon ........................................................................................................... 8
3.1 Person Arming ........................................................................................................................ 8
3.1.1 Device Auto Person Arming .......................................................................................... 8
3.1.2 Manual Person Arming ............................................................................................... 12
3.1.3 Advanced Sengs ....................................................................................................... 12
3.2 Vehicle Arming ..................................................................................................................... 14
3.2.1 Basic Sengs .............................................................................................................. 14
3.2.2 Manual Vehicle Arming ............................................................................................... 15
3.2.3 Auto Vehicle Arming ................................................................................................... 15
3.2.4 Plaorm-Controlled Vehicle Arming ........................................................................... 17
3.2.5 Advanced Sengs ....................................................................................................... 18
3.3 Road Trac .......................................................................................................................... 19
3.3.1 Set Detecon Rule for PTZ channel ............................................................................. 20
3.3.2 Set Detecon Rule for Panoramic Channel ................................................................. 20
Smart Linkage PTZ Camera User Manual
iii
background
3.3.3 Picture Sengs ........................................................................................................... 21
3.4 Mul-Target-Type Detecon ................................................................................................ 22
3.4.1 Set Mul-Target-Type Detecon in PTZ Channel ........................................................ 22
3.4.2 Set Mul-Target-Type Detecon in Panoramic Channel ............................................. 26
3.5 Smart Event .......................................................................................................................... 29
3.5.1 Set Intrusion Detecon ............................................................................................... 29
3.5.2 Set Line Crossing Detecon ......................................................................................... 31
3.5.3 Set Region Entrance Detecon ................................................................................... 32
3.5.4 Set Region Exing Detecon ....................................................................................... 34
3.5.5 Detect Audio Excepon ............................................................................................... 36
3.6 Smart Display ....................................................................................................................... 36
Chapter 4 PTZ ........................................................................................................................... 38
4.1 PTZ Control .......................................................................................................................... 38
4.2 Set Preset ............................................................................................................................. 40
4.2.1 Special Presets ............................................................................................................ 40
4.3 Set Patrol Scan ..................................................................................................................... 41
4.4 Set Limit ............................................................................................................................... 42
4.5 Set Inial Posion ................................................................................................................ 43
4.6 Set Scheduled Tasks ............................................................................................................. 43
4.7 Set Park Acon ..................................................................................................................... 43
4.8 Set Privacy Mask .................................................................................................................. 44
4.9 Set Smart Tracking ............................................................................................................... 45
4.10 Set Rapid Focus .................................................................................................................. 45
4.11 Panorama Tracking ............................................................................................................. 46
4.11.1 Adjust Scene of Panoramic Channel ......................................................................... 46
4.11.2 Link Channels by Calibraon ..................................................................................... 47
4.11.3 Set Tracking Parameters ............................................................................................ 47
4.11.4 Advanced Sengs for Panorama Tracking ................................................................ 48
Smart Linkage PTZ Camera User Manual
iv
background
4.12 Set Device Posion ............................................................................................................. 49
4.13 GPS Calibraon .................................................................................................................. 50
4.13.1 Set GPS Calibraon ................................................................................................... 50
4.13.2 Verify Calibraon ...................................................................................................... 51
4.14 Set Power O Memory ...................................................................................................... 51
4.15 Set PTZ Priority ................................................................................................................... 52
Chapter 5 Live View .................................................................................................................. 53
5.1 Live View Parameters ........................................................................................................... 53
5.1.1 Window Division ......................................................................................................... 53
5.1.2 Start and Stop Live View ............................................................................................. 53
5.1.3 Aspect Rao ................................................................................................................ 53
5.1.4 Live View Stream Type ................................................................................................ 53
5.1.5 Start Digital Zoom ....................................................................................................... 54
5.1.6 Conduct Regional Focus .............................................................................................. 54
5.1.7 Conduct Regional Exposure ........................................................................................ 54
5.1.8 Conduct 3D Posioning ............................................................................................... 54
5.1.9 Lens Inializaon ........................................................................................................ 55
5.1.10 Light .......................................................................................................................... 55
5.1.11 Display Target Informaon on Live View ................................................................... 55
5.2 Set Transmission Parameters ............................................................................................... 55
Chapter 6 Video and Audio ....................................................................................................... 57
6.1 Video Sengs ...................................................................................................................... 57
6.1.1 Stream Type ................................................................................................................ 57
6.1.2 Video Type .................................................................................................................. 57
6.1.3 Resoluon ................................................................................................................... 58
6.1.4 Bitrate Type and Max. Bitrate ..................................................................................... 58
6.1.5 Video Quality .............................................................................................................. 58
6.1.6 Frame Rate .................................................................................................................. 58
Smart Linkage PTZ Camera User Manual
v
background
6.1.7 Video Encoding ........................................................................................................... 58
6.1.8 Prole .......................................................................................................................... 60
6.1.9 SVC .............................................................................................................................. 60
6.1.10 I-Frame Interval ......................................................................................................... 60
6.1.11 Smoothing ................................................................................................................. 60
6.2 ROI ....................................................................................................................................... 60
6.2.1 Set ROI ........................................................................................................................ 61
6.2.2 Set License Plate Tracking ROI ..................................................................................... 61
6.2.3 Set Target Tracking ROI ............................................................................................... 62
6.3 Display Info. on Stream ........................................................................................................ 62
6.4 Audio Sengs ...................................................................................................................... 62
6.4.1 Audio Input ................................................................................................................. 62
6.4.2 Audio Output .............................................................................................................. 63
6.4.3 Environmental Noise Filter .......................................................................................... 63
6.5 Two-way Audio .................................................................................................................... 63
6.6 Display Sengs .................................................................................................................... 63
6.6.1 Scene Mode ................................................................................................................ 64
6.6.2 Image Parameters Switch ............................................................................................ 67
6.6.3 Video Standard ........................................................................................................... 68
6.7 OSD ...................................................................................................................................... 68
Chapter 7 Video Recording and Picture Capture ........................................................................ 69
7.1 Storage Sengs ................................................................................................................... 69
7.1.1 Memory Card .............................................................................................................. 69
7.1.2 Set FTP ........................................................................................................................ 71
7.1.3 Set NAS ....................................................................................................................... 72
7.1.4 Set Cloud Storage ........................................................................................................ 73
7.2 Video Recording ................................................................................................................... 73
7.2.1 Record Automacally .................................................................................................. 73
Smart Linkage PTZ Camera User Manual
vi
background
7.2.2 Record Manually ......................................................................................................... 75
7.2.3 Playback and Download Video .................................................................................... 75
7.3 Capture Conguraon .......................................................................................................... 76
7.3.1 Capture Automacally ................................................................................................ 76
7.3.2 Capture Manually ........................................................................................................ 76
7.3.3 View and Download Picture ........................................................................................ 76
Chapter 8 Event and Alarm ....................................................................................................... 78
8.1 Basic Event ........................................................................................................................... 78
8.1.1 Set Moon Detecon .................................................................................................. 78
8.1.2 Set Video Tampering Alarm ........................................................................................ 80
8.1.3 Set Excepon Alarm .................................................................................................... 81
8.1.4 Set Alarm Input ........................................................................................................... 82
Chapter 9 Arming Schedule and Alarm Linkage ......................................................................... 83
9.1 Set Arming Schedule ............................................................................................................ 83
9.2 Linkage Method Sengs ...................................................................................................... 83
9.2.1 Trigger Alarm Output .................................................................................................. 83
9.2.2 FTP/NAS/Memory Card Uploading ............................................................................. 84
9.2.3 Send Email .................................................................................................................. 85
9.2.4 Nofy Surveillance Center .......................................................................................... 86
9.2.5 Trigger Recording ........................................................................................................ 86
9.2.6 Flashing Light .............................................................................................................. 86
9.2.7 Audible Warning ......................................................................................................... 86
Chapter 10 Network Sengs .................................................................................................... 88
10.1 TCP/IP ................................................................................................................................. 88
10.1.1 Mulcast ................................................................................................................... 89
10.1.2 Mulcast Discovery ................................................................................................... 90
10.2 Port .................................................................................................................................... 90
10.3 Port Mapping ..................................................................................................................... 91
Smart Linkage PTZ Camera User Manual
vii
background
10.3.1 Set Auto Port Mapping .............................................................................................. 91
10.3.2 Set Manual Port Mapping ......................................................................................... 91
10.3.3 Set Port Mapping on Router ..................................................................................... 92
10.4 SNMP ................................................................................................................................. 93
10.5 Access to Device via Domain Name ................................................................................... 93
10.6 Access to Device via PPPoE Dial Up Connecon ................................................................ 94
10.7 Set ISUP .............................................................................................................................. 95
10.8 Set ONVIF ........................................................................................................................... 95
10.9 Set Network Service ........................................................................................................... 95
10.10 Set Alarm Server .............................................................................................................. 96
10.11 TCP Acceleraon .............................................................................................................. 97
10.12 Trac Shaping .................................................................................................................. 97
10.13 Set SRTP ........................................................................................................................... 97
Chapter 11 System and Security ................................................................................................ 98
11.1 View Device Informaon .................................................................................................... 98
11.2 Restore and Default ........................................................................................................... 98
11.3 Search and Manage Log ..................................................................................................... 98
11.4 Import and Export Conguraon File ................................................................................ 99
11.5 Export Diagnose Informaon ............................................................................................. 99
11.6 Reboot ............................................................................................................................... 99
11.7 Upgrade ............................................................................................................................. 99
11.8 View Open Source Soware License ................................................................................ 100
11.9 Set Live View Connecon ................................................................................................. 100
11.10 Time and Date ................................................................................................................ 100
11.10.1 Synchronize Time Manually .................................................................................. 100
11.10.2 Set NTP Server ...................................................................................................... 100
11.10.3 Set DST .................................................................................................................. 101
11.11 Security .......................................................................................................................... 101
Smart Linkage PTZ Camera User Manual
viii
background
11.11.1 Authencaon ...................................................................................................... 101
11.11.2 Set IP Address Filter .............................................................................................. 102
11.11.3 Set HTTPS .............................................................................................................. 102
11.11.4 Set QoS .................................................................................................................. 104
11.11.5 Set IEEE 802.1X ..................................................................................................... 104
11.11.6 Security Audit Log ................................................................................................. 104
11.11.7 SSH ........................................................................................................................ 105
11.11.8 Control Timeout Sengs ...................................................................................... 106
11.11.9 Cercate Management ....................................................................................... 106
11.11.10 User and Account ................................................................................................ 108
Appendix A. Device Command ................................................................................................ 110
Appendix B. Device Communicaon Matrix ............................................................................ 111
Smart Linkage PTZ Camera User Manual
ix
background
Chapter 1 Overview
1.1 Product Introducon
The Smart Linkage PTZ Camera integrates a xed panoramic channel with a PTZ channel to oer
both an overall view of the monitoring scene and target details.
1.2 Key Funcon
The key funcons of the device are as follows. The person arming, vehicle arming, road trac,
smart event and mul-target type detecon are mutually exclusive from each other. You can
enable the desired one on VCA Resource page ( Conguraon → System → System Sengs
VCA Resource ).
Person Arming
The device detects the armed face or human body in the monitoring scene. When the wanted
targets are found, the device triggers alarms, and starts tracking and capturing the target. The
real-me target locaon and other related informaon are uploaded during tracking if properly
congured.
Vehicle Arming
The device detects the armed vehicle (license plates) in the monitoring scene. When the wanted
vehicles are found, the device triggers alarms, and starts tracking and capturing the target. The
real-me target locaon and other related informaon are uploaded during tracking if properly
congured.
Road Trac
The device captures the passing vehicles and uploads the vehicle informaon together with the
captured picture.
Smart Event
The device detects 4 smart events, that are, line crossing detecon, intrusion detecon, region
entrance detecon, and region exing detecon.
Mul-Target-Type Detecon
The device captures dierent types of targets, such as faces and human bodies, and extracts
features of the targets.
Linked Tracking and Capture
The panoramic channel and the PTZ channel work together to detect, locate, track and capture
targets with both overall picture and adequate details.
Smart Linkage PTZ Camera User Manual
1
background
1.3 System Requirement
Your computer should meet the requirements for proper vising and operang the product.
Recommended Specicaons
Operang System Microso Windows XP/ Windows 7/ Windows 8/ Windows 10
Mac OS 10.13 or later
CPU Intel® Penum® IV 3.0 GHz or higher
RAM 1 G or higher
Display 1024 × 768 resoluon or higher
Web Browser Internet Explorer 10 and above version, Apple Safari 12 and above
version, Mozilla Firefox 52 and above version, Google Chrome 57 and
above version.
Smart Linkage PTZ Camera User Manual
2
background
Chapter 2 Device Acvaon and Accessing
To protect the security and privacy of the user account and data, you should set a login password
to acvate the device when access the device via network.
Note
Refer to the user manual of the soware client for the detailed informaon about the client
soware acvaon.
2.1 Acvate Device
The device need to be acvated by seng a strong password before use. This part introduces
acvaon using dierent client tools.
2.1.1 Acvate Device via Web Browser
Use web browser to acvate the device. For the device with the DHCP enabled by default, use
SADP soware or PC client to acvate the device.
Before You Start
Make sure your device and your PC connect to the same LAN.
Steps
1.
Change the IP address of your PC to the same subnet as the device.
The default IP address of the device is 192.168.1.64.
2.
Open a web browser and input the default IP address.
3.
Create and conrm the admin password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4.
Click OK to complete acvaon and enter Live View page.
5.
Modify IP address of the camera.
1) Enter IP address modicaon page. Conguraon → Network → TCP/IP
2) Change IP address.
3) Save the sengs.
Smart Linkage PTZ Camera User Manual
3
background
2.1.2 Acvate via SADP
SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.
Before You Start
Get the SADP soware from the supplied disk or the ocial website hp://
www.hikvision.com/ , and install the SADP according to the prompts.
The device and the PC that runs the SADP tool should belong to the same subnet.
The following steps show how to acvate one device and modify its IP address. For batch acvaon
and IP address modicaon, refer to User Manual of SADP for details.
Steps
1.
Run the SADP soware and search the online devices.
2.
Find and select your device in online device list.
3.
Input new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4.
Click Acvate to start acvaon.
Status of the device becomes Acve aer successful acvaon.
5.
Modify IP address of the device.
1) Select the device.
Smart Linkage PTZ Camera User Manual
4
background
2) Change the device IP address to the same subnet as your computer by either modifying the IP
address manually or checking Enable DHCP.
3) Input the admin password and click Modify to acvate your IP address modicaon.
2.2 Access Device via Web Browser
Before You Start
Check the system requirement to conrm that the operang computer and web browser meets
the requirements.
Steps
1.
Open the web browser.
2.
Input IP address of the device to enter the login interface.
3.
Input user name and password.
Note
Illegal login lock is acvated by default. If admin user performs seven failed password aempts
(ve aempts for user/operator), the IP address is blocked for 30 minutes.
If illegal login lock is not needed, go to Conguraon → System → Security → Security Service
to turn it o.
4.
Click Login.
5.
Download and install appropriate plug-in for your web browser.
For IE based web browser, webcomponents and
TM
are oponal. For non-IE based web browser,
webcomponents,
TM
, VLC and MJEPG are oponal.
2.2.1 Plug-in Installaon
Certain operaon systems and web browser may restrict the display and operaon of the device
funcon. You should install plug-in or complete certain sengs to ensure normal display and
operaon. For detailed restricted funcon, refer to the actual device.
Operang System Web Browser Operaon
Windows Internet Explorer 10+ Follow pop-up prompts to
complete plug-in installaon.
Windows 7 and above version Google Chrome 57+
Mozilla Firefox 52+
Click
to
download and install plug-in.
Mac OS Google Chrome 57+
Mozilla Firefox 52+
Mac Safari 12+
Plug-in installaon is not
required.
Go to Conguraon
Network → Advanced Sengs
Smart Linkage PTZ Camera User Manual
5
background
Operang System Web Browser Operaon
→ Network Service to enable
WebSocket or Websockets for
normal view. Display and
operaon of certain funcons
are restricted. For example,
Playback and Picture are not
available. For detailed
restricted funcon, refer to the
actual device.
Note
The device only supports Windows and Mac OS system and do not support Linux system.
2.2.2 Admin Password Recovery
If you forget the admin password, you can reset the password by clicking Forget Password on the
login page aer compleng the account security sengs.
You can reset the password by seng the security queson or email.
Note
When you need to reset the password, make sure that the device and the PC are on the same
network segment.
Security Queson
You can set the account security during the acvaon. Or you can go to Conguraon → System
User Management , click Account Security Sengs, select the security queson and input your
answer.
You can click Forget Password and answer the security queson to reset the admin password when
access the device via browser.
Email
You can set the account security during the acvaon. Or you can go to Conguraon → System
User Management , click Account Security Sengs, input your email address to receive the
vericaon code during the recovering operaon process.
2.2.3 Illegal Login Lock
It helps to improve the security when accessing the device via Internet.
Smart Linkage PTZ Camera User Manual
6
background
Go to Conguraon → System → Security → Security Service , and enable Enable Illegal Login
Lock. Illegal Login Aempt and Locking Duraon are congurable.
Illegal Login Aempt
When your login aempts with the wrong password reach the set mes, the device is locked.
Locking Duraon
The device releases the lock aer the seng duraon.
Smart Linkage PTZ Camera User Manual
7
background
Chapter 3 Smart Funcon
3.1 Person Arming
When the device detects the armed face or human body in the monitoring scene, it triggers
alarms, and tracks and captures the target. During the tracking, the target locaon and other
related informaon are uploaded.
Note
Select Person Arming on VCA Resource page to show the conguraon page.
Target locaon informaon can be uploaded only when you set the GPS Calibraon properly. See
GPS Calibraon for instrucons.
This funcon is only supported by certain device models.
Device Auto Person Arming and Manual Person Arming are supported. The Manual Person
Arming has a higher priority than the other, which means it can interrupt the ongoing auto person
arming.
Manual Person Arming The device tracks and captures the manually selected target and uploads
the related data.
Device Auto Person
Arming
The device tracks and captures targets automacally according to the
seng rule.
3.1.1 Device Auto Person Arming
You need to set face picture libraries, human body libraries, and auto person arming rules to realize
device auto person arming.
Set Face Picture Library
Face picture library is used to store modeled human faces and informaon.
Steps
1.
Go to Conguraon → Face Picture Library .
2.
Create a face picture library.
1) Click to add a face picture library.
2) Input library name, threshold and remarks.
Threshold
Face similarity higher than the set threshold triggers face picture comparison alarm
uploading.
Smart Linkage PTZ Camera User Manual
8
background
3) Click OK.
4) Oponal: Modify a face picture library. Select the desired library and click and change
related parameters.
5) Oponal: Delete a library. Select the desired library and click .
3.
Add face pictures to the library.
Note
The picture format should be JPEG, and the size no larger than 300 K per le.
Add one face
Click Add and upload the face picture with detailed face informaon.
Import face
pictures in
batch
Click Import and select picture path.
Note
When you import face pictures in batch, the picture name is saved as the
face name. For other face informaon, you should modify one by one
manually.
The vericaon code for exporng and imporng should be a combinaon
of 8 to 16 digits, containing numerics, upper case and lower case leers.
4.
Oponal: Modify face informaon.
1) Select a face picture library.
2) Select the target face picture. You can use the search funcon to locate the picture by
inpung search condions, and click Search.
3) Click Modify.
4) Edit detailed informaon.
Note
Face picture is not allowed to change.
5) Click OK.
5.
Create models for each face picture in library.
Modeling process builds up face model for each face picture. Face model is compulsory for face
picture comparison to take eect.
Modeling Select one or more face pictures, and click Modeling.
Batch Modeling Select a face picture library, and click Batch Modeling.
6.
Oponal: Repeat to create more face libraries.
Set Human Body Library
Human body library is used to store modeled human bodies and informaon.
Smart Linkage PTZ Camera User Manual
9
background
Steps
1.
Go to Conguraon → Human Body Library .
2.
Create a human body library.
1) Click to add a human body library.
2) Input library name, threshold and remarks.
Threshold
Human body similarity higher than the set threshold triggers human body picture
comparison alarm uploading.
3) Click OK.
4) Oponal: Modify a library. Select the desired library and click and change related
parameters.
5) Oponal: Delete a library. Select the desired library and click .
3.
Add human body pictures to the library.
Note
The picture format should be JPEG, and the size no larger than 300 K per le.
Add a human
body picture
Click Add and upload the human body picture with detailed informaon.
Import
pictures in
batch
Click Import and select picture path.
Note
When you import human body pictures in batch, the picture name is
saved as the human body name. For other human body informaon, you
should modify one by one manually.
The vericaon code for exporng and imporng should be a
combinaon of 8 to 16 digits, containing numerics, upper case and lower
case leers.
4.
Oponal: Modify human body informaon.
1) Select a picture library.
2) Select the target picture. You can use the search funcon to locate the picture by inpung
search condions, and click Search.
3) Click Modify.
4) Edit detailed informaon.
Note
The picture is not allowed to change.
5) Click OK.
5.
Create models for human body pictures in the library.
Modeling process builds up human body model for each picture. Human body model is
compulsory for the comparison to take eect.
Smart Linkage PTZ Camera User Manual
10
background
Modeling Select one or more pictures, and click Modeling.
Batch Modeling Select a picture library, and click Batch Modeling.
6.
Oponal: Repeat to create more human body libraries.
Set Auto Person Arming Rule
Before You Start
Complete Mul-Target-Type Detecon sengs for Camera 01 in advance. See
Mul-Target-Type
Detecon for instrucons.
The face picture library and the human body library should be set in advance. See Set Face Picture
Library and Set Human Body Library for instrucons.
Steps
1.
Go to Conguraon → Person Arming → Basic Sengs .
2.
Check Person Arming.
3.
Set the parameters for face picture comparison and arming.
1) Set the Face Grading Threshold for Detecon and Max. Detecon Time of Face.
Face Grading Threshold for Detecon
Every face entering the monitoring scene is graded by the device according to the quality.
When a face with its grading exceeds the set threshold, it triggers the comparison with the
pictures in the selected face picture library.
Max. Detecon Time of Face
If the grading of a target face does not reach the set Face Grading Threshold for Detecon
during the set me, the device stops grading the target face.
2) Select the Library Type as Face Picture Library, and select a desired library.
3) Set the arming schedule and linkage method for the selected library.
Note
The arming schedule and linkage method for dierent libraries are allowed to set
independently.
4.
Set the parameters for human body comparison and arming.
1) Set the Human Body Grading Threshold for Detecon and Max. Detecon Time of Human
Body.
Human Body Grading Threshold for Detecon
Every human body entering the monitoring scene is graded by the device according to the
quality. When a human body with its grading exceeds the set threshold, it triggers the
comparison with the pictures in the selected human body library.
Max. Detecon Time of Human Body
Smart Linkage PTZ Camera User Manual
11
background
If the grading of a target human body does not reach the set Human Body Grading
Threshold for Detecon during the set Max. Detecon Time of Human Body, the device
stops grading the target human body.
2) Select the Library Type as Human Body Library, and select a desired library.
3) Set the arming schedule and linkage method for the selected library.
Note
The arming schedule and linkage method for dierent libraries are allowed to set
independently.
5.
Save the sengs.
3.1.2 Manual Person Arming
Before You Start
Complete person arming sengs before using manual person arming. Refer to Person Arming for
instrucons.
Steps
1.
Click to start manual person arming.
2.
Click or frame a person as the target.
The device starts to track the target and upload related data.
3.
Click to stop manual person arming.
3.1.3 Advanced Sengs
In advanced parameters, you can set the tracking, capture and other parameters for the person
arming.
Tuning Mode
The mode is only for the professional users.
Tracking Capture
Check to enable the device to capture the targets during the tracking.
Some capture parameters are allowed to adjust.
Face Capture Threshold
It refers for the quality of face to trigger capture and alarm. Higher value means beer quality
should be met to trigger capture and alarm.
Human Body Capture Threshold
It refers for the quality of human body to trigger capture and alarm. Higher value means beer
quality should be met to trigger capture and alarm.
Smart Linkage PTZ Camera User Manual
12
background
Tracking Parameters
Zooming Control
Two modes are available. Controlled by target frame or by lt angle of the device.
By Tilt Angle
The device calculates the tracking zoom rao automacally according to the lt angle of the
device.
Note
The atude of the device aects the accuracy of this zooming control mode. For the model
with a built-in gyroscope, try to calibrate the atude if some zooming problems happen
during tracking. See Set Device Posion for instrucons.
By Target Frame
The tracked target has a virtual frame around. The device calculates a suitable zoom rao
according to the frame and the set Tracking Zoom Rao. Larger value means bigger zoom
rao.
Dwell Time aer Failed Tracking
The me the device stays at the posion where the target tracking fails.
Report Interval of Tracking Info
The alarming informaon upload interval during tracking.
Wait to Stop Tracking If Low Validity
The validity is an internal parameter that helps judge whether the device should keep tracking
or not. This parameter is the waing me level before the device stops tracking when the
validity is low. Larger value means longer waing me.
Wait to Lower Tracking Speed If Low Validity
The validity is an internal parameter that helps judge whether the PTZ channel should lower the
tracking speed or not. This parameter is the waing me level before the device lowers the
tracking speed when the validity is low. Larger value means longer waing me.
Tracking Duraon
When you set the Tracking Duraon as 0, the device keeps tracking the target unl it
disappears.
When you set the Tracking Duraon as a number other than 0, the device tracks a target for the
set me. The tracking stops when the me is up or when the target disappears.
Display Tracking Target on Panorama
Check to display a frame around the target that is tracked by the PTZ channel.
Smart Linkage PTZ Camera User Manual
13
background
Note
Go to Conguraon → Local → Live View Parameters , and enable Rules before using this
funcon.
3.2 Vehicle Arming
The device detects and tracks designated license plates, and uploads real-me target locaon and
other related informaon.
Note
Select Vehicle Arming on VCA Resource page to show the conguraon page.
Target locaon informaon can be uploaded only when the GPS calibraon is completed. See
GPS Calibraon for conguraon instrucons.
This funcon is only supported by certain device models.
Three vehicle arming modes are supported. Priority from high to low: manual vehicle arming,
plaorm-controlled vehicle arming, and device auto vehicle arming.
Manual Vehicle Arming The device tracks the target manually selected by user and uploads
related informaon.
Device Auto Vehicle
Arming
The device automacally tracks the vehicles and uploads the informaon
according to the set arming rules.
Plaorm-Controlled
Vehicle Arming
The device receives orders from the plaorm and performs arming tasks.
Note
To use plaorm-controlled vehicle arming, you need to build a plaorm
with the SDK tool provided on our website.
3.2.1 Basic Sengs
You can set the basic informaon, camera No. and informaon, listening server, and ANR.
Go to Conguraon → Vehicle Arming → Common Sengs → Basic Conguraon to complete
the sengs. The basic sengs apply to all three vehicle arming modes.
Basic Informaon
Input Device No. and select the Country/Region.
Camera
Select a channel and input the Camera No. and Camera Info.
Listening Server
Smart Linkage PTZ Camera User Manual
14
background
If the device uploads alarms in listening mode via our company's SDK, you should set the IP
address and port for the listening server.
ANR
When the network is disconnected, data is temporarily saved on the memory card. When the
network connecon is resumed, the device automacally uploads the saved data to the arming
host, in which case, the arming host IP address is required.
Note
A memory card should be installed in the device. Memory card sengs should be completed.
See Memory Card for instrucons.
3.2.2 Manual Vehicle Arming
Steps
1.
Go to Live View .
2.
Click .
3.
Frame or click on a vehicle in the live image.
The device starts to track the vehicle.
4.
Click to stop manual vehicle arming.
3.2.3 Auto Vehicle Arming
You need to set the rules and armed license plates for auto vehicle arming.
Set Arming Rule in Panoramic Channel
It is the predened rule for the panoramic channel to perform auto vehicle arming.
Steps
1.
Go to Conguraon → Vehicle Arming → Common Sengs → Box Camera Rule Sengs .
2.
Draw the lanes according to the scene.
1) Click Add to add desired number of lanes according to your need.
Blue lane lines and a trigger line appear on the image.
2) Drag the endpoints of each lane line to match the real lane markings.
3) Drag the trigger line to adjust its posion.
Vehicle detecon and capture are triggered when a vehicle hits the trigger line.
3.
Check Enable to enable Vehicle Detecon.
4.
Check the lanes you want to arm.
5.
Set arming schedule. See
Set Arming Schedule .
6.
Click Save.
Smart Linkage PTZ Camera User Manual
15
background
Set Arming Rule in PTZ Channel
It is the predened rule for the PTZ channel to perform auto vehicle arming. It supports mulple
detecon scenes and rule sengs for each scene.
Steps
1.
Go to Conguraon → Vehicle Arming → Common Sengs → Speed Dome Rule Sengs
2.
Set the scene for arming.
1) Select a Scene and check Enable.
2) Adjust the live image to desired scene with PTZ control buons.
3) Edit the Scene Name and Scene Direcon.
Note
You can dene the scene direcon according to your need. It does not necessarily represent
the true direcon.
4) Click Save.
5) Oponal: When the PTZ channel turns to another scene, click Call to return to the scene.
3.
Draw the lanes according to the scene.
1) Click Add to add desired number of lanes according to your need.
Blue lane lines and a trigger line appear on the image.
2) Drag the endpoints of each lane line to match the real lane markings.
3) Drag the trigger line to adjust its posion.
Vehicle detecon and capture are triggered when a vehicle hits the trigger line.
4.
Check Enable to enable Vehicle Detecon.
5.
Check the lanes you want to arm.
6.
Click Save.
7.
Oponal: Repeat the steps to set other scenes.
8.
Set the arming schedule.
1) Go to Conguraon → Vehicle Arming → Common Sengs → Speed Dome Arming
Schedule .
2) Check Enable.
3) Draw a bar on the meline to set the arming me.
4) Click on the me bar, and click Conguraon to set the patrol sequence and dwell me on
each scene.
5)
Click
to copy the seng to another day.
6) Click Save.
Set Armed License Plates
You can specify the vehicles you want to arm by adding their license plates to the blocklist or
allowlist.
Smart Linkage PTZ Camera User Manual
16
background
Steps
1.
Go to Conguraon → Vehicle Arming → Advanced Conguraon → Blocklist & Allowlist .
2.
Click Export to export license plate list template.
Note
If a list of license plates exists, the exisng list is exported.
3.
Fill in the list.
4.
Click Browse to import the list.
The list shows on the web page.
5.
Select a mode according to your need.
Normal Mode No vehicle is armed.
Allowlist Mode Vehicles NOT on the list are armed.
Blocklist Mode Only the vehicles on the list are armed.
6.
Click Save.
3.2.4 Plaorm-Controlled Vehicle Arming
The device receives arming tasks from the plaorm to detect and track target vehicles. You can
view the arming tasks in arming status.
Set Arming Locaon
Steps
1.
Go to Conguraon → Vehicle Arming → Common Sengs → Arming Scene .
Note
The PTZ control is automacally locked to avoid interrupon during conguraon.
2.
Select a channel.
3.
Adjust the live image to the target scene with PTZ control buons.
4.
Click Add.
The scene is added to the Arming Scene List.
5.
Edit the scene name and moving direcon of the vehicles.
6.
Repeat the steps to add other scenes.
7.
Click Save.
View Arming Task
Go to Conguraon → Vehicle Arming → Advanced Conguraon → Arming Status to view the
arming tasks sent from the plaorm.
Smart Linkage PTZ Camera User Manual
17
background
The device performs a single task at one me. If it receives mulple tasks, former tasks are
interrupted and the device performs the latest task.
3.2.5 Advanced Sengs
You can set the advanced sengs according to your need to get beer vehicle arming eect.
Advanced Parameters
Go to Conguraon → Vehicle Arming → Advanced Conguraon → Advance Parameters to set
the following parameters.
License Plate Thumbnail
If the device recognizes a license plate, an addional thumbnail of the license plate is uploaded.
Tuning Mode
The tuning mode is for professional technicians. It is not recommended to other users as it may
aect the live view image.
Capture No Plate Vehicle
When this funcon is enabled, the device captures and uploads vehicle pictures with or without
license plate. If it is not enabled, only pictures of vehicles with license plate are uploaded.
Dwell Time aer Failed Tracking
The me the device stays at the posion where the target tracking fails.
Report Interval of Tracking Info
The alarming informaon upload interval during tracking.
Wait to Stop Tracking If Low Validity
The validity is an internal parameter that helps judge whether the device should keep tracking
or not. This parameter is the waing me level before the device stops tracking when the
validity is low. Larger value means longer waing me.
Wait to Lower Tracking Speed If Low Validity
The validity is an internal parameter that helps judge whether the PTZ channel should lower the
tracking speed or not. This parameter is the waing me level before the device lowers the
tracking speed when the validity is low. Larger value means longer waing me.
Self-adapve Rao Coecient
It represents the rao of vehicle size to live image size during tracking. The larger the coecient
is, the larger the vehicle is shown.
Smart Linkage PTZ Camera User Manual
18
background
Uploading Picture Sengs
Go to Conguraon → Vehicle Arming → Advanced Conguraon → Picture to set the
parameters of alarm pictures.
Picture Quality
Pictures with higher resoluon and beer quality have more details and larger le size.
Enable OSD Overlay
The device OSD is overlaid on alarm pictures.
Display Target Info. on Alarm Picture
Check to display target informaon on alarm pictures.
License Plate Exposure
You can adjust the exposure parameters to make sure that the license plates are exposed properly
during vehicle arming.
Steps
1.
Go to Conguraon → Vehicle Arming → Advanced Conguraon → License Plate Exposure .
2.
Select a channel.
3.
Check License Plate Exposure.
4.
Set exposure parameters.
Reference Brightness
Adjust the reference brightness to the value that the license plate is exposed properly.
Min. Duraon
The minimum duraon to maintain the exposure level for the license plates when they are
detected.
Arming Schedule
Set the start me and end me when the license plate exposure sengs are valid.
5.
Click Save.
3.3 Road Trac
The device captures the passing vehicles and uploads the vehicle informaon together with the
captured picture.
Note
For certain device models, you need to select Road Trac on VCA Resource page rst.
This funcon is only supported by certain device models.
Smart Linkage PTZ Camera User Manual
19
background
3.3.1 Set Detecon Rule for PTZ channel
In Vehicle Detecon, the device detects and captures the passed vehicles and the license plates.
The vehicle color, type, and other informaon can be recognized automacally.
Steps
1.
Go to Conguraon → Road Trac Detecon Conguraon .
2.
Select Channel No. as Camera 01.
3.
Select Vehicle Detecon and enable the funcon.
4.
Click Area Sengs to set the detecon rule.
5.
Select a detecon scene from the drop-down list and change the Scene Name as required.
The device supports mulple detecon scenes with independent detecon parameters.
6.
Draw lane area in the scene.
1) Click Lock to avoid accidental PTZ changing during conguraon.
2) Adjust the pan, lt, and zoom posion to obtain the target scene.
3) Select the Total Number of the Lanes according to the actual lane number you want to
monitor in your scene.
Yellow lane lines, a blue detecon line, and a red frame are displayed on live image.
4) Adjust the zoom rao of the device so that the size of the vehicle in the image is close to that
of the red frame. The posion of red frame is adjustable.
5) Click and drag the lane lines or the endpoints to set the posions according to the actual lane
lines on the road.
6) Oponal: Click and drag the blue detecon line to adjust the posion. Vehicle detecon is
triggered when target vehicles hit the line.
7) Set the vehicle moving direcon for each lane in the scene.
8) Click Save.
7.
Oponal: Repeat to set other detecon scenes if needed.
8.
Select the Country/Region.
9.
Click Save to nish area sengs.
10.
Set the arming schedule of vehicle detecon.
1) Click Arming Schedule.
2) Select a detecon scene and draw the me bar in the me table. Dierent scenes are
marked with dierent colors on schedule.
3) Oponal: Move the mouse to the end of each day, a copy icon pops up, and you can click to
copy the current sengs to other days.
4) Click Save aer nishing schedule sengs.
11.
Set linkage method. See
Linkage Method Sengs .
3.3.2 Set Detecon Rule for Panoramic Channel
In Vehicle Detecon, the device detects and captures the passed vehicles and the license plates.
The vehicle color, type, and other informaon can be recognized automacally.
Smart Linkage PTZ Camera User Manual
20
background
Steps
1.
Go to Conguraon → Road Trac Detecon Conguraon .
2.
Select Channel No. as Camera 02.
3.
Select Vehicle Detecon and enable the funcon.
4.
Click Area Sengs to set the detecon rule.
5.
Draw lane area in the scene.
1) Select the Total Number of the Lanes according to the actual lane number you want to
monitor in your scene.
Yellow lane lines, a blue detecon line, and a red frame are displayed on live image.
2) Click and drag the lane lines or the endpoints to set the posions according to the actual lane
lines on the road.
3) Oponal: Click and drag the blue detecon line to adjust the posion. Vehicle detecon is
triggered when target vehicles hit the line.
4) Set the vehicle moving direcon for each lane in the scene.
6.
Select the Country/Region.
7.
Click Save to nish area sengs.
8.
Set arming schedule. See Set Arming Schedule .
9.
Set linkage method. See Linkage Method Sengs .
3.3.3 Picture Sengs
Captured vehicle pictures are uploaded. Picture size, quality and overlay informaon are
congurable.
Go to Conguraon → Road Trac → Picture to start.
Picture Quality Vs Picture Size
Both Picture Quality and Picture Size inuence the size and quality of pictures for uploading. They
cannot be set at the same me.
Picture Quality
The quality of the uploaded picture is accordance with the set value. To keep the quality, the
size of the pictures may vary according to the image complexity. Higher value means clearer
image.
Picture Size
The size of the uploaded picture is accordance with the set value. To keep the size, picture with
more complex contents might be less sasfactory in quality than that with simpler contents.
Overlay
With Overlay enabled, every uploaded picture has an addional part to display the overlaid
informaon.
Font Color
Smart Linkage PTZ Camera User Manual
21
background
The font color of overlaid texts.
Background
The background color for the overlaid texts.
Text Overlay
Check the desired item to display on the picture. Display sequence is adjustable.
Note
Vehicle Color, Brand, and Type are not supported in this rmware version.
Device No., Camera No., and Camera info. are set on Conguraon → Road Trac
Camera .
3.4 Mul-Target-Type Detecon
Mul-Target-Type Detecon is to detect, capture and upload data of targets in mulple types, such
as human face, human body, and vehicle.
Note
For certain device models, you need to select Mul-Target-Type Detecon on VCA Resource page
rst.
3.4.1 Set Mul-Target-Type Detecon in PTZ Channel
Go to Conguraon → System → System Sengs → VCA Resource to enable the mul-target-type
detecon for Camera 1 (the PTZ channel).
Go to Conguraon Mul-Target-Type Detecon and select Camera 01 to start conguraon.
Set Mul-Target-Type Detecon Rule
Aer set the mul-target-type detecon rules and algorithm parameters, the device captures
targets of mulple types and trigger linkage acons automacally.
Steps
1.
Go to Conguraon Mul-Target-Type Detecon → Camera 01 → Rule .
2.
Check Enable.
3.
Select a conguraon mode.
Normal One detecon scene is allowed to set. The device captures targets in the scene in
the set arming schedule.
See
Normal Mode Sengs for details.
Smart Linkage PTZ Camera User Manual
22
background
Expert The device can patrol among the detecon scenes and capture target images.
Detecon scenes and patrol schedule should be set in advance.
See Expert Mode Sengs for details.
4.
Click Save.
What to do next
Go to Picture to search and view the captured pictures.
Go to Smart Display to see currently captured target pictures.
Normal Mode Sengs
Steps
1.
Oponal: Click Lock to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
2.
Use PTZ control panel or click
to locate a scene with a face.
3.
Click
, and draw a detecon area on live image.
4.
Input Mounng Height of the device.
5.
Input the min. pupil distance in the text eld, or click to draw min. pupil distance.
Min. Pupil Distance
The min. pupil distance refers to the minimum area between two pupils, and it is basic for the
device to recognize a face.
6.
Click Save.
7.
Set arming schedule. See Set Arming Schedule .
8.
Set linkage method. See Linkage Method Sengs .
Expert Mode Sengs
Steps
1.
Oponal: Click Lock to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
2.
Set detecon scenes and detecon areas.
1) Select a detecon scene.
2) Adjust the live image to a desired scene. You can use PTZ control buons or click
to locate a
scene with a face.
3) Click , and draw a detecon area on live image.
4) Click Save.
5) Repeat above steps to set other detecon scenes and areas.
Smart Linkage PTZ Camera User Manual
23
background
3.
Input Mounng Height of the device.
4.
Input the min. pupil distance in the text eld, or click to draw min. pupil distance.
Min. Pupil Distance
The min. pupil distance refers to the minimum area between two pupils, and it is basic for the
device to recognize a face.
5.
Set patrol schedule.
1) Click Patrol Schedule.
2) Draw me bars as desired.
3) Click a me bar and click Conguraon.
4) Edit patrol path and input dwell me for each detecon scene.
Add a detecon scene to the patrol path.
Adjust the order of the scenes.
Delete the detecon scene.
6.
Set linkage method. See Linkage Method Sengs .
7.
Click Save.
Overlay and Capture
Choose to congure capture parameters and the informaon you want to display on stream and
picture.
Display VCA Info. on Stream
Display smart informaon on stream, including the target and rules informaon.
Display Target Info. on Alarm Picture
Overlay the alarm picture with target informaon.
Target Picture Sengs
You can set the face picture type by selecng Custom, Head Shot, Half-Body Shot, or Full-Body
Shot. If you select Custom, you can dene detailed picture width and height of a picture freely.
If the captured pictures should have the same picture height, check Fixed Value and input
desired picture height.
Check Face Beaucaon and adjust the beaucaon level as needed.
Note
Face Beaucaon slightly adjusts skin tone and reduces facial noise.
Background Picture Sengs
Comparing to target picture, background picture is the scene image oers extra environmental
informaon. You can set the background picture quality and resoluon. If the background image
need to be uploaded to surveillance center, check Background Upload.
Smart Linkage PTZ Camera User Manual
24
background
Text Overlay
You can check desired items (Device No., Camera Info. and Capture Time) and adjust their order
to display on captured pictures by .
The content of Device No. and Camera Info should be input on the same page.
Mul-Target-Type Detecon Algorithm Parameters
It is used to set and opmize the parameters of the algorithm library for Mul-Target-Type
Detecon.
HMS Version
It refers to the current algorithm version, which cannot be edited.
Restore Defaults
Click Restore to restore all the sengs in advanced conguraon to the factory default.
Detecon Parameters
Generaon Speed
It is the speed of deciding whether an object in detecon area is a target or not. The higher the
value is, the faster the target will be detected. The default value is recommended.
Sensivity
It is the sensivity of recognizing a target. The higher the value is, the easier a target will be
recognized, and the higher possibility of misinformaon would be. The default value is
recommended.
Capture Parameters
Best Shot
Capture Threshold
It refers for the quality of face to trigger capture and alarm. Higher value means beer quality
should be met to trigger capture and alarm.
Quick Shot
The device captures the target picture once the score of the captured face exceeds the Quick
Shot Threshold during the Max. Capture Interval. Otherwise, the device selects and uploads
the picture with the highest score during the Max. Capture Interval.
Quick Shot Threshold
It refers to the quality of face to trigger quick shot.
Max. Capture Interval
It describes the max. me occupaon for one quick shot.
Face Exposure
Smart Linkage PTZ Camera User Manual
25
background
Enable the funcon, and the device automacally adjusts exposure level when human faces
appear in the scene.
Reference Brightness
It refers to the reference brightness of a face in the face exposure mode. If a face in the actual
scene is brighter than the set reference brightness, the device lower the exposure level. If a
face in the actual scene is darker than the set reference, the device increases the exposure
level.
Minimum Duraon
The extra me the device keeps the face exposure level aer the face disappears in the scene.
Face Filtering Time
It means the me interval between the camera detecng a face and taking a capture acon. If
the detected face stays in the scene for less than the set ltering me, capture will not be
triggered. For example, if the face ltering me is set as 5 seconds, the camera will capture the
detected face when the face keeps staying in the scene for 5 seconds.
3.4.2 Set Mul-Target-Type Detecon in Panoramic Channel
Go to Conguraon → System → System Sengs → VCA Resource to enable the mul-target-type
detecon for Camera 2 (the panoramic channel).
Go to Conguraon Mul-Target-Type Detecon and select Camera 02 to start conguraon.
Set Mul-Target-Type Detecon Rule
Aer set the mul-target-type detecon rules and algorithm parameters, the device captures
targets of mulple types and trigger linkage acons automacally.
Steps
1.
Go to Conguraon Mul-Target-Type Detecon → Camera 02 → Rule .
2.
Check Rule.
3.
Click
, and draw a detecon area on live image.
4.
Input the min. pupil distance in the text eld, or click to draw min. pupil distance.
Min. Pupil Distance
The min. pupil distance refers to the minimum area between two pupils, and it is basic for the
device to recognize a face.
5.
Click Save.
6.
Set arming schedule. See Set Arming Schedule .
7.
Set linkage method. See Linkage Method Sengs .
What to do next
Go to Picture to search and view the captured pictures.
Smart Linkage PTZ Camera User Manual
26
background
Go to Smart Display to see currently captured target pictures.
Set Shield Region
The shield region allows you to set the specic region in which the set smart funcon rule is
invalid.
Steps
1.
Select Shield Region.
2.
Click to draw shield area. Repeat this step above to set more shield regions.
3.
Oponal: Click to delete the drawn areas.
4.
Click Save.
Overlay and Capture
Choose to congure capture parameters and the informaon you want to display on stream and
picture.
Display VCA Info. on Stream
Display smart informaon on stream, including the target and rules informaon.
Display on Picture
Check the desired informaon to be overlaid on alarm pictures.
Display Target Info. on Alarm Picture
Overlay the alarm picture with target informaon.
Target Picture Sengs
You can set the face picture type by selecng Custom, Head Shot, Half-Body Shot, or Full-Body
Shot. If you select Custom, you can dene detailed picture width and height of a picture freely.
If the captured pictures should have the same picture height, check Fixed Value and input
desired picture height.
Check Face Beaucaon and adjust the beaucaon level as needed.
Note
Face Beaucaon slightly adjusts skin tone and reduces facial noise.
Background Picture Sengs
Comparing to target picture, background picture is the scene image oers extra environmental
informaon. You can set the background picture quality and resoluon. If the background image
need to be uploaded to surveillance center, check Background Upload.
Text Overlay
You can check desired items (Device No., Camera Info. and Capture Time) and adjust their order
to display on captured pictures by .
Smart Linkage PTZ Camera User Manual
27
background
The content of Device No. and Camera Info should be input on the same page.
Mul-Target-Type Detecon Algorithm Parameters
It is used to set and opmize the parameters of the algorithm library for Mul-Target-Type
Detecon in the panoramic channel.
Go to the Conguraon Mul-Target-Type Detecon → Camera 02 → Advanced Conguraon
for conguraon.
HMS Version
It refers to the current algorithm version, which cannot be edited.
Restore Defaults
Click Restore to restore all the sengs in advanced conguraon to the factory default.
Detecon Parameters
Generaon Speed
It is the speed of deciding whether an object in detecon area is a target or not. The higher the
value is, the faster the target will be detected. The default value is recommended.
Sensivity
It is the sensivity of recognizing a target. The higher the value is, the easier a target will be
recognized, and the higher possibility of misinformaon would be. The default value is
recommended.
Capture Parameters
Best Shot
Capture Threshold
It refers for the quality of face to trigger capture and alarm. Higher value means beer quality
should be met to trigger capture and alarm.
Quick Shot
The device captures the target picture once the score of the captured face exceeds the Quick
Shot Threshold during the Max. Capture Interval. Otherwise, the device selects and uploads
the picture with the highest score during the Max. Capture Interval.
Quick Shot Threshold
It refers to the quality of face to trigger quick shot.
Max. Capture Interval
It describes the max. me occupaon for one quick shot.
Face Filtering Time
Smart Linkage PTZ Camera User Manual
28
background
It means the me interval between the camera detecng a face and taking a capture acon. If
the detected face stays in the scene for less than the set ltering me, capture will not be
triggered. For example, if the face ltering me is set as 5 seconds, the camera will capture the
detected face when the face keeps staying in the scene for 5 seconds.
3.5 Smart Event
Note
You need to enable the smart event funcon on VCA Resource page rst to show the funcon
conguraon page.
Both channel supports the 4 smart event types, line crossing detecon, intrusion detecon, region
entrance detecon and region exit detecon.
If you enable the panorama tracking and the smart event in the panoramic channel, the PTZ
channel tracks the target that triggers the event rule set in the panoramic channel.
When both channels set the smart events and the arming schedule overlaps, the panorama target
tracking is prior to the smart event detecon of the PTZ channel.
3.5.1 Set Intrusion Detecon
Intrusion detecon detects the object movement of entering and loitering in a predened area.
When intrusion occurs, the device takes linkage acons as response.
Steps
1.
Go to Conguraon → Event → Smart Event → Intrusion Detecon .
2.
Select a channel.
3.
Check Enable.
4.
Oponal: Click Lock to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
5.
Adjust the live image to the desired scene by using PTZ control buons.
Note
PTZ control is only available for Camera 01.
6.
Draw detecon area.
1) Select a Region No.. Up to 4 regions can be set.
2) Click Detecon Area.
3) Click on the live image to draw the boundaries of the detecon area, and right click to
complete drawing.
Smart Linkage PTZ Camera User Manual
29
background
7.
Oponal: Set the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the detecon.
1) Click Max. Size, and drag the mouse on live image. If you want to change the size, click the
buon and draw again.
2) Click Min. Size, and drag the mouse on the live image. If you want to change the size, click the
buon and draw again.
8.
Set detecon parameters.
Sensivity It stands for the sensivity of detecng an target. The higher the value of
sensivity is, the more easily the target is detected.
Threshold Threshold stands for the me of the target loitering in the region. If the me
that she/he stays in the region exceeds the threshold, the alarm is triggered.
Detecon
Target
You can specify the object type, and the device only detects the selected
type of objects.
Figure 3-1 Draw Area
9.
Click Save.
10.
Repeat above steps to set other detecon areas.
11.
Set arming schedule. See Set Arming Schedule .
12.
Set linkage method. See Linkage Method Sengs .
Smart Linkage PTZ Camera User Manual
30
background
3.5.2 Set Line Crossing Detecon
Line crossing detecon is used to detect the object movement of crossing a predened line. When
it occurs, the device takes linkage acons as response.
Steps
1.
Go to Conguraon → Event → Smart Event → Line Crossing Detecon .
2.
Select a channel.
3.
Check Enable.
4.
Oponal: Click Lock to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
5.
Adjust the live image to the desired scene by using PTZ control buons.
Note
PTZ control is only available for Camera 01.
6.
Draw detecon line.
1) Select a Line No.. Up to 4 lines can be set in the scene.
2) Click Detecon Area.
A yellow line is displayed on live image.
3) Click on the line, and drag its end points to adjust the length and posion.
4) Select the Direcon for the detecon line.
Direcon
It stands for the direcon from which the object goes across the line.
A<->B
The object going across the line from both direcons can be detected and alarms are
triggered.
A->B
Only the object crossing the congured line from side A to side B can be detected.
B->A
Only the object crossing the congured line from side B to side A can be detected.
Smart Linkage PTZ Camera User Manual
31
background
Figure 3-2 Draw Line
7.
Oponal: Set the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the detecon.
1) Click Max. Size, and drag the mouse on live image. If you want to change the size, click the
buon and draw again.
2) Click Min. Size, and drag the mouse on the live image. If you want to change the size, click the
buon and draw again.
8.
Set detecon parameters.
Sensivity It stands for the sensivity of detecng an target. The higher the value is,
the more easily the target is detected.
Detecon
Target
You can specify the object type, and the device only detects the selected
type of objects.
9.
Click Save.
10.
Repeat above steps to set other lines.
11.
Set arming schedule. See
Set Arming Schedule .
12.
Set linkage method. See Linkage Method Sengs .
3.5.3 Set Region Entrance Detecon
Region entrance detecon is used to detect the object movement of entering a predened area.
When it occurs, the device takes linkage acons as response.
Smart Linkage PTZ Camera User Manual
32
background
Steps
1.
Go to Conguraon → Event → Smart Event → Region Entrance Detecon .
2.
Select a channel.
3.
Check Enable.
4.
Oponal: Click Lock to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
5.
Adjust the live image to the desired scene by using PTZ control buons.
Note
PTZ control is only available for Camera 01.
6.
Draw detecon area.
1) Select a Region No.. Up to 4 regions can be set.
2) Click Detecon Area.
3) Click on the live image to draw the boundaries of the detecon area, and right click to
complete drawing.
7.
Oponal: Set the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the detecon.
1) Click Max. Size, and drag the mouse on live image. If you want to change the size, click the
buon and draw again.
2) Click Min. Size, and drag the mouse on the live image. If you want to change the size, click the
buon and draw again.
8.
Set detecon parameters.
Sensivity It stands for the sensivity of detecng an target. The higher the value is,
the more easily the target is detected.
Detecon
Target
You can specify the object type, and the device only detects the selected
type of objects.
Smart Linkage PTZ Camera User Manual
33
background
Figure 3-3 Draw Area
9.
Click Save.
10.
Repeat above steps to set other regions.
11.
Set arming schedule. See Set Arming Schedule .
12.
Set linkage method. See Linkage Method Sengs .
3.5.4 Set Region Exing Detecon
Region exing detecon is used to detect the objects movement of exing from a predened area.
When it occurs, the device takes linkage acons as response.
Steps
1.
Go to Conguraon → Event → Smart Event → Region Exing Detecon .
2.
Select a channel.
3.
Check Enable.
4.
Oponal: Click Lock to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
5.
Adjust the live image to the desired scene by using PTZ control buons.
Note
PTZ control is only available for Camera 01.
6.
Draw detecon area.
1) Select a Region No.. Up to 4 regions can be set.
Smart Linkage PTZ Camera User Manual
34
background
2) Click Detecon Area.
3) Click on the live image to draw the boundaries of the detecon area, and right click to
complete drawing.
7.
Oponal: Set the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the detecon.
1) Click Max. Size, and drag the mouse on live image. If you want to change the size, click the
buon and draw again.
2) Click Min. Size, and drag the mouse on the live image. If you want to change the size, click the
buon and draw again.
8.
Set detecon parameters.
Sensivity It stands for the sensivity of detecng an target. The higher the value is,
the more easily the target is detected.
Detecon
Target
You can specify the object type, and the device only detects the selected
type of objects.
Figure 3-4 Draw Area
9.
Click Save.
10.
Repeat above steps to set other regions.
11.
Set arming schedule. See Set Arming Schedule .
12.
Set linkage method. See Linkage Method Sengs .
Smart Linkage PTZ Camera User Manual
35
background
3.5.5 Detect Audio Excepon
Audio excepon detecon funcon detects the abnormal sound in the video security scene, such
as the sudden increase/decrease of the sound intensity, and some certain acons can be taken as
response.
Steps
1.
Go to Conguraon → Event → Smart Event → Audio Excepon Detecon .
2.
Select one or several audio excepon detecon types.
Audio Loss Detecon
Detect sudden loss of audio track.
Sudden Increase of Sound Intensity Detecon
Detect sudden increase of sound intensity. Sensivity and Sound Intensity Threshold are
congurable.
Note
The lower the sensivity is, the more signicant the change should be to trigger the
detecon.
The sound intensity threshold refers to the sound intensity reference for the detecon. It is
recommended to set as the average sound intensity in the environment. The louder the
environment sound, the higher the value should be. You can adjust it according to the real
environment.
Sudden Decrease of Sound Intensity Detecon
Detect sudden decrease of sound intensity. Sensivity is congurable.
3.
Refer to
Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage methods.
4.
Click Save.
Note
The funcon varies according to dierent models.
3.6 Smart Display
This funcon displays real me images captured by certain smart funcons.
Note
To use this funcon, you should rst enable and congure certain smart funcons.
Smart Linkage PTZ Camera User Manual
36
background
You can view the live image in one or two windows. Click or to switch.
You can choose a live view. Click to choose a live view camera channel to display.
You can change the layout of the display page. Click and check the display content you need
to add to the layout.
Smart Linkage PTZ Camera User Manual
37
background
Chapter 4 PTZ
PTZ is an abbreviaon for pan, lt, and zoom. It means the movement opons of the camera.
4.1 PTZ Control
In live view interface, you can use the PTZ control buons to control the device panning, lng,
and zooming.
PTZ Control Panel
Click and hold the direconal buon to pan/lt
the device.
Note
You can set Keyboard Control Speed in
Conguraon → PTZ → Basic Sengs . The
speed of pan/lt movement in live view is
based on this speed level.
You can set Max. Tilt-angle in Conguraon
→ PTZ → Basic Sengs to limit lt
movement range.
Click the buon, then the device keeps panning.
Note
You can set Auto Scan Speed in Conguraon
→ PTZ → Basic Sengs . The higher the value
you set, the faster the device pans.
Drag the slider to adjust the speed of pan/lt
movement.
Note
You can set Manual Control Speed in Conguraon → PTZ → Basic Sengs .
Smart Linkage PTZ Camera User Manual
38
background
Compable The control speed is same as Keyboard Control
Speed.
Pedestrian Choose Pedestrian when you monitor the
pedestrians.
Non-motor Vehicle Choose Non-motor Vehicle when you monitor
the non-motor vehicles.
Motor Vehicle Choose Motor Vehicle when you monitor the
motor vehicles.
Auto You are recommended to set it as Auto when
the applicaon scene of the speed dome is
complicated.
To avoid blurred image resulted from fast zoom, you can check Enable Proporonal Pan in
Conguraon → PTZ → Basic Sengs . If you enable this funcon, the pan/lt speed change
according to the amount of zoom. When there is a large amount of zoom, the pan/lt speed will be
slower for keeping the image from moving too fast on the live view image.
Zoom in/out
Click the buon, and the lens zooms in.
Click the buon, and the lens zooms out.
Note
You can set Zooming Speed in Conguraon → PTZ → Basic Sengs . The higher the value is,
the faster the zooming speed is.
You can set Zoom Limit in Conguraon → Image → Display Sengs → Other to limit the
maximum value of the total zoom (digital zoom and opcal zoom).
Focus
Click the buon, then the lens focuses near and
the object nearby gets clear.
Click the buon, then the lens focuses far and
the object far away gets clear.
Smart Linkage PTZ Camera User Manual
39
background
Iris
When the image is too dark, click the buon to
enlarge the iris.
When the image is too bright, click the buon
to stop down the iris.
4.2 Set Preset
A preset is a predened image posion. For the dened preset, you can call the preset No. to view
the posion.
Steps
1.
Click to show the seng panel, and click .
2.
Use the PTZ control buons to move the lens to the desired posion.
3.
Select a preset number from the preset list, and click to nish the seng.
Note
Some presets are predened with special command. You can only call them but not congure
them.
4.
Repeat the steps above to set mulple presets.
Click the buon to call the preset.
Click the buon to delete the preset.
Note
You can delete all presets in Conguraon → PTZ → Clear Cong . Click Clear All Presets, and
click Save.
What to do next
Go to Conguraon → PTZ → Basic Sengs to set preset freezing and preset speed.
Aer enabling preset freezing, the live image switches directly from one preset to another, without
showing the areas between these two scenes. It also guarantees the masked area will not be seen
when the device is moving.
4.2.1 Special Presets
You can call the following presets with special demands to enable corresponding funcons.
Smart Linkage PTZ Camera User Manual
40
background
Preset No. Funcon Preset No. Funcon
33 Auto ip 92 Set manual limits
34 Back to origin 93 Save manual limits
35 Call patrol 1 94 Remote reboot
36 Call patrol 2 95 Call OSD menu
37 Call patrol 3 96 Stop a scan
38 Call patrol 4 97 Start random scan
39 Day mode 98 Start frame scan
40 Night mode 99 Start auto scan
41 Call paern 1 100 Start lt scan
42 Call paern 2 101 Start panorama scan
43 Call paern 3 102 Call patrol 5
44 Call paern 4 103 Call patrol 6
45 One-touch patrol 104 Call patrol 7
46 Day/Night Mode 105 Call patrol 8
4.3 Set Patrol Scan
Patrol scan is a funcon to automacally move among mulple presets.
Before You Start
Make sure that you have dened more than one presets. See Set Preset for detailed conguraon.
Steps
1.
Click to show the seng panel, and click to enter patrol seng interface.
2.
Select a patrol number from the list and click
.
3.
Click to add presets.
Preset
Select predened preset.
Speed
Set the speed of moving from one preset to another.
Time
It is the duraon staying on one patrol point.
Delete the presets in patrol.
Smart Linkage PTZ Camera User Manual
41
background
Adjust the preset order.
Note
A patrol can be congured with 32 presets at most, and 2 presets at least.
4.
Click OK to nish a patrol seng.
5.
Repeat the steps above to congure mulple patrols.
6.
Operate patrols.
Call the patrol.
Stop patroling.
Delete the patrol.
Set the patrol.
Note
You can delete all patrols in Conguraon → PTZ → Clear Cong . Click Clear All Patrols, and
click Save.
4.4 Set Limit
The device can only move within the limited range.
Steps
1.
Go to Conguraon → PTZ → Limit .
2.
Select Limit Type.
Manual Stops
It refers to the movement range limit when you control the device manually.
Scan Stops
It refers to the movement range limit when the device scans automacally.
Note
Scan limit is only supported by the device that has scan funcon.
3.
Click Set and set limits according to the prompt on the live image.
4.
Oponal: Click Clear to clear the limit sengs of the selected mode.
5.
Click Save.
6.
Check Enable Limit.
Note
If you need to cancal all the set patrol paths, go to Conguraon → PTZ → Clear Cong , select
Clear All PTZ Limited, and click Save.
Smart Linkage PTZ Camera User Manual
42
background
Result
The device can only move within the set region aer saving the sengs.
4.5 Set Inial Posion
Inial posion refers to the relave inial posion of the device azimuth. You can set the inial
posion if you need to select one point in the scene as the base point.
Steps
1.
Go to Conguraon → PTZ Inial Posion .
2.
Move the device to the needed posion by manually controlling the PTZ control buons.
3.
Click Set to save the informaon of inial posion.
Call The device moves to the set inial posion.
Clear Clear the set inial posion.
4.6 Set Scheduled Tasks
You can set the device to perform a certain task during a certain period.
Steps
1.
Go to Conguraon → PTZ → Scheduled Tasks .
2.
Check Enable Scheduled Task.
3.
Select the task type and set the period. For seng the period, refer to
Set Arming Schedule .
4.
Repeat step 3 to set more than one scheduled tasks.
5.
Set Park Time. During the set task period, if you operate the device manually, the scheduled task
will be suspended. When the manual operaon is over, the device will connue to perform the
scheduled task aer the set park me.
6.
Click Save.
Note
If you want to clear all scheduled tasks, go to Conguraon → PTZ → Clear Cong , check Clear
All Scheduled Tasks, and click Save.
4.7 Set Park Acon
You can set the device to perform an acon (for example, preset or patrol) or return to a posion
aer a period of inacvity (park me).
Before You Start
Set the acon type rst. For example, if you want to select patrol as park acon, you should set the
patrol. See Set Patrol Scan for details.
Smart Linkage PTZ Camera User Manual
43
background
Steps
1.
Go to Conguraon → PTZ → Park Acon .
2.
Check Enable Park Acon.
3.
Set Park Time: the inacve me before the device starts park acon.
4.
Select Acon Type according to your needs.
5.
Select an Acon Type ID, if you select patrol or preset as acon type.
When the acon type is patrol, acon type ID stands for patrol No. When the acon type is
preset, acon type ID stands for preset No.
6.
Click Save.
4.8 Set Privacy Mask
Privacy masks cover certain areas on the live image to protect personal privacy from being live
viewed and recorded.
Steps
1.
Go to Conguraon → PTZ → Privacy Mask .
2.
Select the PTZ channel.
1) Check Enable Privacy Masks.
2) Adjust the live image to the target scene via PTZ control buons.
3) Draw the area.
Draw Area Click Draw Area and drag the mouse in live
view image. You can drag the corners of the
red rectangle to adjust the area.
Stop Drawing Click Stop Drawing aer drawing area.
4) Click Add.
It is listed in Privacy Mask List.
5) Edit Name, Type, and Acve Zoom Rao on your demand.
Acve Zoom Rao
When the actual zoom rao is less than the set acve zoom rao, the set area can not be
covered. When the actual zoom rao is greater than the set acve zoom rao, the privacy
mask is valid. The maximum value of acve zoom rao depends on the camera module.
6) Click Save.
7) Repeat the steps above to set other privacy masks.
3.
Select panoramic channel.
1) Check Enable Privacy Masks.
2) Draw the area.
Smart Linkage PTZ Camera User Manual
44
background
Draw Area Click Draw Area and drag the mouse in live
image. You can drag the corners of the red
rectangle to adjust the area.
Stop Drawing ClickStop Drawing aer drawing area.
3) Click Add.
It will be listed in Privacy Mask List.
4) Edit Name, Type on your demand.
5) Click Save.
6) Repeat the steps above to set other privacy masks.
4.9 Set Smart Tracking
The funcon allows the device detecng and tracking the moving targets in the scene. The target
stays in the center of the live image with a predened size during the tracking process.
Steps
1.
Go to Conguraon → PTZ → Smart Tracking .
2.
Check Enable Smart Tracking
3.
Set the Duraon. The device stops tracking when the duraon me is up.
4.
Select a target in the live image and adjust the PTZ buons to see the target at desired size.
5.
Click Set Zoom Rao. The device tracks the target at a xed zoom rao.
6.
Click Save.
4.10 Set Rapid Focus
Rapid focus is a funcon to reduce me of focusing comparing with that of normal focusing. To use
the funcon, calibraon should be done rst. Rapid focus may not be supported by certain device
models.
Steps
1.
Go to Conguraon → PTZ → Rapid Focus .
2.
Add scenes for calibraon.
1) Adjust the live image to a desired scene via PTZ control buons, and click Add.
2) Set the Rate and the Calibraon Point Amount of the added scene.
Note
More calibraon points may increase calibraon accuracy, but more focusing me is required.
The default amount is recommended.
3.
Select the scene to display the calibraon line.
A red line displays on live image.
4.
Adjust the length and posion of the line by dragging its two endpoints.
Smart Linkage PTZ Camera User Manual
45
background
Note
The red line is recommended to stay in the center of the scene and to cover ground at the same
me.
Double click the image to enter full screen mode.
5.
Click Start Calibraon.
Calibraon status displays on the live image.
6.
Repeat to add other scenes and complete the calibraon.
7.
Check Enable Height Compensaon if the mounng height of the device is lower than 3 meters.
8.
Check Enable aer successful calibraon.
9.
Click Save.
4.11 Panorama Tracking
This funcon links panoramic channel with PTZ channel through calibraon. The PTZ channel tracks
moving objects in panoramic channel and automacally adjusts its PTZ posions to keep the target
in the center of PTZ view for more details.
4.11.1 Adjust Scene of Panoramic Channel
If the panoramic channel adopts a varifocal lens, you have to set the scene for the channel before
calibrang the two channels to establish the link.
Steps
1.
Go to Conguraon → PTZ → Panorama Tracking .
2.
Click 1. Scene Calibraon.
3.
Click Unlock to start adjustment.
4.
Adjust the scene of the panoramic channel to the desired place via PTZ control buons.
Note
If you nd it is unable to focus clear, you can set Focus Mode as Semi-auto or Auto, and
adjustMin. Focus Distance to a smaller level.
If you want to lt more than the current limit, check Elevaon Range and set it to a larger
range if available.
5.
Click Lock to nish.
6.
Adjust the angle of the speaker.
-
You can check the box to bind the lt angle of the panoramic channel and the speaker.
-
Or click Speaker Angle Down and Speaker Angle Up to adjust the angle.
7.
Click Save.
8.
Oponal: Click Restore the Scene to restore the scene sengs to the factory.
Smart Linkage PTZ Camera User Manual
46
background
4.11.2 Link Channels by Calibraon
Calibrate the panoramic channel and the PTZ channel to establish the link.
Steps
1.
Go to Conguraon → PTZ → Panorama Tracking .
2.
Click Calibraon.
3.
Calibrate the channels automacally.
1) Select the Calibraon Mode as Auto.
2) Click Start Calibraon.
The device starts calibraon automacally.
3) Aer the calibraon is nished, click Stop Calibraon and exit the interface.
4.
Oponal: If automac calibraon fails, you can use the manual calibraon.
1) Select the Calibraon Mode as Manual.
2) Select a calibraon point in Calibraon Parameter list.
A numbered green cross is displayed on the panoramic image. You can drag the green cross to
adjust its posion.
3) Click Add to save the cross posion in the panoramic channel.
4) Adjust PTZ to place the green cross in the PTZ camera channel to the same posion as the
green cross in panoramic camera channel. 1× zoom rao is recommended.
Note
To quickly locate the desired point in the PTZ channel, you can click and click the target
posion in the PTZ channel.
5) Click to save the PTZ posion of this calibraon point.
6) Repeat the steps above to set at least 4 calibraon points.
7) Click Start Calibraon.
5.
Check Track to enable the funcon.
6.
Click Save to nish calibraon.
4.11.3 Set Tracking Parameters
The tracking parameters includes the inial tracking posion, tracking zoom rao, and tracking
duraon.
Note
The tracking parameters are only available when you select the VCA resource as Smart Event, Road
Trac, and Vehicle Arming.
Steps
1.
Go to Conguraon → PTZ → Panorama Tracking .
2.
Set the inial tracking posion of the PTZ channel.
Smart Linkage PTZ Camera User Manual
47
background
When the tracking task stops, the PTZ channel returns to the set inial posion.
1) Adjust the PTZ channel to the desired scene as the inial posion.
2) Click Inial Tracking Posion to save the posion.
3.
Set the tracking zoom rao.
Set a xed
zoom rao
A xed zoom rao mean the PTZ channel keeps the set zoom value
throughout the tracking.
Adjust the Self-adapve Rao Coecient to 0.
Adjust the zoom to a desired level.
Click Set Zoom Rao to save the zoom level.
Set auto zoom
rao control
The device determines the actual zoom rao dynamically according to the
detected target size and the set Self-adapve Rao Coecient.
Larger Self-adapve Rao Coecient means larger zoomed target during
tracking
4.
Set the tracking duraon.
-
When you set the Tracking Duraon as 0, the PTZ channel keeps tracking the target unl it
leaves the view of the panoramic channel.
-
When you set the Tracking Duraon as a number other than 0, the PTZ channel tracks a target
for the set me. The tracking stops when the me is up or when the target leaves the view of
the panoramic channel.
5.
Click Save.
4.11.4 Advanced Sengs for Panorama Tracking
Note
The advanced sengs are only available when you select VCA resource as Smart Event.
Tracking Takeover and Linked Tracking Capture are two mutually exclusive modes for panorama
tracking.
Tracking Takeover
When the target leaves the view of the panoramic channel, the PTZ channel takes over the leading
role of the task and keeps tracking.
Check to enable the funcon.
Linked Tracking Capture
The PTZ channel captures the target during tracking.
Capture parameters are allowed to adjust.
Capture Threshold
It refers for the quality of face to trigger capture and alarm. Higher value means beer quality
should be met.
Smart Linkage PTZ Camera User Manual
48
background
Remove Duplicated Faces
This funcon can lter out repeated captures of one target face.
Similarity Threshold for Duplicates Removing
It is the similarity between the newly captured face and the picture in the duplicates
removing library. When the similarity is higher than the value you set, the captured picture is
regarded as a duplicated face and will be dropped.
Duplicates Removing Library Grading Threshold
It is the face grading threshold that triggers duplicates checking. When the face grading is
higher than the set value, the captured face is compared with the face pictures that in the
duplicates removing library.
Duplicates Removing Library Update Time
Every face picture is kept in the duplicates removing library for the set update me.
Face Exposure
Enable the funcon, and the device automacally adjusts exposure level when human faces
appear in the scene.
Reference Brightness
It refers to the reference brightness of a face in the face exposure mode. If a face in the actual
scene is brighter than the set reference brightness, the device lower the exposure level. If a
face in the actual scene is darker than the set reference, the device increases the exposure
level.
Minimum Duraon
The extra me the device keeps the face exposure level aer the face disappears in the scene.
4.12 Set Device Posion
Before You Start
Go to Conguraon → PTZ → Basic Sengs → PTZ OSD to enable PT Status display.
Use other direcon indicang devices to nd the North at the device locaon.
Steps
1.
Go to Conguraon → PTZ Posion Sengs .
2.
Set compass.
1) Adjust the lt posion of the device to 0 by controlling the up arrow and down arrow on the
PTZ panel.
2) Adjust the pan posion to show the live view of the north direcon by controlling the le
arrow and right arrow on the PTZ panel.
3) Click Set as North.
3.
Click Gyroscope Atude Calibraon to calibrate gyroscope.
Smart Linkage PTZ Camera User Manual
49
background
Note
Only the device with built-in gyroscope supports this funcon.
4.
Get the device locaon informaon in advance, and input the longitude and latude of the
device manually.
5.
Set vandal-proof alarm.
The funcon enables the device to trigger alarms when its posion changes because of shock or
vandalism.
Sensivity
The higher the value is, the easier the alarm will be triggered.
Upload Vandal-proof Alarm
The device uploads the alarm informaon when the alarm is triggered.
Vandal-proof Alarm Voice Warning
The device triggers the alarm with audible warning.
6.
Click Save.
What to do next
If you lost direcon when operang the device, you can click Point to North to call the north
posion that is saved in the device.
4.13 GPS Calibraon
GPS calibraon is used to map the geographical locaon to the camera scene so that the device
can calculate the real-me geographic informaon of targets. This funcon is only supported under
certain VCA resource opons.
4.13.1 Set GPS Calibraon
Before You Start
Choose at least 4 calibraon points on the ground in the monitoring scene and measure the
precise longitude and latude of the points. The calibraon points should scaer in a 2 × 2 or 3 × 3
array.
Steps
1.
Go to Conguraon → PTZ → GPS Calibraon Calibraon .
Note
The PTZ control is automacally locked to avoid interrupon during conguraon.
2.
Select the longitude and latude type according to device locaon.
3.
Set calibraon points.
1) Adjust the pan, lt, and zoom to nd the scene with a calibraon point.
2) Click and click on the calibraon point on the live image.
Smart Linkage PTZ Camera User Manual
50
background
The selected point is zoomed in and placed in the center of the image.
3) Click again.
A green cross shows on the point.
4) Click Add and input the precise longitude and latude of the point.
5) Click to save the pan, lt, and zoom value of the point.
6) Click Save.
7) Repeat the steps to set other calibraon points.
4.13.2 Verify Calibraon
Before You Start
Choose vericaon points on the ground in the monitoring scene and measure the precise
longitude and latude of the points.
Steps
1.
Go to Conguraon → PTZ → GPS Calibraon Calibraon Vericaon .
Note
The PTZ control is automacally locked to avoid interrupon during conguraon.
2.
Set vericaon points.
1) Adjust the pan, lt, and zoom to nd the scene with a vericaon point.
2) Click and click on the vericaon point on the live image.
The selected point is zoomed in and placed in the center of the image.
3) Click again.
A red cross shows on the point.
4) Click Add and input the precise longitude and latude of the point.
5) Click to save the pan, lt, and zoom value of the point.
6) Click Save.
7) Repeat the steps to set other vericaon points.
Numbered green and blue rectangles are displayed on the image. The blue rectangle marks
the PTZ posion of the vericaon point you set and the green rectangle marks the calculated
PTZ posion based on the longitude and latude you input. If the two rectangles are close to
each other, then the GPS calibraon succeeds.
4.14 Set Power O Memory
This funcon can resume the previous PTZ status of device aer it restarng from a power-o.
Steps
1.
Go to Conguraon → PTZ → Basic Sengs .
Smart Linkage PTZ Camera User Manual
51
background
2.
Select Resume Time Point. When the device stays at one posion for the set resume me point
or more, the posion is saved as a momory point. The device returns to the last memory point
when it restarts.
3.
Click Save.
4.15 Set PTZ Priority
The funcon can set the PTZ priority of dierent signals.
Steps
1.
Go to Conguraon → PTZ Priorize PTZ .
2.
Set the priority signal and delayed me.
Network
The network signal controls the device with priority.
RS-485
The RS-485 signal controls the device with priority.
Delay
It refers to the me interval of PTZ operaon controlled by dierent signals. When the
operaon with high priority is nished, the low priority signal controls the device aer the
seng interval.
3.
Click Save.
Smart Linkage PTZ Camera User Manual
52
background
Chapter 5 Live View
It introduces the live view parameters, funcon icons and transmission parameters sengs.
5.1 Live View Parameters
The supported funcons vary depending on the model.
Note
For mulchannel devices, select the desired channel rst before live view sengs.
5.1.1 Window Division
You can choose a layout for live view window.
displays one live image. You can click to switch between channels.
displays live images in 2 × 2 layout.
displays live images in PIP (picture in picture) layout.
displays live images in 1 × 2 layout.
displays live images in 2 × 1 layout.
5.1.2 Start and Stop Live View
On Live View page, click to start all live view. Click to stop all live view.
You can also start the live view of the channels one by one through clicking a divided window rst
and double-clicking a channel from the channel list on le.
5.1.3 Aspect Rao
Aspect Rao is the display rao of the width to height of the image.
refers to 4:3 window size.
refers to 16:9 window size.
refers to original window size.
refers to self-adapve window size.
5.1.4 Live View Stream Type
Select the live view stream type according to your needs. For the detailed informaon about the
stream type selecon, refer to Stream Type .
Smart Linkage PTZ Camera User Manual
53
background
5.1.5 Start Digital Zoom
It helps to see a detailed informaon of any region in the image.
Steps
1.
Click to enable the digital zoom.
2.
In live view image, drag the mouse to select the desired region.
3.
Click in the live view image to back to the original image.
5.1.6 Conduct Regional Focus
You can enable the funcon to focus on certain area.
Steps
1.
Click to enable regional focus.
2.
Drag the mouse on the live view to draw a rectangle as the desired focus area.
3.
Click to disable this funcon.
5.1.7 Conduct Regional Exposure
When the brightness of live view is not balanced, you can enable this funcon to opmize the
exposure of the selected image region.
Steps
1.
Click to enable regional exposure.
2.
Drag the mouse on the live view to draw a rectangle as the desired exposure area.
3.
Click to disable this funcon.
5.1.8 Conduct 3D Posioning
3D posioning is to relocate the selected area to the image center.
Steps
1.
Click to enable the funcon.
2.
Select a target area in live image.
-
Le click on a point on live image: the point is relocated to the center of the live image. With
no zooming in or out eect.
-
Hold and drag the mouse to a lower right posion to frame an area on the live: the framed
area is zoomed in and relocated to the center of the live image.
-
Hold and drag the mouse to an upper le posion to frame an area on the live: the framed
area is zoomed out and relocated to the center of the live image.
3.
Click the buon again to turn o the funcon.
Smart Linkage PTZ Camera User Manual
54
background
5.1.9 Lens Inializaon
Lens inializaon is used on the device equipped with motorized lens. The funcon can reset lens
when long me zoom or focus results in blurred image. This funcon varies according to dierent
models.
Manual Lens Inializaon
Click to operate lens inializaon.
Auto Lens Inializaon
Go to Conguraon → System → Maintenance → Lens Correcon to enable this funcon. You
can set the arming schedule, and the device will correct lens automacally during the
congured me periods.
5.1.10 Light
Click to turn on or turn o the illuminator.
5.1.11 Display Target Informaon on Live View
Go to Conguraon → Local → Live View Parameters for sengs.
Note
Related smart funcon should be congured and enabled in advance.
Display POS Informaon
POS informaon refers to the target features, such as target ID, etc. Supported POS informaon
types varies according to device models.
5.2 Set Transmission Parameters
The live view image may be displayed abnormally according to the network condions. In dierent
network environments, you can adjust the transmission parameters to solve the problem.
Steps
1.
Go to Conguraon → Local .
2.
Set the transmission parameters as required.
Protocol
TCP
TCP ensures complete delivery of streaming data and beer video quality, yet the real-me
transmission will be aected. It is suitable for the stable network environment.
Smart Linkage PTZ Camera User Manual
55
background
UDP
UDP is suitable for the unstable network environment that does not demand high video
uency.
MULTICAST
MULTICAST is suitable for the situaon that there are mulple clients. You should set the
mulcast address for them before selecon.
Note
For detailed informaon about mulcast, refer to Mulcast .
HTTP
HTTP is suitable for the situaon that the third-party needs to get the stream from the
device.
Play Performance
Shortest Delay
The device takes the real-me video image as the priority over the video uency.
Balanced
The device ensures both the real-me video image and the uency.
Fluent
The device takes the video uency as the priority over teal-me. In poor network
environment, the device cannot ensures video uency even the uency is enabled.
Custom
You can set the frame rate manually. In poor network environment, you can reduce the
frame rate to get a uent live view. But the rule informaon may cannot display.
Auto Start Live View
Yes means the live view is started automacally. It requires a high performance monitoring
device and a stable network environment.
No means the live view should be started manually.
3.
Click OK.
Smart Linkage PTZ Camera User Manual
56
background
Chapter 6 Video and Audio
This part introduces the conguraon of video and audio related parameters.
6.1 Video Sengs
This part introduces the sengs of video parameters, such as, stream type, video encoding, and
resoluon.
Go to seng page: Conguraon → Video/Audio → Video .
Note
For device with mulple camera channels, select a channel before other sengs.
6.1.1 Stream Type
For device supports more than one stream, you can specify parameters for each stream type.
Main Stream
The stream stands for the best stream performance the device supports. It usually oers the
best resoluon and frame rate the device can do. But high resoluon and frame rate usually
means larger storage space and higher bandwidth requirements in transmission.
Sub Stream
The stream usually oers comparavely low resoluon opons, which consumes less bandwidth
and storage space.
Other Streams
Steams other than the main stream and sub stream may also be oered for customized usage.
6.1.2 Video Type
Select the content (video and audio) that should be contained in the stream.
Video
Only video content is contained in the stream.
Video & Audio
Video content and audio content are contained in the composite stream.
Smart Linkage PTZ Camera User Manual
57
background
6.1.3 Resoluon
Select video resoluon according to actual needs. Higher resoluon requires higher bandwidth and
storage.
6.1.4 Bitrate Type and Max. Bitrate
Constant Bitrate
It means that the stream is compressed and transmied at a comparavely xed bitrate. The
compression speed is fast, but mosaic may occur on the image.
Variable Bitrate
It means that the device automacally adjust the bitrate under the set Max. Bitrate. The
compression speed is slower than that of the constant bitrate. But it guarantees the image
quality of complex scenes.
6.1.5 Video Quality
When Bitrate Type is set as Variable, video quality is congurable. Select a video quality according
to actual needs. Note that higher video quality requires higher bandwidth.
6.1.6 Frame Rate
The frame rate is to describe the frequency at which the video stream is updated and it is
measured by frames per second (fps).
A higher frame rate is advantageous when there is movement in the video stream, as it maintains
image quality throughout. Note that higher frame rate requires higher bandwidth and larger
storage space.
6.1.7 Video Encoding
It stands for the compression standard the device adopts for video encoding.
Note
Available compression standards vary according to device models.
Smart Linkage PTZ Camera User Manual
58
background
H.264
H.264, also known as MPEG-4 Part 10, Advanced Video Coding, is a compression standard. Without
compressing image quality, it increases compression rao and reduces the size of video le than
MJPEG or MPEG-4 Part 2.
H.264+
H.264+ is an improved compression coding technology based on H.264. By enabling H.264+, you
can esmate the HDD consumpon by its maximum average bitrate. Compared to H.264, H.264+
reduces storage by up to 50% with the same maximum bitrate in most scenes.
When H.264+ is enabled, Max. Average Bitrate is congurable. The device gives a recommended
max. average bitrate by default. You can adjust the parameter to a higher value if the video quality
is less sasfactory. Max. average bitrate should not be higher than max. bitrate.
Note
When H.264+ is enabled, Video Quality, I Frame Interval, Prole and SVC are not congurable.
H.265
H.265, also known as High Eciency Video Coding (HEVC) and MPEG-H Part 2, is a compression
standard. In comparison to H.264, it oers beer video compression at the same resoluon, frame
rate and image quality.
H.265+
H.265+ is an improved compression coding technology based on H.265. By enabling H.265+, you
can esmate the HDD consumpon by its maximum average bitrate. Compared to H.265, H.265+
reduces storage by up to 50% with the same maximum bitrate in most scenes.
When H.265+ is enabled, Max. Average Bitrate is congurable. The device gives a recommended
max. average bitrate by default. You can adjust the parameter to a higher value if the video quality
is less sasfactory. Max. average bitrate should not be higher than max. bitrate.
Note
When H.265+ is enabled, Video Quality, I Frame Interval, Prole and SVC are not congurable.
MJPEG
Moon JPEG (M-JPEG or MJPEG) is a video compression format in which intraframe coding
technology is used. Images in a MJPEG format is compressed as individual JPEG images.
Smart Linkage PTZ Camera User Manual
59
background
6.1.8 Prole
This funcon means that under the same bitrate, the more complex the prole is, the higher the
quality of the image is, and the requirement for network bandwidth is also higher.
6.1.9 SVC
Scalable Video Coding (SVC) is the name for the Annex G extension of the H.264 or H.265 video
compression standard.
The objecve of the SVC standardizaon has been to enable the encoding of a high-quality video
bitstream that contains one or more subset bitstreams that can themselves be decoded with a
complexity and reconstrucon quality similar to that achieved using the exisng H.264 or H.265
design with the same quanty of data as in the subset bitstream. The subset bitstream is derived
by dropping packets from the larger bitstream.
SVC enables forward compability for older hardware: the same bitstream can be consumed by
basic hardware which can only decode a low-resoluon subset, while more advanced hardware
will be able decode high quality video stream.
6.1.10 I-Frame Interval
I-frame interval denes the number of frames between 2 I-frames.
In H.264 and H.265, an I-frame, or intra frame, is a self-contained frame that can be independently
decoded without any reference to other images. An I-frame consumes more bits than other
frames. Thus, video with more I-frames, in other words, smaller I-frame interval, generates more
steady and reliable data bits while requiring more storage space.
6.1.11 Smoothing
It refers to the smoothness of the stream. The higher value of the smoothing is, the beer uency
of the stream will be, though, the video quality may not be so sasfactory. The lower value of the
smoothing is, the higher quality of the stream will be, though it may appear not uent.
6.2 ROI
ROI (Region of Interest) encoding helps to discriminate the ROI and background informaon in
video compression. The technology assigns more encoding resource to the region of interest, thus
to increase the quality of the ROI whereas the background informaon is less focused.
Smart Linkage PTZ Camera User Manual
60
background
6.2.1 Set ROI
ROI (Region of Interest) encoding helps to assigns more encoding resource to the region of
interest, thus to increase the quality of the ROI whereas the background informaon is less
focused.
Before You Start
Please check the video coding type. ROI is supported when the video coding type is H.264 or H.
265.
Steps
1.
Go to Conguraon → Video/Audio → ROI .
2.
Check Enable.
3.
Select the channel No. according to your need.
4.
Select Stream Type.
5.
Select Region No. in Fixed Region to draw ROI region.
1) Click Drawing.
2) Click and drag the mouse on the view screen to draw the xed region.
3) Click Stop Drawing.
Note
Select the xed region that needs to be adjusted and drag the mouse to adjust its posion.
6.
Input the Region Name and ROI Level.
7.
Click Save.
Note
The higher the ROI level is, the clearer the image of the detected region is.
8.
Oponal: Select other region No. and repeat the above steps if you need to draw mulple xed
regions.
6.2.2 Set License Plate Tracking ROI
When the license plate tracking ROI funcon is enabled and the license plate appears in the live
picture, the image of the license plate is clearer than that of the surrounding area.
Steps
1.
Go to the ROI seng page: Conguraon → Video/Audio → ROI .
2.
Check Enable License Plate Tracking.
3.
Select ROI Level in Dynamic Region.
Note
ROI level means the image quality enhancing level. The larger the value is, the beer the image
quality would be.
Smart Linkage PTZ Camera User Manual
61
background
4.
Click Save.
6.2.3 Set Target Tracking ROI
The moving target is clearer than other areas in live image or recordings aer enabling the
funcon.
Before You Start
Go to Conguraon → PTZ → Smart Tracking to complete the smart tracking sengs.
Steps
1.
Go to Conguraon → Video/Audio → ROI .
2.
Check Enable Target Tracking.
3.
Set ROI Level for target tracking. The higher the value is, the clearer the target is.
4.
Click Save.
6.3 Display Info. on Stream
The informaon of the objects (e.g. human, vehicle, etc.) is marked in the video stream. You can
set rules on the connected rear-end device or client soware to detect the events including line
crossing, intrusion, etc.
Steps
1.
Go to the seng page: Conguraon → Video/Audio → Display Info. on Stream .
2.
Select a channel.
3.
Check Enable Dual-VCA.
4.
Click Save.
6.4 Audio Sengs
It is a funcon to set audio parameters such as audio encoding, environment noise ltering.
Go to the audio sengs page: Conguraon → Video/Audio → Audio .
6.4.1 Audio Input
External audio pick-up device is available for audio input, and audio encoding and input volume are
congurable.
Audio Encoding
The device oers several compression standard. Select according to your need.
Audio Input
Smart Linkage PTZ Camera User Manual
62
background
LineIn is supported for external audio pick-up device.
Input volume
Adjust the volume of the audio input.
6.4.2 Audio Output
The device outputs audio by the built-in speaker. You can adjust the output volume according to
your need.
6.4.3 Environmental Noise Filter
Set it as OFF or ON. When the funcon is enabled, the noise in the environment can be ltered to
some extent.
6.5 Two-way Audio
It is used to realize the two-way audio funcon between the monitoring center and the target in
the monitoring screen.
Before You Start
Make sure the audio input device (pick-up or microphone) and audio output device (speaker)
connected to the device is working properly. Refer to specicaons of audio input and output
devices for device connecon.
If the device has built-in microphone and speaker, two-way audio funcon can be enabled
directly.
Steps
1.
Click Live View.
2.
Click
on the toolbar to enable two-way audio funcon of the camera.
3.
Click and select , move the slider to adjust the volume.
4.
Click , disable the two-way audio funcon.
6.6 Display Sengs
It oers the parameter sengs to adjust image features.
Go to Conguraon → Image → Display Sengs .
For device that supports mulple channels, display sengs of each channel is required. The
sengs for dierent channels may be dierent. This part introduces all possible parameters among
the channels.
Click Default to restore sengs.
Smart Linkage PTZ Camera User Manual
63
background
6.6.1 Scene Mode
There are several sets of image parameters predened for dierent installaon environments.
Select a scene according to the actual installaon environment to speed up the display sengs.
Image Adjustment
By adjusng the Brightness, Saturaon, Contrast and Sharpness, the image can be best displayed.
Exposure Sengs
Exposure is controlled by the combinaon of iris, shuer, and gain. You can adjust image eect by
seng exposure parameters.
Exposure Mode
Auto
The iris, shuer, and gain values are adjusted automacally.
You can limit the changing ranges of iris, shuer and gain by seng Max. Iris Limit, Min. Iris
Limit, Max. Shuer Limit, Min. Shuer Limit and Limit Gain for beer exposure eect.
Iris Priority
The value of iris needs to be adjusted manually. The shuer and gain values are adjusted
automacally according to the brightness of the environment.
You can limit the changing ranges of the shuer and gain by seng Max. Shuer Limit, Min.
Shuer Limit and Limit Gain for beer exposure eect.
Shuer Priority
The value of shuer needs to be adjusted manually. The iris and gain values are adjusted
automacally according to the brightness of the environment.
You can limit the changing ranges of the iris by seng Max. Iris Limit, Min. Iris Limit and
Limit Gain for beer exposure eect.
Manual
You need to set Iris, Shuer, and Gain manually.
Slow Shuer
The higher the slow shuer level is, the slower the shuer speed is. It ensures full exposure in
underexposure condion.
Focus
It oers opons to adjust the focus mode and the minimum focus distance.
Smart Linkage PTZ Camera User Manual
64
background
Focus Mode
Auto
The device focuses automacally as the scene changes. If you cannot get a well-focused
image under auto mode, reduce light sources in the image and avoid ashing lights.
Semi-auto
The device focuses once aer the PTZ and lens zooming. If the image is clear, the focus does
not change when the scene changes.
Manual
You can adjust the focus manually on the live view page.
Min. Focus Distance
When the distance between the scene and lens is shorter than the Min. Focus Distance, the lens
does not focus.
Day/Night Switch
Day/Night Switch funcon can provide color images in the day mode and black/white images in the
night mode. Switch mode is congurable.
Day
The image is always in color.
Night
The image is always black/white
Auto
The camera switches between the day mode and the night mode according to the illuminaon
automacally.
Scheduled-Switch
Set the Start Time and the End Time to dene the duraon for day mode.
Triggered by alarm input
Two trigger modes are available: Day and Night. For example, if the trigger mode is Night, the
image turns black and white when the device receives alarm input signal.
Note
Day/Night Switch funcon varies according to models.
Set Supplement Light
Steps
1.
Go to Conguraon → Maintenance → System Service .
Smart Linkage PTZ Camera User Manual
65
background
2.
Check Enable Supplement Light.
3.
Click Save.
4.
Go to Conguraon → Image → Display Sengs → Day/Night Switch to set supplement light
parameters.
Smart Supplement Light
This feature uses smart image processing technology to reduce overexposure caused by
supplement light.
IR Light Mode
When the mode is set to Auto, the supplement light is automacally turned in or o
according to the image brightness.
Brightness Limit
Adjust the upper limit of supplement light power.
BLC
If you focus on an object against strong backlight, the object will be too dark to be seen clearly. BLC
(backlight compensaon) compensates light to the object in the front to make it clear. If BLC mode
is set as Custom, you can draw a red rectangle on the live view image as the BLC area.
HLC
When the bright area of the image is over-exposed and the dark area is under-exposed, the HLC
(High Light Compression) funcon can be enabled to weaken the bright area and brighten the dark
area, so as to achieve the light balance of the overall picture.
WDR
The WDR (Wide Dynamic Range) funcon helps the camera provide clear images in environment
with strong illuminaon dierences.
When there are both very bright and very dark areas simultaneously in the eld of view, you can
enable the WDR funcon and set the level. WDR automacally balances the brightness level of the
whole image and provides clear images with more details.
Note
When WDR is enabled, some other funcons may be not supported. Refer to the actual interface
for details.
Smart Linkage PTZ Camera User Manual
66
background
DNR
Digital Noise Reducon is used to reduce the image noise and improve the image quality. Normal
and Expert modes are selectable.
Normal
Set the DNR level to control the noise reducon degree. The higher level means stronger
reducon degree.
Expert
Set the DNR level for both space DNR and me DNR to control the noise reducon degree. The
higher level means stronger reducon degree.
White Balance
White balance is the white rendion funcon of the camera. It is used to adjust the color
temperature according to the environment.
Defog
You can enable the defog funcon when the environment is foggy and the image is misty. It
enhances the subtle details so that the image appears clearer.
EIS
Increase the stability of video image by using jier compensaon technology.
6.6.2 Image Parameters Switch
The device automacally switches image parameters in set me periods.
Go to image parameters switch seng page: Conguraon → Image → Image Parameters Switch ,
and set parameters as needed.
Set Link to Preset
You can set a preset to switch the image to a linked scene.
Steps
1.
Check Link to Preset.
2.
Select a preset.
3.
Check and set a me period and a linked scene mode.
Smart Linkage PTZ Camera User Manual
67
background
4.
Click Save.
Set Scheduled-switch
Switch the image to the linked scene mode automacally in certain me periods.
Steps
1.
Check Scheduled-switch.
2.
Select and congure the corresponding me period and linked scene mode.
Note
For Linked Scene conguraon, refer to Scene Mode .
3.
Click Save.
6.6.3 Video Standard
Video standard is an ability of a video card or video display device that denes the amount of
colors that are shown and the resoluon. The two most common video standard used are NTSC
and PAL. In NTSC, 30 frames are transmied each second. Each frame is made up of 525 individual
scan lines. In PAL, 25 frames are transmied each second. Each frame is made up of 625 individual
scan lines. Select video signal standard according to the video system in your country.
6.7 OSD
You can customize OSD (On-screen Display) informaon such as device name, me/date, font,
color, and text overlay displayed on video stream.
Go to OSD seng page: Conguraon → Image → OSD Sengs .
Select a channel.
Set the corresponding parameters, and click Save to take eect.
Displayed Informaon
Set camera name, date, week, and their related display format.
Text Overlay
Set customized overlay text on image.
OSD Parameters
Set OSD parameters, such as Display Mode, OSD Size, Font Color, and Alignment.
Smart Linkage PTZ Camera User Manual
68
background
Chapter 7 Video Recording and Picture Capture
This part introduces the operaons of capturing video clips and snapshots, playback, and
downloading captured les.
7.1 Storage Sengs
This part introduces the conguraon of several common storage paths.
7.1.1 Memory Card
You can view the capacity, free space, status, type, and property of the memory card. Encrypon of
memory card is supported to ensure data security.
Set New or Unencrypted Memory Card
Before You Start
Insert a new or unencrypted memory card to the device. For detailed installaon, refer to Quick
Start Guide of the device.
Steps
1.
Go to Conguraon → Storage → Storage Management → HDD Management .
2.
Select the memory card.
Note
If an Unlock buon appears, you need to unlock the memory card rst. See Detect Memory
Card Status for details.
3.
Click Format to inialize the memory card.
When the Status of memory card turns from Uninialized to Normal, the memory card is ready
for use.
4.
Oponal: Encrypt the memory card.
1) Click Encrypted Format.
2) Set the encrypon password.
3) Click OK.
When the Encrypon Status turns to Encrypted, the memory card is ready for use.
Note
Keep your encrypon password properly. Encrypon password cannot be found if forgoen.
5.
Oponal: Dene the Quota of the memory card. Input the percentage for storing dierent
contents according to your needs.
Smart Linkage PTZ Camera User Manual
69
background
6.
Click Save.
Set Encrypted Memory Card
Before You Start
Insert an encrypted memory card to the device. For detailed installaon, refer to Quick Start
Guide of the device.
You need to know the correct encrypon password of the memory card.
Steps
1.
Go to Conguraon → Storage → Storage Management → HDD Management .
2.
Select the memory card.
Note
If an Unlock buon appears, you need to unlock the memory card rst. See Detect Memory
Card Status for details.
3.
Verify the encrypon password.
1) Click Parity.
2) Enter the encrypon password.
3) Click OK.
When the Encrypon Status turns to Encrypted, the memory card is ready for use.
Note
If the encrypon password is forgoen and you sll want to use this memory card, see Set New
or Unencrypted Memory Card to format and set the memory card. All exisng contents will be
removed.
4.
Oponal: Dene the Quota of the memory card. Input the percentage for storing dierent
contents according to your needs.
5.
Click Save.
Detect Memory Card Status
The device detects the status of Hikvision memory card. You receive nocaons when your
memory card is detected abnormal.
Before You Start
The conguraon page only appears when a Hikvision memory card is installed to the device.
Steps
1.
Go to Conguraon → Storage → Storage Management → Memory Card Detecon .
2.
Click Status Detecon to check the Remaining Lifespan and Health Status of your memory card.
Remaining Lifespan
Smart Linkage PTZ Camera User Manual
70
background
It shows the percentage of the remaining lifespan. The lifespan of a memory card may be
inuenced by factors such as its capacity and the bitrate. You need to change the memory
card if the remaining lifespan is not enough.
Health Status
It shows the condion of your memory card. There are three status descripons: good, bad,
and damaged. You will receive a nocaon if the health status is anything other than good
when the Arming Schedule and Linkage Method are set.
Note
It is recommended that you change the memory card when the health status is not "good".
3.
Click R/W Lock to set the permission of reading and wring to the memory card.
-
Add a Lock
a. Select the Lock Switch as ON.
b. Enter the password.
c. Click Save
-
Unlock
If you use the memory card on the device that locks it, unlocking will be done automacally
and no unlocking procedures are required on the part of users.
If you use the memory card (with a lock) on a dierent device, you can go to HDD
Management to unlock the memory card manually. Select the memory card, and click
Unlock. Enter the correct password to unlock it.
-
Remove the Lock
a. Select the Lock Switch as OFF.
b. Enter the password in Password Sengs.
c. Click Save.
Note
Only admin user can set the R/W Lock.
The memory card can only be read and wrien when it is unlocked.
If the device, which adds a lock to a memory card, is restored to the factory sengs, you can
go to HDD Management to unlock the memory card.
4.
Set Arming Schedule and Linkage Method. See Set Arming Schedule and Linkage Method
Sengs for details.
5.
Click Save.
7.1.2 Set FTP
You can congure the FTP server to save images which are captured by events or a med snapshot
task.
Before You Start
Get the FTP server address rst.
Smart Linkage PTZ Camera User Manual
71
background
Steps
1.
Go to Conguraon → Network → Advanced Sengs → FTP .
2.
Congure FTP sengs.
Server Address and Port
The FTP server address and corresponding port.
User Name and Password
The FTP user should have the permission to upload pictures.
If the FTP server supports picture uploading by anonymous users, you can check Anonymous
to hide your device informaon during uploading.
Directory Structure
The saving path of snapshots in the FTP server.
Picture Filling Interval
For beer picture management, you can set the picture ling interval from 1 day to 30 days.
Pictures captured in the same me interval will be saved in one folder named aer the
beginning date and ending date of the me interval.
Picture Name
Set the naming rule for captured pictures. You can choose Default in the drop-down list to
use the default rule, that is, IP address_channel number_capture me_event type.jpg (e.g.,
10.11.37.189_01_20150917094425492_FACE_DETECTION.jpg). Or you can customize it by
adding a Custom Prex to the default naming rule.
3.
Click Upload Picture to enable uploading snapshots to the FTP server.
4.
Click Test to verify the FTP server.
5.
Click Save.
7.1.3 Set NAS
Take network server as network disk to store the record les, captured images, etc.
Before You Start
Get the IP address of the network disk rst.
Steps
1.
Go to NAS seng page: Conguraon → Storage → Storage Management → Net HDD .
2.
Click HDD No.. Enter the server address and le path for the disk.
Server Address
The IP address of the network disk.
File Path
The saving path of network disk les.
Mounng Type
Smart Linkage PTZ Camera User Manual
72
background
Select le system protocol according to the operaon system.
Enter user name and password of the net HDD to guarantee the security if SMB/CIFS is
selected.
3.
Click Test to check whether the network disk is available.
4.
Click Save.
7.1.4 Set Cloud Storage
It helps to upload the captured pictures and data to the cloud. The plaorm requests picture
directly from the cloud for picture and analysis. The funcon is only supported by certain models.
Steps
Cauon
If cloud storage is enabled, the pictures are stored in the cloud storage server preferenally.
1.
Go to Conguraon → Storage → Storage Management → Cloud Storage .
2.
Check Enable Cloud Storage.
3.
Set basic parameters.
Protocol Version The protocol version of the cloud storage server.
Server IP The IP address of the cloud storage server. It supports IPv4 address.
Serve Port The port of the cloud storage server. 6001 is the default port and you
are not recommended to edit it.
User Name and
Password
The user name and password of the cloud storage server.
Picture Storage
Pool ID
The ID of the picture storage region in the cloud storage server. Make
sure storage pool ID and the storage region ID are the same.
4.
Click Test to test the congured sengs.
5.
Click Save.
7.2 Video Recording
This part introduces the operaons of manual and scheduled recording, playback, and
downloading recorded les.
7.2.1 Record Automacally
This funcon can record video automacally during congured me periods.
Smart Linkage PTZ Camera User Manual
73
background
Before You Start
Select Trigger Recording in event sengs for each record type except Connuous. See Event and
Alarm for details.
Steps
1.
Go to Conguraon → Storage → Schedule Sengs → Record Schedule .
2.
Select channel No.
3.
Check Enable.
4.
Select a record type.
Note
The record type is vary according to dierent models.
Connuous
The video will be recorded connuously according to the schedule.
Moon
When moon detecon is enabled and trigger recording is selected as linkage method, object
movement is recorded.
Alarm
When alarm input is enabled and trigger recording is selected as linkage method, the video is
recorded aer receiving alarm signal from external alarm input device.
Moon | Alarm
Video is recorded when moon is detected or alarm signal is received from the external
alarm input device.
Moon & Alarm
Video is recorded only when moon is detected and alarm signal is received from the
external alarm input device.
Event
The video is recorded when congured event is detected.
5.
Set schedule for the selected record type. Refer to Set Arming Schedule for the seng
operaon.
6.
Click Advanced to set the advanced sengs.
Overwrite
Enable Overwrite to overwrite the video records when the storage space is full. Otherwise
the camera cannot record new videos.
Pre-record
The me period you set to record before the scheduled me.
Post-record
The me period you set to stop recording aer the scheduled me.
Smart Linkage PTZ Camera User Manual
74
background
Stream Type
Select the stream type for recording.
Note
When you select the stream type with higher bitrate, the actual me of the pre-record and
post-record may be less than the set value.
Recording Expiraon
The recordings are deleted when they exceed the expired me. The expired me is
congurable. Note that once the recordings are deleted, they can not be recovered.
7.
Click Save.
7.2.2 Record Manually
Steps
1.
Go to Conguraon → Local .
2.
Set the Record File Size and saving path to for recorded les.
3.
Click Save.
4.
Click to start recording. Click to stop recording.
7.2.3 Playback and Download Video
You can search, playback and download the videos stored in the local storage or network storage.
Steps
1.
Click Playback.
2.
Select channel No.
3.
Set search condion and click Search.
The matched video les showed on the ming bar.
4.
Click to play the video les.
-
Click
to clip video les.
-
Click
to play video les in full screen. Press ESC to exit full screen.
Note
Go to Conguraon → Local , click Save clips to to change the saving path of clipped video les.
5.
Click on the playback interface to download les.
1) Set search condion and click Search.
2) Select the video les and then click Download.
Note
Go to Conguraon → Local , click Save downloaded les to to change the saving path of
downloaded video les.
Smart Linkage PTZ Camera User Manual
75
background
7.3 Capture Conguraon
The device can capture the pictures manually or automacally and save them in congured saving
path. You can view and download the snapshots.
7.3.1 Capture Automacally
This funcon can capture pictures automacally during congured me periods.
Before You Start
If event-triggered capture is required, you should congure related linkage methods in event
sengs. Refer to Event and Alarm for event sengs.
Steps
1.
Go to Conguraon → Storage → Schedule Sengs → Capture → Capture Parameters .
2.
Set the capture type.
Timing
Capture a picture at the congured me interval.
Event-Triggered
Capture a picture when an event is triggered.
3.
Set the Format, Resoluon, Quality, Interval, and Capture Number.
4.
Refer to Set Arming Schedule for conguring schedule me.
5.
Click Save.
7.3.2 Capture Manually
Steps
1.
Go to Conguraon → Local .
2.
Set the Image Format and saving path to for snapshots.
JPEG
The picture size of this format is comparavely small, which is beer for network
transmission.
BMP
The picture is compressed with good quality.
3.
Click Save.
4.
Click
near the live view or play back window to capture a picture manually.
7.3.3 View and Download Picture
You can search, view and download the pictures stored in the local storage or network storage.
Smart Linkage PTZ Camera User Manual
76
background
Steps
1.
Click Picture.
2.
Select channel No.
3.
Set search condion and click Search.
The matched pictures showed in the le list.
4.
Select the pictures then click Download to download them.
Note
Go to Conguraon → Local , click Save snapshots when playback to change the saving path of
pictures.
Smart Linkage PTZ Camera User Manual
77
background
Chapter 8 Event and Alarm
This part introduces the conguraon of events. The device takes certain response to triggered
alarm.
8.1 Basic Event
8.1.1 Set Moon Detecon
This funcon detects moving objects in the detecon region and trigger linkage acons.
Steps
1.
Go to Conguraon → Event → Basic Event Moon Detecon .
2.
Select the channel No.
3.
Check Enable Moon Detecon.
4.
Oponal: (Only available in PTZ channel) Check Enable Moon Detecon in PTZ Control, and
the device detects moving targets in PTZ movement.
5.
Oponal: Highlight moving objects in green.
1) Check Enable Dynamic Analysis for Moon.
2) Go to Conguraon → Local to enable Rules.
6.
Select Conguraon Mode. Normal mode and expert mode are selectable.
-
For the informaon about normal mode, see
Normal Mode .
-
For the informaon about expert mode, see
Expert Mode .
7.
Set the arming schedule. See Set Arming Schedule for details.
8.
Set linkage methods. See Linkage Method Sengs for details.
9.
Click Save.
Normal Mode
You can set moon detecon parameters according to the device default parameters.
Steps
1.
Select normal mode in Conguraon.
2.
Set the sensivity of normal mode. The higher the value of sensivity is, the more sensive the
moon detecon is. If the sensivity is set to 0, moon detecon and dynamic analysis do not
take eect.
3.
Click Draw Area. Click and drag the mouse on the live video, then release the mouse to nsh
drawing one area.
Smart Linkage PTZ Camera User Manual
78
background
Figure 8-1 Set Rules
Stop Drawing Stop drawing one area.
Clear All Clear all the areas.
4.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
Expert Mode
You can congure dierent moon detecon parameters for day and night according to the actual
needs.
Steps
1.
Select Expert Mode in Conguraon.
2.
Set parameters of expert mode.
Scheduled Image Sengs
OFF
Image switch is disabled.
Auto-Switch
The system switches day/night mode automacally according to environment. It displays
colored image at day and black and white image at night.
Scheduled-Switch
The system switches day/night mode according to the schedule. It switches to day mode
during the set periods and switches to night mode during the other periods.
Smart Linkage PTZ Camera User Manual
79
background
Sensivity
The higher the value of sensivity is, the more sensive the moon detecon is. If scheduled
image sengs is enabled, the sensivity of day and night can be set separately.
3.
Select an Area and click Draw Area. Click and drag the mouse on the live image and then release
the mouse to nish drawing one area.
Figure 8-2 Set Rules
Stop Drawing Finish drawing one area.
Clear All Delete all the areas.
4.
Click Save.
5.
Oponal: Repeat above steps to set mulple areas.
8.1.2 Set Video Tampering Alarm
When the congured area is covered and cannot be monitored normally, the alarm is triggered and
the device takes certain alarm response acons.
Steps
1.
Go to Conguraon → Event → Basic Event → Video Tampering .
2.
Select the channel number.
3.
Check Enable.
4.
Set the Sensivity. The higher the value is, the easier to detect the area covering.
5.
Click Draw Area and drag the mouse in the live view to draw the area.
Stop Drawing Finish drawing.
Smart Linkage PTZ Camera User Manual
80
background
Clear All Delete all the drawn areas.
Figure 8-3 Set Video Tampering Area
6.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
7.
Click Save.
8.1.3 Set Excepon Alarm
Excepon such as network disconnecon can trigger the device to take corresponding acon.
Steps
1.
Go to Conguraon → Event → Basic Event Excepon .
2.
Select Excepon Type.
HDD Full The HDD storage is full.
HDD Error Error occurs in HDD.
Smart Linkage PTZ Camera User Manual
81
background
Network Disconnected The device is oine.
IP Address Conicted The IP address of current device is same as that of other device in
the network.
Illegal Login Incorrect user name or password is entered.
Voltage Instable The power supply voltage is uctuang.
3.
Refer to
Linkage Method Sengs for seng linkage method.
4.
Click Save.
8.1.4 Set Alarm Input
Alarm signal from the external device triggers the corresponding acons of the current device.
Before You Start
Make sure the external alarm device is connected. See Quick Start Guide for cables connecon.
Steps
1.
Go to Conguraon → Event → Basic Event → Alarm Input .
2.
Check Enable Alarm Input Handing.
3.
Select Alarm Input NO. and Alarm Type from the dropdown list. Edit the Alarm Name.
4.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
5.
Click Copy to... to copy the sengs to other alarm input channels.
6.
Click Save.
Smart Linkage PTZ Camera User Manual
82
background
Chapter 9 Arming Schedule and Alarm Linkage
Arming schedule is a customized me period in which the device performs certain tasks. Alarm
linkage is the response to the detected certain incident or target during the scheduled me.
9.1 Set Arming Schedule
Set the valid me of the device tasks.
Steps
1.
Click Arming Schedule.
2.
Drag the me bar to draw desired valid me.
Note
Up to 8 periods can be congured for one day.
3.
Adjust the me period.
-
Click on the selected me period, and enter the desired value. Click Save.
-
Click on the selected me period. Drag the both ends to adjust the me period.
-
Click on the selected me period, and drag it on the me bar.
4.
Oponal: Click Copy to... to copy the same sengs to other days.
5.
Click Save.
9.2 Linkage Method Sengs
You can enable the linkage funcons when an event or alarm occurs.
9.2.1 Trigger Alarm Output
If the device has been connected to an alarm output device, and the alarm output No. has been
congured, the device sends alarm informaon to the connected alarm output device when an
alarm is triggered.
Steps
1.
Go to Conguraon → Event → Basic Event → Alarm Output .
2.
Set alarm output parameters.
Automac Alarm For the informaon about the conguraon, see
Automac Alarm .
Manual Alarm For the informaon about the conguraon, see
Manual Alarm .
3.
Click Save.
Smart Linkage PTZ Camera User Manual
83
background
Automac Alarm
Set the automac alarm parameters, then the device triggers an alarm output automacally in the
set arming schedule.
Steps
1.
Set automac alarm parameters.
Alarm Output No.
Select the alarm output No. according to the alarm interface connected to the external alarm
device.
Alarm Name
Custom a name for the alarm output.
Delay
It refers to the me duraon that the alarm output remains aer an alarm occurs.
2.
Set the alarming schedule. For the informaon about the sengs, see Set Arming Schedule .
3.
Click Copy to… to copy the parameters to other alarm output channels.
4.
Click Save.
Manual Alarm
You can trigger an alarm output manually.
Steps
1.
Set the manual alarm parameters.
Alarm Output No.
Select the alarm output No. according to the alarm interface connected to the external alarm
device.
Alarm Name
Custom a name for the alarm output.
Delay
Select Manual.
2.
Click Manual Alarm to enable manual alarm output.
3.
Oponal: Click Clear Alarm to disable manual alarm output.
9.2.2 FTP/NAS/Memory Card Uploading
If you have enabled and congured the FTP/NAS/memory card uploading, the device sends the
alarm informaon to the FTP server, network aached storage and memory card when an alarm is
triggered.
Smart Linkage PTZ Camera User Manual
84
background
Refer to Set FTP to set the FTP server.
Refer to Set NAS for NAS conguraon.
Refer to Set New or Unencrypted Memory Card for memory card storage conguraon.
9.2.3 Send Email
Check Send Email, and the device sends an email to the designated addresses with alarm
informaon when an alarm event is detected.
For email sengs, refer to Set Email .
Set Email
When the email is congured and Send Email is enabled as a linkage method, the device sends an
email nocaon to all designated receivers if an alarm event is detected.
Before You Start
Set the DNS server before using the Email funcon. Go to Conguraon → Network → Basic
Sengs → TCP/IP for DNS sengs.
Steps
1.
Go to email sengs page: Conguraon → Network → Advanced Sengs → Email .
2.
Set email parameters.
1) Input the sender's email informaon, including the Sender's Address, SMTP Server, and
SMTP Port.
2) Oponal: If your email server requires authencaon, check Authencaon and input your
user name and password to log in to the server.
3) Set the E-mail Encrypon.
When you select SSL or TLS, and disable STARTTLS, emails are sent aer encrypted by SSL or
TLS. The SMTP port should be set as 465.
When you select SSL or TLS and Enable STARTTLS, emails are sent aer encrypted by
STARTTLS, and the SMTP port should be set as 25.
Note
If you want to use STARTTLS, make sure that the protocol is supported by your email server.
If you check the Enable STARTTLS while the protocol is not supported by your email sever,
your email is sent with no encrypon.
4) Oponal: If you want to receive nocaon with alarm pictures, check Aached Image. The
nocaon email has 3 aached alarm pictures about the event with congurable image
capturing interval.
5) Input the receiver's informaon, including the receiver's name and address.
6) Click Test to see if the funcon is well congured.
3.
Click Save.
Smart Linkage PTZ Camera User Manual
85
background
9.2.4 Nofy Surveillance Center
Check Nofy Surveillance Center, the alarm informaon is uploaded to the surveillance center
when an alarm event is detected.
9.2.5 Trigger Recording
Check Trigger Recording, and the device records the video about the detected alarm event.
For device with more than one camera channels, you can set one or more channels to take
recordings if needed.
For recording sengs, refer to Video Recording and Picture Capture
9.2.6 Flashing Light
Aer enabling Flashing Light and seng the Flashing Light Alarm Output, the light ashes when
an alarm event is detected.
Set Flashing Alarm Light Output
Steps
1.
Go to Conguraon → Event → Basic Event → Flashing Alarm Light Output .
2.
Set Flashing Duraon, Flashing Frequency and Brightness.
Flashing Duraon
The me period the ashing lasts when one alarm happens.
Flashing Frequency
The ashing speed of the light. High, Medium, and Low are selectable.
Brightness
The brightness of the light.
3.
Edit the arming schedule.
4.
Click Save.
Note
Only certain camera models support the funcon.
9.2.7 Audible Warning
Aer enabling Audible Warning and seng the Audible Alarm Output, the built-in speaker of the
device or connected external speaker plays warning sounds when alarm happens.
For audible alarm output sengs, refer to Set Audible Alarm Output .
Smart Linkage PTZ Camera User Manual
86
background
Note
Before using the funcon, go to Conguraon → Video/Audio → Audio to enable built-in speaker
in advance.
The funcon is only supported by certain camera models.
Set Audible Alarm Output
When the device detects targets in the detecon area, audible alarm can be triggered as a
warning.
Steps
1.
Go to Conguraon → Event → Basic Event → Audible Alarm Output .
2.
Select Sound Type and set related parameters.
-
Select Prompt and set the alarm mes you need.
-
Select Warning and its contents. Set the alarm mes you need.
-
Select Custom Audio. You can select a custom audio le from the drop-down list. If no le is
available, you can click Add to upload an audio le that meets the requirement. Up to three
audio les can be uploaded.
3.
Oponal: Click Test to play the selected audio le on the device.
4.
Set arming schedule for audible alarm. See
Set Arming Schedule for details.
5.
Click Save.
Note
The funcon is only supported by certain device models.
Smart Linkage PTZ Camera User Manual
87
background
Chapter 10 Network Sengs
10.1 TCP/IP
TCP/IP sengs must be properly congured before you operate the device over network. IPv4 and
IPv6 are both supported. Both versions can be congured simultaneously without conicng to
each other.
Go to Conguraon → Network → Basic Sengs → TCP/IP for parameter sengs.
NIC Type
Select a NIC (Network Interface Card) type according to your network condion.
IPv4
Two IPv4 modes are available.
DHCP
The device automacally gets the IPv4 parameters from the network if you check DHCP. The
device IP address is changed aer enabling the funcon. You can use SADP to get the device IP
address.
Note
The network that the device is connected to should support DHCP (Dynamic Host
Conguraon Protocol).
Manual
You can set the device IPv4 parameters manually. Input IPv4 Address, IPv4 Subnet Mask, and
IPv4 Default Gateway, and click Test to see if the IP address is available.
IPv6
Three IPv6 modes are available.
Route Adversement
The IPv6 address is generated by combining the route adversement and the device Mac
address.
Note
Route adversement mode requires the support from the router that the device is connected
to.
DHCP
The IPv6 address is assigned by the server, router, or gateway.
Manual
Smart Linkage PTZ Camera User Manual
88
background
Input IPv6 Address, IPv6 Subnet, IPv6 Default Gateway. Consult the network administrator for
required informaon.
MTU
It stands for maximum transmission unit. It is the size of the largest protocol data unit that can
be communicated in a single network layer transacon.
The valid value range of MTU is 1280 to 1500.
DNS
It stands for domain name server. It is required if you need to visit the device with domain
name. And it is also required for some applicaons (e.g., sending email). Set Preferred DNS
Server and Alternate DNS server properly if needed.
Dynamic Domain Name
Check Enable Dynamic Domain Name and input Register Domain Name. The device is
registered under the register domain name for easier management within the local area
network.
Note
DHCP should be enabled for the dynamic domain name to take eect.
10.1.1 Mulcast
Mulcast is a group communicaon where data transmission is addressed to a group of desnaon
devices simultaneously. Aer seng mulcast, you can send the source data eciently to mulple
receivers.
Go to Conguraon → Network → Basic Sengs Mulcast for the mulcast sengs.
IP Address
It stands for the address of mulcast host.
Stream Type
The stream type of the mulcast source.
Video Port
The video port of the selected stream.
Audio Port
The audio port of the selected stream.
FEC Port
The FEC port of the selected stream.
FEC Rao
The rao of forward error correcon.
Smart Linkage PTZ Camera User Manual
89
background
10.1.2 Mulcast Discovery
Check the Enable Mulcast Discovery, and then the online network camera can be automacally
detected by client soware via private mulcast protocol in the LAN.
10.2 Port
The device port can be modied when the device cannot access the network due to port conicts.
Cauon
Do not modify the default port parameters at will, otherwise the device may be inaccessible.
Go to Conguraon → Network → Basic Sengs → Port for port sengs.
HTTP Port
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.168.1.64:81 in the browser for login.
HTTPS Port
It refers to the port through which the browser accesses the device with cercate. Cercate
vericaon is required to ensure the secure access.
RTSP Port
It refers to the port of real-me streaming protocol.
SRTP Port
It refers to the port of secure real-me transport protocol.
Server Port
It refers to the port through which the client adds the device.
Enhanced SDK Service Port
It refers to the port through which the client adds the device. Cercate vericaon is required
to ensure the secure access.
WebSocket Port
TCP-based full-duplex communicaon protocol port for plug-in free preview.
WebSockets Port
TCP-based full-duplex communicaon protocol port for plug-in free preview. Cercate
vericaon is required to ensure the secure access.
Smart Linkage PTZ Camera User Manual
90
background
Note
Enhanced SDK Service Port, WebSocket Port, and WebSockets Port are only supported by certain
models.
For device models that support that funcon, go to Conguraon → Network → Advanced
Sengs → Network Service to enable it.
10.3 Port Mapping
By seng port mapping, you can access devices through the specied port.
Before You Start
When the ports in the device are the same as those of other devices in the network, refer to Port
to modify the device ports.
Steps
1.
Go to Conguraon → Network → Basic Sengs → NAT .
2.
Select the port mapping mode.
Auto Port Mapping Refer to
Set Auto Port Mapping for detailed informaon.
Manual Port Mapping Refer to
Set Manual Port Mapping for detailed informaon.
3.
Click Save.
10.3.1 Set Auto Port Mapping
Steps
1.
Check Enable UPnP™, and choose a friendly name for the camera, or you can use the default
name.
2.
Select the port mapping mode to Auto.
3.
Click Save.
Note
UPnP™ funcon on the router should be enabled at the same me.
10.3.2 Set Manual Port Mapping
Steps
1.
Check Enable UPnP™, and choose a friendly name for the device, or you can use the default
name.
2.
Select the port mapping mode to Manual, and set the external port to be the same as the
internal port.
3.
Click Save.
Smart Linkage PTZ Camera User Manual
91
background
What to do next
Go to the router port mapping sengs interface and set the port number and IP address to be the
same as those on the device. For more informaon, refer to the router user manual.
10.3.3 Set Port Mapping on Router
The following sengs are for a certain router. The sengs vary depending on dierent models of
routers.
Steps
1.
Select the WAN Connecon Type.
2.
Set the IP Address, Subnet Mask and other network parameters of the router.
3.
Go to Forwarding → Virtual Severs , and input the Port Number and IP Address.
4.
Click Save.
Example
When the cameras are connected to the same router, you can congure the ports of a camera as
80, 8000, and 554 with IP address 192.168.1.23, and the ports of another camera as 81, 8001, 555,
8201 with IP 192.168.1.24.
Figure 10-1 Port Mapping on Router
Smart Linkage PTZ Camera User Manual
92
background
Note
The port of the network camera cannot conict with other ports. For example, some web
management port of the router is 80. Change the camera port if it is the same as the management
port.
10.4 SNMP
You can set the SNMP network management protocol to get the alarm event and excepon
messages in network transmission.
Before You Start
Before seng the SNMP, you should download the SNMP soware and manage to receive the
device informaon via SNMP port.
Steps
1.
Go to the sengs page: Conguraon → Network → Advanced Sengs → SNMP .
2.
Check Enable SNMPv1, Enable SNMP v2c or Enable SNMPv3.
Note
The SNMP version you select should be the same as that of the SNMP soware.
And you also need to use the dierent version according to the security level required. SNMP v1
is not secure and SNMP v2 requires password for access. And SNMP v3 provides encrypon and
if you use the third version, HTTPS protocol must be enabled.
3.
Congure the SNMP sengs.
4.
Click Save.
10.5 Access to Device via Domain Name
You can use the Dynamic DNS (DDNS) for network access. The dynamic IP address of the device can
be mapped to a domain name resoluon server to realize the network access via domain name.
Before You Start
Registraon on the DDNS server is required before conguring the DDNS sengs of the device.
Steps
1.
Refer to
TCP/IP to set DNS parameters.
2.
Go to the DDNS sengs page: Conguraon → Network → Basic Sengs → DDNS .
3.
Check Enable DDNS and select DDNS type.
DynDNS
Dynamic DNS server is used for domain name resoluon.
NO-IP
NO-IP server is used for domain name resoluon.
Smart Linkage PTZ Camera User Manual
93
background
4.
Input the domain name informaon, and click Save.
5.
Check the device ports and complete port mapping. Refer to Port to check the device port , and
refer to Port Mapping for port mapping sengs.
6.
Access the device.
By Browsers Enter the domain name in the browser address bar to access the device.
By Client Soware Add domain name to the client soware. Refer to the client manual for
specic adding methods.
10.6 Access to Device via PPPoE Dial Up Connecon
This device supports the PPPoE auto dial-up funcon. The device gets a public IP address by ADSL
dial-up aer the device is connected to a modem. You need to congure the PPPoE parameters of
the device.
Steps
1.
Go to Conguraon → Network → Basic Sengs → PPPoE .
2.
Check Enable PPPoE.
3.
Set the PPPoE parameters.
Dynamic IP
Aer successful dial-up, the dynamic IP address of the WAN is displayed.
User Name
User name for dial-up network access.
Password
Password for dial-up network access.
Conrm
Input your dial-up password again.
4.
Click Save.
5.
Access the device.
By Browsers Enter the WAN dynamic IP address in the browser address bar to access
the device.
By Client Soware Add the WAN dynamic IP address to the client soware. Refer to the
client manual for details.
Note
The obtained IP address is dynamically assigned via PPPoE, so the IP address always changes
aer reboong the camera. To solve the inconvenience of the dynamic IP, you need to get a
domain name from the DDNS provider (e.g. DynDns.com). Refer to Access to Device via Domain
Name for detail informaon.
Smart Linkage PTZ Camera User Manual
94
background
10.7 Set ISUP
When the device is registered on ISUP plaorm (formerly called Ehome), you can visit and manage
the device, transmit data, and forward alarm informaon over public network.
Steps
1.
Go to Conguraon → Network → Advanced Sengs Plaorm Access .
2.
Select ISUP as the plaorm access mode.
3.
Select Enable.
4.
Select a protocol version and input related parameters.
5.
Click Save.
Register status turns to Online when the funcon is correctly set.
10.8 Set ONVIF
If you need to access to the device through ONVIF protocol, you can congure the ONVIF user to
enhance the network security.
Steps
1.
Go to Conguraon → Network → Advanced Sengs Integraon Protocol .
2.
Check Enable ONVIF.
3.
Click Add to congure the ONVIF user.
Delete Delete the selected ONVIF user.
Modify Modify the selected ONVIF user.
4.
Click Save.
5.
Oponal: Repeat the steps above to add more ONVIF users.
10.9 Set Network Service
You can control the ON/OFF status of certain protocol as desired.
Steps
Note
This funcon varies according to dierent models.
1.
Go to Conguraon → Network → Advanced Sengs → Network Service .
2.
Set network service.
WebSocket & WebSockets
Smart Linkage PTZ Camera User Manual
95
background
WebSocket or WebSockets protocol should be enabled if you use Google Chrome 57 and its
above version or Mozilla Firefox 52 and its above version to visit the device. Otherwise, live
view, image capture, digital zoom, etc. cannot be used.
If the device uses HTTP, enable WebSocket.
If the device uses HTTPS, enable WebSockets.
When you use WebSockets, select the Server Cercate.
Note
Complete cercate management before selecng server cercate. Refer to Cercate
Management for detailed informaon.
SDK Service & Enhanced SDK Service
Check Enable SDK Service to add the device to the client soware with SDK protocol.
Check Enable Enhanced SDK Service to add the device to the client soware with SDK over
TLS protocol.
When you use Enhanced SDK Service, select the Server Cercate.
Note
Complete cercate management before selecng server cercate. Refer to Cercate
Management for detailed informaon.
When set up connecon between the device and the client soware, it is recommended to
use Enhanced SDK Service and set the communicaon in Arming Mode to encrypt the data
transmission. See the user manual of the client soware for the arming mode sengs.
TLS (Transport Layer Security)
The device oers TLS1.1 and TLS1.2. Enable one or more protocol versions according to your
need.
Bonjour
Uncheck to disable the protocol.
3.
Click Save.
10.10 Set Alarm Server
The device can send alarms to desnaon IP address or host name through HTTP, HTTPS, or ISUP
protocol. The desnaon IP address or host name should support HTTP, HTTP, or ISUP data
transmission.
Steps
1.
Go to Conguraon → Network → Advanced Sengs → Alarm Server .
2.
Enter Desnaon IP or Host Name, URL, and Port.
3.
Select Protocol.
Smart Linkage PTZ Camera User Manual
96
background
Note
HTTP, HTTPS, and ISUP are selectable. It is recommended to use HTTPS, as it encrypts the data
transmission during communicaon.
4.
Click Test to check if the IP or host is available.
5.
Click Save.
10.11 TCP Acceleraon
TCP acceleraon is used to improve latency and reduce packet loss caused by network congeson
in poor network condion, and guarantee the uency of live view.
10.12 Trac Shaping
Trac shaping is used to shape and smooth video data packet before transmission.
It helps to improve latency and reduce packet loss caused by network congeson and ensure the
video quality as well. Shaping level is congurable.
10.13 Set SRTP
The Secure Real-me Transport Protocol (SRTP) is a Real-me Transport Protocol (RTP) internet
protocol, intended to provide encrypon, message authencaon and integrity, and replay aack
protecon to the RTP data in both unicast and mulcast applicaons.
Steps
1.
Go to Conguraon → Network → Advanced Sengs → SRTP .
2.
Select Server Cercate.
3.
Select Encrypted Algorithm.
4.
Click Save.
Note
Only certain device models support this funcon.
If the funcon is abnormal, check if the selected cercate is abnormal in cercate
management.
Smart Linkage PTZ Camera User Manual
97
background
Chapter 11 System and Security
It introduces system maintenance, system sengs and security management, and explains how to
congure relevant parameters.
11.1 View Device Informaon
You can view device informaon, such as Device No., Model, Serial No. and Firmware Version.
Enter Conguraon → System → System Sengs → Basic Informaon to view the device
informaon.
11.2 Restore and Default
Restore and Default helps restore the device parameters to the default sengs.
Steps
1.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance .
2.
Click Restore or Default according to your needs.
Restore Reset device parameters, except user informaon, IP parameters and video format
to the default sengs.
Default Reset all the parameters to the factory default.
Note
Be careful when using this funcon. Aer reseng to the factory default, all the
parameters are reset to the default sengs.
11.3 Search and Manage Log
Log helps locate and troubleshoot problems.
Steps
1.
Go to Conguraon → System → Maintenance → Log .
2.
Set search condions Major Type, Minor Type, Start Time, and End Time.
3.
Click Search.
The matched log les will be displayed on the log list.
4.
Oponal: Click Export to save the log les in your computer.
Smart Linkage PTZ Camera User Manual
98
background
11.4 Import and Export Conguraon File
It helps speed up batch conguraon on other devices with the same parameters.
Steps
1.
Export conguraon le.
1) Go to Conguraon → System → Maintenance → Upgrade & Maintenance .
2) Click Device Parameters and input the encrypon password to export the current
conguraon le.
3) Set the saving path to save the conguraon le in local computer.
2.
Import conguraon le.
1) Access the device that needs to be congured via web browser.
2) Click Browse to select the saved conguraon le.
3) Input the encrypon password you have set when exporng the conguraon le.
4) Click Import.
11.5 Export Diagnose Informaon
Diagnose informaon includes running log, system informaon, hardware informaon.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance . Check desired
diagnose informaon and click Diagnose Informaon to export corresponding diagnose
informaon of the device.
11.6 Reboot
You can reboot the device via browser.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance , and click Reboot.
11.7 Upgrade
Before You Start
You need to obtain the correct upgrade package.
Cauon
DO NOT disconnect power during the process, and the device reboots automacally aer upgrade.
Steps
1.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance .
2.
Choose one method to upgrade.
Firmware Locate the exact path of the upgrade le.
Smart Linkage PTZ Camera User Manual
99
background
Firmware Directory Locate the directory which the upgrade le belongs to.
3.
Click Browse to select the upgrade le.
4.
Click Upgrade.
11.8 View Open Source Soware License
Go to Conguraon → System → System Sengs → About Device , and click View Licenses.
11.9 Set Live View Connecon
It controls the remote live view connecon amount.
Live view connecon controls the maximun live view that can be streamed at the same me.
Enter Conguraon → System → Maintenance → System Service to set the upper limit of the
remote connecon number.
11.10 Time and Date
You can congure me and date of the device by conguring me zone, me synchronizaon and
Daylight Saving Time (DST).
11.10.1 Synchronize Time Manually
Steps
1.
Go to Conguraon → System → System Sengs → Time Sengs .
2.
Select Time Zone.
3.
Click Manual Time Sync..
4.
Choose one me synchronizaon method.
-
Select Set Time, and manually input or select date and me from the pop-up calendar.
-
Check Sync. with computer me to synchronize the me of the device with that of the local
PC.
5.
Click Save.
11.10.2 Set NTP Server
You can use NTP server when accurate and reliable me source is required.
Before You Start
Set up a NTP server or obtain NTP server informaon.
Smart Linkage PTZ Camera User Manual
100
background
Steps
1.
Go to Conguraon → System → System Sengs → Time Sengs .
2.
Select Time Zone.
3.
Click NTP.
4.
Set Server Address, NTP Port and Interval.
Note
Server Address is NTP server IP address.
5.
Click Test to test server connecon.
6.
Click Save.
11.10.3 Set DST
If the region where the device is located adopts Daylight Saving Time (DST), you can set this
funcon.
Steps
1.
Go to Conguraon → System → System Sengs → DST .
2.
Check Enable DST.
3.
Select Start Time, End Time and DST Bias.
4.
Click Save.
11.11 Security
You can improve system security by seng security parameters.
11.11.1 Authencaon
You can improve network access security by seng RTSP and WEB authencaon.
Go to Conguraon → System → Security Authencaon to choose authencaon protocol
and method according to your needs.
RTSP Authencaon
Digest and digest/basic are supported, which means authencaon informaon is needed when
RTSP request is sent to the device. If you select digest/basic, it means the device supports
digest or basic authencaon. If you select digest, the device only supports digest
authencaon.
RTSP Digest Algorithm
MD5, SHA256 and MD5/SHA256 encrypted algorithm in RTSP authencaon. If you enable the
digest algorithm except for MD5, the third-party plaorm might not be able to log in to the
Smart Linkage PTZ Camera User Manual
101
background
device or enable live view because of compability. The encrypted algorithm with high strength
is recommended.
WEB Authencaon
Digest and digest/basic are supported, which means authencaon informaon is needed when
WEB request is sent to the device. If you select digest/basic, it means the device supports digest
or basic authencaon. If you select digest, the device only supports digest authencaon.
WEB Digest Algorithm
MD5, SHA256 and MD5/SHA256 encrypted algorithm in WEB authencaon. If you enable the
digest algorithm except for MD5, the third-party plaorm might not be able to log in to the
device or enable live view because of compability. The encrypted algorithm with high strength
is recommended.
Note
Refer to the specic content of protocol to view authencaon requirements.
11.11.2 Set IP Address Filter
IP address lter is a tool for access control. You can enable the IP address lter to allow or forbid
the visits from the certain IP addresses.
IP address refers to IPv4.
Steps
1.
Go to Conguraon → System → Security → IP Address Filter .
2.
Check Enable IP Address Filter.
3.
Select the type of IP address lter.
Forbidden IP addresses in the list cannot access the device.
Allowed Only IP addresses in the list can access the device.
4.
Edit the IP address lter list.
Add Add a new IP address or IP address range to the list.
Modify Modify the selected IP address or IP address range in the list.
Delete Delete the selected IP address or IP address range in the list.
5.
Click Save.
11.11.3 Set HTTPS
HTTPS is a network protocol that enables encrypted transmission and identy authencaon,
which improves the security of remote access.
Smart Linkage PTZ Camera User Manual
102
background
Steps
1.
Go to Conguraon → Network → Advanced Sengs → HTTPS .
2.
Check Enable.
3.
Oponal: Check HTTPS Browsing to access the device only via HTTPS protocol.
4.
Select a server cercate.
Note
Complete cercate management before selecng server cercate. Refer to Cercate
Management for detailed informaon.
If the funcon is abnormal, check if the selected cercate is abnormal in Cercate
Management.
5.
Click Save.
Create and Install Self-signed Cercate
Steps
1.
Check Create Self-signed Cercate.
2.
Click Create.
3.
Follow the prompt to enter Country, Hostname/IP, Validity and other parameters.
4.
Click OK.
Result
The device will install the self-signed cercate by default.
Install Authorized Cercate
If the demand for external access security is high, you can create and install authorized cercate
via HTTPS protocol to ensure the data transmission security.
Steps
1.
Select Create cercate request rst and connue the installaon.
2.
Click Create.
3.
Follow the prompt to input Country, Hostname/IP, Validity and other parameters.
4.
Click Download to download the cercate request and submit it to the trusted authority for
signature.
5.
Import cercate to the device.
-
Select Signed cercate is available, start the installaon directly. Click Browse and Install to
import the cercate to the device.
-
Select Create the cercate request rst and connue the installaon. Click Browse and
Install to import the cercate to the device.
6.
Click Save.
Smart Linkage PTZ Camera User Manual
103
background
11.11.4 Set QoS
QoS (Quality of Service) can help improve the network delay and network congeson by seng
the priority of data sending.
Note
QoS needs support from network device such as router and switch.
Steps
1.
Go to Conguraon → Network → Advanced Conguraon → QoS .
2.
Set Video/Audio DSCP, Alarm DSCP and Management DSCP.
Note
Network can idenfy the priority of data transmission. The bigger the DSCP value is, the higher
the priority is. You need to set the same value in router while conguraon.
3.
Click Save.
11.11.5 Set IEEE 802.1X
You can authencate user permission of the connected device by seng IEEE 802.1X.
Go to Conguraon → Network → Advanced Sengs → 802.1X , and enable the funcon.
Select protocol and version according to router informaon. User name and password of server are
required.
Note
If you set the Protocol to EAP-TLS, select the Client Cercate and CA Cercate.
If the funcon is abnormal, check if the selected cercate is abnormal in Cercate
Management.
11.11.6 Security Audit Log
The security audit logs refer to the security operaon logs. You can search and analyze the security
log les of the device so as to nd out the illegal intrusion and troubleshoot the security events.
Security audit logs can be saved on device internal storage. The log will be saved every half hour
aer device boong. Due to limited storage space, you can also save the logs on a log server.
Search Security Audit Logs
You can search and analyze the security log les of the device so as to nd out the illegal intrusion
and troubleshoot the security events.
Smart Linkage PTZ Camera User Manual
104
background
Steps
Note
This funcon is only supported by certain camera models.
1.
Go to Conguraon → System → Maintenance → Security Audit Log .
2.
Select log types, Start Time, and End Time.
3.
Click Search.
The log les that match the search condions will be displayed on the Log List.
4.
Oponal: Click Export to save the log les to your computer.
Set Log Server
The log server should support syslog (RFC 3164) over TLS.
Before You Start
Install client and CA cercates before conguraon. Refer to Cercate Management for
detailed informaon.
Select cercates according to the requirement of the log server. If two-way authencaon is
required, select the CA cercate and the client cercate. If one-way authencaon is
required, select the CA cercate only.
Steps
1.
Check Enable Log Upload Server.
2.
Oponal: Check Enable Encrypted Transmission if you want the log data to be encrypted.
3.
Input Log Server IP and Log Server Port.
4.
Oponal: Select client cercate.
5.
Select CA cercate to the device.
6.
Click Test to test the sengs.
7.
Click Save.
11.11.7 SSH
Secure Shell (SSH) is a cryptographic network protocol for operang network services over an
unsecured network.
The SSH funcon is disabled by default.
Cauon
Use the funcon with cauon. The security risk of device internal informaon leakage exists when
the funcon is enabled.
Smart Linkage PTZ Camera User Manual
105
background
11.11.8 Control Timeout Sengs
If this funcon is enabled, you will be logged out when you make no operaon (not including
viewing live image) to the device via web browser within the set meout period.
Go to Conguraon → System → Security → Advanced Security to complete sengs.
11.11.9 Cercate Management
It manages the server/client cercates and CA cercate of the device.
Server Cercate/Client Cercate
Note
The device has default self-signed server/client cercate installed. The cercate ID is default.
Create and Install Self-signed Cercate
Steps
1.
Go to Conguraon → System → Security Cercate Management .
2.
Click Create Self-signed Cercate.
3.
Input cercate informaon.
Note
The input cercate ID cannot be the same as the exisng ones.
4.
Click OK to save and install the cercate.
The created cercate is displayed in the Server/Client Cercate list.
If the cercate is used by certain funcons, the funcon name is shown in the column
Funcons.
5.
Oponal: Click Cercate Property to see the cercate details.
Install Self-signed Request Cercate
You can send the self-signed cercate to a trusted third-party for the signature, and install the
cercate to the device.
Before You Start
Create a self-signed cercate rst. See
Create and Install Self-signed Cercate for instrucons.
Steps
1.
Go to Conguraon → System → Security Cercate Management .
Smart Linkage PTZ Camera User Manual
106
background
2.
Select a self-signed cercate from the Server/Client Cercate list.
3.
Click Create Cercate Request.
4.
Input request informaon.
5.
Click OK.
The cercate request details are displayed in a pop-up window.
6.
Copy the request content and save it as a request le.
7.
Send the le to a trusted-third party for signature.
8.
Aer receiving the cercated sent back from the third-party, install it to the device.
1) Click Import.
2) Input Cercate ID.
Note
The input cercate ID cannot be the same as the existed ones.
3) Click Browse to select the cercate le.
4) Select Self-signed Request Cercate.
5) Click OK.
The imported cercate is displayed in the Server/Client Cercate list.
If the cercate is used by certain funcon, the funcon name is shown in the column
Funcons.
9.
Oponal: Click Cercate Property see the cercate details.
Install Other Authorized Cercate
If you already has an authorized cercate (not created by the device), you can import it to the
device directly.
Steps
1.
Go to Conguraon → System → Security Cercate Management .
2.
Click Import.
3.
Input Cercate ID.
Note
The input cercate ID cannot be the same as the existed ones.
4.
Click Browse to select the cercate le.
5.
Select Cercate and Key and select a Key Type according to your cercate.
Independent Key If your cercate has a independent key, select this opon.
Browse to select the private key and input the private-key password.
PKCS#12 If your cercate has the key in the same cercate le, select this opon
and input the password.
6.
Click OK.
The imported cercate is displayed in the Server/Client Cercate list.
Smart Linkage PTZ Camera User Manual
107
background
If the cercate is used by certain funcon, the funcon name is shown in the column
Funcons.
Install CA Cercate
Before You Start
Prepare a CA cercate in advance.
Steps
1.
Go to Conguraon → System → Security Cercate Management .
2.
Input Cercate ID.
Note
The input cercate ID cannot be the same as the exisng ones.
3.
Click Browse to select the cercate le.
4.
Click OK.
The imported cercate is displayed in the CA Cercate list.
If the cercate is used by certain funcons, the funcon name is shown in the Funcons
column.
11.11.10 User and Account
Set User Account and Permission
The administrator can add, modify, or delete other accounts, and grant dierent permission to
dierent user levels.
Cauon
To increase security of using the device on the network, please change the password of your
account regularly. Changing the password every 3 months is recommended. If the device is used in
high-risk environment, it is recommended that the password should be changed every month or
week.
Steps
1.
Go to Conguraon → System → User Management → User Management .
2.
Click Add. Enter User Name, select Level, and enter Password. Assign remote permission to
users based on needs.
Administrator
The administrator has the authority to all operaons and can add users and operators and
assign permission.
Smart Linkage PTZ Camera User Manual
108
background
User
Users can be assigned permission of viewing live video, seng PTZ parameters, and changing
their own passwords, but no permission for other operaons.
Operator
Operators can be assigned all permission except for operaons on the administrator and
creang accounts.
Modify Select a user and click Modify to change the password and permission.
Delete Select a user and click Delete.
Note
The administrator can add up to 31 user accounts.
3.
Click OK.
Online Users
The informaon of users logging into the device is shown.
Go to Conguraon → System → User Management → Online Users to view the list of online
users.
Simultaneous Login
The administrator can set the maximum number of users logging into the system through web
browser simultaneously.
Go to Conguraon → System → User Management , click General and set Simultaneous Login.
Smart Linkage PTZ Camera User Manual
109
background
Appendix A. Device Command
Scan the following QR code to get device common serial port commands.
Note that the command list contains the commonly used serial port commands for all Hikvision
network cameras.
Smart Linkage PTZ Camera User Manual
110
background
Appendix B. Device Communicaon Matrix
Scan the following QR code to get device communicaon matrix.
Note that the matrix contains all communicaon ports of Hikvision network cameras.
Smart Linkage PTZ Camera User Manual
111
background
UD20021B-C

Specifications

Hikvision IDS-2SK8144IXS-D/J Questions and Answers
