30" ADDISON VANITY
E444-V30-GW
Features and Materials
Solids: Yellow Poplar
Panels: MDF
Installation Type: Floor Standing
Number of Basins: One, with Optional 3cm Top
Vanity Top Included: NO, Optional 3cm Tops Available with Sinks
Overflow: Yes, Front Facing
Number of Doors: One
Number of Drawers: Three
Number of Tip Outs: One
USB/Power Component:
YES (ETL501108
0)
Cord Length: 6'6"
Assembly Type: Yes, with Optional 3cm Top
Bamboo Storage Tray: YES
Door Panel: Reversible. One Side Finished in Glossy White, One Side Natural Cork
(Pattern: Casablanca)
Drawer Box Material and Construction: 15mm Poplar/English Dovetail Joinery
Hardware Material and Finish: Zinc Alloy in Polished Chrome
Fits Drain Hole Size: 1 3/4"
Full Extension, Soft Close Glides
European Soft Close Hinges
Aluminum Laminate Drawer Liners
Adjustable Levelers
Width: 29-7/8"
Depth: 23-3/8"
Height: 34-1/2"
Rough-In Height: 21-1/2"
Dimension
Version: 202404
Visit website for warranty and installation information
www.jamesmartinvanities.com
1/31/3
30" ADDISON VANITY
E444-V30-GW
Version: 202404
Diagrams are of cabinet only–James Martin Optional Countertops and sinks are not shown
Visit website for warranty and installation information
www.jamesmartinvanities.com
Front View
Top View 1
2 1/2" [63mm]
9 7/8"
[251mm]
18 1/4"
[464mm]
13 1/8" [333mm]
4 3/4" [120mm]
5"
[127mm]
9 1/2" [240mm]
29 7/8" [758mm]
22 1/4"
[566mm]
3 7/8" [100mm]
12 5/8" [321mm] 12 5/8" [322mm]
4 7/8"
[123mm]
5 7/8"
[149mm]
9 1/2"
[240mm]
Top View 2
12" [305mm]
8 5/8" [218mm] 3 1/8" [80mm]
Knob
Bamboo Drawer Organizer
27 1/8" [688mm]
17 7/8" [453mm]
3 1/8" [78mm]
7/8" [21mm]
1"
[24mm]
2 1/2" [63mm]
1" [25mm]
1"
[25mm]
1" [24mm]
3/4"
[19mm]
3/4" [19mm]
All dimensions are nominal
Top view of electrical unit
16 3/8" [415mm]
14 7/8"
[376mm]
19 1/4"
[489mm]
2/32/3
11 3/8"
[288mm]
34 1/2"
[876mm]
28 1/8"
[714mm]
30" ADDISON VANITY
E444-V30-GW
E444-V30-GW
Back View
Version: 202404
Side View 1 Side View 2
34 1/2" [876mm]
23 3/8" [595mm]
3" [77mm]
2 1/8" [55mm]
7 7/8" [200mm]
21 1/2"
[546mm]
32 1/2" [826mm]
3 7/8"
[100mm]
13 7/8" [352mm]
4 1/2" [113mm]
24 3/8" [620mm]
Diagrams are of cabinet only–James Martin Optional Countertops and sinks are not shown
Visit website for warranty and installation information
www.jamesmartinvanities.com
18 1/4" [464mm]
Suggested
rough-in
height 21.5
H x 5-1/8 W
24 3/8" [619mm]
All dimensions are nominal
16 1/2" [419mm]
Side view of electrical unit
Grommet opening
for power cord
17 3/8"
[442mm]
3/33/3
5 3/8" [137mm]
24 1/2" [621mm]
