USER GUIDE
.7 Cu. Ft. Compact
Microwave
NS-MW7BK5/NS-MW7WH5/NS-MW7BK5-C/NS-MW7WH5-C
Before using your new product, please read these instructions to prevent any damage.
www.insigniaproducts.com
2
2
www.insigniaproducts.com
Contents
SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
GROUNDING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
RADIO INTERFERENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Cookware and cooking materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Materials you can use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Materials to be avoided . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Unpacking your microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Microwave. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Setting up your microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Installing the turntable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Setting the clock and the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using the kitchen timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Cooking with your microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Microwave cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Cooking quickly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Cooking with the auto menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Using a memorized procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Multi-stage cooking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Muting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Using ECO mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Defrosting in your microwave. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Defrosting by time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Defrosting by weight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Changing other microwave settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Using the child lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Checking the time or power level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Cleaning and maintaining your microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Cleaning the outside of your microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Cleaning the inside of your microwave. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
ONE-YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
3
.7 Cu. Ft. Compact Microwave
www.insigniaproducts.com
SAFETY INFORMATION
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY:
1 Do not attempt to operate this oven with the door open because this can
result in harmful exposure to microwave energy. It is important not to defeat
or tamper with the safety interlocks.
2 Do not place any object between the oven front face and the door or allow soil
or cleaner residue to accumulate on sealing surfaces.
3 Do not operate the oven if it is damaged. It is particularly important that the
oven door closes properly and that there is no damage to the:
(a) DOOR (bent)
(b) HINGES and LATCHES (broken or loosened)
(c) DOOR SEALS and SEALING SURFACES
4 The oven should not be adjusted or repaired by anyone except properly
qualified service personnel.
IMPORTANT SAFETY
INSTRUCTIONS
1 Read all instructions before using the oven.
2 Read and follow the specific: PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY: found on page 3.
3 As with any cooking appliances, close supervision is necessary to reduce the
risk of a fire in the oven cavity or when used by children.
4 To reduce the risk of fire in the oven cavity:
• Do not overcook food. Carefully attend the oven when paper, plastic, or
other combustible materials are placed inside the oven to facilitate cooking.
• Remove wire twist-ties and metal handles from paper or plastic
containers/bags before placing them in the oven.
• If materials inside the oven ignite, keep the oven door closed. Turn the oven
off and unplug the oven or shut off power at the fuse or circuit breaker
panel.
• Do not use the oven cavity for storage purposes. Do not leave paper
products, cooking utensils, or food in the cavity when not in use.
5 This oven must be grounded. Connect only to a properly grounded outlet. See
GROUNDING INSTRUCTIONS found on page 5.
WARNING: To reduce the risk of burns, electric shock, fire, injury to persons, or
exposure to excessive microwave oven energy when using your oven, follow
these basic safety precautions.
4
www.insigniaproducts.com
6 Install or locate this appliance only in accordance with the provided
installation instructions.
7 Some products, such as whole eggs and sealed containers (for example closed
glass jars), are able to explode and should not be heated in this oven.
8 Use this oven only for its intended purpose, as described in this manual. Do
not use corrosive chemicals or vapors in this oven. This oven is specifically
designed to heat, cook, or dry food. It is not designed for industrial or
laboratory use.
9 HOT CONTENTS CAN CAUSE SEVERE BURNS. DO NOT ALLOW CHILDREN TO
USE THE MICROWAVE. Use caution when removing hot items. Do not operate
this oven if it has a damaged cord or plug, if it is not working properly, or if it
has been damaged or dropped.
10 This oven should be serviced only by qualified service technicians. Contact the
nearest authorized service facility for examination, repair, or adjustment.
11 Do not cover or block any openings on the oven.
12 Do not store or use this oven outdoors.
13 Do not use this oven near water (for example, near a kitchen sink, in a wet
basement, near a swimming pool, or similar locations).
14 Do not immerse the cord or plug in water.
15 Keep the cord away from heated surfaces.
16 Do not let the cord hang over the edge of a table or counter.
17 When cleaning the surfaces of the door and the oven that come together on
closing the door, use only mild, nonabrasive soaps or detergents applied with
a sponge or soft cloth.
18 Liquids, such as water, coffee, or tea can be overheated beyond the boiling
point without appearing to be boiling. Visible bubbling or boiling when the
container is removed from the microwave oven is not always present. THIS
COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO
THE LIQUID.
• Do not overheat the liquid.
• Stir the liquid both before and halfway through heating it.
• Do not use straight-sided containers with narrow necks.
• After heating, allow the container to stand in the microwave oven for a short
time before removing the container.
• Use extreme care when inserting a spoon or other utensil into the container.
SAVE THESE INSTRUCTIONS
WARNING: Handling the power cord on this oven, or cords associated with
accessories sold with this oven, will expose you to lead, a chemical known to the
state of California to cause cancer and birth defects or other reproductive harm.
Wash your hands after handling.
5
.7 Cu. Ft. Compact Microwave
www.insigniaproducts.com
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short
circuit, grounding reduces the risk of electric shock by providing an
escape wire for the electric current. This appliance is equipped with a cord
having a grounding wire with a grounding plug. The plug must be
plugged into an outlet that is properly installed and grounded.
1 A short power supply cord is provided to reduce the risks resulting
from becoming entangled in or tripping over a longer cord.
2 Longer cord sets or extension cords are available and may be used if
care is exercised in their use.
3 If a long cord or extension cord is used:
• The marked electrical rating of the cord set or extension cord
should be at least as great as the electrical rating of the appliance.
• The extension cord must be a grounding-type 3-wire cord.
• The longer cord should be arranged so that it will not drape over
the counter top or tabletop where it can be pulled on by children or
tripped over unintentionally.
RADIO INTERFERENCE
1 Operation of the microwave oven may cause interference to your radio, TV, or
similar equipment.
2 When there is interference, it may be reduced or eliminated by taking the
following measures:
• Clean the door and the sealing surface of the oven.
• Reorient the receiving antenna of the radio or television.
• Relocate the microwave oven with respect to the receiver.
• Move the oven away from the receiver.
• Plug the oven into a different outlet so that the oven and receiver are on
different branch circuits.
• This device complies with part 18 of the FCC Rules.
DANGER - Electric Shock Hazard
Touching some of the internal components can cause serious
personal injury. Do not disassemble this appliance.
WARNING - Electric Shock Hazard
Improper use of the grounding plug can result in electric shock. Do
not plug into an outlet until the appliance is properly installed and
grounded.
Consult a qualified electrician or serviceman if the grounding
instructions are not completely understood, or if doubt exists as to
whether the appliance is properly grounded.
6
www.insigniaproducts.com
Cookware and cooking materials
Cookware and other materials must fit on the turntable. Always use oven mitts or
pot holders because cookware may become hot.
Refer to the Materials you can use
on page 6 and Materials to be avoided on
page 7 tables as a guide, then test before using.
There may be certain non-metallic utensils that are not safe to use for
microwaving. If in doubt, you can test the utensil in question following the
procedure below.
Utensils test
1 Fill a microwave-safe container with 1 cup (250 ml) of cold water, along with
the utensil in question.
2 Cook on maximum power for one minute. Do not exceed one minute
cooking time.
3 Carefully feel the utensil. If the empty utensil is warm, do not use it for
microwave cooking.
4 To prevent the risk of fire, do not put hot pads, blankets, clothes, or other
textiles in oven.
Materials you can use
WARNING: Personal Injury Hazard
Tightly-closed containers could explode. Closed containers should be opened
and plastic pouches should be pierced before cooking.
MATERIAL REMARKS
Browning dish Follow the manufacturer’s instructions. The bottom of the
browning dish must be at least 3/16-in. (5 mm) above the
turntable. Incorrect usage may cause the turntable to break.
Dinnerware Use microwave-safe only. Follow the manufacturer's instructions.
Do not use cracked or chipped dishes.
Glass jars Always remove the lid. Use only to heat food until just warm. Most
glass jars are not heat resistant and may break.
Glassware Use heat-resistant oven glassware only. Make sure that there is no
metallic trim. Do not use cracked or chipped dishes.
Oven cooking
bags
Follow the manufacturer’s instructions. Do not close with a metal
tie. Make slits to let steam escape.
Paper plates and
cups
Use for short–term cooking/warming only. Do not leave your
microwave unattended while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with
supervision for short-term cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic Use only if labeled “Microwave Safe.” Follow the manufacturer’s
instructions. Some plastic containers soften as the food inside
gets hot. “Boiling bags” and tightly closed plastic bags should be
slit, pierced, or vented, as indicated on the package.
7
.7 Cu. Ft. Compact Microwave
www.insigniaproducts.com
Materials to be avoided
Package contents
• .7 Cu. Ft. Microwave Oven
• Glass tray
• Turntable ring assembly
• User Guide
Unpacking your microwave
Remove your microwave oven and all materials from the box and oven cavity. Your
microwave oven comes with the following accessories:
Plastic wrap Use microwave-safe only. Use to cover food during cooking to
retain moisture. Do not let plastic wrap touch food.
Thermometers Use microwave-safe only (such as meat and candy
thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
MATERIAL REMARKS
Aluminum foil May cause an electric spark. Transfer food into microwave-safe dish.
Aluminum tray May cause an electric spark. Transfer food into microwave-safe dish.
Food carton with
metal handle
May cause an electric spark. Use a microwave-safe dish instead.
Metal or metal
trimmed utensils
Metal shields the food from microwave energy. The metal trim may
cause arcing.
Metal twist ties May cause an electric spark and could cause a fire in your
microwave.
Paper bags May cause a fire in your microwave.
Plastic foam Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
Textiles Hot pads, blankets, clothes, or other fabric items maycause burns or
a fire.
Wood Wood will dry out when used in your microwave and may split or
crack.
MATERIAL REMARKS
Glass tray
Turntable ring assembly
Turntable shaft
User Guide
8
www.insigniaproducts.com
Features
• .7 cu ft compact design fits on your countertop or kitchen cart
• 700W with 11 power levels cook or reheat meat, vegetables, pasta and more
• 9 preset functions, including popcorn, potato, pizza, frozen veg, beverage,
dinner plate, express cook, add 30s, and defrost
• 10-inch (25.4 cm) glass turntable helps distribute heat evenly
• Internal light lets you keep an eye on your meal’s progress
• Black or white finish matches your existing kitchen décor
Microwave
Opening the door for the first time
1 Press upward on the button on the inside top of the door handle.
2 Pull the door outward to swing open from right to left.
# ITEM DESCRIPTION
1 Safety interlock system Prevents your microwave from operating when the door
is open.
2 Door release button Press upward to release the door, then pull the handle to
open.
3 Oven window Lets you see food while it is cooking.
4 Door handle Pull to open the door after pressing the door release
button.
5 Door assembly Includes the door frame, oven window, and handle.
6 Oven cavity Where the food is placed for cooking.
7 Turntable shaft Rotates the turntable assembly.
8 Control panel Provides controls to set cooking times and enter other
information as needed.
9
.7 Cu. Ft. Compact Microwave
www.insigniaproducts.com
Control panel
# ITEM DESCRIPTION
1 Display In standby mode, shows the time.
In cooking mode, shows cooking time, weight, and other information.
2 Time Cook Press to set the amount of time you want to heat your food, then press
the number buttons to enter the time you want (up to 99 minutes and
99 seconds).
3 Power Press to set the power level of your microwave, then press the number
buttons to set the level you want (0-10).
4 Auto menu Press one of these buttons to automatically cook the item indicated.
See Cooking with the auto menus
on page 13.
5Express
cook
In standby mode, press to quickly start cooking for 1 to 6 minutes. See
Cooking quickly
on page 13.
6Number
pad
Press to enter cook time, defrost time, clock time, and other
information.
7 Stop/
Cancel
Press to stop the cooking process. Press again to cancel the cooking
operation.
10
www.insigniaproducts.com
Setting up your microwave
1 Remove all packing material, protective film, and accessories. Do not remove the cream-colored plastic
cover that is attached to the interior wall to protect the magnetron.
2 Check for any damage such as dents or a broken door. Do not use your microwave if it is damaged.
3 Select a level surface that provides enough open space for the vents.
4 Plug your microwave into a power outlet.
8 Time
Defrost
Press, then enter the time you want for an item to defrost. See
Defrosting by time
on page 16.
Weight
Defrost
Press, then enter the weight of the item you want to defrost. The
cooking time is set automatically. See Defrosting by weight
on
page 16.
9 Clock Press to set or check the clock. See Setting the clock
on page 12.
10 Kitchen
Timer
Press this button, then enter the time you want to count down. See
Using the kitchen timer
on page 12.
11 Start/ +30
Sec.
In standby mode, press this button to begin cooking.
While cooking, press this button to add 30 seconds to cooking time.
12 0/Memory Press repeatedly to choose a memorized procedure.
CAUTIONS:
• Do not install your microwave over a range cooktop or other heat-producing
appliance. Installing over a heat source can damage your microwave and void
your warranty.
• One side of your microwave oven must be unrestricted (open).
• Do not remove the feet from your microwave oven.
• Do not block intake or outlet openings.
• Place your microwave oven as far away from radios and TVs as possible, as it
may cause interference.
• The accessible surface may be hot during operation.
# ITEM DESCRIPTION
12 in. (30.5 cm)
3 in. (7.5 cm)
3 in. (7.5 cm)
One side open
Minimum height = 3 ft.
(91.4 cm)
11
.7 Cu. Ft. Compact Microwave
www.insigniaproducts.com
Installing the turntable
1 Remove all packing materials from your microwave oven, then remove the shipping tape from the
turntable shaft.
2 Clean the cooking compartment and the accessories.
3 Place the turntable ring assembly into the round depression in the bottom of your microwave so that it
turns freely.
4 Place the glass turntable (flat side up) on the turntable ring so that the hub engages the turntable shaft in
the bottom of your microwave. The glass turntable should not turn freely when it is correctly installed.
Note: The turntable is shipped inside your microwave’s oven cavity.
Notes:
• Never use your microwave oven without the glass turntable and turntable
ring.
• Never place the glass tray into your microwave oven upside down. The glass
tray should never be restricted.
• Always place all food and containers of food on the glass tray for cooking.
• Do not restrict the movement of the turntable.
• If the glass tray or turntable ring cracks or breaks, contact your nearest
authorized service center.
Turntable ring assembly
Glass turntable
Turntable shaft
12
www.insigniaproducts.com
Setting the clock and the timer
Setting the clock
1 In standby mode, press Clock. “12:00” will appear on the display.
2 Use the number pad to enter the current time.
For example, if you want to set the clock time to 12:30, press the number
buttons 1, 2, 3, and 0, then press Clock to save the setting.
Using the kitchen timer
1 In standby mode, press Kitchen Timer. The display shows “00:00.”
2 Use the number pad to enter the time (up to 99 minutes and 99 seconds), then
press Start/+30sec.. The timer begins counting down. When the time reaches
0 (zero), the current time will be displayed.
Cooking with your microwave
Microwave cooking
1 Press Time Cook, “00:00” appears on the display.
2 Press the number pad keys to enter the cooking time that you want (to a
maximum of 99 minutes and 99 seconds).
3 Press Power, then enter the power level that you want (0-10). The default
power level is 100% (PL10).
Notes:
• While setting the clock, if you press Stop/Cancel or if you don’t press a button
within 30 seconds, your microwave goes back to its last setting.
• The clock is pre-configured for 12-hour display. If the clock is not set, it will not
work when turned on.
• Repeat steps 1 and 2 if you need to reset the clock.
Notes:
• To check the amount of time left on the timer, press Kitchen Timer.
• To cancel the timer, press Stop/Cancel.
Notes:
• In standby mode, if you set the clock the display shows the current time. If you
don’t set the clock, the display shows “:”.
• To turn off the beep, press and hold the number 8 for three seconds. To turn it
back on, press the number 8 again for three seconds.
• To turn off the display, press the Stop/Cancel button. To turn it back on, press
any button or open the door.
Note: For example, to enter 3 minutes and 15 seconds, press 3, 1, and then 5.
LEVEL109876543210
Power 100% 90% 80% 70% 60% 50% 40% 30% 20% 10% 0%
Display PL10 PL9 PL8 PL7 PL6 PL5 PL4 PL3 PL2 PL1 PL0
13
.7 Cu. Ft. Compact Microwave
www.insigniaproducts.com
4 If you want to set a second cook setting (multi-stage cooking), repeat steps 1
and 2.
5 Press Start/+30sec. to begin cooking. Your microwave beeps when it is
finished.
Cooking quickly
1 In standby mode, press Start/+30sec. to instantly cook something at 100%
power for 30 seconds.
OR
Press a number between 1 and 6 on the number pad to instantly cook
something at 100% power for 1 to 6 minutes.
2 To increase the time in 30 second increments, press Start/+30sec. repeatedly.
The maximum cooking time is 99 minutes and 99 seconds.
Cooking with the auto menus
Your microwave has six auto menus for commonly cooked items. You do not have
to set the cook time when you use an auto menu.
Notes:
•Press Power at any time to change the power setting. Enter the number of the
new power setting you want, then press Start/+30sec. to confirm. Your
microwave cooks at the new power setting for the remainder of the cook time.
You cannot change the power setting for auto-menu items.
• While making your settings, if the Stop/Cancel button is pressed, or if there is
no input within 30 seconds, your microwave oven goes back to the former
setting.
•If “PL0” is selected, only your microwave oven fan comes on. You can use this
to eliminate odors from your oven.
Notes:
• Multi-stage cooking lets you program two cook times and power levels at the
same time.
• Your microwave beeps between stages and automatically moves to the
second stage.
• You can set time defrost or weight defrost for the first or second stage. Your
microwave always defrosts first.
• You cannot use multi-stage cooking with the auto menu programs.
Notes:
• While cooking, if you press Stop/Cancel once, your microwave pauses the
cooking program. Press Start/+30sec. to resume.
• While cooking, if you press Stop/Cancel twice, your microwave stops cooking
and cancels the cooking program.
Note: You cannot increase cook time when using Weight Defrost, or auto-menu
items.
14
www.insigniaproducts.com
Popcorn
1 Press Popcorn repeatedly until the display shows the weight of your popcorn
bag (3.0 or 3.5, or 1.75 ounces).
2 Press Start/+30sec. to start. Your microwave beeps once, then cooks your
popcorn. When cooking is complete, there will be a beep and "End" will
appear on the display. If the door is not opened or the Stop/Cancel button is
not pressed within 9 minutes, your oven will sound two beeps every 3
minutes. After 9 minutes, your microwave oven will return to standby mode.
Potato
1 Press Potato repeatedly until the display shows the number of potatoes you’re
cooking (1-3).
2 Press Start/+30sec. to start. Your microwave beeps once, then cooks your
potato. When cooking is complete, there will be a beep and "End" will appear
on the display. If the door is not opened or the Stop/Cancel button is not
pressed within 9 minutes, your oven will sound two beeps every 3 minutes.
After 9 minutes, your microwave oven will return to standby mode.
Pizza
1 Press Pizza repeatedly until the display shows the approximate weight of your
pizza (4.0, 8.0, or 14.0 ounces).
2 Press Start/+30sec. to start. Your microwave beeps once, then heats your
pizza. When cooking is complete, there will be a beep and "End" will appear
on the display. If the door is not opened or the Stop/Cancel button is not
pressed within 9 minutes, your oven will sound two beeps every 3 minutes.
After 9 minutes, your microwave oven will return to standby mode.
Frozen vegetables
1 Press Frozen Vegetable repeatedly until the display shows the number
weight of your vegetables (4.0, 8.0, or 16.0 ounces).
2 Press Start/+30sec. to start. Your microwave beeps once, then cooks your
vegetables. When cooking is complete, there will be a beep and "End" will
appear on the display. If the door is not opened or the Stop/Cancel button is
not pressed within 9 minutes, your oven will sound two beeps every 3
minutes. After 9 minutes, your microwave oven will return to standby mode.
Beverages
1 Press Beverage repeatedly until the display shows the number of 4 ounce
cups (1-3).
Note: Each potato is assumed to be 8 oz. (227 g) If your potato is large, select the
amount based on the potato’s weight.
AMOUNT WEIGHT (APPROX.)
1 potato 8 oz. (227 g)
2 potatoes 16 oz. (453 g)
3 potatoes 24 oz. (680 g)
15
.7 Cu. Ft. Compact Microwave
www.insigniaproducts.com
2 Press Start/+30sec. to start. Your microwave beeps once, then heats your
drink. When cooking is complete, there will be a beep and "End" will appear
on the display. If the door is not opened or the Stop/Cancel button is not
pressed within 9 minutes, your oven will sound two beeps every 3 minutes.
After 9 minutes, your microwave oven will return to standby mode.
Dinner plate
1 Press Dinner Plate repeatedly until the display shows the approximate weight
of your food (9.0, 12.0, or 18.0 ounces).
2 Press Start/+30sec. to start. Your microwave beeps once, then heats your
food. When cooking is complete, there will be a beep and "End" will appear on
the display. If the door is not opened or the Stop/Cancel button is not pressed
within 9 minutes, your oven will sound two beeps every 3 minutes. After 9
minutes, your microwave oven will return to standby mode.
Using a memorized procedure
Memorized procedures let you save heating operations (cook time and power
level) that you use often. You must save a memorized procedure before using this
feature. You can save three procedures. One of these procedures can be a
multi-stage procedure.
1 Press 0/Memory repeatedly to choose a memorized number (1 through 3)
that you want to assign to the procedure.
2 Press Time Cook, then use the number pad to enter the cook time you want.
3 Press Power, then enter the power level that you want (0 through 10). The
default power level is 100% (PL10).
4 (Optional) If you want to add a second stage, repeat steps 2 and 3. You can
only add two stages to a memorized procedure.
5 Press Start/+30sec.. Your microwave beeps and the display shows the
memorized procedure number.
6 Press Start/+30sec. again to run the procedure.
Multi-stage cooking
You can set up two stages of cooking (maximum). For example, you can set up one
stage for defrosting and one stage for cooking.
In this example, using the following steps, we set up a defrost time of five minutes
at 80% power and 10 minutes of cooking at 60% power;
1 Press Time Defrost once, then press "5", "0", "0" to set the cooking time.
2 Press Power once, then press 8 to select 80% power.
Note: For example, to enter 3 minutes and 15 seconds, press 3, 1, and then 5.
LEVEL109876543210
Power 100% 90% 80% 70% 60% 50% 40% 30% 20% 10% 0%
Display PL10 PL9 PL8 PL7 PL6 PL5 PL4 PL3 PL2 PL1 PL0
Notes:
• If your microwave loses power, it forgets your memorized procedures.
• Auto menu functions cannot be set as memorized procedures.
16
www.insigniaproducts.com
3 Press Time Cook again, then press 1, 0, 0, 0 to set the cooking time.
4 Press Power again, then press 6 to select 60% power.
5 Press Start/+30sec. to start cooking. When cooking is complete, there will be
a beep and "End" will appear on the display. If the door is not opened or the
Stop/Cancel button is not pressed within 9 minutes, your oven will sound two
beeps every 3 minutes. After 9 minutes, your microwave oven will return to
standby mode.
Muting the sound
You can mute the beep sounds made by your microwave oven.
1 In standby mode, press and hold the 8 button for three seconds. A beep will
sound and the mute mode is activated.
2 To deactivate the mute mode, press and hold the 8 button for three seconds. A
beep will sound and the mute mode is canceled.
Using ECO mode
You can use ECO mode to save power by turning off the display.
1 In standby mode with the door closed, press Stop/Cancel once to turn off the
display.
2 To cancel ECO mode, press any key or open and close the door.
Defrosting in your microwave
You can use your microwave to defrost frozen food by entering a defrost time or
the weight of the food.
Defrosting by time
1 Press Time Defrost. The display shows “dEF2”.
2 Use the number pad to enter the defrosting time you want. The time range
must be between 00:01 and 99:99. The maximum defrost time is 99 minutes
and 99 seconds.
3 The default power setting is PL3 (power level 3). If you want to change the
power level, press Power once. When the display shows “PL3”, press the
number pad of the power level you want.
4 Press Start/+30sec. to start defrosting. The display shows the remaining
defrosting time.
Defrosting by weight
When you enter the weight of the item, your microwave automatically adjusts the
time and defrosting power.
1 Press Weight Defrost. The display shows “dEF1”.
2 Use the number pad to enter the weight of the item to be defrosted (in
ounces). The input weight must be between 4 and 100 ounces.
3 Press Start/+30sec. to start defrosting. The display shows the remaining
defrosting time.
Note: Your microwave beeps and displays “turn” during the defrost operation to
remind you to turn the food over. If you do not open your microwave to turn the
food, the defrost operation continues.
17
.7 Cu. Ft. Compact Microwave
www.insigniaproducts.com
Changing other microwave settings
Using the child lock
• To lock your microwave, press and hold Stop/Cancel for three seconds while
in standby mode. Your microwave beeps and the display shows .
• To unlock your microwave, press and hold Stop/Cancel for three seconds until
your microwave beeps. Your microwave unlocks and returns to standby mode.
Checking the time or power level
• To check the time while cooking a meal, press Clock. The display shows the
current time for three seconds, then returns to the cooking time remaining.
• To check the power level while using a microwave cooking program, press
Power. The display shows the power level being used for three seconds, then
returns to the cooking time remaining.
Cleaning and maintaining your microwave
Cleaning the outside of your microwave
Exterior
Clean the outside with a damp cloth. If needed you can use mild soap and water,
then rinse and dry with a soft cloth. Do not use any type of household or abrasive
cleaner. To prevent damage to the operating parts inside your microwave, make
sure that water does not get into the ventilation openings.
Door
Wipe the window and door on both sides, the door seals, and adjacent parts with
a damp cloth to remove any spills or spatters. Metal parts are easier to maintain if
wiped frequently with a damp cloth. Avoid the use of spray and other harsh
cleaners as they may stain, streak, or dull the door surface.
Control panel
If the control panel is dirty, open the microwave door before cleaning to prevent
your microwave from turning on. Wipe the panel with a cloth dampened slightly
with water only. Dry with a soft cloth. Do not scrub or use any sort of chemical
cleaners. Close the door and press Stop/Cancel to clear any buttons you may have
pressed.
Cleaning the inside of your microwave
Interior
Wipe with a soft cloth and warm water. Do not use abrasive or harsh cleaners or
scouring pads. For baked-on food, use baking soda or a mild soap, then rinse
thoroughly with hot water.
Note: The display does not show the time while your microwave is locked.
Note: Press Power at any time to change the power setting. Enter the number
of the new power setting you want. Your microwave cooks at the new power
setting for the remainder of the cook time. You cannot change the power
setting for time defrost, weight defrost, or auto-menu items.
18
www.insigniaproducts.com
Waveguide cover
The waveguide cover is located on the side wall inside the microwave cavity. It is
made from mica so requires special care. Keep the waveguide cover clean to
assure good microwave performance. Carefully wipe with a damp cloth any food
spatters from the surface of the cover immediately after they occur. Built-up
splashes may overheat and cause smoke or possibly catch fire. DO NOT REMOVE
THE WAVEGUIDE COVER.
Removing odors
Occasionally, a cooking odor may remain in your microwave. To remove, combine
one cup (.25 L) water, grated peel and juice of one lemon, and several whole
cloves in a two-cup (.5 L) glass measuring cup. Boil for several minutes using 100%
power, then let it cool in your microwave. Wipe the interior with a soft cloth.
Turntable
Remove the turntable and wash it in mild, sudsy water. For stubborn stains, use a
mild cleanser and non-abrasive scouring sponge. You can also wash it in the top
rack of a dishwasher.
The turntable motor shaft is not sealed, so excess water or spills should be wiped
up immediately.
Clean the ring and the floor regularly to avoid excessive noise. Wipe the bottom
surface of your microwave with mild detergent. Wash the ring in mild, soapy water
or in a dishwasher. When removing the ring, make sure that you replace it in its
original position.
19
.7 Cu. Ft. Compact Microwave
www.insigniaproducts.com
Troubleshooting
If you have a problem with your microwave, review the following chart for a
possible solution. If your microwave still doesn’t work correctly, contact the
nearest authorized service center.
Obtaining replacement parts
Call Insignia Customer Service at 1-877-467-4289.
PROBLEM POSSIBLE SOLUTION
My microwave won’t start Plug the electrical cord into a power outlet.
Close the door and try again.
Arching or sparking in my
microwave
Use only microwave-safe materials. See Materials you
can use on page 6.
Don’t operate your microwave when it’s empty.
Clean your microwave with a wet towel.
Unevenly cooked foods Use only microwave-safe materials. See Materials you
can use on page 6.
Defrost the food completely before cooking it.
Use the correct cooking time and power level.
Turn or stir the food intermittently to ensure even
cooking.
Overcooked foods Use the correct cooking time and power level.
Undercooked foods Use only microwave-safe materials. See Materials you
can use on page 6.
Defrost the food completely before attempting to
cook it.
Use the correct cooking time and power level.
Make sure that the air vents aren’t blocked or
restricted.
Incorrect defrosting Use only microwave-safe materials. See Materials you
can use on page 6.
Use the correct cooking time and power level.
Turn or stir the food intermittently to ensure even
cooking.
20
www.insigniaproducts.com
Specifications
Model NSMW7BK5/NS-MW7WH5/MW7BK5-C/
NSMW7WH5-C
Rated voltage 120VAC, 60Hz
Rated input power 1,050W
Rated output power 700W
Microwave capacity .7 cu. ft. (19.8 L)
Turntable diameter 10 in. (25.4 cm)
External dimensions
(H × W × D)
10.17 x 17.3 x 13.96 in. (25.82 x 43.95 x 35.45 cm)
Power cord length 39.4 in. (1 m)
Net weight NS-MW7WH5/NS-MW7BK5: Net weight: 20.83 Ibs. (9.45 kg)
NS-MW7BK5-C/NS-MW7WH5-C: Net weight: 21.01 Ibs. (9.53 kg)
21
.7 Cu. Ft. Compact Microwave
www.insigniaproducts.com
ONE-YEAR LIMITED WARRANTY
Definitions:
The Distributor* of Insignia branded products warrants to you, the original purchaser of this
new Insignia-branded product (“Product”), that the Product shall be free of defects in the
original manufacturer of the material or workmanship for a period of one (1) year from the
date of your purchase of the Product (“Warranty Period”).
For this warranty to apply, your Product must be purchased in the United States or Canada
from a Best Buy branded retail store or online at www.bestbuy.com
or www.bestbuy.ca and
is packaged with this warranty statement.
How long does the coverage last?
The Warranty Period lasts for 1 year (365 days) from the date you purchased the Product.
Your purchase date is printed on the receipt you received with the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the material or workmanship of
the Product is determined to be defective by an authorized Insignia repair center or store
personnel, Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or
(2) replace the Product at no charge with new or rebuilt comparable products or parts.
Products and parts replaced under this warranty become the property of Insignia and are
not returned to you. If service of Products or parts are required after the Warranty Period
expires, you must pay all labor and parts charges. This warranty lasts as long as you own your
Insignia Product during the Warranty Period. Warranty coverage terminates if you sell or
otherwise transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy retail store location or from a Best Buy online
website (www.bestbuy.com or www.bestbuy.ca), please take your original receipt and the
Product to any Best Buy store. Make sure that you place the Product in its original packaging
or packaging that provides the same amount of protection as the original packaging.
To obtain warranty service, in the United States and Canada call 1-877-467-4289. Call agents
may diagnose and correct the issue over the phone.
Where is the warranty valid?
This warranty is valid only in the United States and Canada at Best Buy branded retail stores
or websites to the original purchaser of the product in the country where the original
purchase was made.
What does the warranty not cover?
This warranty does not cover:
• Food, beverage, and/or medicine loss/spoilage.
• Customer instruction/education
•Installation
•Set up adjustments
• Cosmetic damage
• Damage due to weather, lightning, and other acts of God, such as power surges
• Accidental damage
•Misuse
•Abuse
•Negligence
• Commercial purposes/use, including but not limited to use in a place of business or in
communal areas of a multiple dwelling condominium or apartment complex, or
otherwise used in a place of other than a private home.
• Modification of any part of the Product, including the antenna
• Display panel damaged by static (non-moving) images applied for lengthy periods
(burn-in).
22
www.insigniaproducts.com
• Damage due to incorrect operation or maintenance
• Connection to an incorrect voltage or power supply
• Attempted repair by any person not authorized by Insignia to service the Product
• Products sold “as is” or “with all faults”
• Consumables, including but not limited to batteries (i.e. AA, AAA, C etc.)
• Products where the factory applied serial number has been altered or removed
• Loss or Theft of this product or any part of the product
• Display panels containing up to three (3) pixel failures (dots that are dark or incorrectly
illuminated) grouped in an area smaller than one tenth (1/10) of the display size or up to
five (5) pixel failures throughout the display. (Pixel based displays may contain a limited
number of pixels that may not function normally.)
• Failures or Damage caused by any contact including but not limited to liquids, gels or
pastes.
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY
FOR BREACH OF WARRANTY. INSIGNIA SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON
THIS PRODUCT, INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR
PRODUCT, LOST BUSINESS OR LOST PROFITS. INSIGNIA PRODUCTS MAKES NO OTHER
EXPRESS WARRANTIES WITH RESPECT TO THE PRODUCT, ALL EXPRESS AND IMPLIED
WARRANTIES FOR THE PRODUCT, INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THE WARRANTY
PERIOD. SOME STATES, PROVINCES AND JURISDICTIONS DO NOT ALLOW LIMITATIONS ON
HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO
YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Contact Insignia:
1-877-467-4289
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its affiliated companies.
*Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A
©2024 Best Buy. All rights reserved.
For product inquiries, please contact us with the information below:
1-877-467-4289
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2024 Best Buy. All rights reserved.
V3 ENGLISH
24-0049
