Hikvision DS-KB8113-IME1B Vandal-Resistant Doorbell

Product's Documents

Below are documents related to this product, you can read online or download:
User Manual Specification Installation Instruction
DS-KB8113-IME1B photo

User Manual

This is the main product document for model DS-KB8113-IME1B.

The file format is pdf, 60 pages, you can download this manual here .

background
DS-KB8113-IME1(B) Series Vandal-Resistant
Door Staon
User Manual
background
Legal Informaon
©2023 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
i
background
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Data Protecon
During the use of device, personal data will be collected, stored and processed. To protect data,
the development of Hikvision devices incorporates privacy by design principles. For example, for
device with facial recognion features, biometrics data is stored in your device with encrypon
method; for ngerprint device, only ngerprint template will be saved, which is impossible to
reconstruct a ngerprint image.
As data controller, you are advised to collect, store, process and transfer data in accordance with
the applicable data protecon laws and regulaons, including without limitaon, conducng
security controls to safeguard personal data, such as, implemenng reasonable administrave and
physical security controls, conduct periodic reviews and assessments of the eecveness of your
security controls.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
ii
background
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
iii
background
Safety Instrucon
Warning
All the electronic operaon should be strictly compliance with the electrical safety regulaons,
re prevenon regulaons and other related regulaons in your local region.
Please use the power adapter, which is provided by normal company. The power consumpon
cannot be less than the required value.
Do not connect several devices to one power adapter as adapter overload may cause over-heat
or re hazard.
Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
When the product is installed on wall or ceiling, the device shall be rmly xed.
If smoke, odors or noise rise from the device, turn o the power at once and unplug the power
cable, and then please contact the service center.
If the product does not work properly, please contact your dealer or the nearest service center.
Never aempt to disassemble the device yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
Cauon
Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
Do not place the device in extremely hot (refer to the specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
The device cover for indoor use shall be kept from rain and moisture.
Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a malfuncon however), and aecng the endurance of sensor at the
same me.
Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the ngers may erode the surface coang of the device
cover.
Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
Please keep all wrappers aer unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper. Transportaon without the
original wrapper may result in damage on the device and lead to addional costs.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
iv
background
Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the baery manufacturer.
Improper replacement of the baery with an incorrect type may defeat a safeguard (for
example, in case of some lithium baery types).
Do not dispose of the baery into re or a hot oven, or mechanically crush or cut the baery,
which may result in an explosion.
Do not leave the baery in an extremely high temperature surrounding environment, which may
result in an explosion or leakage of ammable liquid or gas.
Do not subject the baery to extremely low air pressure, which may result in an explosion or the
leakage of ammable liquid or gas.
CAUTION: Risk of explosion if the baery is replaced by an incorrect type.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
v
background
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference in a residenal installaon. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instrucons, may cause harmful interference to radio communicaons. However, there is
no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television recepon, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
vi
background
under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve
2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to
the following two condions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired
operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence. L'exploitaon est autorisée aux deux condions suivantes :
1. l'appareil ne doit pas produire de brouillage, et
2. l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est suscepble d'en compromere le fonconnement.
Under Industry Canada regulaons, this radio transmier may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmier by Industry Canada. To reduce
potenal radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communicaon.
Conformément à la réglementaon d'Industrie Canada, le présent émeeur radio peut fonconner
avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émeeur par
Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intenon des
autres ulisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une
communicaon sasfaisante.
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
vii
background
Cet équipement doit être installé et ulisé à une distance minimale de 20 cm entre le radiateur et
votre corps.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
viii
background
Contents
Chapter 1 Appearance ................................................................................................................ 1
Chapter 2 Terminal and Wiring Descripon ................................................................................. 3
2.1 Terminal Descripon .............................................................................................................. 3
2.2 Wiring Descripon ................................................................................................................. 4
2.2.1 Door Lock Wiring .......................................................................................................... 4
2.2.2 Door Contact Wiring ..................................................................................................... 5
2.2.3 Exit Buon Wiring ......................................................................................................... 5
2.2.4 Alarm Device Input Wiring ............................................................................................ 7
Chapter 3 Door Staon Installaon ............................................................................................. 8
3.1 Wall Mounng Plate .............................................................................................................. 8
3.2 Wall Mounng ....................................................................................................................... 8
Chapter 4 Acvate Device via Web ........................................................................................... 14
Chapter 5 Remote Conguraon via Indoor Staon .................................................................. 15
5.1 Set Up Door Staon via Indoor Staon ................................................................................ 15
5.2 Local Operaon .................................................................................................................... 15
Chapter 6 Remote Conguraon via Mobile Client ................................................................... 17
6.1 Set Up Mobile Client ............................................................................................................ 17
6.2 Set Up Door Staon via Client .............................................................................................. 17
6.3 Remote Operaon via Client ................................................................................................ 18
Chapter 7 Remote Conguraon via Web ................................................................................. 22
7.1 Live View .............................................................................................................................. 22
7.2 User Management ............................................................................................................... 22
7.3 Device Management ............................................................................................................ 23
7.4 Conguraon ....................................................................................................................... 24
7.4.1 Local Parameters Sengs ........................................................................................... 24
7.4.2 System Sengs ........................................................................................................... 25
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
ix
background
7.4.3 Network Sengs ......................................................................................................... 27
7.4.4 Video & Audio Sengs ............................................................................................... 31
7.4.5 Image Sengs ............................................................................................................. 35
7.4.6 Event Sengs .............................................................................................................. 38
7.4.7 Intercom Sengs ........................................................................................................ 42
7.4.8 Access Control Sengs ............................................................................................... 45
Appendix A. Appendix .............................................................................................................. 47
Appendix B. Communicaon Matrix and Device Command ...................................................... 48
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
x
background
Chapter 1 Appearance
Figure 1-1 Appearance
Table 1-1 Component Descripon
No. Descripon
1 Microphone
2 Built-in Camera
3 Low Illuminaon Supplement Light
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
1
background
No. Descripon
4 Call Buon
5 Loudspeaker
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
2
background
Chapter 2 Terminal and Wiring Descripon
2.1 Terminal Descripon
Figure 2-1 Terminals Descripon
Table 2-1 Descripon
Name No. Interface Descripon
Power Supply 1 12 VDC 12 VDC Power Supply Input
LAN 2 LAN Network Interface (PoE Supported)
ALARM IN A1 AI Alarm Input
A2 GND Grounding
ALARM OUT B1 COM Common Interface
B2 NO Door Lock Relay Output (Connect Electric Strike)
B3 NC Door Lock Relay Output (Connect Electric Bolt
or Contact Lock)
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
3
background
2.2 Wiring Descripon
2.2.1 Door Lock Wiring
Terminal NC/COM is set as default for connecng magnec lock/electric bolt; terminal NO/ COM is
set as default for connecng electric strike.
To connect electric lock, it is required to set the output of terminal NC/COM/NO to be electric lock
via Batch Conguraon Tool or iVMS-4200 client soware or the web browser.
Figure 2-2 Door Lock Wiring
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
4
background
2.2.2 Door Contact Wiring
To connect door contact, it is required to set the output of terminal AI to be door status via Batch
Conguraon Tool or iVMS-4200 client soware or the web browser.
Figure 2-3 Door Contact Wiring
2.2.3 Exit Buon Wiring
To connect exit buon, it is required to set the output of terminal AI to be door status via Batch
Conguraon Tool or iVMS-4200 client soware or the web browser.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
5
background
Figure 2-4 Exit Buon Wiring
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
6
background
2.2.4 Alarm Device Input Wiring
When you set the output of terminal AI to be custom via Batch Conguraon Tool or iVMS-4200
client soware or the web browser, you can connect any alarm input device to the door staon via
the terminal AI.
Figure 2-5 Alarm Device Input Wiring
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
7
background
Chapter 3 Door Staon Installaon
3.1 Wall Mounng Plate
To install the door staon onto the wall, you are required to use a matched mounng plate.
Figure 3-1 Wall Mounng Plate
3.2 Wall Mounng
Steps
1.
Fix the wall mounng plate to the wall with 4 expansion screws.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
8
background
Figure 3-2 Install the Plate
2.
Insert terminal blocks into the interfaces of the door staon body, and connect the network
cable.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
9
background
Figure 3-3 Insert Terminals and Network Cable
3.
Fix the door staon body to the protecve shield ghtly.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
10
background
Figure 3-4 Fix the Body to the Shield
4.
Hook the door staon to the wall mounng plate ghtly.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
11
background
Figure 3-5 Hook the Door Staon to the Plate
5.
Use the set screw to secure the door staon with the mounng plate.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
12
background
Figure 3-6 Secure the Door Staon
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
13
background
Chapter 4 Acvate Device via Web
You are required to acvate the device rst by seng a strong password for it before you can use
the device.
Default parameters of the door staon are as follows:
Default IP Address: 192.0.0.65.
Default Port No.: 8000.
Default User Name: admin
Steps
1.
Power on the device, and connect the device to the network.
2.
Enter the IP address into the address bar of the web browser, and click Enter to enter the
acvaon page.
Note
The computer and the device should belong to the same subnet.
3.
Create and enter a password into the password eld.
4.
Conrm the password.
5.
Click OK to acvate the device.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
14
background
Chapter 5 Remote Conguraon via Indoor Staon
5.1 Set Up Door Staon via Indoor Staon
Steps
1.
Choose Language and tap Next.
2.
Set network parameters and tap Next
-
Edit Local IP, Subnet Mask and Gateway parameters.
-
Enable DHCP, the device will get network parameters automacally.
3.
Congure the indoor staon.
1) Choose Indoor Staon Type.
2) Edit Floor and Room No.
3) Tap Next.
4.
Linked related devices and tap Next. If the device and the indoor staon are in the same LAN,
the device will be displayed in the list. Tap the device or enter the serial No. to link.
1) Tap the door staon in the list to link.
Note
If the door staon is inacve, the system will pop up the dialog to acvate the door staon.
2) Tap to pop up the Network Sengs page.
3) Edit the network parameters of the door staon manually or enable DHCP to get the network
parameters automacally.
4) Oponal: Enable Synchronize Language to synchronize the language of door staon with
indoor staon.
5) Tap OK to save the sengs.
5.
Tap Finish to save the sengs.
5.2 Local Operaon
You can call the resident (the indoor staon) or the center (the master staon) via the door staon
by pressing or holding the call buon. Default sengs of the call buon: when you press the call
buon, it calls the resident, and when you hold the call buon, it calls the center.
Before You Start
Make sure the door staon has been acvated.
Make sure the network cable is well-connected.
Steps
1.
Press the call buon to call the resident.
2.
The resident can accept/decline the calling from the door staon, and unlock the door via the
indoor staon.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
15
background
Note
Besides the indoor staon, you can also unlock the door by the master staon, the client
soware, and the web.
When the video intercom between you and the resident is realized, you can speak to the
resident, and the live view of door staon will be displayed on the connected indoor staon.
When live view of door staon is displayed on other devices or door staon is calling resident,
the door staon will detect the brightness of video. When the brightness is lower than the
expected threshold, the supplement light will be enabled.
When the supplement light is enabled, the backlight of key will be auto-enabled, otherwise,
the door staon will detect the brightness of live view and enable the backlight of key when
the brightness of live view is lower than expected threshold.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
16
background
Chapter 6 Remote Conguraon via Mobile Client
6.1 Set Up Mobile Client
Before You Start
Make sure your mobile device has been connected to Wi-Fi.
Hik-Connect client is necessary for door staon conguraon and operaon.
Steps
1.
Install Hik-Connect client and register a user account for iOS and Android.
1) Search Hik-Connect in App Store or Google Play
TM
to download and install the client.
2) Launch the App and follow the on-screen instrucons to register a user account.
2.
Start the Hik-Connect client, and login the client.
6.2 Set Up Door Staon via Client
To operate the door staon normally, you should add the door staon to the client.
Steps
1.
On the home page of the client, tap Add Device.
-
Scan QR code of the device to add.
Note
The QR code is printed on the label, which is on the rear panel of door staon. If you have
already installed the device, you can scan the QR code on the cloud service page in the
device.
Tap to enable the ashlight if the scanning environment is too dark.
-
If there are device QR codes in photo album of the phone, tap
to extract QR code from
local album.
-
If the system fails to recognize the QR code, tap
and enter the serial No. to add the device
manually.
2.
Connect to the network.
1) Tap Next.
2) Connect the device to the router with a network cable.
Note
Make sure your mobile phone is connected to the same router.
3) Tap Connected.
3.
The account is connected to the device.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
17
background
6.3 Remote Operaon via Client
You can realize some certain funcons of the door staon via Hik-Connect (including, but not
limited to, live view, and remote playback).
Live View
Tap the door staon in the list to open the oang windows. And then tap the oang window to
enter the Live View page.
Tap the video on the screen, you can tap to capture the screen.
Tap to record.
Two-Way Audio
Call from client soware: On the Live View page, tap to create a call between the client and the
device.
Receive call from the device: You can receive or decline the call from device.
Tap to receive the call.
Tap to decline the call.
Tap to unlock the door remotely.
Tap to adjust the volume.
When you communicaon with the device, you can tap to mute.
Unlock Remotely
On the main page or on the live view page, tap to unlock the door.
Playback
On the Live View page, tap ... → Playback to playback the videos stored in the TF card.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
18
background
Figure 6-1 Playback
Synchronize Time
On the Live View page, tap ... Sengs , you can set the me of door staon.
Tap Time Zone to select the right me zone.
Tap Date Format to change the format.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
19
background
Alarm Nocaon
On the Live View page, tap ... Sengs Nocaon , slide the slider to enable alarm
nocaon.
Tap Draw Moon Detecon Area and select area. Tap to save.
Figure 6-2 Draw Moon Detecon Area
Tap Moon Detecon Sensivity to adjust the sensivity.
Note
When Moon Detecon is triggered, the device can capture the picture and upload to the
plaorm as an event.
Volume
On the Live View page, tap ... Sengs , you can adjust the Loudspeaker Volume and
Microphone Volume.
Note
Loudspeaker volume and microphone volume can be set from 0 to 10.
Nocaon
On the home page of the client, tap Nocaon to get or edit alarm messages.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
20
background
Note
The messages will be pushed automacally by enabling Receive Events and Push Nocaons.
The client can receive the triggered alarm automacally when the door staon is powered on by
Receive Events but NOT Push Nocaons.
Share Account
On the main page, tap to share the informaon to other accounts. Or on the live view page,
tap ... → Share to share.
Note
Up to 4 accounts can be added to share.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
21
background
Chapter 7 Remote Conguraon via Web
7.1 Live View
In the browser address bar, enter the IP address of the device, and press the Enter key to enter the
login page.
Enter the user name and password and click Login to enter the Live View page. Or you can click
Live View to enter the page.
Figure 7-1 Live View
You can start/stop live view, capture, record, audio on/o, two-way audio, etc.
The stream type can be set as main stream or sub stream.
For IE (Internet Explorer) or Google users, the device support two-way audio communicaon.
Note
Live View funcon may vary with dierent models. Please refer to the actual product.
7.2 User Management
You can add, delete or search the informaon of the user.
Click User to enter the sengs page.
Add User
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
22
background
Basic Informaon
Click Add to add users. Enter the Employee ID, Name, Floor No. and Room No., Set the
Start Time and End Time. You can set the user as Administrator.
Note
If you disable Always Valid, seng start me and end me is necessary.
Other Operaon
Click to modify the informaon of the user.
Check the box of the user and click Delete to delete the selected user.
Enter the keyword and click search icon. The informaon will display in the list.
Note
User management funcon may vary with dierent models. Please refer to the actual product.
7.3 Device Management
You can manage the linked device on the page.
Click Device Management to enter the sengs page.
Add Device
Click Add to add the indoor staon, sub door staon or decoder staon. Enter the parameters
and click OK to add.
Click Import. Enter the informaon of the device in the template to import devices in batch.
Export
Click Export to export the informaon to the PC.
Delete
Select the device and click Delete to remove the selected device from the list.
Refresh
Click Refresh to get the device informaon.
Oponal: Set device informaon.
Click
to edit device informaon.
Click to delete device informaon from the list.
Select Status and Device Type to search devices.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
23
background
7.4 Conguraon
7.4.1 Local Parameters Sengs
You can congure the parameters of the live view, record les and captured pictures. The record
les and captured pictures are the ones you record and capture by using the web browser. You can
also set and view the saving paths of the captured pictures and recorded videos on the PC that
running the web browser.
Figure 7-2 Local Parameters
Live View Parameters
Stream Type
Set the stream type as Main Stream or Sub-stream.
Play Performance
Set the live view performance to Shortest Delay, Balanced or Fluent.
Auto Start Live View
Check Yes to enable the funcon.
Image Format
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
24
background
Select the image format for picture capture.
Click Save to enable the sengs.
Record File Parameters
Record File Size
Select the packed size of the manually recorded and downloaded video les to 256M, 512M or
1G. Aer the selecon, the maximum record le size is the value you selected.
Save record les to
Set the saving path for the manually recorded video les.
Click Save to enable the sengs.
Picture and Clip Sengs
Save snapshots in live view to
Set the saving path of the manually captured pictures in live view mode.
Note
You can click Browse to change the directory for saving the clips and pictures, and click Open to
open the set folder of clips and picture saving.
Click Save to enable the sengs.
7.4.2 System Sengs
Follow the instrucons below to congure the system sengs, include System Sengs,
Maintenance, Security, and User Management, etc.
Click System to enter the sengs page.
Basic Informaon
Click System Sengs → Basic Informaon to enter the sengs page. On the page, you can edit
Device Name and Device No. Set the Language according to your needs.
You can view the quanes of added users in Capacity.
Click Save to enable the sengs.
Time Sengs
Click System Sengs → Time Sengs to enter the sengs page. Select the Time Zone of your
locaon from the drop-down list.
Enable NTP, set the Alarm Receiver Type, Server Address, NTP Port and Interval.
Enable Manual Time Sync., set the me manually or check the Sync. with computer me.
Click Save to enable the sengs.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
25
background
DST
Click System Sengs → DST to check Enable DST. Set the parameters according to your needs and
click Save to enable the sengs.
About
Click System Sengs → About and click Open Source Soware Licenses to view the details.
Maintenance
Click Maintenance → Upgrade & Maintenance to enter the sengs page.
Reboot: Click Reboot to reboot the device.
Default
Click Default to reset all the parameters, except the IP parameters and user informaon, to
the default sengs.
Restore All
Click Restore All to restore all parameters to default sengs.
Unlink APP Account: Click Unlink APP Account to unlink the APP account of the device.
Export parameters:
1. Select Device Parameters, and click Export to pop up the dialog box.
2. Set and conrm the encrypon password.
3. Click OK to export parameters.
Import Cong. File:
1. Click browse icon to select the conguraon le.
2. Click Import and enter the encrypon password to import.
Upgrade: Click browse icon to select the upgrade le.
Note
The upgrading process will last 1 to 10 minutes, do not power o during the upgrading. The
device reboots automacally aer upgrading.
Security Service
Click Security → Security Service to enter the sengs page. On the page, you can enable SSH
according to your actual needs.
Click Save to enable the sengs.
User Management
Click User Management to enter the sengs page.
Administrator can edit the permission for the users.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
26
background
Note
We highly recommend you to create a strong password of your own choosing (using a minimum of
8 characters, including at least three kinds of following categories: upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And we
recommend you change your password regularly, especially in the high security system, changing
the password monthly or weekly can beer protect your product.
Online Users
Click User Management → Online Users to enter the page.
Click Refresh to get the present informaon.
Arming/Disarming Informaon
Click User Management → Arming/Disarming Informaon to view the informaon. Click Refresh
to get the present informaon.
7.4.3 Network Sengs
TCP/IP Sengs
TCP/IP sengs must be properly congured before you operate the device over network. The
device supports IPv4.
Steps
1.
Click Network → Basic Sengs → TCP/IP to enter the sengs page.
2.
Congure the network parameters.
-
Check DHCP, the device will get the parameters automacally.
-
Set the IPv4 Address, IPv4 Subnet Mask and IPv4 Default Gateway manually.
3.
Select Network Card.
4.
Congure the DNS server.
5.
Click Save to enable the sengs.
Port Sengs
Steps
1.
Click Network → Basic Sengs → Port to enter the sengs page.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
27
background
Figure 7-3 Port Sengs
2.
Set the ports of the device.
HTTP Port
The default port number is 80, and it can be changed to any port No. which is not occupied.
RTSP Port
The default port number is 554.
HTTPS Port
The default port number is 443, and it can be changed to any port No. which is not occupied.
Server Port
The default server port number is 8000, and it can be changed to any port No. ranges from
2000 to 65535.
3.
Click Save to enable the sengs.
SIP Seng
Steps
1.
Click Network → Basic Sengs → SIP to enter the sengs page.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
28
background
Figure 7-4 SIP Sengs
2.
Check Enable VOIP Gateway.
3.
Congure the SIP parameters.
4.
Click Save to enable the sengs.
FTP Sengs
Steps
1.
Click Network → Advanced → FTP to enter the sengs page.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
29
background
Figure 7-5 FTP Sengs
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
30
background
2.
Check Enable FTP.
3.
Select Server Type.
4.
Input the Server IP Address and Port.
5.
Congure the FTP Sengs, and the user name and password are required for the server login.
6.
Set the Directory Structure, Parent Directory and Child Directory.
7.
Set the picture naming rules.
8.
Click Save to enable the sengs.
Plaorm Access
Steps
1.
Click Network → Advanced Plaorm Access to enter the sengs page.
2.
Select the Plaorm Access Mode.
Note
Hik-Connect is an applicaon for mobile devices. With the App, you can view live image of the
device, receive alarm nocaon and so on.
3.
Check the checkbox of Enable to enable the funcon.
4.
Oponal: Check the checkbox of Custom to custom the Server Address.
5.
Create a Stream Encrypon/Encrypon Key for the device.
Note
6 to 12 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are recommended to use a
combinaon of no less than 8 leers or numbers.
6.
Click Save to enable the sengs.
7.4.4 Video & Audio Sengs
Video Parameters
Steps
1.
Click Video/Audio → Video to enter the sengs page.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
31
background
Figure 7-6 Video Parameters
2.
Select the Stream Type.
3.
Congure the video parameters.
Stream Type
Select the stream type to main stream or sub stream.
Video Type
The video type is set as Video&Audio by default.
Resoluon
Select the resoluon of the video output.
Note
When the Stream Type is selected as Sub-stream, the Resoluon is 640*480p by default.
Bitrate Type
Select the bitrate type as constant or variable.
Video Quality
When bitrate type is selected as Variable, 6 levels of video quality are selectable.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
32
background
Frame Rate
Set the frame rate. The frame rate is to describe the frequency at which the video stream is
updated and it is measured by frames per second (fps). A higher frame rate is advantageous
when there is movement in the video stream, as it maintains image quality throughout.
Max. Bitrate
Set the max. bitrate from 32 to 16384 Kbps. The higher value corresponds to the higher video
quality, but the beer bandwidth is required.
Video Encoding
The device supports H.264.
I Frame Interval
Set I Frame Interval from 1 to 400.
4.
Click Save to save the sengs.
Audio Parameters
Steps
1.
Click Video/Audio → Audio to enter the sengs page.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
33
background
Figure 7-7 Audio Sengs
2.
Congure the stream type and the audio encoding type.
Audio Channel
Select the audio channel to adjust the audio parameters.
Stream Type
Select the stream type to main stream or sub stream.
Audio Encoding
The device support G.711ulaw and G.711 alaw.
3.
Adjust the Input Volume, Output Volume and Speak Volume.
Note
Available range of volume: 0 to 10.
4.
Click Save to save the sengs.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
34
background
7.4.5 Image Sengs
Display Sengs
Congure the image adjustment, backlight sengs and other parameters in display sengs.
Steps
1.
Click Image → Display Sengs to enter the display sengs page.
Figure 7-8 Display Sengs
2.
Select the Video Standard.
3.
Select to enable or disable WDR.
Note
Wide Dynamic Range can be used when there is a high contrast of the bright area and the dark
area of the scene.
4.
Set the basic parameters.
Brightness
Brightness describes bright of the image, which ranges from 1 to 100.
Contrast
Contrast describes the contrast of the image, which ranges from 1 to 100.
Saturaon
Saturaon describes the colorfulness of the image color, which ranges from 1 to 100.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
35
background
Sharpness
Sharpness describes the edge contrast of the image, which ranges from 1 to 100.
5.
Set the Day/Night Switch.
Figure 7-9 Day/Night Switch
-
Set Dayme or Night.
-
Set the mode as Auto and edit the sensivity according to your needs.
-
Set the mode as Scheduled-Switch. Set the start me and end me.
6.
Set the backlight parameters.
Figure 7-10 Backlight
1) Check to enable BLC.
2) Select BLC Area.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
36
background
OSD Sengs
You can customize the camera name, me/date format on the live view.
Steps
1.
Click Image → OSD to enter the sengs page.
Figure 7-11 OSD
2.
Check to enable Display Name, Display Date or Display Week at your actual needs.
3.
Edit the Camera Name.
Note
You can edit the camera name only when Display Name is enabled.
4.
Select from the drop-down list to set the Time Format and Date Format.
5.
Click Save to enable the sengs.
Target Cropping
Steps
1.
Click Image → Crop to enter the page.
2.
Check Enable Target Cropping to enable the funcon.
3.
Click to capture photo.
4.
Click to start recording.
5.
Select Cropping Resoluon.
6.
Click Save.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
37
background
Note
You can select Cropping Resoluon as 704*576, 1280*720, or 1920*1080.
You can zoom in or zoom out the image by selecng Cropping Resoluon aer clicking Save.
7.4.6 Event Sengs
Moon Detecon
Moon detecon detects the moving objects in the congured security area, and a series of
acons can be taken when the alarm is triggered.
Steps
1.
Click Event → Basic Event Moon to enter the sengs page.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
38
background
Figure 7-12 Moon Detecon
2.
Click to Enable Moon Detecon.
3.
Click Draw Area. Click and drag to draw a moon detecon area.
Clear Area Click Clear All to clear all of the areas.
Adjust Sensivity Move the slider to set the sensivity of the detecon.
4.
Click Arming Schedule to edit the arming schedule.
5.
Click on the me bar and drag to select the me period. Click Save to save the sengs.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
39
background
Delete Schedule Click Delete to delete the current arming schedule.
6.
Click Linkage Method to enable the linkages.
Nofy Security Center
Send an excepon or alarm signal to the remote management soware when an event
occurs.
7.
Click Save to enable the sengs.
Event Linkage
Steps
1.
Click Event → Basic Event → Event Linkage to enter the sengs page.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
40
background
Figure 7-13 Event Linkage
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
41
background
2.
Select the Major Type as Device Event or Door Event.
3.
Select the Minor Type.
-
For device event, the Minor Type is set as Tampering Alaem by default.
-
For door event, select Minor Type as Door Open Timed Out (Door Contact).
4.
Select the type of the Normal Linkage for the event.
5.
Click Save to enable the sengs.
7.4.7 Intercom Sengs
Device No. Conguraon
Set the No. of the device, and linked devices can build a communicaon.
Steps
1.
Click Intercom → Device No. to enter the sengs page.
2.
Select the device type from the drop-down list, and set the corresponding informaon.
3.
Select the device type from the drop-down list, and set the corresponding informaon including
Floor No., Door Staon No., Building No., Community No. and Unit No.
Note
When you select Doorphone as Device Type, only Community No., Building No. and Unit No.
can be set.
4.
Click Save to enable the device number conguraon.
Note
For main door staon (D series or V series), the serial No. is 0.
For sub door staon (D series or V series), the serial No. cannot be 0. Serial No. ranges from 1
to 99.
For each villa or building, at least one main door staon (D series or V series) should be
congured, and one sub door staons (D series or V series) can be customized.
For one main door staon (D series or V series), up to 8 sub door staons can be congured.
Session Sengs
Steps
1.
Click Intercom → Session Sengs to enter the sengs page.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
42
background
Figure 7-14 Session Sengs
2.
Set Registraon Password.
3.
Set Main Staon IP and Private Server IP.
4.
Slide to enable Protocol 1.0.
5.
Click Save to enable the sengs.
Call Sengs
Go to Intercom → Call Sengs to enter the page.
Congure Max. Call Communicaon, Max. Message Duraon and Max. Ring Duraon, and click
Save.
Note
Max. call duraon between the module indoor staon and client ranges from 90 s to 120 s. The
call will end automacally when the actual calling duraon is longer than the congured one.
Max. message duraon ranges from 30 s to 60 s. The message will end automacally when the
actual message duraon is longer than the congured one.
Max. ring duraon ranges from 65 s to 255 s.
Ring-Back Tone Sengs
Click Intercom → Ringbacktone Sengs to enter the sengs page.
Click Add to select the ring tone from PC.
Note
Available Audio Format: WAVAAC, Size: Less than 600 KB, Sample Rate: 8000Hz, Mono.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
43
background
Press Buon to Call
Steps
1.
Click Intercom → Press Buon to Call to enter the seng page.
2.
Check Call Management Centeror Call Specied Indoor Staon to set the buon.
Note
If you check Call Specied Indoor Staon, you should enter the specied indoor staon No.
3.
ClickBacklight Mode and you can select a backlight mode from the drop-down list.
I/O Sengs
Steps
1.
Click Intercom → I/O Sengs to enter the I/O input and output sengs page.
2.
Select I/O input No., input mode, output No., and output mode.
3.
Click Save to enable the sengs.
Note
For door staon, there are 4 I/O input terminals. By default, Terminal 1 and 2 correspond to
Door Status. Terminal 3 and 4 correspond to interfaces of Door Switch.
For door staon, there are 2 I/O Output Terminals. Terminal 1 and 2 correspond to Door
interfaces (NO1/COM/NC1; NO2/COM/NC2) of door staon. Door 1 is enabled by default. You
can enable/disable IO Out according to needs.
Number Sengs
Link the room No. and SIP numbers.
Click Intercom → Number Sengs to enter the page.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
44
background
Figure 7-15 Number Sengs
Click Add, set the Room No. and SIP numbers in the pop-up dialog box.
7.4.8 Access Control Sengs
Door Parameters
Set the parameters of the door which is linked to the device.
Steps
1.
Click Access Control → Door Parameters to enter the sengs page.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
45
background
Figure 7-16 Door Parameters
2.
Select Door No., and edit the Name.
3.
Set Open Duraon. When the me to open over the open duraon you set, the door will be
locked again.
4.
Select Relay Reverse as ON or Disable.
5.
Click Save to enable the sengs.
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
46
background
Appendix A. Appendix
Installaon Noce
While installing the door staon, make sure that the distance between any two devices is far
enough to avoid the howling and echo. The distance between two devices is recommended to be
longer than 10 meters.
Note
Devices menoned here refer to indoor staon, door staon and master staon.
Wiring Cables
Cable Specicaon
Power Cord of Door Staon RVV 2*1.0
Network Cable of Door Staon UTP-ve Categories
Door Lock Wiring (with Door Contact) RVV 4*1.0
Door Lock Wiring (without Door Contact) RVV 2*1.0
Exit Buon Wiring RVV 2*0.5
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
47
background
Appendix B. Communicaon Matrix and Device
Command
Communicaon Matrix
Scan the following QR code to get the device communicaon matrix.
Note that the matrix contains all communicaon ports of Hikvision access control and video
intercom devices.
Figure B-1 QR Code of Communicaon Matrix
Device Command
Scan the following QR code to get the device common serial port commands.
Note that the command list contains all commonly used serial ports commands for all Hikvision
access control and video intercom devices.
Figure B-2 Device Command
DS-KB8113-IME1(B) Series Vandal-Resistant Door Staon User Manual
48
background
UD31659B

Specifications

Indexed Terms: Doorbell, Vandal Resistant

Hikvision DS-KB8113-IME1B Questions and Answers
