Hikvision DS-KB8113-IME1 2MP Vandal Resistant IP Doorbell

Product's Documents

Below are documents related to this product, you can read online or download:
User Manual Installation Instruction Specification
  • Hikvision DS-KB8113-IME1 2MP Vandal Resistant IP Doorbell Datasheet 0.90MB - (English) Download
DS-KB8113-IME1 photo

User Manual

This is the main product document for model DS-KB8113-IME1.

The file format is pdf, 58 pages, you can download this manual here .

background
Video Intercom Vandal-Resistant
Doorbell
User Manual
background
Legal Informaon
©2020 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product.
Pictures, charts, images and all other informaon hereinaer are for
descripon and explanaon only. The informaon contained in the Manual
is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision
website (
hps://www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals
trained in supporng the Product.
Trademarks
and other Hikvision's trademarks and logos are the
properes of Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their
respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL
AND THE PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND
FIRMWARE, ARE PROVIDED “AS IS” AND “WITH ALL FAULTS AND ERRORS”.
HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS
AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR
ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR
LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT,
TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN
Video Intercom Vandal-Resistant Doorbell User Manual
i
background
CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR
INHERENT SECURITY RISKS, AND HIKVISION SHALL NOT TAKE ANY
RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR
OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION
WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE
LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE
CONFORMS TO THE APPLICABLE LAW. ESPECIALLY, YOU ARE RESPONSIBLE,
FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT INFRINGE ON THE
RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND
OTHER PRIVACY RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY
PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR PRODUCTION
OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN
THE CONTEXT RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR
FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
Data Protecon
During the use of device, personal data will be collected, stored and
processed. To protect data, the development of Hikvision devices
incorporates privacy by design principles. For example, for device with facial
recognion features, biometrics data is stored in your device with
encrypon method; for ngerprint device, only ngerprint template will be
saved, which is impossible to reconstruct a ngerprint image.
As data controller, you are advised to collect, store, process and transfer
data in accordance with the applicable data protecon laws and regulaons,
including without limitaon, conducng security controls to safeguard
personal data, such as, implemenng reasonable administrave and
physical security controls, conduct periodic reviews and assessments of the
eecveness of your security controls.
Video Intercom Vandal-Resistant Doorbell User Manual
ii
background
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or
could result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not
avoided, could result in equipment damage, data loss,
performance degradaon, or unexpected results.
Note
Provides addional informaon to emphasize or
supplement important points of the main text.
Video Intercom Vandal-Resistant Doorbell User Manual
iii
background
Safety Instrucon
Warning
All the electronic operaon should be strictly compliance with the electrical
safety regulaons, re prevenon regulaons and other related regulaons in
your local region.
Please use the power adapter, which is provided by normal company. The power
consumpon cannot be less than the required value.
Do not connect several devices to one power adapter as adapter overload may
cause over-heat or re hazard.
Please make sure that the power has been disconnected before you wire, install
or dismantle the device.
When the product is installed on wall or ceiling, the device shall be rmly xed.
If smoke, odors or noise rise from the device, turn o the power at once and
unplug the power cable, and then please contact the service center.
If the product does not work properly, please contact your dealer or the nearest
service center. Never aempt to disassemble the device yourself. (We shall not
assume any responsibility for problems caused by unauthorized repair or
maintenance.)
Cauon
Do not drop the device or subject it to physical shock, and do not expose it to
high electromagnesm radiaon. Avoid the equipment installaon on vibraons
surface or places subject to shock (ignorance can cause equipment damage).
Do not place the device in extremely hot (refer to the specicaon of the device
for the detailed operang temperature), cold, dusty or damp locaons, and do
not expose it to high electromagnec radiaon.
The device cover for indoor use shall be kept from rain and moisture.
Exposing the equipment to direct sun light, low venlaon or heat source such
as heater or radiator is forbidden (ignorance can cause re danger).
Do not aim the device at the sun or extra bright places. A blooming or smear
may occur otherwise (which is not a malfuncon however), and aecng the
endurance of sensor at the same me.
Video Intercom Vandal-Resistant Doorbell User Manual
iv
background
Please use the provided glove when open up the device cover, avoid direct
contact with the device cover, because the acidic sweat of the ngers may erode
the surface coang of the device cover.
Please use a so and dry cloth when clean inside and outside surfaces of the
device cover, do not use alkaline detergents.
Please keep all wrappers aer unpack them for future use. In case of any failure
occurred, you need to return the device to the factory with the original wrapper.
Transportaon without the original wrapper may result in damage on the device
and lead to addional costs.
Improper use or replacement of the baery may result in hazard of explosion.
Replace with the same or equivalent type only. Dispose of used baeries
according to the instrucons provided by the baery manufacturer.
Improper replacement of the baery with an incorrect type may defeat a
safeguard (for example, in case of some lithium baery types).
Do not dispose of the baery into re or a hot oven, or mechanically crush or
cut the baery, which may result in an explosion.
Do not leave the baery in an extremely high temperature surrounding
environment, which may result in an explosion or leakage of ammable liquid or
gas.
Do not subject the baery to extremely low air pressure, which may result in an
explosion or the leakage of ammable liquid or gas.
CAUTION: Risk of explosion if the baery is replaced by an incorrect type.
Video Intercom Vandal-Resistant Doorbell User Manual
v
background
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved
by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC compliance: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protecon against harmful
interference in a residenal installaon. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instrucons, may cause harmful interference to radio
communicaons. However, there is no guarantee that interference will not
occur in a parcular installaon. If this equipment does cause harmful
interference to radio or television recepon, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help
This equipment should be installed and operated with a minimum distance
20cm between the radiator and your body.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to
the following two condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference
that may cause undesired operaon.
Video Intercom Vandal-Resistant Doorbell User Manual
vi
background
EU Conformity Statement
This product and - if applicable - the supplied accessories too are
marked with "CE" and comply therefore with the applicable
harmonized European standards listed under the EMC Direcve
2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve 2011/
65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol
cannot be disposed of as unsorted municipal waste in the
European Union. For proper recycling, return this product to your
local supplier upon the purchase of equivalent new equipment, or
dispose of it at designated collecon points. For more informaon
see: www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery
that cannot be disposed of as unsorted municipal waste in the
European Union. See the product documentaon for specic
baery informaon. The baery is marked with this symbol,
which may include leering to indicate cadmium (Cd), lead (Pb),
or mercury (Hg). For proper recycling, return the baery to your
supplier or to a designated collecon point. For more informaon
see:www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operaon is subject to the following two condions:
1.
this device may not cause interference, and
2.
this device must accept any interference, including interference that may
cause undesired operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radioexempts de licence. L'exploitaon est autorisée aux deux
condions suivantes :
Video Intercom Vandal-Resistant Doorbell User Manual
vii
background
1.
l'appareil ne doit pas produire de brouillage, et
2.
l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est suscepble d'en compromere le
fonconnement.
Under Industry Canada regulaons, this radio transmier may only operate
using an antenna of a type and maximum (or lesser) gain approved for the
transmier by Industry Canada. To reduce potenal radio interference to
other users, the antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more than that
necessary for successful communicaon.
Conformément à la réglementaon d'Industrie Canada, le présent émeeur
radio peut fonconner avec une antenne d'un type et d'un gain maximal (ou
inférieur) approuvé pour l'émeeur par Industrie Canada. Dans le but de
réduire les risques de brouillage radioélectrique à l'intenon des autres
ulisateurs, il faut choisir le type d'antenne et son gain de sorte que la
puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité
nécessaire à l'établissement d'une communicaon sasfaisante.
This equipment should be installed and operated with a minimum distance
20cm between the radiator and your body.
Cet équipement doit être installé et ulisé à une distance minimale de 20
cm entre le radiateur et votre corps.
Video Intercom Vandal-Resistant Doorbell User Manual
viii
background
Contents
1 Appearance ................................................................................................ 1
2 Terminal and Wiring Descripon ................................................................ 2
2.1 Terminal Descripon ......................................................................................... 2
2.2 Wiring Descripon ............................................................................................ 2
2.2.1 Door Lock Wiring ...................................................................................... 3
2.2.2 Door Contact Wiring ................................................................................. 3
2.2.3 Exit Buon Wiring .................................................................................... 4
2.2.4 Alarm Device Input Wiring ....................................................................... 5
3 Doorbell Installaon ................................................................................... 7
3.1 Wall Mounng Plate ......................................................................................... 7
3.2 Wall Mounng .................................................................................................. 7
4 Acvate Device via Web ........................................................................... 11
5 Remote Conguraon via Indoor Staon ................................................. 12
5.1 Set Up Doorbell via Indoor Staon ................................................................. 12
5.2 Local Operaon ............................................................................................... 12
6 Remote Conguraon via Mobile Client .................................................. 14
6.1 Set Up Mobile Client ....................................................................................... 14
6.2 Set Up Doorbell via Client ............................................................................... 14
6.3 Remote Operaon via Client ........................................................................... 15
7 Remote Conguraon via Web ................................................................ 21
7.1 Live View ......................................................................................................... 21
7.2 Query .............................................................................................................. 21
Video Intercom Vandal-Resistant Doorbell User Manual
ix
background
7.3 User Management .......................................................................................... 21
7.4 Parameters Sengs ........................................................................................ 22
7.4.1 Local Parameters Sengs ....................................................................... 22
7.4.2 System Sengs ....................................................................................... 23
7.4.3 Network Sengs .................................................................................... 26
7.4.4 Video & Audio Sengs ........................................................................... 30
7.4.5 Image Sengs ........................................................................................ 32
7.4.6 Event Sengs ......................................................................................... 35
7.4.7 Intercom Sengs .................................................................................... 38
7.4.8 Access Control Sengs ........................................................................... 42
7.5 Number Sengs ............................................................................................. 44
7.6 Device Management ....................................................................................... 44
A. Appendix ................................................................................................. 45
B. Communicaon Matrix and Device Command ....................................... 46
Video Intercom Vandal-Resistant Doorbell User Manual
x
background
1 Appearance
Figure 1-1 Appearance
Table 1-1 Component Descripon
No. Descripon
1 Microphone
2 Built-in Camera
3 Low Illuminaon Supplement Light
4 Call Buon
5 Loudspeaker
Video Intercom Vandal-Resistant Doorbell User Manual
1
background
2 Terminal and Wiring Descripon
2.1 Terminal Descripon
Figure 2-1 Terminals Descripon
Table 2-1 Descripon
Name No. Interface Descripon
Power
Supply
1 12 VDC 12 VDC Power Supply Input
LAN 2 LAN Network Interface (PoE Supported)
ALARM IN A1 AI Alarm Input
A2 GND Grounding
ALARM OUT B1 COM Common Interface
B2 NO Door Lock Relay Output (Connect
Electric Strike)
B3 NC Door Lock Relay Output (Connect
Electric Bolt or Contact Lock)
2.2 Wiring Descripon
Video Intercom Vandal-Resistant Doorbell User Manual
2
background
2.2.1 Door Lock Wiring
Terminal NC/COM is set as default for connecng magnec lock/electric bolt;
terminal NO/ COM is set as default for connecng electric strike.
To connect electric lock, it is required to set the output of terminal NC/COM/NO to
be electric lock via Batch Conguraon Tool or iVMS-4200 client soware or the web
browser.
Figure 2-2 Door Lock Wiring
2.2.2 Door Contact Wiring
To connect door contact, it is required to set the output of terminal AI to be door
status via Batch Conguraon Tool or iVMS-4200 client soware or the web browser.
Video Intercom Vandal-Resistant Doorbell User Manual
3
background
Figure 2-3 Door Contact Wiring
2.2.3 Exit Buon Wiring
To connect exit buon, it is required to set the output of terminal AI to be door
status via Batch Conguraon Tool or iVMS-4200 client soware or the web browser.
Video Intercom Vandal-Resistant Doorbell User Manual
4
background
Figure 2-4 Exit Buon Wiring
2.2.4 Alarm Device Input Wiring
When you set the output of terminal AI to be custom via Batch Conguraon Tool or
iVMS-4200 client soware or the web browser, you can connect any alarm input
device to the door staon via the terminal AI.
Video Intercom Vandal-Resistant Doorbell User Manual
5
background
Figure 2-5 Alarm Device Input Wiring
Video Intercom Vandal-Resistant Doorbell User Manual
6
background
3 Doorbell Installaon
3.1 Wall Mounng Plate
To install the doorbell onto the wall, you are required to use a matched mounng
plate.
Figure 3-1 Wall Mounng Plate
3.2 Wall Mounng
Steps
1.
Fix the wall mounng plate to the wall with 4 expansion screws.
Video Intercom Vandal-Resistant Doorbell User Manual
7
background
Figure 3-2 Install the Plate
2.
Insert terminal blocks into the interfaces of the doorbell body, and connect the
network cable.
Figure 3-3 Insert Terminals and Network Cable
3.
Fix the doorbell body to the protecve shield ghtly.
Video Intercom Vandal-Resistant Doorbell User Manual
8
background
Figure 3-4 Fix the Body to the Shield
4. Hook the doorbell to the wall mounng plate ghtly.
Figure 3-5 Hook the Doorbell to the Plate
5.
Use the set screw to secure the doorbell with the mounng plate.
Video Intercom Vandal-Resistant Doorbell User Manual
9
background
Figure 3-6 Secure the Doorbell
Video Intercom Vandal-Resistant Doorbell User Manual
10
background
4 Acvate Device via Web
You are required to acvate the device rst by seng a strong password for it before
you can use the device.
Default parameters of the door staon are as follows:
Default IP Address: 192.0.0.65.
Default Port No.: 8000.
Default User Name: admin
Steps
1.
Power on the device, and connect the device to the network.
2. Enter the IP address into the address bar of the web browser, and click Enter to
enter the acvaon page.
Note
The computer and the device should belong to the same subnet.
3.
Create and enter a password into the password eld.
4.
Conrm the password.
5.
Click OK to acvate the device.
Video Intercom Vandal-Resistant Doorbell User Manual
11
background
5 Remote Conguraon via Indoor
Staon
5.1 Set Up Doorbell via Indoor Staon
Steps
1. Choose Language and tap Next.
2.
Set network parameters and tap Next
-
Edit Local IP, Subnet Mask and Gateway parameters.
-
Enable DHCP, the device will get network parameters automacally.
3.
Congure the indoor staon.
1) Choose Indoor Staon Type.
2) Edit Floor and Room No.
3) Tap Next.
4.
Linked related devices and tap Next. If the device and the indoor staon are in
the same LAN, the device will be displayed in the list. Tap the device or enter the
serial No. to link.
1) Tap the doorbell in the list to link.
Note
If the doorbell is inacve, the system will pop up the dialog to acvate the
doorbell.
2)
Tap
to pop up the Network Sengs page.
3) Edit the network parameters of the doorbell manually or enable DHCP to get
the network parameters automacally.
4) Oponal: Enable Synchronize Language to synchronize the language of
doorbell with indoor staon.
5) Tap OK to save the sengs.
5.
Tap Finish to save the sengs.
5.2 Local Operaon
Video Intercom Vandal-Resistant Doorbell User Manual
12
background
You can call the resident (the indoor staon) or the center (the master staon) via
the doorbell by pressing or holding the call buon. Default sengs of the call
buon: when you press the call buon, it calls the resident, and when you hold the
call buon, it calls the center.
Before You Start
Make sure the doorbell has been acvated.
Make sure the network cable is well-connected.
Steps
1.
Press the call buon to call the resident.
2.
The resident can accept/decline the calling from the doorbell, and unlock the
door via the indoor staon.
Note
Besides the indoor staon, you can also unlock the door by the master
staon, the client soware, and the web.
When the video intercom between you and the resident is realized, you can
speak to the resident, and the live view of doorbell will be displayed on the
connected indoor staon.
When live view of doorbell is displayed on other devices or doorbell is calling
resident, the doorbell will detect the brightness of video. When the
brightness is lower than the expected threshold, the supplement light will be
enabled.
When the supplement light is enabled, the backlight of key will be auto-
enabled, otherwise, the doorbell will detect the brightness of live view and
enable the backlight of key when the brightness of live view is lower than
expected threshold.
Video Intercom Vandal-Resistant Doorbell User Manual
13
background
6 Remote Conguraon via Mobile Client
6.1 Set Up Mobile Client
Before You Start
Make sure your mobile device has been connected to Wi-Fi.
Hik-Connect client is necessary for doorbell conguraon and operaon.
Steps
1.
Install Hik-Connect client and register a user account for iOS and Android.
1) Search Hik-Connect in App Store or Google Play
TM
to download and install
the client.
2) Launch the App and follow the on-screen instrucons to register a user
account.
2.
Start the Hik-Connect client, and login the client.
6.2 Set Up Doorbell via Client
To operate the doorbell normally, you should add the doorbell to the client.
Steps
1.
On the home page of the client, tap Add Device.
-
Scan QR code of the device to add.
Note
The QR code is printed on the label, which is on the rear panel of
doorbell. If you have already installed the device, you can scan the QR
code on the cloud service page in the device.
Tap
to enable the ashlight if the scanning environment is too dark.
-
If there are device QR codes in photo album of the phone, tap
to extract
QR code from local album.
-
If the system fails to recognize the QR code, tap
and enter the serial No.
to add the device manually.
2.
Connect to the network.
1) Tap Next.
2) Connect the device to the router with a network cable.
Video Intercom Vandal-Resistant Doorbell User Manual
14
background
Note
Make sure your mobile phone is connected to the same router.
3) Tap Connected.
3.
The account is connected to the device.
6.3 Remote Operaon via Client
You can realize some certain funcons of the doorbell via Hik-Connect (including,
but not limited to, live view, and remote playback).
Live View
Tap the doorbell in the list to open the oang windows. And then tap the
oang window to enter the Live View page.
Figure 6-1 Live View
Video Intercom Vandal-Resistant Doorbell User Manual
15
background
Tap the video on the screen, you can tap to capture the screen.
Tap
to record.
Two-Way Audio
Call from client soware: On the Live View page, tap to create a call
between the client and the device.
Receive call from the device: You can receive or decline the call from device.
Figure 6-2 Receive Call from Device
Tap
to receive the call.
Tap
to decline the call.
Tap
to unlock the door remotely.
Tap to adjust the volume.
When you communicaon with the device, you can tap to mute.
Video Intercom Vandal-Resistant Doorbell User Manual
16
background
Unlock Remotely
On the main page or on the live view page, tap
to unlock the door.
Playback
On the Live View page, tap ... → Playback to playback the videos stored in
the TF card.
Figure 6-3 Playback
Synchronize Time
On the Live View page, tap ... Sengs , you can set the me of doorbell.
Tap Time Zone to select the right me zone.
Tap Date Format to change the format.
Video Intercom Vandal-Resistant Doorbell User Manual
17
background
Alarm Nocaon
On the Live View page, tap ... Sengs Nocaon , slide the slider to
enable alarm nocaon.
Tap Draw Moon Detecon Area and select area. Tap
to save.
Figure 6-4 Draw Moon Detecon Area
Tap Moon Detecon Sensivity to adjust the sensivity.
Video Intercom Vandal-Resistant Doorbell User Manual
18
background
Figure 6-5 Moon Detecon Sensivity
Volume
On the Live View page, tap ... Sengs , you can adjust the Loudspeaker
Volume and Microphone Volume.
Note
Loudspeaker volume and microphone volume can be set from 0 to 10.
Nocaon
On the home page of the client, tap Nocaon to get or edit alarm
messages.
Video Intercom Vandal-Resistant Doorbell User Manual
19
background
Note
The messages will be pushed automacally by enabling Receive Events
and Push Nocaons.
The client can receive the triggered alarm automacally when the
doorbell is powered on by Receive Events but NOT Push Nocaons.
Share Account
On the main page, tap
to share the informaon to other accounts. Or on
the live view page, tap ... → Share to share.
Note
Up to 4 accounts can be added to share.
Video Intercom Vandal-Resistant Doorbell User Manual
20
background
7 Remote Conguraon via Web
7.1 Live View
In the browser address bar, enter the IP address of the device, and press the Enter
key to enter the login page.
Enter the user name and password and click Login to enter the Live View page. Or
you can click Live View to enter the page.
Figure 7-1 Live View
You can start/stop live view, capture, record, audio on/o, two-way audio, etc.
The stream type can be set as main stream or sub stream.
For IE (Internet Explorer) users, the device support two-way audio
communicaon.
7.2 Query
Click Search to enter the page.
Input the Employee ID, Name and Card No.. Select Start Time, End Time and click
Search, the informaon will display on the page.
7.3 User Management
You can add, delete or search the informaon of the user.
Click User to enter the sengs page.
Video Intercom Vandal-Resistant Doorbell User Manual
21
background
Click Add and enter the username, oor No. and room No. to add.
Check the box of the user and click Delete to delete the selected user.
Enter the keyword and click Search. The informaon will display in the list.
7.4 Parameters Sengs
Click Conguraon to set the parameters of the device.
Remote conguraon in iVMS-4200 and Batch Conguraon Tool is the same as that
in Web. Here takes the conguraon in web for example.
Note
Run the browser, click → Internet Opons → Security to disable the Protected
Mode.
7.4.1 Local Parameters Sengs
You can congure the parameters of the live view, record les and captured pictures.
The record les and captured pictures are the ones you record and capture by using
the web browser. You can also set and view the saving paths of the captured pictures
and recorded videos on the PC that running the web browser.
Live View Parameters
Stream Type
Set the stream type as Main Stream or Sub-stream.
Play Performance
Set the live view performance to Shortest Delay, Balanced or Fluent.
Auto Start Live View
Check Yes to enable the funcon.
Image Format
Select the image format for picture capture.
Click Save to enable the sengs.
Record File Parameters
Record File Size
Video Intercom Vandal-Resistant Doorbell User Manual
22
background
Select the packed size of the manually recorded and downloaded video
les to 256M, 512M or 1G. Aer the selecon, the maximum record le
size is the value you selected.
Save record les to
Set the saving path for the manually recorded video les.
Click Save to enable the sengs.
Picture and Clip Sengs
Save snapshots in live view to
Set the saving path of the manually captured pictures in live view mode.
Note
You can click Browse to change the directory for saving the clips and
pictures, and click Open to open the set folder of clips and picture saving.
Click Save to enable the sengs.
7.4.2 System Sengs
Follow the instrucons below to congure the system sengs, include System
Sengs, Maintenance, Security, and User Management, etc.
Click System to enter the sengs page.
Basic Informaon
Click System Sengs → Basic Informaon to enter the sengs page. On
the page, you can edit Device Name and Device No. Set the Language and
System Type according to your needs.
Click Save to enable the sengs.
Time Sengs
Click System Sengs → Time Sengs to enter the sengs page. Select the
Time Zone of your locaon from the drop-down list.
Video Intercom Vandal-Resistant Doorbell User Manual
23
background
Enable NTP, set the Server Address, NTP Port and Interval.
Enable Manual Time Sync., set the me manually or check the Sync.
with computer me.
Click Save to enable the sengs.
DST
Click System Sengs → DST to enable DST. Set the parameters according to
your needs and click Save to enable the sengs.
Maintenance
Click Maintenance → Upgrade & Maintenance to enter the sengs page.
Figure 7-2 Maintenance
Reboot: Click Reboot to reboot the device.
Restore
Click Restore to reset all the parameters, except the IP parameters
and user informaon, to the default sengs.
Default
Click Default to restore all parameters to default sengs.
Export parameters:
1. Click Device Parameters to pop up the dialog box.
2. Set and conrm the encrypon password.
3. Click OK to export parameters.
Import Cong. File:
1. Click Browse to select the conguraon le.
Video Intercom Vandal-Resistant Doorbell User Manual
24
background
2. Click Import and enter the encrypon password to import.
Upgrade: Click Browse to select the upgrade le.
Note
The upgrading process will last 1 to 10 minutes, do not power o during
the upgrading. The device reboots automacally aer upgrading.
User Management
Click User Management to enter the sengs page.
Administrator can edit the permission for the users.
Note
We highly recommend you to create a strong password of your own
choosing (using a minimum of 8 characters, including at least three kinds of
following categories: upper case leers, lower case leers, numbers, and
special characters) in order to increase the security of your product. And we
recommend you change your password regularly, especially in the high
security system, changing the password monthly or weekly can beer
protect your product.
Online Users
Click User Management → Online Users to enter the page.
Figure 7-3 Online Users
Click Refresh to get the present informaon.
Arming/Disarming Informaon
Click User Management → Arming/Disarming Informaon to view the
informaon. Click Refresh to get the present informaon.
Video Intercom Vandal-Resistant Doorbell User Manual
25
background
7.4.3 Network Sengs
TCP/IP Sengs
TCP/IP sengs must be properly congured before you operate the device over
network. The device supports IPv4.
Steps
1.
Click Network → Basic Sengs → TCP/IP to enter the sengs page.
Figure 7-4 TCP/IP Sengs
2.
Congure the network parameters.
-
Check DHCP, the device will get the parameters automacally.
-
Set the IPv4 Address, IPv4 Subnet Mask and IPv4 Default Gateway
manually.
3.
Congure the DNS server.
Video Intercom Vandal-Resistant Doorbell User Manual
26
background
4. Click Save to enable the sengs.
Port Sengs
Steps
1.
Click Network → Basic Sengs → Port to enter the sengs page.
Figure 7-5 Port Sengs
2.
Set the ports of the device.
HTTP Port
The default port number is 80, and it can be changed to any port No. which
is not occupied.
HTTPS Port
The default port number is 443, and it can be changed to any port No. which
is not occupied.
RTSP Port
The default port number is 554.
Server Port
The default server port number is 8000, and it can be changed to any port
No. ranges from 2000 to 65535.
SIP Server Port
The default port number is 5065, and it can be changed to any port No.
which is not occupied.
3.
Click Save to enable the sengs.
SIP Seng
Video Intercom Vandal-Resistant Doorbell User Manual
27
background
Steps
1. Click Network → Basic Sengs → SIP to enter the sengs page.
Figure 7-6 SIP Sengs
2.
Check Enable VOIP Gateway.
3. Congure the SIP parameters.
4.
Click Save to enable the sengs.
FTP Sengs
Steps
1.
Click Network → Advanced → FTP to enter the sengs page.
Video Intercom Vandal-Resistant Doorbell User Manual
28
background
Figure 7-7 FTP Sengs
2.
Check Enable FTP.
3.
Select Server Type.
4.
Input the Server IP Address and Port.
5.
Congure the FTP Sengs, and the user name and password are required for the
server login.
6.
Set the Directory Structure, Parent Directory and Child Directory.
7.
Set the picture naming rules.
8.
Click Save to enable the sengs.
Video Intercom Vandal-Resistant Doorbell User Manual
29
background
Ezviz Sengs
Steps
1.
Click Network → Advanced → Ezviz to enter the sengs page.
Figure 7-8 Ezviz Sengs
2.
Check the checkbox of Enable to enable the funcon.
3.
Select the Plaorm Access Mode.
Note
Hik-Connect is an applicaon for mobile devices. With the App, you can view live
image of the device, receive alarm nocaon and so on.
4.
Create a Stream Encrypon/Encrypon for the device.
Note
6 to 12 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are
recommended to use a combinaon of no less than 8 leers or numbers.
5.
Click Save to enable the sengs.
7.4.4 Video & Audio Sengs
Video Parameters
Video Intercom Vandal-Resistant Doorbell User Manual
30
background
Steps
1. Click Video/Audio → Video to enter the sengs page.
Figure 7-9 Video Parameters
2.
Select the Stream Type.
3.
Congure the video parameters.
Stream Type
Select the stream type to main stream or sub stream.
Video Type
Select the stream type to video stream, or video & audio composite stream.
The audio signal will be recorded only when the Video Type is Video &
Audio.
Resoluon
Select the resoluon of the video output.
Bitrate Type
Video Intercom Vandal-Resistant Doorbell User Manual
31
background
Select the bitrate type to constant or variable.
Video Quality
When bitrate type is selected as Variable, 6 levels of video quality are
selectable.
Frame Rate
Set the frame rate. The frame rate is to describe the frequency at which the
video stream is updated and it is measured by frames per second (fps). A
higher frame rate is advantageous when there is movement in the video
stream, as it maintains image quality throughout.
Max. Bitrate
Set the max. bitrate from 32 to 16384 Kbps. The higher value corresponds to
the higher video quality, but the beer bandwidth is required.
Video Encoding
The device supports H.264.
I Frame Interval
Set I Frame Interval from 1 to 400.
Audio Encoding
The device support G.711ulaw.
4.
Click Save to enable the sengs.
Audio Parameters
Steps
1.
Click Video/Audio → Audio to enter the sengs page.
2.
Adjust the Input Volume, Output Volume and Speak Volume.
Note
Available range of volume: 0 to 10.
3.
Click Save to enable the sengs.
7.4.5 Image Sengs
Display Sengs
Video Intercom Vandal-Resistant Doorbell User Manual
32
background
Congure the image adjustment, backlight sengs and other parameters in display
sengs.
Steps
1. Click Image → Display Sengs to enter the display sengs page.
Figure 7-10 Display Sengs
2.
Select the Format.
3.
Set the display parameters.
WDR
Wide Dynamic Range can be used when there is a high contrast of the bright
area and the dark area of the scene.
Brightness
Brightness describes bright of the image, which ranges from 1 to 100.
Contrast
Contrast describes the contrast of the image, which ranges from 1 to 100.
Saturaon
Saturaon describes the colorfulness of the image color, which ranges from 1
to 100.
Sharpness
Sharpness describes the edge contrast of the image, which ranges from 1 to
100.
4.
Set the Day/Night Mode.
Video Intercom Vandal-Resistant Doorbell User Manual
33
background
Figure 7-11 Day/Night Mode
-
Set Day Mode or Night Mode manually.
-
Set the mode as Auto and edit the sensivity according to your needs.
-
Set the mode as Scheduled-Switch. Set the start me and end me.
Note
Dayme is from congured start me to congured me. The rest of the me is
set as night by default.
5.
Set the backlight parameters.
Video Intercom Vandal-Resistant Doorbell User Manual
34
background
Figure 7-12 Backlight
1) Check the checkbox to enable BLC.
2) Select BLC Area.
6. Click Save to enable the sengs.
OSD Sengs
You can customize the camera name, me/date format, display mode, and OSD size
displayed on the live view.
Steps
1.
Click Image → OSD Sengs to enter the sengs page.
2.
Check the corresponding checkbox to select the display of camera name, date or
week if required.
3. Edit the Camera Name.
4.
Select from the drop-down list to set the Time Format and Date Format.
5.
Adjust the OSD posion.
6.
Click Save to enable the sengs.
7.4.6 Event Sengs
Video Intercom Vandal-Resistant Doorbell User Manual
35
background
Moon Detecon
Moon detecon detects the moving objects in the congured surveillance area,
and a series of acons can be taken when the alarm is triggered.
Steps
1.
Click Event Moon to enter the sengs page.
Figure 7-13 Moon Detecon
2.
Check Enable Moon Detecon to enable the funcon.
3.
Click Draw Area. Click and drag the mouse on the live video to draw a moon
detecon area. Click Stop Drawing to nish drawing one area. Click Save to save
the sengs.
Clear Area Click Clear All to clear all of the areas.
Adjust Sensivity Move the slider to set the sensivity of the detecon.
4.
Click Arming Schedule to edit the arming schedule.
Video Intercom Vandal-Resistant Doorbell User Manual
36
background
5. Click on the me bar and drag the mouse to select the me period. Click Save to
save the sengs.
Delete Schedule Click Delete to delete the current arming schedule.
6.
Click Linkage Method to enable the linkages.
Nofy Surveillance Center
Send an excepon or alarm signal to the remote management soware
when an event occurs.
7.
Click Save to enable the sengs.
Access Control Events
Steps
1.
Click Event → Basic Event → Access Control Event to enter the sengs page.
Video Intercom Vandal-Resistant Doorbell User Manual
37
background
Figure 7-14 Access Control Event
2.
Select the Major Type as Device Event or Door Event.
3.
Select the type of the Normal Linkage for the event.
4.
Click Save to enable the sengs.
7.4.7 Intercom Sengs
Device ID Conguraon
Video Intercom Vandal-Resistant Doorbell User Manual
38
background
Steps
1. Click Device ID Sengs to enter the page.
Figure 7-15 Device ID Sengs
2.
Select the device type from the drop-down list, and set the corresponding
informaon.
3.
Click Save to enable the device number conguraon.
Note
For main door staon (D series or V series), the serial No. is 0.
For sub door staon (D series or V series), the serial No. cannot be 0. Serial
No. ranges from 1 to 99.
For each villa or building, at least one main door staon (D series or V series)
should be congured, and one sub door staons (D series or V series) can be
customized.
For one main door staon (D series or V series), up to 8 sub door staons
can be congured.
Linked Network Sengs
Steps
1.
Click Intercom → Linked Network Sengs to enter the sengs page.
Video Intercom Vandal-Resistant Doorbell User Manual
39
background
Figure 7-16 Linked Network Sengs
2.
Set the master staon IP address and master staon SIP cllient Port.
3.
Set the private SIP server IP address and private SIP Server Port.
4.
Set the SIP Client Port.
5.
Enter the password.
6.
Click Save to enable the sengs.
Time Parameters
Click Intercom → Time Parameters to enter the page.
Congure the me parameters and click Save.
Note
Maximum speaking me varies from 90s to 120s, and maximum message me varies
from 30s to 60s.
Intercom Protocol
Slide to enable protocol 1.0.
Video Intercom Vandal-Resistant Doorbell User Manual
40
background
Ring-Back Tone Sengs
Click Intercom → Ringbacktone Sengs to enter the sengs page.
Click Add to select the ring tone from PC.
Note
Available Audio Format: WAVAAC, Size: Less than 600 KB, Sample Rate: 8000Hz,
Mono.
Press Buon to Call
Steps
1.
Click Intercom → Press Buon to Call to enter the sengs page.
2.
Set the parameters.
-
Edit call No. for every buon.
-
Check Call Management Center to set the buon calling center.
Note
If you check Call Management Center and set the call No. as well, call
management center has higher privilege than call No.
I/O Sengs
Steps
1.
Click Intercom → I/O Sengs to enter the I/O input and output sengs page.
2.
Select I/O input No., input mode, output No., and output mode.
3.
Click Save to enable the sengs.
Note
For door staon, there are 4 I/O input terminals. By default, Terminal 1 and 2
correspond to Door Status. Terminal 3 and 4 correspond to interfaces of
Door Switch.
For door staon, there are 2 I/O Output Terminals. Terminal 1 and 2
correspond to Door interfaces (NO1/COM/NC1; NO2/COM/NC2) of door
staon. Door 1 is enabled by default. You can enable/disable IO Out
according to needs.
Video Intercom Vandal-Resistant Doorbell User Manual
41
background
7.4.8 Access Control Sengs
Door Parameters
Steps
1.
Click Access Control → Door Parameters to enter the sengs page.
Figure 7-17 Door Parameters
2.
Select the door and edit the door name.
3.
Set door contact status.
4.
Set lock acon me.
5. Click Save to enable the sengs.
Elevator Control
Before You Start
Make sure your door staon is in the mode of main door staon. Only the main
door staon support elevator control funcon.
Make sure your door staon has been connected to the elevator controller via
RS-485 wire if you want to use RS-485 interface.
Steps
1.
Click Access Control → Elevator Control to enter the corresponding
conguraon page.
Video Intercom Vandal-Resistant Doorbell User Manual
42
background
Figure 7-18 Elevator Control
2.
Check to enable elevator control funcon.
3.
Select an Elevator No., and select an elevator controller type for the elevator.
4.
Set the Negave Floor.
5.
Select the Interface Type as RS-485 or Network Interface. And enable the
elevator control.
-
If you select RS-485, make sure you have connected the door staon to the
elevator controller with RS-485 wire.
-
If you select Network interface, enter the elevator controller's IP address,
port No., user name, and password.
6.
Click Save to enable the sengs.
Note
Up to 4 elevator controllers can be connected to one door staon.
Up to 10 negave oors can be added.
Make sure the interface types of elevator controllers, which are connected
to the same door staon are consistent.
Video Intercom Vandal-Resistant Doorbell User Manual
43
background
7.5 Number Sengs
Link the room No. and SIP numbers.
Click Number Sengs to enter the page.
Click Add, set the Room No. and SIP numbers in the pop-up dialog box.
7.6 Device Management
You can manage the linked device on the page.
Click Device List to enter the sengs page.
Add Device
Click Add to add the indoor staon or sub door staon. Enter the
parameters and click OK to add.
Click Import. Enter the informaon of the device in the template to
import devices in batch.
Export
Click Export to export the informaon to the PC.
Upgrade
Click Upload Package to select the upgrade package.
Click Timing Upgrading, slide Enable auto-upgrade to set the start me
and end me. The device will upgrade from start me to end me
automacally.
Click Upgrading Status to view the version fo the device.
Video Intercom Vandal-Resistant Doorbell User Manual
44
background
A. Appendix
Installaon Noce
While installing the doorbell, make sure that the distance between any two
devices is far enough to avoid the howling and echo. The distance between
two devices is recommended to be longer than 10 meters.
Note
Devices menoned here refer to indoor staon, door staon and master
staon.
Wiring Cables
Cable Specicaon
Power Cord of Doorbell RVV 2*1.0
Network Cable of Doorbell UTP-ve Categories
Door Lock Wiring (with Door Contact) RVV 4*1.0
Door Lock Wiring (without Door Contact) RVV 2*1.0
Exit Buon Wiring RVV 2*0.5
Video Intercom Vandal-Resistant Doorbell User Manual
45
background
B. Communicaon Matrix and Device
Command
Communicaon Matrix
Scan the following QR code to get the device communicaon matrix.
Note that the matrix contains all communicaon ports of Hikvision access
control and video intercom devices.
Figure B-1 QR Code of Communicaon Matrix
Device Command
Scan the following QR code to get the device common serial port
commands.
Note that the command list contains all commonly used serial ports
commands for all Hikvision access control and video intercom devices.
Figure B-2 Device Command
Video Intercom Vandal-Resistant Doorbell User Manual
46
background
UD18948B

Specifications

Indexed Terms: Doorbell, Vandal Resistant

Hikvision DS-KB8113-IME1 Questions and Answers
