DS-K1A340 Series Face Recognion Terminal
User Manual
Legal Informaon
©2021 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DS-K1A340 Series Face Recognion Terminal User Manual
i
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Data Protecon
During the use of device, personal data will be collected, stored and processed. To protect data,
the development of Hikvision devices incorporates privacy by design principles. For example, for
device with facial recognion features, biometrics data is stored in your device with encrypon
method; for ngerprint device, only ngerprint template will be saved, which is impossible to
reconstruct a ngerprint image.
As data controller, you are advised to collect, store, process and transfer data in accordance with
the applicable data protecon laws and regulaons, including without limitaon, conducng
security controls to safeguard personal data, such as, implemenng reasonable administrave and
physical security controls, conduct periodic reviews and assessments of the eecveness of your
security controls.
DS-K1A340 Series Face Recognion Terminal User Manual
ii
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
DS-K1A340 Series Face Recognion Terminal User Manual
iii
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference in a residenal installaon. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instrucons, may cause harmful interference to radio communicaons. However, there is
no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television recepon, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
DS-K1A340 Series Face Recognion Terminal User Manual
iv
under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve
2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
DS-K1A340 Series Face Recognion Terminal User Manual
v
Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
The precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury or death.
Cauons: Neglecng any of the cauons may cause injury or equipment damage.
Dangers: Follow these safeguards to prevent
serious injury or death.
Cauons: Follow these precauons to prevent
potenal injury or material damage.
Danger:
●
In the use of the product, you must be in strict compliance with the electrical safety regulaons
of the naon and region.
●
Do not connect several devices to one power adapter as adapter overload may cause over-heat
or re hazard.
●
If smoke, odors or noise rise from the device, turn o the power at once and unplug the power
cable, and then please contact the service center.
●
The socket-outlet shall be installed near the equipment and shall be easily accessible.
●
1. Do not ingest baery. Chemical burn hazard!
2. This product contains a coin/buon cell baery. If the coin/buon cell baery is swallowed, it
can cause severe internal burns in just 2 hours and can lead to death.
3. Keep new and used baeries away from children.
4. If the baery compartment does not close securely, stop using the product and keep it away
from children.
5. If you think baeries might have been swallowed or placed inside any part of the body, seek
immediate medical aenon.
6. CAUTION: Risk of explosion if the baery is replaced by an incorrect type.
7. Improper replacement of the baery with an incorrect type may defeat a safeguard (for
example, in the case of some lithium baery types).
8. Do not dispose of the baery into re or a hot oven, or mechanically crush or cut the baery,
which may result in an explosion.
9. Do not leave the baery in an extremely high temperature surrounding environment, which
may result in an explosion or the leakage of ammable liquid or gas.
10. Do not subject the baery to extremely low air pressure, which may result in an explosion or
the leakage of ammable liquid or gas.
11. Dispose of used baeries according to the instrucons.
DS-K1A340 Series Face Recognion Terminal User Manual
vi
Cauons:
●
Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
●
Do not place the device in extremely hot (refer to the specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
●
Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
●
The device cover for indoor use shall be kept from rain and moisture.
●
Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
●
Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
●
Biometric recognion products are not completely applicable to an-spoong environments.
If you require a higher security level, use mulple authencaon modes.
●
The serial port of the equipment is used for debugging only.
●
Install the equipment according to the instrucons in this manual. To prevent injury, this
equipment must be securely aached to the oor/wall in accordance with the installaon
instrucons.
●
Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the baery manufacturer.
●
This bracket is intended for use only with equipped devices. Use with other equipment may
result in instability causing injury.
●
This equipment is for use only with equipped bracket. Use with other (carts, stands, or carriers)
may result in instability causing injury.
DS-K1A340 Series Face Recognion Terminal User Manual
vii
Available Models
Product Name Model
Face Time and Aendance Terminal DS-K1A340X
DS-K1A340FX
DS-K1A340FWX
DS-K1A340WX
Use only power supplies listed in the user instrucons:
Model Manufacturer Standard
ADS-12FG-12N 12012EPG Shenzhen Honor Electronic Co.,
Ltd
PG
DS-K1A340 Series Face Recognion Terminal User Manual
viii
Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Overview ................................................................................................................................ 1
1.2 Features ................................................................................................................................. 1
Chapter 2 Appearance ................................................................................................................ 2
Chapter 3 Installaon ................................................................................................................. 4
3.1 Installaon Environment ........................................................................................................ 4
3.2 Base Mounng ....................................................................................................................... 4
3.3 Install with Gang Box ............................................................................................................. 5
Chapter 4 Device Wiring ............................................................................................................. 9
Chapter 5 Acvate via Device ................................................................................................... 10
Chapter 6 Quick Operaon ....................................................................................................... 12
6.1 Select Language ................................................................................................................... 12
6.2 Set Applicaon Mode .......................................................................................................... 13
6.3 Set Network Parameters ...................................................................................................... 13
6.4 Access to Plaorm ............................................................................................................... 14
6.5 Link to Mobile Client ............................................................................................................ 15
6.6 Privacy Sengs .................................................................................................................... 16
6.7 Set Administrator ................................................................................................................. 17
Chapter 7 Basic Operaon ........................................................................................................ 20
7.1 Login .................................................................................................................................... 20
7.1.1 Login by Administrator ................................................................................................ 20
7.1.2 Login by Acvaon Password ...................................................................................... 21
7.1.3 Forget Password .......................................................................................................... 22
7.2 Communicaon Sengs ...................................................................................................... 23
7.2.1 Set Wi-Fi Parameters ................................................................................................... 23
7.2.2 Plaorm Access ........................................................................................................... 24
DS-K1A340 Series Face Recognion Terminal User Manual
ix
7.3 Local Time and Aendance .................................................................................................. 24
7.3.1 Aendance Process Descripon ................................................................................. 24
7.3.2 Department Management .......................................................................................... 24
7.3.3 User Management ...................................................................................................... 25
7.3.4 Shi Management ...................................................................................................... 30
7.3.5 Manage Holiday (Add/Edit/Delete) ............................................................................. 35
7.3.6 Shi Schedule ............................................................................................................. 35
7.4 Time and Aendance Status Sengs .................................................................................. 38
7.4.1 Disable Aendance Mode via Device ......................................................................... 38
7.4.2 Set Manual Aendance via Device ............................................................................. 39
7.4.3 Set Auto Aendance via Device .................................................................................. 40
7.4.4 Set Manual and Auto Aendance via Device .............................................................. 41
7.5 Data Management ............................................................................................................... 43
7.5.1 Export Aendance Template ...................................................................................... 43
7.5.2 Export Aendance Summary Table/Abnormal Aendance Table/Aendance Card
Report Table ......................................................................................................................... 43
7.5.3 Import Face Picture ..................................................................................................... 44
7.5.4 Export User Data/Access Control Parameters ............................................................. 45
7.6 Identy Authencaon ........................................................................................................ 45
7.6.1 Authencate via Single Credenal .............................................................................. 45
7.6.2 Authencate via Mulple Credenal .......................................................................... 46
7.7 Basic Sengs ....................................................................................................................... 46
7.8 Set Biometric Parameters .................................................................................................... 48
7.9 System Maintenance ............................................................................................................ 49
Chapter 8 Congure the Device via the Mobile Browser ........................................................... 52
8.1 Login .................................................................................................................................... 52
8.2 Search Event ........................................................................................................................ 52
8.3 Conguraon ....................................................................................................................... 52
DS-K1A340 Series Face Recognion Terminal User Manual
x
8.3.1 View Device Informaon ............................................................................................. 52
8.3.2 Time Sengs ............................................................................................................... 54
8.3.3 Set DST ........................................................................................................................ 55
8.3.4 View Open Source Soware License ........................................................................... 57
8.3.5 Network Sengs ......................................................................................................... 57
8.3.6 Set Time and Aendance via Mobile Web Browser .................................................... 59
8.3.7 General Sengs .......................................................................................................... 67
8.3.8 Face Parameters Sengs ............................................................................................ 69
Chapter 9 Operaon via Web Browser ...................................................................................... 72
9.1 Login .................................................................................................................................... 72
9.2 Person Management ............................................................................................................ 72
9.3 Search Event ........................................................................................................................ 73
9.4 Conguraon ....................................................................................................................... 74
9.4.1 Set Local Parameters ................................................................................................... 74
9.4.2 View Device Informaon ............................................................................................. 74
9.4.3 Set Time ...................................................................................................................... 74
9.4.4 Set DST ........................................................................................................................ 75
9.4.5 View Open Source Soware License ........................................................................... 75
9.4.6 Upgrade and Maintenance ......................................................................................... 75
9.4.7 Security Mode Sengs ............................................................................................... 76
9.4.8 Cercate Management ............................................................................................. 76
9.4.9 Object Missing ............................................................................................................ 78
9.4.10 Online Users .............................................................................................................. 78
9.4.11 View Device Arming/Disarming Informaon ............................................................ 78
9.4.12 Network Sengs ....................................................................................................... 78
9.4.13 Set Video and Audio Parameters .............................................................................. 81
9.4.14 Customize Audio Content ......................................................................................... 81
9.4.15 Time and Aendance Sengs .................................................................................. 83
DS-K1A340 Series Face Recognion Terminal User Manual
xi
9.4.16 General Sengs ........................................................................................................ 85
9.4.17 Title: Local Time and Aendance Sengs ................................................................ 88
9.4.18 Set Biometric Parameters ......................................................................................... 93
9.4.19 Set Theme ................................................................................................................. 95
Chapter 10 Client Soware Conguraon ................................................................................. 97
10.1 Conguraon Flow of Client Soware ............................................................................... 97
10.2 Device Management .......................................................................................................... 97
10.2.1 Add Device ................................................................................................................ 98
10.2.2 Reset Device Password ........................................................................................... 100
10.2.3 Manage Added Devices .......................................................................................... 101
10.3 Group Management ......................................................................................................... 102
10.3.1 Add Group ............................................................................................................... 102
10.3.2 Import Resources to Group ..................................................................................... 102
10.4 Person Management ........................................................................................................ 103
10.4.1 Add Organizaon .................................................................................................... 103
10.4.2 Import and Export Person Idenfy Informaon ...................................................... 104
10.4.3 Get Person Informaon from Access Control Device .............................................. 106
10.4.4 Issue Cards to Persons in Batch ............................................................................... 107
10.4.5 Report Card Loss ..................................................................................................... 107
10.4.6 Set Card Issuing Parameters .................................................................................... 108
10.5 Congure Schedule and Template ................................................................................... 109
10.5.1 Add Holiday ............................................................................................................. 109
10.5.2 Add Template .......................................................................................................... 110
10.6 Set Access Group to Assign Access Authorizaon to Persons .......................................... 111
10.7 Congure Advanced Funcons ........................................................................................ 113
10.7.1 Congure Device Parameters .................................................................................. 114
10.7.2 Congure Device Parameters .................................................................................. 119
10.8 Door Control .................................................................................................................... 121
DS-K1A340 Series Face Recognion Terminal User Manual
xii
10.8.1 Control Door Status ................................................................................................. 122
10.8.2 Check Real-Time Access Records ............................................................................ 123
Appendix A. Tips for Installaon Environment ........................................................................ 126
Appendix B. Tips for Scanning Fingerprint ............................................................................... 127
Appendix C. Tips When Collecng/Comparing Face Picture .................................................... 129
Appendix D. Aendance Capacity ........................................................................................... 131
Appendix E. Aendance Report Table ..................................................................................... 132
Chapter 11 Dimensions ........................................................................................................... 125
Appendix F. Communicaon Matrix and Device Command ..................................................... 136
DS-K1A340 Series Face Recognion Terminal User Manual
xiii
Chapter 1 Overview
1.1 Overview
Face me and aendance terminal is a kind of access control device for face aendance. Face,
ngerprint and other identy vericaon and are supported. It is mainly applied in high security
access control systems, such as buildings, enterprises, oce buildings, nancial outlets and key
area protecon.
1.2 Features
●
Supports local me aendance and remote me aendance.
●
4.3-inch touch screen
●
2 MP wide-angle dual-lens
●
Face an-spoong
●
Face recognion distance: 0.3 m to 2 m
●
Face recognion duraon < 0.2 s/User; face recognion accuracy rate ≥ 99%
●
Deep learning algorithm
●
1,500 face capacity
●
Supports 3000 ngerprints (supported by some models) and store 300,000 aendance records
●
Supports face, ngerprint, face or ngerprint or pin code, face + ngerprint, face + pin code,
ngerprint + pin code, face + ngerprint + pin code authencaon methods
Note
Some devices support ngerprint authencaon. Refers to the actual device for details.
●
Export pictures, events, from the device to the USB ash drive
●
Manage, search and set device data aer logging in the device locally
●
Supports ll-in light funcon. The interface of the device is automacally brightened at night
●
Supports long press the increase or decrease icon in the me dialog box to quickly increase or
decrease the me period for modifying the schedule sengs.
DS-K1A340 Series Face Recognion Terminal User Manual
1
Chapter 2 Appearance
Figure 2-1 Appearance（With Fingerprint)
Figure 2-2 Appearance（Without Fingerprint)
Table 2-1 Appearance Descripon
No. Name
1 Loudspeaker
2 USB Interface
3 Touch Screen
DS-K1A340 Series Face Recognion Terminal User Manual
2
No. Name
4 IR Light
5 Camera
6 Camera
7 IR Light
8 Fingerprint Module
Note
Only devices that support the ngerprint funcon contain a
ngerprint module.
9 Power Interface
10 Debugging Port 2
11 Debugging Port 1
Note
The device requires special hardware to connect to the network.
DS-K1A340 Series Face Recognion Terminal User Manual
3
Chapter 3 Installaon
3.1 Installaon Environment
●
Install the device at least 2 meters away from the light, and at least 3 meters away from the
window or the door.
●
Make sure the environment illuminaon is more than 100 Lux.
Note
For details about installaon environment, see Tips for Installaon Environment.
3.2 Base Mounng
Steps
1.
Route the cables through the cable hole of the bracket, and connect the terminals with
peripherals cables. Place the bracket close to the back side of the device.
Figure 3-1 Place Bracket Close to Device Back Side
2.
Press the bracket with both hands, and make sure that the buckle of the bracket ts with the
back side of the device. Fasten the bracket in the direcon of the arrow.
DS-K1A340 Series Face Recognion Terminal User Manual
4
Figure 3-2 Fasten Bracket
3.
Buckle into the bracket to the end to complete the installaon.
Figure 3-3 Complete Installaon
3.3 Install with Gang Box
Steps
1.
Make sure the gang box is installed on the wall.
Note
You should purchase the gang box separately.
DS-K1A340 Series Face Recognion Terminal User Manual
5
Figure 3-4 Install Gang Box
2.
Use 4 supplied screws (M4) to secure the mounng plate on the gang box.
DS-K1A340 Series Face Recognion Terminal User Manual
6
Figure 3-5 Install Mounng Plate
3.
Route the cables through the cable hole of the mounng plate, and connect to the
corresponding peripherals cables.
4.
Buckle into the mounng plate aer aligning the device with the mounng plate. Use 1 supplied
screw (M3) to secure the device on the mounng plate.
DS-K1A340 Series Face Recognion Terminal User Manual
7
Figure 3-6 Secure Device
DS-K1A340 Series Face Recognion Terminal User Manual
8
Chapter 4 Device Wiring
Connect the device to the power supply with the supplied power cable.
Figure 4-1 Device Wiring
DS-K1A340 Series Face Recognion Terminal User Manual
9
Chapter 5 Acvate via Device
If the device is not acvated, you can acvate the device aer it is powered on.
Aer powing on, you will enter the QR code scanning page. Tap Local. On the Acvate Device page,
create a password and conrm the password. Tap Acvate and the device will acvated.
Figure 5-1 Acvaon Page
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change your
password regularly, especially in the high security system, changing the password monthly or
weekly can beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
●
Aer acvaon, you should select a language according to your actual needs, see Select
Language .
●
Aer acvaon, you should select an applicaon mode. For details, see Set Applicaon Mode .
DS-K1A340 Series Face Recognion Terminal User Manual
10
●
Aer acvaon, if you need to set privacy, you should check the item. For details, see Privacy
Sengs .
●
Aer acvaon, if you need to add administrator to manage the device parameters, you should
set administrator. For details, see Add Administrator .
DS-K1A340 Series Face Recognion Terminal User Manual
11
Chapter 6 Quick Operaon
6.1 Select Language
You can select a language for the device system.
Aer the device acvaon, you can select a language for the device system.
Figure 6-1 Select System Language
By default, the system language is English.
DS-K1A340 Series Face Recognion Terminal User Manual
12
6.2 Set Applicaon Mode
Aer acvang the device, you should select an applicaon mode for beer device applicaon.
Steps
1.
On the Welcome page, select Indoor or Others from the drop-down list.
Figure 6-2 Welcome Page
2.
Tap OK to save.
Note
●
You can also change the sengs in System Sengs.
●
If you install the device indoors near the window or the face recognion funcon is not
working well, select Others.
●
If you do not congure the applicaon mode and tap Next, the system will select Indoor by
default.
●
If you acvate the device via other tools remotely, the system will select Indoor as the
applicaon mode by default.
6.3 Set Network Parameters
Aer acvaon, selecng language and selecng applicaon mode, you can set the network for
the device.
DS-K1A340 Series Face Recognion Terminal User Manual
13
Steps
1.
Select a Wi-Fi and enter the Wi-Fi's password to get connected. Or tap Add Wi-Fi and enter the
Wi-Fi's name and the password to get connected.
Figure 6-3 Select Wi-Fi
2.
Oponal: Tap Skip to skip network sengs.
6.4 Access to Plaorm
Enable the funcon and the device can communicate via Hik-Connect. You can add the device to
Hik-Connect modile client and so on.
Steps
1.
Enable Access to Hik-Connect, and set the server IP address and vericaon code.
DS-K1A340 Series Face Recognion Terminal User Manual
14
Figure 6-4 Access to Hik-Connect
2.
Tap Next.
6.5 Link to Mobile Client
Aer acvaon, selecng language, selecng applicaon mode, selecng network, accessing to
plaorm, you can add the device to the mobile client.
Download and install the mobile client. Use the scan QR code funcon of the mobile client and
scan the QR code displayed on the device to link the device to the mobile client.
Follow the instrucons to link the device to the mobile client.
DS-K1A340 Series Face Recognion Terminal User Manual
15
Figure 6-5 Link to Mobile Client
6.6 Privacy Sengs
Aer acvaon, selecng applicaon mode, and selecng network, you should set the privacy
parameters, including the picture uploading and storage.
Select parameters according to your actual needs.
DS-K1A340 Series Face Recognion Terminal User Manual
16
Figure 6-6 Privacy
Upload Captured Pic. When Auth. (Upload Captured Picture When Authencang)
Upload the pictures captured when authencang to the plaorm automacally.
Save Captured Pic. When Auth. (Save Captured Picture When Authencang)
If you enable this funcon, you can save the picture when Authencang to the device.
Save Registered Pic. (Save Registered Picture)
The registered face picture will be saved to the system if you enable the funcon.
Upload Pic. Aer Linked Capture (Upload Picture Aer Linked Capture)
Upload the pictures captured by linked camera to the plaorm automacally.
Save Pic. Aer Linked Capture (Save Pictures Aer Linked Capture)
If you enable this funcon, you can save the picture captured by linked camera to the device.
Tap Next to complete the sengs.
6.7 Set Administrator
Aer device acvaon, you can add an administrator to manage the device parameters.
Steps
1.
Oponal: Tap Skip to skip adding administrator if not required.
2.
Enter the administrator's name (oponal) and tap Next.
DS-K1A340 Series Face Recognion Terminal User Manual
17
Note
Up to 5 administrators can be added.
Figure 6-7 Add Administrator Page
3.
Select a credenal to add.
Note
Up to one credenal should be added.
-
: Face forward at the camera. Make sure the face is in the face recognion area. Tap to
capture and tap to conrm.
-
: Press your nger according to the instrucons on the device screen. Tap to conrm.
4.
Tap OK.
You will enter the authencaon page.
Status Icon Descripon
/
Device is armed/not armed.
/
Hik-Connect is enabled/disabled.
/ /
The device wired network is connected/not connected/connecng failed.
/ /
DS-K1A340 Series Face Recognion Terminal User Manual
18
Chapter 7 Basic Operaon
7.1 Login
Login the device to set the device basic parameters.
7.1.1 Login by Administrator
If you have added an administrator for the device, only the administrator can login the device for
device operaon.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture to enter
the admin login page.
Figure 7-1 Admin Login
2.
Authencate the administrator's face, ngerprint to enter the home page.
DS-K1A340 Series Face Recognion Terminal User Manual
20
Figure 7-2 Home Page
Note
The device will be locked for 30 minutes aer 5 failed face, or ngerprint aempts.
3.
Oponal: Tap and you can enter the device acvaon password for login.
4.
Oponal: Tap and you can exit the admin login page.
7.1.2 Login by Acvaon Password
You should login the system before other device operaons. If you do not congure an
administrator, you should follow the instrucons below to login.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture to enter
password entering page.
2.
Tap the Password eld and enter the device acvaon password.
3.
Tap OK to enter the home page.
DS-K1A340 Series Face Recognion Terminal User Manual
21
Note
The device will be locked for 30 minutes aer 5 failed password aempts.
Figure 7-3 Home Page
7.1.3 Forget Password
If you forget the password during authencaon, you can reset the password by imprng the key.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in
the page.
2.
Tap
in the pop-up admin authencaon page.
3.
Tap Forget Password in the upper right corner of the page.
4.
Plug USB ash drive into the USB interface.
DS-K1A340 Series Face Recognion Terminal User Manual
22
Note
●
The supported USB ash drive formats are FAT32 and exfat.
●
The device supports 1 G to 32 G (including 1 G and 32 G) USB ash drive. Make sure that the
free space of the USB ash drive is more than 512 M.
5.
Tap Export File, and contact the technician to get the key, and enter the key in the export le.
6.
Tap Import File to import the le with the key to the device.
7.
Follow the prompts to reset the password.
7.2 Communicaon Sengs
Support Wi-Fi, ISUP and remote conguraion via mobile browser.
7.2.1 Set Wi-Fi Parameters
You can enable the Wi-Fi funcon and set the Wi-Fi related parameters.
Steps
Note
The funcon should be supported by the device.
1.
Tap Comm. (Communicaon Sengs) on the Home page to enter the Communicaon Sengs
page.
2.
On the Communicaon Sengs page, tap Wi-Fi.
3.
Enable the Wi-Fi funcon.
4.
Congure the Wi-Fi parameters.
-
Select a Wi-Fi from the list, and enter the Wi-Fi's password. Tap OK.
-
If the target Wi-Fi is not in the list, tap Add Wi-Fi. Enter the Wi-Fi's name and password. And
tap OK.
Note
●
If the mobile phone remote conguraon is enabled, the Wi-Fi funcon will be disabled.
●
Only digits, leers, and special characters are allowed in the password.
5.
Set the Wi-Fi's parameters.
-
By default, DHCP is enable. The system will allocate the IP address, the subnet mask, and the
gateway automacally.
-
If disable DHCP, you should enter the IP address, the subnet mask, and the gateway manually.
6.
Tap OK to save the sengs and go back to the Wi-Fi tab.
7.
Tap
to save the network parameters.
DS-K1A340 Series Face Recognion Terminal User Manual
23
7.2.2 Plaorm Access
You can change the device vericaon code and set the server address before you add the device
to the Hik-Connect mobile client.
Before You Start
Make sure your device has connected to a network.
Steps
1.
Tap Comm. (Communicaon Sengs) on the Home page to enter the Communicaon Sengs
page.
2.
On the Communicaon Sengs page, tap Access to Hik-Connect.
3.
Enable Access to Hik-Connect
4.
Enter Server IP.
5.
Create the Vericaon Code, and you need to enter the vericaon code when you manage the
devices via Hik-Connect.
7.3 Local Time and Aendance
Manage department, shi, holiday, schedule, and report.
You can add, edit, delete department/shi/holiday/schedule. You can also export the aendance
report.
7.3.1 Aendance Process Descripon
Figure 7-4 Aendance Process Descripon
7.3.2 Department Management
You can add, edit and delete the department.
Tap Dept. on the Home page to enter the sengs page.
Add Department
Tap +, enter the department name, and tap OK.
DS-K1A340 Series Face Recognion Terminal User Manual
24
Figure 7-5 Add Department
Note
●
The department name supports uppercase English, lowercase English, numbers and symbols.
●
Up to 32 characters can be entered in department name.
●
There are 7 departments in the department management by default.
Edit Department
Tap the department that needs to be edited, to edit the sengs.
You can edit the department name, and view employee informaon according to your actual
needs.
Delete Department
Tap the department that needs to be deleted.
Tap , and tap OK to delete the department.
7.3.3 User Management
On the user management interface, you can add, edit, delete and search the user.
Add Administrator
The administrator can log in the device and congure the device parameters.
DS-K1A340 Series Face Recognion Terminal User Manual
25
Steps
1.
Long tap on the inial page and log in the backend.
2.
Tap User → + to enter the Add User page.
3.
Edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Tap the Name eld and enter the user name.
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
Up to 32 characters are allowed in the user name.
5.
Select the department.
Note
For details about adding a department, see Manage Department via Mobile Web Browser .
6.
Oponal: Add a face picture, or ngerprints for the administrator.
Note
●
For details about adding a face picture, see Add Face Picture .
●
Note
For details about adding a ngerprint, see Add Fingerprint .
7.
Oponal: Set the administrator's authencaon type.
Note
For details about seng the authencaon type, see Set Authencaon Mode .
8.
Select the User Role.
9.
Tap to save the sengs.
Add Face Picture
Add user's face picture to the device. And the user can use the face picture to authencate.
Steps
Note
Up to 1000 face pictures can be added.
DS-K1A340 Series Face Recognion Terminal User Manual
26
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in
the backend.
2.
Tap User → + to enter the Add User page.
3.
Edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Tap the Name eld and input the user name on the so keyboard.
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 32 characters.
5.
Tap the Face Picture eld to enter the face picture adding page.
Figure 7-6 Add Face Picture
6.
Look at the camera.
Note
●
Make sure your face picture is in the face picture outline when adding the face picture.
●
Make sure the captured face picture is in good quality and is accurate.
●
For details about the instrucons of adding face pictures, see Tips When Collecng/
Comparing Face Picture .
DS-K1A340 Series Face Recognion Terminal User Manual
27
Aer completely adding the face picture, a captured face picture will be displayed at the upper
right corner of the page.
7.
Tap Save to save the face picture.
8.
Oponal: Tap Try Again and adjust your face posion to add the face picture again.
9.
Set the user role.
Administrator
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
10.
Tap to save the sengs.
Add Fingerprint
Add a ngerprint for the user and the user can authencate via the added ngerprint.
Steps
Note
●
The funcon should be supported by the device.
●
Up to 3000 ngerprints can be added.
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and enter
the device backend.
2.
Tap User → + to enter the Add User page.
3.
Tap the Employee ID. eld and edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not start with 0 and should not be duplicated.
4.
Tap the Name eld and input the user name on the so keyboard.
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 32 characters.
5.
Tap the Fingerprint eld to enter the Add Fingerprint page.
6.
Follow the instrucons to add a ngerprint.
DS-K1A340 Series Face Recognion Terminal User Manual
28
Note
●
The same ngerprint cannot be repeatedly added.
●
Up to 10 ngerprints can be added for one user.
●
You can also use the client soware or the ngerprint recorder to record ngerprints.
For details about the instrucons of scanning ngerprints, see Tips for Scanning Fingerprint .
7.
Set the user role.
Administrator
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
8.
Tap to save the sengs.
View PIN code
Add a PIN code for the user and the user can authencate via the PIN code.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in
the backend.
2.
Tap User → + to enter the Add User page.
3.
Tap the Employee ID. eld and edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Tap the Name eld and input the user name on the so keyboard.
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 32 characters.
5.
Tap the PIN code to view the PIN code.
Note
The PIN code cannot be edited. It can only be applied by the plaorm.
6.
Set the user role.
Administrator
DS-K1A340 Series Face Recognion Terminal User Manual
29
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
7.
Tap to save the sengs.
Set Authencaon Mode
Aer adding the user's face picture, PIN code, or other credenals, you should set the
authencaon mode and the user can authencate his/her identy via the congured
authencaon mode.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in
the backend.
2.
Tap User → Add User/Edit User → Authencaon Mode .
3.
Select the authencaon mode.
Custom
You can combine dierent authencaon modes together according to your actual needs.
4.
Tap to save the sengs.
Search and Edit User
Aer adding the user, you can search the user and edit it.
Search User
On the User Management page, Tap the search area to enter the Search User page. Enter the
employee ID, or the user name for searching. Tap to search.
Edit User
On the User Management page, select a user from the user list to enter the Edit User page. Follow
the steps in
User Management to edit the user parameters. Tap to save the sengs.
Note
The employee ID cannot be edited.
7.3.4 Shi Management
The normal shi and the man-hour shi are available to be congured.
DS-K1A340 Series Face Recognion Terminal User Manual
30
●
Normal Shi: It is applicable to the normal aendance situaon. You can set the aendance rule
and the aendance checking mes in the normal shi.
●
Man-Hour Shi: It is applicable to the situaon with exible working hours.
Note
Up to 256 shis can be added.
Set Aendance Rule for Normal Shi
Set aendance rule before seng normal shi.
Tap Local T&A → Shi Management → Normal Shi Management → Aendance Rule to enter
the page.
Figure 7-7 Aendance Rule
Set the aendance rule, including Advanced Check In Time, Latest Check In Time, Absence Time
(Late), Earliest Check Out Time, Latest Check Out Time and Absence Time (Early Leave). Aer
entering the duraon, tap OK to save the sengs.
Take the following picture as an example to describe the rules.
DS-K1A340 Series Face Recognion Terminal User Manual
31
Figure 7-8 Aendance Rule Example
Advanced Check In Time
Set the earliest check in me. For example, if set the on work me as 8:00, and set the
parameter as 10 min, the earliest check in me will be 7:50. Checking in at and earlier than 7:49
will be marked as invalid.
Note
By default, if set as 0 min, the valid check in me starts from 00:00.
Latest Check In Time
Set the latest check in me. For example, if set the on work me as 8:00, and set the parameter
as 10 min, the latest check in me will be 8:10. Checking in at and later than 8:11 will be marked
as late or absence.
Late Time
The late me is N min aer the latest check in me. For example, if set the latest check in me
as 8:10, and set the parameter as 60 min, checking in at and later than 9:11 will be marked as
absence. 8:10 to 9:10 will be marked as late.
Earliest Check Out Time
Set the earliest check out me. For example, set the o work me as 17:30 and set the
parameter as 10 min, the earliest check out me will be 17:20. Checking out at or earlier than
17:19 will be marked as invalid.
Latest Check Out Time
Set the latest check out me. For example, set the o work me as 17:30 and set the parameter
as 30 min, the latest check out me will be 18:00. Checking out at or later than 18:01 will be
marked as invalid.
Note
By default, if set as 0 min, the valid check out me ends at 23:59:59.
Absence Time (Early Leave)
The early leave me is N min earlier than the check out me. For example, if set the earliest
check out me as 17:20, and set the parameter as 30 min, checking out between 16:50 and
17:20 will be marked as early leave.
DS-K1A340 Series Face Recognion Terminal User Manual
32
Note
●
The unit is min.
●
The available me is from 0 to 1440 min.
Set Normal Shi
Edit or add the normal shi aendance informaon, including the shi name, the shi period, and
the overme shi period. You can also reset the normal shi aer eding.
Before You Start
Set the aendance rule. For details, see Set Aendance Rule for Normal Shi .
Steps
1.
Tap Local T&A → Shi Management → Normal Shi Management to enter the page.
Figure 7-9 Normal Shi Management
2.
Select a shi from the list to enter the Shi Details page.
Note
By default, there are 3 congured normal shis in the system.
3.
Set the shi name and period in order and set the overme shi period according to your
needs.
DS-K1A340 Series Face Recognion Terminal User Manual
33
Note
●
If the aendance rules conict with the normal shi period, the device will prompt "Incorrect
Time Duraon". Delete all congured me duraons and reset aer exing.
●
The shi name supports numbers, uppercase leers, lowercase leers, Chinese characters
and symbols.
●
Up to 32 characters are allowed in the shi name.
4.
Tap OK to save the sengs.
5.
Oponal: Add shi.
1) Tap + in the upper right of the Normal Shi Management page to add shi.
2) Set shi name, start me and end me in order.
3) Tap in the upper right of the add shi page to save the sengs.
Set Man-Hour Shi
Set the man-hour shi parameters, including the shi name, the work duraon, the latest on-work
me, and the break me. You can also reset the man-hour shi aer eding.
Steps
1.
Tap Local T&A → Shi Management → Man-Hour Shi Management to enter the page.
Figure 7-10 Man-Hour Shi
2.
Tap + in the upper right of the Man-Hour Shi page to add the shi.
3.
Set shi name, work duraon, latest on-work me and add break me.
DS-K1A340 Series Face Recognion Terminal User Manual
34
Note
●
Break me is not recorded as working duraon.
●
If the latest on-work me is set as 0, this feature is disabled by default.
4.
Tap in the upper right of the add shi page to save the sengs.
7.3.5 Manage Holiday (Add/Edit/Delete)
Set the aendance holiday. The aendance will not be recorded during the holiday.
Add Holiday
Tap Local T&A → Holiday Management , and tap + in the upper right of the Holiday page to enter
the Add Holiday page. Enter Holiday Name and set Holiday Duraon, and tap in the upper right
of the Add Holiday page to save the sengs.
Edit Holiday
Tap Local T&A → Holiday Management to enter the Holiday page. Select a holiday to enter the
Holiday Details page to edit the holiday.
Delete Holiday
Tap Local T&A → Holiday Management to enter the Holiday page. Select a holiday to enter the
Holiday Details page and tap in the upper right of the Holiday Details page to delete the holiday.
7.3.6 Shi Schedule
Combine shi and holiday according to your actual needs. Scheduling shi by department and
scheduling shi by individual are supported.
Schedule Shi by Department: All persons in the department use the same shi schedule to take
aendance.
Schedule Shi by Individual: Take aendance according to individual's condions.
Shi Schedule by Department
All persons in the department use the same shi schedule to take aendance.
Before You Start
●
Edit department. For details, see
Department Management .
●
Set normal shit or man-hour shi. For details, see Set Normal Shi and Set Man-Hour Shi .
●
Set the aendance holiday. For details, see Manage Holiday (Add/Edit/Delete) .
DS-K1A340 Series Face Recognion Terminal User Manual
35
Steps
1.
Tap Local T&A → Shi Schedule by Department to enter the Shi Schedule by Department
page.
2.
Select a department from the list to enter the Shi Schedule Details page.
3.
Edit parameters.
Department Name
The department name should be edited in Dept. management page. For details, see
Department Management .
Employee
You can see employees in the department.
Add Shi Schedule
You can add shi schedules and set shi schedule of each shi schedule and shi type of shi
on Monday to Sunday.
Note
Up to 8 shi schedules can be added and each shi schedule me can not be overlapped
with other shi schedule me.
Holiday Sengs
Tap holiday sengs and tap in the upper right of the Holiday Sengs page. Aer saving
the sengs, the aendance will not be recorded during the holiday.
4.
Tap to save the sengs.
Shi Schedule by Individual (Add/Edit/Delete)
Take aendance according to individual's condions.
Before You Start
●
Add user before seng shi schedule by individual. For details, see User Management .
●
Set normal shit or man-hour shi. For details, see Set Normal Shi 和 Set Man-Hour Shi .
●
Set the aendance holiday. For details, see Manage Holiday (Add/Edit/Delete) .
Steps
Note
The shi schedule by individual has higher priority than shi schedule by department. If a user has
congured both shi schedule by department and by individual, the system will take aendance
according to shi schedule by individual rst.
1.
Tap Local T&A → Shi Schedule by Individual to enter the Shi Schedule by Individual page.
DS-K1A340 Series Face Recognion Terminal User Manual
36
Figure 7-11 Shi Schedule by Individual
2.
Tap + in the upper right of the Shi Schedule by Individual page to add Shi Schedule by
Individual.
3.
Select a person from the list to enter the Shi Schedule Details page.
4.
Edit parameters.
Add Shi Schedule
You can add shi schedules and set shi schedule of each shi schedule and shi type of shi
on Monday to Sunday.
Note
Up to 8 shi schedules can be added and each shi schedule me can not be overlapped
with other shi schedule me.
Holiday Sengs
Tap Holiday Sengs in the Holiday Sengs page. Aer saving the sengs, the aendance
will not be recorded during the holiday.
5.
Tap
to save the sengs.
6.
Oponal: Select an individual in the Shi Schedule by Individual page and edit the shi
schedule.
7.
Oponal: Select an individual you want to delete in the Shi Schedule by Individual page, and
tap in the upper right of the Shi Schedule by Individual page to delete the shi schedule.
DS-K1A340 Series Face Recognion Terminal User Manual
37
7.4 Time and Aendance Status Sengs
You can set the aendance mode as check in, check out, break out, break in, overme in, and
overme out according to your actual situaon.
Note
The funcon should be used cooperavely with me and aendance funcon on the client
soware.
7.4.1 Disable Aendance Mode via Device
Disable the aendance mode and the system will not display the aendance status on the inial
page.
Tap T&A Status to enter the T&A Status page.
Figure 7-12 Disable Aendance Mode
Set the Aendance Mode as Disable.
You will not view or congure the aendance status on the inial page. And the system will follow
the aendance rule that congured on the plaorm.
DS-K1A340 Series Face Recognion Terminal User Manual
38
7.4.2 Set Manual Aendance via Device
Set the aendance mode as manual, and you should select a status manually when you take
aendance.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Tap T&A Status to enter the T&A Status page.
2.
Set the Aendance Mode as Manual.
Figure 7-13 Manual Aendance Mode
3.
Enable the Aendance Status Required.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
The name will be displayed on the T & A Status page and the authencaon result page.
Result
You should select an aendance status manually aer authencaon.
DS-K1A340 Series Face Recognion Terminal User Manual
39
Note
If you do not select a status, the authencaon will be failed and it will not be marked as a valid
aendance.
7.4.3 Set Auto Aendance via Device
Set the aendance mode as auto, and you can set the aendance status and its available schedule.
The system will automacally change the aendance status according to the congured schedule.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Tap T&A Status to enter the T&A Status page.
2.
Set the Aendance Mode as Auto.
Figure 7-14 Auto Aendance Mode
3.
Enable the Aendance Status funcon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
The name will be displayed on the T & A Status page and the authencaon result page.
6.
Set the status' schedule.
DS-K1A340 Series Face Recognion Terminal User Manual
40
1) Tap Aendance Schedule.
2) Select Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, or Sunday.
3) Set the selected aendance status's start me of the day.
4) Tap Conrm.
5) Repeat step 1 to 4 according to your actual needs.
Note
The aendance status will be valid within the congured schedule.
Result
When you authencate on the inial page, the authencaon will be marked as the congured
aendance status according to the congured schedule.
Example
If set the Break Out as Monday 11:00, and Break In as Monday 12:00, the valid user's
authencaon from Monday 11:00 to 12:00 will be marked as break.
7.4.4 Set Manual and Auto Aendance via Device
Set the aendance mode as Manual and Auto, and the system will automacally change the
aendance status according to the congured schedule. At the same me you can manually
change the aendance status aer the authencaon.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Tap T&A Status to enter the T&A Status page.
2.
Set the Aendance Mode as Manual and Auto.
DS-K1A340 Series Face Recognion Terminal User Manual
41
Figure 7-15 Manual and Auto Mode
3.
Enable the Aendance Status funcon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
The name will be displayed on the T & A Status page and the authencaon result page.
6.
Set the status' schedule.
1) Tap Aendance Schedule.
2) Select Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, or Sunday.
3) Set the selected aendance status's start me of the day.
4) Tap OK.
5) Repeat step 1 to 4 according to your actual needs.
Note
The aendance status will be valid within the congured schedule.
Result
On the inial page and authencate. The authencaon will be marked as the congured
aendance status according to the schedule. If you tap the edit icon on the result tab, you can
select a status to take aendance manually, the authencaon will be marked as the edited
aendance status.
DS-K1A340 Series Face Recognion Terminal User Manual
42
Example
If set the Break Out as Monday 11:00, and Break In as Monday 12:00, the valid user's
authencaon from Monday 11:00 to 12:00 will be marked as break.
7.5 Data Management
You can import user data, face data, access control parameters, and export aendance summary
table, abnormal aendance table, aendance template, user data, face data, and access control
parameters.
7.5.1 Export Aendance Template
Steps
1.
Plug a USB ash drive in the device.
Note
●
The supported USB ash drive format is FAT32 and exfat.
●
The system supports the USB ash drive with the storage of 1 G to 32 G. Make sure the free
space of the USB ash drive is more than 512 M.
2.
Tap Data → Import Data → Aendance Template .
3.
Set the start date and end date.
4.
Tap OK to export the aendance template.
7.5.2 Export Aendance Summary Table/Abnormal Aendance Table/Aendance
Card Report Table
You can export aendance summary table, abnormal aendance table, and aendance card report
table.
Steps
1.
Plug a USB ash drive in the device.
Note
●
The supported USB ash drive format is FAT32 and exfat.
●
The system supports the USB ash drive with the storage of 1 G to 32 G. Make sure the free
space of the USB ash drive is more than 512 M.
2.
Tap Data → Export Data → Aendance Summary Table/Abnormal Aendance Table/
Aendance Card Report Table .
3.
Tap the table that needs to be exported.
DS-K1A340 Series Face Recognion Terminal User Manual
43
Note
●
You need to enter the start date and end date when exporng aendance summary table/
abnormal aendance table/aendance card report table.
●
For exported table content details, see Aendance Report Table .
Result
The exported content will be stored in the USB ash drive in Excel format.
7.5.3 Import Face Picture
Face pictures can be imported into the device through a USB ash drive. You can also export the
pictures from one device and import them into other devices.
Steps
1.
Import the external face pictures through a USB ash drive directly.
1) Plug a USB ash drive in the device.
Note
●
The supported USB ash drive format is FAT32 and exfat.
●
The system supports the USB ash drive with the storage of 1 G to 32 G. Make sure the free
space of the USB ash drive is more than 512 M.
2) Tap Data → Import Data → Face Data .
3) Enter the password when imporng the face data, and tap OK.
Note
The pictures are stored in the enroll_pic folder in the root directory of the USB ash drive.
2.
Export the pictures from one device and import them into other devices.
1) Tap Data → Export Data → Face Data .
2) Enter the password when exporng face data.
Note
The pictures are stored in the enroll_pic folder in the root directory of the USB ash drive.
3) Store the exported pictures in the export_pic folder in the root directory of the USB ash
drive.
4) Tap Data → Import Data → Face Data .
5) Enter the password when imporng the face data, and tap OK.
Note
●
The picture size cannot be larger than 200 KB, and the picture format supports .jpg, 24
bit .bmp, or .png formats. The format of the picture imported by the user is: Employee
DS-K1A340 Series Face Recognion Terminal User Manual
44
●
Non-encrypted or encrypted imporng/exporng are supported.
7.5.4 Export User Data/Access Control Parameters
You can export user data and access control parameters.
Steps
1.
Plug a USB ash drive in the device.
Note
●
The supported USB ash drive format is FAT32 and exfat.
●
The system supports the USB ash drive with the storage of 1 G to 32 G. Make sure the free
space of the USB ash drive is more than 512 M.
2.
Tap Data → Export Data → User Data/Access Control Parameters .
3.
Tap User Data or Access Control Parameters.
4.
Enter the password when imporng the user data/access control parameters, and tap OK.
Note
●
You can export the imported data to iVMS-4200.
●
Non-encrypted or encrypted imporng/exporng are supported.
●
Please refer to for exported table content.
Result
The exported content will be stored in the USB ash drive in Excel format.
7.6 Identy Authencaon
Aer network conguraon, system parameters conguraon and user conguraon, you can go
back to the inial page for identy authencaon. The system will authencate person according
to the congured authencaon mode. Identy authencaon is generally used in places with
high security levels such as public security or judicial place.
7.6.1 Authencate via Single Credenal
Set the user authencaon type before authencaon. For details, see Set Authencaon Mode .
Authencate face, ngerprint, card or QR code.
Face
Face forward at the camera and start authencaon via face.
Fingerprint
DS-K1A340 Series Face Recognion Terminal User Manual
45
Place the enrolled ngerprint on the ngerprint module and start authencaon via ngerprint.
PIN Code
Enter the PIN code to authencate via PIN code.
Note
PIN code should be congured in the plaorm.
If authencaon completed, a prompt "Authencated" will pop up.
7.6.2 Authencate via Mulple Credenal
Before You Start
Set the user authencaon type before authencaon. For details, see Set Authencaon Mode .
Steps
1.
If the authencaon mode is Face, PIN code and Face, PIN code, Face and Fingerprint,
authencate any credenal according to the instrucons on the live view page.
Note
●
Some devices support ngerprint authencaon. Refers to the actual device for details.
●
Support, face + ngerprint, face + pin, ngerprint + pin, face + ngerprint + pin authencaon
methods.
2.
Aer the previous credenal is authencated, connue authencate other credenals.
Note
●
For detailed informaon about scanning ngerprint, see Tips for Scanning Fingerprint.
●
For detailed informaon about authencang face, see Tips When Collecng/Comparing Face
Picture.
If authencaon succeeded, the prompt "Authencated" will pop up.
7.7 Basic Sengs
You can set the shortcut key, theme, voice, me, sleeping (s), wait to Logout (s), language.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and login the
device home page. Tap Basic.
DS-K1A340 Series Face Recognion Terminal User Manual
46
Figure 7-16 Basic Sengs Page
Shortcut Key
Choose the shortcut key that displayed on the authencaon page, including the PIN code
entering funcon.
Theme
You can set the theme of the prompt window on the authencaon page. You can select Theme
as Default/Simple. If select Simple, the live view of the authencaon page will be disabled,
and in the meanwhile, the person's name, employee ID, face pictures will all be hidden.
Voice Sengs
You can enable/disable the voice prompt funcon and adjust the voice volume.
Note
You can set the voice volume between 0 and 10.
Time Sengs
Set the me zone, the device me and the DST.
DS-K1A340 Series Face Recognion Terminal User Manual
47
Sleeping (s)
Set the device sleeping waing me (minute). When you are on the inial page and if you set
the sleeping me to 30 min, the device will sleep aer 30 min without any operaon.
Note
If you set the sleeping me to 0, the device will not enter sleeping mode.
Wait to Logout (s)
If there is no operaon within the congured me, the system will logout.
Language
Select the language according to actual needs.
Note
Aer changing the language, the device will reboot.
Privacy
You can enable Save Registered Pic., Name Desensizaon Display, and Word ID
Desensizaon Display. Aer enabling, name and work ID only display paral contents.
7.8 Set Biometric Parameters
You can customize the face parameters to improve the face recognion performance. The
congurable parameters includes applicaon mode, face liveness level, face recognion distance,
face recognion interval, wide dynamic, face 1:N security level, face 1:1 security level, ECO
sengs, and face with mask detecon.
Long tap on the inial page for 3 s and login the home page. Tap Biometric.
Table 7-1 Face Picture Parameters
Parameter Descripon
Applicaon Mode Select either others or indoor according to actual environment.
Face Liveness Level Aer enabling face an-spoong funcon, you can set the matching
security level when performing live face authencaon.
Face Recognion
Distance
Set the valid distance between the user and the camera when
authencang.
Face Recognion
Interval
The me interval between two connuous face recognions when
authencang.
Note
You can input the number from 1 to 10.
DS-K1A340 Series Face Recognion Terminal User Manual
48
Parameter Descripon
Face 1:N Security Level Set the matching threshold when authencang via 1:N matching mode.
The larger the value, the smaller the false accept rate and the larger the
false rejecon rate.
Face 1:1 Security Level Set the matching threshold when authencang via 1:1 matching mode.
The larger the value, the smaller the false accept rate and the larger the
false rejecon rate.
ECO Sengs Aer enabling the ECO mode, the device will use the IR camera to
authencate faces in the low light or dark environment. And you can set
the ECO mode threshold, ECO mode (1:N), and ECO mode (1:1).
ECO Threshold
When enabling the ECO mode, you can set the ECO mode’s threshold.
The larger the value, the easier the device entering the ECO mode.
ECO Mode (1:1)
Set the matching threshold when authencang via ECO mode 1:1
matching mode. The larger the value, the smaller the false accept rate
and the larger the false rejecon rate.
ECO Mode (1:N)
Set the matching threshold when authencang via ECO mode 1:N
matching mode. The larger the value, the smaller the false accept rate
and the larger the false rejecon rate
Mulple Faces
Authencaon
Aer mulple faces authencaon is enabled, mulple faces
authencaon is supported.
7.9 System Maintenance
You can view the device system informaon and capacity. You can also restore the system to
factory sengs, default sengs, unlink APP account, and reboot the system.
Long tap on the inial page for 3 s and login the home page. Tap Maint.
DS-K1A340 Series Face Recognion Terminal User Manual
49
Figure 7-18 Maintenance Page
System Informaon
You can view the device informaon including serial No., rmware version, MCU version, MAC
address, producon data, device QR code, open source code license.
Note
The page may vary according to dierent device models. Refers to the actual page for details.
Capacity
You can view the number of administrator, user, face picture, card, and event.
Note
Parts of the device models support displaying the ngerprint number. Refers to the actual page
for details.
Device Upgrade
DS-K1A340 Series Face Recognion Terminal User Manual
50
Plug the USB ash drive in the device USB interface. Tap Device Upgrade → Upgrade , and the
device will read the digicap.dav le in the USB ash drive to start upgrading.
Unlink APP Account
Unlink the Hik-Connect account from the plaorm.
Restore to Factory Sengs
All parameters will be restored to the factory sengs. The system will reboot to take eect.
Restore to Default Sengs
All parameters, except for the communicaon sengs, remotely imported user informaon, will
be restored to the default sengs. The system will reboot to take eect.
Reboot
The device will reboot aer the conrmaon.
Long tap , and enter admin password to view device version informaon.
DS-K1A340 Series Face Recognion Terminal User Manual
51
Chapter 8 Congure the Device via the Mobile
Browser
8.1 Login
You can login via mobile browser.
Note
●
Parts of the model supports Wi-Fi sengs.
●
Make sure the device is acvated.
Obtain the IP address from the device aer Wi-Fi is enabled. Make sure the IP segment of the
device and the computer is the same. For details, refers to Set Wi-Fi Parameters .
Enter the device IP address in the address bar of the mobile browser and press Enter to enter the
login page.
Enter the device user name and the password. Click Login.
8.2 Search Event
Click Search to enter the Search page.
Enter the search condions, including the employee ID, the name, the card No., the start me, and
the end me, and click Search.
Note
Support searching for names within 32 digits.
The results will be displayed in the list.
8.3 Conguraon
8.3.1 View Device Informaon
You can view the device name, device No., language, model, serial No., version, device capacity,
etc.
Tap Conguraon → System → System Sengs → Basic Informaon , to enter the sengs page.
DS-K1A340 Series Face Recognion Terminal User Manual
52
Figure 8-1 Device Informaon
DS-K1A340 Series Face Recognion Terminal User Manual
53
You can view the device name, device No., language, model, serial No., version, device capacity,
etc.
8.3.2 Time Sengs
Set the me zone, me sync. mode, and displayed me.
Tap Conguraon → System → System Sengs → Time Sengs to enter the sengs page.
Figure 8-2 Time Sengs
Tap Save to save the sengs.
Time Zone
Select the me zone where the device is located from the drop-down list.
Time Sync. Mode
Manual
DS-K1A340 Series Face Recognion Terminal User Manual
54
By default, the device me should be synchronized manually. You can set the device me
manually.
NTP
Set the NTP server's IP address, port No., and interval.
8.3.3 Set DST
Steps
1.
Tap Conguraon → System → System Sengs → DST , to enter the sengs page.
DS-K1A340 Series Face Recognion Terminal User Manual
55
Figure 8-3 DST
2.
Tap Enable DST.
3.
Set the start me, end me, and DST bias.
4.
Tap Save.
DS-K1A340 Series Face Recognion Terminal User Manual
56
8.3.4 View Open Source Soware License
Tap Conguraon → System → System Sengs → About , and tap View Licenses to view the
device license.
8.3.5 Network Sengs
You can set the port and Wi-Fi parameters.
Set Port Parameters
You can set the HTTP, RTSP, HTTPS, and Server according to actual needs when accessing the device
via network.
Tap Conguraon → Network → Basic Sengs → Port , to enter the sengs page.
HTTP
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.0.0.65:81 in the browser for login.
RTSP
It refers to the port of real-me streaming protocol.
HTTPS
Set the HTTPS for accessing the browser. Cercate is required when accessing.
Server
It refers to the port through which the client adds the device.
Set Wi-Fi Parameters
Set the Wi-Fi parameters for device wireless connecon.
Steps
Note
The funcon should be supported by the device.
1.
Tap Conguraon → Network → Basic Sengs → Wi-Fi to enter the sengs page.
2.
Check Enable Wi-Fi.
Note
If Wi-Fi is enabled, the AP will be disabled automacally.
DS-K1A340 Series Face Recognion Terminal User Manual
57
Figure 8-4 Wi-Fi
3.
Add Wi-Fi.
1) Tap +.
DS-K1A340 Series Face Recognion Terminal User Manual
58
Figure 8-5 Add Wi-Fi
2) Enter Wi-Fi Name and Wi-Fi Password, and select Working Mode and Encrypon Type.
3) Tap Save.
4.
Select the Wi-Fi name, and tap Connect.
5.
Enter the password and tap Save.
6.
Set WLAN parameters.
1) Set the IP address, subnet mask, and gateway. Or enable DHCP and the system will allocate
the IP address, subnet mask, and gateway automacally.
2) Tap Save.
8.3.6 Set Time and Aendance via Mobile Web Browser
You can set me and aendance by managing department, user, shi, holiday, and shi schedule.
You can add, edit, and delete aendance department, user, shi, holiday, and shi schedule.
Manage Department via Mobile Web Browser
You can add, edit and delete the department.
Steps
1.
Tap Conguraon → Time and Aendance → Department Management to enter the sengs
page.
2.
Add the department.
1) Tap +.
DS-K1A340 Series Face Recognion Terminal User Manual
59
Figure 8-6 Add Department
2) Enter the department name, and tap OK.
Note
●
The department name supports uppercase English, lowercase English, numbers and symbols.
●
Up to 32 characters can be entered in department name.
●
There are 7 departments in the department management by default.
3.
Oponal: You can view employee according to your actual needs.
4.
Delete the department.
1) Tap the department that needs to be deleted.
2) Tap , and tap OK to delete the department.
User Management
You can add, edit, delete, and search users via mobile Web browser.
Steps
1.
Tap User to enter the sengs page.
2.
Add user.
1) Tap+.
DS-K1A340 Series Face Recognion Terminal User Manual
60
Figure 8-7 Add User
2) Set the following parameters.
DS-K1A340 Series Face Recognion Terminal User Manual
61
Employee ID
Enter the employee ID. The Employee ID cannot be 0 or exceed 32 characters. It can be a
combinaon of uppercase, lowercase leers and numbers.
Name
Enter your name. The name supports numbers, uppercase and lowercase English, and
characters. The name is recommended to be within 32 characters.
User Role
Select your user role.
Floor No./Room No.
Enter the oor No./room No.
Face
Add Face picture. Tap Face, then tapImport, and select the mode to import the face.
Fingerprint
Add ngerprint. Tap Fingerprint, then tap +, and add ngerprint via the ngerprint module.
Start Date/End Date
Set Start Date and End Date of user permission.
Administrator
If the user needs to be set as administrator, you can enable Administrator.
Authencaon Type
Set the authencaon type.
3) Tap Save.
3.
Tap the user that needs to be edited in the user list to edit the informaon.
4.
Tap the user that needs to be deleted in the user list, and tap to delete the user.
5.
You can search the user by entering the employee ID or name in the search bar.
Manage Shi via Mobile Web Browser
You can set the normal shi and man-hour shi. Normal shi can be applied in aendance
scenarios of regular aendance, and you can set the aendance rules and the aendance number.
Man-hour shi can be applied in the aendance scenarios of exible working system.
Manage Normal Shi via Mobile Web Browser
You can edit and add normal shi aendance informaon, including shi name and aendance
duraon.
DS-K1A340 Series Face Recognion Terminal User Manual
62
Steps
1.
Set aendance rules.
1) Tap Conguraon → Time and Aendance → Shi Management → Normal Shi
Management .
2) Tap Aendance Rule.
3) Set advanced check in me, latest check in me, absence me(late), earliest check out me,
latest check out me, and absence me(early leave).
Note
●
The me unit is minute.
●
The congurable me range is from 0 to 1440 minutes (including 0 and 1440).
4) Tap Save.
2.
Set normal shi.
1) Tap Conguraon → Time and Aendance → Shi Management → Normal Shi
Management .
2) Tap a normal shi to enter the sengs page.
Note
3 normal shis has been congured by default.
3) Set the shi name, the start me and end me of the aendance duraon.
Note
●
If the aendance rules conict with the normal shi duraons, the device will prompt
"Duraon error". Please delete all duraons and recongure the sengs aer exing.
●
The shi name supports Chinese, uppercase English, lowercase English, numbers and
symbols.
●
Up to 32 characters can be entered in shi name.
4) Tap Save.
3.
Oponal: Add the shi.
1) Tap + in normal shi management page.
DS-K1A340 Series Face Recognion Terminal User Manual
63
Figure 8-8 Add Shi
2) Set the shi name, the start me and end me of the aendance duraon.
3) Tap Save.
Manage Man-Hour Shi via Mobile Web Browser
You can edit the shi name, work duraon, latest on-work me, and break me.
Steps
1.
Tap Conguraon → Time Aendance → Shi Management → Man-Hour Shi Management .
2.
Tap +.
3.
Edit the shi name, work duraon, latest on-work me, and break me.
Note
●
Break me is not recorded in working me.
●
If the latest work me is set to 0, this funcon is not enabled by default.
4.
Tap Save.
Manage Holiday via Mobile Web Browser
There is no aendance during the holidays.
Steps
1.
Add the holidays.
1) Tap Conguraon → Time and Aendance → Holiday Management , to enter the sengs
page.
2) Tap + to enter the sengs page. Enter Holiday Name, Start Date and End Date, and tap Save.
DS-K1A340 Series Face Recognion Terminal User Manual
64
2.
Edit the holidays. Tap Conguraon → Time and Aendance → Holiday Management to enter
the sengs page. Tap the holiday to edit the sengs.
3.
Delete the holidays. Tap Conguraon → Time and Aendance → Holiday Management , tap
the holiday to enter the sengs page, and tap to delete the holiday.
Manage Shi Schedule via Mobile Web Browser
You can combine the shi and holiday according to your actual needs. Shi schedule by
department and shi schedule by individual are supported.
Manage Shi Schedule by Department via Mobile Web Browser
You can set the shi schedule by department, and the employees in the same department will use
the same shi schedule.
Before You Start
●
Edit the department. You can refer to Manage Department via Mobile Web Browser for details.
●
Set the normal shi and man-hour shi. You can refer to Manage Normal Shi via Mobile Web
Browser and Manage Man-Hour Shi via Mobile Web Browser for details.
●
Set the holiday aendance. You can refer to Manage Holiday via Mobile Web Browser for
details.
Steps
1.
Tap Conguraon → Time and Aendance → Shi Schedule Management → Shi Schedule by
Department to enter the sengs page.
2.
Tap the shi schedule to edit the shi schedule by department.
3.
Edit the shi schedule by department parameters.
Department Name
You should set the department name in department management. You can refer to
Manage
Department via Mobile Web Browser for details.
Add Shi Schedule
Tap +, and set the shi schedule name, shi schedule me and daily shi schedule
informaon.
Note
Up to 8 shi schedules can be added, and the dates of each shi schedule cannot overlap.
Holiday Sengs
Tap Holiday Sengs, select the holiday and tap OK. Aer seng, the aendance will not be
checked during holidays.
4.
Tap Save.
DS-K1A340 Series Face Recognion Terminal User Manual
65
5.
Oponal: Tap the shi schedule that needs to be deleted, and tap to delete the shi
schedule.
Manage Shi Schedule by Individual via Mobile Web Browser
You can set the shi schedule by individual.
Before You Start
●
Edit the department. You can refer to Manage Department via Mobile Web Browser for details.
●
Set the normal shi and man-hour shi. You can refer to Manage Normal Shi via Mobile Web
Browser and Manage Man-Hour Shi via Mobile Web Browser for details.
●
Set the holiday aendance. You can refer to Manage Holiday via Mobile Web Browser for
details.
Steps
Note
The priority of shi schedule by individual is higher than that of shi schedule by department. If a
person is congured with shi schedule by individual and department at the same me, shi
schedule by individual will be used rst during aendance.
1.
Tap Conguraon → Time and Aendance → Shi Schedule Management → Shi Schedule by
Individual to enter the sengs page.
2.
Tap + to add the shi schedule by individual.
3.
Select the employee.
4.
Edit the shi schedule parameters.
Add Shi Schedule
Tap +, and set the shi schedule name, shi schedule me and daily shi schedule
informaon.
Note
Up to 8 shi schedules can be added, and the dates of each shi schedule cannot overlap.
Holiday Sengs
Tap Holiday Sengs, select the holiday and tap OK. Aer seng, the aendance will not be
checked during holidays.
5.
Tap Save.
6.
Oponal: Tap the shi schedule that needs to be edited, to edit the sengs.
7.
Oponal: Tap the shi schedule that needs to be deleted, and tap to delete the shi
schedule.
DS-K1A340 Series Face Recognion Terminal User Manual
66
8.3.7 General Sengs
Set Authencaon Parameters
Set Authencaon Parameters.
Steps
1.
Tap Conguraon → General Sengs → Authencaon Sengs .
2.
Tap Save.
Device Type
Main Card Reader
You can congure the device card reader's parameters. If you select main card reader, you
need to congure the following parameters: Card Reader Type, Card Reader Descripon,
Enable Card Reader, Authencaon, Recognion Interval (s), Max.Authencaon Failed
Aempts Alarm/Alarm of Max. Failed Aempts.
Card Reader Type
Get card reader type.
Card Reader Descripon
Get card reader descripon. It is read-only.
Enable Card Reader
Enable the card reader's funcon.
Authencaon
Select an authencaon mode according to your actual needs from the drop-down list.
Recognion Interval
If the interval between card presenng of the same card is less than the congured value, the
card presenng is invalid. The interval me range is from 0 to 255 seconds (When set to 0, it
means that recognion interval is not enabled, and the same authencaon can be used for
unlimited mes).
Mulple People Authecaon
Aer mulple faces authencaon is enabled, mulple faces authencaon is supported.
Max. Authencaon Failed Aempts Alarm/Alarm of Max. Failed Aempts
Enable to report alarm when the card reading aempts reach the set value.
Set Privacy Parameters
Set the event storage type, picture upload and storage parameters, and the picture clearing
parameters.
DS-K1A340 Series Face Recognion Terminal User Manual
67
Tap Conguraon → General Sengs → Privacy .
Event Storage Sengs
Select a method to delete the event. You can select from Delete Old Events Periodically, Delete
Old Events by Specied Time, or Overwring.
Delete Old Events Periodically
Drag the block or enter number to set the period for event deleng. All events will be deleted
according to the congured me duraon.
Delete Old Events by Specied Time
Set a me and all events will be deleted on the congured me.
Overwring
The earliest 5% events will be deleted when the system detects the stored events has been over
95% of the full space.
Authencaon Sengs
Display Authencaon Result
Check Face Picture, Name, or Employee ID. When authencaon is completed, the system will
display the selected contents in the result.
Picture Uploading and Storage
You can upload and store pictures.
Upload Captured Picture When Authencang
Upload the pictures captured when authencang to the plaorm automacally.
Save Captured Picture When Authencang
If you enable this funcon, you can save the picture when authencang to the device.
Save Registered Picture
The registered face picture will be saved to the system if you enable the funcon.
Upload Picture Aer Linked Capture
Upload the pictures captured by linked camera to the plaorm automacally.
Save Pictures Aer Linked Capture
If you enable this funcon, you can save the picture captured by linked camera to the device.
Clear All Pictures in Device
You can clear registered face pictures and captured pictures in device.
Clear Registered Face Pictures
All registered pictures in the device will be deleted.
Clear Authencaon/Captured Pictures
DS-K1A340 Series Face Recognion Terminal User Manual
68
All authencaon/captured pictures in the device will be deleted.
8.3.8 Face Parameters Sengs
Set face parameters.
Face Parameters Sengs
Tap Conguraon → Smart → Intelligent Parameter to enter the page.
Note
The funcons vary according to dierent models. Refers to the actual device for details.
Set Face Parameters.
Face An-spoong
Enable or disable the live face detecon funcon. If enabling the funcon, the device can
recognize whether the person is a live one or not.
Live Face Detecon Security Level
Aer enabling the face an-spoong funcon, you can set the matching security level when
performing live face authencaon.
Recognion Distance
Select the distance between the authencang user and the device camera.
Applicaon Mode
Select Indoor or Others according to actual environment. In the outdoor scene, indoor scene
near the window, or bad environment, you can choose Others.
Note
If the device is not acvated by other tools, the device uses indoor as the environment mode by
default.
Face Recognion Mode
Normal Mode
The device uses a camera to perform face recognion.
Deep Mode
It is applicable for for more complex environments, and the range of people recognized is
wider.
DS-K1A340 Series Face Recognion Terminal User Manual
69
Note
●
The two modes cannot be compable with each other. Do not change the mode once it is
selected. If you change the mode, all face pictures of the previous mode will be cleared.
●
In the deep mode, you can add the face pictures only via the user adding funcon of the
device or the enrollment staon. It is not supported to add face pictures via pictures
imporng.
The device uses a camera to perform face recognion.
Connuous Face Recognion Interval
Set the me interval between two connuous face recognions when authencang.
Note
Value Range: 1 to 10.
1:1 Matching Threshold
Set the matching threshold when authencang via 1:1 matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate.
1:N Matching Threshold
Set the matching threshold when authencang via 1:N matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate. The maximum value is
100.
Face Recognion Timeout Value
Congure the meout period for face recognion. If the face recognion me exceeds the
congured value, the device will prompt the face recognion meout.
Face with Mask Detecon
Aer enabling the face with mask detecon, the system will recognize the captured face with
mask picture. You can set face with mask1:N matching threshold, its ECO mode, and the
strategy.
None
If the person do not wear a face mask when authencang, the device will not prompt a
nocaon.
Reminder of Wearing
If the person do not wear a face mask when authencang, the device prompts a
nocaon and the door will open.
Must Wear
If the person do not wear a face mask when authencang, the device prompts a
nocaon and the door keeps closed.
Face with Mask & Face (1:1)
DS-K1A340 Series Face Recognion Terminal User Manual
70
Set the matching value when authencang with face mask via 1:1 matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate.
Face with Mask 1:N Matching Threshold
Set the matching threshold when authencang with face mask via 1:N matching mode. The
larger the value, the smaller the false accept rate and the larger the false rejecon rate.
Face with Mask & Face (1:1 ECO)
Set the matching value when authencang with face mask via ECO mode 1:1 matching mode.
The larger the value, the smaller the false accept rate and the larger the false rejecon rate.
Face with Mask 1:N Matching Threshold (ECO Mode)
Set the matching threshold when authencang with face mask via ECO mode 1:N matching
mode. The larger the value, the smaller the false accept rate and the larger the false rejecon
rate.
ECO Mode
Aer enabling the ECO mode, the device will use the IR camera to authencate faces in the low
light or dark environment. And you can set the ECO mode threshold, ECO mode (1:N), and ECO
mode (1:1).
ECO Mode Threshold
Set the matching threshold when authencang via ECO mode 1:1 matching mode and ECO
mode 1:N matching mode.
ECO Mode (1:1)
Set the matching threshold when authencang via ECO mode 1:1 matching mode.
ECO Mode (1:N)
Set the matching threshold when authencang via ECO mode 1: N matching mode.
Set Recognion Area
Tap Conguraon → Smart → Area Conguraon to enter the page.
Drag the blue frame in the live video to adjust the recognion area. Only the face within the area
can be recognized by the system.
Drag the slider to congure the eecve area of face recognion.
Tap Save to save the sengs.
DS-K1A340 Series Face Recognion Terminal User Manual
71
Chapter 9 Operaon via Web Browser
9.1 Login
You can login via the web browser.
Note
●
Parts of the model supports Wi-Fi sengs.
●
Make sure the device is acvated.
Obtain the IP address from the device aer Wi-Fi is enabled. Make sure the IP segment of the
device and the computer is the same. For details, refers to Set Wi-Fi Parameters .
Enter the device IP address in the address bar of the web browser and press Enter to enter the
login page.
Enter the device user name and the password. Click Login.
Note
Make sure that the IP address starts with "Hps:".
9.2 Person Management
Click and add the person's informaon, including the basic informaon, authencaon mode, card,
ngerprint. And you can also edit user informaon, view user picture and search user informaon
in the user list.
Click OK to save the person.
Add Basic Informaon
Click User → Add to enter the Add Person page.
Add the person's basic informaon, including the employee ID, the person's name, user level,
department name, oor No., and room No.
Click Save to save the sengs.
Add Card
Click User → Add to enter the Add Person page.
Click Add Card, enter the Card No. and select the Property, and click OK to add the card.
Click Save to save the sengs.
Add Fingerprint
Click User → Add to enter the Add Person page.
DS-K1A340 Series Face Recognion Terminal User Manual
72
Click Add Fingerprint, and press your nger on the ngerprint module of the device to add your
ngerprint.
Click Complete to save the sengs.
Add Face Picture
Click User
→ Add to enter the Add Person page.
Click + on the right to upload a face picture from the local PC.
Note
The picture format should be JPG or JPEG or PNG, and the size should be less than 200 K.
Click Save to save the sengs.
Set Permission Time
Click User
→ Add to enter the Add Person page.
Set Start Time and End Time.
Click OK to save the sengs.
Set Access Control
Click User
→ Add to enter the Add Person page.
Aer check Administrator in Access Control, the added person can log in by authencang face.
You can click Add to enter the Floor No. and Room No. of access control, and click to delete it.
Click OK to save the sengs.
Add Authencaon Mode
Click User
→ Add to enter the Add Person page.
Set the authencaon mode.
Click Save to save the sengs.
9.3 Search Event
Click Search to enter the Search page.
Enter the search condions, including the employee ID, the name, the card No., the start me, and
the end me, and click Search.
The results will be displayed in the list.
DS-K1A340 Series Face Recognion Terminal User Manual
73
9.4 Conguraon
9.4.1 Set Local Parameters
Set the live view parameters, record le saving path, and captured pictures saving path.
Set Live View Parameters
Click Conguraon → Local to enter the Local page. Congure the stream type, the play
performance, auto start live view, and the image format and click Save.
Set Record File Saving Path
Click Conguraon → Local to enter the Local page. Select a record le size and select a saving
path from your local computer and click Save.
You can also click Open to open the le folder to view details.
Set Captured Pictures Saving Path
Click Conguraon → Local to enter the Local page. Select a saving path from your local computer
and click Save.
You can also click Open to open the le folder to view details.
9.4.2 View Device Informaon
View the device name, language, model, serial No., QR code, version, device capacity, etc.
Click Conguraon → System → System Sengs → Basic Informaon to enter the conguraon
page.
You can view the device name, language, model, serial No., QR code, version, device capacity, etc.
9.4.3 Set Time
Set the device's me zone, synchronizaon mode, and the device me.
Click Conguraon → System → System Sengs → Time Sengs .
Click Save to save the sengs aer the conguraon.
Time Zone
Select the device located me zone from the drop-down list.
Time Sync.
NTP
You should set the NTP server's IP address, port No., and interval.
DS-K1A340 Series Face Recognion Terminal User Manual
74
Manual
By default, the device me should be synchronized manually. You can set the device me
manually or check Sync. with Computer Time to synchronize the device me with the
computer's me.
9.4.4 Set DST
Steps
1.
Click Conguraon → System → System Sengs → DST .
2.
Check Enable DST.
3.
Set the DST start me, end me and bias me.
4.
Click Save to save the sengs.
9.4.5 View Open Source Soware License
Go to Conguraon → System → System Sengs → About , and click View Licenses to view the
device license.
9.4.6 Upgrade and Maintenance
Reboot device, restore device parameters, and upgrade device version.
Reboot Device
Click Conguraon → System → Maintenance → Upgrade & Maintenance .
Click Reboot to start reboot the device.
Restore Parameters
Click Conguraon → System → Maintenance → Upgrade & Maintenance .
Restore All
All parameters will be restored to the factory sengs. You should acvate the device before
usage.
Default
The device will restore to the default sengs, except for the device IP address and the user
informaon.
Unlink APP Account
Unlink the Hik-Connect account from the plaorm.
Import and Export Parameters
Click Conguraon → System → Maintenance → Upgrade & Maintenance .
DS-K1A340 Series Face Recognion Terminal User Manual
75
Export
Click Export to export the logs or device parameters.
Note
You can import the exported device parameters to another device.
Import
Click and select the le to import. Click Import to start import conguraon le.
Upgrade
Click Conguraon → System → Maintenance → Upgrade & Maintenance .
Select an upgrade type from the drop-down list. Click and select the upgrade le from your
local PC. Click Upgrade to start upgrading.
Note
Do not power o during the upgrading.
9.4.7 Security Mode Sengs
Set the security mode for logging in.
On the Device for Management page, click Conguraon → System → Security → Security
Service .
Enable SSH
To raise network security, disable SSH service. The conguraon is only used to debug the
device for the professionals.
Enable HTTPS
In order to increase the network security level when vising websites, you can enable HTTPS to
acquire a more secure and encrypted network communicaon environment. The
communicaon should authencated by identy and encrypon password aer enabling
HTTPS, which is save.
Enable Illegal Login Lock
In order to increase the network security level when vising websites, you can enable Illegal
Login Lock to secure legal login. The auto-lock feature will block devices that are aempng to
connect for 30 minutes if the login is entered incorrectly aer several aempts.
9.4.8 Cercate Management
It helps to manage the server/client cercates and CA cercate.
DS-K1A340 Series Face Recognion Terminal User Manual
76
Note
The funcon is only supported by certain device models.
Create and Install Self-signed Cercate
Steps
1.
Go to Conguraon → System → Security → Cercate Management .
2.
In the Cercate Files area, select a Cercate Type from the drop-down list.
3.
Click Create.
4.
Input cercate informaon.
5.
Click OK to save and install the cercate.
The created cercate is displayed in the Cercate Details area.
The cercate will be saved automacally.
6.
Download the cercate and save it to an asking le in the local computer.
7.
Send the asking le to a cercaon authority for signature.
8.
Import the signed cercate.
1) Select a cercate type in the Import Passwords area, and select a cercate from the local,
and click Install.
2) Select a cercate type in the Import Communicaon Cercate area, and select a cercate
from the local, and click Install.
Install Other Authorized Cercate
If you already has an authorized cercate (not created by the device), you can import it to the
device directly.
Steps
1.
Go to Conguraon → System → Security → Cercate Management .
2.
In the Import Passwords and Import Communicaon Cercate areas, select cercate type
and upload cercate.
3.
Click Install.
Install CA Cercate
Before You Start
Prepare a CA cercate in advance.
Steps
1.
Go to Conguraon → System → Security → Cercate Management .
2.
Create an ID in the Inport CA Cercate area.
DS-K1A340 Series Face Recognion Terminal User Manual
77
Note
The input cercate ID cannot be the same as the exisng ones.
3.
Upload a cercate le from the local.
4.
Click Install.
9.4.9 Object Missing
This object is not available in the repository.
9.4.10 Online Users
The informaon of users logging into the device is shown.
Go to Conguraon → System → User Management → Online Users to view the list of online
users.
9.4.11 View Device Arming/Disarming Informaon
View device arming type and arming IP address.
Go to Conguraon → Arming/Disarming Informaon .
You can view the device arming/disarming informaon. Click Refresh to refresh the page.
9.4.12 Network Sengs
Set TCP/IP, port, Wi-Fi parameters, report strategy, plaorm access, HTTP listening, and network
service.
Note
Some device models do not support Wi-Fi sengs. Refer to the actual products when
conguraon.
Set Basic Network Parameters
Click Conguraon → Network → Basic Sengs → TCP/IP .
Set the parameters and click Save to save the sengs.
DHCP
If uncheck the funcon, you should set the IPv4 address, IPv4 subnet mask, IPv4 default
gateway, MTU, and the device port.
DS-K1A340 Series Face Recognion Terminal User Manual
78
If you check the funcon, the system will allocate the IPv4 address, IPv4 subnet mask, and the
IPv4 default gateway automacally.
NIC Type
Select a NIC type from the drop-down list. By default, it is Auto.
DNS Server
Set the preferred DNS server and the Alternate DNS server according to your actual need.
Set Port Parameters
Set the HTTP, RTSP, HTTPS and Server port parmaeters.
Click Conguraon → Network → Basic Sengs → Port .
HTTP
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.0.0.65:81 in the browser for login.
RTSP
It refers to the port of real-me streaming protocol.
HTTPS
Set the HTTPS for accessing the browser. Cercate is required when accessing.
Server
It refers to the port through which the client adds the device.
Set Wi-Fi Parameters
Set the Wi-Fi parameters for device wireless connecon.
Steps
Note
The funcon should be supported by the device.
1.
Click Conguraon → Network → Basic Sengs → Wi-Fi .
2.
Check Wi-Fi.
3.
Select a Wi-Fi
-
Click
of a Wi-Fi in the list and enter the Wi-Fi password.
-
Click Add and enter a Wi-Fi's name, password, and encrypon type. Click Connect. When the
Wi-Fi is connected, click OK.
4.
Oponal: Set the WLAN parameters.
1) Click TCP/IP Sengs.
2) Set the IP address, subnet mask, and default gateway. Or check Enable DHCP and the system
will allocate the IP address, subnet mask, and default gateway automacally.
DS-K1A340 Series Face Recognion Terminal User Manual
79
5.
Click Save.
Report Strategy Sengs
You can set the center group for uploading the log via the ISUP protocol.
Go to Conguraon → Network → Basic Sengs → Report Strategy .
You can set the center group and the system will transfer logs via ISUP protocol. Click Save to save
the sengs.
Center Group
Select a center group from the drop-down list.
Main Channel
The device will communicate with the center via the main channel.
Note
N1 refers to wired network.
Plaorm Access
Plaorm access provides you an opon to manage the devices via plaorm.
Steps
1.
Click Conguraon → Network → Advanced → Plaorm Access to enter the sengs page.
2.
Check the checkbox of Enable to enable the funcon.
3.
Select the Plaorm Access Mode.
Note
Hik-Connect is an applicaon for mobile devices. With the App, you can view live image of the
device, receive alarm nocaon and so on.
4.
Create a Stream Encrypon/Encrypon Key for the device.
Note
6 to 12 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are recommended to use a
combinaon of no less than 8 leers or numbers.
5.
Click Save to enable the sengs.
Set ISUP Parameters
Set the ISUP parameters for accessing device via ISUP protocol.
DS-K1A340 Series Face Recognion Terminal User Manual
80
Steps
Note
The funcon should be supported by the device.
1.
Click Conguraon → Network → Advanced Sengs → Plaorm .
2.
Select ISUP from the plaorm access mode drop-down list.
3.
Check Enable.
4.
Set the ISUP version, server address, device ID, and the ISUP status.
Note
If you select 5.0 as the version, you should set the ISUP key as well.
5.
Click Save.
Enable SDK Service
Aer enabling SDK service, the device can be connected to the SDK server.
Click Conguraon → Network → Advanced → Network Service to enter the sengs page.
Check the checkbox of Enable to enable the funcon.
Click Save to enable the sengs.
9.4.13 Set Video and Audio Parameters
Set the output volumn and voice prompt.
Click Conguraon → Video/Audio → Audio .
Drag the block to adjust the output volumn.
Enable Voice Prompt, and the device will make voice prompts.
Click Save to save the sengs aer the conguraon.
Note
The funcons vary according to dierent models. Refers to the actual device for details.
9.4.14 Customize Audio Content
Customize the output audio content when authencaon succeeded and failed.
Steps
1.
Click Conguraon → Video/Audio → Prompt .
DS-K1A340 Series Face Recognion Terminal User Manual
81
Figure 9-1 Customize Audio Content
2.
Select me schedule.
3.
Enable the funcon.
4.
Set the appellaon.
5.
Set the me period when authencaon succeeded.
1) Click Add.
2) Set the me duraon and the language.
Note
If authencaon is succeeded in the congured me duraon, the device will broadcast the
congured content.
3) Enter the audio content.
4) Oponal: Repeat substep 1 to 3.
5) Oponal: Click to delete the congured me duraon.
6.
Set the me duraon when authencaon failed.
1) Click Add.
2) Set the me duraon and the language.
Note
If authencaon is failed in the congured me duraon, the device will broadcast the
congured content.
3) Enter the audio content.
4) Oponal: Repeat substep 1 to 3.
5) Oponal: Click
to delete the congured me duraon.
DS-K1A340 Series Face Recognion Terminal User Manual
82
7.
Oponal: Add holiday schedule.
1) Click Add to add holiday schedule.
2) Repeat step 3 to 6.
8.
Click Save to save the sengs.
9.4.15 Time and Aendance Sengs
If you want to track and monitor when the persons start/stop work and monitor their working
hours and late arrivals, early departures, me taken on breaks, and absenteeism, you can add the
person to the shi group and assign a shi schedule (a rule for the aendance dening how the
schedule repeats, the shi type, break sengs, and the card swiping rule.) to the shi group to
dene the aendance parameters for the persons in the shi group.
Disable Aendance Mode via Web
Disable the aendance mode and the system will not display the aendance status on the inial
page.
Steps
1.
Click Conguraon → Aendance to enter the sengs page.
2.
Set the Aendance Mode as Disable.
Result
You will not view or congure the aendance status on the inial page. And the system will follow
the aendance rule that congured on the plaorm.
Time Sengs
Steps
1.
Click Conguraon → Time Sengs to enter the sengs page.
2.
Select Status Type.
3.
Oponal: Edit Schedule Name according to the actual needs.
4.
Drag mouse to set the schedule.
Note
Set the schedule from Monday to Sunday according to the actual needs.
5.
Oponal: Select a meline and click Delete. Or click Delete All to clear the sengs.
6.
Click Save.
DS-K1A340 Series Face Recognion Terminal User Manual
83
Set Manual Aendance via Web
Set the aendance mode as manual, and you should select a status manually when you take
aendance.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Click Conguraon → Aendance to enter the sengs page.
2.
Set the Aendance Mode as Manual.
3.
Enable the Aendance Status Required and set the aendace status lasts duraon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
Result
You should select an aendance status manually aer authencaon.
Note
If you do not select a status, the authencaon will be failed and it will not be marked as a valid
aendance.
Set Auto Aendance via Web
Set the aendance mode as auto, and you can set the aendance status and its available schedule.
The system will automacally change the aendance status according to the congured schedule.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Click Conguraon → Aendance to enter the sengs page.
2.
Set the Aendance Mode as Auto.
3.
Enable the Aendance Status funcon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
6.
Set the status' schedule. Refers to Time Sengs for details.
DS-K1A340 Series Face Recognion Terminal User Manual
84
Set Manual and Auto Aendance via Web
Set the aendance mode as Manual and Auto, and the system will automacally change the
aendance status according to the congured schedule. At the same me you can manually
change the aendance status aer the authencaon.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Click Conguraon → Aendance to enter the sengs page.
2.
Set the Aendance Mode as Manual and Auto.
3.
Enable the Aendance Status funcon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
6.
Set the status' schedule. Refers to Time Sengs for details.
Result
On the inial page and authencate. The authencaon will be marked as the congured
aendance status according to the schedule. If you tap the edit icon on the result tab, you can
select a status to take aendance manually, the authencaon will be marked as the edited
aendance status.
Example
If set the Break Out as Monday 11:00, and Break In as Monday 12:00, the valid user's
authencaon from Monday 11:00 to 12:00 will be marked as break.
9.4.16 General Sengs
Set Authencaon Parameters
Click Conguraon → General → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
Click Save to save the sengs aer the conguraon.
Card Reader
You can congure the device card reader's parameters.
DS-K1A340 Series Face Recognion Terminal User Manual
85
Card Reader Type/Card Reader Descripon
Get card reader type and descripon. They are read-only.
Enable Card Reader
Enable the card reader's funcon.
Authencaon
Select an authencaon mode according to your actual needs from the drop-down list.
Mulple People Authencaon
Mulple people can be authencated at the same me.
Recognion Interval
You can set the interval between 2 connuous recognion of a same person during the
authencaon. In the congured interval, Person A can only recognized once. If another person
(Person B) has recognized during the interval, Person A can recognized again.
Alarm of Max. Failed Aempts
Enable to report alarm when the card reading aempts reach the set value.
Max. Authencaon Failed Aempts
Enable to report alarm when the card reading aempts reach the set value.
Set Privacy Parameters
Set the event storage type, picture upload and storage parameters, and the picture clearing
parameters.
Go to Conguraon → General → Privacy .
Event Storage Sengs
Select a method to delete the event. You can select from Delete Old Events Periodically, Delete
Old Events by Specied Time, or Overwring.
Delete Old Events Periodically
Drag the block or enter number to set the period for event deleng. All events will be deleted
according to the congured me duraon.
Delete Old Events by Specied Time
Set a me and all events will be deleted on the congured me.
Overwring
The earliest 5% events will be deleted when the system detects the stored events has been over
95% of the full space.
Authencaon Sengs
Display Authencaon Result
DS-K1A340 Series Face Recognion Terminal User Manual
86
You can check Face Picture, Name, Employee ID and Temperature, to display the authencaon
result.
Name De-idencaon
You can check Name De-idencaon, and the whole name will not be displayed.
ID De-idencaon
You can check ID De-idencaon, and the ID will not be displayed.
Picture Uploading and Storage
Upload Captured Picture When Authencang
Upload the pictures captured when authencang to the plaorm automacally.
Save Captured Picture When Authencang
If you enable this funcon, you can save the picture when authencang to the device.
Save Registered Picture
The registered face picture will be saved to the system if you enable the funcon.
Upload Picture Aer Linked Capture
Upload the pictures captured by linked camera to the plaorm automacally.
Save Pictures Aer Linked Capture
If you enable this funcon, you can save the picture captured by linked camera to the device.
Clear All Pictures in Device
Note
All pictures cannot be restored once they are deleted.
Clear Registered Face Pictures
All registered pictures in the device will be deleted.
Clear Captured Pictures
All captured pictures in the device will be deleted.
Set Face Recognion Parameters
You can set face recognion parameters for accessing.
Click Conguraon → General → Face Recognion Parameters .
You can set Working Mode as Access Control Mode. The access control mode is the device normal
mode. You should authencate your credenal for accessing.
Enable Blocklist Authencaon.
Click Save to save the sengs aer the conguraon.
DS-K1A340 Series Face Recognion Terminal User Manual
87
9.4.17 Title: Local Time and Aendance Sengs
You can set the department management, normal shi management, man-hour shi management,
holiday management and shi sengs for the device.
Manage Department via Web
You can add, edit and delete department informaon via Web.
Steps
1.
Click Conguraon → Time and Aendance → Department Management .
Figure 9-2 Department Management
2.
Click Add to add department.
1) Enter Department Name.
2) Click OK to save the sengs.
3.
Oponal: Manage department informaon.
Edit Department Informaon Click
to edit department informaon.
Delete Department Informaon Click
to delete department informaon.
Manage Normal Shi via Web
You can add, edit and delete normal shi informaon via Web.
Steps
1.
Click Conguraon → Time and Aendance → Normal Shi Management .
2.
Set check in and check out informaon.
DS-K1A340 Series Face Recognion Terminal User Manual
88
Figure 9-3 Check In and Out Sengs
1) Enter Advanced Check In Time, Latest Check In Time and Absence Time (Late).
2) Enter Earliest Check Out Time, Latest Check Out Time and Absence Time (Early Leave).
3.
Click Add to add shi.
Figure 9-4 Shi Informaon
DS-K1A340 Series Face Recognion Terminal User Manual
89
1) Enter Shi Name.
2) Click Add.
3) Set Time Period.
4) Click OK to save the sengs.
4.
Oponal: Manage shi informaon.
Edit Shi Informaon Click
to edit shi informaon.
Delete Shi Informaon Click
to delete shi informaon.
Manage Man-Hour Shi via Web
You can add, edit and delete man-hour shi informaon via Web.
Steps
1.
Click Conguraon → Time and Aendance → Man-Hour Shi Management .
Figure 9-5 Man-Hour Shi Management
2.
Click Add to add shi.
1) Enter Shi Name.
2) Set Work Duraon and Latest On-Work Time.
3) Click Add Duraon.
4) Set Time Period.
5) Click OK to save the sengs.
3.
Oponal: Manage shi informaon.
Edit Shi Informaon Click
to edit shi informaon.
Delete Shi Informaon Click
to delete shi informaon.
DS-K1A340 Series Face Recognion Terminal User Manual
90
Manage Holiday via Web
You can add, edit and delete holiday informaon via Web.
Steps
1.
Click Conguraon → Time and Aendance → Holiday Management .
Figure 9-6 Holiday Management
2.
Click Add to add holiday.
1) Enter Holiday Name.
2) Set Holiday Start Time and Holiday End Time.
3) Click OK to save the sengs.
3.
Oponal: Manage holiday informaon.
Edit Holiday Informaon Click
to edit holiday informaon.
Delete Holiday Informaon Click
to delete holiday informaon.
Manage Shi Schedule by Department
You can add, edit and delete shi schedule by department informaon via Web.
Steps
1.
Click Conguraon → Time and Aendance → Shi Sengs .
DS-K1A340 Series Face Recognion Terminal User Manual
91
Figure 9-7 Shi Schedule by Department
2.
Oponal: Manage shi schedule by department informaon.
Edit Shi Schedule by Department
Informaon
Click
to edit shi schedule by department
informaon.
Delete Shi Schedule by Department
Informaon
Click
to delete shi schedule by department
informaon.
Manage Shi Schedule by Individual
You can add, edit and delete shi schedule by individual informaon via Web.
Steps
1.
Click Conguraon → Time and Aendance → Shi Sengs .
DS-K1A340 Series Face Recognion Terminal User Manual
92
Figure 9-8 Shi Schedule by Individual
2.
Click Add to add shi schedule by individual.
1) Enter Person Name.
2) Set Holiday.
3) Click Add Week Schedule.
4) Enter Week Schedule Name, and set Start Time and End Time.
5) Select duraon and shi.
6) Click OK to save the sengs.
3.
Oponal: Manage shi schedule by individual informaon.
Edit Shi Schedule by Individual
Informaon
Click
to edit shi schedule by individual
informaon.
Delete Shi Schedule by Individual
Informaon
Click
to delete shi schedule by individual
informaon.
9.4.18 Set Biometric Parameters
Set Basic Parameters
Click Conguraon → Smart → Smart .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
Click Save to save the sengs aer the conguraon.
Face Recognion Mode
DS-K1A340 Series Face Recognion Terminal User Manual
93
Normal Mode
Recognize face via the camera normally.
Deep Mode
In the deep mode, you can add the face pictures only via the user adding funcon of the
device or the enrollment staon. It is not supported to add face pictures via pictures
imporng.
Note
In the deep mode, you can add the face pictures only via the device or the enrollment staon. It
is not supported to add face pictures via pictures imporng.
Enable Mulple Faces Authencaon
Aer enabling, mulple people can authencate at the same me.
Face An-spoong
Enable or disable the live face detecon funcon. If enabling the funcon, the device can
recognize whether the person is a live one or not.
Note
Biometric recognion products are not completely applicable to an-spoong environments.
If you require a higher security level, use mulple authencaon modes.
Live Face Detecon Security Level
Aer enabling the face an-spoong funcon, you can set the matching security level when
performing live face authencaon.
Recognion Distance
Select the distance between the authencang user and the device camera.
Applicaon Mode
Select either others or indoor according to actual environment.
Connuous Face Recognion Interval
Set the me interval between two connuous face recognions when authencang.
Pitch Angle
The maximum pitch angle when starng face authencaon.
Yaw Angle
The maximum yaw angle when starng face authencaon.
Min. Detecon Area (Width)
Set the minimum width of the detecon area.
Min. Detecon Area (Height)
Set the minimum height of the detecon area.
DS-K1A340 Series Face Recognion Terminal User Manual
94
Face Grading
Set the face grading according to your needs.
1:1 Matching Threshold
Set the matching threshold when authencang via 1:1 matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate.
1:N Matching Threshold
Set the matching threshold when authencang via 1:N matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate.
Face Recognion Timeout Value
Set the meout value when face recognizing. If the face recognion me is longer than the
congured value, the system will pop up a prompt.
ECO Mode
Aer enabling the ECO mode, the device will use the IR camera to authencate faces in the low
light or dark environment. And you can set the ECO mode threshold, ECO mode (1:N), and ECO
mode (1:1).
ECO Mode (1:1)
Set the matching threshold when authencang via ECO mode 1:1 matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate.
ECO Mode (1:N)
Set the matching threshold when authencang via ECO mode 1:N matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate
Fingerprint Security Level
Select the ngerprint security level.
The higher is the security level, the lower is the false acceptance rate (FAR).
The higher is the security level, the higher is the false rejecon rate (FRR).
Set Recognion Area
Click Conguraon → Smart → Area Conguraon .
Drag the yellow frame in the live video to adjust the recognion area. Only the face within the area
can be recognized by the system.
Set Area Conguraon, Margin (Le), Margin (Right), Margin (Top) and Margin (Boom) as
desired.
Click Save to save the sengs.
Click or to record videos or capture pictures.
9.4.19 Set Theme
You can set the theme for the device.
DS-K1A340 Series Face Recognion Terminal User Manual
95
Click Conguraon → Theme → Media Database to enter the page.
Click Add to add media database le.
Click Upload.
Click Conguraon → Theme → Theme to enter the page.
Click Add Media File.
Note
Only 1 media le can be added.
Click + to select media le and click OK.
Click
to edit media le name.
Set play schedule. Select a theme to play. Drag the me bar in the meline to set the me for the
image to play. Select the me period, you can edit the start and end me of the me period, click
Save or Delete to save or delete the me period. You can also click Delete or Delete All to delete
the selected me period or to delete all me periods.
DS-K1A340 Series Face Recognion Terminal User Manual
96
Chapter 10 Client Soware Conguraon
10.1 Conguraon Flow of Client Soware
Follow the ow diagram below to congure on the client soware.
Figure 10-1 Flow Diagram of Conguraon on Client Soware
10.2 Device Management
The client supports managing access control devices and video intercom devices.
DS-K1A340 Series Face Recognion Terminal User Manual
97
Example
You can control entrance & exit and manage aendance aer adding access control devices to the
client; you can perform video intercom with the indoor staons and door staons.
10.2.1 Add Device
The client provides three device adding modes including by IP/domain, IP segment, and ISUP
protocol. The client also supports imporng mulple devices in a batch when there are large
amount of devices to be added.
Add Device by IP Address or Domain Name
If you know the IP address or domain name of the device to add, you can add devices to the client
by specifying the IP address (or domain name), user name, password, etc.
Steps
1.
Enter Device Management module.
2.
Click Device tab on the top of the right panel.
The added devices are displayed on the right panel.
3.
Click Add to open the Add window, and then select IP/Domain as the adding mode.
4.
Enter the required informaon.
Name
Create a descripve name for the device. For example, you can use a nickname that can show
the locaon or feature of the device.
Address
The IP address or domain name of the device.
Port
The devices to add share the same port number. The default value is 80.
User Name
Enter the device user name. By default, the user name is admin.
Password
Enter the device password.
Cauon
The password strength of the device can be automacally checked. We highly recommend
you change the password of your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers, lower case leers, numbers,
and special characters) in order to increase the security of your product. And we recommend
DS-K1A340 Series Face Recognion Terminal User Manual
98
you change your password regularly, especially in the high security system, changing the
password monthly or weekly can beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
5.
Oponal: Check Transmission Encrypon (TLS) to enable transmission encrypon using TLS
(Transport Layer Security) protocol for security purpose.
Note
●
This funcon should be supported by the device.
●
If you have enabled Cercate Vericaon, you should click Open Cercate Directory to
open the default folder, and copy the cercate le exported from the device to this default
directory to strengthen the security. See for details about enabling cercate vericaon.
●
You can log into the device to get the cercate le by web browser.
6.
Check Synchronize Time to synchronize the device me with the PC running the client aer
adding the device to the client.
7.
Oponal: Check Import to Group to create a group by the device name, and import all the
channels of the device to this group.
Example
For access control device, its access points, alarm inputs/outputs, and encoding channels (if
exist) will be imported to this group.
8.
Finish adding the device.
-
Click Add to add the device and back to the device list page.
-
Click Add and New to save the sengs and connue to add other device.
Import Devices in a Batch
You can add mulple devices to the client in a batch by entering the device parameters in a pre-
dened CSV le.
Steps
1.
Enter the Device Management module.
2.
Click Device tab on the top of the right panel.
3.
Click Add to open the Add window, and then select Batch Import as the adding mode.
4.
Click Export Template and then save the pre-dened template (CSV le) on your PC.
5.
Open the exported template le and enter the required informaon of the devices to be added
on the corresponding column.
Note
For detailed descripon of the required elds, refer to the introducons in the template.
Adding Mode
Enter 0 or 1 or 2.
DS-K1A340 Series Face Recognion Terminal User Manual
99
Address
Edit the address of the device.
Port
Enter the device port number. The default port number is 80.
User Name
Enter the device user name. By default, the user name is admin.
Password
Enter the device password.
Cauon
The password strength of the device can be automacally checked. We highly recommend
you change the password of your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers, lower case leers, numbers,
and special characters) in order to increase the security of your product. And we recommend
you change your password regularly, especially in the high security system, changing the
password monthly or weekly can beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
Import to Group
Enter 1 to create a group by the device name. All the channels of the device will be imported
to the corresponding group by default. Enter 0 to disable this funcon.
6.
Click and select the template le.
7.
Click Add to import the devices.
10.2.2 Reset Device Password
If you forgot the password of the detected online devices, you can reset the device password via
the client.
Steps
1.
Enter Device Management page.
2.
Click Online Device to show the online device area.
All the online devices sharing the same subnet will be displayed in the list.
3.
Select the device from the list and click on the Operaon column.
4.
Reset the device password.
-
Click Generate to pop up the QR Code window and click Download to save the QR code to
your PC. You can also take a photo of the QR code to save it to your phone. Send the picture
to our technical support.
DS-K1A340 Series Face Recognion Terminal User Manual
100
Note
For the following operaons for reseng the password, contact our technical support.
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
10.2.3 Manage Added Devices
Aer adding devices to device list, you can manage the added devices including eding device
parameters, remote conguraon, viewing device status, etc.
Table 10-1 Manage Added Devices
Edit Device Click to edit device informaon including device name, address, user
name, password, etc.
Delete Device Check one or more devices, and click Delete to delete the selected
devices.
Remote Conguraon Click to set remote conguraon of the corresponding device. For
details, refer to the user manual of device.
View Device Status Click to view device status, including door No., door status, etc.
Note
For dierent devices, you will view dierent informaon about device
status.
View Online User Click to view the details of online user who access the device,
including user name, user type, IP address and login me.
Refresh Device
Informaon
Click to refresh and get the latest device informaon.
DS-K1A340 Series Face Recognion Terminal User Manual
101
Upgrade Device View device status on Firmware Upgrade column, check one or more
upgradable devices, and click Upgrade Device Firmware to upgrade the
selected devices. For details, refer to .
Get Events from Device Check one device, and click Get Events from Device to synchronize
events. For details, refer to .
10.3 Group Management
The client provides groups to manage the added resources in dierent groups. You can group the
resources into dierent groups according to the resources' locaons.
Example
For example, on the 1st oor, there mounted 16 doors, 64 alarm inputs, and 16 alarm outputs. You
can organize these resources into one group (named 1st Floor) for convenient management. You
can control door status, and do some other operaons of the devices aer managing the resources
by groups.
10.3.1 Add Group
You can add group to organize the added device for convenient management.
Steps
1.
Enter the Device Management module.
2.
Click Device Management → Group to enter the group management page.
3.
Create a group.
-
Click Add Group and enter a group name as you want.
-
Click Create Group by Device Name and select an added device to create a new group by the
name of the selected device.
Note
The resources (such as alarm inputs/outputs, access points, etc.) of this device will be
imported to the group by default.
10.3.2 Import Resources to Group
You can import the device resources (such as alarm inputs/outputs, access points, etc.) to the
added group in a batch.
Before You Start
Add a group for managing devices. Refer to
Add Group .
DS-K1A340 Series Face Recognion Terminal User Manual
102
Steps
1.
Enter the Device Management module.
2.
Click Device Management → Group to enter the group management page.
3.
Select a group from the group list and select the resource type as Access Point, Alarm Input,
Alarm Output, etc.
4.
Click Import.
5.
Select the thumbnails/names of the resources in the thumbnail/list view.
Note
You can click or to switch the resource display mode to thumbnail view or to list view.
6.
Click Import to import the selected resources to the group.
10.4 Person Management
You can add person informaon to the system for further operaons such as access control, video
intercom, me and aendance, etc. You can manage the added persons such as issuing cards to
them in a batch, imporng and exporng person informaon in a batch, etc.
10.4.1 Add Organizaon
You can add an organizaon and import person informaon to the organizaon for eecve
management of the persons. You can also add a surbodinate organizaon for the added one.
Steps
1.
Enter Person module.
2.
Select a parent organizaon in the le column and click Add in the upper-le corner to add an
organizaon.
3.
Create a name for the added organizaon.
Note
Up to 10 levels of organizaons can be added.
4.
Oponal: Perform the following operaon(s).
Edit Organizaon Hover the mouse on an added organizaon and click
to edit its name.
Delete
Organizaon
Hover the mouse on an added organizaon and click
to delete it.
Note
●
The lower-level organizaons will be deleted as well if you delete an
organizaon.
●
Make sure there is no person added under the organizaon, or the
organizaon cannot be deleted.
DS-K1A340 Series Face Recognion Terminal User Manual
103
Show Persons in
Sub Organizaon
Check Show Persons in Sub Organizaon and select an organizaon to
show persons in its sub organizaons.
10.4.2 Import and Export Person Idenfy Informaon
You can import the informaon and pictures of mulple persons to the client soware in a batch.
Meanwhile, you can also export the person informaon and pictures and save them in your PC.
Import Person Informaon
You can enter the informaon of mulple persons in a predened template (CSV/Excel le) to
import the informaon to the client in a batch.
Steps
1.
Enter the Person module.
2.
Select an added organizaon in the list, or click Add in the upper-le corner to add an
organizaon and then select it.
3.
Click Import to open the Import panel.
4.
Select Person Informaon as the imporng mode.
5.
Click Download Template for Imporng Person to download the template.
6.
Enter the person informaon in the downloaded template.
Note
●
If the person has mulple cards, separate the card No. with semicolon.
●
Items with asterisk are required.
●
By default, the Hire Date is the current date.
7.
Click to select the CSV/Excel le with person informaon from local PC.
8.
Click Import to start imporng.
Note
●
If a person No. already exists in the client's database, delete the exisng informaon before
imporng.
●
You can import informaon of no more than 2,000 persons.
Import Person Pictures
Aer imporng face pictures for the added persons to the client, the persons in the pictures can be
idened by an added face recognion terminal. You can either import person pictures one by
one, or import mulple pictures at a me according to your need.
Before You Start
Be sure to have imported person informaon to the client beforehand.
DS-K1A340 Series Face Recognion Terminal User Manual
104
Steps
1.
Enter the Person module.
2.
Select an added organizaon in the list, or click Add in the upper-le corner to add an
organizaon and then select it.
3.
Click Import to open the Import panel and check Face.
4.
Oponal: Enable Verify by Device to check whether face recognion device managed in the
client can recognize the face in the photo.
5.
Click to select a face picture le.
Note
●
The (folder of) face pictures should be in ZIP format.
●
Each picture le should be in JPG format and should be no larger than 200 KB.
●
Each picture le should be named as "Person ID_Name". The Person ID should be the same
with that of the imported person informaon.
6.
Click Import to start imporng.
The imporng progress and result will be displayed.
Export Person Informaon
You can export the added persons' informaon to local PC as a CSV/Excel le.
Before You Start
Make sure you have added persons to an organizaon.
Steps
1.
Enter the Person module.
2.
Oponal: Select an organizaon in the list.
Note
All persons' informaon will be exported if you do not select any organizaon.
3.
Click Export to open the Export panel.
4.
Check Person Informaon as the content to export.
5.
Check desired items to export.
6.
Click Export to save the exported le in CSV/Excel le on your PC.
Export Person Pictures
You can export face picture le of the added persons and save in your PC.
Before You Start
Make sure you have added persons and their face pictures to an organizaon.
DS-K1A340 Series Face Recognion Terminal User Manual
105
Steps
1.
Enter the Person module.
2.
Oponal: Select an organizaon in the list.
Note
All persons' face pictures will be exported if you do not select any organizaon.
3.
Click Export to open the Export panel and check Face as the content to export.
4.
Click Export to start exporng.
Note
●
The exported le is in ZIP format.
●
The exported face picture is named as "Person ID_Name_0" ("0" is for a full-frontal face).
10.4.3 Get Person Informaon from Access Control Device
If the access control device has been congured with person informaon (including person details,
ngerprint, and issued card informaon), you can get the person informaon from the added
device and import them to the client for further operaons.
Steps
Note
●
If the person name stored in the device is empty, the person name will be lled with the issued
card No. aer imporng to the client.
●
If the card number or person ID (employee ID) stored on the device already exists in the client
database, the person with this card number or person ID will not be imported to the client.
1.
Enter Person module.
2.
Select an organizaon to import the persons.
3.
Click Get from Device.
4.
Select an added access control device or the enrollment staon from the drop-down list.
Note
If you select the enrollment staon, you should click Login, and enter IP address, port No., user
name and password of the device.
5.
Select the Geng Mode.
Note
The geng mode varies according to dierent devices. The access control device supports
geng the person informaon by employee ID. Up to 5 employee IDs can be specied each
me.
6.
Click Import to start imporng the person informaon to the client.
DS-K1A340 Series Face Recognion Terminal User Manual
106
Note
Up to 2,000 persons and 5,000 cards can be imported.
The person informaon, including person details, person's ngerprint informaon (if
congured), and the linked cards (if congured), will be imported to the selected organizaon.
10.4.4 Issue Cards to Persons in Batch
The client provides a convenient way to issue cards to mulple persons in a batch.
Steps
1.
Enter Person module.
2.
Click Batch Issue Cards.
All the added persons with no card issued will be displayed in the right panel.
3.
Oponal: Enter key words (name or person ID) in the input box to lter the person(s) that need
issuing cards.
4.
Oponal: Click Sengs to set the card issuing parameters. For details, refer to Issue a Card by
Local Mode.
5.
Click Inialize to inialize the card enrollment staon or card reader to make it ready for issuing
cards.
6.
Click the Card No. column and enter the card number.
-
Place the card on the card enrollment staon.
-
Swipe the card on the card reader.
-
Manually enter the card number and press the Enter key.
The person(s) in the list will be issued with card(s).
10.4.5 Report Card Loss
If the person lost his/her card, you can report the card loss so that the card's related access
authorizaon will be inacve.
Steps
1.
Enter Person module.
2.
Select the person you want to report card loss for and click Edit to open the Edit Person window.
3.
In the Credenal → Card panel, click
on the added card to set this card as lost card.
Aer reporng card loss, the access authorizaon of this card will be invalid and inacve. Other
person who gets this card cannot access the doors by swiping this lost card.
4.
Oponal: If the lost card is found, you can click to cancel the loss.
Aer cancelling card loss, the access authorizaon of the person will be valid and acve.
5.
If the lost card is added in one access group and the access group is applied to the device
already, aer reporng card loss or cancelling card loss, a window will pop up to nofy you to
DS-K1A340 Series Face Recognion Terminal User Manual
107
apply the changes to the device. Aer applying to device, these changes can take eect on the
device.
10.4.6 Set Card Issuing Parameters
The client provides two modes for reading a card's number: via card enrollment staon or via the
card reader of the access control device. If a card enrollment staon is available, connect it to the
PC running the client by USB interface or COM, and place the card on the card enrollment to read
the card number. If not, you can also swipe the card on the card reader of the added access control
device to get the card number. As a result, before issuing a card to one person, you need to set the
card issuing parameters including the issuing mode and related parameters.
When adding a card to one person, click Sengs to open the Card Issuing Sengs window.
Local Mode: Issue Card by Card Enrollment Staon
Connect a card enrollment staon to the PC running the client. You can place the card on the card
enrollment staon to get the card number.
Card Enrollment Staon
Select the model of the connected card enrollment staon
Note
Currently, the supported card enrollment staon models include DS-K1F100-D8, DS-K1F100-M,
DS-K1F100-D8E, and DS-K1F180-D8E.
Card Type
This eld is only available when the model is DS-K1F100-D8E or DS-K1F180-D8E.
Select the card type as EM card or IC card according to the actual card type.
Serial Port
It is only available when the model is DS-K1F100-M.
Select the COM the card enrollment staon connects to.
Buzzing
Enable or disable the buzzing when the card number is read successfully.
Card No. Type
Select the type of the card number according to actual needs.
M1 Card Encrypon
This eld is only available when the model is DS-K1F100-D8, DS-K1F100-D8E, or DS-K1F180-D8E.
If the card is M1 card, and if you need to enable the M1 Card Encrypon funcon, you should
enable this funcon and select the sector of the card to encrypt.
DS-K1A340 Series Face Recognion Terminal User Manual
108
Remote Mode: Issue Card by Card Reader
Select an access control device added in the client and swipe the card on its card reader to read
the card number.
10.5 Congure Schedule and Template
You can congure the template including holiday and week schedule. Aer seng the template,
you can adopt the congured template to access groups when seng the access groups, so that
the access group will take eect in the me duraons of the template.
Note
For access group sengs, refer to Set Access Group to Assign Access Authorizaon to Persons .
10.5.1 Add Holiday
You can create holidays and set the days in the holidays, including start date, end date, and holiday
duraon in one day.
Steps
Note
You can add up to 64 holidays in the soware system.
1.
Click Access Control → Schedule → Holiday to enter the Holiday page.
2.
Click Add on the le panel.
3.
Create a name for the holiday.
4.
Oponal: Enter the descripons or some nocaons of this holiday in the Remark box.
5.
Add a holiday period to the holiday list and congure the holiday duraon.
Note
Up to 16 holiday periods can be added to one holiday.
1) Click Add in the Holiday List eld.
2) Drag the cursor to draw the me duraon, which means in that duraon of me, the
congured access group is acvated.
Note
Up to 8 me duraons can be set to one holiday period.
3) Oponal: Perform the following operaons to edit the me duraons.
DS-K1A340 Series Face Recognion Terminal User Manual
109
●
Move the cursor to the me duraon and drag the me duraon on the meline bar to the
desired posion when the cursor turns to .
●
Click the me duraon and directly edit the start/end me in the appeared dialog.
●
Move the cursor to the start or the end of me duraon and drag to lengthen or shorten
the me duraon when the cursor turns to .
4) Oponal: Select the me duraon(s) that need to be deleted, and then click in the
Operaon column to delete the selected me duraon(s).
5) Oponal: Click in the Operaon column to clear all the me duraon(s) in the me bar.
6) Oponal: Click in the Operaon column to delete this added holiday period from the
holiday list.
6.
Click Save.
10.5.2 Add Template
Template includes week schedule and holiday. You can set week schedule and assign the me
duraon of access authorizaon for dierent person or group. You can also select the added
holiday(s) for the template.
Steps
Note
You can add up to 255 templates in the soware system.
1.
Click Access Control → Schedule → Template to enter the Template page.
Note
There are two default templates: All-Day Authorized and All-Day Denied, and they cannot be
edited or deleted.
All-Day Authorized
The access authorizaon is valid in each day of the week and it has no holiday.
All-Day Denied
The access authorizaon is invalid in each day of the week and it has no holiday.
2.
Click Add on the le panel to create a new template.
3.
Create a name for the template.
4.
Enter the descripons or some nocaon of this template in the Remark box.
5.
Edit the week schedule to apply it to the template.
1) Click Week Schedule tab on the lower panel.
2) Select a day of the week and draw me duraon(s) on the meline bar.
Note
Up to 8 me duraon(s) can be set for each day in the week schedule.
3) Oponal: Perform the following operaons to edit the me duraons.
DS-K1A340 Series Face Recognion Terminal User Manual
110
●
Move the cursor to the me duraon and drag the me duraon on the meline bar to the
desired posion when the cursor turns to .
●
Click the me duraon and directly edit the start/end me in the appeared dialog.
●
Move the cursor to the start or the end of me duraon and drag to lengthen or shorten
the me duraon when the cursor turns to .
4) Repeat the two steps above to draw more me duraons on the other days of the week.
6.
Add a holiday to apply it to the template.
Note
Up to 4 holidays can be added to one template.
1) Click Holiday tab.
2) Select a holiday in the le list and it will be added to the selected list on the right panel.
3) Oponal: Click Add to add a new holiday.
Note
For details about adding a holiday, refer to Add Holiday .
4) Oponal: Select a selected holiday in the right list and click to remove the selected one, or
click Clear to clear all the selected holiday(s) in the right list.
7.
Click Save to save the sengs and nish adding the template.
10.6 Set Access Group to Assign Access Authorizaon to Persons
Aer adding the person and conguring the person's credenals, you can create the access groups
to dene which person(s) can get access to which door(s) and then apply the access group to the
access control device to take eect.
Before You Start
●
Add person to the client.
●
Add access control device to the client and group access points. For details, refer to
Group
Management .
●
Add template.
Steps
When the access group sengs are changed, you need to apply the access groups to the devices
again to take eect. The access group changes include changes of template, access group sengs,
person's access group sengs, and related person details (including card number, ngerprint, face
picture, linkage between card number and ngerprint, linkage between card number and
ngerprint, card password, card eecve period, etc).
1.
Click Access Control → Authorizaon → Access Group to enter the Access Group interface.
2.
Click Add to open the Add window.
3.
In the Name text eld, create a name for the access group as you want.
4.
Select a template for the access group.
DS-K1A340 Series Face Recognion Terminal User Manual
111
Note
You should congure the template before access group sengs. Refer to Congure Schedule
and Template for details.
5.
In the le list of the Select Person eld, select person(s) to assign access authority.
6.
In the le list of the Select Access Point eld, select door(s), door staon(s) or oor(s) for the
selected persons to access.
7.
Click Save.
You can view the selected person(s) and the selected access point(s) on the right side of the
interface.
Figure 10-2 Display the Selected Person(s) and Access Point(s)
8.
Aer adding the access groups, you need to apply them to the access control device to take
eect.
1) Select the access group(s) to apply to the access control device.
2) Click Apply All to Devices start applying all the selected access group(s) to the access control
device or door staon.
3) Click Apply All to Devices or Apply Changes to Devices.
Apply All to Devices
This operaon will clear all the existed access groups of the selected devices and then
apply the new access group to the device.
Apply Changes to Devices
DS-K1A340 Series Face Recognion Terminal User Manual
112
This operaon will not clear the existed access groups of the selected devices and only
apply the changed part of the selected access group(s) to the device(s).
4) View the applying status in the Status column or click Applying Status to view all the applied
access group(s).
Note
You can check Display Failure Only to lter the applying results.
The selected persons in the applied access groups will have the authorizaon to enter/exit the
selected doors/door staons with their linked card(s) or ngerprints.
9.
Oponal: Click to edit the access group if necessary.
Note
If you change the persons' access informaon or other related informaon, you will view the
promptAccess Group to Be Applied on the right corner of the client.
You can click the prompt to apply the changed data to the device. You can select either Apply
Now or Apply Later.
Figure 10-3 Data Synchronizaon
10.7 Congure Advanced Funcons
You can congure the advanced funcons of access control to meet some special requirements in
dierent scene.
Note
●
For the card related funcons(the type of access control card), only the card(s) with access group
applied will be listed when adding cards.
●
The advanced funcons should be supported by the device.
●
Hover the cursor on the Advanced Funcon, and then Click to customize the advanced
funcon(s) to be displayed.
DS-K1A340 Series Face Recognion Terminal User Manual
113
10.7.1 Congure Device Parameters
Aer adding the access control device, you can congure the parameters of access control device,
access control points.
Congure Parameters for Access Control Device
Aer adding the access control device, you can congure its parameters, including overlaying user
informaon on picture, uploading pictures aer capturing, saving captured pictures, etc.
Before You Start
Add access control device to the client.
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter .
Note
If you can not nd Device Parameter in the Advanced Funcon list, hover the cursor on the
Advanced Funcon, and then Click to select the Device Parameter to be displayed.
2.
Select an access device to show its parameters on the right page.
3.
Turn the switch to ON to enable the corresponding funcons.
Note
●
The displayed parameters may vary for dierent access control devices.
●
Some of the following parameters are not listed in the Basic Informaon page, click More to
edit the parameters.
RS-485 Comm. Redundancy
You should enable this funcon if you wire the RS-485 card reader to the access control
device redundantly.
Display Detected Face
Display face picture when authencang.
Display Card Number
Display the card informaon when authencang.
Display Person Informaon
Display the person informaon when authencang.
Overlay Person Info. on Picture
Display the person informaon on the captured picture.
Voice Prompt
If you enable this funcon, the voice prompt is enabled in the device. You can hear the voice
prompt when operang in the device.
DS-K1A340 Series Face Recognion Terminal User Manual
114
Upload Pic. Aer Linked Capture
Upload the pictures captured by linked camera to the system automacally.
Save Pic. Aer Linked Capture
If you enable this funcon, you can save the picture captured by linked camera to the device.
Press Key to Enter Card Number
If you enable this funcon, you can input the card No. by pressing the key.
Wi-Fi Probe
If you enable this funcon, the device can probe the surrounding communicaon devices'
MAC address and upload the MAC address to the system. If the MAC address match the
specied MAC address, the system can trigger some linkage acons.
3G/4G
If you enable this funcon, the device can communicate in 3G/4G network.
NFC An-Cloning
If you enable this funcon, you cannot use the cloned card for authencaon and further
enhance security.
4.
Click OK.
5.
Oponal: Click Copy to, and then select the access control device(s) to copy the parameters in
the page to the selected device(s).
Congure Parameters for Door
Aer adding the access control device, you can congure its access point (door) parameters.
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter .
2.
Select an access control device on the le panel, and then click
to show the doors or oors of
the selected device.
3.
Select a door to show its parameters on the right page.
4.
Edit the door parameters.
Note
●
The displayed parameters may vary for dierent access control devices.
●
Some of the following parameters are not listed in the Basic Informaon page, click More to
edit the parameters.
Dismiss Code
Create a dismiss code which can be used to stop the buzzer of the card reader (by entering
the dismiss code on the keypad).
DS-K1A340 Series Face Recognion Terminal User Manual
115
Note
●
The dismiss code should be dierent from the authencaon password.
●
The length of the dismiss code is according the device, usually it should contains 4 to 8 digits.
5.
Click OK.
6.
Oponal: Click Copy to , and then select the door(s) to copy the parameters in the page to the
selected door(s).
Note
The door's status duraon sengs will be copied to the selected door(s) as well.
Congure Parameters for Card Reader
Aer adding the access control device, you can congure its card reader parameters.
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter .
2.
In the device list on the le, click to expand the door, select a card reader and you can edit the
card reader's parameters on the right.
3.
Edit the card reader basic parameters in the Basic Informaon page.
Note
●
The displayed parameters may vary for dierent access control devices. There are part of
parameters listed as follows. Refer to the user manual of the device for more details.
●
Some of the following parameters are not listed in the Basic Informaon page, click More to
edit the parameters.
Name
Edit the card reader name as desired.
Minimum Card Swiping Interval
If the interval between card swiping of the same card is less than the set value, the card
swiping is invalid. You can set it as 0 to 255.
Alarm of Max. Failed Aempts
Enable to report alarm when the card reading aempts reach the set value.
Max. Times of Card Failure
Set the max. failure aempts of reading card.
Card Reader Type/Card Reader Descripon
Get card reader type and descripon. They are read-only.
Default Authencaon Mode
View the default card reader authencaon mode.
DS-K1A340 Series Face Recognion Terminal User Manual
116
Fingerprint Capacity
View the maximum number of available ngerprints.
Exisng Fingerprint Number
View the number of existed ngerprints in the device.
4.
Click Advanced and you can congure more parameters.
Enable Card Reader
Enable the funcon and you can operate the funcons below on the card reader.
Buzzer Polarity
Set Buzzer Polarity of main board according to the card reader parameters. Generally, adopts
the default sengs.
Max. Interval When Entering PWD
When you inpung the password on the card reader, if the interval between pressing two
digits is larger than the set value, the digits you pressed before will be cleared automacally.
Fingerprint Recognion Level
Select the ngerprint recognion level from the drop-down list.
Fingerprint Recognion Interval
Select the ngerprint recognion interval from the drop-down list.
5.
Click OK.
6.
Oponal: Click Copy to, and then select the card reader(s) to copy the parameters in the page to
the selected card reader(s).
Congure Parameters for Alarm Output
Aer adding the access control device, if the device links to alarm outputs, you can congure the
parameters.
Before You Start
Add access control device to the client, and make sure the device supports alarm output.
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter to enter access control
parameter conguraon page.
2.
In the device list on the le, click
to expand the door, select an alarm input and you can edit
the alarm input's parameters on the right.
3.
Set the alarm output parameters.
Name
Edit the card reader name as desired.
Alarm Output Acve Time
How long the alarm output will last aer triggered.
4.
Click OK.
DS-K1A340 Series Face Recognion Terminal User Manual
117
5.
Oponal: Set the switch on the upper right corner to ON to trigger the alarm output.
Congure Parameters for Lane Controller
Aer adding the lane controller to the client, you can congure its parameters for passing through
the lane.
Before You Start
Add access control device to the client.
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter to enter Parameter Sengs
page.
2.
In the device list on the le, select a lane controller and you can edit the lane controller's
parameters on the right.
3.
Edit the parameters.
Passing Mode
Select the controller which will control the barrier status of the device.
●
If you select According to Lane Controller's DIP Sengs, the device will follow the lane
controller's DIP sengs to control the barrier. The sengs on the soware will be invalid.
●
If you select According to Main Controller's Sengs, the device will follow the sengs of
the soware to control the barrier. The DIP sengs of the lane controller will be invalid.
Free Passing Authencaon
If you enable this funcon, when both entrance and exit's barrier mode is Remain Open, the
pedestrians should authencate each me passing through the lane. Or an alarm will be
triggered.
Opening/Closing Barrier Speed
Set the barrier's opening and closing speed. You can select from 1 to 10. The greater the
value, the faster the speed.
Note
The recommended value is 6.
Audible Prompt Duraon
Set how long the audio will last, which is played when an alarm is triggered .
Note
0 refers to the alarm audio will be played unl the alarm is ended.
Temperature Unit
Select the temperature unit that displayed in the device status.
4.
Click OK.
DS-K1A340 Series Face Recognion Terminal User Manual
118
10.7.2 Congure Device Parameters
Aer adding the access control device, you can set its parameters such as network parameters.
Set Parameters for Face Recognion Terminal
For face recognion terminal, you can set its parameters including face picture database, QR code
authencaon, etc.
Steps
Note
This funcon should be supported by the device.
1.
Enter the Access Control module.
2.
On the navigaon bar on the le, enter Advanced Funcon → More Parameters .
3.
Select an access control device in the device list and click Face Recognion Terminal.
4.
Set the parameters.
Note
These parameters displayed vary according to dierent device models.
COM
Select a COM port for conguraon. COM1 refers to the RS-485 interface and COM2 refers to
the RS-232 interface.
Face Picture Database
select Deep Learning as the face picture database.
Authencate by QR Code
If enabled, the device camera can scan the QR code to authencate. By default, the funcon
is disabled.
Blocklist Authencaon
If enabled, the device will compare the person who want to access with the persons in the
blocklist.
If matched (the person is in the blocklist), the access will be denied and the device will upload
an alarm to the client.
If mismatched (the person is not in the blocklist), the access will be granted.
Save Authencang Face Picture
If enabled, the captured face picture when authencang will be saved on the device.
MCU Version
View the device MCU version.
DS-K1A340 Series Face Recognion Terminal User Manual
119
5.
Click Save.
Set RS-485 Parameters
You can set the access control device's RS-485 parameters including the baud rate, data bit, the
stop bit, parity type, ow control type, communicaon mode, work mode, and connecon mode.
Steps
Note
The RS-485 Sengs should be supported by the device.
1.
Enter the Access Control module.
2.
On the navigaon bar on the le, enter Advanced Funcon → More Parameters .
3.
Select an access control device in the device list and click RS-485 to enter the RS-485 Sengs
page.
4.
Select the serial port number from the drop-down list to set the RS-485 parameters.
5.
Set the serial number, external device, authencaon center, baud rate, data bit, stop bit, parity
type, ow control type, communicaon mode, and working mode in the drop-down list.
6.
Click Save.
●
The congured parameters will be applied to the device automacally.
●
When you change the working mode or connecon mode, the device will reboot
automacally.
Set Wiegand Parameters
You can set the access control device's Wiegand channel and the communicaon mode. Aer
seng the Wiegand parameters, the device can connect to Wiegand card reader via Wiegand
communicaon.
Steps
Note
This funcon should be supported by the device.
1.
Enter the Access Control module.
2.
On the navigaon bar on the le, enter Advanced Funcon → More Parameters .
3.
Select an access control device in the device list and click Wiegand to enter the Wiegand
Sengs page.
4.
Set the switch to on to enable the Wiegand funcon for the device.
5.
Select the Wiegand channel No. and the communicaon mode from the drop-down list.
DS-K1A340 Series Face Recognion Terminal User Manual
120
Note
If you set Communicaon Direcon as Sending, you are required to set the Wiegand Mode as
Wiegand 26 or Wiegand 34.
6.
Check Enable Wiegand to enable the Wiegand funcon.
7.
Click Save.
●
The congured parameters will be applied to the device automacally.
●
Aer changing the communicaon direcon, the device will reboot automacally.
Enable M1 Card Encrypon
M1 card encrypon can improve the security level of authencaon.
Steps
Note
The funcon should be supported by the access control device and the card reader.
1.
Enter the Access Control module.
2.
On the navigaon bar on the le, enter Advanced Funcon → More Parameters .
3.
Select an access control device in the device list and click M1 Card Encrypon Vericaon to
enter the M1 Card Encrypon Vericaon page.
4.
Set the switch to on to enable the M1 card encrypon funcon.
5.
Set the sector ID.
Note
●
The sector ID ranges from 1 to 100.
●
By default, Sector 13 is encrypted. It is recommended to encrypt sector 13.
6.
Click Save to save the sengs.
10.8 Door Control
In Monitoring module, you can view the real-me status of the doors managed by the added
access control device. You can also view the access details and person details.
Note
For the user with door control permission, the user can enter the Monitoring module and control
the door. Or the icons used for control will not show. For seng the user permission, refer to Add
User in the user manual of the client soware.
DS-K1A340 Series Face Recognion Terminal User Manual
121
10.8.1 Control Door Status
You can control the status for the door(s), including unlock door, locking door, remaining the door
unlock, remaining the door locked, remain all unlocked, etc.
Before You Start
●
Add person and assign access authorizaon to designed person, and person will have the access
authorizaon to the access points (doors). For details, refer to Person Management and Set
Access Group to Assign Access Authorizaon to Persons .
●
Make sure the operaon user has the permission of the access points (doors). For details, refer
to .
Steps
1.
Click Monitoring to enter the status monitoring page.
2.
Select an access point group on the upper-right corner.
Note
For managing the access point group, refer to Group Management .
The doors in the selected access control group will display.
3.
Click a door icon to select a door, or press Ctrl and select mulple doors.
Note
For Remain All Unlocked and Remain All Locked, ignore this step.
4.
Click the following buons to control the door.
Unlock
When the door is locked, unlock it and it will be open for once. Aer the open duraon, the
door will be closed and locked again automacally.
Lock
When the door is unlocked, lock it and it will be closed. The person who has the access
authorizaon can access the door with credenals.
Remain Unlocked
The door will be unlocked (no maer closed or open). All the persons can access the door
with no credenals required.
Remain Locked
The door will be closed and locked. No person can access the door even if he/she has the
authorized credenals, except the super users.
Remain All Unlocked
All doors in the group will be unlocked (no maer closed or open). All the persons can access
the doors with no credenals required.
Remain All Locked
DS-K1A340 Series Face Recognion Terminal User Manual
122
All doors in the group will be closed and locked. No person can access the doors even if
he/she has the authorized credenals, except the super users.
Capture
Capture a picture manually.
Note
The Capture buon is available when the device supports capture funcon. The picture is
saved in the PC running the client. For seng the saving path, refer to Set File Saving Path in
the user manual of the client soware.
Result
The icon of the doors will change in real-me according to the operaon if the operaon is
succeeded.
10.8.2 Check Real-Time Access Records
The real-me access records can be displayed in the client, including card swiping records, face
recognion records, skin-surface temperature informaon, etc. Also, you can view the person
informaon and view the picture captured during access.
Before You Start
You have added person(s) and access control device(s) to the client. For details, refer to Person
Management and Add Device .
Steps
1.
Click Monitoring to enter monitoring module.
Real-me access records are displayed on the boom of the page. You can view record details,
including card No., person name, event me, door locaon, temperature, authencaon type
etc.
Figure 10-4 Real-me Access Records
DS-K1A340 Series Face Recognion Terminal User Manual
123
Note
You can right click the column name of access event table to show or hide the column according
to actual needs.
2.
Oponal: Select an access point group from the drop-down list in the upper-right corner to
show the real me access records of the selected group.
3.
Oponal: Check the event type and event status.
The detected events of checked type and status will be displayed in the list below.
4.
Oponal: Check Show Latest Event to view the latest access record.
The record list will be listed reverse chronologically.
5.
Oponal: Check Enable Abnormal Temperature Prompt to enable abnormal skin-surface
temperature prompt.
Note
When enabled, if there is abnormal temperature informaon, an Abnormal Temperature
window pops up when you enter Monitoring module, displaying person's picture, skin-surface
temperature, card No., person name, etc.
6.
Oponal: Click an event to view person pictures (including captured picture and prole).
Note
In Linked Capture Picture eld, you can double click the captured picture to view an enlarged
picture.
7.
Oponal: Click to view details (including person's detailed informaon and the captured
picture).
Note
In the pop-up window, you can click to view details in full screen.
DS-K1A340 Series Face Recognion Terminal User Manual
124
Chapter 11 Dimensions
Figure 11-1 Dimensions (With Fingerprint)
Figure 11-2 Dimensions (Without Fingerprint)
DS-K1A340 Series Face Recognion Terminal User Manual
125
Appendix A. Tips for Installaon Environment
1. Light Source Illuminaon Reference Value
Candle: 10Lux
Bulb: 100~850Lux
Sunlight: More than 1200Lux
2. Avoid backlight, direct and indirect sunlight
DS-K1A340 Series Face Recognion Terminal User Manual
126
Appendix B. Tips for Scanning Fingerprint
Recommended Finger
Forenger, middle nger or the third nger.
Correct Scanning
The gure displayed below is the correct way to scan your nger:
You should press your nger on the scanner horizontally. The center of your scanned nger should
align with the scanner center.
Incorrect Scanning
The gures of scanning ngerprint displayed below are incorrect:
DS-K1A340 Series Face Recognion Terminal User Manual
127
Environment
The scanner should avoid direct sun light, high temperature, humid condions and rain.
When it is dry, the scanner may not recognize your ngerprint successfully. You can blow your
nger and scan again.
Others
If your ngerprint is shallow, or it is hard to scan your ngerprint, we recommend you to use other
authencaon methods.
If you have injuries on the scanned nger, the scanner may not recognize. You can change another
nger and try again.
DS-K1A340 Series Face Recognion Terminal User Manual
128
Appendix C. Tips When Collecng/Comparing Face
The posion when collecng or comparing face picture is as below:
Posions (Recommended Distance: 0.5 m)
Expression
●
Keep your expression naturally when collecng or comparing face pictures, just like the
expression in the picture below.
●
Do not wear hat, sunglasses, or other accessories that can aect the facial recognion funcon.
●
Do not make your hair cover your eyes, ears, etc. and heavy makeup is not allowed.
Posture
In order to get a good quality and accurate face picture, posion your face looking at the camera
when collecng or comparing face pictures.
DS-K1A340 Series Face Recognion Terminal User Manual
129
Size
Make sure your face is in the middle of the collecng window.
DS-K1A340 Series Face Recognion Terminal User Manual
130
Appendix D. Aendance Capacity
View the aendance data capacity, including department, normal shi, man-hour shi, etc.
Content Maximum Conguraon
Parameters
Department Department Number 128
Shi Schedule Duraon
(Department)
8
Shi Normal Shi 256
Man-Hour Shi 256
Holiday Holiday Schedule 64
Holiday Group The same as the shi schedule
number.
Shi Schedule Schedule by Department 128
The same as the department
number.
Schedule by Individual 512
Time and Aendance Schedule Shi Schedule Duraon 640
The same as the shi schedule
number.
Week Schedule The same as the shi schedule
number.
Holiday Schedule 64
Holiday Group The same as the shi schedule
number.
Shi Schedule Template The same as the shi schedule
number.
DS-K1A340 Series Face Recognion Terminal User Manual
131
Appendix E. Aendance Report Table
View the exported aendance table name, content, data name, etc.
Descripon of Aendance Report File Name
●
KaoQinHuiZong.xls: Aendance Summary Table
●
Aendance Record.xls: Aendance Summary Table
●
KaoQinYiChang.xls: Aendance Abnormal Table
●
AendanceCardReport.xls: Aendance Card Report Table
●
KaoQinPaiBan.xls: Aendance Schedule Table
●
PuTongBan.xls: Normal Shi Table
●
export_pic: Face Data Exporng File Name
●
recordList_Serial No.cvs: Event and Data
●
acs.db/aend.db/userdata_cong/enrlFace: User Data
●
devCfg.json: Conguraon File
Aendance Report Table Content
Table E-1 Aendance Schedule Table
Aendance Schedule
Create Time: 2021/02/22 10:35
Export Date: 2021/02/01
Emp
loye
e ID
Nam
e
Dep
artm
ent
Shi
Sche
dule
Type
01 02 03 ......
One Two Thre
e
......
Aendance Schedule Table: All users' shi schedules for a duraon will be displayed in this table.
You are able to set the shi schedule and the holiday (No aendance recorded during the holiday)
in shi schedule conguraon.
●
Employee ID: The user's ID No.
●
Name: The user's name.
●
Department: The department of the user.
●
Shi Schedule Type: Schedule by department or by individual.
DS-K1A340 Series Face Recognion Terminal User Manual
132
Table E-2 Shi Table
Shi Table
Create Time: 2021/02/22 10:35
Shi
No.
Shi
Name
Duraon 1 Duraon 2 Duraon 3 Duraon 4
Start End Start End Start End Start End
1 Normal
Shi 1
09:00 18:00 00:00 00:00 00:00 00:00 00:00 00:00
2 Normal
Shi 2
08:00 17:00 00:00 00:00 00:00 00:00 00:00 00:00
3 Normal
Shi 3
09:00 12:00 13:00 18:00 00:00 00:00 00:00 00:00
Shi Table: Aendance by the congured me duraon.
For example: If set Duraon 1 as 9:00 (Start) and 18:00 (End), it is eecve for the user to take
aendance between 9:00 and 18:00.
Combining with the aendance rule, you are able to set mulple aendance types.
Table E-3 Aendance Abnormal Table
Aendance Abnormal Table
Create Time: 2020-02-22 10:34
Export Date: 2021-02-01 2021-02-22
Emp
loye
e ID
Na
me
Dep
art
men
t
Dat
e
Duraon
1
Duraon
2
Duraon
3
Duraon
4
Late
Dur
ao
n
(mi
n)
Earl
y
Lea
ve
(mi
n)
Insuff
icie
nt
Wor
k
Hou
r
(mi
n)
Tota
l
(mi
n)
Not
e
Star
t
Wor
k
End
Wor
k
Star
t
Wor
k
End
Wor
k
Star
t
Wor
k
End
Wor
k
Star
t
Wor
k
End
Wor
k
Abnormal Aendance Table: Calculate the abnormal aendance according to the aendance
records and the shi schedule conguraon.
●
Employee ID: The user's ID No.
●
Card No.: The user's card No.
●
Department: The department of the user.
●
Date: The date of the abnormal aendance generated.
DS-K1A340 Series Face Recognion Terminal User Manual
133
●
Start Work - End Work: Set 4 me duraons (start work and end work). It records the aendance
me of each user every day.
●
Late Duraon (min): The start work aendance me is later than the normal start work me.
●
Early Leave Duraon (min): The end work aendance me is earlier than the normal end work
me.
●
Insucient Work Hour: The start work duraon is not sucient.
●
Total: The absence me duraon of the day.
Table E-4 Aendance Summary Table
Aendance Summary Table
Create Time: 2021-02-22 08:36:26
Export Date: 2021-02-01 20201-02-22
E
m
pl
oy
ee
ID
N
a
m
e
D
ep
ar
t
m
en
t
Work
Dura
on
Late Early
Leave
Over
me
Work
Insu
cient
Work
Hour
At
te
nd
an
ce
D
ay
St
an
da
rd
/
Ac
tu
al
A
bs
en
ce
(D
ay
)
B
us
in
es
s
Tri
p
(D
ay
)
As
k
fo
r
Le
av
e
(D
ay
)
Addional
Salary
Ac
tu
al
Sa
lar
y
N
ot
e
St
an
da
rd
(
mi
n)
Ac
tu
al
(
mi
n)
Ti
m
es
D
ur
a
on
(
mi
n)
Ti
m
es
D
ur
a
on
(
mi
n)
N
or
m
al
Sp
ec
ial
Ti
m
es
D
ur
a
on
(
mi
n)
Re
m
ar
k
O
ve
r
m
e
W
or
k
Su
bs
id
y
La
te
/
Ea
rly
Le
av
e
Pe
rs
on
al
Le
av
e
D
ed
uct
io
n
Aendance Summary Table: Calculate the user aendance informaon in a duraon of me.
●
Employee ID: User ID
●
Name: The user's name.
●
Department: The user's department.
●
Work Duraon: Standard work duraon and actual work duraon.
●
Late: The start work aendance me is later than the normal start work me. Late arriving for
no more than once every day.
●
Early Leave: The end work aendance me is earlier than the normal end work me. Early leave
for no more than once every day.
●
Overme Work: Normal overme work duraon and special overme work duraon.
●
Insucient Work Hour: Times and duraon of insucient work hours.
●
Absence: Total absence days.
DS-K1A340 Series Face Recognion Terminal User Manual
134
●
Business trip: Total business trip days.
●
Ask for Leave: Total ask for leave days.
●
Subsidy: According to remarks, overme work, late/early leave, personal leave, and deducon,
the company can view the increase and decrease.
●
Actual Salary: Calculate the user's actual salary.
Table E-5 Aendance Record Table
Aendance Record Table
Create Time: 2021/05/20 14:49
Made Date: 2021/05/01
Employee ID Name Department Aendance Record
●
Employee ID: User ID
●
Name: The user's name.
●
Department: The user's department.
●
Aendance Record: The user aendance record on that day.
Note
Up to 31 days aendance record can be exported.
Table E-6 Aendance Card Report Table
Aendance Employee
Create Time:2021/09/14 14:41:16
Dept Company Name name10000
Dept 2021/08/01-2021/08/31 ID 10000
Absent
(Days)
Casual
(Days)
On
business
(Days)
Aenda
nce
(Days)
Over(hours) Late Leave Early
Normal Special (mes) (mins) (mes) (mins)
Aendance Info
Date Week First Second Third Over
On O On O On O In Out
1 Mon. 08:59 18:01
DS-K1A340 Series Face Recognion Terminal User Manual
135
Appendix F. Communicaon Matrix and Device
Command
Communicaon Matrix
Scan the following QR code to get the device communicaon matrix.
Note that the matrix contains all communicaon ports of Hikvision access control and video
intercom devices.
Figure F-1 QR Code of Communicaon Matrix
Device Command
Scan the following QR code to get the device common serial port commands.
Note that the command list contains all commonly used serial ports commands for all Hikvision
access control and video intercom devices.
Figure F-2 Device Command
DS-K1A340 Series Face Recognion Terminal User Manual
136
UD24081B-B
