www.samsung.com
User Manual
2
Getting started
4 Device layout and functions
10 Turning the computer on and off
12 Unlocking the screen
12 Windows
Basics
13 Using the computer as a tablet
14 Using the S Pen
18 Touch screen
24 Keyboard
26 Touchpad
29 Wireless LAN
31 Bluetooth
33 Fingerprint recognition
36 Memory card slot
38 Thunderbolt™ 4
39 External display
Apps and features
41 Using apps
42 Samsung Account
43 Samsung Settings
44 Samsung Notes
48 Samsung Update
49 Samsung Flow
49 Samsung Studio
50 Samsung Gallery
51 Samsung Care+
52 Samsung Device Care
54 Samsung Pass
55 Bixby
56 Galaxy Book Smart Switch
57 Galaxy Book Experience
58 Online Support(S Service)
59 Screen Recorder
60 Second Screen
61 SmartThings
62 Quick Share
62 Quick Search
Settings & Upgrade
63 Display brightness
65 Volume
66 BIOS (Setup utility)
72 Battery
Table of contents
3
Table of contents
Troubleshooting
76 Samsung Recovery
81 Windows recovery feature
81 Q&A
Usage notices
84 Precautions for using the device
88 Ergonomic tips
92 Safety precautions
Appendix
102 Product specifications
103 Important safety information
106 Replacement parts and accessories
109 Regulatory compliance statements
117 WEEE symbol information
119 Samsung package Take-Back
program (USA only)
4
Getting started
Device layout and functions
Leaving the screen idle for extended periods may result
in afterimages (screen burn-in) or ghosting. Turn off
the screen, or turn on the screen saver or power saving
mode when you are not using the computer.
•
Features or options may differ depending on the
model.
•
The items marked as optional may not be provided
or may be provided in different locations.
•
Since some space on the storage device is reserved
for system recovery and operations, the available
space on the storage device may be less than the
actual capacity.
Getting started
5
Number/Name Description
1
Microphone
•
You can use the voice recording
or video call features through
the built-in microphone.
2
Ambient light
sensor
•
Recognizes the brightness of
the environment where you use
the computer.
•
When the surroundings become
dark, the keyboard backlight
turns on.
•
When the surroundings become
bright, the keyboard backlight
turns off.
Do not cover the ambient
light sensor.
3
Camera
•
Using this camera, you can take
still pictures and record video.
4
Camera indicator
light
•
This indicates the camera
operating status.
5
Display/Touch
screen
•
The screen’s images are
displayed here.
•
Recognizes touch interactions.
Front view
9
4
5
3
2
1
6
7
8
Getting started
6
Right view
1 32
Number/Name Description
1
Memory card slot
•
Insert a memory card into the
slot.
2
USB 3.2 port
•
Connect various accessories,
such as a mouse, camera, or
keyboard.
3
Earpiece/
Headset jack
•
Connect an earpiece or a
headset to the computer to
listen to audio.
Number/Name Description
6
Power button/
Fingerprint
recognition
sensor
•
Turns the computer on and off.
•
The fingerprint recognition
sensor recognizes fingerprints.
Scans a fingerprint to sign in to
Windows, apps, and services.
7
Numeric keypad
•
Enter numbers.
8
Keyboard
•
Enter text or control computer
functions.
9
Touchpad
•
Moves the cursor and selects
options.
•
Functions as a mouse.
Getting started
7
Number/Name Description
1
HDMI port
•
Used to connect an HDMI cable to
an external device.
2
Thunderbolt
™
4 port
•
Connect the supplied adapter to
charge the computer.
•
Connect and charge a USB Type-C
device and Thunderbolt
™
device,
or connect to an external display
device.
Some features may not be
supported depending on your
device’s specifications.
3
Operating
status LED
•
Shows the operating status of the
computer.
‒
Red: Charging
‒
Green: Fully charged
‒
Blue: Turned on
Left view
1 32
Getting started
8
Charging a USB Type-C device or Thunderbolt
™
device
Connect and charge your USB Type-C or Thunderbolt
™
device
by connecting it to the Thunderbolt
™
4 port.
To charge another device when the computer is in hibernation
mode or is turned off, the USB charging feature must be
turned on.
1
Select the Start button ( )
→
All apps
→
Samsung
Settings
.
2
Select
Battery and performance
and select the
USB
charging
switch to turn it on.
•
It may take longer to charge the battery when
charging a connected device.
•
The battery power level may be reduced when
charging a connected device while the computer is
powered by the battery.
•
The charging status of the connected device is not
displayed on the computer.
•
This charging feature may not be available on some
devices.
The charging feature of the Thunderbolt
™
4 port
Charging the computer
Connect an external power supply (sold separately) to the
Thunderbolt
™
4 port to use it as the auxiliary power or charge
the computer.
Use an external power supply (sold separately) with a rating
level higher than 10 W (5 V, 2 A) that supports USB Type-C or
USB BC 1.2.
Getting started
9
Number/Name Description
1
Fan vents
•
Sucks in outside air and discharges
heat generated inside the computer
through these holes.
•
If the vents are blocked the computer
may overheat. Avoid blocking the
vents as this may be dangerous.
2
Internal
battery
•
Provides power to the computer
when not connected to an adapter.
•
To remove or replace the internal
battery, take it to a Samsung Service
Center. You will be charged for this
service.
3
Speaker
•
Sound is emitted from the speakers.
•
If the case at the bottom of the device is replaced,
the laser-carved model name, serial number, and
various logos will not be displayed anymore. For
more information, contact a Samsung Service
Center.
•
Remove all of the protective papers from the rubber
feet at the bottom of the computer before use.
Bottom view
2
33
1
Getting started
10
3
The computer turns on automatically when the display
panel is opened.
If the computer does not turn on automatically, press the
Power button.
Set the computer to not turn on automatically when
the display panel is opened.
1. SelecttheStartbutton(
)
→
All apps
→
Samsung
Settings
.
2. Select
Advanced features
and select the
Auto
booting
switch to turn it off.
Turning the computer on and off
Fully charge the battery using the supplied adapter
before using the computer
for the first time
.
Turning the computer on
1
Before turning on the computer, check that the battery is
charged and charge it if necessary.
2
Open the display panel.
Getting started
11
Turning the computer off
1
Select the Start button ( ).
2
Select
→
Shut down
.
Save all data before turning off the computer.
About Windows Activation
When you turn the computer on for the first time, the Windows
Activation screen appears.
Follow the activation procedures according to the instructions
on the screen to use the computer.
The computer’s date and time may be incorrect when you
turn it on for the first time. They may also be incorrect if the
battery has been fully discharged or removed. To set the date
and time, go to the desktop taskbar and right-click the date
and clock area. Then, select
Adjust date and time
and set the
current date and time.
Getting started
12
Windows
Microsoft Windows is an operating system that is used to
control a computer.
•
Images and available features may differ depending
on the model and operating system.
•
This manual is designed for Windows 11 and content
may differ depending on the OS version.
•
The image displayed on the desktop screen may
differ between models and OS versions.
Configuring the Windows Settings
You can configure the basic system settings, such as installing
or uninstalling apps and managing accounts, from the
Windows Settings.
Select the Start button (
)
→
Settings
.
Then, select an option you want to change after the
Settings
window appears.
You can also configure the settings from the Control
Panel like previous OS versions. Select the Start button
(
)
→
All apps
→
Windows Tools
→
Control Panel
.
Unlocking the screen
To unlock the lock screen, do one of the following:
•
Touch screen
: Swipe upwards from the bottom of the
screen.
•
Mouse
: Click the lock screen.
•
Keyboard
: Press any key.
•
Touchpad
: Tap the touchpad.
If the account has a password, enter the password to log in
after unlocking the screen.
13
Basics
Using the computer as a tablet
You can use the computer as a tablet by folding the display
panel behind the keyboard.
Open the display panel and rotate it away from the keyboard
until it touches the bottom side of the computer.
When storing the computer in a bag or carrying it, close
the display panel to protect the computer.
•
When the display panel is tilted past the transition
point
‒
The keyboard and touchpad will automatically be
locked and will not function. But, during processes
that start before Windows operation, such as the
BIOS setup or DOS, the keyboard and touchpad
will not be locked.
‒
The display will rotate automatically depending on
the computer’s orientation.
•
When the screen is turned off while using the
computer as a tablet, touch the screen to unlock
it. When the computer is in sleep mode, press the
Power button to unlock the screen.
Basics
14
Using the S Pen
S Pen
S Pen button
S Pen nib
Name Functions
S Pen nib
•
Use the S Pen to write, draw, or
perform touch actions on the screen.
S Pen button
•
Hover the S Pen over the screen and
press the S Pen button to display the
Air command features.
Do not bend or apply excessive pressure with the S Pen
while using it. The S Pen may be damaged or the nib
may be deformed.
•
If a magnet is near the computer, some S Pen
actions, such as tapping the touch screen, may not
work.
•
If you use the S Pen at sharp angles on the screen,
the device may not recognize the S Pen actions.
•
For more information about the S Pen, visit the
Samsung website.
•
If the S Pen is not working properly, take it to a
Samsung Service Center.
Basics
15
•
Create note
: Open the Samsung Notes app and create a
new note.
•
View all notes
: Open the Samsung Notes app and check all
saved notes.
•
Smart select
: Use the S Pen to select an area and perform
actions, such as sharing or saving.
•
Screen write
: Capture screenshots to write or draw on
them or crop an area from the captured image.
•
PENUP
: Post your artwork, check out others’ artwork, and
get useful drawing tips.
•
Add shortcuts
: Add shortcuts to frequently used apps to
the Air command panel.
Air command
Introduction
Air command is a menu that provides S Pen features and direct
access to frequently used apps.
To open the Air command panel, hover the S Pen over the
screen and press the S Pen button.
Alternatively, select the Start button (
)
→
All apps
→
Air
Command
.
Images and features may differ depending on the
model and the app version.
Air command
settings
View all notes
Create note
Smart select
Add shortcuts
Screen write
PENUP
Basics
16
3
Select an option to use with the selected area.
•
Pin/Insert
: Pin the selected area to the screen.
•
: Automatically changes the appearance of the
selected area.
•
: Write or draw on the selected area.
•
: Extract text from the selected area.
•
: Share the selected area with others.
•
: Save the selected area as an image to the clipboard.
•
: Save the selected area in
Pictures
.
Smart select
Use the S Pen to select an area and perform actions, such as
sharing or saving. You can also select an area from a video and
capture it as a GIF.
1
When there is content you want to capture, open the Air
command panel and select
Smart select
.
2
Select a desired shape icon on the toolbar and drag the
S Pen across the content you want to select.
Basics
17
Screen write
Capture screenshots to write or draw on them or crop an area
from the captured image.
1
When there is content you want to capture, open the Air
command panel and select
Screen write
.
The current screen will be automatically captured.
2
Select and write a memo on the screenshot.
Pen settings
Eraser
Redo
Undo
Share
Save
Save to the clipboard
3
Share or save the screenshot.
You can check the screenshots in
Pictures
.
It is not possible to capture a screenshot while using
some app or some features.
Basics
18
Double tapping
Double tap the screen.
Touching and holding (right-clicking)
To use additional options of an item, touch and hold it on the
screen.
Touch screen
Use your fingers on the touch screen to perform actions.
Touch screen gestures
Tapping
Tap the screen.
Basics
19
Spreading and pinching
To zoom in, spread two fingers apart on an image or text. Pinch
to zoom out.
Dragging
Touch and hold an item and drag it to the target position.
Scrolling
To scroll up, down, left, or right, swipe on the screen.
Basics
20
•
Very light touches on the touch screen may not be
recognized.
•
Precisely tap items on the touch screen for the best
results.
•
When used under some 3-wavelength lamps, the
touch screen could malfunction.
•
The touch screen sensors are located on the edges
of the touch screen. Therefore, do not cover the
edges of the touch screen with protective covers or
accessories.
•
Touch screen gestures are available for touch screen
models running Windows and work only with some
apps.
•
Do not subject the touch screen to severe impacts
or press it with sharp objects. Doing so may damage
the touch screen.
•
Do not allow the touch screen to come into
contact with other electrical devices. Electrostatic
discharges can cause the touch screen to
malfunction.
•
Do not expose the touch screen to water. The touch
screen may malfunction in humid conditions or when
exposed to water.
•
Do not spray liquid cleansing solutions directly onto
the touch screen. The solution may enter the touch
screen or cause undesired operation. To clean the
screen, dampen a cloth with solution and gently
wipe the screen. Do not use solutions or cloths that
contain abrasive materials, as they may damage the
touch screen.
•
Do not damage the edges of the touch screen. Doing
so may damage the touch screen.
•
Make sure your hands are clean and dry before using
the touch screen. Remove any moisture from your
hands before using the touch screen.
•
Do not expose the computer to foreign substances.
Doing so may cause the touch screen to malfunction.
Basics
21
1
2
3
4
5
8
4
10
9
12
11
6
7
Number Description
1
•
Switch to a floating keyboard.
2
•
Delete a preceding character.
3
•
Move to the next line.
4
•
Create an uppercase character. For all caps,
tap it twice.
5
•
Change the keyboard layout.
6
•
Move the cursor.
7
•
Turn on the dictation feature to convert
spoken words into text.
8
•
Enter a space.
9
•
Tap it to use keyboard shortcuts.
•
Tap it twice to open the Start menu.
10
•
Enter numerals and punctuation marks.
Entering text
Use the on-screen keyboard to enter text.
To open the on-screen keyboard, tap
on the taskbar.
•
Some languages are not supported by the virtual
keyboard. To enter text, change the input language
to one of the supported languages.
•
When using the computer for extended periods,
it is recommended to enter text with the physical
keyboard.
•
When using the computer as a tablet, the on-screen
keyboard icon will appear on the taskbar.
Changing the keyboard layout
To change the keyboard layout, tap and select one of the
following:
•
Keyboard layout
→
Default
: Simplified QWERTY keyboard
•
Keyboard layout
→
Small
: Floating keyboard
•
Keyboard layout
→
Split
: Split QWERTY keyboard
•
Keyboard layout
→
Traditional
: Standard QWERTY
keyboard
Basics
22
Sending feedback
Tap
→
Give feedback
to ask questions or access frequently
asked questions.
Configuring keyboard settings
To configure various settings for the keyboard, tap
→
More
settings
and select options.
•
Typing
: Change the settings available when typing.
•
Language
: Add the languages you can use when typing,
and set the display language of the computer.
•
Learn more
: Access the tips for using the keyboard.
Entering uppercase
Tap before entering a character. For all caps, tap it twice.
Number Description
11
•
Change the keyboard settings.
12
•
Enter emojis, animated GIFs, and special
characters. You can also add items from the
clipboard.
Handwriting
Tap
→
Handwriting
, and then write a word in the on-screen
text input field.
Handwriting is not supported for some languages.
Applying a keyboard theme and resizing the
keyboard
To resize the keyboard and apply various themes, tap
→
Size
and theme
.
Basics
23
Copying and pasting
1
Touch and hold over text.
2
Drag or to select the desired text, or tap
Select all
text
to select all text.
3
Tap
Copy
or
Cut
.
The selected text is copied to the clipboard.
4
Touch and hold where the text is to be inserted and tap
Paste
.
To paste text that you have previously copied, tap
→
and select the text.
Basics
24
Using hot keys
To use keyboard hot keys, do one of the following:
•
Press and hold the
Fn
key and press a hot key.
Keyboard
Enter text or access computer functions with the keyboard.
•
Images and available features may differ depending on the model and operating system.
•
The keyboard layout may differ depending on the country. The hot keys will be mainly explained in this manual.
•
Press and hold the
Fn
key and press the
F12
key. When the
Fn Lock feature turns on, press a hot key.
When the Fn Lock feature is on, hot keys are activated
without pressing the
Fn
key.
Basics
25
Hot key functions
Key/Icon Description
F1
•
Samsung Settings
: Open the
Samsung
Settings
app.
F2
•
Screen brightness control
: Adjust the
brightness of the display.
F3
F4
•
Display/External monitor
: Switch between
the display and an external display
device when an external display device is
connected to the computer.
F5
•
Touchpad
: Turn the touchpad feature on or
off.
F6
•
Mute
: Mute or unmute the audio.
F7
•
Volume control
: Adjust the volume level.
F8
Key/Icon Description
F9
•
Keyboard backlight brightness
: Turn the
keyboard backlight on or off and adjust its
brightness.
F10
•
Block camera and mic
: Limit the use of
the camera and the microphone to prevent
recording.
F11
•
Performance mode
: Change the system’s
performance mode.
F12
•
Fn Lock
: Lock the
Fn
key so that hot keys
can be used without pressing the
Fn
key.
If the hot keys do not work properly, install the
Samsung Settings
app.
Basics
26
Touchpad
Use the touchpad to move the cursor or select an item. The left
and right buttons of the touchpad act the same as the left and
right buttons of a mouse.
•
Use the touchpad only with fingers. The touchpad
will not recognize actions of other objects.
•
Images and the touchpad layout may differ
depending on the model.
Basic touchpad functions
Moving
To move the cursor, move a finger on the touchpad.
Clicking
Tap the touchpad or press the left touchpad button.
or
Tap
Click
Double-clicking
Double tap the touchpad or press the left touchpad button
twice.
or
Tap-tap
Click-click
Basics
27
Right-clicking
Press the touchpad with two fingers simultaneously or press
the right touchpad button.
or
Tap
Click
Dragging
To move an icon or an app to a desired location, press and hold
it and then drag it to the target position with the left touchpad
button pressed.
Press and hold
the left touchpad
button
Move
Gesture functions
Swiping
To scroll up, down, left or right to a desired location, swipe with
two fingers on the touchpad.
or
Pinching
To zoom in, spread two fingers apart on the touchpad. Pinch to
zoom out.
Basics
28
Touchpad lock
Press and hold the
Fn
key and press the
F5
key to lock the
touchpad.
Configuring touchpad gestures
Configure touchpad gestures.
Select the Start button (
)
→
Settings
→
Bluetooth & devices
→
Touchpad
and select the desired options.
Some options in the touchpad settings may not be
available depending on the model.
Basics
29
Connecting to a Wi-Fi network
1
Select the status icons on the taskbar and select on the
Wi-Fi
option.
1
2
Wireless LAN
Connect the computer to a wireless network to use the
internet.
These descriptions are for computer models with a
Wireless LAN card or device. A Wireless LAN device is
optional. The pictures in this manual may differ from
the actual product depending on the wireless LAN
device model.
About Access Point (AP)
An Access Point (AP) is a network device that bridges wired
and wireless LANs and corresponds to a wireless hub in a wired
network. Multiple devices can be connected to an AP.
Basics
30
2
Select a network from the list of detected wireless
networks and select
Connect automatically
→
Connect
.
3
Enter a password, if necessary, and select
Next
.
Once the computer has been connected to a wireless
network, it will attempt to connect to it automatically
when it is available. If you require a network password,
contact the system administrator.
Deactivating the Wi-Fi feature
When you are not using the Wi-Fi feature, turn it off to save
battery power.
Select the status icons on the taskbar and select
.
The Wi-Fi feature is deactivated.
2
1
Airplane mode
Set the computer to turn off all wireless functions on your
computer. You can use only non-network services.
To turn on
Airplane mode
, select the status icons on the
taskbar and select
.
Basics
31
Bluetooth
Use Bluetooth to listen to music or exchange data or media
files with other Bluetooth-enabled devices.
•
Samsung is not responsible for the loss, interception,
or misuse of data sent or received through
Bluetooth.
•
Always ensure that you share and receive data
with devices that are trusted and properly secured.
If there are obstacles between the devices, the
operating distance may be reduced.
•
Some devices, especially those that are not tested or
approved by the Bluetooth SIG, may be incompatible
with your device.
•
Do not use the Bluetooth feature for illegal purposes
(for example, pirating copies of files or illegally
tapping communications for commercial purposes).
Samsung is not responsible for the repercussion of
illegal use of the Bluetooth feature.
Pairing with other Bluetooth devices
1
Select the status icons on the taskbar to ensure that
Bluetooth is activated.
2
Select the Start button ( )
→
Settings
→
Bluetooth &
devices
→
Add device
.
Basics
32
Unpairing Bluetooth devices
1
Select the Start button ( )
→
Settings
→
Bluetooth &
devices
.
Your computer will display the paired devices.
2
On the device you want to unpair from your computer,
select
→
Remove device
.
The connection to the Bluetooth device will be
disconnected.
3
Select
Bluetooth
to select a device you want to add and
finish pairing.
Basics
33
1
2
2
Select
Fingerprint recognition (Windows Hello)
→
Set up
to start the fingerprint registration.
3
Select
Get started
on the
Windows Hello setup
window.
4
Enter the PIN number you set.
Fingerprint recognition
You can sign in to Windows, apps, and services by teaching
Windows to recognize your fingerprint.
Remove the sticker from the fingerprint recognition
sensor before using it.
Registering your fingerprint
Create a password and PIN first to use the fingerprint scan
feature.
1
Select the Start button ( )
→
Settings
→
Accounts
→
Sign-in options
.
Basics
34
Removing a fingerprint
1
Select the Start button ( )
→
Settings
→
Accounts
→
Sign-in options
.
2
Select
Fingerprint recognition (Windows Hello)
→
Remove
.
The fingerprint will be removed.
Unlocking the screen with a fingerprint
You can unlock the screen by resting your fingerprint on the
fingerprint recognition sensor.
Place a registered finger on the fingerprint recognition sensor.
The screen will be unlocked if the fingerprint is scanned
correctly.
5
Repeatedly lift and rest your finger on the fingerprint
recognition sensor until setup is complete.
The fingerprint recognition sensor’s location may vary
depending on the model.
6
Fingerprint registration is complete.
If you want to add another fingerprint, select
Add a finger
.
Basics
35
For better fingerprint recognition
•
Prevent the fingerprint recognition sensor from being
scratched or damaged by metal objects, such as coins,
keys, and necklaces.
•
Ensure that the fingerprint recognition sensor and your
fingers are clean and dry.
•
The fingerprint recognition sensor may not recognize
fingerprints that are affected by wrinkles or scars.
•
The fingerprint recognition sensor may not recognize
fingerprints from small or thin fingers.
•
If you bend your finger or use your fingertips, the
fingerprint recognition sensor may not recognize your
fingerprints. Make sure to cover the entire fingerprint
recognition sensor with your finger.
•
To improve recognition performance, register the
fingerprints of the fingers used most often to perform
tasks on the computer.
•
In dry environments, static electricity can build up in the
computer. Avoid using this feature in dry environments
or before using the feature, discharge static electricity by
touching a metal object.
Basics
36
Inserting a memory card
1
Insert a memory card into the memory card slot in the
indicated direction until it clicks into place.
2
If a pop-up message appears, choose an action.
3
Select
Open folder to view files
.
4
Save, move, or delete data on the memory card.
Memory card slot
Use a memory card to transfer data to other devices. You
can use data stored on your device, such as digital cameras,
phones, or tablets, on your computer, or you can take your
saved data to another device.
Memory cards are sold separately.
This computer supports the following types of memory cards.
Abbreviation Description
micro SD
•
micro Secure Digital
micro SDHC
•
micro Secure Digital High Capacity
micro SDXC
•
micro Secure Digital eXtended Capacity
•
Some memory cards may not be fully compatible
with the computer. Using an incompatible card may
damage the computer, the memory card, or the data
stored in it.
•
Use caution to insert the memory card in the
indicated direction.
•
Store the card separately to prevent losing the card
when moving the computer.
•
Memory card speeds vary.
Basics
37
•
To use a memory card to exchange data with a digital
device, such as a digital camera, formatting the data
with the digital device is recommended.
•
When trying to use a formatted memory card in
another digital device, format the memory card
again in the device.
•
Data protected by copyright laws cannot be
reviewed or modified.
•
Inserting and removing a memory card repeatedly
may damage the memory card.
•
Secure Digital Input Output (SDIO) is not supported.
•
If the write-protect tab is in the locked position, you
cannot format, write, or delete data on the card.
Removing a memory card
When you push the card, it clicks and disengages from the
memory card slot. Grasp the end of the card and pull it out of
the slot.
Formatting a memory card
Format the memory card to remove all data or before using it
for the first time.
Formatting a memory card deletes all data saved on
the card. If necessary, back up important data before
formatting the card.
1
On the taskbar, select File Explorer ( ).
2
Right-click the memory card drive, and then select
Format
.
3
Select
Start
.
Basics
38
4
On the main computer’s Desktop, select the icon for the
connected computer to access the folder being shared.
If the computer does not properly scan your
Thunderbolt
™
device after connecting it
After removing a Thunderbolt
™
device, you can
connect a new Thunderbolt
™
device after a few
seconds. Your computer may fail to recognize a device
connected immediately after removing the previous
device.
Thunderbolt
™
4
You can use Thunderbolt
™
devices or share files and printers
by connecting two computers that support Thunderbolt
™
.
Using Thunderbolt
™
devices
Connect the Thunderbolt
™
device to the Thunderbolt
™
4 port.
Connecting two computers that support
Thunderbolt
™
1
Use a Thunderbolt
™
cable (sold separately) to connect the
computers through their Thunderbolt
™
4 ports.
2
Select the Start button ( )
→
Settings
→
Network &
internet
→
Advanced network settings
→
Advanced
sharing settings
.
3
Select the switches of network profile sharing options to
turn on them.
The following screen is an example of allowing network
discovery and the accessing of files and printers.
Basics
39
2
Connect the other end of the cable to the external display.
<When using a Thunderbolt
™
display cable>
Thunderbolt
™
4 port Thunderbolt
™
port
<When using an HDMI cable>
HDMI port HDMI port
External display
Connecting the computer to an external display device can
be useful for presentations or when watching a movie. The
cables and adapters required to connect an external display
are sold separately. The computer supports HDMI cables and
Thunderbolt
™
display cables.
Thunderbolt
™
display cable
HDMI cable
Check the available ports on the display device to
ensure that it is compatible with the computer.
Connecting to a display
1
Connect the cable to the HDMI port or Thunderbolt
™
4
port of the computer.
Basics
40
You can also select the display mode in Windows
settings.
Select the Start button (
)
→
Settings
→
System
→
Display
→
Multiple displays
and select
Detect
next to
Detect other display
.
3
Connect the power cord to the external display.
4
Turn on the display and change its display mode to one
that supports an external input.
5
Press and hold the
Fn
key and press the
F4
key.
6
Select a mode.
PC screen only
Show the screen on the computer monitor
only.
Duplicate
Show the screen on both the computer and the
external display.
Extend
Extend the screen to the external display.
Second screen only
Show the screen on the external display only.
41
Apps and features
Using apps
•
Images and features may differ depending on the
model and the app version.
•
Some apps may not be supported depending on the
model.
•
Apps that are provided by Samsung can be installed
from
Samsung Update
.
•
Third-party software related apps
For descriptions about and service requests for
third-party apps, please contact the relevant
manufacturer. Some troubleshooting actions
in response to service requests may not work
depending on the app manufacturer.
Apps and features
42
Finding your ID and resetting your password
If you forget your Samsung account ID or password, select
Find ID
or
Forgot password?
on the Samsung account sign-in
screen. You can find your ID or reset your password after you
enter the required information.
Signing out of your Samsung account
When you sign out of your Samsung account, your data which
is related to your Samsung account will also be removed from
your computer.
Select the Start button (
)
→
All apps
→
Samsung Account
→
Sign out
.
Samsung Account
Using the Samsung account, you can use a variety of Samsung
services that are provided through computers, mobile devices,
TVs, and the Samsung website.
To check the list of services that can be used with your
Samsung account, visit account.samsung.com.
To use this feature, the computer must be connected to
the internet.
1
Select the Start button ( )
→
All apps
→
Samsung
Account
.
2
Select
Sign in
and sign in to your Samsung account. If you
do not have a Samsung account, select
Create account
.
Apps and features
43
Menu Description
Connections
•
Set connection settings, such as
the Bluetooth connection.
Connected devices
•
Change settings for computer
connections.
Sound
•
Change settings for sounds.
Notifications
•
Change the notification
settings, such as turning the app
notifications or do not disturb
feature on or off.
Display
•
Change the display settings.
Security and privacy
•
Set the security and privacy status.
Advanced features
•
Turn on advanced features and
change the settings that control
them.
Battery and
performance
•
Set the battery settings.
Keyboard
•
Set keyboard backlight settings.
About
•
Check out the computer and
the Samsung Settings app
information.
Samsung Settings
Samsung Settings
, a Samsung-integrated settings app, offers
various settings functions.
Images and features may differ depending on the
model and the app version.
1
Select the Start button ( )
→
All apps
→
Samsung
Settings
.
2
Select an option to configure the corresponding feature.
Apps and features
44
2
When you are finished composing the note, select to
save it.
If you want to save the note in another file format, select
→
Save as file
.
Deleting notes
Right-click the note you want to delete on the note list and
select
Delete
.
Samsung Notes
Introduction
Create notes by entering text from the keyboard or by
handwriting or drawing on the screen. You can also insert
images or voice recordings into your notes.
Creating notes
1
Select the Start button ( )
→
All apps
→
Samsung Notes
→
and create a note.
Select an input method from the toolbar on the right side
of the screen.
More options
Insert files.
Add memos to
PDF files.
Reading mode
Manage pages.
Insert an image.
Apps and features
45
Using the eraser
When you want to erase handwriting from a note, select
and select an area to erase. Alternatively, select an area while
pressing and holding the S Pen button.
•
Stroke eraser
: Erase the line you select.
•
Area eraser
: Erase only the area you select. You can adjust
the size of the eraser by dragging the size adjustment bar.
•
Erase highlighter only
: Erase only the area you draw with
the highlighter.
•
Erase all handwriting
: Erase all the handwriting.
Even with a smaller eraser, you may still not be able to
precisely erase the intended part.
Editing handwritten notes
Edit handwritten notes using various editing options, such as
cutting, moving, or resizing.
1
When there is handwriting on the note, select .
You can also change the shape of the selection.
Composing notes with handwriting
On the note composer screen, select a tool on the right side of
the screen to write or draw with the S Pen.
You can enter your handwriting in a larger size if you magnify
the screen by spreading two fingers on it.
Pen
Eraser
Change styles.
Straighten
Undo
S Pen to text
Redo
Convert to text.
Lock canvas.
Highlighter
Select and edit.
Easy writing pad
Neat shapes.
Apps and features
46
Converting handwriting to text
Select and write on the screen with the S Pen. The
handwriting will be replaced with text right away.
After writing on the screen, select
. Options will appear in
the preview window. If you drag
or , you can select the
handwriting you want. To replace the handwriting with the
text, select
Convert
.
Straightening content horizontally
You can horizontally straighten your handwriting and
drawings.
After writing or drawing on the screen, select
.
2
Select the input or draw a line around the input to select.
•
To move the input to another location, select the input,
and then drag it to a new location.
•
To change the size of the selection, select the input and
drag a corner of the frame that appears.
•
To edit the input, right-click the input and select an
option you want.
Apps and features
47
Automatically fixing shapes
Select and draw a shape. The shape will be fixed.
Recording voice to notes
Make a recording of your voice while creating a note, and then
the content will be synchronized with the recording.
On the note composer screen, select
→
Voice recordings
and create a note.
Select a note from the list and select
to play the recording.
Then the content you created while recording will be displayed
on the screen along with the recording.
Adding memos to PDF files
On the note composer screen, select , and then select a PDF
file. You can add memos to the PDF file.
Changing styles
You can change the style of your handwriting and drawings.
After writing or drawing on the screen, select
and select a
color or line thickness you want. Then, point the S Pen toward
where you want to apply the style. When the
icon appears,
select where you want to change the style.
Using the easy writing pad
On the note composer screen, select . The input field will be
magnified and appear as the easy writing pad.
Easy writing pad
Apps and features
48
3
Select
Update all
. Or, select
Install
or
Update
of the item
to be updated.
The items will be updated.
Samsung Update
Install and update Samsung apps and drivers on the computer.
You can search for or download the BIOS, drivers, and apps
over the internet. Keep the computer performing better and
more stably with
Samsung Update
.
•
To check for available updates, the computer must
be connected to the internet.
•
Only apps that have been installed with this app can
be updated.
•
Images and features may differ depending on the
model and the app version.
1
Select the Start button ( )
→
All apps
→
Samsung
Update
.
2
Read and agree to the User Agreement.
This step appears only when the app runs for the first
time.
Apps and features
49
Samsung Studio
Create and edit videos using photos and videos in your
computer.
1
Select the Start button ( )
→
All apps
→
Samsung
Studio
.
2
Select
New project
.
3
Select
Files
,
Folder
, or
Samsung Gallery
to add files and
select
OK
.
4
Edit the video by inserting music or text.
5
When you are finished editing the video, select
Export
to
save the video.
Samsung Flow
Connect your mobile device to your computer and use them
together doing things like checking notifications and sharing
content.
1
Select the Start button ( )
→
All apps
→
Samsung Flow
.
2
On your mobile device, open the Samsung Flow app.
If Samsung Flow is not installed, download it from the
Galaxy Store or Play Store.
3
Select
Start
.
4
Select your mobile device from the detected devices list.
If the connection method selection pop-up window
appears, select the method you want.
5
Check the passkey on both devices and select
Ok
.
The devices will be connected.
•
This feature is only available on some Samsung
Android devices.
•
Refer to the mobile device’s user manual for more
information about how to use Samsung Flow.
Apps and features
50
Deleting images or videos
1
Select the Start button ( )
→
All apps
→
Samsung
Gallery
.
2
Select the images and videos you want to delete and select
.
The deleted images and videos will move to the Windows
Recycle Bin.
Syncing images and videos
1
Select the Start button ( )
→
All apps
→
Samsung
Gallery
.
2
Select
Settings
and select the
Sync with Cloud
switch.
•
To use this feature, you must sign in to your Samsung
account.
•
To access pictures from other devices signed in to
your Samsung account on your computer, the sync
feature (cloud or OneDrive) of the other devices’
Gallery apps must be turned on.
Samsung Gallery
Access images and videos stored in your computer. You
can also sync content with the cloud to update in real time
and safely store content across the devices using the same
account.
Viewing images and videos
Select the Start button ( )
→
All apps
→
Samsung Gallery
.
The images and videos stored on your computer will appear.
Editing images or videos
1
Select the Start button ( )
→
All apps
→
Samsung
Gallery
.
2
Select the images and videos you want to edit and select
.
Apps and features
51
Samsung Care+
The guaranteed services provided by
Samsung Care+
will
cover certain problems that may arise while using the product,
such as damaged or lost computers.
Select the Start button (
)
→
All apps
→
Samsung Care+
.
The website will appear. Refer to the website for more
information.
•
To use this feature, the computer must be connected
to the internet.
•
This feature may not be available depending on your
model or region.
Apps and features
52
Restoring to an earlier restore point
1
Select the Start button ( )
→
All apps
→
Samsung Device
Care
.
2
Select
Backups
and select the date that you backed up the
system.
3
Select
Restore
.
Managing the storage
1
Select the Start button ( )
→
All apps
→
Samsung Device
Care
.
2
Select
Storage
.
3
Check the status of the used and available storage.
To delete files that you do not use anymore, select a
category, select an item, and then select
Delete
.
Samsung Device Care
You can create a system restore point and restore back to that
point. You can also check and clean up computer’s storage or
memory. When someone else is using your computer, such
as when you send it for repairs, you can turn on maintenance
mode to protect your privacy.
Creating a restore point
1
Select the Start button ( )
→
All apps
→
Samsung Device
Care
.
2
Select
Backups
→
Back up now
.
If you do not want to use the auto backup feature,
select
Settings
and select the
Back up automatically
and monitor app installations
switch to turn it off.
Apps and features
53
Optimizing the memory
1
Select the Start button ( )
→
All apps
→
Samsung Device
Care
.
2
Select
Optimize memory
.
Check the memory usage and clean up the unused
memory.
Using maintenance mode
1
Select the Start button ( )
→
All apps
→
Samsung Device
Care
.
2
Select
Settings
→
Maintenance mode
.
3
Select
Turn on Maintenance mode
and follow the
on-screen instructions.
The computer will enter maintenance mode.
Apps and features
54
1
Select the Start button ( )
→
All apps
→
Samsung Pass
.
2
Select
Sign in
and follow the on-screen instructions to
complete the setup.
3
On the sign-in page of the website or app, log in or enter
the personal information with Samsung Pass.
Samsung Pass
On your computer, use the login or personal information saved
in Samsung Pass on your phone or tablet. When entering your
Samsung account, ID, password, or personal information,
such as your address, use Samsung Pass to sign in or enter
information.
•
To use this feature, you must complete the Samsung
Pass setup on your phone or tablet and also register
your information first. Refer to the device’s user
manual for more information.
•
To use this feature, you must sign in your Samsung
account. Use the same Samsung account that was
set up with Samsung Pass on your phone or tablet.
•
To use this feature, the computer must be connected
to the internet.
Apps and features
55
For example, say “Hi, Bixby” and say “How’s the weather
today?” The weather information will appear on the screen.
If Bixby asks you a question during a conversation, say “Hi,
Bixby” and answer Bixby. Or select
and answer Bixby.
Waking up Bixby using your voice
You can start a conversation with Bixby by saying “Hi, Bixby”.
1
Select the Start button ( )
→
All apps
→
Bixby
.
2
Select
→
Settings
and select the
Wake with “Hi, Bixby”
switch to turn it on.
Now you can say “Hi, Bixby” and start a conversation.
Communicating by typing text
If your voice is not recognized because of noisy environments
or if you are in a situation where speaking is difficult, you can
communicate with Bixby through text.
Select the Start button (
)
→
All apps
→
Bixby
→
, and
then type what you want.
Bixby
Bixby is a user interface that helps you use your device more
conveniently.
You can talk to Bixby or type text. Bixby will launch a
feature you request or show the information you want. Visit
www.samsung.com/bixby for more information.
•
Bixby is only available in some languages, and it may
not be available depending on the region.
•
To use this feature, the computer must be connected
to the internet.
Starting Bixby
Select the Start button ( )
→
All apps
→
Bixby
. The Bixby
intro page will appear. After you select the language to use
with Bixby, sign in to your Samsung account, and complete the
setup by following the on-screen instructions, the Bixby screen
will appear.
Using Bixby
Say “Hi, Bixby” and say what you want. Alternatively, press the
Ctrl
,
Shift
, and
B
keys at the same time and tell Bixby what you
want.
Apps and features
56
5
On your computer, select
Receive data
.
6
On the previous computer, select
Allow
.
7
On your computer, select an item to bring and select
Transfer
.
Transferring data increases the battery power
consumption of your computer. Ensure that your
computer is sufficiently charged before transferring
data. If the battery power is low, data transfer may be
interrupted.
Galaxy Book Smart Switch
Using the
Galaxy Book Smart Switch
app, you can transfer
data from your previous computer to your new computer.
•
To use this feature, both your computer and previous
computer must be connected to the same Wi-Fi
network.
•
This feature may not be supported on some
computers.
•
Samsung takes copyright seriously. Only transfer
content that you own or have the right to transfer.
1
On the previous computer, open the
Galaxy Book Smart
Switch
app.
If you do not have the app, download it from
Microsoft
Store
.
2
On your computer, select the Start button ( )
→
All apps
→
Galaxy Book Smart Switch
.
3
Place the computers near each other.
4
On the previous computer, select
Send data
.
Apps and features
57
Galaxy Book Experience
Using the
Galaxy Book Experience
app, you can check the
information for various apps or features provided by Samsung
and use them.
1
Select the Start button ( )
→
All apps
→
Galaxy Book
Experience
.
2
Select the card you want.
3
Check the information of the app or feature, and select
Open
to open it.
Apps and features
58
3
Select
Online Talk
on the main page.
Select
Please enter the details of your inquiry.
, enter your
inquiry, and then select
Request
.
Online Talk
4
You can speak to a service associate to resolve your
computer’s problems.
Waiting times may vary depending on the network and
number of waiting customers.
Online Support(S Service)
A service associate can resolve any problems you have with
your computer using the online chat and remote control
program. You can receive the help when you are having trouble
using Samsung software.
You can access the online service for free for a certain period of
time after purchasing your computer.
•
Online Support(S Service)
may not be offered or its
version may be different depending on the model or
region.
•
If
Online Support(S Service)
is not installed, select
the Start button (
)
→
Microsoft Store
( ) and,
search for
S Service
to download it.
1
Select the Start button ( )
→
All apps
→
Online
Support(S Service)
.
2
Read and agree to the terms and conditions.
This step appears only when the app runs for the first
time.
Apps and features
59
3
When you are finished recording the screen, select .
You can check the file in
Videos
or
Pictures
.
4
Select to finish the screen recorder toolbar.
•
Select to expand or collapse the screen recorder
toolbar.
•
If your computer enters sleep mode while recording
the screen, the recording will be paused.
•
If your computer turns off abnormally while
recording the screen, the recorded file will not play
normally.
•
Some apps or programs may not support the screen
record or screen capture features.
Screen Recorder
Record the screen while using your computer.
1
Select the Start button ( )
→
All apps
→
Screen
Recorder
.
The screen recorder toolbar will appear on the top of the
screen.
2
Select to start recording.
After a countdown, recording will start.
•
To adjust the position and size of the recording area,
select
before starting recording.
•
To capture the screen, select .
•
To record the screen with a video overlay of yourself,
select
. The web cam window will appear.
•
To change the screen recorder settings, select before
starting recording.
•
To write or draw on the screen, select .
•
To add a text box on the screen, select .
Apps and features
60
Second Screen
Connect your computer and tablet to use the tablet as an
additional display for the computer.
•
Only Samsung tablets can be connected using
this feature. To check out models that support the
Second Screen feature, visit the Samsung website.
•
This feature is only available on tablets running One
UI version 3.1 or higher software.
•
To use this feature, you must connect the computer
and tablet to the Wi-Fi network. It is not necessary
to connect both devices to the same Wi-Fi network,
but it is recommended to connect them to the same
Wi-Fi network for a stable connection.
1
On your tablet, turn on the Second Screen feature.
2
Select the Start button ( )
→
All apps
→
Second Screen
.
3
Select your tablet from the detected devices list.
Your computer’s screen will appear on the connected
tablet.
If the computer has previously connected to a tablet, it
will automatically reconnect to that tablet.
Setting the video resolution
1
Select the Start button ( )
→
All apps
→
Screen
Recorder
.
The screen recorder toolbar will appear on the top of the
screen.
2
Select .
The
Screen Recorder settings
window will appear.
3
Select
Video
and select the resolution you want under
Video resolution
.
You can set the video resolution only when recording in
full screen mode.
Apps and features
61
•
To use this feature, you must sign in to your Samsung
account.
•
You can connect devices through the SmartThings
app on your phone or tablet.
•
Connected devices’ own problems or defects are not
covered by the Samsung warranty. When problems
or defects occur on the connected devices, contact
the device’s manufacturer.
•
To use this feature, the computer must be connected
to the internet.
SmartThings
Control and manage smart appliances and SmartThings
compatible products.
Select the Start button (
)
→
All apps
→
SmartThings
.
•
Favorites
: You can access the frequently used devices,
routines, and services.
•
Devices
: Control the devices registered to your Samsung
account.
•
Routines
: Add routines to control several devices
simultaneously.
•
SmartThings Find
: Find your Galaxy device’s location.
•
How to use
: Learn about how to use the SmartThings app.
•
Settings
: Configure settings for the SmartThings app.
Apps and features
62
Quick Search
Search for content on the computer quickly.
1
Select the Start button ( )
→
All apps
→
Quick Search
.
2
Read the on-screen instructions and select
Start Quick
Search
.
This step appears only when the app runs for the first
time.
3
Select the search field to enter a keyword.
Content on your computer will be searched.
Quick Share
Send content to nearby devices using Wi-Fi Direct or
Bluetooth.
1
Select the Start button ( )
→
All apps
→
Quick Share
.
2
Select a device to transfer the content to.
3
Select the content.
4
Accept the file transfer request on the other device.
63
Settings & Upgrade
Display brightness
Adjust the display brightness to reduce eye strain and save
power.
Controlling brightness using the keyboard
•
To dim the display screen, press and hold the
Fn
key and
press the
F2
key.
•
To brighten the display screen, press and hold the
Fn
key
and press the
F3
key.
Controlling brightness using the taskbar
1
Select the status icons on the taskbar.
2
Drag the adjustment bar to the desired brightness.
Brightness
adjustment bar
•
The display screen is automatically set to the
brightest level when the adapter is connected. The
display screen automatically becomes dimmer when
the adapter is disconnected.
•
The computer has an automatic screen brightness
adjustment to extend the battery usage time.
When necessary, the screen brightness is gradually
adjusted.
Settings & Upgrade
64
Optimizing the full screen color balance
Optimize the screen color by adjusting the color tones to your
preference.
1
Select the Start button ( )
→
All apps
→
Samsung
Settings
.
2
Select
Display
→
Advanced color settings
.
3
Drag the color adjustment bar to the desired color tone.
Color adjustment bar
Changing display mode
Select the optimal screen settings based on your activity.
Some options may not be available depending on the
model.
1
Select the Start button ( )
→
All apps
→
Samsung
Settings
.
2
Select
Display
→
Auto mode
, and then select an option.
•
Auto mode
: Optimizes the screen automatically for the
currently running program.
•
Vivid (AMOLED native)
: Makes scenes more vivid and
clear using AMOLED color space.
•
Natural (sRGB)
: Make videos natural using sRGB color
space.
•
Photo editing (Adobe RGB)
: Optimizes photo editing
using Adobe RGB color space.
•
Movie (DCI-P3)
: Optimizes for movies using DCI-P3
color space.
Settings & Upgrade
65
Controlling volume using the taskbar
1
Select the status icons on the taskbar.
2
Drag the adjustment bar to the desired volume.
Volume
adjustment bar
Volume
Adjust the system volume or sound volume when playing
music or video.
Controlling volume using the keyboard
•
To turn down the volume, press and hold the
Fn
key and
press the
F7
key.
•
To turn up the volume, press and hold the
Fn
key and press
the
F8
key.
•
To mute or unmute the volume, press and hold the
Fn
key
and press the
F6
key.
Settings & Upgrade
66
Entering the BIOS screen
1
Turn on the computer.
2
Before the Samsung logo appears, press the
F2
key several
times.
•
If the computer is password-protected, press the
F2
key
several times before the password screen appears.
•
If the password screen or the Windows start screen
appears, restart the computer and try again.
BIOS (Setup utility)
Define a boot password, change the boot priority, or configure
the installed chipsets.
•
Incorrect settings may cause the system to
malfunction or crash.
•
The BIOS setup screens, menus, and items may
appear differently depending on the model and BIOS
version.
•
BIOS setup functions are subject to upgrades.
Settings & Upgrade
67
Number Name
1
•
Setup items
2
•
Setup tools
‒
Help
: Get help with the BIOS setup.
‒
Default
: Return to the default settings.
‒
Restore
: Cancel changes.
‒
Save
: Save settings.
‒
Exit
: Exit BIOS setup.
3
•
Setup menu
‒
SysInfo
: Check the computer’s
specifications.
‒
Advanced
: Configure the chipsets and
additional functions.
‒
Security
: Configure security functions.
‒
Boot
: Configure accessories and boot-
related settings.
The BIOS setup screen appears only in English.
The BIOS screen
The BIOS setup screen appears as shown.
You can change BIOS settings using the keyboard or mouse.
3
2
1
Settings & Upgrade
68
•
HDD Password
(high security level): This password is
required to access the hard disk drive (HDD) from another
computer. This password may not be supported, depending
on the model or storage device.
Setting a boot password
1
Turn on the computer.
2
Before the Samsung logo appears, press the
F2
key several
times.
3
Access the
Security
menu on the BIOS setup screen.
4
Select a password type (
Set Supervisor Password
,
Set User
Password
, or
Set HDD Password
).
If you cannot select an item or the
HDD Password Frozen
message appears, turn off the computer and turn it on
again. Then, press the
F2
key several times before the
Samsung logo appears to enter the BIOS setup screen.
5
Enter a password and select
OK
.
The password should be 8-20 characters and contain both
uppercase and lowercase letters and numbers.
Boot password
Setting a password with the BIOS enhances protection against
viruses and hacking attacks.
•
Do not forget your password or expose it to others.
•
If you forget the
Supervisor Password
or
HDD
Password
, request assistance from the Samsung
Service Center. In this case, a service fee will be
charged.
•
If you forget the
User Password
, disable the
Supervisor Password
, and the
User Password
will
also be automatically disabled.
Setting passwords
You can set passwords following these instructions on the
BIOS setup screen.
•
Supervisor Password
(low security level): This password
is required when turning on the computer or entering the
BIOS setup.
•
User Password
(low security level): This password is
required to enter the BIOS setup. This password will be
deactivated automatically if the
Supervisor Password
is
disabled.
Settings & Upgrade
69
7
Select
Save
→
OK
to save and restart.
For some models, to cancel the password, select
Cancel
in the
Setup Notice
window.
Changing the boot priority
Change the boot priority from the BIOS setup.
1
Turn on the computer.
2
Before the Samsung logo appears, press the
F2
key several
times.
3
Access the
Boot
menu on the BIOS setup screen.
4
Select
Boot Device Priority
.
5
Select an option menu to open the list.
6
Select an option.
7
Select
Save
→
OK
to save and restart.
Select
Exit
→
OK
to restart without saving the changes.
6
Select
Save
→
OK
to save and restart.
•
To enable the
Password On Boot
option, set a
Supervisor Password
and enter the password when
starting up the computer.
•
For some models, if the password entered message
appears in the
Setup Notice
window, select
OK
to
complete the setup.
Removing a password
1
Turn on the computer.
2
Before the Samsung logo appears, press the
F2
key several
times.
3
Access the
Security
menu on the BIOS setup screen.
4
Select a password type (
Set Supervisor Password
,
Set User
Password
, or
Set HDD Password
).
5
Enter the current password next to
Enter Current
Password
.
6
Do not enter any characters next to
Create New Password
,
Confirm New Password
and select
OK
→
OK
.
Settings & Upgrade
70
3
Select
Advanced
→
Smart Battery Calibration
.
4
The Battery Calibration feature is activated and the battery
is forcefully discharged. To stop the operation, press the
Esc
key.
This operation requires 3–5 hours depending on the
battery capacity and the remaining battery charge.
Using the Battery Calibration feature
When charging/discharging the battery repeatedly for a
short time only, the battery usage time may be reduced by
the difference between the actual battery charge and the
remaining charge display.
You can make the actual battery charge and the remaining
charge display the same by discharging the battery completely
using the Battery Calibration feature, and then recharging it
again.
The screen images and terms may differ from the
actual product depending on the computer model and
driver version.
1
Turn off the computer and then disconnect the adapter.
2
Turn the computer back on and press the
F2
key before the
Samsung logo appears to enter the BIOS setup screen.
Settings & Upgrade
71
4
Select
Yes
.
The computer will turn off automatically.
5
After connecting the adapter, turn on the computer again.
Using the Smart Battery Power Off feature
Storing your computer in a discharged state for an extended
period of time can shorten battery life quickly. If you are
not going to use your computer for a long period, more than
3 months, you can use the Smart Battery Power Off feature to
prevent the battery life from quickly shortening.
•
After shutting down the computer, store it in a
cool, dry environment to maintain stable battery
performance.
•
The battery must be charged at least 30 % before
using this feature.
•
To use this feature, use the supplied adapter.
1
Turn off the computer and then disconnect the adapter.
2
Turn the computer back on and press the
F2
key before the
Samsung logo appears to enter the BIOS setup screen.
3
Select
Advanced
→
Smart Battery Power Off
.
Settings & Upgrade
72
•
To restore the battery power after cutting it, connect
the adapter.
•
When you connect the adapter to a multiport
adapter to charge the computer, the charging speed
message may appear, but the computer will be
charged normally.
•
If many devices are connected to the multiport
adapter, the computer may not be charged or the
charging time may increase. In this case, connect the
adapter directly to the computer.
•
When the adapter is directly connected to the
computer, the charging speed message will not
appear.
•
If the computer will not be used for an extended
period, longer than 3 months, you can use the Smart
Battery Power Off feature to prevent the battery life
from quickly shortening. Refer to Using the Smart
Battery Power Off feature for more information.
•
The super fast charging feature supported by the
adapter can be used only with phones that support
this feature. (Only for models that support super fast
charging feature by the adapter).
Battery
Fully charge the battery using the supplied adapter before
using the computer for the first time.
•
Use only Samsung-approved adapters, batteries, and
cables. Unapproved adapters or cables can cause the
battery to explode or damage the computer.
•
Incorrectly connecting the adapter may cause
serious damage to the computer.
•
This computer is equipped with an internal battery.
The battery is not user-serviceable or user-
replaceable.
•
To safely remove or replace the battery, take the
device to a Samsung Service Center. You will be
charged for this service.
•
You can use the computer while it is charging,
but the battery charging time may increase. If the
battery temperature rises too much, the charging
may stop as a safety measure.
Settings & Upgrade
73
3
When the battery is fully charged, the operating status
LED turns green. Disconnect the adapter from the
computer.
Operating status LED Status
•
Red
: Charging
•
Green
: Fully charged
•
Blue
: Turned on
4
Unplug the adapter from the electric socket.
Do not allow the adapter to make contact with your skin
for a long time. A low-temperature burn may result.
Charging the battery
1
Connect the adapter to the Thunderbolt
™
4 port of the
computer.
2
Plug the adapter into an electric socket.
Settings & Upgrade
74
Saving battery power
Right-click the battery icon on the taskbar and select
Power
and sleep settings
→
Battery saver
→
Turn on now
.
Battery saver mode is activated.
Battery saver mode is disabled when the adapter is
connected.
Extending battery life
When charging your computer by connecting the adapter, turn
on the Protect battery feature. You can extend the battery life
by limiting the maximum charge.
1
Select the Start button ( )
→
All apps
→
Samsung
Settings
.
2
Select
Battery and performance
and select the
Protect
battery
switch to turn it on.
Battery status
When the adapter is removed, move the cursor over the battery
icon on the taskbar to check the current battery charge.
The current battery charge may differ depending on
the model.
Checking the current battery charge when the
computer is turned off
Connect or disconnect the adapter from the computer to check
the current battery charge when the computer is turned off.
Settings & Upgrade
75
When the battery has expired
Batteries are consumable parts and the current battery cannot
be used as the battery life has expired. Please replace it with
a new battery (genuine) to prevent data loss and ensure safe
usage. Whether or not batteries can be used is determined
based on safety evaluations. To prevent data loss while
replacing batteries, please be sure to save your work first.
When the battery ages or its performance decreases
The battery performance has decreased so it can affect the
battery life and computer performance.
If you need help, contact a Samsung Service Center.
Instruction messages related to battery life are
displayed properly when the
Samsung Settings
app
is installed on your computer. The messages may vary
depending on the model and software version.
Battery usage time
Batteries are replaceable items and over time the battery’s
capacity to hold a charge and its power level is reduced. If
a battery can only hold its charge for half of the time that
it could when new, it is recommended to purchase a new,
replacement battery.
Checking battery life instruction messages
When the battery has expired, an instruction message may
appear on the screen. To prevent the computer from losing
data and to use the computer safely, follow the on-screen
instructions.
When battery expiration is imminent
Batteries are consumable parts and the remaining battery
life is currently low. Continued use may result in charge or
discharge failures. Whether or not batteries can be used is
determined based on safety evaluations. Please replace it with
a new battery (genuine) to prevent data loss and ensure safe
usage.
76
Troubleshooting
Samsung Recovery
When a problem occurs with the computer, restore the
computer back to the factory default settings by using the
Samsung Recovery
app (Recovery/Backup). It is also possible
to restore the computer to a previously backed up point. Back
up important data regularly before a problem occurs with the
computer.
•
The
Samsung Recovery
app may not be provided in
models with less than 64 GB of storage. If you cannot
access the Samsung Recovery app, refer to Windows
recovery feature.
•
Some functions may differ or may be unavailable
depending on the version. Refer to the app’s help
information.
•
The
Samsung Recovery
app (Recovery/Backup) is
not available when using CD/DVD drives.
•
Recovering the computer erases the data or apps
saved after a backup point. Therefore, back up
important data regularly before a problem occurs
with the computer.
•
When you open the app for the first time, read and
accept the Terms and Conditions when they display
on the screen.
Troubleshooting
77
2
Select
Computer factory reset
→
Start factory reset
.
Follow the on-screen instructions to complete the
recovery to its initial status.
Recovering to factory default
You can restore the computer to its factory default settings.
If necessary, back up important data to an external storage
device before restoring the system. Refer to Backing up data.
1
When the computer starts Windows:
Select the Start button (
)
→
All apps
→
Samsung
Recovery
.
When the computer does not start Windows:
Turn on the computer and press the
F4
key several times
before the Samsung logo appears.
Troubleshooting
78
2
Select a drive to save the backed up data and select
Start
backup
.
•
When backing up to an external storage device, connect
the device to the computer and then select the external
drive.
3
Follow the on-screen instructions to complete the backup.
Backing up user data
You can back up data files and folders.
1
Turn on the computer and press the
F4
key several times
before the Samsung logo appears.
2
Select
Back up user data
.
3
Select the files or folders to back up and choose a storage
device to save the data to and then select
Start backup
.
•
The backed up folders or files can be saved only on an
external storage device. Connect an external storage
device to your computer first and then select the
external drive.
4
Follow the on-screen instructions to complete the backup.
Backing up data
Back up important data to an alternate internal drive or an
external storage device regularly to prevent data loss.
Backing up the current system
You can back up the factory default system or current system
to an alternate internal drive or an external storage device.
1
Select the Start button ( )
→
All apps
→
Samsung
Recovery
→
Back up computer
.
Troubleshooting
79
3
Select
Backup and restore management
.
4
Select
Restore
of the data you want to recover and select
Start restore
.
5
Follow the on-screen instructions to complete data
recovery.
Recovering after a backup
Select a backup point saved on an alternate internal drive or
an external storage device to recover the computer to that
point.
1
When backing up to an external storage device, connect
the device to the computer.
2
Select the Start button ( )
→
All apps
→
Samsung
Recovery
.
Troubleshooting
80
4
Select a disk to be copied and select
Start copy
.
The data on the disk is copied to the new disk.
Copying the drive (making a disk image)
To replace the drive, move the data to the new drive by making
a disk image. The new drive must be large enough to hold
the data from the current drive. Purchase an external hard
drive connector separately to connect the new drive to the
computer.
When Windows is installed on a non-user replaceable
disk, such as an eMMC, you cannot copy the drive.
1
Connect the new drive to the computer with an external
hard drive connector.
2
Select the Start button ( )
→
All apps
→
Samsung
Recovery
.
3
Select
Create a factory state disk
or
Create a disk copy
.
Troubleshooting
81
Q&A
When experiencing problems with the computer, try these
solutions.
Windows
How can I uninstall an app?
1
Select the Start button ( )
→
Settings
→
Apps
→
Installed apps
.
2
On the list, select next to the app you want to delete,
and then select
Uninstall
.
Windows recovery feature
If the
Samsung Recovery
app is not supported by the
computer, reinstall Windows using the recovery feature of
Windows.
Reinstalling Windows will erase all data saved on
the computer. Back up apps and personal data to an
external storage device before reinstalling Windows.
1
Select the Start button ( )
→
Settings
→
System
→
Recovery
.
2
Select
Reset PC
.
3
Select
Keep my files
or
Remove everything
.
After the system is recovered, select the Start button
(
)
→
All apps
→
Samsung Update
to install the
required Samsung apps.
Troubleshooting
82
Why is the capacity representation of the hard disk
drive (HDD) in Windows different from the product
specifications?
The capacity of the storage device (HDD or SSD) of the
manufacturer is calculated assuming that 1 KB = 1,000 Bytes.
However, the operating system (Windows) calculates the
storage device capacity assuming that 1 KB = 1,024 Bytes, and
therefore the capacity representation of the HDD in Windows
is smaller than the actual capacity. The capacity representation
in Windows may be smaller than the actual capacity because
some apps occupy a certain area of the HDD outside of
Windows.
For models with the
Samsung Recovery
app, the HDD capacity
representation in Windows may be smaller than the actual
capacity because the
Samsung Recovery
app uses a hidden
area of 5–20 GB of the HDD to save the recovery image, and
that hidden area is not counted towards the total size available
to Windows. The size of the
Samsung Recovery
app varies by
model.
Samsung Recovery
What is a Recovery Area?
The computer has an additional partition for restoring data
or saving backup files (only for models with the
Samsung
Recovery
app). This partition is called a Recovery Area and it
includes a recovery image comprised of the operating system
and apps.
Troubleshooting
83
Miscellaneous
The camera and the microphone are not working.
How do I turn them on again?
When recording protect mode is activated, the camera and
microphone will not work.
Select the Start button (
)
→
All apps
→
Samsung Settings
→
Security and privacy
and select the
Block camera and mic
switch to set it
Off
.
The computer does not turn on automatically when
the display panel is opened.
To turn on the computer, the display panel should be opened
greater than a certain angle.
The angle may differ depending on the model.
If the computer LED does not turn on automatically, press the
Power button.
What is a recovery image?
This refers to the operating system, drivers, and software that
are converted to a data image. It is required to recover the
computer and is embedded in the computer’s HDD. However,
this is not provided for storage devices where the capacity is
less than 64 GB.
How can I restore a computer that does not have
the Samsung Recovery app?
Restore the computer with the recovery feature provided by
Windows. Refer to the Recover Functionality item in the help
for more details.
84
Usage notices
Precautions for using the device
•
This user manual is specially designed to detail the
computer’s functions and features.
•
The user manual supplied with the computer may vary
depending on the model.
•
Please read this manual when using the computer to
ensure safe and proper use.
•
Optional accessories, some devices, and software referred
to in this manual may not be provided or may not be
subject to upgrades. Note that the computer environment
referred to in the user manual may not be the same as your
environment.
•
Descriptions are based on the computer’s default settings
and the Windows 11 operating system. Available features
and additional services may vary depending on the
computer or operating system.
•
This user manual describes procedures for using the
touchpad, mouse and touch screen. Instructions for using
the touch screen are for models with the touch screen
feature.
•
Images and screenshots are those of the representative
model of the series and may differ in appearance from the
actual product.
•
Content may differ from the final product and is subject to
change without prior notice. For the latest version of the
manual, refer to the Samsung website, www.samsung.com.
Usage notices
85
Copyright
Copyright © 2023 Samsung Electronics Co., Ltd.
This manual is protected under international copyright laws.
No part of this manual may be reproduced, distributed,
translated, or transmitted in any form or by any means,
electronic or mechanical, including photocopying, recording, or
storing in any information storage and retrieval system.
Computer specifications or the contents of this manual may be
changed without prior notice if the computer’s functions are
upgraded.
Instructional icons and expressions
Warning
: situations that could cause injury to yourself
or others
Caution
: situations that could cause damage to the
computer or other equipment
Note
: notes, usage tips, or additional information
The path you should follow to carry out an instruction.
For example, “select
Settings
→
Bluetooth & devices
”
indicates that you should select
Settings
and then
Bluetooth & devices
.
Select Click the mouse or tap the touchpad or touch screen.
Usage notices
86
•
Manufactured under license from Dolby Laboratories.
Dolby, Dolby Atmos, and the double-D symbol are
trademarks of Dolby Laboratories.
•
All other trademarks and copyrights are the property of
their respective owners.
Energy Star (USA only)
As an ENERGY STAR
®
Partner, Samsung
has determined that this Product meets the
ENERGY STAR Guidelines for energy efficiency.
The ENERGY STAR Program has reduced
greenhouse gas emissions and saved energy
through voluntary labeling. Samsung is a proud
ENERGY STAR Partner and commits to meet the guidelines
for this product to be ENERGY STAR certified. By selecting
an ENERGY STAR certified product, you reduce greenhouse
emissions, save energy, and can lower operating cost. For more
information, see http://www.energystar.gov/.
•
The Power Management setting of this product has been
enabled by default and has various timing settings (of up
to 300 minutes for energy saving. In case you don’t want
the power management setting enabled, select “Never”).
•
To change this in Settings, go to the System menu > Power
& sleep menu > Screen/Sleep timeout option.
This product can be awakened from sleep mode by pressing
the Power button.
Trademarks
•
Samsung and the Samsung logo are trademarks or
registered trademarks of Samsung Electronics Co., Ltd.
•
Intel and Core are trademarks or registered trademarks of
the Intel Corporation.
•
Microsoft, MS-DOS, and Windows are trademarks or
registered trademarks of the Microsoft Corporation.
•
Bluetooth
®
is a registered trademark of Bluetooth SIG, Inc.
worldwide.
•
Wi-Fi
®
, Wi-Fi Direct
™
, Wi-Fi CERTIFIED
™
, and the Wi-Fi
logo are registered trademarks of the Wi-Fi Alliance.
•
HDMI, the HDMI logo, and
the term High Definition
Multimedia Interface are
trademarks or registered
trademarks of HDMI
Licensing LLC.
•
Thunderbolt and the Thunderbolt logo are trademarks of
Intel Corporation in the U.S. and/or other countries.
Usage notices
87
Product capacity representation
Storage capacity representation
The capacity of the storage device (HDD, SSD) of the
manufacturer is calculated assuming that 1 KB = 1,000 Bytes.
However, the operating system (Windows) calculates the
storage device capacity assuming that 1 KB = 1,024 Bytes.
Therefore, the available capacity of the HDD in Windows is
smaller than the actual capacity because of the difference in
capacity calculation. For example, for an 80 GB HDD, Windows
calculates the capacity as 74.5 GB, (80x1,000x1,000x1,000)
Bytes/(1,024x1,024x1,024) Bytes = 74.505 GB.
In addition, the capacity representation in Windows may be
even smaller because some programs, such as Samsung
Recovery, may reside in a hidden area of the HDD.
Memory capacity representation
The available memory capacity in Windows is less than the
actual capacity of memory. This is because some memory is
required for regular system operations.
For example, for 1 GB (= 1,024 MB) memory installed, Windows
may report the capacity as 1,022 MB or less.
Data precautions
Samsung shall not be liable for any data loss. Please take care
to avoid losing any important data and back up your data to
prevent any such data loss.
Operating system and software support
If you change the product’s factory OS (Operating System) to
another OS or if you install software which is not supported
by the product’s original factory OS, you will not receive any
technical support, product exchange or refund, and a fee will
be charged when requesting a service.
Please use your computer with the original factory OS. If you
install an OS other than the factory OS, data may be deleted or
the computer may not start.
* Please use Windows 11 for this model.
Usage notices
88
•
Use an adjustable chair with firm, comfortable support.
•
Adjust the height of your chair so that thighs are horizontal
to the floor and feet are flat on the floor.
•
The back of the chair should support the lower back. Adjust
the backrest to fit your body properly.
•
Sit back fully in your chair and straighten the back and
neck. Avoid leaning forward or craning your neck toward
the computer screen.
•
Avoid using the computer while lying down or on your lap.
If the computer’s temperature increases, there is a danger
of burn injury.
•
The instructions in this manual have been prepared
so that they can be applied to the range of needs of
general users. If the user is not included in the range,
the recommendations should be applied according
to the user’s needs.
•
Images may differ from actual products.
Ergonomic tips
Maintaining proper posture during computer use is very
important to prevent physical injury. Improper or prolonged
keyboard use may result in repetitive strain injury. Viewing
the monitor screen for extended periods of time may result in
eye strain. Therefore, please follow these guidelines carefully
when setting up and using the computer.
Back and neck
Usage notices
89
Arms and hands
•
When using the keyboard and touchpad, the shoulders
should be relaxed. The upper arm and forearm should form
an angle that is slightly greater than a right angle, with the
wrist and hand in almost a straight line.
•
Use a light touch when typing or using the touchpad and
keep the hands and fingers relaxed. Avoid rolling the
thumbs under your palms or supporting the wrists on the
desk while typing.
•
Use an external keyboard and mouse when using the
computer for long periods. When using an external
keyboard and mouse, position the devices at the same
height as the computer and within comfortable reach.
Usage notices
90
Eye position and display illumination
50 cm
•
Position the screen at least 50 cm away from your eyes.
•
Adjust the height of the screen so that its top edge is equal
to or just below the level of your eyes.
•
Avoid setting the screen’s brightness settings excessively
high.
•
Keep the screen clean.
•
If wearing glasses, clean them before using the computer.
•
When referring to printed content while typing, use a
static paper holder to hold the paper at about the same
height as the monitor.
Hearing and volume control
VOLUME
Check your volume!
•
Ensure that the volume is not too loud before using a
headset or headphones. Excessive exposure to loud sounds
can cause hearing damage.
•
Always turn the volume down before plugging the
headphones into an audio source and use only the
minimum volume setting necessary to hear your
conversation or music.
•
Avoid using headphones for long periods of time.
•
Default audio settings can be changed by software and
driver updates without your knowledge. Always recheck
equalizer and volume settings before listening to audio.
•
To prevent possible hearing damage, do not listen at high
volume levels for long periods.
Usage notices
91
•
If anyone related to you has experienced seizures
or blackouts while using a similar product, consult a
physician before using the computer.
•
If you feel discomfort, such as a muscle spasm, or
disoriented, stop using the computer immediately and
consult a physician.
•
To prevent eye strain, take frequent breaks while using the
computer.
Reduce the risk of repetitive motion injuries.
When you repetitively perform actions, such as pressing keys,
drawing characters on a touch screen, or playing games,
you may experience occasional discomfort in your hands,
neck, shoulders, or other parts of your body. When using your
computer for extended periods, hold the computer with a
relaxed grip, press the keys lightly, and take frequent breaks. If
you continue to have discomfort during or after such use, stop
using the computer and consult a physician.
Operating conditions
•
Take at least a 10 minute break every hour.
•
Avoid using the computer in dark locations. Use the
computer with as much ambient light as you would when
reading a book.
•
Indirect illumination is recommended. Use a curtain to
prevent reflections and glare on the screen.
•
While operating a computer and talking on a phone, use
a headset. Using the computer while holding a phone on
your shoulder or with your neck may lead to muscle strain
or injury.
•
Keep frequently used items within reach.
•
Only use the computer within the temperature and
humidity ranges specified in this manual.
Use caution when exposed to flashing lights.
•
While using your computer, leave some lights on in the
room and do not hold the screen too close to your eyes.
•
Seizures or blackouts can occur when you are exposed
to flashing lights while watching videos or playing
Flash-based games for extended periods. If you feel any
discomfort, stop using the computer immediately.
Usage notices
92
Power related
Handle the power cord with care.
•
Do not touch with wet hands.
•
Do not use a damaged power cord.
•
Do not overload a multi-outlet or an extension cord
beyond the specified voltage/current capacity.
•
Correctly insert the plug into the outlet.
•
Do not unplug the power cord by pulling on the cable.
•
Unplug the wall-mount adapter (integrated plug and
power adapter) from the wall outlet while holding the
body and pulling it in the direction of the arrow.
Failure to do so may result in electric shock or fire.
Connect the power cord to the adapter firmly.
An improper connection may result in a fire.
Use the approved adapter or cable included in the product box.
If you use the unapproved adapter or cable, it cause the
damage or malfunction of the computer.
Safety precautions
For your safety and security and to prevent damage, carefully
read the following safety instructions. This ’Safety precautions’
relate to computer use. Some of the content may not be
applicable to your computer.
•
Since this is commonly applied to Samsung
computers, some pictures may differ from actual
products.
•
The product mentioned in this guide refers to all
items supplied with the computer including the
battery, the adapter, and all other Samsung-provided
accessories.
Warning
Failure to follow the instructions marked with this symbol may
result in physical injury or fatality.
NP UM Rev 5.0
Usage notices
93
Battery usage related
Use manufacturer-approved batteries, adapters, accessories,
and supplies.
•
Using generic batteries or adapters may shorten the life of
your product or cause the computer to malfunction. They
may also cause a fire or cause the battery to explode.
•
Use only Samsung-approved battery and adapter
specifically designed for your device. Incompatible battery
and adapter can cause serious injuries or damage to your
device.
•
Samsung cannot be responsible for the user’s safety when
using accessories or supplies that are not approved by
Samsung.
Take care to not allow metal objects such as a key or clip to
touch the battery terminals (metal parts).
This may cause excessive current and result in fire, burns, or
damage to the battery.
If the computer or the computer battery leaks, emits strange
odors, or swells, immediately stop using the computer and
contact a Samsung Service Center.
Failure to do so may result in an explosion or fire.
Use only properly earthed electric sockets or extension cords.
Unearthed electric sockets or extension cords may cause
electric shock. Any connection to unearthed electric sockets or
extension cords may produce an electric field from a current
leak.
If water or other substances enter the product, disconnect
the power cord and contact a Samsung Service Center. For
notebook computers that are supplied with an optional
removable battery, disconnect the battery.
Failure to do so may result in electric shock or fire caused by a
computer malfunction.
Prevent dust from accumulating on the power cord or the
electric socket. Regularly wipe the power cord and the electric
socket with a dry cloth.
Failure to do so may result in electric shock or fire.
Do not bend or damage the power cord or the adapter with a
heavy or sharp-edged object.
A damaged cable or cord may result in electric shock or fire.
Keep the battery, adapter, and power cord away from infants,
children, and pets.
Failure to do so may result in electric shock or damage.
Usage notices
94
Usage related
Do not use the computer on heated floors or electric pads, or
on beds, blankets, or cushions that block the ventilation of the
computer.
A blocked vent causes the computer to overheat, resulting in
an explosion, fire, burns, or computer malfunction.
Do not use the computer in hot or humid locations, such as a
bathroom, sauna, or inside a car during summer.
Failure to do so may result in computer malfunction or electric
shock.
The computer can be used in locations with an ambient
temperature of 10 °C to 35 °C and a relative humidity of 20 %
to 80 %RH.
To avoid suffocation, keep the plastic bag away from infants
and children.
Putting a plastic bag over the head may result in suffocation.
Never heat the computer (or the battery) or put the computer
(or the battery) into a fire or microwave.
Failure to do so may result in an explosion or fire.
Replace a run-down battery with a new, Samsung-approved
battery.
Dispose of worn-out batteries properly.
•
There is a danger of fire or explosion.
•
The battery disposal method may differ depending on
your country and region. Dispose of the used battery in an
appropriate way.
When removing the real time clock (RTC) battery, keep it away
from infants and children.
If a child swallows the battery, the child may suffocate. If this
happens, immediately contact a doctor.
Do not throw or disassemble the battery and do not put it into
water.
There is a danger of injury, fire or explosion.
Charge the battery according to the instructions in the
manual.
Failure to do so may cause an explosion or fire.
Usage notices
95
Caution
Failure to follow instructions marked with this symbol may
result in minor physical injury or damage to the computer.
Installation related
Do not block the ports (holes), vents, etc., of the product and
do not insert objects.
Damage to a component within the computer may cause
electric shock or fire.
When using the computer on its side, ensure the vents are
clear and facing upwards.
Failure to do so, may cause the internal temperature of the
computer to rise and the computer to malfunction or halt.
Keep the computer’s vents at least 15 cm away from walls and
other objects.
Failure to do so may result in physical injury.
Before cleaning the computer, disconnect all the cables that
are connected to the computer. For notebook computers that
are supplied with an optional removable battery, disconnect
the battery.
Failure to do so may result in electric shock or fire.
Keep the computer away from water or liquid.
Water or liquid entering the computer may short-circuit the
computer, resulting in electric shock or fire.
If the computer is dropped or broken, disconnect the power
cord and contact a Samsung Service Center. For notebook
computers that are supplied with an optional removable
battery, disconnect the battery.
Using a broken computer may result in electric shock or fire.
Do not touch the computer’s surface or the vents for extended
periods while the computer is on.
Contact with the vent or the surface for extended periods may
result in low-temperature burns, such as redness on the skin.
Do not carry your device in your back pockets.
•
The device may be damaged, explode, or result in a fire if
too much pressure is applied to it.
•
You may be injured if you are bumped or fall.
Usage notices
96
Usage related
Do not use the pen for unintended purposes, such as poking
the body, like eyes or ears, and do not put it in your mouth.
Doing so may result in physical injury.
Do not place a candle, lit cigar, etc., over or on the product.
There is a danger of fire.
Make sure to have the product tested by a safety service
engineer after repairing the product.
Using a repaired product without testing it for safety may
cause an electric shock or fire.
In case of lightning, immediately turn the system off, then
disconnect the power cord from the wall outlet and phone line
from modem.
There is a danger of electric shock or fire.
Connect only permitted devices to the connectors or ports of
the computer.
Failure to do so may result in an electric shock or fire.
Do not place or use the computer on slanted or vibrating
surfaces.
Failure to do so may result in computer malfunction or
damage.
Do not place heavy objects on the product.
This may cause a problem with the computer. In addition, the
object may fall and cause injury or damage the computer.
Properly shut down, disconnect and secure the computer
cables before moving it.
Failure to do so may damage the computer or cause someone
to trip over a loose cable.
Usage notices
97
Do not store your device near or in heaters, microwaves, hot
cooking equipment, or high pressure containers.
•
The battery may leak.
•
Your device may overheat and cause a fire.
Do not insert your fingers into the ports (holes), card slot, or
vents.
There is a danger of injury or electric shock.
Use recommended computer cleansing solutions when
cleaning the product and only use the computer when it is
completely dry.
Failure to do so may result in electric shock or fire.
Close the display panel only after checking if the notebook
computer is turned off.
The temperature may rise and it may cause deformation of the
product.
Do not drop or hit the computer against anything.
Failure to do so may result in physical injury or computer
malfunction.
When handling computer parts, follow the instructions on the
manual supplied with the parts.
Failure to do so may result in damage to the product.
If the product emits smoke or there is a burning smell,
disconnect the adapter from the wall outlet and contact
a Samsung Service Center immediately. For notebook
computers that are supplied with an optional removable
battery, disconnect the battery.
There is a danger of fire.
Usage notices
98
Do not use your computer in a hospital or on an aircraft that
can be interfered with by radio frequency.
•
Avoid using your computer within a 15 cm range of a
pacemaker, if possible, as your computer can interfere with
the pacemaker.
•
To minimize possible interference with a pacemaker,
use your computer only on the side of your body that is
opposite the pacemaker.
•
If you use medical equipment, contact the equipment
manufacturer before using your computer to determine
whether or not the equipment will be affected by radio
frequencies emitted by the computer.
•
When in a hospital, turn off your computer and follow all
hospital regulations. Radio frequencies emitted from the
computer may affect medical equipment.
Do not use the product if it is cracked or broken.
Broken glass or acrylic could cause injury to your hands and
face. Take the device to a Samsung Service Center to have it
repaired.
When using wireless communication (LAN, Bluetooth, etc.)
always follow applicable instructions. For example, airlines
and hospitals have strict requirements.
Avoid exposing a drive to magnetic fields. Security devices
with magnetic fields include airport walk-through devices
and security wands. The airport security devices that check
carry-on luggage use X-rays instead of magnetism and will
not damage a drive.
Keep the computer away from magnetic material.
•
Magnetic materials may cause computer malfunction or
cause the battery to discharge.
•
To avoid damaging the computer or magnetic stripe cards,
such as credit cards, keep magnetic stripe cards away from
the computer.
Usage notices
99
Shut down the computer and disconnect all cables before
disassembling the computer. For notebook computers that are
supplied with an optional removable battery, disconnect the
battery.
Failure to do so may cause electric shock.
Make sure to close the computer cover before connecting the
power after a reassembly.
There is a danger of electric shock if your body touches an
internal part.
Never disassemble or repair the product by yourself.
There is danger of an accident. Use an authorized Samsung
Service Center.
To connect a device that is not manufactured or authorized
by Samsung, enquire at a Samsung Service Center before
connecting the device.
There is a danger of damaging the product.
Upgrade Related
Do not attempt to upgrade the computer, unless you are
qualified. Otherwise, contact a Samsung Service Center or an
authorized technician.
When you upgrade permitted devices, according to the
manual, follow the specified instructions in the manual to
upgrade them. Do not disassemble any other parts by yourself.
Failure to do so may result in computer malfunction, electric
shock, or fire.
Take care when touching the product or parts.
The computer may be damaged or you may be injured.
Do not disassemble the power supply unit in any
circumstances.
Failure to do so may result in electric shock, fire, or an
explosion.
Usage notices
100
Cautions on preventing data loss (storage device
(such as HDD, SSD, eMMC) management)
Take care not to damage the data on a storage device (such as
HDD, SSD, eMMC).
•
Subjecting the device to physical impacts may result in
data loss.
•
Data may be lost when the computer is turned off or reset
by a power failure while the storage device (such as HDD,
SSD, eMMC) is operating.
•
Data may be lost and irrecoverable because of a computer
virus.
•
Data may be lost if the power is turned off while running
an app.
•
Samsung is not liable for any loss of data on a storage
device (such as HDD, SSD, eMMC).
To prevent data loss caused by damage to a storage device
(such as HDD, SSD, eMMC), please back up the data frequently.
Storage and movement related
Do not store the computer in an enclosed space, such as a
computer bag, while it is running.
Failure to do so may result in fire. Completely shut down the
computer before putting the computer into an enclosed space.
When carrying the notebook computer with other items,
such as the adapter, mouse, books etc., take care not to press
anything against the notebook computer.
If a heavy object is pressed against the notebook computer, a
white spot or stain may appear on the display.
Do not operate or look at the computer while driving a vehicle.
There is a danger of a traffic accident. Please concentrate on
driving.
For long periods of inactivity or storage, discharge the battery
and separate it from the computer (for external or removable
battery types).
Usage notices
101
Display bad pixels
Samsung observes strict specifications regarding the quality
and reliability of the display. However, there is a small chance
that a few pixels may be bad. A large number of bad pixels can
cause problems with the display, but a small number of bad
pixels does not generally affect computer performance.
Samsung’s quality standards for bad pixels are as follows:
•
Bright dot
: 2 or fewer
•
Black dot
: 4 or fewer
•
Combination (bright and dark)
: 4 or fewer
Clean the display screen with a soft cloth dampened with
computer cleansing detergent.
Do not use excessive force. Doing so may damage the display
screen.
102
Appendix
Product specifications
The system specifications may differ depending on the derived
model. For detailed system specifications, refer to the product
catalog.
Item Specification
Operating
environment
•
Temperature: -5–40 °C for storage,
10–35 °C when
op
erating
•
Humidity: 5–90 % for storage,
20–80 % when operating
A
C/DC rating
•
Input: 100–240 V–, 50–60 Hz, 1.7 A
•
Output: (PDO) 5.0 VDC, 3.0 A or
9.0 VDC, 3.0 A or 15 VDC,
3.0 A or 20 VDC, 3.25 A,
65.0 W
(PPS) 5.0–20.0 VDC, 3.25 A
PC r
ating
•
20 VDC, 3.25 A (65 W)
•
Optional components may not be provided or
different components may be provided depending
on the model.
•
The system specifications are subject to change
without notice.
•
The Storage device capacity of a computer in which
Samsung Recovery
is installed is smaller than the
product specification.
•
For some models, it is not possible to add storage or
add or replace memory because of the computer’s
design. To replace the storage, contact the Samsung
Service Center. You will be charged for this service.
•
The amount of memory that Windows can use may
be smaller than the actual amount of memory
available.
Appendix
103
Setting up the system
•
Read and follow all instructions marked on the product
and in the documentation before operating the system.
Retain all safety and operating instructions for future use.
•
Do not use this product near water or a heat source such as
a radiator.
•
Set up the system on a stable work surface.
•
The product should be operated only with the type of
power source indicated on the rating label.
•
Ensure that the electrical outlet to power the equipment is
easily accessible in case of fire or short circuit.
•
If the computer has a voltage selector switch, make sure
that the switch is in the proper position for your area.
•
Openings in the computer case are provided for
ventilation. Do not block or cover these openings. Make
sure you provide adequate space, at least 6 inches (15 cm),
around the system for ventilation when setting up your
work area. Never insert objects of any kind into the
computer ventilation openings.
Important safety information
Safety instructions
The system is designed and tested to meet the latest
standards for safety of information technology equipment.
However, to ensure safe use of this product, it is important
that the safety instructions marked on the product and in the
documentation are followed.
Always follow these instructions to help guard against
personal injury and damage to the system.
Appendix
104
Care during use
•
Do not walk on the power cord or allow anything to rest on
it.
•
Do not spill anything on the computer or its components.
The best way to avoid spills is to not eat or drink near the
computer or its components.
•
Some products have a replaceable CMOS battery on
the system board. There is a danger of explosion if the
CMOS battery is replaced incorrectly. Replace the battery
with the same or equivalent type recommended by the
manufacturer.
Dispose of batteries according to the manufacturers
instructions. If the CMOS battery requires replacement
ensure that a qualified technician performs the task.
•
When the computer is turned off, a small amount of
electrical current still flows through the computer.
To avoid electrical shock, always unplug all cables, remove
the battery and modem cables from the wall outlets
before cleaning the system.
•
Ensure that the fan vents at the bottom of the casing are
clear at all times. Do not place the computer on a soft
surface, doing so will block the bottom vents.
•
When using an extension cord with this system, make sure
that the total power rating on the products plugged into
the extension cord does not exceed the extension cord
power rating.
•
For computers with glossy display bezels the user should
consider the placement of the computer as the bezel
may cause reflections from surrounding light and bright
surfaces.
Appendix
105
Operating instructions
1
When installing and operating devices please refer to
safety requirements in the user manual.
2
Devices can be used only with the equipment specified in
the technical specifications of the devices.
3
If any smell of burning or smoke is detected from the
computer the unit should be switched off and the battery
removed. The unit should be checked by a qualified
technician before reuse.
4
Service and repair of devices should be carried out by
authorized service centers.
5
Do not allow the portable computer to operate with the
base resting directly on exposed skin for extended periods
of time. The surface temperature of the base will rise
during normal operation (particularly when AC Power is
present). Allowing sustained contact with exposed skin
can cause discomfort or eventually a burn.
•
Unplug the system from the wall outlet and contact a
Samsung Service Center if:
‒
The power cord or plug is damaged.
‒
Liquid has been spilled into the computer.
‒
The computer does not operate properly when the
operating instructions are followed.
‒
The computer was dropped or the casing is damaged.
‒
The computer performance changes.
Appendix
106
Battery disposal
Do not put rechargeable batteries or products powered
by non-removable rechargeable batteries in the
garbage.
Contact the Samsung Service Center for information on how
to dispose of batteries that you cannot use or recharge any
longer. Follow all local regulations when disposing of old
batteries.
THERE IS RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
Replacement parts and
accessories
Use only replacement parts and accessories recommended by
manufacturer.
To reduce the risk of fire, use only No. 26 AWG or larger
telecommunications line cord.
Do not use this product in areas classified as
hazardous. Such areas include patient care areas
of medical and dental facilities, oxygen rich
environments, or industrial areas.
Appendix
107
•
Laser Safety Note: Use of controls or adjustments
or performance of procedures other than those
specified in this manual may result in hazardous
radiation exposure. To prevent exposure to laser
beams, do not try to open the enclosure of a CD or
DVD drive.
•
Class 1M laser radiation when operating part is open.
Do not view directly with optical instruments.
•
Class 3B invisible laser radiation when open.
Avoid exposure to the beam.
Connecting and disconnecting the adapter
The socket-outlet shall be installed near the equipment and
shall be easily accessible.
Do not unplug the power cord by pulling the cable only.
Laser safety
All systems equipped with CD or DVD drives comply with
the appropriate safety standards, including IEC 60825-1. The
laser devices in these components are classified as “Class 1
Laser Products” under a US Department of Health and Human
Services (DHHS) Radiation Performance Standard. Should
the unit ever need servicing, contact an authorized service
location.
Appendix
108
General requirements
The requirements listed below are applicable to all countries:
•
All power cord sets must be approved by an acceptable
accredited agency responsible for evaluation in the country
where the power cord set will be used.
•
The power cord set must have a minimum current capacity
of 7 A and a nominal voltage rating of 125 or 250 volts AC,
as required by each country’s power system (USA only).
•
The appliance coupler must meet the mechanical
configuration of an EN 60 320/IEC 320 Standard Sheet C7
(or C5) connector, for mating with appliance inlet on the
computer.
Power cord requirements
The power cord set (all plugs, cable and adapter plugs) you
received with your computer meets the requirements for use in
the country where you purchased your equipment.
Power cord sets for use in other countries must meet the
requirements of the country where you use the computer. For
more information on power cord set requirements, contact
your authorized dealer, reseller, or service provider.
India only
The power cord set must have a minimum current capacity
and a nominal voltage rating, as required by country’s power
system.
Appendix
109
The RF field strength of the wireless device or devices that may
be embedded in the notebook are well below all international
RF exposure limits as known at this time. Because the wireless
devices (which may be embedded into the notebook) emit less
energy than is allowed in radio frequency safety standards and
recommendations, manufacturer believes these devices are
safe for use. Regardless of the power levels, care should be
taken to minimize human contact during normal operation.
Some circumstances require restrictions on wireless devices.
Examples of common restrictions are listed on the next page:
Regulatory compliance
statements
Wireless guidance
(If fitted with 2.4 G band, 5 G band or 6 G band)
Low power, Radio LAN type devices (radio frequency
(RF) wireless communication devices), operating in the
2.4 GHz/5 GHz/6 GHz Band, may be present (embedded) in the
notebook system. The following section is a general overview
of considerations while operating a wireless device.
Additional limitations, cautions, and concerns for specific
countries are listed in the specific country sections (or country
group sections). The wireless devices in the system are only
qualified for use in the countries identified by the Radio
Approval Marks on the system rating label. If the country you
will be using the wireless device in, is not listed, please contact
your local Radio Approval agency for requirements. Wireless
devices are closely regulated and use may not be allowed.
Appendix
110
•
If the system came equipped with an internal
embedded wireless device, do not operate the
wireless device unless all covers and shields are in
place and the system is fully assembled.
•
Wireless devices are not user serviceable. Do not
modify them in any way. Modification to a wireless
device will void the authorization to use it. Please
contact the manufacturer for service.
•
Only use drivers approved for country in which
the device will be used. Refer to the manufacturer
System Restoration Kit, or contact the
manufacturer’s technical support for additional
information.
Explosive Device Proximity Warning
Do not operate a portable transmitter (such as a wireless
network device) near unshielded blasting caps or in an
explosive environment unless the device has been modified to
be qualified for such use.
•
Radio frequency wireless communication can
interfere with equipment on commercial aircraft.
Current aviation regulations require wireless devices
to be turned off while traveling in an airplane.
802.11 (also known as wireless Ethernet or Wi-Fi) and
Bluetooth communication devices are examples of
devices that provide wireless communication.
•
In environments where the risk of interference to
other devices or services is harmful or perceived as
harmful, the option to use a wireless device may
be restricted or eliminated. Airports, hospitals, and
oxygen or flammable gas laden atmospheres are
limited examples where use of wireless devices may
be restricted or eliminated. When in environments
where you are uncertain of the sanction to use
wireless devices, ask the applicable authority for
authorization prior to use or turning on the wireless
device.
•
Every country has different restrictions on the use
of wireless devices. Since your system is equipped
with a wireless device, when traveling between
countries with your system, check with the local
Radio Approval authorities prior to any move or trip
for any restrictions on the use of a wireless device in
the destination country.
Appendix
111
Explosive Device Proximity Warning
Do not operate a portable transmitter (such as a
wireless network device) near unshielded blasting caps
or in an explosive environment unless the device has
been modified to be qualified for such use.
Use On Aircraft Caution
FCC, FAA, and TCCA regulations prohibit airborne
operation of radio-frequency wireless devices because
their signals could interfere with critical aircraft
instruments.
Other wireless devices
Safety notices for other devices in the wireless network:
Refer to the documentation supplied with wireless Ethernet
adapters or other devices in the wireless network.
United States of America and Canada
USA and Canada Safety Requirements and Notices
Do not touch or move antenna while the unit is transmitting or
receiving.
Do not hold any component containing the radio such that
the antenna is very close to touching any exposed parts of the
body, especially the face or eyes, while transmitting.
Do not operate the radio or attempt to transmit data unless
the antenna is connected; if not, the radio may be damaged.
Use in specific environments:
The use of wireless devices in hazardous locations is limited
by the constraints posed by the safety directors of such
environments.
The use of wireless devices on airplanes is governed by
the Federal Aviation Administration (FAA) in the USA and
Transport Canada Civil Aviation (TCCA) in Canada.
The use of wireless devices in hospitals is restricted to the
limits set forth by each hospital.
Appendix
112
This equipment has been tested and found to
comply with the limits for a Class B digital device
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate
radio frequency energy. If not installed and used in
accordance with the instructions, it may cause harmful
interference. If this equipment does cause harmful
interference to radio or television reception, which can
be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference
by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and
receiver.
•
Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
•
Consult the dealer or an experienced radio/TV
technician for help.
The Part 15 radio device operates on a non-interference
basis with other devices operating at this frequency.
Any changes or modification to said product not
expressly approved by Intel could void the user’s
authority to operate this device.
FCC Part 15 Information and Notices
Responsible Party – U.S. Contact Information
Samsung Electronics America, Inc.
85 Challenger Road.
Ridgefield Park, NJ 07660
Phone: 1-800-SAMSUNG (726-7864)
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept
any interference received, including interference that may
cause undesired operation.
Appendix
113
Health and safety information
Exposure to Radio Frequency (RF) Signals
Certification Information
This product can contain an embedded radio transmitter
and receiver. It is designed and manufactured not to exceed
the exposure limits for radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the U.S.
government. These FCC exposure limits are derived from the
recommendations of two expert organizations, the National
Council on Radiation Protection and Measurement (NCRP) and
the Institute of Electrical and Electronics Engineers (IEEE). In
both cases, the recommendations were developed by scientific
and engineering experts drawn from industry, government,
and academia after extensive reviews of the scientific
literature related to the biological effects of RF energy.
Before a new model is available for sale to the public, it must
be certified to the FCC that it does not exceed the exposure
limit established by the FCC. Evaluation per each model is
performed in positions and locations (such as at the bottom on
the body) as required by the FCC.
If necessary, the user should consult the dealer or an
experienced radio/television technician for additional
suggestions. The user may find the following booklet helpful:
“Something About Interference.”
This is available at FCC local regional offices. Our company
is not responsible for any radio or television interference
caused by unauthorized modifications of this equipment
or the substitution or attachment of connecting cables and
equipment other than those specified by our company. The
correction will be the responsibility of the user. Use only
shielded data cables with this system.
Operation of transmitters in the 5.925-7.125 GHz band is
prohibited for control of or communications with unmanned
aircraft systems.
Appendix
114
For corresponding model only
The Specific Absorption Rate (SAR) is a measure of the rate
of absorption of RF energy by the human body expressed in
units of watts per kilogram (W/kg). The FCC wireless devices to
comply with a safety limit of 1.6 watts per kilogram (1.6 W/kg).
SAR level of this device while operating can be well below
the maximum value. This is because the device is designed to
operate at multiple power levels so as to use only the power
required to reach the network. In general, the closer you are to
a wireless base station antenna, the lower the power output.
For body worn operation, this model meets the FCC RF
exposure guidelines when used with Samsung accessory
designated for this product. Non-compliance with the above
restrictions may result in violation of FCC RF exposure
guidelines.
RF exposure or SAR information can be viewed on-line at
www.fcc.gov/oet/ea/fccid/. This site uses this product FCC ID
number on the outside of the product. Sometimes it may be
necessary to remove the battery pack to find number. Once
you have the FCC ID number for a particular product, follow the
instructions on the website and it should provide RF exposure
information or values for typical or maximum SAR for particular
product.
Appendix
115
RTC caution
CAUTION: Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type
recommended by the manufacturer. Discard used batteries
according to the Manufacturer’s instruction.
Manufacturer information
Samsung Electronics Co., Ltd.
129, Samsung-Ro, Yeongtong-Gu, Suwon-City, Gyeonggi-Do,
16677, Korea
Samsung Electronics Vietnam Co., Ltd.
Khu Cong nghiep Yen Phong 1, Yen Trung, Yen Phong, Bac Ninh,
Viet Nam
Tel: +84-222-369-6875
For the web or the phone number of the Samsung Service
Center, refer to the Warranty or contact the retailer where you
purchased your product.
Appendix
116
Innovation, Sciences et Développement
économique Canada
L’émetteur/récepteur exempt de licence contenu dans le
présent appareil est conforme aux CNR d’Innovation, Sciences
et Développement économique Canada applicables aux
appareils radio exempts de licence. L’exploitation est autorisée
aux deux conditions suivantes :
1. L’appareil ne doit pas produire de brouillage.
2. L’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le
fonctionnement.
Avertissement:
Les dispositifs fonctionnant dans la bande 5 150-5 250 MHz
sont réservés uniquement pour une utilisation à l’intérieur a n
de réduire les risques de brouillage préjudiciable aux systèmes
de satellites mobiles utilisant les mêmes canaux.
Les appareils fonctionnant dans la bande
5 925-7 125 MHz ne doivent pas être utilisés pour le contrôle ou
les communications avec des systèmes d’aéronefs sans pilote.
Canada
Innovation, Science and Economic Development
Statement:
This device contains licence-exempt transmitter(s)/
receiver(s) that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is
subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including
interference that may cause undesired operation of the
device.
Industry Canada Caution
The device for operation in the band 5150-5250 MHz is only for
indoor use to reduce the potential for harmful interference to
co-channel mobile satellite systems.
Devices to operate in the 5925-7125 MHz Band shall not be
used for control of or communications with unmanned aircraft
systems.
Appendix
117
Household users should contact either the retailer where
they purchased this product, or their local government office,
for details of where and how they can take these items for
environmentally safe recycling.
Business users should contact their supplier and check the
terms and conditions of the purchase contract. This product
and its electronic accessories should not be mixed with other
commercial wastes for disposal.
For information on Samsung’s environmental commitments
and product regulatory obligations, such as REACH, visit our
sustainability page available at www.samsung.com.
India only
For more information on safe disposal and recycling visit
our website www.samsung.com/in or contact our Helpline
numbers - 18002668282, 180030008282.
This product is RoHS compliant.
WEEE symbol information
Correct disposal of this product (Waste Electrical &
Electronic Equipment)
(Applicable in countries with separate collection
systems)
This marking on the product, accessories or literature indicates
that the product and its electronic accessories (for example,
charger, headset, USB cable) should not be disposed of with
other household waste at the end of their working life.
To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate these items
from other types of waste and recycle them responsibly to
promote the sustainable reuse of material resources.
Appendix
118
Removing the battery (Europe only)
•
To remove the battery, contact an authorised service
centre. To obtain battery removal instructions, please visit
www.samsung.com/global/ecodesign_energy.
•
For your safety, you must not attempt to remove the
battery. If the battery is not properly removed, it may lead
to damage to the battery and device, cause personal injury,
and result in the device being unsafe.
•
Samsung does not accept liability for any damage or loss
(whether in contract or tort, including negligence) which
may arise from failure to precisely follow these warnings
and instructions, other than death or personal injury
caused by Samsung’s negligence.
Correct disposal of batteries in this product
(Applicable in countries with separate collection
systems)
This marking on the battery, manual or packaging indicates
that the batteries in this product should not be disposed of
with other household waste at the end of their working life.
Where marked, the chemical symbols Hg, Cd or Pb indicate
that the battery contains mercury, cadmium or lead above
the reference levels in EC Directive 2006/66. If batteries are
not properly disposed of, these substances can cause harm to
human health or the environment.
To protect natural resources and to promote material re-use,
please separate batteries from other types of waste and
recycle them through your local, free battery return system.
PO BOX 12987, DUBLIN. IE
Appendix
119
Samsung package Take-Back
program
(USA only)
In partnering with select recyclers, Samsung offers packaging
take-back at no cost to you.
Simply call the following number for the locations nearest you.
CRT Processing, LLC
(877) 278-0799
Kathy Severson – Logistics contact
For more recycling information, go to our website:
www.samsung.com/recycling or call 1-800-SAMSUNG.
USA only
This Perchlorate warning applies only to primary CR
(Manganese Dioxide) Lithium coin cells in the product sold or
distributed ONLY in California USA.
“Perchlorate Material- special handling may apply, refer to
www.dtsc.ca.gov/hazardouswaste/perchlorate.”
Some content may differ from the computer depending on the region, service provider, software version, or computer model, and is
subject to change without prior notice.
English. 11/2023. Rev. 1.0www.samsung.com
