MOTORCYCLE ENGINE CRANKCASE
SEPARATOR
Model no: SMC30
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAfETY
WARNING! ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this tool.
WARNING! Familiarise yourself with the specic applications and limitations of the kit, as well as any potential hazards.
9 This kit should be used in conjunction with inspection maintenance procedures recommended in the vehicle manufacturer’s manual.
9 ensure that the kit is correct for the task.
9 Wear the appropriate personal protective equipment for the task. A full range is available from your Sealey stockist.
8 DO NOT use the kit for any purpose other than that for which it is designed.
9 ensure there is adequate lighting prior to using the kit. A range of inspection lamps are available from your Sealey stockist.
9 Keep children and unauthorised persons away from the working area.
8 DO NOT use the kit if any parts are damaged or missing, as this may cause failure and/or personal injury.
8 DO NOT use the kit when you are tired, or under the inuence of alcohol, drugs or intoxicating medication.
9 After use, store in a safe, dry childproof area.
2. INTRODuCTION
Fully adjustable robust tool for assisting in the successful separation of the engine crankcases to allow access to the crankshaft,
connecting rods and other internal components. Suitable for use on a variety of motorcycle and ATV engines. Supplied in storage
case.
3. CONTENTS
4. OPERATION
NOTE: Suitable for engines with M6 casing bolts only.
4.1. lightly lubricate all threads.
4.2. Assemble the tool as shown in g.2 and g.3.
4.3. Select appropriate height M6 adaptors to ensure that the tool is
level before use (see g.3).
SMC30 Issue 1 11/11/19
Original Language Version
© Jack Sealey limited
Refer to
instructions
Wear eye
protection
Wear protective
gloves
Wear protective
footwear
Item Part no. Description
1 SMC30.01 Main threaded bar M14 x 1.5 x 180mm
2 SMC30.02 Mounting bolt M8 x 1.25 x 90mm (x3)
3 SMC30.03 Mounting bolt adaptor M6 x 1 x 65mm
4 SMC30.04 Mounting bolt adaptor M6 x 1 x 57mm
5 SMC30.05 Mounting bolt adaptor M6 x 1 x 49mm
g.1
g.2
Attach adaptors (not shown)
See g.3 also.
Original Language Version
© Jack Sealey limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENvIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: no liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
g.3
