Refrigerator
Simple User manual
• Free standaing Appliance
• For detailed instructions on installation and cleaning of the appliance and ecodesign
information (according to (EU)2019/2023), visit the Samsung website (http://www.
samsung.com), go to Support > Support home, and then enter the model name. Or,
download and install the SmartThings app on your mobile device, and then open
HomeCare Wizard in SmartThings for tips and guides.
• Open a QR code scanner app and scan the QR code image attached to the product. You
can access ‘Product registration’, ‘Manual’, and ‘Customer support’ through SmartThings
connection.
• Figures and illustrations are provided for reference only and may differ from the actual
product appearance. Product design and specifications may change without notice.
Scan this with your phone.
Instructions about the WEEE
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its
electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other
household waste at the end of their working life. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, please separate these items from other
types of waste and recycle them responsibly to promote the sustainable reuse of material
resources.
Household users should contact either the retailer where they purchased this product, or
their local government office, for details of where and how they can take these items for
environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product and its electronic accessories should not be mixed with other
commercial wastes for disposal.
For information on Samsung’s environmental commitments and product regulatory obligations, e.g.
REACH, WEEE or Batteries, visit our sustainability page available via www.samsung.com
(For products sold in European countries and in the UK only)
Simple_RS4000D_DA68-04820B-00_EN.indd 1Simple_RS4000D_DA68-04820B-00_EN.indd 1 2024-07-18 3:07:322024-07-18 3:07:32
Safety information2
English
Safety information
• Congratulations on your new Samsung appliances. This manual contains important information on the
installation, use, and care of your appliances. Read this manual thoroughly before using the appliances
to ensure that you know how to safely and efficiently operate the features and functions that your new
appliances offers.
• To check the product’s model name, see the label enclosed with the product or attached to the product.
Important safety symbols
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury, death and/or property damage.
CAUTION
Hazards or unsafe practices that may result in personal injury and/or property damage.
NOTE
Supplementary information that may be useful
Read the instructions
These warning signs are here to prevent injury to yourself and others.
Please follow them explicitly.
After reading this manual, store it in a safe place for future reference.
WARNING
Failure to follow the instructions may result in electric shock, injury, fire,
breakdown or explosion.
Important safety precautions
1. This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
Simple_RS4000D_DA68-04820B-00_EN.indd 2Simple_RS4000D_DA68-04820B-00_EN.indd 2 2024-07-18 3:07:322024-07-18 3:07:32
3Safety information
English
2. For use in Europe : This appliance can be used by children aged from
8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
3. Children should be supervised to ensure that they do not play with
the appliance.
4. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order
to avoid a hazard.
WARNING; Risk of fire / flammable materials
5. This appliance contains a small amount of combustible refrigerant
isobutane (R-600a). For installation, handling, servicing and disposal
of the appliance, care should be taken to ensure that no parts of the
refrigerating circuit are damaged.
6. R-600a or R-134a is used as a refrigerant. Check the compressor label
on the rear of the appliance or the rating label inside the fridge to
see which refrigerant is used for your appliance. When this product
contains flammable gas (Refrigerant R-600a), contact your local
authority in regard to safe disposal of this product.
7. Do not damage the refrigerant circuit.
Simple_RS4000D_DA68-04820B-00_EN.indd 3Simple_RS4000D_DA68-04820B-00_EN.indd 3 2024-07-18 3:07:332024-07-18 3:07:33
Safety information4
English
8. To avoid the creation of a flammable gas-air mixture if a leak in the
refrigerating circuit occurs, the room size must be 1 m3 in size for
every 8 g of R-600a refrigerant inside the appliance. And, unplug the
appliance showing any signs of damage and please consult to your
dealer if in doubt.
9. Cyclopentane is used in the insulation. The gases in the insulation
material require a special disposal procedure. Please contact your
local authorities for environmentally safe disposal.
10. The socket must be easily accessible so that the appliance can be
quickly disconnected from the supply in an emergency.
11. When positioning the appliance, ensure the supply cord is not
trapped or damaged.
12. Do not locate multiple portable socket-outlets or portable power
supplies at the rear of the appliance.
13. This appliance is intended to be used in household and similar
applications such as
– staff kitchen areas in shops, offices and other working
environments;
– farm houses and by clients in hotels, motels and other residential
type environments;
– bed and breakfast type environments;
– catering and similar non-retail applications.
14. Keep ventilation openings, in the appliance enclosure or in the builtin
structure, clear of obstruction.
15. Do not use mechanical devices or any other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
Simple_RS4000D_DA68-04820B-00_EN.indd 4Simple_RS4000D_DA68-04820B-00_EN.indd 4 2024-07-18 3:07:332024-07-18 3:07:33
5Safety information
English
16. Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
17. Do not keep volatile or flammable objects or substances in the
refrigerator.
– This refrigerator is for storing food only.
– This may result in fire or explosion.
18. Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
19. For the most efficient use of energy, please keep the all inner
fittings such as baskets, drawers, shelves on the position supplied by
manufacturer.
20. Connect to potable water supply only. (applicable models only)
21. Fill with potable water only. (applicable models only)
– Fill the water tank, ice tray and water cubes only with potable
water (mineral water or purified water).
– Do not fill the tank with tea, juice or sports drink, this may damage
the refrigerator.
22. New hose-sets supplied with the appliance are to be used and old
hose-sets should not be reused.
23. Please connect to the potable water supply only. Water pressure of
206-861 kPa(30-125 psi) is required for the correct operation.
24. If the product is equipped with LED lamps, please contact a local
Samsung service center or it's agents to replace the lamps.
Simple_RS4000D_DA68-04820B-00_EN.indd 5Simple_RS4000D_DA68-04820B-00_EN.indd 5 2024-07-18 3:07:332024-07-18 3:07:33
Safety information6
English
25. To avoid contamination of food, please respect the following
instructions:
– Opening the door for long periods can cause a significant increase
of the temperature in the compartments of the appliance.
– Clean regularly surfaces that can come in contact with food and
accessible drainage systems.
– Clean water tanks if they have not been used for 48 h; flush the
water system connected to a water supply if water has not been
drawn for 5 days.
– Store raw meat and fish in suitable containers in the refrigerator,
so that it is not in contact with or drip onto other food.
– Two-star frozen-food compartments are suitable for storing
prefrozen food, storing or making icecream and making ice cubes.
– One-, two- and three-star compartments are not suitable for the
freezing of fresh food.
– If the refrigerating appliance is left empty for long periods, switch
off, defrost, clean, dry, and leave the door open to prevent mould
developing within the appliance.
26. The temperature of two star section (sections) or compartment
(compartments) which have two star symbol ( ) is slightly higher
than other freezer compartment (compartments).
Installation
• This appliance should only be transported by two or more people holding the appliance securely.
• Install the appliance on a firm and level floor.
• Do not install the appliance in a damp and dusty place. Do nit install or store the appliance in any
outdoor area, or any area that is subject to weathering conditions such as direct sunlight, wind, rain, or
temperatures below freezing.
• Do not place the appliance in direct sunlight or expose it to the heat from heating appliances such as
stoves or heaters.
• Be careful not to expose the rear of the appliance when installing.
• Install the appliance in a place where it is easy to unplug the power plug of the appliance.
• Be careful not to let the appliance door fall during assembly or disassembly.
• Be careful not to pinch, crush, or damage the power cable during assembly or disassembly of the
appliance door.
• Be careful not to point the power plug up or let the appliance lean against the power plug.
Simple_RS4000D_DA68-04820B-00_EN.indd 6Simple_RS4000D_DA68-04820B-00_EN.indd 6 2024-07-18 3:07:332024-07-18 3:07:33
7Safety information
English
• Do not connect a plug adapter or other accessories to the power plug.
• Do not modify or extend the power cable.
• Ensure that the outlet socker is properly grounded, and that the earth pin on the power cord is not
damaged or removed from the power plug. Fore more details on grounding, inquire at the Samsung
Electronics service center.
• This appliance is equipped with a power cord having an equipment-grounding conductro and a
grounding power plug. The power plug must be plugged into an appropriate outlet socket that is
installed and grounded in accordance with all local codes and ordinances.
• Never start up an appliance showing any signs of damage. If in doubt, consult your dealer.
• Do no plug the appliance into a multi socket adapter which does not have a power cable (mounted).
• The appliance should be connected to a dedicated power line which is separetely fused.
• Do not use a multi socker outlet which is not properly grounded (portable). In case of using a properly-
gounded multi socket outlet (portable), use the multi socket outlet with the current capacity of the
power cord rating or higher and use the multi socker outlet only for the appliance.
• Dispose of all packaging materials (such as plastick bags and styroform) away from children. The
packaging materials can cause suffocation.
Operation
CAUTION
To reduce the risk of minor injury to persons, malfunction, or damage to the product or preperty when
using this product, follow basic precaution, including the folowing:
• Be careful of nearby children when you open or close the appliance door, The door may bump the child
and cause injury.
• Avoid the danger of children getting trapped inside the appliance. A child trapped inside the appliance
can cause suffocation.Do not touch frozen food or the metal parts in the freezer comparment with wet
or damp hands. It may cause frostbite.
• Do not place glass containers, bottles or cans (especially those containing carbonated drinks) in the
freezer compartment, shelves or ice bin that will be exposed to temperatures below freezing,
• The tempered glass on the front side of the applicance door or the selves can be damaged by an impact.
If it is broken. Do not touch it with hands.
• Do not hang from the appliance doors, storage room, shelf or climb up into it.
• Do not store an excessive amount of water bottles or containers for side dishes on the door baskets.
• Do not open or close the appliance door with excessive force.
• If the hinge of the appliance door is damaged or operates improperly, stop using the appliance and
contact an authorized service centre.
• Prevent animals from nibbling on the power cable or water hose.
• Never eat frozen foods immediately after they have been taken out in the freezer compartment.
• Make sure not to get a hand or foot stuck upon opening or closing the appliance door or door in door.
Maintenance
• Do not clean glass shelves or covers with warm water when they are cold. They my shatter if exposed to
sudden temperature changes.
• Do not insert the shelves upside down. The shelves may fall.
• To remove frost from the appliance, contact the Samsung Electronics service center.
• Dispose of the ice inside the ice bin in the freezer compartment during an extended power outage.
Simple_RS4000D_DA68-04820B-00_EN.indd 7Simple_RS4000D_DA68-04820B-00_EN.indd 7 2024-07-18 3:07:332024-07-18 3:07:33
Installation8
English
Installation
Refrigerator at a glance
The actual refrigerator and provided component parts of your refrigerator may differ from the illustrations
in this manual, depending on the model and the country.
01
03
07
04
05
06
A
02
01 Freezer shelves
02 Multipurpose freezer bin
03 Dried food and meat storage drawer
04 Fridge bin
05 Fridge shelves
06 Vegetable drawer
07 Water tank *
A. Freezer
* Applicable models only
NOTE
The design of the egg container may differ with the model.
CAUTION
For normal models, do not change the position of the freezer shelves. Freezer shelves have different
lengths, and if you change the position, you may damage the product when closing the door.
Simple_RS4000D_DA68-04820B-00_EN.indd 8Simple_RS4000D_DA68-04820B-00_EN.indd 8 2024-07-18 3:07:332024-07-18 3:07:33
9Installation
English
Clearance
See the following figures and tables for installation space requirements.
A
B
D
C
Depth “A” 654
Width “B” 912
Height “C” 1744
Overall Height “D” 1780
(unit: mm)
01
02 03
05
06
07
08
09
04
01 more than 50 mm recommended
02 165°
03 170°
04 564 mm
05 1730 mm
06 548 mm
07 912 mm
08 30 mm (without handle)
09 1103 mm
NOTE
The measurements in the above table may differ,
depending on the measuring method.
Simple_RS4000D_DA68-04820B-00_EN.indd 9Simple_RS4000D_DA68-04820B-00_EN.indd 9 2024-07-18 3:07:332024-07-18 3:07:33
Installation10
English
Step-by-step installation
STEP 1 Door removal for entrance
If the refrigerator cannot pass through the
entrance due to its size, follow these instructions:
Tools required (not provided)
These tools are used for removing the doors.
Phillips screwdriver Flat-head screwdriver
Socket spanner
(10 mm)
Allen spanner (5 mm)
Detach the doors
CAUTION
The door may fall off or over and damage itself
during any of these steps. To prevent an accident,
use extreme caution when performing these steps.
A
A
1. Use a Phillips screwdriver to unscrew the hinge
covers (A) on the top of each door.
2. Open the doors to loosen the hinges and
remove the hinge covers. Once the covers are
removed, close the doors.
3. Disconnect the electrical harness.
4. Disconnect the two wire connectors on the left
door. The position of the connectors differs with
the model.
CAUTION
• Do not remove both doors simultaneously.
Make sure to remove one door at a time.
Otherwise, any of the doors may fall and cause
physical injury.
• Make sure the refrigerator is off before
disconnecting the connectors.
5. Gently lift the clamp.
NOTE
To prevent damage to the clamp or injuries, do not
lift the clamp forcefully.
Simple_RS4000D_DA68-04820B-00_EN.indd 10Simple_RS4000D_DA68-04820B-00_EN.indd 10 2024-07-18 3:07:342024-07-18 3:07:34
11Installation
English
6. Pull the clamp to remove.
7. Open the door by 90 degrees. While holding the
door, remove the hinge.
CAUTION
If you remove the hinge without holding the door,
the door may fall and cause injury.
Reattach the doors
CAUTION
• Before reattaching the doors, make sure all the
electrical connectors are properly connected.
• The freezer door must be reattached before the
fridge door.
• Take care when removing the door to ensure
that it does not fall on you.
• Be careful not to scratch.
1. Hold the freezer door and hook to the hinge at
the bottom of the refrigerator.
2. Put the hinge into its position, and then insert it
into the hole on the door.
3. Insert the clamp in the arrow direction.
4. Press the clamp as shown.
Simple_RS4000D_DA68-04820B-00_EN.indd 11Simple_RS4000D_DA68-04820B-00_EN.indd 11 2024-07-18 3:07:352024-07-18 3:07:35
Installation12
English
5. Connect the electrical harness.
6. Connect the wire connectors.
CAUTION
Make sure the wire connectors are connected
properly. Otherwise, the display will not operate.
7. Insert the hinge covers with the front sides
first, and then tighten the screws. Use a Phillips
screwdriver for this step.
STEP 2 Adjust the levelling feet
CAUTION
• The refrigerator must be levelled on a flat, solid
floor. Failing to do so can cause damage to the
refrigerator or physical injury.
• Levelling must be performed with an empty
refrigerator. Make sure no food items remain
inside the refrigerator.
• For safety reasons, adjust the front side a little
higher than the rear side.
The refrigerator can be levelled using the front legs
that have a special screw (leveller) for levelling
purposes. Use a flat-head screwdriver for levelling.
To adjust the height of the freezer side:
Insert a flat-head screwdriver into the leveller
of the freezer-side front leg. Turn the leveller
clockwise to raise, or turn it counter clockwise to
lower.
To adjust the height of the fridge side:
Insert a flat-head screwdriver into the leveller
of the fridge-side front leg. Turn the leveller
clockwise to raise, or turn it counter clockwise to
lower.
Simple_RS4000D_DA68-04820B-00_EN.indd 12Simple_RS4000D_DA68-04820B-00_EN.indd 12 2024-07-18 3:07:362024-07-18 3:07:36
13Installation
English
STEP 3 Adjust the door height as well as the
door gap
To adjust the height of a door
The height of a door can be adjusted using the
clamp nut and the height nut on the front bottom
of each door.
B
A
1. Open the door to adjust, and locate the two nuts
(A) and (B) on the front bottom of the door.
A
2. With a 19 mm spanner (provided), turn the
clamp nut (A) clockwise to loosen. Then, open
the door, and do the following inside the door.
- To raise the door, turn the height nut (B)
counter clockwise.
- To lower the door, turn the height nut (B)
clockwise.
A
3. When complete, tighten the clamp nut (A) by
turning it counter clockwise.
STEP 4 Spacing (applicable models only)
1. Open the door and locate the provided spacer.
2. Unpack the spacer and attach it to the rear of
the refrigerator as shown. It helps ventilate air
to the rear wall and save power consumption.
STEP 5 Flooring
Adjusting the height with the height lever
(applicable models only)
• The surface to install the refrigerator must
support a fully loaded refrigerator.
• To protect the floor, put a large piece of
cardboard on each leg of the refrigerator.
• Once the refrigerator is in its final position, do
not move it unless necessary to protect the
floor. If you have to, use a thick paper or cloth
such as old carpets along the movement path.
NOTE
If the refrigerator cannot pass through the
entrance due to its size, see the STEP 1 Door
removal for entrance section in the Installation
chapter.
Simple_RS4000D_DA68-04820B-00_EN.indd 13Simple_RS4000D_DA68-04820B-00_EN.indd 13 2024-07-18 3:07:362024-07-18 3:07:36
Maintenance14
English
Maintenance
Cleaning
Interior and exterior
WARNING
• Do not use benzene, thinner, home/car
detergent, or Clorox™ to clean the refrigerator.
They may damage the surface of the
refrigerator and cause a fire.
• Do not spray water onto the refrigerator. This
may cause electric shock.
Regularly use a dry cloth to remove all foreign
substances such as dust or water from the power
plug terminals and contact points.
1. Unplug the power cord.
2. Use a moistened, soft, lint-free cloth or paper
towel to clean the refrigerator’s interior and
exterior.
3. When done, use a dry cloth or paper towel to
dry well.
4. Plug in the power cord.
Rubber seals
If the rubber seals of a door become dirty, the door
may not close properly and reducing refrigerator
performance and efficiency. Use a mild detergent
and damp cloth to clean the rubber seals. Then, dry
well with a cloth.
Rear panel
To keep cords and exposed parts of the rear panel
free of dirt, vacuum the panel once or twice a year.
CAUTION
Do not remove the rear panel cover. Electric shock
may occur.
LED Lamps
To replace the lamps of the refrigerator, contact a
local Samsung service center.
WARNING
The lamps are not user-serviceable. Do not
attempt to replace a lamp yourself. This can cause
electric shock.
Lamp (Light Source)
This product contains a light source of energy
efficiency class <G>.
The lamp(s) and/or control gear(s) are not user-
serviceable. To replace the lamp(s) and/or control
gear(s) in the product, contact a local Samsung
service centre.
For detailed instructions on replacing lamp(s) or
control gear(s) in your product, visit the Samsung
website (http://www.samsung.com), go to Support
> Support home, and then enter the model name.
For detailed instructions on dismantling
lamp(s) and/or control gear(s), simply follow the
replacement instruction reached as described
above.
Simple_RS4000D_DA68-04820B-00_EN.indd 14Simple_RS4000D_DA68-04820B-00_EN.indd 14 2024-07-18 3:07:372024-07-18 3:07:37
15Appendix
English
Appendix
Safety Instruction
• For the most efficient use of energy, please keep the all inner fittings such as baskets, drawers, shelves
and ice cube tray on the position supplied by manufacturer.
• This refrigerating appliance is not intended to be used as a built-in appliance.
Install Instruction
For refrigerating appliances with climate class
Depending on the climate class, This refrigerating appliance is intended to be used at ambient
temperatures range as specified following table.
The climate class can be found on the rating plate. The product may not operate properly at temperatures
outside of the specific range.
You can find climate class on label inside of your refrigerator
Effective temperature range
The refrigerator is designed to operate normally in the temperature range specified by its class rating.
Class Symbol
Ambient Temperature range (°C)
IEC 62552 (ISO 15502) ISO 8561
Extended Temperate SN +10 to +32 +10 to +32
Temperate N +16 to +32 +16 to +32
Subtropical ST +16 to +38 +18 to +38
Tropical T +16 to +43 +18 to +43
NOTE
The cooling performance and power consumption of the refrigerator may be affected by the ambient
temperature, the door-opening frequency, and the location of the refrigerator. We recommend adjusting
the temperature settings as appropriate.
Temperature Instruction
Recommended Temperature
The optimal temperature setting for food storage:
• Fridge: 3 °C
• Freezer: -19 °C
NOTE
The optimal temperature setting of each compartment depends on the ambient temperature. Above
optimal temperature is based on the ambient temperature of 25 °C.
Simple_RS4000D_DA68-04820B-00_EN.indd 15Simple_RS4000D_DA68-04820B-00_EN.indd 15 2024-07-18 3:07:372024-07-18 3:07:37
Appendix16
English
Power Cool
Power Cool speeds up the cooling process at maximum fan speed. The fridge keeps running at full speed
for two and a half hours and then returns to the previous temperature.
Power Freeze
Power Freeze speeds up the freezing process at maximum fan speed. The freezer keeps running at full
speed for 50 hours and then returns to the previous temperature. To freeze large amounts of food, activate
Power Freeze for at least 20 hours before putting food in the freezer.
NOTE
When you use this function the energy consumption of the refrigerator will increase. Remember to turn it
off when you don’t need it and return the freezer to your original temperature setting.
How to store for best preservation (applicable models only)
Cover foods to retain moisture and prevent them from picking up odors from other foods. A large pot of
food like soup or stew should be divided into small portions and put in shallow containers before being
refrigerated. A large cut of meat or whole poultry should be divided into smaller pieces or placed in shallow
containers before refrigerating.
Placement of Foods
Shelves Shelves should be adjustable to accommodate a variety of packages.
Specialized compartment
(applicable models only)
Sealed crisper drawers provide an optimal storage environment for fruits
and vegetables. Vegetables require higher humidity conditions while fruits
require lower humidity conditions.
Crispers are equipped with controls devices to control the humidity level.
(*Depending on model and options) An adjustable temperature meat
drawer maximizes the storage time of meats and cheeses.
Stored on the door
Don’t store perishable foods in the door. Eggs should be stored in the
carton on a shelf. The temperature of the storage bins in the door fluctuate
more than the temperature in the cabinet. Keep the door closed as much
as possible.
Freezer Compartment
You can store frozen food, make ice cubes and freeze fresh food in the
freezer compartment.
NOTE
Freeze fresh, undamaged food only. Keep food which is to be frozen away from food which is already frozen.
To prevent food from losing its flavour or drying out, place in airtight containers.
Simple_RS4000D_DA68-04820B-00_EN.indd 16Simple_RS4000D_DA68-04820B-00_EN.indd 16 2024-07-18 3:07:372024-07-18 3:07:37
17Appendix
English
Refrigerator & Freezer Storage Chart
The freshness longevity depends on temperature and exposure to moisture. Since product dates aren’t a
guide for safe use of a product, consult this chart and follow these tips.
Product Refrigerator Freezer
Milk products
Milk 1 week 1 month
Butter 2 weeks 12 months
Cream cheese 2 weeks Not recommended
Meat
Fresh roasts, steaks, chops 3-4 days 2-3 months
Sausage, Raw from pork, beef, turkey 1-2 days 1-2 months
Poultry / Eggs
Fresh poultry 2 days 6-8 months
Eggs, Fresh in shell 2-4 weeks Not recommended
Fish / Seafood
Fresh fish 1-2 days 3-6 months
Dried or pickled fish 3-4 weeks -
Fruits
Apples 1 month -
Other fresh fruit 3-5 days 9-12 months
Vegetables
Asparagus 2-3 days -
Broccoli, Brussels sprouts, green peas,
mushrooms
3-5 days -
Cabbage, cauliflower, celery,
cucumbers, lettuce
1 week -
Carrots, beets, radishes 2 weeks -
Information for model and ordering spare parts
Model information
To access energy labelling information about this product on the European Product Registry for Energy
Labelling (EPREL), scan QR-Code on the energy label.
You can find QR-Code on the energy label in your product box.
Part information
• The minimum period during which spare parts, necessary for the repair of the appliance, are available
- 7 Years thermostats, temperature sensors, printed circuit boards and light sources, door handles,
door hinges, trays, baskets (boxes or drawers)
- 10 Years door gaskets
• The minimum duration of the guarantee of the refrigerating appliance offered by the manufacturer 24
Months.
• Relevant information for ordering spare parts, directly or through other channels provided by the
manufacturer, importer or authorized representative
• You can find professional repair information on http://samsung.com/support.
You can find user servicing manual on http://samsung.com/support.
Simple_RS4000D_DA68-04820B-00_EN.indd 17Simple_RS4000D_DA68-04820B-00_EN.indd 17 2024-07-18 3:07:372024-07-18 3:07:37
Memo
Simple_RS4000D_DA68-04820B-00_EN.indd 18Simple_RS4000D_DA68-04820B-00_EN.indd 18 2024-07-18 3:07:372024-07-18 3:07:37
Memo
Simple_RS4000D_DA68-04820B-00_EN.indd 19Simple_RS4000D_DA68-04820B-00_EN.indd 19 2024-07-18 3:07:372024-07-18 3:07:37
NOTE (For Wi-Fi models only)
Hereby, Samsung declares that this radio equipment is in compliance with Directive 2014/53/EU and with
the relevant statutory requirements in the UK.
The full text of the EU declaration of conformity and the UK declaration of conformity is available at the
following internet address: The official Declaration of conformity may be found at http://www.samsung.
com, go to Support > Search Product Support and enter the model name.
Frequency range Transmitter power (Max)
Wi-Fi 2412 - 2472 MHz 20 dBm
Bluetooth 2402 - 2480 MHz 20 dBm
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG
customer care centre.
Country Contact Center Web Site
UK 0333 000 0333 www.samsung.com/uk/support
IRELAND (EIRE) 0818 717100 www.samsung.com/ie/support
DA68-04820B-00
Simple_RS4000D_DA68-04820B-00_EN.indd 20Simple_RS4000D_DA68-04820B-00_EN.indd 20 2024-07-18 3:07:372024-07-18 3:07:37
