BABY HIGH CHAIR
AD10004
USER’S MANUAL
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
02
Before You Start
General Warnings:
Danger! Keep all small parts and packaging materials for this product away from
babies and children, otherwise they may pose a choking hazard.
The product must be installed and used under the supervision of an adult.
Read through each step carefully and follow the proper order.
Remove all Packaging, separate and count all parts and hardware before
installation.
Please ensure that all parts are correctly installed, incorrect installation can lead to
a danger.
We recommend that, where possible, all items are assembled near the area in
which they will be placed in use, to avoid moving the product unnecessarily once
assembled.
Ensure a secure surface during installation, and place the product always on a flat,
steady and stable surface.
Please read all instructions carefully and keep it for future reference.
03
1. Anti-slide pillar (PICTURE 1, PICTURE 2)
Insert Anti-slide pillar into back of the tray. The Anti-slide pillar can be used
in the baby chair to prevent the baby sliding down the chair.
PARTS LIST
INSTALLATION INSTRUCTIONS
Tray
Anti-slide pillarBaby Chair Seat cover
PICTURE 1 PICTURE 2
4. Seat lift adjustment (PICTURE 5,PICTURE 6)
Pull the back of the chair up to the appropriate position,and you also can
pinch the button on the back to adjust the height.
2. Seat Cover (PICTURE 3)
Insert the seat cover to the position As shown in PICTURE 3.
3. Open the chair (PICTURE 4)
As shown in PICTURE 4,press the folding handle and open the chair along
the direction.
Seat cover
Folding
handle
PICTURE 3 PICTURE 4
04
Lift adjustment button
PICTURE 5 PICTURE 6
05
5. Install and adjust the tray (PICTURE 7)
Move the tray along the dotted line in PICTURE 7.When the "click" can be
heard, it means that the tray is installed in the right place. The tray can be
adjusted in three positions. Please make sure the tray can not be moved
when child sits on the chair.
6. Footrest adjustment button (PICTURE 8)
Press the Angle/Height adjustment button at the left and right side, then can
adjust the angle and height.
PICTURE 7 PICTURE8
Tray adjustment
positions
Footrest Angle
adjustment
button
Footrest height
adjustment
button
PICTURE 9 PICTURE 10
WARNING
06
7. Adjust backrest (PICTURE 9)
4 shifts adjustment:pull the adjuster to regulate the backrest angle.
8. Fold the chair (PICTURE 10)
Hold the lifting button under the seat, adjust the seat height to the minimum
height, then press the folding handle to fold the chair.
Press the button at the bottom of the tray, remove it and put it at the back
of the chair foot as shown in PICTURE 10.
Maintenance
In order to guard against damage when baby using,the adult should do
inspection and maintenance regularly.
Safety and integral effect will be influenced if using non-original
components and parts.
Use a damp cloth or a cloth with a neutral detergent to clean the chair.
Do not use harsh chemicals, cleaning solvents, or strong detergents to clean
the chair.
Fitting your child into the chair
1.Let your child sit in the chair after fixing.
2.Fasten the buckle.
3.Adjust the belt to the desired length.
4.Install the adjustable tray.
● NEVER LEAVE YOUR CHILD UNATTENDED.
● ALWAYS USE THE RESTRAINT SYSTEM AND SECURE WITH THE CHAIR
ATTACHMENT SYSTEMS.
● ALWAYS CHECK THE SECURITY AND STABILITY OF
THE CHAIR MOUNTED SEAT BEFORE USE.
● DO NOT USE IF ANY PART IS BROKEN OR MISSING.
1. Never leave the child unattended.
2. Harness must be always fastened properly when child is seated.
3. FALL HAZARD: Children suffer severe head injuries including skull
fractures when falling from high chairs. Falls can happen suddenly if child is
not restrained properly. Always use restraints, and adjust to fit snugly.
4. Do not use the product unless all components are correctly fitted and
adjusted.
5. Be aware of the risk of open fires and other sources of strong heat in the
vicinity of the chair.
6. Be aware of the risk of tilting when your child can push its feet against a
table or any other structure.
7. Tray max weight capacity is 6.6 lbs (3 kg).
8. This product is intended for children able to sit up unaided and up to 3
years or a maximum weight of 55 lbs (25 kg).
9. Tray is not designed to hold child in chair.
10. Stay near and watch child during use.
11. The child should be secured in the high chair at all times by the
restraining system, both in the reclined and upright positions.
12. It is recommended that the high chair be used in the upright position
only by children capable of sitting upright unassisted.
Additional information:
1.Please do not use this chair until the child can sit up unaided;
2.Please do not use this chair any longer if any part is broken, torn or
missing;
3.Please examine this chair regularly;
4.Please use the moistened cloth to clean, don’t put any parts into washing
machine to clean;
5.Please keep the children away when unfolding and folding the chair to
avoid injury.
07
Please give us a chance to make it right and do better !
Contact our friendly customer service department for help first.
Replacements for missing or damaged parts will be shipped ASAP !
Contact Us !
Do NOT return this item.
