Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Product Introducon .............................................................................................................. 1
1.2 Key Funcon .......................................................................................................................... 1
1.3 System Requirement .............................................................................................................. 2
Chapter 2 Device Acvaon and Accessing ................................................................................. 3
2.1 Acvate Device ...................................................................................................................... 3
2.1.1 Acvate Device via Web Browser .................................................................................. 3
2.1.2 Acvate via SADP .......................................................................................................... 4
2.2 Access Device via Web Browser ............................................................................................. 5
2.2.1 Plug-in
Installaon ........................................................................................................ 5
2.2.2 Admin Password Recovery ............................................................................................ 6
2.2.3 Illegal Login Lock ........................................................................................................... 7
Chapter 3 Smart
Funcon ........................................................................................................... 8
3.1 Allocate VCA Resource ........................................................................................................... 8
3.2 General
Sengs ..................................................................................................................... 8
3.2.1 Set Camera Info ............................................................................................................. 9
3.2.2 Metadata ....................................................................................................................... 9
3.3 Road
Trac ............................................................................................................................ 9
3.3.1 Set Vehicle Detecon Rule ............................................................................................ 9
3.3.2 Picture Sengs ........................................................................................................... 11
3.3.3 Set Armed License Plates ............................................................................................ 12
3.3.4 Advanced Parameters ................................................................................................. 12
3.4 Face Capture ........................................................................................................................ 12
3.4.1 Set Auto Face Capture Rule ......................................................................................... 12
3.4.2 Operate Manual Face Capture .................................................................................... 14
3.4.3 Overlay and Capture ................................................................................................... 15
Network Speed Dome User Manual
v
3.4.4 Face Recognion Algorithm Parameters ..................................................................... 15
3.5 Face Comparison .................................................................................................................. 17
3.5.1 Set Face Picture Library ............................................................................................... 17
3.5.2 Set Face Picture Comparison ...................................................................................... 19
3.5.3 View Face Comparison Result ..................................................................................... 20
3.6 Capture Target with Feature ................................................................................................ 20
3.6.1 Set
Detecon Rule ...................................................................................................... 20
3.6.2 Overlay and Capture ................................................................................................... 21
3.6.3 Advanced Parameters ................................................................................................. 21
3.7 Person Arming ...................................................................................................................... 23
3.7.1 Device Auto Person Arming ........................................................................................ 24
3.7.2 Manual Person Arming ............................................................................................... 26
3.7.3 Capture
Sengs .......................................................................................................... 26
3.8 Intelligent
Trac Event (ITS) ................................................................................................ 29
3.8.1 Basic Sengs .............................................................................................................. 29
3.8.2 Vehicle Detecon ........................................................................................................ 30
3.8.3 ITS Linkage and Alarm ................................................................................................. 32
3.8.4 Vehicle Arming ............................................................................................................ 33
3.8.5 Advanced
Sengs ....................................................................................................... 35
3.9 Display Alarm ....................................................................................................................... 36
Chapter 4 PTZ ........................................................................................................................... 38
4.1 PTZ Control .......................................................................................................................... 38
4.2 Set Preset ............................................................................................................................. 40
4.2.1 Special Presets ............................................................................................................ 40
4.3 Set Patrol Scan ..................................................................................................................... 41
4.3.1 Set One-Touch Patrol .................................................................................................. 42
4.4 Set
Paern Scan ................................................................................................................... 42
4.5 Set Limit ............................................................................................................................... 43
Network Speed Dome User Manual
vi
4.6 Set Home Posion ................................................................................................................ 44
4.7 Set Park Acon ..................................................................................................................... 44
4.7.1 Set One-Touch Park ..................................................................................................... 44
4.8 Set Scheduled Tasks ............................................................................................................. 45
4.9 Set Power
O Memory ........................................................................................................ 45
4.10 Set PTZ Priority ................................................................................................................... 45
4.11 Set Privacy Mask ................................................................................................................ 46
4.12 Set Rapid Focus .................................................................................................................. 46
4.13 GPS Calibraon .................................................................................................................. 47
4.13.1 Set GPS Calibraon ................................................................................................... 47
4.13.2 Verify Calibraon ...................................................................................................... 48
4.14 Set Device Posion ............................................................................................................. 48
4.14.1 Set Manual Compass ................................................................................................. 49
Chapter 5 Live View .................................................................................................................. 50
5.1 Live View Parameters ........................................................................................................... 50
5.1.1 Start and Stop Live View ............................................................................................. 50
5.1.2 Aspect
Rao ................................................................................................................ 50
5.1.3 Live View Stream Type ................................................................................................ 50
5.1.4 Select the Third-Party Plug-in ..................................................................................... 50
5.1.5 Start Digital Zoom ....................................................................................................... 51
5.1.6 Conduct Regional Focus .............................................................................................. 51
5.1.7 Conduct Regional Exposure ........................................................................................ 51
5.1.8 Count Pixel .................................................................................................................. 51
5.1.9 Light ............................................................................................................................ 52
5.1.10 Operate Wiper .......................................................................................................... 52
5.1.11 Lens
Inializaon ...................................................................................................... 52
5.1.12 Track Manually .......................................................................................................... 52
5.1.13 Conduct 3D
Posioning ............................................................................................. 53
Network Speed Dome User Manual
vii
5.2 Set Transmission Parameters ............................................................................................... 53
Chapter 6 Video and Audio ....................................................................................................... 55
6.1 Video
Sengs ...................................................................................................................... 55
6.1.1 Stream Type ................................................................................................................ 55
6.1.2 Video Type .................................................................................................................. 55
6.1.3 Resoluon ................................................................................................................... 55
6.1.4 Bitrate Type and Max. Bitrate ..................................................................................... 56
6.1.5 Video Quality .............................................................................................................. 56
6.1.6 Frame Rate .................................................................................................................. 56
6.1.7 Video Encoding ........................................................................................................... 56
6.1.8 Prole .......................................................................................................................... 57
6.1.9 I-Frame Interval ........................................................................................................... 58
6.1.10 SVC ............................................................................................................................ 58
6.1.11 Smoothing ................................................................................................................. 58
6.2 Audio Sengs ...................................................................................................................... 58
6.2.1 Audio Input ................................................................................................................. 58
6.2.2 Audio Output .............................................................................................................. 59
6.2.3 Environmental Noise Filter .......................................................................................... 59
6.3 Two-way Audio .................................................................................................................... 59
6.4 ROI ....................................................................................................................................... 60
6.4.1 Set ROI ........................................................................................................................ 60
6.5 Target Cropping .................................................................................................................... 60
6.6 Display Info. on Stream ........................................................................................................ 61
6.7 Display
Sengs .................................................................................................................... 61
6.7.1 Scene Mode ................................................................................................................ 61
6.7.2 Image Parameters Switch ............................................................................................ 65
6.7.3 Mirror .......................................................................................................................... 66
6.7.4 Video Standard ........................................................................................................... 66
Network Speed Dome User Manual
viii
6.8 OSD ...................................................................................................................................... 66
Chapter 7 Video Recording and Picture Capture ........................................................................ 67
7.1 Storage
Sengs ................................................................................................................... 67
7.1.1 Memory Card .............................................................................................................. 67
7.1.2 Set FTP ........................................................................................................................ 69
7.1.3 Set NAS ....................................................................................................................... 70
7.1.4 eMMC Protecon ........................................................................................................ 71
7.1.5 Set Cloud Storage ........................................................................................................ 71
7.2 Video Recording ................................................................................................................... 72
7.2.1 Record Automacally .................................................................................................. 72
7.2.2 Record Manually ......................................................................................................... 74
7.2.3 Playback and Download Video .................................................................................... 74
7.3 Capture
Conguraon .......................................................................................................... 74
7.3.1 Capture
Automacally ................................................................................................ 75
7.3.2 Capture Manually ........................................................................................................ 75
7.3.3 View and Download Picture ........................................................................................ 76
Chapter 8 Event and Alarm ....................................................................................................... 77
8.1 Basic Event ........................................................................................................................... 77
8.1.1 Set
Moon Detecon .................................................................................................. 77
8.1.2 Set Video Tampering Alarm ........................................................................................ 79
8.1.3 Set Alarm Input ........................................................................................................... 80
8.1.4 Set
Excepon Alarm .................................................................................................... 81
8.1.5 Detect Audio
Excepon ............................................................................................... 81
8.1.6 Set Vandal-proof Alarm ............................................................................................... 82
8.2 Smart Event .......................................................................................................................... 83
8.2.1 Set Intrusion
Detecon ............................................................................................... 83
8.2.2 Set Line Crossing Detecon ......................................................................................... 84
8.2.3 Set Region Entrance
Detecon ................................................................................... 86
Network Speed Dome User Manual
ix
8.2.4 Set Region Exing Detecon ....................................................................................... 87
8.2.5 Set Object Removal Detecon .................................................................................... 89
8.2.6 Set
Unaended Baggage Detecon ............................................................................ 91
8.2.7 Set Tracking Parameters .............................................................................................. 92
8.2.8 Overlay and Capture ................................................................................................... 93
Chapter 9 Arming Schedule and Alarm Linkage ......................................................................... 94
9.1 Set Arming Schedule ............................................................................................................ 94
9.2 Linkage Method Sengs ...................................................................................................... 94
9.2.1 Trigger Alarm Output .................................................................................................. 95
9.2.2 FTP/NAS/Memory Card Uploading ............................................................................. 96
9.2.3 Send Email .................................................................................................................. 96
9.2.4 Nofy Surveillance Center .......................................................................................... 97
9.2.5 Smart Tracking ............................................................................................................ 97
9.2.6 Trigger Recording ........................................................................................................ 97
9.2.7 Flashing Light .............................................................................................................. 97
9.2.8 Audible Warning ......................................................................................................... 98
9.2.9 Alarm Server ............................................................................................................... 99
Chapter 10 Network
Sengs .................................................................................................. 100
10.1 TCP/IP ............................................................................................................................... 100
10.2 Port Mapping ................................................................................................................... 101
10.2.1 Set Auto Port Mapping ............................................................................................ 101
10.2.2 Set Manual Port Mapping ....................................................................................... 102
10.2.3 Set Port Mapping on Router ................................................................................... 102
10.3 SNMP ............................................................................................................................... 103
10.4 Access to Device via Domain Name ................................................................................. 104
10.5 Access to Device via PPPoE Dial Up
Connecon .............................................................. 104
10.6 Accessing via Mobile Client .............................................................................................. 105
10.6.1 Enable Hik-Connect Service on Camera .................................................................. 105
Network Speed Dome User Manual
x
10.6.2 Set Up Hik-Connect ................................................................................................. 106
10.6.3 Add Camera to Hik-Connect .................................................................................... 107
10.7 HTTP(S) ............................................................................................................................ 107
10.8
Mulcast .......................................................................................................................... 108
10.8.1 Mulcast Discovery ................................................................................................. 108
10.9 RTSP ................................................................................................................................. 109
10.10 Set SRTP ......................................................................................................................... 109
10.10.1 Mulcast ............................................................................................................... 110
10.10.2 Mulcast Discovery ............................................................................................... 110
10.11 Bonjour .......................................................................................................................... 110
10.12 WebSocket(s) ................................................................................................................. 111
10.13 TCP Acceleraon ............................................................................................................ 111
10.14
Trac Shaping ................................................................................................................ 111
10.15 Set OTAP ......................................................................................................................... 111
10.16 Set ISUP .......................................................................................................................... 112
10.17 Set Open Network Video Interface ................................................................................ 112
10.18 Set SDK Service .............................................................................................................. 112
Chapter 11 System and Security .............................................................................................. 114
11.1 View Device
Informaon .................................................................................................. 114
11.2 Reboot ............................................................................................................................. 114
11.3 Upgrade ........................................................................................................................... 114
11.4 Restore and Default ......................................................................................................... 114
11.5 Search and Manage Log ................................................................................................... 115
11.6 Import and Export
Conguraon File .............................................................................. 115
11.7 Export Diagnose Informaon ........................................................................................... 115
11.8 Search and Export Data Aware
Informaon .................................................................... 116
11.9 View Open Source Soware License ................................................................................ 116
11.10 Set Live View
Connecon ............................................................................................... 116
Network Speed Dome User Manual
xi
11.11 Time and Date ................................................................................................................ 117
11.11.1 Synchronize Time Manually .................................................................................. 117
11.11.2 Synchronize Time by Satellite ............................................................................... 117
11.11.3 Set NTP Server ...................................................................................................... 117
11.11.4 Set DST .................................................................................................................. 118
11.12 Set RS-485 ...................................................................................................................... 118
11.13 Security .......................................................................................................................... 118
11.13.1 Set IP Address Filter .............................................................................................. 118
11.13.2 Set MAC Address Filter ......................................................................................... 119
11.13.3 Security Audit Log ................................................................................................. 119
11.13.4 Set QoS .................................................................................................................. 120
11.13.5 Set IEEE 802.1X ..................................................................................................... 121
11.13.6 SSH ........................................................................................................................ 121
11.13.7 Control Timeout
Sengs ...................................................................................... 121
11.13.8 Cercate Management ....................................................................................... 122
11.13.9 TLS ......................................................................................................................... 124
11.13.10 User and Account ................................................................................................ 125
Appendix A. Device Command ................................................................................................ 127
Appendix B. Device
Communicaon Matrix ............................................................................ 128
Network Speed Dome User Manual
xii
Chapter 1 Overview
1.1 Product Introducon
The F Series Network Speed Dome is an integraon of HD camera, PTZ moon control module, and
video content analysis algorithms, ideal for remote monitoring.
The device has basic PTZ funcons, such as presets, scans, and target tracking, and smart
funcons, such as Road Trac, Face Capture and Smart Event.
The device is well suited for HD monitoring in various places, such as rivers, forests, roads, railways,
airports, ports, oil
elds, posts, squares, parks, scenic areas, streets, staons, stadiums, residenal
blocks, prisons, libraries, shopping malls, hotels, government buildings, museums, and banks.
1.2 Key
Funcon
The key funcons of the device are as follows. Some smart funcons are mutually exclusive. You
can enable the desired one on VCA Resource page.
Note
Actual funcons may vary for dierent models.
Road Trac
The device captures vehicles on the road and uploads related vehicle informaon, such as license
plates.
License plate
recognion of mulple countries and regions are supported.
Face Capture
The device captures human faces according to set pupil distance or capture threshold and uploads
the pictures to the center.
Face Comparison
The device compares captured faces with pictures in the library, and outputs the result.
Event
The device detects basic events and mulple smart events, such as line crossing detecon,
intrusion detecon, region entrance detecon, region exing detecon, etc.
Vehicle
Detecon
The device detects vehicles in the detecon area, recognizes license plates, captures and saves
pictures, and uploads alarms.
Network Speed Dome User Manual
1
Vehicle Arming
The device detects the armed vehicle (license plates) in the monitoring scene. When the wanted
vehicles are found, the device triggers alarms, and starts tracking and capturing the target. The
real-me target locaon and other related informaon are uploaded during tracking if properly
congured.
Capture Target with Feature
The device captures dierent types of targets, such as faces and human bodies, and extracts
features of the targets.
Person Arming
The device detects the armed face or human body in the monitoring scene. When the wanted
targets are found, the device triggers alarms, and starts tracking and capturing the target. The
real-
me target locaon and other related informaon are uploaded during tracking if properly
congured.
PTZ
The device supports PTZ funcons, such as presets, scans, patrol, smart tracking and power-o
memory.
1.3 System Requirement
Your computer should meet the requirements for vising and operang the product.
Recommended Specicaons
Operang System Microso Windows XP/ Windows 7/ Windows 8/ Windows 10
Mac OS 10.13 or later
CPU Intel® Penum® IV 3.0 GHz or higher
RAM 1 GB or higher
Display 1024 × 768 resoluon or higher
Web Browser Internet Explorer 10 and above version, Apple Safari 12 and above
version, Mozilla Firefox 52 and above version, Google Chrome 57 and
above version.
Network Speed Dome User Manual
2
Chapter 2 Device Acvaon and Accessing
To protect the security and privacy of the user account and data, you should set a login password
to
acvate the device when access the device via network.
Note
Refer to the user manual of the soware client for the detailed informaon about the client
soware acvaon.
2.1 Acvate Device
The device needs to be acvated by seng a strong password before use. This part introduces
acvaon using dierent client tools.
2.1.1
Acvate Device via Web Browser
Use web browser to acvate the device. For the device with the DHCP enabled by default, use
SADP soware or PC client to acvate the device.
Before You Start
Make sure your device and your PC connect to the same LAN.
Steps
1.
Change the IP address of your PC to the same subnet as the device.
The default IP address of the device is 192.168.1.64.
2.
Open a web browser and input the default IP address.
3.
Create and
conrm the admin password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4.
Click OK to complete acvaon and enter Live View page.
5.
Modify IP address of the camera.
1) Enter IP address
modicaon page. Conguraon → Network → TCP/IP
2) Change IP address.
3) Save the
sengs.
Network Speed Dome User Manual
3
2.1.2 Acvate via SADP
SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.
Before You Start
●
Get the SADP
soware from the supplied disk or the ocial website hp://
www.hikvision.com/ , and install the SADP according to the prompts.
●
The device and the PC that runs the SADP tool should belong to the same subnet.
The following steps show how to acvate one device and modify its IP address. For batch acvaon
and IP address modicaon, refer to User Manual of SADP for details.
Steps
1.
Run the SADP soware and search the online devices.
2.
Find and select your device in online device list.
3.
Input new password (admin password) and
conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4.
Click Acvate to start acvaon.
Status of the device becomes Acve aer successful acvaon.
5.
Modify IP address of the device.
1) Select the device.
Network Speed Dome User Manual
4
2) Change the device IP address to the same subnet as your computer by either modifying the IP
address manually or checking Enable DHCP.
3) Input the admin password and click Modify to acvate your IP address modicaon.
2.2 Access Device via Web Browser
Before You Start
Check the system requirement to conrm that the operang computer and web browser meets
the requirements. See
System Requirement .
Steps
1.
Open the web browser.
2.
Input IP address of the device to enter the login interface.
3.
Input user name and password.
Note
Illegal login lock is acvated by default. If admin user performs seven failed password aempts
(ve aempts for user/operator), the IP address is blocked for 30 minutes.
If illegal login lock is not needed, go to Conguraon → System → Security → Security Service
to turn it
o.
4.
Click Login.
5.
Download and install appropriate plug-in for your web browser.
For IE based web browser, webcomponents and QuickTime
TM
are
oponal. For non-IE based web
browser, webcomponents, QuickTime
TM
, VLC and MJEPG are oponal.
2.2.1 Plug-in
Installaon
Certain operaon systems and web browser may restrict the display and operaon of the camera
funcon. You should install plug-in or complete certain sengs to ensure normal display and
operaon. For detailed restricted funcon, refer to the actual device.
Network Speed Dome User Manual
5
Operang System Web Browser Operaon
Windows
●
Internet Explorer 10+
●
Google Chrome 57 and
earlier version
●
Mozilla Firefox 52 and earlier
version
Follow pop-up prompts to
complete plug-in installaon.
●
Google Chrome 57+
●
Mozilla Firefox 52+
Click to download and install
plug-in.
Mac OS
●
Google Chrome 57+
●
Mozilla Firefox 52+
●
Mac Safari 16+
Plug-in installaon is not
required.
Go to Conguraon →
Network → Network Service
→ WebSocket(s) to enable
WebSocket or Websockets for
normal view. Display and
operaon of certain funcons
are restricted. For example,
Playback and Picture are not
available. For detailed
restricted
funcon, refer to the
actual device.
Note
The camera only supports Windows and Mac OS system and do not support Linux system.
2.2.2 Admin Password Recovery
If you forget the admin password, you can reset the password by clicking Forget Password on the
login page
aer compleng the account security sengs.
You can reset the password by seng the security queson or email.
Note
When you need to reset the password, make sure that the device and the PC are on the same
network segment.
Security Queson
You can set the account security during the acvaon. Or you can go to Conguraon → System →
User Management , click Account Security Sengs, select the security queson and input your
answer.
Network Speed Dome User Manual
6
You can click Forget Password and answer the security queson to reset the admin password when
access the device via browser.
Email
You can set the account security during the acvaon. Or you can go to Conguraon → System →
User Management , click Account Security Sengs, input your email address to receive the
vericaon code during the recovering operaon process.
2.2.3 Illegal Login Lock
It helps to improve the security when accessing the device via Internet.
Go to Maintenance and Security → Security → Login Management , and enable Enable Illegal
Login Lock. Illegal Login Aempts and Locking Duraon are congurable.
Illegal Login Aempts
When your login aempts with the wrong password reach the set mes, the device is locked.
Locking Duraon
The device releases the lock aer the seng duraon.
Network Speed Dome User Manual
7
Chapter 3 Smart Funcon
3.1 Allocate VCA Resource
VCA resource oers you opons to enable certain VCA funcons according to actual needs. It helps
allocate more resources to the desired funcons.
Steps
1.
Click VCA on the le tab.
2.
Enable the desired VCA
funcon.
3.
Click Next to nish sengs.
Note
Certain VCA funcons are mutually exclusive.
3.2 General Sengs
Set the general parameters which are related to the smart applicaons.
Go to VCA → Set Applicaon → General Sengs to set the following parameters.
Camera Info.
For camera informaon sengs, refer to Set Camera Info .
FTP
For FTP sengs, refer to Set FTP .
Email
For Email sengs, refer to Set Email .
Alarm Output
For alarm output sengs, refer to Automac Alarm .
Audible Alarm Output
For audible alarm output sengs, refer to Set Audible Alarm Output .
Alarm Server
For alarm server sengs, refer to Alarm Server .
Metadata
For metadata sengs, refer to Metadata .
Network Speed Dome User Manual
8
3.2.1 Set Camera Info
Customize specic informaon for the device. It may help idenfy a certain device when mulple
devices are under management.
Go to VCA → Set Applicaon → General Sengs → Camera Info. to set Camera No. and Camera
Info.
3.2.2 Metadata
Metadata is the raw data that the device collects before algorithm processing. It is oen used for
the third party
integraon.
Go to VCA → Set Applicaon → General Sengs → metadata Sengs to enable metadata
uploading of the desired funcon.
Road Trac
The metadata of the road trac includes the target vehicle/plate license ID, target coordinate,
me, license plate number, moving direcon, etc.
3.3 Road
Trac
The device captures the passing vehicles and uploads the vehicle informaon together with the
captured picture.
Note
●
For certain device models, you need to select Road Trac on VCA Resource page rst.
●
This funcon is only supported by certain device models.
3.3.1 Set Vehicle Detecon Rule
In Vehicle Detecon, the device detects and captures the passing vehicles and the license plates.
The vehicle color, type, and other related
informaon can be recognized automacally.
Before You Start
Go to VCA → Select
Applicaon to select Road Trac, and click Next to enable the funcon.
Steps
1.
Go to VCA → Set Applicaon → Road Trac → Rule .
2.
Check Enable.
3.
Select a
Detecon Scene. Change the Scene Name if required.
The device supports mulple detecon scenes with independent detecon parameters.
4.
Draw lane areas in the scene.
1) Click
to avoid accidental PTZ changing during conguraon.
Network Speed Dome User Manual
9
2) Adjust the pan, lt, and zoom posion to obtain the target scene.
3) Select the Total Number of the Lanes according to the actual lane number you want to
monitor in the scene.
Yellow lane lines and a blue
detecon line are displayed on live image.
4) Click and drag the lane lines or the endpoints to set the
posions according to the actual lane
lines on the road.
5)
Oponal: Click and drag the blue detecon line to adjust the posion. Vehicle detecon is
triggered when target vehicles hit the line.
6) Click Save.
5.
Oponal: Repeat to set other detecon scenes if needed.
6.
Set
detecon parameters.
Country/Region
Select according to the device locaon. License plate rules of the selected country or region
are acvated.
Detecon Mode
The device is able to detect vehicles and license plates. With the detecon mode sengs, the
detecon priority of the vehicle and license plate can be adjusted on demand.
License Plate & Vehicle
The vehicle and license plates are detected simultaneously. The device takes a capture
either when it detects a vehicle or a license plate.
Vehicle Priority
The device takes a capture only when it detects a vehicle.
Filter Duplicated License Plates
The
funcon is used to avoid repeated captures of the same license plate. Set the Time
Interval. During the set interval, the same license plate is only captured once.
7.
Click Save to
nish area sengs.
8.
Set the arming schedule for each detecon scene.
1) Click Arming Schedule and Linkage Method.
2) Select a
detecon scene and draw the me bar in the me table. Dierent scenes are marked
with dierent colors on schedule.
9.
Set Park Time. During the set task period, if you operate the device manually, the scheduled task
will be suspended. When the manual
operaon is over, the device will connue to perform the
scheduled task aer the set park me.
10.
Set linkage method. See Linkage Method Sengs .
11.
Click Save to nish arming schedule and linkage method sengs.
What to do next
Go to Playback → Picture to search and view the captured pictures. When you select File Type as
Vehicle
Detecon, you can search the pictures by license plate No.
Network Speed Dome User Manual
10
3.3.2 Picture Sengs
Captured vehicle pictures are uploaded. Picture size, quality and overlay informaon are
congurable.
Go to VCA → Set Applicaon → Road Trac → Advanced Sengs → Overlay & Capture to start.
Picture Type
Select one or more picture types to upload. Background picture, close-up of license plate or target,
and picture of the vehicle are available.
Picture Quality Vs Picture Size
Both Picture Quality and Picture Size aect the size and quality of pictures for uploading. They
cannot be set at the same me.
Picture Quality
The quality of the uploaded pictures is in accordance with the set value. Higher value means
clearer image. To maintain the quality, the size of the pictures may vary according to the image
complexity.
Picture Size
The size of the uploaded pictures is in accordance with the set value. To maintain the size,
pictures with more complex contents might be less
sasfactory in quality than that with simpler
contents.
Text Overlay
Enable Text Overlay to display the overlaid informaon on every uploaded picture.
Font Color
The font color of overlaid texts.
Background Color
The background color for the overlaid texts.
Text Overlay
Check the desired items to display on the picture. The display sequence is adjustable.
Note
See Set Camera Info to set Device No. and Camera Info.
FTP Picture Name
Go to VCA → Set Applicaon → Road Trac → Advanced Sengs → FTP Host to start.
Default and Custom are available. When Custom is selected, you can choose the
informaon to
form the picture le name.
Network Speed Dome User Manual
11
3.3.3 Set Armed License Plates
You can specify the vehicles you want to arm by adding their license plates to the blocklist or
allowlist.
Steps
1.
Go to VCA → Set
Applicaon → Road Trac → Advanced Sengs → Blocklist & Allowlist .
2.
Click Export All to export license plate list template.
Note
If a list of license plates exists, the exisng list is exported.
3.
Fill in the list.
4.
Click Import, and click
to select a list. Click Import to import the list.
The list shows on the web page.
3.3.4 Advanced Parameters
The version of license plate recognion algorithm is shown.
License Plate Day/Night
The device switches day/night mode according to the brightness of license plates in the scene.
Auto day/night switch should be enabled
rst in Conguraon → Image → Display Sengs →
Day/Night Switch for this funcon to take eect.
3.4 Face Capture
Face capture funcon detects faces and captures pictures. When the grading of the detected face
exceeds an
algorithm-dened value, the device captures the face and triggers linkage acons. Set
up rule and parameters before using the funcon.
Note
●
This funcon is only supported by certain device models.
●
To enable this funcon, you may need to select Face Capture on VCA Resource page. See
Allocate VCA Resource for details.
3.4.1 Set Auto Face Capture Rule
Aer seng the face capture rules and algorithm parameters, the device captures faces and
triggers linkage
acons automacally.
Before You Start
Go to VCA → Select Applicaon to select Face Comparison, and click Next to enable the funcon.
Network Speed Dome User Manual
12
Steps
1.
Go to VCA → Set Applicaon → Face Comparison → Face Recognion → Rule .
2.
Check Enable.
3.
Select a
conguraon mode.
Normal One detecon scene is allowed to set. The device captures face in the scene in set
arming schedule.
See Normal Mode Sengs for details.
Expert The device can patrol among the detecon scenes and capture face images.
Detecon scenes and patrol schedule should be set in advance.
See Expert Mode Sengs for details.
4.
Click Save.
What to do next
Go to Playback → Picture to search and view the captured pictures.
Go to
Applicaon Display → Smart Display → Display Alarm to see currently captured face
pictures.
Normal Mode
Sengs
Steps
1.
Oponal: Click to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
2.
Use PTZ control panel to locate a scene with a face.
3.
Click
, and draw a detecon area on live image.
4.
Input or draw the min. pupil distance and the max. pupil distance.
The Min. Pupil Distance and the Max. Pupil Distance are used to improve
detecon accuracy.
Only targets whose pupil distance are between the maximum distance and the minimum
distance trigger the capture.
Click
and to draw the distance on live image, or input values in the text elds of Min. Pupil
Distance and Max. Pupil Distance.
5.
Click Save.
6.
Set arming schedule. See
Set Arming Schedule .
7.
Set linkage method. See Linkage Method Sengs .
Expert Mode
Sengs
Steps
1.
Oponal: Click to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Network Speed Dome User Manual
13
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
2.
Set detecon scenes and detecon areas.
1) Select a
detecon scene.
2) Adjust the live image to a desired scene. You can use PTZ control
buons to locate a scene
with a face.
3) Click
, and draw a detecon area on live image.
4) Click Save.
5) Repeat above steps to set other
detecon scenes and areas.
3.
Input or draw the min. pupil distance and the max. pupil distance.
The Min. Pupil Distance and the Max. Pupil Distance are used to improve
detecon accuracy.
Only targets whose pupil distance are between the maximum distance and the minimum
distance trigger the capture.
Click
and to draw the distance on live image, or input values in the text elds of Min. Pupil
Distance and Max. Pupil Distance.
4.
Set patrol schedule.
1) Go to VCA → Set
Applicaon → Face Recognion → Auto-Switch Schedule and Linkage
Method .
2) Click Modify.
3) Draw
me bars as desired.
4) Click a me bar and click Set Scene Auto-switch.
5) Edit patrol path and input dwell
me for each detecon scene.
Add
Add a detecon scene to the patrol path.
Adjust the order of the scenes.
Delete the detecon scene.
6) Click OK.
5.
Set linkage method. See
Linkage Method Sengs .
6.
Click Save.
3.4.2 Operate Manual Face Capture
Capture the target face manually in live view image.
Steps
1.
Click Live View.
2.
Click to start manual face capture.
3.
Draw a frame to select the target face in live view image.
The captured picture can be uploaded to the center.
4.
Click the icon again to stop manual face capture.
Network Speed Dome User Manual
14
3.4.3 Overlay and Capture
Choose to congure capture parameters and the informaon you want to display on stream and
picture.
Display VCA Info. on Stream
Display smart
informaon on stream, including the target and rules informaon.
Display Target Info. on Alarm Picture
Overlay the alarm picture with target
informaon.
Target Picture Sengs
You can set the face picture type by selecng Custom, Head Shot, Half-Body Shot, or Full-Body
Shot. If you select Custom, you can dene detailed picture width and height of a picture freely.
If the captured pictures should have the same picture height, check Fixed Picture Height and
input desired picture height.
Face
Beaucaon
Check Face Beaucaon and adjust the beaucaon level as needed.
Note
Face Beaucaon slightly adjusts skin tone and reduces facial noise.
Background Picture Sengs
Comparing to target picture, background picture is the scene image oers extra environmental
informaon. You can set the background picture quality and resoluon.
If the background image need to be uploaded to surveillance center, check Background Upload.
If a small face image need to be uploaded to surveillance center, check Face Picture.
Text Overlay
You can check desired items (Device No., Camera Info. and Capture Time) and adjust their order
to display on captured pictures by
.
See Set Camera Info to set Device No. and Camera Info.
3.4.4 Face
Recognion Algorithm Parameters
It is used to set and opmize the parameters of the algorithm library for face recognion.
Version of Face Capture Algorithm Library
It refers to the current algorithm version, which cannot be edited.
Face Comparison Version
It refers to the current algorithm version, which cannot be edited.
Network Speed Dome User Manual
15
Capture Parameters
Best Shot
The device captures the target picture with the highest score aer seng the parameters.
Capture Threshold
It refers for the quality of face to trigger capture and alarm. Higher value means
beer quality
should be met to trigger capture and alarm.
Capture Times
It refers to the capture
mes a face will be captured during its stay in the detecon area.
Remove Duplicated Faces
This funcon can lter out repeated captures of certain face.
Similarity Threshold for Duplicates Removing
It is the similarity between the newly captured face and the picture in the duplicates
removing library. When the similarity is higher than the value you set, the captured picture is
regarded as a duplicated face and will be dropped.
Duplicates Removing Library Grading Threshold
It is the face grading threshold that triggers duplicates checking. When the face grading is
higher than the set value, the captured face is compared with the face pictures that are
already in the duplicates removing library.
Duplicates Removing Library Update Time
Every face picture is kept in the duplicates removing library for the set update
me.
Quick Shot
The device captures the target picture once the score of the captured face exceeds the Quick
Shot Threshold during the Max. Capture Interval. Otherwise, the device selects and uploads
the picture with the highest score during the Max. Capture Interval.
Quick Shot Threshold
It refers to the quality of face to trigger quick shot.
Max. Capture Interval
It describes the max.
me occupaon for one quick shot.
Capture Times
It refers to the capture mes a face will be captured during its stay in the congured area.
Unlimited
The device keeps capturing the target face, which exceeds the Quick Shot Threshold during
the Max. Capture Interval.
Network Speed Dome User Manual
16
Limited
The device captures the target face according to the set mes.
Face Exposure
Enable the funcon, and the device automacally adjusts exposure level when human faces
appear in the scene.
Reference Brightness
It refers to the reference brightness of a face in the face exposure mode. If a face in the actual
scene is brighter than the set reference brightness, the device lower the exposure level. If a
face in the actual scene is darker than the set reference, the device increases the exposure
level.
Min.
Duraon
The extra me the device keeps the face exposure level aer the face disappears in the scene.
Face Filtering Time
It means the
me interval between the camera detecng a face and taking a capture acon. If
the detected face stays in the scene for less than the set ltering me, capture will not be
triggered. For example, if the face ltering me is set as 5 seconds, the camera will capture the
detected face when the face keeps staying in the scene for 5 seconds.
Upload Feature
Feature stands for the feature informaon the algorithm can tell from face pictures. Check the
funcon to upload the informaon.
Restore Parameters
Restore Defaults
Click Restore to restore all the sengs in advanced conguraon to the factory default.
3.5 Face Comparison
Face comparison serves the purpose of face recognion by comparing the captured faces with
those in face picture library.
To realize the face comparison, you should set up:
●
Face Capture for capturing face pictures. See
Face Capture for conguraon instrucons.
●
Face picture library, see Set Face Picture Library for conguraon instrucons.
●
Face picture comparison rule, see Set Face Picture Comparison for conguraon instrucons.
3.5.1 Set Face Picture Library
Face picture library is used to store modeled human faces and informaon.
Network Speed Dome User Manual
17
Steps
1.
Go to VCA → Face Comparison → Set Applicaon → General Sengs → Face Picture Library .
2.
Create a face picture library.
1) Click
to add a face picture library.
2) Input library name, threshold and remarks.
Threshold
Face similarity higher than the set threshold triggers face picture comparison alarm
uploading.
3) Click OK.
4) Oponal: Modify a face picture library. Select the desired library and click and change
related parameters.
5)
Oponal: Delete a library. Select the desired library and click .
3.
Add face pictures to the library.
Note
The picture format should be JPEG, and the size no larger than 300 K per le.
Add one face
Click Add and upload the face picture with detailed face informaon.
Import face
pictures in
batch
Click Import and select picture path.
Note
When you import face pictures in batch, the picture name is saved as the
face name. For other face informaon, you should modify one by one
manually.
The
vericaon code for exporng and imporng should be a combinaon
of 8 to 16 digits, containing numerics, upper case and lower case leers.
4.
Oponal: Modify face informaon.
1) Select a face picture library.
2) Select the target face picture. You can use the search
funcon to locate the picture by
inpung search condions, and click Search.
3) Click Modify.
4) Edit detailed
informaon.
Note
Face picture is not allowed to change.
5) Click OK.
5.
Create models for each face picture in library.
Modeling process builds up face model for each face picture. Face model is compulsory for face
picture comparison to take
eect.
Modeling
Select one or more face pictures, and click Modeling.
Network Speed Dome User Manual
18
Batch Modeling Select a face picture library, and click Batch Modeling.
6.
Oponal: Repeat to create more face libraries.
3.5.2 Set Face Picture Comparison
The funcon compares captured pictures with face pictures in the library and outputs comparison
result. Comparison result can trigger certain
acons when arming schedule and linkage method are
set.
Before You Start
You should
rst create at least one face picture library and add face pictures. See Set Face Picture
Library .
Note
For face comparison, the faces captured in a certain face picture library will be compared with the
data in all face libraries.
Steps
1.
Go to VCA → Face Comparison → Set
Applicaon → Comparison and Modeling .
2.
Check Enable.
3.
Select a face picture library as the reference.
4.
Select desired face
informaon to upload.
5.
Select a face comparison mode.
Best
Comparison
The device captures and compares the target face connuously when the
face target stays in the detecon area, and upload the best scored face
picture and related alarm informaon when the target face leaves the area.
Quick
Comparison
The device capture and compares the target face when the face grading
exceeds the set Face Grading Threshold for Capture.
Face Grading Threshold for Capture
The face grading threshold for the device to judge whether to capture and
upload the face or not.
Max. Capture Interval
The max. interval between two captures when the target is in the
detecon area. The camera takes the capture when it reaches the max.
interval even if the face grading does not reach the set threshold.
Quick Setup Mode
Custom, Face Aendance, and Face Recognion are selectable. Select
according to actual using scenarios. In custom mode, you can set
Comparison Timeout and Comparison Times.
6.
Click to set arming schedule for the selected face library. Set arming schedule. See Set Arming
Schedule .
Network Speed Dome User Manual
19
7.
Click to set linkage method for the selected face library. Set linkage method. See Linkage
Method Sengs
3.5.3 View Face Comparison Result
Steps
1.
Go to Applicaon Display → Face Picture Comparison Stascs .
2.
Set Start Time and End Time.
3.
Click Search.
Matched results are shown in Face Picture Comparison
Stascs area.
3.6 Capture Target with Feature
It is to detect, capture and upload features of targets in mulple types, such as human face and
human body.
Note
For certain device models, you need to select Face+Human on VCA Resource page rst. See
Allocate VCA Resource for instrucons.
3.6.1 Set Detecon Rule
Aer the rules and algorithm parameters are set, the device captures targets of mulple types and
triggers linkage
acons automacally.
Before You Start
Go to VCA → Select
Applicaon to select Face+Human/Mul-Target-Type Detecon, and click
Next to enable the funcon.
Steps
1.
Go to VCA → Set Applicaon → Face+Human → Rule .
2.
Check Enable.
3.
Select a
conguraon mode.
Normal
One detecon scene is allowed to set. The device captures targets in the scene in
the set arming schedule.
See Normal Mode Sengs for details.
Expert The device can patrol among the detecon scenes and capture target images.
Detecon scenes and patrol schedule should be set in advance.
See Expert Mode Sengs for details.
4.
Click Save.
Network Speed Dome User Manual
20
What to do next
Go to Picture to search and view the captured pictures.
Go to Smart Display to see currently captured target pictures.
3.6.2 Overlay and Capture
Choose to congure capture parameters and the informaon you want to display on stream and
picture.
Display VCA Info. on Stream
Display smart informaon on stream, including the target and rules informaon.
Display Target Info. on Alarm Picture
Overlay the alarm picture with target informaon.
Target Picture Sengs
You can set the face picture type by selecng Custom, Head Shot, Half-Body Shot, or Full-Body
Shot. If you select Custom, you can
dene detailed picture width and height of a picture freely.
If the captured pictures should have the same picture height, check Fixed Picture Height and
input desired picture height.
Face
Beaucaon
Check Face Beaucaon and adjust the beaucaon level as needed.
Note
Face Beaucaon slightly adjusts skin tone and reduces facial noise.
Background Picture Sengs
Comparing to target picture, background picture is the scene image oers extra environmental
informaon. You can set the background picture quality and resoluon.
If the background image need to be uploaded to surveillance center, check Background Upload.
If a small face image need to be uploaded to surveillance center, check Face Picture.
Text Overlay
You can check desired items (Device No., Camera Info. and Capture Time) and adjust their order
to display on captured pictures by
.
See
Set Camera Info to set Device No. and Camera Info.
3.6.3 Advanced Parameters
It is used to set the parameters of the algorithm library for
beer detecon performance.
HMS Version
It refers to the current algorithm version, which cannot be edited.
Network Speed Dome User Manual
21
Capture Parameters
Best Shot
The device captures the target picture with the highest score aer seng the parameters.
Capture Threshold
It refers for the quality of face to trigger capture and alarm. Higher value means
beer quality
should be met to trigger capture and alarm.
Capture Times
It refers to the capture
mes a face will be captured during its stay in the detecon area.
Remove Duplicated Faces
This funcon can lter out repeated captures of certain face.
Similarity Threshold for Duplicates Removing
It is the similarity between the newly captured face and the picture in the duplicates
removing library. When the similarity is higher than the value you set, the captured picture is
regarded as a duplicated face and will be dropped.
Duplicates Removing Library Grading Threshold
It is the face grading threshold that triggers duplicates checking. When the face grading is
higher than the set value, the captured face is compared with the face pictures that are
already in the duplicates removing library.
Duplicates Removing Library Update Time
Every face picture is kept in the duplicates removing library for the set update
me.
Quick Shot
The device captures the target picture once the score of the captured face exceeds the Quick
Shot Threshold during the Max. Capture Interval. Otherwise, the device selects and uploads
the picture with the highest score during the Max. Capture Interval.
Quick Shot Threshold
It refers to the quality of face to trigger quick shot.
Max. Capture Interval
It describes the max.
me occupaon for one quick shot.
Capture Times
It refers to the capture mes a face will be captured during its stay in the congured area.
Unlimited
The device keeps capturing the target face, which exceeds the Quick Shot Threshold during
the Max. Capture Interval.
Network Speed Dome User Manual
22
Limited
The device captures the target face according to the set mes.
Face Exposure
Enable the funcon, and the device automacally adjusts exposure level when human faces
appear in the scene.
Reference Brightness
It refers to the reference brightness of a face in the face exposure mode. If a face in the actual
scene is brighter than the set reference brightness, the device lower the exposure level. If a
face in the actual scene is darker than the set reference, the device increases the exposure
level.
Min.
Duraon
The extra me the device keeps the face exposure level aer the face disappears in the scene.
Face Filtering Time
It means the
me interval between the camera detecng a face and taking a capture acon. If
the detected face stays in the scene for less than the set ltering me, capture will not be
triggered. For example, if the face ltering me is set as 5 seconds, the camera will capture the
detected face when the face keeps staying in the scene for 5 seconds.
Data Upload
Check one or more desired target types for picture uploading.
3.7 Person Arming
When the device detects the armed face or human body in the monitoring scene, it triggers
alarms, and tracks and captures the target. During the tracking, the target locaon and other
related
informaon are uploaded.
Note
●
Select Person Arming on VCA Resource page to show the conguraon page.
●
Target locaon informaon can be uploaded only when you set the GPS Calibraon properly. See
GPS Calibraon for instrucons.
●
This
funcon is only supported by certain device models.
Device Auto Person Arming and Manual Person Arming are supported. The Manual Person
Arming has a higher priority than the other, which means it can interrupt the ongoing auto person
arming.
Network Speed Dome User Manual
23
Manual Person Arming The device tracks and captures the manually selected target and uploads
the related data.
Device Auto Person
Arming
The device tracks and captures targets automacally according to the
seng rule.
3.7.1 Device Auto Person Arming
You need to set face picture libraries and auto person arming rules to realize device auto person
arming.
Set Auto Person Arming Rule
Before You Start
The face picture library should be set in advance. See Set Face Picture Library .
Steps
1.
Go to VCA → Set Applicaon → Person Arming → Basic Sengs .
2.
Check Enable.
3.
Set the parameters for face picture comparison and arming.
1) Set the Face Grading Threshold for
Detecon and Max. Detecon Time of Face.
Face Grading Threshold for Detecon
Every face entering the monitoring scene is graded by the device according to the quality.
When a face with its grading exceeds the set threshold, it triggers the comparison with the
pictures in the selected face picture library.
Max.
Detecon Time of Face
If the grading of a target face does not reach the set Face Grading Threshold for Detecon
during the set me, the device stops grading the target face.
2) Select a desired library, and set as the Face Picture Library.
3) Set the arming schedule and linkage method for the selected library.
Note
The arming schedule and linkage method for dierent libraries are allowed to set
independently.
4.
Click Save.
Advanced
Sengs
In advanced parameters, you can set the tracking, capture and other parameters for the person
arming.
Network Speed Dome User Manual
24
Tuning Mode
The mode is only for the professional users.
Tracking Capture
Check to enable the device to capture the targets during the tracking.
Some capture parameters are allowed to adjust.
Face Capture Threshold
It refers for the quality of face to trigger capture and alarm. Higher value means
beer quality
should be met to trigger capture and alarm.
Human Body Capture Threshold
It refers for the quality of human body to trigger capture and alarm. Higher value means beer
quality should be met to trigger capture and alarm.
Tracking Parameters
Zooming Control
Two modes are available. Controlled by target frame or by lt angle of the device.
By Tilt Angle
The device calculates the tracking zoom rao automacally according to the lt angle of the
device.
Note
The atude of the device aects the accuracy of this zooming control mode. For the model
with a built-in gyroscope, try to calibrate the atude if some zooming problems happen
during tracking. See Set Device Posion for instrucons.
By Target Frame
The tracked target has a virtual frame around. The device calculates a suitable zoom rao
according to the frame and the set Tracking Zoom Rao. Larger value means bigger zoom
rao.
Dwell Time aer Failed Tracking
The me the device stays at the posion where the target tracking fails.
Report Interval of Tracking Info
The alarming informaon upload interval during tracking.
Wait to Stop Tracking If Low Validity
The validity is an internal parameter that helps judge whether the device should keep tracking
or not. This parameter is the
waing me level before the device stops tracking when the
validity is low. Larger value means longer waing me.
Wait to Lower Tracking Speed If Low Validity
Network Speed Dome User Manual
25
The validity is an internal parameter that helps judge whether the PTZ channel should lower the
tracking speed or not. This parameter is the waing me level before the device lowers the
tracking speed when the validity is low. Larger value means longer waing me.
Tracking Duraon
When you set the Tracking Duraon as 0, the device keeps tracking the target unl it
disappears.
When you set the Tracking
Duraon as a number other than 0, the device tracks a target for the
set me. The tracking stops when the me is up or when the target disappears.
3.7.2 Manual Person Arming
The device tracks and captures the manually selected target and uploads the related data.
Note
Manual face capture is prior to the manual person arming. When the manual face capture in use,
the manual person arming is temporary unavailable.
Steps
1.
Click Live View.
2.
Click
to start manual person arming.
3.
Click or frame a person as the target.
The device starts to track the target and upload related data.
4.
Click
to stop manual person arming.
3.7.3 Capture
Sengs
Mul-target-type detecon is used for capturing armed persons. You can set the capture rules and
parameters according to your needs.
Set
Detecon Rule
Aer the rules and algorithm parameters are set, the device captures targets of mulple types and
triggers linkage
acons automacally.
Before You Start
Go to VCA → Select Applicaon to select Face+Human/Mul-Target-Type Detecon, and click
Next to enable the funcon.
Steps
1.
Go to VCA → Set
Applicaon → Face+Human → Rule .
2.
Check Enable.
3.
Select a conguraon mode.
Network Speed Dome User Manual
26
Normal One detecon scene is allowed to set. The device captures targets in the scene in
the set arming schedule.
See Normal Mode Sengs for details.
Expert The device can patrol among the detecon scenes and capture target images.
Detecon scenes and patrol schedule should be set in advance.
See Expert Mode Sengs for details.
4.
Click Save.
What to do next
Go to Picture to search and view the captured pictures.
Go to Smart Display to see currently captured target pictures.
Overlay and Capture
Choose to congure capture parameters and the informaon you want to display on stream and
picture.
Display VCA Info. on Stream
Display smart
informaon on stream, including the target and rules informaon.
Display Target Info. on Alarm Picture
Overlay the alarm picture with target informaon.
Target Picture Sengs
You can set the face picture type by selecng Custom, Head Shot, Half-Body Shot, or Full-Body
Shot. If you select Custom, you can dene detailed picture width and height of a picture freely.
If the captured pictures should have the same picture height, check Fixed Picture Height and
input desired picture height.
Face
Beaucaon
Check Face Beaucaon and adjust the beaucaon level as needed.
Note
Face Beaucaon slightly adjusts skin tone and reduces facial noise.
Background Picture Sengs
Comparing to target picture, background picture is the scene image oers extra environmental
informaon. You can set the background picture quality and resoluon. If the background image
need to be uploaded to surveillance center, check Background Upload.
Text Overlay
You can check desired items (Device No., Camera Info. and Capture Time) and adjust their order
to display on captured pictures by
.
See
Set Camera Info to set Device No. and Camera Info.
Network Speed Dome User Manual
27
Advanced Parameters
It is used to set the parameters of the algorithm library for beer detecon performance.
HMS Version
It refers to the current algorithm version, which cannot be edited.
Capture Parameters
Best Shot
The device captures the target picture with the highest score aer seng the parameters.
Capture Threshold
It refers for the quality of face to trigger capture and alarm. Higher value means beer quality
should be met to trigger capture and alarm.
Capture Times
It refers to the capture
mes a face will be captured during its stay in the detecon area.
Remove Duplicated Faces
This funcon can lter out repeated captures of certain face.
Similarity Threshold for Duplicates Removing
It is the similarity between the newly captured face and the picture in the duplicates
removing library. When the similarity is higher than the value you set, the captured picture is
regarded as a duplicated face and will be dropped.
Duplicates Removing Library Grading Threshold
It is the face grading threshold that triggers duplicates checking. When the face grading is
higher than the set value, the captured face is compared with the face pictures that are
already in the duplicates removing library.
Duplicates Removing Library Update Time
Every face picture is kept in the duplicates removing library for the set update
me.
Quick Shot
The device captures the target picture once the score of the captured face exceeds the Quick
Shot Threshold during the Max. Capture Interval. Otherwise, the device selects and uploads
the picture with the highest score during the Max. Capture Interval.
Quick Shot Threshold
It refers to the quality of face to trigger quick shot.
Max. Capture Interval
It describes the max.
me occupaon for one quick shot.
Capture Times
Network Speed Dome User Manual
28
It refers to the capture mes a face will be captured during its stay in the congured area.
Unlimited
The device keeps capturing the target face, which exceeds the Quick Shot Threshold during
the Max. Capture Interval.
Limited
The device captures the target face according to the set
mes.
Face Exposure
Enable the funcon, and the device automacally adjusts exposure level when human faces
appear in the scene.
Reference Brightness
It refers to the reference brightness of a face in the face exposure mode. If a face in the actual
scene is brighter than the set reference brightness, the device lower the exposure level. If a
face in the actual scene is darker than the set reference, the device increases the exposure
level.
Min.
Duraon
The extra me the device keeps the face exposure level aer the face disappears in the scene.
Face Filtering Time
It means the me interval between the camera detecng a face and taking a capture acon. If
the detected face stays in the scene for less than the set
ltering me, capture will not be
triggered. For example, if the face ltering me is set as 5 seconds, the camera will capture the
detected face when the face keeps staying in the scene for 5 seconds.
Data Upload
Check one or more desired target types for picture uploading.
3.8 Intelligent
Trac Event (ITS)
The device detects vehicles, trac violaons, and trac accidents, captures evidence pictures, and
collects trac data. You can set the rules for detecon, alarm messages, and data uploading.
3.8.1 Basic
Sengs
You can set the basic informaon, listening server, and ANR.
Go to VCA → Set Applicaon → ITS (Intelligent Transportaon System) → Basic Conguraon to
complete the
sengs.
Basic Informaon
Select the Country/Region.
Network Speed Dome User Manual
29
Listening Server
If the device uploads alarms in listening mode via our company's SDK, you should set the IP
address and port for the listening server.
ANR
When the network is disconnected, data is temporarily saved on the memory card. When the
network
connecon is resumed, the device automacally uploads the saved data to the arming
host, in which case, the arming host IP address is required.
Note
A memory card should be installed in the device. Memory card sengs should be completed.
See Memory Card for instrucons.
3.8.2 Vehicle Detecon
The device detects vehicles in the detecon area, recognizes license plates, captures and saves
pictures, and uploads alarms.
Before You Start
Set detecon scenes and detecon areas. See Set Detecon Scene and Set Lane Area for details.
Steps
1.
Go to VCA → Set
Applicaon → ITS (Intelligent Transportaon System) → Close-up Rule
Sengs .
2.
Select a scene.
3.
Check Enable.
4.
Click Add in Event List, and select Vehicle
Detecon.
5.
Select Arm Lane.
Vehicle
detecon takes eect in the selected lane areas.
6.
Select the vehicle types.
Only selected car types will trigger alarms.
7.
Click Save.
What to do next
Set the arming schedule and linkage and alarm. See
Set ITS Arming Schedule and ITS Linkage and
Alarm for details.
Set
Detecon Scene
A detecon scene is an area you want to monitor. If one detecon scene cannot cover all the
intended monitoring areas, set mulple detecon scenes.
Network Speed Dome User Manual
30
Steps
1.
Go to VCA → Set Applicaon → ITS (Intelligent Transportaon System) → Close-up Rule
Sengs .
2.
Oponal: Click to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
3.
Select a Scene.
4.
Check Enable to enable the scene.
5.
Click the PTZ control
buons to adjust the scene to where you want to monitor.
6.
Enter a Scene Name.
7.
Select the Scene
Direcon according to the trac direcon in the scene.
8.
Click Save.
9.
Oponal: Repeat the steps above to set mulple detecon scenes.
10.
Oponal: Select a Scene to turn the live view image to the scene.
Set Lane Area
A lane area is where you want to set the detecon rules. Mark the lane area according to the
actual lanes in the view.
Steps
1.
Go to VCA → Set
Applicaon → ITS (Intelligent Transportaon System) → Close-up Rule
Sengs and click Lane Area.
2.
Click Add.
Blue lane lines and a trigger line show on the live view.
3.
Drag the lane lines to frame the actual lane on the image.
Note
●
You can click to enlarge the live view window. Press ESC on the keyboard to exit.
●
Lane lines cannot overlap.
4.
Select the direcon of the trac and line type of the le and right lane lines according to the
actual
situaon.
5.
Drag the trigger line to adjust its length and posion.
The trigger line is where the device captures the vehicle pictures in some detecons and where
trac data collecon is triggered.
6.
Oponal: Repeat the steps above to set mulple lane areas.
7.
Click Save.
Network Speed Dome User Manual
31
Set ITS Arming Schedule
The device automacally detects among mulple scenes according to the arming schedule.
Before You Start
Set mulple detecon scenes. See Set Detecon Scene for details.
Steps
1.
Go to VCA → Set
Applicaon → ITS (Intelligent Transportaon System) → Close-up Scene
Alarm Schedule .
2.
Check Enable.
3.
Draw a bar on the
meline to cover the arming hours.
4.
Oponal: Click on an arming period and adjust the arming hours.
-
Enter the start me and end me and click Save to ne-tune the arming period.
-
Click Delete to delete the arming period.
5.
Click on an arming period, and click Set Scene Auto-switch.
6.
Set the patrol sequence and Dwell Time in each scene.
Add a detecon scene to the patrol sequence.
Adjust the order of the scenes.
Remove the detecon scene from the patrol sequence.
7.
Click to copy the seng to another day.
8.
Click Save.
9.
Oponal: Go to VCA → Set Applicaon → ITS (Intelligent Transportaon System) → Advanced
Sengs → Advanced to set PTZ Camera Moon Parameters.
Park Time
Manual control of the device takes priority over
automac patrols. When manual control is
over, the device waits for the set Park Time before resuming automac detecon.
3.8.3 ITS Linkage and Alarm
When trac events are detected, the device can perform linkage acons, for example, uploading
captured pictures and sending alarm messages.
Note
Some linkage acons may not be supported by certain device models.
Network Speed Dome User Manual
32
Upload Pictures
Set the parameters for the device to automacally upload captured pictures to FTP server or other
plaorms.
See Upload by FTP to upload captured pictures by FTP.
See Upload by SDK or Set ISUP to upload captured pictures to plaorms.
Upload by FTP
Upload the data of vehicle detecon to an FTP server.
Before You Start
The FTP server is
congured.
Steps
1.
Go to VCA → Set Applicaon → ITS (Intelligent Transportaon System) → Advanced Sengs →
FTP Host
2.
Check Enable FTP.
3.
Select a Character Encoding Mode.
4.
Enter the IP Address, Port, User Name, and Password of the FTP server.
5.
Set the picture names and saving paths of
detecons.
6.
Click Save.
Upload by SDK
Upload the alarm messages by SDK in listening and arming mode.
Go to VCA → Set
Applicaon → ITS (Intelligent Transportaon System) → Basic Conguraon to
set Listening Server and ANR. See Basic Sengs for details.
3.8.4 Vehicle Arming
The device detects and tracks designated license plates, and uploads real-me target locaon and
other related informaon.
Note
●
Select ITS (Intelligent Transportaon System) on VCA Resource page to show the conguraon
page.
●
Target locaon informaon can be uploaded only when the GPS calibraon is completed. See
GPS Calibraon for conguraon instrucons.
●
This
funcon is only supported by certain device models.
Network Speed Dome User Manual
33
Manual vehicle arming and plaorm-controlled vehicle arming are supported, and manual vehicle
arming has a higher priority.
Manual Vehicle Arming The device tracks the target manually selected by user and uploads
related informaon.
Plaorm-Controlled
Vehicle Arming
The device receives orders from the plaorm and performs arming tasks.
Note
To use plaorm-controlled vehicle arming, you need to build a plaorm
with the SDK tool provided on our website.
Manual Vehicle Arming
Steps
1.
Go to Live View .
2.
Click .
3.
Frame or click on a vehicle in the live image.
The device starts to track the vehicle.
4.
Click
to stop manual vehicle arming.
Plaorm-Controlled
Vehicle Arming
The device receives arming tasks from the plaorm to detect and track target vehicles. You can
view the arming tasks in arming status.
Set Arming
Locaon
Steps
1.
Go to VCA → Set Applicaon → ITS (Intelligent Transportaon System) → Vehicle Arming →
Arming Scene .
Note
The PTZ control is automacally locked to avoid interrupon during conguraon.
2.
Adjust the live image to the target scene with PTZ control buons.
3.
Click New Scene.
The scene is added to the Arming Scene List.
4.
Edit the scene name and moving
direcon of the vehicles.
5.
Repeat the steps to add other scenes.
6.
Click Save.
Network Speed Dome User Manual
34
View Arming Task
Go to VCA → Set Applicaon → ITS (Intelligent Transportaon System) → Vehicle Arming →
Arming Status to view the arming tasks sent from the
plaorm.
The device performs a single task at one me. If it receives mulple tasks, former tasks are
interrupted and the device performs the latest task.
3.8.5 Advanced Sengs
You can set the advanced sengs according to your need to get beer vehicle arming eect.
Advanced Parameters
Go to VCA → Set Applicaon → ITS (Intelligent Transportaon System) → Advanced Sengs →
Advance to set the following parameters.
License Plate Thumbnail
If the device recognizes a license plate, an
addional thumbnail of the license plate is uploaded.
Tuning Mode
The tuning mode is for professional technicians. It is not recommended to other users as it may
aect the live view image.
Target Informaon
When target informaon is enabled, the target is highlighted with a frame in the video.
Rule Informaon
When rule informaon is enabled, the rule frames (for example, detecon areas) show in the
video.
Capture No Plate Vehicle
When this
funcon is enabled, the device captures and uploads vehicle pictures with or without
license plate. If it is not enabled, only pictures of vehicles with license plate are uploaded.
Dwell Time aer Failed Tracking
The me the device stays at the posion where the target tracking fails.
Report Interval of Tracking Info
The alarming informaon upload interval during tracking.
Wait to Stop Tracking If Low Validity
The validity is an internal parameter that helps judge whether the device should keep tracking
or not. This parameter is the
waing me level before the device stops tracking when the
validity is low. Larger value means longer waing me.
Wait to Lower Tracking Speed If Low Validity
Network Speed Dome User Manual
35
The validity is an internal parameter that helps judge whether the PTZ channel should lower the
tracking speed or not. This parameter is the waing me level before the device lowers the
tracking speed when the validity is low. Larger value means longer waing me.
Uploading Picture Sengs
Go to VCA → Set Applicaon → ITS (Intelligent Transportaon System) → Advanced Sengs →
Picture to set the parameters of alarm pictures.
Picture Quality
Pictures with higher resoluon and beer quality have more details and larger le size.
Enable OSD Overlay
The device OSD is overlaid on alarm pictures.
Display Target Info. on Alarm Picture
Check to display target informaon on alarm pictures.
License Plate Exposure
You can adjust the exposure parameters to make sure that the license plates are exposed properly
during vehicle arming.
Steps
1.
Go to VCA → Set Applicaon → ITS (Intelligent Transportaon System) → Advanced Sengs →
License Plate Exposure .
2.
Check License Plate Exposure.
3.
Set exposure parameters.
Reference Brightness
Adjust the reference brightness to the value that the license plate is exposed properly.
Min.
Duraon
The minimum duraon to maintain the exposure level for the license plates when they are
detected.
Arming Schedule
Set the start
me and end me when the license plate exposure sengs are valid.
4.
Click Save.
3.9 Display Alarm
This funcon displays real me pictures captured by smart funcons and analyzes the target in real
me.
Network Speed Dome User Manual
36
Go to Applicaon Display → Display Alarm to view the real-me images. Click to go back to
Applicaon Display.
Note
●
To use this funcon, you should rst enable and congure certain smart funcons.
●
To use this funcon, your web browser version should be above IE11.0.9600.17843.
Live View
Icon Descripon
Capture a picture.
Start or stop recording.
Mute.
Adjust the volume of live view. Move the slider
to right to turn up the volume and le to turn
down the volume. Move to the le end to mute
the live view.
Download Display Picture
Click and the device stores captured pictures to the browser cache. Hover the pointer over the
icon to see the number of pictures in the cache. Click again to download the pictures in a
package.
Note
The browser cache has a limited size. The recommended number of pictures to download is no
more than 200.
Layout
Click and choose Layout. Check the display content you need to add it to the smart display page.
When real-me analyze is selected, you can choose the contents you want to display.
Detect Features
Click and choose Detect Features. Check the corresponding checkbox to display the features of
the
detecon target.
Network Speed Dome User Manual
37
Chapter 4 PTZ
PTZ is an abbreviaon for pan, lt, and zoom. It means the movement opons of the camera.
4.1 PTZ Control
In live view interface, you can use the PTZ control buons to control the device panning, lng,
and zooming.
PTZ Control Panel
Click and hold the direconal buon to pan/lt
the device.
Note
●
You can set Keyboard Control Speed in
Conguraon → PTZ → Basic Sengs . The
speed of pan/lt movement in live view is
based on this speed level.
●
You can set Max. Tilt-angle in Conguraon
→ PTZ → Basic Sengs to limit lt
movement range.
Click the buon, then the device keeps panning.
Note
You can set Auto Scan Speed in Conguraon
→ PTZ → Basic Sengs . The higher the value
you set, the faster the device pans.
Drag the slider to adjust the speed of pan/lt
movement.
Note
You can set Manual Control Speed in Conguraon → PTZ → Basic Sengs .
Network Speed Dome User Manual
38
Compable The control speed is same as Keyboard Control
Speed.
Pedestrian Choose Pedestrian when you monitor the
pedestrians.
Non-motor Vehicle Choose Non-motor Vehicle when you monitor
the non-motor vehicles.
Motor Vehicle Choose Motor Vehicle when you monitor the
motor vehicles.
Auto You are recommended to set it as Auto when
the applicaon scene of the speed dome is
complicated.
To avoid blurred image resulted from fast zoom, you can check Enable Proporonal Pan in
Conguraon → PTZ → Basic Sengs . If you enable this funcon, the pan/lt speed change
according to the amount of zoom. When there is a large amount of zoom, the pan/lt speed will be
slower for keeping the image from moving too fast on the live view image.
Zoom in/out
Click the buon, and the lens zooms in.
Click the buon, and the lens zooms out.
Note
●
You can set Zooming Speed in Conguraon → PTZ → Basic Sengs . The higher the value is,
the faster the zooming speed is.
●
You can set Zoom Limit in Conguraon → Image → Display Sengs → Other to limit the
maximum value of the total zoom (digital zoom and
opcal zoom).
Focus
Click the buon, then the lens focuses near and
the object nearby gets clear.
Click the buon, then the lens focuses far and
the object far away gets clear.
Network Speed Dome User Manual
39
Iris
When the image is too dark, click the buon to
enlarge the iris.
When the image is too bright, click the buon
to stop down the iris.
4.2 Set Preset
A preset is a predened image posion. For the dened preset, you can call the preset No. to view
the posion.
Steps
1.
Click
to show the seng panel, and click .
2.
Use the PTZ control buons to move the lens to the desired posion.
3.
Select a preset number from the preset list, and click to nish the seng.
Note
Some presets are predened with special command. You can only call them but not congure
them.
4.
Repeat the steps above to set mulple presets.
Click the
buon to call the preset.
Click the buon to delete the preset.
Note
You can delete all presets in Conguraon → PTZ → Clear Cong . Check Clear All Presets, and
click Save.
What to do next
Go to
Conguraon → PTZ → Basic Sengs to set preset freezing and preset speed.
Aer enabling preset freezing, the live image switches directly from one preset to another, without
showing the areas between these two scenes. It also guarantees the masked area will not be seen
when the device is moving.
4.2.1 Special Presets
You can call the following presets with special demands to enable corresponding
funcons.
Network Speed Dome User Manual
40
Preset No. Funcon Preset No. Funcon
33 Auto ip 92 Set manual limits
34 Back to origin 93 Save manual limits
35 Call patrol 1 94 Remote reboot
36 Call patrol 2 95 Call OSD menu
37 Call patrol 3 96 Stop a scan
38 Call patrol 4 97 Start random scan
39 Day mode 98 Start frame scan
40 Night mode 99 Start auto scan
41 Call paern 1 100 Start lt scan
42 Call paern 2 101 Start panorama scan
43 Call paern 3 102 Call patrol 5
44 Call paern 4 103 Call patrol 6
45 One-touch patrol 104 Call patrol 7
46 Day/Night Auto 105 Call patrol 8
90 Wiper
4.3 Set Patrol Scan
Patrol scan is a funcon to automacally move among mulple presets.
Before You Start
Make sure that you have dened more than one presets. See Set Preset for detailed conguraon.
Steps
1.
Click to show the seng panel, and click to enter patrol seng interface.
2.
Select a patrol number from the list and click
.
3.
Click to add presets.
Preset
Select
predened preset.
Speed
Set the speed of moving from one preset to another.
Time
Network Speed Dome User Manual
41
It is the duraon staying on one patrol point.
Delete the presets in patrol.
Adjust the preset order.
Note
A patrol can be congured with 32 presets at most, and 2 presets at least.
4.
Click OK to nish a patrol seng.
5.
Repeat the steps above to congure mulple patrols.
6.
Operate patrols.
Call the patrol.
Stop patroling.
Delete the patrol.
Note
You can delete all patrols in Conguraon → PTZ → Clear Cong . Check Clear All Patrols, and
click Save.
4.3.1 Set One-Touch Patrol
The device automacally adds presets to one patrol path and starts patrol scan.
Steps
1.
Set two or more presets among preset No.1 to preset No.32. For seng presets, refer to Set
Preset .
The device will automacally add presets to patrol path No.8.
2.
Choose one of the following methods to enable the funcon.
-
Click .
-
Call patrol path No.8.
-
Select and call preset No.45.
4.4 Set
Paern Scan
The device can move as the recorded paern.
Steps
1.
Click
to show the PTZ control panel, and click .
2.
Select one paern scan path that needs to be set.
3.
Click
to start recording paern scan.
4.
Click PTZ control buons as demands.
Network Speed Dome User Manual
42
Note
Recording stops when the space for paern scan is 0%.
5.
Click to complete one paern scan path sengs.
6.
Click to call paern scan.
Stop paern scan.
Reset paern scan path.
Delete the selected paern scan.
Note
If you need to delete all the paern scans, go to Conguraon → PTZ → Clear Cong , and
check Clear All Paerns, and click Save.
4.5 Set Limit
The device can only move within the limited range.
Steps
1.
Go to Conguraon → PTZ → Limit .
2.
Check Enable.
3.
Select Limit Type.
Manual Stops
It refers to the movement range limit when you control the device manually.
Scan Stops
It refers to the movement range limit when the device scans
automacally.
Note
Scan limit is only supported by the device that has scan funcon.
4.
Click Set and set limits according to the prompt on the live image.
5.
Oponal: Click Clear to clear the limit sengs of the selected mode.
6.
Click Save.
Note
If you need to cancel all the set patrol paths, go to Conguraon → PTZ → Clear Cong , select
Clear All PTZ Limited, and click Save.
Result
The device can only move within the set region
aer saving the sengs.
Network Speed Dome User Manual
43
4.6 Set Home Posion
Home posion refers to the relave inial posion of the device azimuth. You can set the home
posion if you need to select one point in the scene as the base point.
Steps
1.
Go to Conguraon → PTZ → Home Posion .
2.
Move the device to the needed
posion by manually controlling the PTZ control buons.
3.
Click Set to save the informaon of inial posion.
View The device moves to the set inial posion.
Clear Clear the set inial posion.
4.7 Set Park Acon
You can set the device to perform an acon (for example, preset or patrol) or return to a posion
aer a period of inacvity (park me).
Before You Start
Set the
acon type rst. For example, if you want to select patrol as park acon, you should set the
patrol. See Set Patrol Scan for details.
Steps
1.
Go to Conguraon → PTZ → Park Acon .
2.
Check Enable Park
Acon.
3.
Set Park Time: the inacve me before the device starts park acon.
4.
Select Acon Type according to your needs.
5.
Select an
Acon Type ID, if you select patrol or preset as acon type.
When the acon type is patrol, acon type ID stands for patrol No. When the acon type is
preset,
acon type ID stands for preset No.
6.
Click Save.
4.7.1 Set One-Touch Park
This funcon is used to start park instantly.
Steps
1.
Refer to Set Park Acon to set a park acon.
2.
Click to start one-touch park.
Network Speed Dome User Manual
44
4.8 Set Scheduled Tasks
You can set the device to perform a certain task during a certain period.
Steps
1.
Go to Conguraon → PTZ → Scheduled Tasks .
2.
Check Enable.
3.
Select the task type and set the period. For
seng the period, refer to Set Arming Schedule .
4.
Repeat step 3 to set more than one scheduled tasks.
5.
Set Park Time. During the set task period, if you operate the device manually, the scheduled task
will be suspended. When the manual
operaon is over, the device will connue to perform the
scheduled task aer the set park me.
6.
Click Save.
Note
If you want to clear all scheduled tasks, go to Conguraon → PTZ → Clear Cong , check Clear
All Scheduled Tasks, and click Save.
4.9 Set Power O Memory
This funcon can resume the previous PTZ status of device aer it restarng from a power-o.
Steps
1.
Go to
Conguraon → PTZ → Basic Sengs .
2.
Select Resume Time Point. When the device stays at one posion for the set resume me point
or more, the
posion is saved as a momory point. The device returns to the last memory point
when it restarts.
3.
Click Save.
4.10 Set PTZ Priority
The funcon can set the PTZ priority of dierent signals.
Steps
1.
Go to Conguraon → PTZ → Priorize PTZ .
2.
Set the priority signal and delayed me.
Network
The network signal controls the device with priority.
RS-485
The RS-485 signal controls the device with priority.
Delay
Network Speed Dome User Manual
45
It refers to the me interval of PTZ operaon controlled by dierent signals. When the
operaon with high priority is nished, the low priority signal controls the device aer the
seng interval.
3.
Click Save.
4.11 Set Privacy Mask
Privacy masks cover certain areas on the live image to protect personal privacy from being live
viewed and recorded.
Steps
1.
Go to Conguraon → Image → Privacy Mask .
2.
Check Enable.
3.
Adjust the live image to the target scene via PTZ control
buons.
4.
Draw the area. Click , and click on the live view image to determine the boundary of the
mask.
5.
Click Add.
It is listed in Privacy Mask list.
6.
Edit Name, Type, and
Acve Zoom Rao on your demand.
Acve Zoom Rao
When the actual zoom rao is less than the set acve zoom rao, the set area can not be
covered. When the actual zoom rao is greater than the set acve zoom rao, the privacy
mask is valid. The maximum value of
acve zoom rao depends on the camera module.
Note
Acve zoom rao is only supported for the PTZ channel.
7.
Repeat the steps above to set other privacy masks.
8.
Click Save.
4.12 Set Rapid Focus
Rapid focus is a funcon to reduce me of focusing comparing with that of normal focusing. To use
the funcon, calibraon should be done rst. Rapid focus may not be supported by certain device
models.
Steps
1.
Go to
Conguraon → Image → Rapid Focus .
2.
Add scenes for calibraon.
1) Adjust the live image to a desired scene via PTZ control buons, and click Add.
2) Set the Rate and the
Calibraon Point Amount of the added scene.
Network Speed Dome User Manual
46
Note
More calibraon points may increase calibraon accuracy, but more focusing me is required.
The default amount is recommended.
3.
Select the scene to display the calibraon line.
A red line displays on live image.
4.
Adjust the length and
posion of the line by dragging its two endpoints.
Note
The red line is recommended to stay in the center of the scene and to cover ground at the same
me.
Double click the image to enter full screen mode.
5.
Click Start Calibraon.
Calibraon status displays on the live image.
6.
Repeat to add other scenes and complete the
calibraon.
7.
Check Enable Height Compensaon if the mounng height of the device is lower than 3 meters.
8.
Check Enable aer successful calibraon.
9.
Click Save.
4.13 GPS
Calibraon
GPS calibraon is used to map the geographical locaon to the camera scene so that the device
can calculate the
real-me geographic informaon of targets. This funcon is only supported under
certain VCA resource opons.
4.13.1 Set GPS
Calibraon
Before You Start
Choose at least 4 calibraon points on the ground in the monitoring scene and measure the
precise longitude and
latude of the points. The calibraon points should scaer in a 2 × 2 or 3 × 3
array.
Steps
1.
Go to Conguraon → Calibrate → GPS Calibraon → Calibraon .
Note
The PTZ control is automacally locked to avoid interrupon during conguraon.
2.
Select the longitude and latude type according to device locaon.
3.
Set calibraon points.
1) Adjust the pan, lt, and zoom to nd the scene with a calibraon point.
2) Click
and click on the calibraon point on the live image.
The selected point is zoomed in and placed in the center of the image.
Network Speed Dome User Manual
47
3) Click again.
A green cross shows on the point.
4) Click Add and input the precise longitude and latude of the point.
Note
You must add at least 4 points, otherwise you cannot save the points.
5) Click Save.
6) Repeat the steps to set other
calibraon points.
4.13.2 Verify Calibraon
Before You Start
Choose vericaon points on the ground in the monitoring scene and measure the precise
longitude and
latude of the points.
Steps
1.
Go to Conguraon → Calibrate → GPS Calibraon → Calibraon Vericaon .
Note
The PTZ control is automacally locked to avoid interrupon during conguraon.
2.
Set vericaon points.
1) Adjust the pan, lt, and zoom to nd the scene with a vericaon point.
2) Click
and click on the vericaon point on the live image.
The selected point is zoomed in and placed in the center of the image.
3) Click
again.
A red cross shows on the point.
4) Click Add and input the precise longitude and
latude of the point.
Note
You must add at least 4 points, otherwise you cannot save the points.
5) Click Save.
6) Repeat the steps to set other vericaon points.
Numbered green and blue rectangles are displayed on the image. The blue rectangle marks
the PTZ
posion of the vericaon point you set and the green rectangle marks the calculated
PTZ posion based on the longitude and latude you input. If the two rectangles are close to
each other, then the GPS
calibraon succeeds.
4.14 Set Device
Posion
Before You Start
Go to Conguraon → PTZ → Basic Sengs → PTZ OSD to enable PT Status display.
Network Speed Dome User Manual
48
Steps
1.
Go to Conguraon → System → System Sengs → Locaon .
2.
Select a PT Mode.
Manual Use a direcon indicang device to determine the North at the device locaon, and
set the North for the device. For details, see Set Manual Compass .
3.
Click Calibrate to calibrate gyroscope atude.
Note
Only devices with built-in gyroscope support this funcon.
4.
Select a Longitude-Latude Mode to set the geographic locaon of the device.
Auto For device with a built-in posioning module, select Auto to automacally obtain
the longitude and latude of the device locaon.
Manual Get the device locaon informaon in advance, and input the longitude and
latude manually.
5.
Click Save.
What to do next
If you lose
direcon when operang the device, you can click Point to North to call the north
posion that is saved in the device.
4.14.1 Set Manual Compass
Use a direcon indicang device to determine the North at the device locaon, and set the North
for the device.
Before You Start
Use a direcon indicang device to determine the north at the device locaon.
Steps
1.
Select the PT Mode as Manual.
2.
Adjust the
lt posion of the device to 0 by controling the up arrow and down arrow on the PTZ
panel.
3.
Adjust the pan
posion to show the live view of the north direcon by controling the le arrow
and right arrow on the PTZ panel.
4.
Click Set as North.
Network Speed Dome User Manual
49
Chapter 5 Live View
It introduces the live view parameters, funcon icons and transmission parameters sengs.
5.1 Live View Parameters
The supported funcons vary depending on the model.
5.1.1 Start and Stop Live View
Click Live View. Click to start live view. Click to stop live view.
5.1.2 Aspect
Rao
Aspect Rao is the display rao of the width to height of the image.
●
refers to 4:3 window size.
●
refers to 16:9 window size.
●
refers to original window size.
●
refers to self-adapve window size.
●
refers to original rao window size.
5.1.3 Live View Stream Type
Select the live view stream type according to your needs. For the detailed informaon about the
stream type selecon, refer to Stream Type .
5.1.4 Select the Third-Party Plug-in
When the live view cannot display via certain browsers, you can change the plug-in for live view
according to the browser.
Steps
1.
Click Live View.
2.
Click
to select the plug-in.
-
When you access the device via Internet Explorer, you can select Webcomponents or
QuickTime.
-
When you access the device via the other browsers, you can select Webcomponents,
QuickTime or MJPEG.
Network Speed Dome User Manual
50
5.1.5 Start Digital Zoom
It helps to see a detailed informaon of any region in the image.
Steps
1.
Click to enable the digital zoom.
2.
In live view image, drag the mouse to select the desired region.
3.
Click in the live view image to back to the original image.
5.1.6 Conduct Regional Focus
You can enable the funcon to focus on certain area.
Steps
Note
This funcon varies with the device model.
1.
Click to enable regional focus.
2.
Drag the mouse on the live view to draw a rectangle as the desired focus area.
3.
Click
to disable this funcon.
5.1.7 Conduct Regional Exposure
When the brightness of live view is not balanced, you can enable this funcon to opmize the
exposure of the selected image region.
Steps
1.
Click
to enable regional exposure.
2.
Drag the mouse on the live view to draw a rectangle as the desired exposure area.
3.
Click
to disable this funcon.
5.1.8 Count Pixel
It helps to get the height and width pixel of the selected region in the live view image.
Steps
1.
Click to enable the funcon.
2.
Drag the mouse on the image to select a desired rectangle area.
The width pixel and height pixel are displayed on the boom of the live view image.
Network Speed Dome User Manual
51
5.1.9 Light
Click to turn on or turn o the illuminator.
5.1.10 Operate Wiper
For the device that has a wiper, you can control the wiper via web browser.
Note
Wiper operaon and sengs vary on device models.
Steps
1.
Go to
Conguraon → PTZ → Wiper .
2.
Select a wiper mode.
One
Time
The wiper wipes one me when you click on live view page.
Cycle The wiper works on schedule at set wiping interval. Click on live view to start
wiping.
Duraon
The schedule in which the wiper is ready to work.
Interval
The interval between two successive wiping acons.
Auto
Note
Auto mode is only available for device that supports rain-sensing auto wiper.
In auto mode, the wiper works when rain drops on the window.
5.1.11 Lens Inializaon
Lens inializaon is used on the device equipped with motorized lens. The funcon can reset lens
when long me zoom or focus results in blurred image. This funcon varies according to dierent
models.
Click to operate lens inializaon.
5.1.12 Track Manually
In live view, manually select a target for the device to track.
Network Speed Dome User Manual
52
Note
The funcon may not be supported by certain device models.
Steps
1.
Click on the toolbar of the live view page.
2.
Click a moving object in the live image.
The device tracks the target and keeps it in the center of live view image.
5.1.13 Conduct 3D Posioning
3D posioning is to relocate the selected area to the image center.
Steps
1.
Click to enable the funcon.
2.
Select a target area in live image.
-
Le click on a point on live image: the point is relocated to the center of the live image. With
no zooming in or out eect.
-
Hold and drag the mouse to a lower right
posion to frame an area on the live: the framed
area is zoomed in and relocated to the center of the live image.
-
Hold and drag the mouse to an upper le posion to frame an area on the live: the framed
area is zoomed out and relocated to the center of the live image.
3.
Click the
buon again to turn o the funcon.
5.2 Set Transmission Parameters
The live view image may be displayed abnormally according to the network condions. In dierent
network environments, you can adjust the transmission parameters to solve the problem.
Steps
1.
Go to Conguraon → Local → Live View Parameters .
2.
Set the transmission parameters as required.
Protocol
TCP
TCP ensures complete delivery of streaming data and
beer video quality, yet the real-me
transmission will be aected. It is suitable for the stable network environment.
UDP
UDP is suitable for the unstable network environment that does not demand high video
uency.
MULTICAST
Network Speed Dome User Manual
53
MULTICAST is suitable for the situaon that there are mulple clients. You should set the
mulcast address for them before selecon.
Note
For detailed informaon about mulcast, refer to Mulcast .
HTTP
HTTP is suitable for the
situaon that the third-party needs to get the stream from the
device.
Play Performance
Shortest Delay
The device takes the real-me video image as the priority over the video uency.
Balanced
The device ensures both the
real-me video image and the uency.
Fluent
The device takes the video uency as the priority over teal-me. In poor network
environment, the device cannot ensures video uency even the uency is enabled.
Custom
You can set the frame rate manually. In poor network environment, you can reduce the
frame rate to get a
uent live view. But the rule informaon may cannot display.
3.
Click Save.
Network Speed Dome User Manual
54
Chapter 6 Video and Audio
This part introduces the conguraon of video and audio related parameters.
6.1 Video Sengs
This part introduces the sengs of video parameters, such as, stream type, video encoding, and
resoluon.
Go to seng page: Conguraon → Video/Audio → Video .
6.1.1 Stream Type
For device supports more than one stream, you can specify parameters for each stream type.
Main Stream
The stream stands for the best stream performance the device supports. It usually
oers the
best resoluon and frame rate the device can do. But high resoluon and frame rate usually
means larger storage space and higher bandwidth requirements in transmission.
Sub Stream
The stream usually
oers comparavely low resoluon opons, which consumes less bandwidth
and storage space.
Other Streams
Steams other than the main stream and sub stream may also be oered for customized usage.
6.1.2 Video Type
Select the content (video and audio) that should be contained in the stream.
Video Stream
Only video content is contained in the stream.
Video&Audio
Video content and audio content are contained in the composite stream.
6.1.3
Resoluon
Select video resoluon according to actual needs. Higher resoluon requires higher bandwidth and
storage.
Network Speed Dome User Manual
55
6.1.4 Bitrate Type and Max. Bitrate
Constant Bitrate
It means that the stream is compressed and transmied at a comparavely xed bitrate. The
compression speed is fast, but mosaic may occur on the image.
Variable Bitrate
It means that the device
automacally adjust the bitrate under the set Max. Bitrate. The
compression speed is slower than that of the constant bitrate. But it guarantees the image
quality of complex scenes.
6.1.5 Video Quality
When Bitrate Type is set as Variable, video quality is congurable. Select a video quality according
to actual needs. Note that higher video quality requires higher bandwidth.
6.1.6 Frame Rate
The frame rate is to describe the frequency at which the video stream is updated and it is
measured by frames per second (fps).
A higher frame rate is advantageous when there is movement in the video stream, as it maintains
image quality throughout. Note that higher frame rate requires higher bandwidth and larger
storage space.
6.1.7 Video Encoding
It stands for the compression standard the device adopts for video encoding.
Note
Available compression standards vary according to device models.
H.264
H.264, also known as MPEG-4 Part 10, Advanced Video Coding, is a compression standard. Without
compressing image quality, it increases compression rao and reduces the size of video le than
MJPEG or MPEG-4 Part 2.
Network Speed Dome User Manual
56
H.264+
H.264+ is an improved compression coding technology based on H.264. By enabling H.264+, you
can
esmate the HDD consumpon by its maximum average bitrate. Compared to H.264, H.264+
reduces storage by up to 50% with the same maximum bitrate in most scenes.
When H.264+ is enabled, Max. Average Bitrate is congurable. The device gives a recommended
max. average bitrate by default. You can adjust the parameter to a higher value if the video quality
is less
sasfactory. Max. average bitrate should not be higher than max. bitrate.
Note
When H.264+ is enabled, Video Quality, I Frame Interval, Prole and SVC are not congurable.
H.265
H.265, also known as High Eciency Video Coding (HEVC) and MPEG-H Part 2, is a compression
standard. In comparison to H.264, it oers beer video compression at the same resoluon, frame
rate and image quality.
H.265+
H.265+ is an improved compression coding technology based on H.265. By enabling H.265+, you
can esmate the HDD consumpon by its maximum average bitrate. Compared to H.265, H.265+
reduces storage by up to 50% with the same maximum bitrate in most scenes.
When H.265+ is enabled, Max. Average Bitrate is
congurable. The device gives a recommended
max. average bitrate by default. You can adjust the parameter to a higher value if the video quality
is less
sasfactory. Max. average bitrate should not be higher than max. bitrate.
Note
When H.265+ is enabled, Video Quality, I Frame Interval, Prole and SVC are not congurable.
MJPEG
Moon JPEG (M-JPEG or MJPEG) is a video compression format in which intraframe coding
technology is used. Images in a MJPEG format is compressed as individual JPEG images.
6.1.8
Prole
This funcon means that under the same bitrate, the more complex the prole is, the higher the
quality of the image is, and the requirement for network bandwidth is also higher.
Network Speed Dome User Manual
57
6.1.9 I-Frame Interval
I-frame interval denes the number of frames between 2 I-frames.
In H.264 and H.265, an I-frame, or intra frame, is a self-contained frame that can be independently
decoded without any reference to other images. An I-frame consumes more bits than other
frames. Thus, video with more I-frames, in other words, smaller I-frame interval, generates more
steady and reliable data bits while requiring more storage space.
6.1.10 SVC
Scalable Video Coding (SVC) is the name for the Annex G extension of the H.264 or H.265 video
compression standard.
The objecve of the SVC standardizaon has been to enable the encoding of a high-quality video
bitstream that contains one or more subset bitstreams that can themselves be decoded with a
complexity and
reconstrucon quality similar to that achieved using the exisng H.264 or H.265
design with the same quanty of data as in the subset bitstream. The subset bitstream is derived
by dropping packets from the larger bitstream.
SVC enables forward
compability for older hardware: the same bitstream can be consumed by
basic hardware which can only decode a
low-resoluon subset, while more advanced hardware
will be able decode high quality video stream.
6.1.11 Smoothing
It refers to the smoothness of the stream. The higher value of the smoothing is, the beer uency
of the stream will be, though, the video quality may not be so sasfactory. The lower value of the
smoothing is, the higher quality of the stream will be, though it may appear not
uent.
6.2 Audio
Sengs
It is a funcon to set audio parameters such as audio encoding, environment noise ltering.
Go to the audio sengs page: Conguraon → Video/Audio → Audio .
6.2.1 Audio Input
If a built-in microphone or an external audio pick-up device is available, audio encoding, audio
input mode and input volume are congurable.
Audio Encoding
The device oers several compression standard. Select according to your need.
Network Speed Dome User Manual
58
Audio Input
Select MicIn for the built-in microphone, and LineIn for external audio pick-up device.
Note
MicIn is only supported by certain models.
Input Volume
Adjust the volume of the audio input.
Environmental Noise Filter
Set it as OFF or ON. When the funcon is enabled, the noise in the environment can be ltered
to some extent.
6.2.2 Audio Output
You can output audio through line out. You can adjust the output volume according to your needs.
Note
●
Connect audio output device according to your needs.
●
This funcon is only supported by certain models.
6.2.3 Environmental Noise Filter
Set it as OFF or ON. When the funcon is enabled, the noise in the environment can be ltered to
some extent.
6.3 Two-way Audio
It is used to realize the two-way audio funcon between the monitoring center and the target in
the monitoring screen.
Before You Start
●
Make sure the audio input device (pick-up or microphone) and audio output device (speaker)
connected to the device is working properly. Refer to
specicaons of audio input and output
devices for device connecon.
●
If the device has built-in microphone and speaker, two-way audio
funcon can be enabled
directly.
Steps
1.
Click Live View.
2.
Click
on the toolbar to enable two-way audio funcon of the camera.
3.
Click , disable the two-way audio funcon.
Network Speed Dome User Manual
59
6.4 ROI
ROI (Region of Interest) encoding helps to discriminate the ROI and background informaon in
video compression. The technology assigns more encoding resource to the region of interest, thus
to increase the quality of the ROI whereas the background informaon is less focused.
6.4.1 Set ROI
ROI (Region of Interest) encoding helps to assign more encoding resource to the region of interest,
thus to increase the quality of the ROI whereas the background
informaon is less focused.
Before You Start
Please check the video coding type. ROI is supported when the video coding type is H.264 or H.
265.
Steps
1.
Go to
Conguraon → Video/Audio → ROI .
2.
Check Enable.
3.
Select Stream Type.
4.
Select Region No. and click
to draw ROI region on the view screen .
Note
Select the xed region that needs to be adjusted and drag the mouse to adjust its posion.
5.
Input the Region Name and ROI Level.
6.
Click Save.
Note
The higher the ROI level is, the clearer the image of the detected region is.
7.
Oponal: Select other region No. and repeat the above steps if you need to draw mulple xed
regions.
6.5 Target Cropping
You can crop the image, transmit and save only the images of the target area to save transmission
bandwidth and storage.
Steps
1.
Go to
Conguraon → Video/Audio → Target Cropping .
2.
Check Enable.
3.
Select a Cropping
Resoluon.
Cropping Resoluon
Cropping resoluon is the main stream resoluon aer target cropping.
Network Speed Dome User Manual
60
A red frame appears in the live view.
4.
Drag the frame to the target area.
5.
Click Save.
Note
●
Some models support target cropping. Refer to the actual device for details.
●
This funcon is mutually exclusive with some funcons. Aer enabling target cropping, some
funcons will fail. Refer to the actual device for details.
6.6 Display Info. on Stream
The informaon of the objects (e.g. human, vehicle, etc.) is marked in the video stream. You can
set rules on the connected rear-end device or client
soware to detect the events including line
crossing, intrusion, etc.
Before You Start
This
funcon is supported in smart events. Go to the VCA Resource page to enable Smart Event.
Steps
1.
Go to Conguraon → Video/Audio → Display Info. on Stream .
2.
Check Enable Dual-VCA.
3.
Click Save.
6.7 Display
Sengs
It oers the parameter sengs to adjust image features.
Go to
Conguraon → Image → Display Sengs .
Click Default to restore sengs.
6.7.1 Scene Mode
There are several sets of image parameters predened for dierent installaon environments.
Select a scene according to the actual installaon environment to speed up the display sengs.
Image Adjustment
By adjusng the Brightness, Saturaon, Contrast and Sharpness, the image can be best displayed.
Network Speed Dome User Manual
61
Exposure Sengs
Exposure is controlled by the combinaon of iris, shuer, and gain. You can adjust image eect by
seng exposure parameters.
Exposure Mode
Auto
The iris, shuer, and gain values are adjusted automacally.
You can limit the changing ranges of iris, shuer and gain by seng Max. Iris Limit, Min. Iris
Limit, Max. Shuer Limit, Min. Shuer Limit and Limit Gain for beer exposure eect.
Iris Priority
The value of iris needs to be adjusted manually. The shuer and gain values are adjusted
automacally according to the brightness of the environment.
You can limit the changing ranges of the
shuer and gain by seng Max. Shuer Limit, Min.
Shuer Limit and Limit Gain for beer exposure eect.
Shuer Priority
The value of shuer needs to be adjusted manually. The iris and gain values are adjusted
automacally according to the brightness of the environment.
You can limit the changing ranges of the iris by seng Max. Iris Limit, Min. Iris Limit and
Limit Gain for beer exposure eect.
Manual
You need to set Iris,
Shuer, and Gain manually.
Slow Shuer
The higher the slow shuer level is, the slower the shuer speed is. It ensures full exposure in
underexposure condion.
Focus
It oers opons to adjust the focus mode and the minimum focus distance.
Focus Mode
Auto
The device focuses automacally as the scene changes. If you cannot get a well-focused
image under auto mode, reduce light sources in the image and avoid
ashing lights.
Semi-auto
The device focuses once aer the PTZ and lens zooming. If the image is clear, the focus does
not change when the scene changes.
Manual
You can adjust the focus manually on the live view page.
Network Speed Dome User Manual
62
Min. Focus Distance
When the distance between the scene and lens is shorter than the Min. Focus Distance, the lens
does not focus.
Compable
This mode is only recommended for indoor devices with a bubble when you cannot get a
clear image with other opons.
Day/Night Switch
Day/Night Switch
funcon can provide color images in the day mode and black/white images in the
night mode. Switch mode is
congurable.
Day
The image is always in color.
Night
The image is always black/white
Auto
The camera switches between the day mode and the night mode according to the illuminaon
automacally.
Scheduled-Switch
Set the Start Time and the End Time to dene the duraon for day mode.
Note
Day/Night Switch funcon varies according to models.
Set Supplement Light
Steps
1.
Go to Conguraon → System → System Sengs → System Service .
2.
Check Enable Supplement Light.
3.
Click Save.
4.
Go to
Conguraon → Image → Display Sengs → Day/Night Switch to set supplement light
parameters.
Smart Supplement Light
This feature uses smart image processing technology to reduce overexposure caused by
supplement light.
IR Light Mode
When the mode is set to Auto, the supplement light is
automacally turned in or o
according to the image brightness.
Network Speed Dome User Manual
63
Brightness Limit
Adjust the upper limit of supplement light power. For devices with both white light and IR
light, white light and IR light brightness limit can be set separately.
Note
The funcon varies on device sengs and device models.
BLC
If you focus on an object against strong backlight, the object will be too dark to be seen clearly. BLC
(backlight compensaon) compensates light to the object in the front to make it clear. If BLC mode
is set as Custom, you can draw a red rectangle on the live view image as the BLC area.
HLC
When the bright area of the image is over-exposed and the dark area is under-exposed, the HLC
(High Light Compression)
funcon can be enabled to weaken the bright area and brighten the dark
area, so as to achieve the light balance of the overall picture.
WDR
The WDR (Wide Dynamic Range) funcon helps the camera provide clear images in environment
with strong illuminaon dierences.
When there are both very bright and very dark areas simultaneously in the eld of view, you can
enable the WDR funcon and set the level. WDR automacally balances the brightness level of the
whole image and provides clear images with more details.
Note
When WDR is enabled, some other funcons may be not supported. Refer to the actual interface
for details.
DNR
Digital Noise Reducon is used to reduce the image noise and improve the image quality. Normal
and Expert modes are selectable.
Normal
Set the DNR level to control the noise
reducon degree. The higher level means stronger
reducon degree.
Expert
Network Speed Dome User Manual
64
Set the DNR level for both space DNR and me DNR to control the noise reducon degree. The
higher level means stronger reducon degree.
White Balance
White balance is the white rendion funcon of the camera. It is used to adjust the color
temperature according to the environment.
Defog
You can enable the defog funcon when the environment is foggy and the image is misty. It
enhances the subtle details so that the image appears clearer.
EIS
Increase the stability of video image by using jier compensaon technology.
6.7.2 Image Parameters Switch
The device automacally switches image parameters in set me periods.
Go to image parameters switch
seng page: Conguraon → Image → Display Sengs → Image
Parameters Switch , and set parameters as needed.
Set Scheduled-switch
Switch the image to the linked scene mode automacally in certain me periods.
Steps
1.
Check Scheduled-switch.
2.
Select and congure the corresponding me period and linked scene mode.
Note
For Linked Scene conguraon, refer to Scene Mode .
3.
Click Save.
Set Link to Preset
You can set a preset to switch the image to a linked scene.
Steps
1.
Check Link to Preset.
Network Speed Dome User Manual
65
2.
Select a preset.
3.
Check and set a me period and a linked scene mode.
4.
Click Save.
6.7.3 Mirror
When the live view image is the reverse of the actual scene, this funcon helps to display the
image normally.
Select the mirror mode as needed.
Note
The video recording will be shortly interrupted when the funcon is enabled.
6.7.4 Video Standard
Video standard is an ability of a video card or video display device that denes the amount of
colors that are shown and the resoluon. The two most common video standard used are NTSC
and PAL. In NTSC, 30 frames are transmied each second. Each frame is made up of 525 individual
scan lines. In PAL, 25 frames are
transmied each second. Each frame is made up of 625 individual
scan lines. Select video signal standard according to the video system in your country/region.
6.8 OSD
You can customize OSD (On-screen Display) informaon such as device name, me/date, font,
color, and text overlay displayed on video stream.
Go to OSD
seng page: Conguraon → Image → OSD Sengs . Set the corresponding
parameters, and click Save to take
eect.
Character Set
Select character set for displayed informaon. If Korean is required to displayed on screen, select
EUC-KR. Otherwise, select GBK.
Display
Set camera name, date, week, and their related display formats.
Format
Sengs
Set OSD parameters, such as Display Mode, OSD Size, Font Color, and Alignment.
Text Overlay
Set customized overlay text on image.
Network Speed Dome User Manual
66
Chapter 7 Video Recording and Picture Capture
This part introduces the operaons of capturing video clips and snapshots, playback, and
downloading captured
les.
7.1 Storage Sengs
This part introduces the conguraon of several common storage paths.
7.1.1 Memory Card
You can view the capacity, free space, status, type, and property of the memory card. Encrypon of
memory card is supported to ensure data security.
Set New or Unencrypted Memory Card
Before You Start
Insert a new or unencrypted memory card to the device. For detailed installaon, refer to Quick
Start Guide of the device.
Steps
1.
Go to
Conguraon → Storage → Storage Management → HDD Management .
2.
Select the memory card.
Note
If an Unlock buon appears, you need to unlock the memory card rst. See Detect Memory
Card Status for details.
3.
Click Format to inialize the memory card.
When the Status of memory card turns from Uninialized to Normal, the memory card is ready
for use.
4.
Oponal: Encrypt the memory card.
1) Click Encrypted Format.
2) Set the
encrypon password.
3) Click OK.
When the
Encrypon Status turns to Encrypted, the memory card is ready for use.
Note
Keep your encrypon password properly. Encrypon password cannot be found if forgoen.
5.
Oponal: Dene the Quota of the memory card. Input the percentage for storing dierent
contents according to your needs.
Network Speed Dome User Manual
67
6.
Click Save.
Set Encrypted Memory Card
Before You Start
●
Insert an encrypted memory card to the device. For detailed
installaon, refer to Quick Start
Guide of the device.
●
You need to know the correct encrypon password of the memory card.
Steps
1.
Go to Conguraon → Storage → Storage Management → HDD Management .
2.
Select the memory card.
Note
If an Unlock buon appears, you need to unlock the memory card rst. See Detect Memory
Card Status for details.
3.
Verify the encrypon password.
1) Click Parity.
2) Enter the
encrypon password.
3) Click OK.
When the
Encrypon Status turns to Encrypted, the memory card is ready for use.
Note
If the encrypon password is forgoen and you sll want to use this memory card, see Set New
or Unencrypted Memory Card to format and set the memory card. All exisng contents will be
removed.
4.
Oponal: Dene the Quota of the memory card. Input the percentage for storing dierent
contents according to your needs.
5.
Click Save.
Detect Memory Card Status
The device detects the status of Hikvision memory card. You receive nocaons when your
memory card is detected abnormal.
Before You Start
The
conguraon page only appears when a Hikvision memory card is installed to the device.
Steps
1.
Go to Conguraon → Storage → Storage Management → Memory Card Detecon .
2.
Click Status Detecon to check the Remaining Lifespan and Health Status of your memory card.
Remaining Lifespan
Network Speed Dome User Manual
68
It shows the percentage of the remaining lifespan. The lifespan of a memory card may be
inuenced by factors such as its capacity and the bitrate. You need to change the memory
card if the remaining lifespan is not enough.
Health Status
It shows the condion of your memory card. You will receive a nocaon if the health status
is anything other than good when the Arming Schedule and Linkage Method are set.
Note
It is recommended that you change the memory card when the health status is not "good".
3.
Click R/W Lock to set the permission of reading and wring to the memory card.
-
Add a Lock
a. Select the Lock Switch as ON.
b. Enter the password.
c. Click Save
-
Unlock
●
If you use the memory card on the device that locks it, unlocking will be done automacally
and no unlocking procedures are required on the part of users.
●
If you use the memory card (with a lock) on a
dierent device, you can go to HDD
Management to unlock the memory card manually. Select the memory card, and click
Unlock. Enter the correct password to unlock it.
-
Remove the Lock
a. Select the Lock Switch as OFF.
b. Enter the password in Password
Sengs.
c. Click Save.
Note
●
Only admin user can set the R/W Lock.
●
The memory card can only be read and wrien when it is unlocked.
●
If the device, which adds a lock to a memory card, is restored to the factory sengs, you can
go to HDD Management to unlock the memory card.
4.
Set Arming Schedule and Linkage Method. See Set Arming Schedule and Linkage Method
Sengs for details.
5.
Click Save.
7.1.2 Set FTP
You can
congure the FTP server to save images which are captured by events or a med snapshot
task.
Before You Start
Get the FTP server address
rst.
Network Speed Dome User Manual
69
Steps
1.
Go to Conguraon → Event → Alarm Seng → FTP .
2.
Congure FTP sengs.
Server Address and Port
The FTP server address and corresponding port.
User Name and Password
The FTP user should have the permission to upload pictures.
If the FTP server supports picture uploading by anonymous users, you can check Anonymous
to hide your device informaon during uploading.
Directory Structure
The saving path of snapshots in the FTP server.
3.
Oponal: Check Upload Picture to enable uploading snapshots to the FTP server.
Picture Filing Interval
For beer picture management, you can set the picture ling interval from 1 day to 30 days.
Pictures captured in the same me interval will be saved in one folder named aer the
beginning date and ending date of the
me interval.
Picture Name
Set the naming rule for captured pictures. You can choose Default in the drop-down list to
use the default rule, that is, IP address_channel number_capture me_event type.jpg (e.g.,
10.11.37.189_01_20150917094425492_FACE_DETECTION.jpg). Or you can customize it by
adding a Custom
Prex to the default naming rule.
4.
Oponal: Check Enable Automac Network Replenishment.
Note
Upload to FTP/Memory Card/NAS in Linkage Method and Enable Automac Network
Replenishment should be both enabled simultaneously.
5.
Click Test to verify the FTP server.
6.
Click Save.
7.1.3 Set NAS
Take network server as network disk to store the record les, captured images, etc.
Before You Start
Get the IP address of the network disk rst.
Steps
1.
Go to NAS seng page: Conguraon → Storage → Storage Management → Net HDD .
2.
Click Add.
3.
Set
Mounng Type.
Network Speed Dome User Manual
70
Mounng Type
Select le system protocol according to the operaon system.
Enter user name and password of the net HDD to guarantee the security if SMB/CIFS is
selected.
4.
Set the Server Address and File Path for the disk.
Server Address
The IP address of the network disk.
File Path
The saving path of network disk
les.
5.
Click Test to check whether the network disk is available.
6.
Click OK to
nish the steps to add a Net HDD.
7.
Oponal: Congure the Net HDD.
Modify Click to modify the parameter seng.
Delete Delete the Net HDD.
●
Click .
●
Select the Net HDD, click Delete.
8.
Click Save.
7.1.4 eMMC
Protecon
It is to automacally stop the use of eMMC as a storage media when its health status is poor.
Note
The eMMC protecon is only supported by certain device models with an eMMC hardware.
Go to Conguraon → System → Maintenance → System Service for the sengs.
eMMC, short for embedded mulmedia card, is an embedded non-volale memory system. It is
able to store the captured images or videos of the device.
The device monitors the eMMC health status and turns
o the eMMC when its status is poor.
Otherwise, using a worn-out eMMC may lead to device boot failure.
7.1.5 Set Cloud Storage
It helps to upload the captured pictures and data to the cloud. The
plaorm requests picture
directly from the cloud for picture and analysis. The funcon is only supported by certain models.
Network Speed Dome User Manual
71
Steps
Cauon
If the cloud storage is enabled, the pictures are stored in the cloud video manager rstly.
1.
Go to Conguraon → Storage → Storage Management → Cloud Storage .
2.
Check Enable.
3.
Set basic parameters.
Protocol Version The protocol version of the cloud video manager.
Server IP The IP address of the cloud video manager. It supports IPv4 address.
Serve Port The port of the cloud video manager. You are recommended to use the
default port.
AccessKey The key to log in to the cloud video manager.
SecretKey The key to encrypt the data stored in the cloud video manager.
User Name and
Password
The user name and password of the cloud video manager.
Picture Storage
Pool ID
The ID of the picture storage region in the cloud video manager. Make
sure storage pool ID and the storage region ID are the same.
4.
Click Test to test the congured sengs.
5.
Click Save.
7.2 Video Recording
This part introduces the operaons of manual and scheduled recording, playback, and
downloading recorded les.
7.2.1 Record
Automacally
This funcon can record video automacally during congured me periods.
Before You Start
Select Trigger Recording in event sengs for each record type except Connuous. See Event and
Alarm for details.
Steps
1.
Go to
Conguraon → Storage → Schedule Sengs → Record Schedule .
2.
Check Enable.
3.
Select a record type.
Network Speed Dome User Manual
72
Note
The record type is vary according to dierent models.
Connuous
The video will be recorded connuously according to the schedule.
Moon
When moon detecon is enabled and trigger recording is selected as linkage method, object
movement is recorded.
Alarm
When alarm input is enabled and trigger recording is selected as linkage method, the video is
recorded
aer receiving alarm signal from external alarm input device.
Moon | Alarm
Video is recorded when moon is detected or alarm signal is received from the external
alarm input device.
Moon & Alarm
Video is recorded only when moon is detected and alarm signal is received from the
external alarm input device.
Event
The video is recorded when congured event is detected.
4.
Set schedule for the selected record type. Refer to
Set Arming Schedule for the seng
operaon.
5.
Set the advanced recording parameters.
Overwrite
Enable Overwrite to overwrite the video records when the storage space is full. Otherwise
the camera cannot record new videos.
Pre-record
The
me period you set to record before the scheduled me.
Post-record
The me period you set to stop recording aer the scheduled me.
Stream Type
Select the stream type for recording.
Note
When you select the stream type with higher bitrate, the actual me of the pre-record and
post-record may be less than the set value.
Recording Expiraon
Network Speed Dome User Manual
73
The recordings are deleted when they exceed the expired me. The expired me is
congurable. Note that once the recordings are deleted, they can not be recovered.
6.
Click Save.
7.2.2 Record Manually
Steps
1.
Go to Conguraon → Local .
2.
Set the Record File Size and saving path to for recorded les.
3.
Click Save.
4.
Click in the live view interface to start recording. Click to stop recording.
7.2.3 Playback and Download Video
You can search, playback, clip and download the videos stored in the local storage or network
storage.
Steps
1.
Go to Playback → Video .
2.
Set search
condion and click Search.
The matched video les showed on the ming bar.
3.
Click
to play the video les.
-
Click to play video les in full screen. Press ESC to exit full screen.
-
Click
to stop video playback for all channels.
4.
Oponal: Click to clip video les. Click again to stop clipping video les
Note
Go to Conguraon → Local → Save clips to , view and change the saving path of clipped video
les.
5.
Oponal: Click on the playback interface to download les.
Note
Go to Conguraon → Local → Save downloaded les to , view and change the saving path of
downloaded video les.
7.3 Capture Conguraon
The device can capture the pictures manually or automacally and save them in congured saving
path. You can view and download the snapshots.
Network Speed Dome User Manual
74
7.3.1 Capture Automacally
This funcon can capture pictures automacally during congured me periods.
Before You Start
If event-triggered capture is required, you should congure related linkage methods in event
sengs. Refer to Event and Alarm for event sengs.
Steps
1.
Go to Conguraon → Storage → Schedule Sengs → Capture .
2.
Set capture schedule. Refer to
Set Arming Schedule for conguring schedule me.
Figure 7-1 Set Capture Schedule
3.
Set the capture type.
Scheduled
Capture a picture at the
congured me interval.
Event-Triggered
Capture a picture when an event is triggered.
4.
Set the Format,
Resoluon, Quality, Interval, and Capture Number.
Note
The resoluon of the captured picture is the same as the resoluon of the captured picture
stream. You can select Stream Type in Advanced.
5.
Click Save.
7.3.2 Capture Manually
Steps
1.
Go to Conguraon → Local .
2.
Set the Image Format and saving path to for snapshots.
JPEG
The picture size of this format is
comparavely small, which is beer for network
transmission.
BMP
Network Speed Dome User Manual
75
The picture is compressed with good quality.
3.
Click Save.
4.
Click near the live view or play back window to capture a picture manually.
7.3.3 View and Download Picture
You can search, view and download the pictures stored in the local storage or network storage.
Steps
1.
Go to Playback → Picture .
2.
Set search condion and click Search.
The matched pictures showed in the le list.
3.
Download the pictures.
-
Select the pictures then click Download to download them.
-
Click Download This Page to download the pictures of this page.
-
Click Download All to download all the pictures.
Note
Go to Conguraon → Local → Save snapshots when playback to , view and change the saving
path of captured pictures when playback.
Network Speed Dome User Manual
76
Chapter 8 Event and Alarm
This part introduces the conguraon of events. The device takes certain response to triggered
alarm.
8.1 Basic Event
8.1.1 Set Moon Detecon
This funcon detects moving objects in the detecon region and trigger linkage acons.
Steps
1.
Go to
Conguraon → Event → Event and Detecon → Moon Detecon .
2.
Check Enable.
3.
Oponal: (Only available in PTZ channel) Check Enable Moon Detecon in PTZ Control, and
the device detects moving targets in PTZ movement.
4.
Oponal: Highlight moving objects in green.
1) Check Enable Dynamic Analysis for Moon.
2) Go to
Conguraon → Local to enable Rules.
5.
Select conguraon mode. Normal mode and expert mode are selectable.
-
For the informaon about normal mode, see Normal Mode .
-
For the
informaon about expert mode, see Expert Mode .
6.
Set the arming schedule. See Set Arming Schedule for details.
7.
Set linkage methods. See
Linkage Method Sengs for details.
8.
Click Save.
Normal Mode
You can set moon detecon parameters according to the device default parameters.
Steps
1.
Select normal mode in Conguraon.
2.
Set the
sensivity of normal mode. The higher the value of sensivity is, the more sensive the
moon detecon is. If the sensivity is set to 0, moon detecon and dynamic analysis do not
take eect.
3.
Click . Click and drag the mouse on the live video, then release the mouse to nish drawing
one area.
Network Speed Dome User Manual
77
Figure 8-1 Set Rules
4.
Oponal: Click to clear all the areas.
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
Expert Mode
You can congure dierent moon detecon parameters for day and night according to the actual
needs.
Steps
1.
Select Expert Mode in Conguraon.
2.
Set parameters of expert mode.
Scheduled Image
Sengs
OFF
Image switch is disabled.
Auto-Switch
The system switches day/night mode automacally according to environment. It displays
colored image at day and black and white image at night.
Scheduled-Switch
The system switches day/night mode according to the schedule. It switches to day mode
during the set periods and switches to night mode during the other periods.
Sensivity
Network Speed Dome User Manual
78
The higher the value of sensivity is, the more sensive the moon detecon is. If scheduled
image sengs is enabled, the sensivity of day and night can be set separately.
3.
Select an Area and click . Click and drag the mouse on the live image and then release the
mouse to
nish drawing one area.
Figure 8-2 Set Rules
4.
Click to clear all the areas.
5.
Click Save.
6.
Oponal: Repeat above steps to set mulple areas.
8.1.2 Set Video Tampering Alarm
When the congured area is covered and cannot be monitored normally, the alarm is triggered and
the device takes certain alarm response
acons.
Steps
1.
Go to
Conguraon → Event → Event and Detecon → Video Tampering .
2.
Check Enable.
3.
Set the
Sensivity. The higher the value is, the easier to detect the area covering.
4.
Click and drag the mouse in the live view to draw the area.
Network Speed Dome User Manual
79
Figure 8-3 Set Video Tampering Area
5.
Oponal: Click to delete all the drawn areas.
6.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
7.
Click Save.
8.1.3 Set Alarm Input
Alarm signal from the external device triggers the corresponding acons of the current device.
Before You Start
Note
This funcon is only supported by certain models.
Make sure the external alarm device is connected. See Quick Start Guide for cable connecon.
Network Speed Dome User Manual
80
Steps
1.
Go to Conguraon → Event → Event and Detecon → Alarm Input .
2.
Check Enable Alarm Input Handling.
3.
Select an Alarm Input NO. and click
to set alarm input.
4.
Select Alarm Type from the dropdown list. Edit the Alarm Name.
5.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
6.
Click Save.
8.1.4 Set Excepon Alarm
Excepon such as network disconnecon can trigger the device to take corresponding acon.
Steps
1.
Go to Conguraon → Event → Event and Detecon → Excepon .
2.
Select Excepon Type.
HDD Full
The HDD storage is full.
HDD Error
Error occurs in HDD.
Network Disconnected
The device is
oine.
IP Address Conicted
The IP address of current device is same as that of other device in the network.
Illegal Login
Incorrect user name or password is entered.
Abnormal Reboot
The device reboots abnormally.
3.
Refer to Linkage Method Sengs for seng linkage method.
4.
Click Save.
8.1.5 Detect Audio
Excepon
Audio excepon detecon funcon detects the abnormal sound in the scene, such as the sudden
increase/decrease of the sound intensity, and some certain
acons can be taken as response.
Steps
1.
Go to Conguraon → Event → Event and Detecon → Audio Excepon Detecon .
2.
Select one or several audio excepon detecon types.
Network Speed Dome User Manual
81
Audio Loss Detecon
Detect sudden loss of audio track.
Sudden Increase of Sound Intensity Detecon
Detect sudden increase of sound intensity. Sensivity and Sound Intensity Threshold are
congurable.
Note
●
The lower the sensivity is, the more signicant the change should be to trigger the
detecon.
●
The sound intensity threshold refers to the sound intensity reference for the detecon. It is
recommended to set as the average sound intensity in the environment. The louder the
environment sound, the higher the value should be. You can adjust it according to the real
environment.
Sudden Decrease of Sound Intensity Detecon
Detect sudden decrease of sound intensity. Sensivity is congurable.
3.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage methods.
4.
Click Save.
Note
The funcon is only supported by certain models. The actual funcon varies according to
dierent models.
8.1.6 Set Vandal-proof Alarm
The device triggers alarms when its posion changes because of shock or vandalism.
Steps
1.
Go to Conguraon → Event → Event and Detecon → Vandal-proof Alarm .
2.
Set vandal-proof alarm parameters.
Sensivity
The higher the value is, the easier the alarm will be triggered.
Upload Vandal-proof Alarm
The device uploads the alarm informaon when the alarm is triggered.
Vandal-proof Alarm Voice Warning
The camera triggers the alarm with audible warning.
3.
Click Save to save the sengs.
Network Speed Dome User Manual
82
8.2 Smart Event
Note
●
The funcon varies according to dierent models.
●
To enable this funcon, you may need to select Smart Event on VCA Resource page. For certain
models, this funcon is supported in the Single Channel mode. See for details.
●
For certain models, when the smart events are in use, the EIS is unavailable.
8.2.1 Set Intrusion Detecon
Intrusion detecon detects the object movement of entering and loitering in a predened area.
When intrusion occurs, the device takes linkage
acons as response.
Before You Start
Go to VCA → Select Applicaon to select Smart Event, and click Next to enable the funcon.
Steps
1.
Go to VCA → Set
Applicaon → Smart Event → Intrusion Detecon .
2.
Check Enable.
3.
Oponal: Click to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
4.
Adjust the live image to the desired scene by using PTZ control buons.
5.
Draw detecon area.
1) Click .
2) Click on the live image to draw the boundaries of the
detecon area, and right click to
complete drawing.
6.
Oponal: Set the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the detecon.
1) Click , and drag the mouse on live image. If you want to change the size, click the buon
and draw again.
2) Click
, and drag the mouse on the live image. If you want to change the size, click the
buon and draw again.
7.
Set
detecon parameters.
Sensivity
It stands for the sensivity of detecng an target. The higher the value of
sensivity is, the more easily the target is detected.
Threshold Threshold stands for the me of the target loitering in the region. If the me
that she/he stays in the region exceeds the threshold, the alarm is triggered.
Network Speed Dome User Manual
83
Detecon
Target
You can specify the object type, and the device only detects the selected
type of objects.
Figure 8-4 Draw Area
8.
Click Save.
9.
Oponal: Click Add, and repeat above steps to set other rules.
Note
Up to 4 rules can be set.
10.
Set arming schedule. See Set Arming Schedule .
11.
Set linkage method. See Linkage Method Sengs .
8.2.2 Set Line Crossing
Detecon
Line crossing detecon is used to detect the object movement of crossing a predened line. When
it occurs, the device takes linkage acons as response.
Before You Start
Go to VCA → Select
Applicaon to select Smart Event, and click Next to enable the funcon.
Steps
1.
Go to VCA → Set
Applicaon → Smart Event → Line Crossing Detecon .
2.
Check Enable.
3.
Oponal: Click to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Network Speed Dome User Manual
84
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
4.
Adjust the live image to the desired scene by using PTZ control buons.
5.
Draw detecon line.
1) Select a Line No.. Up to 4 lines can be set in the scene.
2) Click .
A yellow line is displayed on live image.
3) Click on the line, and drag its end points to adjust the length and posion.
4) Select the Direcon for the detecon line.
Direcon
It stands for the direcon from which the object goes across the line.
A<->B
The object going across the line from both
direcons can be detected and alarms are
triggered.
A->B
Only the object crossing the congured line from side A to side B can be detected.
B->A
Only the object crossing the congured line from side B to side A can be detected.
Figure 8-5 Draw Line
6.
Oponal: Set the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the
detecon.
Network Speed Dome User Manual
85
1) Click , and drag the mouse on live image. If you want to change the size, click the buon
and draw again.
2) Click , and drag the mouse on the live image. If you want to change the size, click the
buon and draw again.
7.
Set
detecon parameters.
Sensivity It stands for the sensivity of detecng an target. The higher the value is,
the more easily the target is detected.
Detecon
Target
You can specify the object type, and the device only detects the selected
type of objects.
8.
Click Save.
9.
Oponal: Click Add, and repeat above steps to set other rules.
Note
Up to 4 rules can be set.
10.
Set arming schedule. See Set Arming Schedule .
11.
Set linkage method. See Linkage Method Sengs .
8.2.3 Set Region Entrance
Detecon
Region entrance detecon is used to detect the object movement of entering a predened area.
When it occurs, the device takes linkage acons as response.
Before You Start
Go to VCA → Select Applicaon to select Smart Event, and click Next to enable the funcon.
Steps
1.
Go to VCA → Set Applicaon → Smart Event → Region Entrance Detecon .
2.
Check Enable.
3.
Oponal: Click to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
4.
Adjust the live image to the desired scene by using PTZ control
buons.
5.
Draw detecon area.
1) Click
.
2) Click on the live image to draw the boundaries of the detecon area, and right click to
complete drawing.
6.
Oponal: Set the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the
detecon.
1) Click , and drag the mouse on live image. If you want to change the size, click the buon
and draw again.
Network Speed Dome User Manual
86
2) Click , and drag the mouse on the live image. If you want to change the size, click the
buon and draw again.
7.
Set detecon parameters.
Sensivity It stands for the sensivity of detecng an target. The higher the value is,
the more easily the target is detected.
Detecon
Target
You can specify the object type, and the device only detects the selected
type of objects.
Figure 8-6 Draw Area
8.
Click Save.
9.
Oponal: Click Add, and repeat above steps to set other rules.
Note
Up to 4 rules can be set.
10.
Set arming schedule. See Set Arming Schedule .
11.
Set linkage method. See
Linkage Method Sengs .
8.2.4 Set Region
Exing Detecon
Region exing detecon is used to detect the objects movement of exing from a predened area.
When it occurs, the device takes linkage acons as response.
Before You Start
Go to VCA → Select Applicaon to select Smart Event, and click Next to enable the funcon.
Network Speed Dome User Manual
87
Steps
1.
Go to VCA → Set Applicaon → Smart Event → Region Exing Detecon .
2.
Check Enable.
3.
Oponal: Click to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
4.
Adjust the live image to the desired scene by using PTZ control buons.
5.
Draw detecon area.
1) Click .
2) Click on the live image to draw the boundaries of the
detecon area, and right click to
complete drawing.
6.
Oponal: Set the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the detecon.
1) Click , and drag the mouse on live image. If you want to change the size, click the buon
and draw again.
2) Click , and drag the mouse on the live image. If you want to change the size, click the
buon and draw again.
7.
Set
detecon parameters.
Sensivity
It stands for the sensivity of detecng an target. The higher the value is,
the more easily the target is detected.
Detecon
Target
You can specify the object type, and the device only detects the selected
type of objects.
Network Speed Dome User Manual
88
Figure 8-7 Draw Area
8.
Click Save.
9.
Oponal: Click Add, and repeat above steps to set other rules.
Note
Up to 4 rules can be set.
10.
Set arming schedule. See Set Arming Schedule .
11.
Set linkage method. See
Linkage Method Sengs .
8.2.5 Set Object Removal
Detecon
Object removal detecon detects whether the objects are removed from the predened detecon
area, such as exhibits on display. When it occurs, the device takes linkage acons as response.
Before You Start
Go to VCA → Select Applicaon to select Smart Event, and click Next to enable the funcon.
Steps
1.
Go to VCA → Set Applicaon → Smart Event → Object Removal Detecon .
2.
Check Enable.
3.
Oponal: Click to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
4.
Adjust the live image to the desired scene by using PTZ control
buons.
Network Speed Dome User Manual
89
5.
Draw detecon area.
1) Click .
2) Click on the live image to draw the boundaries of the detecon area, and right click to
complete drawing.
6.
Oponal: Set the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the detecon.
1) Click , and drag the mouse on live image. If you want to change the size, click the buon
and draw again.
2) Click , and drag the mouse on the live image. If you want to change the size, click the
buon and draw again.
7.
Set detecon parameters.
Sensivity The value of the sensivity denes the size of the object which can trigger the
alarm, when the sensivity is high, a very small object can trigger the alarm.
Threshold The threshold is the me of the objects removed from the area. If you set the
value as 10, alarm is triggered aer the object disappears from the area for 10
seconds.
Figure 8-8 Draw Area
8.
Click Save.
9.
Oponal: Click Add, and repeat above steps to set other rules.
Note
Up to 4 rules can be set.
10.
Set arming schedule. See Set Arming Schedule .
Network Speed Dome User Manual
90
11.
Set linkage method. See Linkage Method Sengs .
8.2.6 Set Unaended Baggage Detecon
Unaended baggage detecon is used to detect the objects le over in the predened area.
Linkage methods are triggered aer the object is le and stays in the area for a set me period.
Before You Start
Go to VCA → Select Applicaon to select Smart Event, and click Next to enable the funcon.
Steps
1.
Go to VCA → Set
Applicaon → Smart Event → Unaended Baggage Detecon .
2.
Check Enable.
3.
Oponal: Click to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
4.
Adjust the live image to the desired scene by using PTZ control
buons.
5.
Draw detecon area.
1) Click .
2) Click on the live image to draw the boundaries of the
detecon area, and right click to
complete drawing.
6.
Oponal: Set the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the
detecon.
1) Click , and drag the mouse on live image. If you want to change the size, click the buon
and draw again.
2) Click
, and drag the mouse on the live image. If you want to change the size, click the
buon and draw again.
7.
Set
detecon parameters.
Sensivity
The value of the sensivity denes the size of the object which can trigger the
alarm, when the sensivity is high, a very small object can trigger the alarm.
Threshold It stands for the me of the objects le in the area. Alarm is triggered aer the
object is le and stays in the area for the set me period.
Network Speed Dome User Manual
91
Figure 8-9 Draw Area
8.
Click Save.
9.
Oponal: Click Add, and repeat above steps to set other rules.
Note
Up to 4 rules can be set.
10.
Set arming schedule. See Set Arming Schedule .
11.
Set linkage method. See
Linkage Method Sengs .
8.2.7 Set Tracking Parameters
Adjust the moon parameters of the device for beer target tracking performance.
Steps
1.
Go to VCA → Set Applicaon → Smart Event → Advanced Sengs .
2.
Oponal: Check Tuning Mode.
Note
Tuning mode is to display the informaon that helps debugging the funcon. This mode is
reserved for technical support.
3.
Set the Tracking Duraon.
The device stops tracking when it tracks a target uninterruptedly for the set
duraon.
4.
Set the zooming control and other tracking parameters.
Zooming Control
Network Speed Dome User Manual
92
Two modes are available. Controlled by target frame or by lt angle of the device.
By Tilt Angle
The device calculates the tracking zoom rao automacally according to the lt angle of
the device.
Note
The atude of the device aects the accuracy of this zooming control mode. For the
model with a built-in gyroscope, try to calibrate the atude if some zooming problems
happen during tracking. See Set Device Posion for instrucons.
By Target Frame
The tracked target has a virtual frame around. The device calculates a suitable zoom rao
according to the frame and the set Tracking Zoom Rao. Larger value means bigger zoom
rao.
Wait to Stop Tracking If Low Validity
The validity is an internal parameter that helps judge whether the device should keep
tracking or not. This parameter is the waing me level before the device stops tracking
when the validity is low. Larger value means longer
waing me.
Wait to Lower Tracking Speed If Low Validity
The validity is an internal parameter that helps judge whether the PTZ channel should lower
the tracking speed or not. This parameter is the waing me level before the device lowers
the tracking speed when the validity is low. Larger value means longer
waing me.
5.
Oponal: Click Default to restore the smart tracking parameters to default sengs.
6.
Click Save.
8.2.8 Overlay and Capture
Choose to congure capture parameters and the informaon you want to display on stream and
picture.
Display Target Info. on Alarm Picture
Overlay the alarm picture with target
informaon.
Display Rule info. on Alarm Picture
The captured target and the congured area will be framed on the alarm picture.
Network Speed Dome User Manual
93
Chapter 9 Arming Schedule and Alarm Linkage
Arming schedule is a customized me period in which the device performs certain tasks. Alarm
linkage is the response to the detected certain incident or target during the scheduled
me.
9.1 Set Arming Schedule
Set the valid
me of the device tasks.
Steps
1.
Oponal: Click Arming Schedule and Linkage Method in the related event interface.
2.
Click Modify behind Arming Schedule.
3.
Click Draw, and drag the
me bar to draw desired valid me.
Note
●
Each cell represents 30 minutes.
●
Move the mouse over the drawn me period to see specic me periods and ne-tune the
start me and end me.
●
Up to 8 periods can be
congured for one day.
4.
Click Erase, and drag the me bar to clear selected valid me.
5.
Click OK to save the sengs.
Figure 9-1 Set Arming Schedule
9.2 Linkage Method
Sengs
You can enable the linkage funcons when an event or alarm occurs.
Network Speed Dome User Manual
94
9.2.1 Trigger Alarm Output
If the device has been connected to an alarm output device, and the alarm output No. has been
congured, the device sends alarm informaon to the connected alarm output device when an
alarm is triggered.
Steps
1.
Go to Conguraon → Event → Alarm Seng → Alarm Output .
2.
Set alarm output parameters.
Automac Alarm For the informaon about the conguraon, see Automac Alarm .
Manual Alarm For the informaon about the conguraon, see Manual Alarm .
Automac Alarm
Set the automac alarm parameters, then the device triggers an alarm output automacally in the
set arming schedule.
Before You Start
Make sure the alarm output device is connected to the device.
Steps
1.
Select the Alarm Output No. according to the alarm interface connected to the external alarm
device. Click
to set alarm parameters.
Alarm Name
Custom a name for the alarm output.
Delay
It refers to the
me duraon that the alarm output remains aer an alarm occurs.
2.
Set the alarming schedule. For the informaon about the sengs, see Set Arming Schedule .
3.
Oponal: Click Copy to… to copy the parameters to other alarm output channels.
4.
Click Save.
Manual Alarm
You can trigger an alarm output manually.
Before You Start
Make sure the alarm output device is connected to the device.
Steps
1.
Select the Alarm Output No. according to the alarm interface connected to the external alarm
device. Click to set alarm parameters.
Alarm Name
Network Speed Dome User Manual
95
Custom a name for the alarm output.
2.
Click Manual Alarm to enable manual alarm output.
3.
Oponal: Click Clear Alarm to disable manual alarm output.
9.2.2 FTP/NAS/Memory Card Uploading
If you have enabled and congured the FTP/NAS/memory card uploading, the device sends the
alarm informaon to the FTP server, network aached storage and memory card when an alarm is
triggered.
Refer to
Set FTP to set the FTP server.
Refer to Set NAS for NAS conguraon.
Refer to Set New or Unencrypted Memory Card for memory card storage conguraon.
9.2.3 Send Email
Check Send Email, and the device sends an email to the designated addresses with alarm
informaon when an alarm event is detected.
For email sengs, refer to Set Email .
Set Email
When the email is congured and Send Email is enabled as a linkage method, the device sends an
email nocaon to all designated receivers if an alarm event is detected.
Before You Start
Set the DNS server before using the Email funcon. Go to Conguraon → Network → Network
Sengs → TCP/IP for DNS sengs.
Steps
1.
Go to email
sengs page: Conguraon → Event → Alarm Seng → Email .
2.
Set email parameters.
1) Input the sender's email
informaon, including the Sender's Address, SMTP Server, and
SMTP Port.
2)
Oponal: If your email server requires authencaon, check Authencaon and input your
user name and password to log in to the server.
3) Set the E-mail Encrypon.
●
When you select TLS, and disable STARTTLS, emails are sent
aer encrypted by TLS. The
SMTP port should be set as 465.
●
When you select TLS and Enable STARTTLS, emails are sent
aer encrypted by STARTTLS,
and the SMTP port should be set as 25.
Network Speed Dome User Manual
96
Note
If you want to use STARTTLS, make sure that the protocol is supported by your email server.
If you check the Enable STARTTLS while the protocol is not supported by your email sever,
your email is sent with no encr ypon.
4) Oponal: If you want to receive nocaon with alarm pictures, check Aached Image. The
nocaon email has 3 aached alarm pictures about the event with congurable image
capturing interval.
5) Input the receiver's
informaon, including the receiver's name and address.
6) Click Test to see if the funcon is well congured.
3.
Click Save.
9.2.4
Nofy Surveillance Center
Check Nofy Surveillance Center, the alarm informaon is uploaded to the surveillance center
when an alarm event is detected.
9.2.5 Smart Tracking
Check Smart Tracking, and the device tracks the target when an alarm event is detected.
Note
This funcon is only supported by certain models.
9.2.6 Trigger Recording
Check Trigger Recording, and the device records the video about the detected alarm event.
For recording sengs, refer to Video Recording and Picture Capture
9.2.7 Flashing Light
Aer enabling Flashing Light and seng the Flashing Light Alarm Output, the light ashes when
an alarm event is detected.
Set Flashing Alarm Light Output
When events occur, the
ashing light on the device can be triggered as an alarm.
Steps
1.
Go to Conguraon → Event → Basic Event → Flashing Alarm Light Output .
2.
Set Flashing
Duraon, Flashing Frequency and Brightness.
Network Speed Dome User Manual
97
Flashing Duraon
The me that the ashing lasts when one alarm happens.
Flashing Frequency
The rate at which the light ashes. High frequency, medium frequency, low frequency, and
normally on are selectable.
Brightness
The brightness of the light.
3.
Set the arming schedule. See
Set Arming Schedule for details.
4.
Click Save.
Note
Only certain device models support the funcon.
9.2.8 Audible Warning
Aer enabling Audible Warning and seng the Audible Alarm Output, the built-in speaker of the
device or connected external speaker plays warning sounds when alarm happens.
For audible alarm output sengs, refer to Set Audible Alarm Output .
Note
Before using the funcon, go to Conguraon → Video/Audio → Audio to enable built-in speaker
in advance.
The funcon is only supported by certain camera models.
Set Audible Alarm Output
When the device detects targets in the detecon area, audible alarm can be triggered as a
warning.
Steps
1.
Go to Conguraon → Event → Alarm Seng → Audible Alarm Output .
2.
Select Sound Type and set related parameters.
-
Select Prompt and set the alarm mes you need.
-
Select Warning and its contents. Set the alarm mes you need.
-
Select Custom Audio. You can select a custom audio
le from the drop-down list. If no le is
available, you can click Set → Add to upload an audio le that meets the requirement. Up to
three audio
les can be uploaded.
3.
Oponal: Click Test to play the selected audio le on the device.
4.
Set arming schedule for audible alarm. See
Set Arming Schedule for details.
5.
Click Save.
Network Speed Dome User Manual
98
Note
The funcon is only supported by certain device models.
Set Alarm Server
Steps
1.
Go to Conguraon → Event → Alarm Seng → Alarm Server .
2.
Enter
Desnaon IP or Host Name, URL, and Port.
3.
Select Protocol.
Note
HTTP, HTTPS, and ISUP are selectable. It is recommended to use HTTPS, as it encrypts the data
transmission during communicaon.
4.
Click Test to check if the IP or host is available.
5.
Click Save.
9.2.9 Alarm Server
The device can send alarms to desnaon IP address or host name through HTTP, HTTPS, or ISUP
protocol. The
desnaon IP address or host name should support HTTP, HTTP, or ISUP data
transmission.
Set Alarm Server
Steps
1.
Go to Conguraon → Event → Alarm Seng → Alarm Server .
2.
Enter
Desnaon IP or Host Name, URL, and Port.
3.
Select Protocol.
Note
HTTP, HTTPS, and ISUP are selectable. It is recommended to use HTTPS, as it encrypts the data
transmission during communicaon.
4.
Click Test to check if the IP or host is available.
5.
Click Save.
Network Speed Dome User Manual
99
Chapter 10 Network Sengs
10.1 TCP/IP
TCP/IP sengs must be properly congured before you operate the device over network. IPv4 and
IPv6 are both supported. Both versions can be congured simultaneously without conicng to
each other.
Go to Conguraon → Network → Network Sengs → TCP/IP for parameter sengs.
NIC Type
Select a NIC (Network Interface Card) type according to your network condion.
IPv4
Two IPv4 modes are available.
DHCP
The device
automacally gets the IPv4 parameters from the network if you check DHCP. The
device IP address is changed aer enabling the funcon. You can use SADP to get the device IP
address.
Note
The network that the device is connected to should support DHCP (Dynamic Host
Conguraon Protocol).
Manual
You can set the device IPv4 parameters manually. Input IPv4 Address, IPv4 Subnet Mask, and
IPv4 Default Gateway, and click Test to see if the IP address is available.
IPv6
Three IPv6 modes are available.
Route
Adversement
The IPv6 address is generated by combining the route adversement and the device Mac
address.
Note
Route adversement mode requires the support from the router that the device is connected
to.
DHCP
The IPv6 address is assigned by the server, router, or gateway.
Manual
Network Speed Dome User Manual
100
Input IPv6 Address, IPv6 Subnet, IPv6 Default Gateway. Consult the network administrator for
required informaon.
MTU
It stands for maximum transmission unit. It is the size of the largest protocol data unit that can
be communicated in a single network layer
transacon.
The valid value range of MTU is 1280 to 1500.
DNS
It stands for domain name server. It is required if you need to visit the device with domain
name. And it is also required for some
applicaons (e.g., sending email). Set Preferred DNS
Server and Alternate DNS server properly if needed.
Domain Name Sengs
Check Enable Dynamic Domain Name and input Register Domain Name. The device is
registered under the register domain name for easier management within the local area
network.
Note
DHCP should be enabled for the dynamic domain name to take eect.
10.2 Port Mapping
By seng port mapping, you can access devices through the specied port.
Steps
1.
Go to Conguraon → Network → Network Service → NAT .
2.
Select the port mapping mode.
Auto Port Mapping
Refer to Set Auto Port Mapping for detailed informaon.
Manual Port Mapping Refer to Set Manual Port Mapping for detailed informaon.
3.
Click Save.
10.2.1 Set Auto Port Mapping
Steps
1.
Check Enable UPnP™, and choose a friendly name for the camera, or you can use the default
name.
2.
Select the port mapping mode to Auto.
3.
Click Save.
Note
UPnP™ funcon on the router should be enabled at the same me.
Network Speed Dome User Manual
101
10.2.2 Set Manual Port Mapping
Steps
1.
Check Enable UPnP™, and choose a friendly name for the device, or you can use the default
name.
2.
Select the port mapping mode to Manual, and set the external port to be the same as the
internal port.
3.
Click Save.
What to do next
Go to the router port mapping
sengs interface and set the port number and IP address to be the
same as those on the device. For more
informaon, refer to the router user manual.
10.2.3 Set Port Mapping on Router
The following sengs are for a certain router. The sengs vary depending on dierent models of
routers.
Steps
1.
Select the WAN
Connecon Type.
2.
Set the IP Address, Subnet Mask and other network parameters of the router.
3.
Go to Forwarding → Virtual Severs , and input the Port Number and IP Address.
4.
Click Save.
Example
When the cameras are connected to the same router, you can
congure the ports of a camera as
80, 8000, and 554 with IP address 192.168.1.23, and the ports of another camera as 81, 8001, 555,
8201 with IP 192.168.1.24.
Network Speed Dome User Manual
102
Figure 10-1 Port Mapping on Router
Note
The port of the network camera cannot conict with other ports. For example, some web
management port of the router is 80. Change the camera port if it is the same as the management
port.
10.3 SNMP
You can set the SNMP network management protocol to get the alarm event and excepon
messages in network transmission.
Before You Start
Before seng the SNMP, you should download the SNMP soware and manage to receive the
device informaon via SNMP port.
Steps
1.
Go to Conguraon → Network → Network Sengs → SNMP .
2.
Check Enable SNMPv1, Enable SNMP v2c or Enable SNMPv3.
Note
The SNMP version you select should be the same as that of the SNMP soware.
Network Speed Dome User Manual
103
And you also need to use the dierent version according to the security level required. SNMP v1
is not secure and SNMP v2 requires password for access. And SNMP v3 provides encrypon and
if you use the third version, HTTPS protocol must be enabled.
3.
Congure the SNMP sengs.
4.
Click Save.
10.4 Access to Device via Domain Name
You can use the Dynamic DNS (DDNS) for network access. The dynamic IP address of the device can
be mapped to a domain name
resoluon server to realize the network access via domain name.
Before You Start
Registraon on the DDNS server is required before conguring the DDNS sengs of the device.
Steps
1.
Refer to
TCP/IP to set DNS parameters.
2.
Go to the DDNS sengs page: Conguraon → Network → Network Sengs → DDNS .
3.
Check Enable and select DDNS Type.
DynDNS
Dynamic DNS server is used for domain name
resoluon.
NO-IP
NO-IP server is used for domain name resoluon.
4.
Input the domain name informaon, and click Save.
5.
Check the device ports and complete port mapping. Refer to to check the device port, and refer
to
Port Mapping for port mapping sengs.
6.
Access the device.
By Browsers
Enter the domain name in the browser address bar to access the device.
By Client Soware Add domain name to the client soware. Refer to the client manual for
specic adding methods.
10.5 Access to Device via PPPoE Dial Up Connecon
This device supports the PPPoE auto dial-up funcon. The device gets a public IP address by ADSL
dial-up aer the device is connected to a modem. You need to congure the PPPoE parameters of
the device.
Steps
1.
Go to
Conguraon → Network → Network Sengs → PPPoE .
2.
Check Enable.
3.
Set the PPPoE parameters.
Dynamic IP
Network Speed Dome User Manual
104
Aer successful dial-up, the dynamic IP address of the WAN is displayed.
User Name
User name for dial-up network access.
Password
Password for dial-up network access.
Conrm
Input your dial-up password again.
4.
Click Save.
5.
Access the device.
By Browsers Enter the WAN dynamic IP address in the browser address bar to access
the device.
By Client Soware Add the WAN dynamic IP address to the client soware. Refer to the
client manual for details.
Note
The obtained IP address is dynamically assigned via PPPoE, so the IP address always changes
aer reboong the camera. To solve the inconvenience of the dynamic IP, you need to get a
domain name from the DDNS provider (e.g. DynDns.com). Refer to Access to Device via Domain
Name for detail informaon.
10.6 Accessing via Mobile Client
Hik-Connect is an applicaon for mobile devices. Using the App, you can view live image, receive
alarm nocaon and so on.
Note
Hik-Connect service should be supported by the camera.
10.6.1 Enable Hik-Connect Service on Camera
Hik-Connect service should be enabled on your camera before using the service.
You can enable the service through SADP soware or Web browser.
Enable Hik-Connect Service via Web Browser
Follow the following steps to enable Hik-Connect Service via Web Browser.
Before You Start
You need to acvate the camera before enabling the service.
Network Speed Dome User Manual
105
Steps
1.
Access the camera via web browser.
2.
Enter plaorm access conguraon interface. Conguraon → Network → Plaorm Access →
Hik-Connect .
3.
Check Enable.
4.
Click and read "Terms of Service" and "Privacy Policy" in pop-up window.
5.
Create a
vericaon code or change the old vericaon code for the camera.
Note
The vericaon code is required when you add the camera to Hik-Connect service.
6.
Save the sengs.
Enable Hik-Connect Service via SADP
Soware
This part introduce how to enable Hik-Connect service via SADP soware of an acvated camera.
Steps
1.
Run SADP soware.
2.
Select a camera and enter Modify Network Parameters page.
3.
Check Enable Hik-Connect.
4.
Create a
vericaon code or change the old vericaon code.
Note
The vericaon code is required when you add the camera to Hik-Connect service.
5.
Click and read "Terms of Service" and "Privacy Policy".
6.
Conrm the sengs.
10.6.2 Set Up Hik-Connect
Steps
1.
Get and install Hik-Connect applicaon by the following ways.
-
Visit hps://appstore.hikvision.com to download the applicaon according to your mobile
phone system.
-
Visit the ocial site of our company. Then go to Support → Tools → Hikvision App Store .
-
Scan the QR code below to download the
applicaon.
Note
If errors like "Unknown app" occur during the installaon, solve the problem in two ways.
●
Visit hps://appstore.hikvision.com/stac/help/index.html to refer to the troubleshoong.
●
Visit hps://appstore.hikvision.com/ , and click Installaon Help at the upper right corner of
the interface to refer to the
troubleshoong.
Network Speed Dome User Manual
106
2.
Start the applicaon and register for a Hik-Connect user account.
3.
Log in aer registraon.
10.6.3 Add Camera to Hik-Connect
Steps
1.
Connect your mobile device to a Wi-Fi.
2.
Log into the Hik-Connect app.
3.
In the home page, tap "+" on the upper-right corner to add a camera.
4.
Scan the QR code on camera body or on the Quick Start Guide cover.
Note
If the QR code is missing or too blur to be recognized, you can also add the camera by inpung
the camera's serial number.
5.
Input the vericaon code of your camera.
Note
●
The required vericaon code is the code you create or change when you enable Hik-Connect
service on the camera.
●
If you forget the vericaon code, you can check the current vericaon code on Plaorm
Access conguraon page via web browser.
6.
Tap Connect to a Network buon in the popup interface.
7.
Choose Wired Connecon.
8.
Connect the camera to the router with a network cable and tap Connected in the result
interface.
Note
The router should be the same one which your mobile phone has connected to.
9.
Tap Add in the next interface to nish adding.
For detailed informaon, refer to the user manual of the Hik-Connect app.
10.7 HTTP(S)
HTTP is an applicaon-layer protocol for transming hypermedia documents. HTTPS is a network
protocol that enables encrypted transmission and identy authencaon, which improves the
security of remote access.
Steps
1.
Go to Conguraon → Network → Network Service → HTTP(S) .
2.
Enter HTTP Port.
Network Speed Dome User Manual
107
Note
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.168.1.64:81 in the browser for login.
3.
Check Enable in HTTPS.
Note
You can click TLS Sengs to set the TLS version that the device supports. Refer to for details.
4.
Enter HTTPS Port.
5.
Oponal: Check HTTPS Browsing to access the device only via HTTPS protocol.
6.
Select Server
Cercate.
7.
Set Web Authencaon.
Authencaon
Digest and digest/basic are supported, which means authencaon informaon is needed
when WEB request is sent to the device. If you select digest/basic, it means the device
supports digest or basic
authencaon. If you select digest, the device only supports digest
authencaon.
Digest Algorithm
MD5, SHA256 and MD5/SHA256 encrypted algorithm in WEB
authencaon. If you enable
the digest algorithm except for MD5, the third-party plaorm might not be able to log in to
the device or enable live view because of compability. The encrypted algorithm with high
strength is recommended.
8.
Click Save.
10.8
Mulcast
Mulcast is group communicaon where data transmission is addressed to a group of desnaon
devices simultaneously.
Go to Conguraon → Network → Network Service → Mulcast for the mulcast sengs.
IP Address
It stands for the address of mulcast host.
10.8.1
Mulcast Discovery
Go to Conguraon → Network → Network Sengs → TCP/IP to enable this funciton.
Check the Enable
Mulcast Discovery, and then the online network camera can be automacally
detected by client soware via private mulcast protocol in the LAN.
Network Speed Dome User Manual
108
10.9 RTSP
RTSP (Real Time Streaming Protocol) is an applicaon-layer controlling protocol for streaming
media.
Steps
1.
Go to Conguraon → Network → Network Service → RTSP .
2.
Enter Port.
3.
Set
Mulcast parameters.
Stream Type
The stream type as the mulcast source.
Video Port
The video port of the selected stream.
Audio Port
The audio port of the selected stream.
4.
Set RTSP
Authencaon.
Authencaon
Digest and digest/basic are supported, which means authencaon informaon is needed
when RTSP request is sent to the device. If you select digest/basic, it means the device
supports digest or basic
authencaon. If you select digest, the device only supports digest
authencaon.
Digest Algorithm
MD5, SHA256 and MD5/SHA256 encrypted algorithm in RTSP authencaon. If you enable
the digest algorithm except for MD5, the third-party plaorm might not be able to log in to
the device or enable live view because of
compability. The encrypted algorithm with high
strength is recommended.
5.
Click Save.
10.10 Set SRTP
The Secure Real-me Transport Protocol (SRTP) is a Real-me Transport Protocol (RTP) internet
protocol, intended to provide encrypon, message authencaon and integrity, and replay aack
protecon to the RTP data in both unicast and mulcast applicaons.
Steps
1.
Go to
Conguraon → Network → Network Service → SRTP .
2.
Enter the Port number.
3.
Set Mulcast parameters.
Stream Type
The stream type as the
mulcast source.
Network Speed Dome User Manual
109
Video Port
The video port of the selected stream.
Audio Port
The audio port of the selected stream.
4.
Select Server Cercate.
5.
Select Encrypted Algorithm.
6.
Click Save.
Note
●
Only certain device models support this funcon.
●
If the funcon is abnormal, check if the selected cercate is abnormal in Cercate
Management .
10.10.1 Mulcast
Mulcast is group communicaon where data transmission is addressed to a group of desnaon
devices simultaneously.
Go to Conguraon → Network → Network Service → Mulcast for the mulcast sengs.
IP Address
It stands for the address of mulcast host.
10.10.2
Mulcast Discovery
Go to Conguraon → Network → Network Sengs → TCP/IP to enable this funciton.
Check the Enable
Mulcast Discovery, and then the online network camera can be automacally
detected by client soware via private mulcast protocol in the LAN.
10.11 Bonjour
It is an implementaon of zero-conguraon networking (zeroconf), a group of technologies that
includes service discovery, address assignment, and hostname
resoluon. Bonjour locates devices
such as printers, other computers, and the services that those devices oer on a local network
using
mulcast Domain Name System (mDNS) service records.
Go to Conguraon → Network → Network Service → Bonjour to enable the funcon, and click
Save.
Aer enabling the funcon, the device spread and receive service informaon in local area
network.
Network Speed Dome User Manual
110
10.12 WebSocket(s)
WebSocket or WebSockets protocol should be enabled if you use Google Chrome 57 and its above
version or Mozilla Firefox 52 and its above version to visit the device. Otherwise, live view, image
capture, digital zoom, etc. cannot be used.
Go to
Conguraon → Network → Network Service → WebSocket(s) to set parameters, and click
Save.
WebSocket
TCP-based full-duplex communicaon protocol port for plug-in free preview via HTTP protocol.
WebSockets
TCP-based full-duplex communicaon protocol port for plug-in free preview via HTTPS protocol.
10.13 TCP
Acceleraon
TCP acceleraon is used to improve latency and reduce packet loss caused by network congeson
in poor network condion, and guarantee the uency of live view.
10.14
Trac Shaping
Trac shaping is used to shape and smooth video data packet before transmission.
It helps to improve latency and reduce packet loss caused by network
congeson and ensure the
video quality as well. Shaping level is congurable.
10.15 Set OTAP
The device can be accessed to the maintenance plaorm via OTAP protocol, in order to search and
acquire device
informaon, upload device status and alarm informaon, reboot and update the
device.
Steps
1.
Go to Conguraon → Network → Plaorm Access → OTAP to enable the funcon.
2.
Set related parameters.
3.
Click Test to check if the device connects to server.
4.
Click Save.
Register Status turns to Online when the
funcon is correctly set.
Network Speed Dome User Manual
111
10.16 Set ISUP
When the device is registered on ISUP plaorm (formerly called Ehome), you can visit and manage
the device, transmit data, and forward alarm informaon over public network.
Steps
1.
Go to Conguraon → Network → Plaorm Access → ISUP .
2.
Oponal: Select an access center.
3.
Check Enable.
4.
Select a protocol version and enter related parameters.
5.
Click Save.
Register status turns to Online when the
funcon is correctly set.
10.17 Set Open Network Video Interface
If you need to access the device through Open Network Video Interface protocol, you can
congure the user sengs to enhance the network security.
Steps
1.
Go to Conguraon → Network → Plaorm Access → Open Network Video Interface .
2.
Check Enable.
3.
Select an
authencaon mode.
-
If you select Digest, the device only supports digest
authencaon.
-
If you select Digest&ws-username token, the device supports digest
authencaon or ws-
username token
authencaon.
4.
Click Add to congure the Open Network Video Interface user.
5.
Click Save.
6.
Oponal: Repeat the steps above to add more Open Network Video Interface users.
7.
Oponal: Manage the user.
-
Click
to delete the selected Open Network Video Interface user.
-
to modify the selected Open Network Video Interface user.
10.18 Set SDK Service
If you want to add the device to the client soware, you should enable SDK Service or Enhanced
SDK Service.
Steps
1.
Go to Conguraon → Network → Plaorm Access → SDK Service .
2.
Set SDK Service parameters.
1) Check Enable to add the device to the client
soware with SDK protocol.
2) Enter the Port number.
Network Speed Dome User Manual
112
3.
Set Enhanced SDK Service parameters.
1) Check Enable to add the device to the client soware with SDK over TLS protocol.
2) Oponal: Click TLS Sengs to enable the TLS version that the device supports. Refer to TLS
for details.
3) Enter the Port number.
4) Select a server
cercate to make sure the data transmission security. You can click Cercate
Management to add a cercate. Refer to for details.
4.
Click Save.
Network Speed Dome User Manual
113
Chapter 11 System and Security
It introduces system maintenance, system sengs and security management, and explains how to
congure relevant parameters.
11.1 View Device Informaon
You can view device informaon, such as Device No., Model, Serial No. and Firmware Version.
Enter Conguraon → System → System Sengs → Basic Informaon to view the device
informaon.
11.2 Reboot
You can reboot the device via browser.
Go to Maintenance and Security → Maintenance → Reboot , and click Reboot.
11.3 Upgrade
Before You Start
You need to obtain the correct upgrade package.
Cauon
DO NOT disconnect power during the process, and the device reboots automacally aer upgrade.
Steps
1.
Go to Maintenance and Security → Maintenance → Upgrade .
2.
Choose one method to upgrade.
Firmware
Locate the exact path of the upgrade le.
Firmware Directory Locate the directory which the upgrade le belongs to.
3.
Click to select the upgrade le.
4.
Click Upgrade.
11.4 Restore and Default
Restore and Default helps restore the device parameters to the default
sengs.
Steps
1.
Go to Maintenance and Security → Maintenance → Backup and Restore .
Network Speed Dome User Manual
114
2.
Click Restore or Default according to your needs.
Restore Reset device parameters, except user informaon, IP parameters and video format
to the default sengs.
Default Reset all the parameters to the factory default.
Note
Be careful when using this funcon. Aer reseng to the factory default, all the
parameters are reset to the default sengs.
11.5 Search and Manage Log
Log helps locate and troubleshoot problems.
Steps
1.
Go to Maintenance and Security → Maintenance → Log .
2.
Set search
condions Major Type, Minor Type, Start Time, and End Time.
3.
Click Search.
The matched log
les will be displayed on the log list.
4.
Oponal: Click Export to save the log les in your computer.
11.6 Import and Export
Conguraon File
It helps speed up batch conguraon on other devices with the same parameters.
Steps
1.
Export conguraon le.
1) Go to Maintenance and Security → Maintenance → Backup and Restore → Backup .
2) Click Export and input the
encrypon password to export the current conguraon le.
3) Set the saving path to save the conguraon le in local computer.
2.
Import conguraon le.
1) Access the device that needs to be congured via web browser.
2) Go to Maintenance and Security → Maintenance → Backup and Restore → Reset .
3) Click
to select the saved conguraon le.
4) Input the encrypon password you have set when exporng the conguraon le.
5) Click Import.
11.7 Export Diagnose
Informaon
Diagnose informaon includes running log, system informaon, hardware informaon.
Network Speed Dome User Manual
115
Go to Maintenance and Security → Maintenance → Device Debugging → Diagnose Informaon .
Click Export. In the pop-up window, check desired diagnose informaon and click Export to export
corresponding diagnose informaon of the device.
11.8 Search and Export Data Aware Informaon
The data aware funcon is used to search and export the data of the restart, arming and capture
alarm stascs.
Before You Start
Log in to the device via admin user account.
Steps
1.
Go to
Applicaon Display → Data Aware .
2.
Select the search
condion.
Stascs Type Opons
Restart Records Type of reboong , start me and end me.
Arming Arming type, start me and end me.
Capture Alarm Stascs Report type, alarm target, protocol, arming IP address and start
me.
Alarm Quality Stascs Report type, alarm target and start me.
3.
Click Search.
The data
informaon that match the condions will be displayed.
4.
Oponal: Click Export to save the data informaon to the local device.
11.9 View Open Source
Soware License
On the top-right corner, click and select Open Source Soware Descripon to download the
license. You can view the license in the editor.
11.10 Set Live View
Connecon
It controls the remote live view connecon amount.
Live view connecon controls the maximum live view that can be streamed at the same me.
Enter Conguraon → System → System Sengs → System Service to set the upper limit of the
remote connecon number.
Network Speed Dome User Manual
116
11.11 Time and Date
You can congure me and date of the device by conguring me zone, me synchronizaon and
Daylight Saving Time (DST).
11.11.1 Synchronize Time Manually
Steps
1.
Go to Conguraon → System → System Sengs → Time Sengs .
2.
Select Time Zone.
3.
Select Manual Time Sync..
4.
Choose one
me synchronizaon method.
-
Select Set Time, and manually input or select date and me from the pop-up calendar.
-
Click Sync. with computer
me to synchronize the me of the device with that of the local PC.
5.
Click Save.
11.11.2 Synchronize Time by Satellite
Note
This funcon varies depending on dierent devices.
Steps
1.
Enter
Conguraon → System → System Sengs → Time Sengs .
2.
Select Satellite Time Sync..
3.
Set Interval.
4.
Click Save.
11.11.3 Set NTP Server
You can use NTP server when accurate and reliable me source is required.
Before You Start
Set up a NTP server or obtain NTP server informaon.
Steps
1.
Go to Conguraon → System → System Sengs → Time Sengs .
2.
Select Time Zone.
3.
Click NTP.
4.
Set Server Address, NTP Port and Interval.
Network Speed Dome User Manual
117
Note
Server Address is NTP server IP address.
5.
Click Test to test server connecon.
6.
Click Save.
11.11.4 Set DST
If the region where the device is located adopts Daylight Saving Time (DST), you can set this
funcon.
Steps
1.
Go to Conguraon → System → System Sengs → Time Sengs .
2.
Check Enable.
3.
Select Start Time, End Time and DST Bias.
4.
Click Save.
11.12 Set RS-485
RS-485 is used to connect the device to external device. You can use RS-485 to transmit the data
between the device and the computer or terminal when the communicaon distance is too long.
Before You Start
Connect the device and computer or termial with RS-485 cable.
Steps
1.
Go to Conguraon → System → System Sengs → RS-485 .
2.
Set the RS-485 parameters.
Note
You should keep the parameters of the device and the computer or terminal all the same.
3.
Click Save.
11.13 Security
You can improve system security by seng security parameters.
11.13.1 Set IP Address Filter
IP address lter is a tool for access control. You can enable the IP address lter to allow or forbid
the visits from the certain IP addresses.
IP address refers to IPv4.
Network Speed Dome User Manual
118
Steps
1.
Go to Maintenance and Security → Security → IP Address Filter .
2.
Check Enable.
3.
Select the type of IP address
lter.
Blocklist IP addresses in the list cannot access the device.
Allowlist Only IP addresses in the list can access the device.
4.
Edit the IP address lter list.
Add Add a new IP address or IP address range to the list.
Modify the selected IP address or IP address range in the list.
Delete the selected IP address or IP address range in the list.
5.
Click Save.
11.13.2 Set MAC Address Filter
MAC address lter is a tool for access control. You can enable the MAC address lter to allow or
forbid the visits from the certain MAC addresses.
Steps
1.
Go to Maintenance and Security → Security → MAC Address Filter .
2.
Check Enable.
3.
Select the type of MAC address
lter.
Blocklist
MAC addresses in the list cannot access the device.
Allowlist Only MAC addresses in the list can access the device.
4.
Edit the MAC address lter list.
Add
Add a new MAC address to the list.
Modify the selected MAC address in the list.
Delete the selected MAC address in the list.
5.
Click Save.
11.13.3 Security Audit Log
The security audit logs refer to the security operaon logs. You can search and analyze the security
log les of the device so as to nd out the illegal intrusion and troubleshoot the security events.
Security audit logs can be saved on device internal storage. The log will be saved every half hour
aer device boong. Due to limited storage space, you can also save the logs on a log server.
Network Speed Dome User Manual
119
Search Security Audit Logs
You can search and analyze the security log les of the device so as to nd out the illegal intrusion
and troubleshoot the security events.
Steps
Note
This funcon is only supported by certain camera models.
1.
Go to Maintenance and Security → Maintenance → Security Audit Log .
2.
Select log types, Start Time, and End Time.
3.
Click Search.
The log
les that match the search condions will be displayed on the Log List.
4.
Oponal: Click Export to save the log les to your computer.
Set Log Server
The log server should support syslog (RFC 3164) over TLS.
Before You Start
●
Install client and CA cercates before conguraon. Refer to Cercate Management for
detailed informaon.
●
Select cercates according to the requirement of the log server. If two-way authencaon is
required, select the CA cercate and the client cercate. If one-way authencaon is
required, select the CA
cercate only.
Steps
1.
Click Advanced Conguraon.
2.
Check Enable Log Upload Server.
3.
Oponal: Check Enable Encrypted Transmission if you want the log data to be encrypted.
4.
Input Log Server IP and Log Server Port.
5.
Oponal: Click Test to test the sengs.
6.
Oponal: Select a client cercate.
7.
Select a CA cercate to the device.
8.
Click Save.
11.13.4 Set QoS
QoS (Quality of Service) can help improve the network delay and network
congeson by seng
the priority of data sending.
Network Speed Dome User Manual
120
Note
QoS needs support from network device such as router and switch.
Steps
1.
Go to Conguraon → Network → Network Sengs → QoS .
2.
Set Video/Audio DSCP, Event/Alarm DSCP and Management DSCP.
Note
Network can idenfy the priority of data transmission. The bigger the DSCP value is, the higher
the priority is. You need to set the same value in router while conguraon.
3.
Click Save.
11.13.5 Set IEEE 802.1X
You can authencate user permission of the connected device by seng IEEE 802.1X.
Go to Conguraon → Network → Network Sengs → 802.1X , and enable the funcon.
Select protocol and version according to router informaon. User name and password of server are
required.
Note
●
If you set the Protocol to EAP-TLS, select the Client Cercate and CA Cercate.
●
If the funcon is abnormal, check if the selected cercate is abnormal in Cercate
Management.
11.13.6 SSH
Secure Shell (SSH) is a cryptographic network protocol for operang network services over an
unsecured network.
Go to Maintenance and Security → Maintenance → Device Debugging , and click
Sengs of SSH.
You can edit the number of the port. Click Save.
Cauon
Use the funcon with cauon. The security risk of device internal informaon leakage exists when
the funcon is enabled.
11.13.7 Control Timeout Sengs
If this funcon is enabled, you will be logged out when you make no operaon (not including
viewing live image) to the device via web browser within the set
meout period.
Network Speed Dome User Manual
121
Go to Maintenance and Security → Security → Login Management → Control Timeout Sengs to
complete sengs.
11.13.8 Cercate Management
It helps to manage the server/client cercates and CA cercate, and to send an alarm if the
cercates are close to expiry date, or are expired/abnormal.
Server Cercate/Client Cercate
Note
The device has default self-signed server/client cercate installed. The cercate ID is default.
Create and Install Self-signed Cercate
Steps
1.
Go to Maintenance and Security → Security →
Cercate Management .
2.
Click Create Self-signed Cercate.
3.
Input
cercate informaon.
Note
The input cercate ID cannot be the same as the exisng ones.
4.
Click Save to save and install the cercate.
The created cercate is displayed in the Server/Client Cercate list.
If the
cercate is used by certain funcons, the funcon name is shown in the column
Funcons.
5.
Oponal: Click Property to see the cercate details.
Install Self-signed Request
Cercate
You can send the self-signed cercate to a trusted third-party for the signature, and install the
cercate to the device.
Before You Start
Create a self-signed cercate rst. See Create and Install Self-signed Cercate for instrucons.
Steps
1.
Go to Maintenance and Security → Security → Cercate Management .
2.
Select a self-signed cercate from the Server/Client Cercate list.
3.
Click Create
Cercate Request.
4.
Input request informaon.
Network Speed Dome User Manual
122
5.
Click Save.
The cercate request details are displayed in a pop-up window.
6.
Copy the request content and save it as a request le.
7.
Send the le to a trusted-third party for signature.
8.
Aer receiving the cercated sent back from the third-party, install it to the device.
1) Click Import.
2) Input
Cercate ID.
Note
The input cercate ID cannot be the same as the existed ones.
3) Click to select the cercate le.
4) Select Self-signed Request Cercate.
5) Click Save.
The imported cercate is displayed in the Server/Client Cercate list.
If the
cercate is used by certain funcon, the funcon name is shown in the column
Funcons.
9.
Oponal: Click Property see the cercate details.
Install Other Authorized
Cercate
If you already has an authorized cercate (not created by the device), you can import it to the
device directly.
Steps
1.
Go to Maintenance and Security → Security → Cercate Management .
2.
Click Import in the Server/Client
Cercate list.
3.
Input Cercate ID.
Note
The input cercate ID cannot be the same as the existed ones.
4.
Click to select the cercate le.
5.
Select Cercate and Key and select a Key Type according to your cercate.
Independent Key
If your cercate has a independent key, select this opon.
Browse to select the private key and input the private-key password.
PKCS#12 If your cercate has the key in the same cercate le, select this opon
and input the password.
6.
Click Save.
The imported cercate is displayed in the Server/Client Cercate list.
If the
cercate is used by certain funcon, the funcon name is shown in the column
Funcons.
Network Speed Dome User Manual
123
Install CA Cercate
Before You Start
Prepare a CA
cercate in advance.
Steps
1.
Go to Maintenance and Security → Security → Cercate Management .
2.
Click Import in the CA Cercate list.
3.
Input
Cercate ID.
Note
The input cercate ID cannot be the same as the exisng ones.
4.
Click to select the cercate le.
5.
Click Save.
The imported cercate is displayed in the CA Cercate list.
If the cercate is used by certain funcons, the funcon name is shown in the Funcons
column.
Enable
Cercate Expiraon Alarm
Steps
1.
Check Enable Cercate Expiraon Alarm. If enabled, you will receive an email or the camera
links to the surveillance center that the
cercate will expire soon, or is expired or abnormal.
2.
Set the Remind Me Before Expiraon (day), Alarm Frequency (day) and Detecon Time (hour).
Note
●
If you set the reminding day before expiraon to 1, then the camera will remind you the day
before the expiraon day. 1 to 30 days are available. Seven days is the default reminding days.
●
If you set the reminding day before expiraon to 1, and the detecon me to 10:00, and the
cercate will expire in 9:00 the next day, the camera will remind you in 10:00 the rst day.
3.
Click Save.
11.13.9 TLS
The Transport Layer Security (TLS) protocol aims primarily to provide privacy and data integrity
between two or more
communicang computer applicaons. TLS sengs are eecve for HTTP(S)
and enhanced SDK service.
Go to Maintenance and Security → Security → TLS , and enable the desired TLS protocol. Click
Save.
Network Speed Dome User Manual
124
Cauon
Use the funcon with cauon. The security risk of device internal informaon leakage exists when
the funcon is enabled.
11.13.10 User and Account
Set User Account and Permission
The administrator can add, modify, or delete other accounts, and grant dierent permission to
dierent user levels.
Cauon
To increase security of using the device on the network, please change the password of your
account regularly. Changing the password every 3 months is recommended. If the device is used in
high-risk environment, it is recommended that the password should be changed every month or
week.
Steps
1.
Go to Conguraon → System → User Management → User Management .
2.
Click Add. Enter User Name, select Level, and enter Password. Assign remote permission to
users based on needs.
Administrator
The administrator has the authority to all
operaons and can add users and operators and
assign permission.
User
Users can be assigned permission of viewing live video,
seng PTZ parameters, and changing
their own passwords, but no permission for other operaons.
Operator
Operators can be assigned all permission except for operaons on the administrator and
creang accounts.
Modify
Select a user and click to change the password and permission.
Delete Select a user and click .
Note
The administrator can add up to 31 user accounts.
3.
Click OK.
Network Speed Dome User Manual
125
Online Users
The informaon of users logging into the device is shown.
Go to
Conguraon → System → User Management → Online Users to view the list of online
users.
Simultaneous Login
The administrator can set the maximum number of users logging into the system through web
browser simultaneously.
Go to
Conguraon → System → User Management → Online Users , click General, and set
Simultaneous Login.
Network Speed Dome User Manual
126
Appendix A. Device Command
Scan the following QR code to get device common serial port commands.
Note that the command list contains the commonly used serial port commands for all Hikvision
network cameras.
Network Speed Dome User Manual
127
Appendix B. Device Communicaon Matrix
Scan the following QR code to get device communicaon matrix.
Note that the matrix contains all
communicaon ports of Hikvision network cameras.
Network Speed Dome User Manual
128
UD31024B
