Legal Informaon
©2020 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product.
Pictures, charts, images and all other informaon hereinaer are for
descripon and explanaon only. The informaon contained in the Manual
is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision
website ( hps://www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals
trained in supporng the Product.
Trademarks
and other Hikvision's trademarks and logos are the
properes of Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their
respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL
AND THE PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND
FIRMWARE, ARE PROVIDED “AS IS” AND “WITH ALL FAULTS AND ERRORS”.
HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS
AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR
ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR
LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT,
TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN
Module Door
Staon User Manual
i
CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR
INHERENT SECURITY RISKS, AND HIKVISION SHALL NOT TAKE ANY
RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR
OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION
WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE
LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE
CONFORMS TO THE APPLICABLE LAW. ESPECIALLY, YOU ARE RESPONSIBLE,
FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT INFRINGE ON THE
RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND
OTHER PRIVACY RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY
PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR PRODUCTION
OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN
THE CONTEXT RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR
FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
Data Protecon
During the use of device, personal data will be collected, stored and
processed. To protect data, the development of Hikvision devices
incorporates privacy by design principles. For example, for device with facial
recognion features, biometrics data is stored in your device with
encrypon method; for ngerprint device, only ngerprint template will be
saved, which is impossible to reconstruct a ngerprint image.
As data controller, you are advised to collect, store, process and transfer
data in accordance with the applicable data protecon laws and regulaons,
including without limitaon, conducng security controls to safeguard
personal data, such as, implemenng reasonable administrave and
physical security controls, conduct periodic reviews and assessments of the
eecveness of your security controls.
Module Door
Staon User Manual
ii
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or
could result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not
avoided, could result in equipment damage, data loss,
performance degradaon, or unexpected results.
Note
Provides addional informaon to emphasize or
supplement important points of the main text.
Module Door Staon User Manual
iii
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved
by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC compliance: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protecon against harmful
interference in a residenal installaon. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instrucons, may cause harmful interference to radio
communicaons. However, there is no guarantee that interference will not
occur in a parcular installaon. If this equipment does cause harmful
interference to radio or television recepon, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit
dierent from that to
which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help
FCC
Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to
the following two condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference
that may cause undesired
operaon.
Module Door
Staon User Manual
iv
EU Conformity Statement
This product and - if applicable - the supplied accessories too are
marked with "CE" and comply therefore with the applicable
harmonized European standards listed under the EMC Direcve
2014/30/EU, the RoHS Direcve 2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol
cannot be disposed of as unsorted municipal waste in the
European Union. For proper recycling, return this product to your
local supplier upon the purchase of equivalent new equipment, or
dispose of it at designated collecon points. For more informaon
see: www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery
that cannot be disposed of as unsorted municipal waste in the
European Union. See the product documentaon for specic
baery informaon. The baery is marked with this symbol,
which may include leering to indicate cadmium (Cd), lead (Pb),
or mercury (Hg). For proper recycling, return the
baery to your
supplier or to a designated collecon point. For more informaon
see:www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
Module Door
Staon User Manual
v
Contents
1 Terminal and Wiring ................................................................................... 1
1.1 Appearance ....................................................................................................... 1
1.2 Terminal Descripon ......................................................................................... 7
1.3 Module Door Staon Wiring ........................................................................... 10
1.3.1 Door Lock Wiring .................................................................................... 10
1.3.2 Door Contact Wiring ............................................................................... 11
1.3.3 Exit
Buon Wiring .................................................................................. 12
2 Installaon ................................................................................................ 13
2.1 Congure Sub Module Address ....................................................................... 13
2.2 One-Module
Installaon ................................................................................. 14
2.2.1 One-Module Surface Mounng .............................................................. 14
2.2.2 One-Module Flush Mounng ................................................................. 17
2.3 Two-Module Installaon ................................................................................. 21
2.3.1 Two-Module Surface Mounng .............................................................. 21
2.3.2 Two-Module Flush Mounng ................................................................. 26
2.4 Three-Module Installaon .............................................................................. 30
2.4.1 Three-Module Surface Installaon ......................................................... 30
2.4.2 Three-Module Flush Mounng ............................................................... 34
2.5 More-Than-Three Module Installaon ............................................................ 38
2.5.1 More-than-Three Module Surface Mounng ......................................... 38
2.5.2 More-Than-Three Module Flush Mounng ............................................ 44
3 Acvaon ................................................................................................. 52
Module Door
Staon User Manual
vi
3.1 Acvate Device via Web .................................................................................. 52
3.2 Acvate Device via Client Soware ................................................................. 52
3.3 Edit Network Parameters ................................................................................ 53
4 Remote Conguraon via Web ................................................................ 54
4.1 Live View ......................................................................................................... 54
4.2 User Management .......................................................................................... 54
4.3 Number Sengs ............................................................................................. 55
4.4 Device Management ....................................................................................... 55
4.5 Parameters
Sengs ........................................................................................ 55
4.5.1 Local Parameters Sengs ....................................................................... 56
4.5.2 System
Sengs ....................................................................................... 57
4.5.3 Network Sengs .................................................................................... 60
4.5.4 Video & Audio
Sengs ........................................................................... 64
4.5.5 Image Sengs ........................................................................................ 67
4.5.6 Event
Sengs ......................................................................................... 70
4.5.7 Schedule Sengs .................................................................................... 73
4.5.8 Intercom Sengs .................................................................................... 73
4.5.9 Access Control Sengs ........................................................................... 76
5
Conguraon via Client Soware ............................................................. 79
5.1 Device Management ....................................................................................... 79
5.1.1 Add Online Device .................................................................................. 79
5.1.2 Add Device by IP Address ....................................................................... 80
5.1.3 Add Device by IP Segment ...................................................................... 80
5.2 Live View via Door Staon .............................................................................. 81
Module Door
Staon User Manual
vii
5.3 Video Intercom Sengs .................................................................................. 81
5.3.1 Receive Call from Door Staon ............................................................... 81
5.3.2 Search Call Logs ...................................................................................... 82
5.3.3 Upload Armed
Informaon .................................................................... 83
A.
Communicaon Matrix and Device Command ....................................... 84
Module Door Staon User Manual
viii
1 Terminal and Wiring
1.1 Appearance
Main Unit
Figure 1-1 Main Unit Appearance
Table 1-1 Appearance Descripon
No. Descripon
1 Microphone
2 Low Illuminaon IR Supplement Light
3 Built-in Camera
4 Loudspeaker
5 Call Buon
6 Nametag
7 TAMPER
8 Network Interface
9 Module-Connecng Interface (output)
10 Terminals
Module Door Staon User Manual
1
Note
•
Nametag area supports insert customized name card. The suggested
card size is: 58 (L) x 11.7(W) mm.
•
The module connecng interface is used to connect other funcon
module, such as nametag module, keypad module, card reader module,
etc. All these modules are known as sub module.
Two-Wire Main Unit
Figure 1-2 Two-Wire Main Unit
Table 1-2 Appearance Descripon
No. Descripon
1 Microphone
2 Low Illuminaon IR Supplement Light
3 Built-in Camera
4 Loudspeaker
5 Call Buon
6 Nametag
7 TAMPER
8 Two-Wire Interface
9 Module-Connecng Interface (output)
10 Terminals
Module Door Staon User Manual
2
Note
•
Nametag area supports insert customized name card. The suggested
card size is: 58 (L) x 11.7(W) mm.
•
The module connecng interface is used to connect other funcon
module, such as nametag module, keypad module, card reader module,
etc. All these modules are known as sub module.
Nametag Module
Figure 1-3 Nametag Module Appearance
Table 1-3 Appearance Descripon
No. Descripon
1 Call Buon
2 Nametag
3 Module-Connecng Interface (output)
4 Module-Connecng Interface (input)
5 Debugging Port
Module Door Staon User Manual
3
Keypad Module
Figure 1-4 Keypad Module Appearance
Table 1-4 Appearance Descripon
No. Descripon
1 Buon
2 Module-Connecng Interface (output)
3 Module-Connecng Interface (input)
4 Debugging Port
Indicator Module
Figure 1-5 Indicator Module
Module Door Staon User Manual
4
Table 1-5 Appearance Descripon
No. Descripon
1 Calling Indicator
2 Two-way Audio Indicator
3 Unlock Indicator
4 Module-connecng Interface (output)
5 Module-connecng Interface(input)
6 Debugging Port
Card Reader Module
Figure 1-6 Card Reader Module
Table 1-6 Appearance Descripon
No. Descripon
1 Card Reading Area
2 Module-connecng Interface (output)
3 Module-connecng Interface(input)
4 Debugging Port
Module Door Staon User Manual
5
Display Module
Figure 1-7 Display Module
Table 1-7 Descripon
No. Descripon No. Descripon
1 Screen 5 Back Buon
2 Up Buon 6 Module-connecng
Interface (output)
3 Down Buon 7 Module-connecng
Interface (input)
4 Conrm Buon 8 Debug Port
Informaon Module
Figure 1-8 Informaon Module
Module Door Staon User Manual
6
Table 1-8 Descripon
No. Descripon
1 Display Area
2 Module-connecng Interface (output)
3 Module-connecng Interface (input)
4 Debugging Port
Note
The debugging port is used for debugging only.
1.2 Terminal Descripon
Main Unit Terminals
Figure 1-9 Main Unit Terminals
Table 1-9 Descripons of Terminals and Interfaces
No. Interface Descripon
A1 NC1 Door Lock Relay Output (NC)
A2 NO1 Door Lock Relay Output (NO)
A3 COM Common Interface
A4 NC2 Door Lock Relay Output (NC)
Module Door Staon User Manual
7
No. Interface Descripon
A5 NO2 Door Lock Relay Output (NO)
A6 GND Grounding
A7 12 VDC Power Input
A8 GND Grounding
B1 AIN2 For the access of Door Magnec 2
B2 AIN1 For the access of Door Magnec 1
B3 AIN3 For the access of Exit Buon 1
B4 AIN4 For the access of Exit Buon 2
B5 485- Module-connecng Interface
B6 485+
B7 12 V OUT
B8 GND
C LAN PoE Network Interface(Supports IEEE
802.3af/at-Compliant Devices)
Two-Wire Main Unit Terminal
Figure 1-10 Two-Wire Main Unit Terminal
Module Door Staon User Manual
8
Table 1-10 Descripons of Terminals and Interfaces
No. Interface Descripon
A1 NC1 Door Lock Relay Output (NC)
A2 NO1 Door Lock Relay Output (NO)
A3 COM Common Interface
A4 NC2 Door Lock Relay Output (NC)
A5 NO2 Door Lock Relay Output (NO)
A6 GND Grounding
A7 12 VDC Reserved
A8 GND Grounding
B1 AIN2 For the access of Door Magnec 2
B2 AIN1 For the access of Door Magnec 1
B3 AIN3 For the access of Exit Buon 1
B4 AIN4 For the access of Exit Buon 2
B5 485- Module-connecng Interface
B6 485+
B7 12 V OUT
B8 GND
C Two-Wire Interface Two-Wire Interface
Module Door Staon User Manual
9
Sub Module Terminal
Figure 1-11 Sub Module Terminal
Table 1-11 Descripon
No. Interface Descripon
A1 485- Module-Connecng Interface (Input)
A2 485+
A3 12V IN
A4 GND
B1 485- Module-Connecng Interface (Output)
B2 485+
B3 12V OUT
B4 GND
1.3 Module Door Staon Wiring
1.3.1 Door Lock Wiring
Module Door Staon User Manual
10
Figure 1-12 Door Lock Wiring
Note
Terminal NC1/COM is set as default for accessing magnec lock/electric bolt;
terminal NO2/COM is set as default for accessing electric strike.
1.3.2 Door Contact Wiring
Figure 1-13 Door Contact Wiring
Module Door
Staon User Manual
11
Note
AIN1 and AIN2 are defaulted to connect door contact. Door contact connected to
AIN1 detects status of the lock that connected to NC1/NO1; Door contact connected
to AIN2 detects the status of the lock connected to NC2/NO2.
1.3.3 Exit Buon Wiring
Figure 1-14 Exit Buon Wiring
Note
AIN3 and AIN4 are set as default for connecng exit buon. Exit buon connected to
AIN3 opens the lock connected to NC1/NO1; Exit buon connected to AIN4 controls
the lock that connected to NC2/NO2.
Module Door Staon User Manual
12
2 Installaon
Note
•
Make sure the device in the package is in good condion and all the assembly
parts are included.
•
Sub module must work along with the main unit.
•
Set the sub module address before start the installaon steps.
•
Make sure the place for surface
mounng is at.
•
Make sure all the related equipment is power-o during the installaon.
•
Tools that you need to prepare for installaon:
Drill (ø6), cross screwdriver (PH1*150 mm), and gradienter.
2.1 Congure Sub Module Address
You need to set the sub module address via DIP switch before installaon.
Steps
1.
Remove the rubber cover on the rear panel of the sub module to expose the DIP
switch.
Figure 2-1 DIP Switch
2.
Set the sub module address according to the DIP rules, and install the rubber
cover back.
Module Door
Staon User Manual
13
Note
•
Bit 1, 2, 3, 4 are used to coding the sub module address. Bit 5, 6, 7 are
reserved. Set Bit 8 as on to enable a resistance (120Ω).
•
Valid sub module address is from 1 to 8. The address should be unique for
connecng to the main unit.
The sub module address and its corresponding switch status are displayed as
below.
Table 2-1 Descripon
Sub
Module
Address
1 2 3 4 5 6 7 8
Bit 1 ON OFF ON OFF ON OFF ON OFF
Bit 2 OFF ON ON OFF OFF ON ON OFF
Bit 3 OFF OFF OFF ON ON ON ON OFF
Bit 4 OFF OFF OFF OFF OFF OFF OFF ON
2.2 One-Module Installaon
2.2.1 One-Module Surface Mounng
Module Door Staon User Manual
14
Before You Start
Figure 2-2 Mounng Frame
Note
•
The dimension of one module mounng frame (W × H × D) is: 117 mm × 107 mm
× 32.7 mm.
•
The dimensions above are for reference only. The actual size can be slightly
dierent from the theorecal dimension.
Steps
1.
Paste the installaon Scker 1 onto the wall. Make sure the scker is placed
horizontally via measuring with the gradienter.
2.
Drill 4 holes according to the screw holes on the scker.
Note
•
The suggested size of hole is 6 (diameter) × 25 (depth) mm.
•
The suggested length of cables le outside is 100 mm.
Module Door Staon User Manual
15
Figure 2-3 Drill Screw Holes
3.
Remove the stricker and insert the expansion sleeves into the screw holes.
4.
Fix the
mounng frame onto the wall with 4 expansion bolts.
Figure 2-4 Fix the Mounng Frame
Module Door
Staon User Manual
16
5.
Connect the cables to the corresponding interfaces of the main unit and insert
the main unit into the frame.
Figure 2-5 Insert the Main Unit
6.
Fix the cover onto the frame.
Figure 2-6 Fix the Cover
2.2.2 One-Module Flush Mounng
Module Door Staon User Manual
17
Before You Start
Figure 2-7 Front and Side View of the Gang Box
Figure 2-8 Gang Box
Note
The dimension of one-module gang box is: 115 (W) × 134 (H) × 56 (D) mm. The
dimension is for reference only.
Module Door Staon User Manual
18
Steps
1.
Drill an installaon hole, and pull the cables out.
Note
•
The suggested dimension of installaon hole is 118 (W) × 108 (H) × 45.5 (D)
mm.
•
The suggested length of cables le outside is 100 mm.
Figure 2-9 Drill Installaon Hole
2.
Remove the plasc sheet of the cable entry.
3.
Mark the gang box screw holes on the wall.
1) Route the cables through the gang box hole.
2) Insert the gang box into the
installaon hole.
3) Mark the gang box screw holes' posion with a marker, and take out the
gang box.
Figure 2-10 Mark the Screw Holes
Module Door Staon User Manual
19
4.
Drill 4 holes according to marks on the wall, and insert the expansion sleeves
into the screw holes.
Note
The suggested size of the hole is 6 (diameter) × 45 (depth) mm.
5.
Route the cables through the gang box hole. Insert the gang box into the
installaon hole. Fix the gang box with 4 expansion bolts.
Figure 2-11 Fix the Gang Box
6.
Fill the gap between the gang box and the wall with concrete. Remove the 4
mounng ears with tool aer concrete is dry.
Figure 2-12 Remove the Mounng Ears
Module Door
Staon User Manual
20
7.
Connect the cables to the corresponding interfaces of the main unit and insert
the unit into the gang box.
Figure 2-13 Insert the Main Unit
8.
Fix the cover and the main unit with 2 socket head cap screws by using a
hexagon wrench (supplied).
Figure 2-14 Fix the Cover
2.3 Two-Module Installaon
2.3.1 Two-Module Surface Mounng
Module Door Staon User Manual
21
Before You Start
Figure 2-15 Mounng Frame
Note
•
The dimension of two-module mounng frame (W × H × D) is: 219 mm × 107
mm × 32.7 mm.
•
The dimensions above are for reference only. The actual size can be slightly
dierent from the theorecal dimension.
Steps
1.
Paste the installaon Scker 1 onto the wall. Make sure the scker is placed
horizontally via measuring with the gradienter.
2.
Drill 4 holes according to the screw holes on the scker. The suggested size of
hole is 6 (diameter) × 25 (depth) mm. The suggested length of cables le outside
is 270 mm.
Module Door
Staon User Manual
22
Figure 2-16 Drill Screw Holes
3.
Remove the scker and insert the expansion sleeves into the screw holes.
4.
Fix the mounng frame onto the wall with 4 expansion bolts.
Figure 2-17 Fix the Mounng Frame
5.
Thread the module-connecng line across the thread hole of the frame. Pass the
main unit connecng lines across the thread hole to the upper grid.
Module Door
Staon User Manual
23
Figure 2-18 Placement of Lines
6.
Connect the cables.
1) Connect the lines and
module-connecng line to the corresponding
interfaces of the main unit, then place the main unit into the upper grid.
2) Connect the other end of the module-connecng line to the input interface
of the sub module.
3) Organize the cable with cable
e in the package. The suggested cable
connecon picture as shown below.
Module Door
Staon User Manual
24
Figure 2-19 Line Connecon Eect Picture
7.
Insert the modules into the frame aer wiring. The main unit must be placed in
the top grid.
Figure 2-20 Insert the Modules
8.
Use the hexagon wrench in the package to x the cover onto the frame.
Module Door
Staon User Manual
25
Figure 2-21 Fix the Cover
2.3.2 Two-Module Flush Mounng
Before You Start
Figure 2-22 Gang Box
Module Door
Staon User Manual
26
Note
The dimension of two-module gang box is: 237 (W) × 134 (H) × 56 (D) mm. The
dimension is for reference only.
Steps
1.
Drill the installaon hole, and pull the cable out.
Note
•
The suggested dimension of installaon hole is 220 (W) × 108 (H) × 45.5 (D)
mm.
•
The suggested length of cables le outside is 270 mm.
Figure 2-23 Drill the Installaon Hole
2.
Select a cable entry and remove the
plasc sheet.
3.
Mark the gang box screw holes on the hole.
1) Routs the cables through the gang box hole.
2) Insert the gang box into the installaon hole.
3) Mark the gang box screw holes'
posion with a marker, and take out the
gang box.
Module Door
Staon User Manual
27
Figure 2-24 Mark the Screw Holes
4.
Drill 4 holes according to the marks on the wall, and insert the expansion sleeves
into the screw holes. The suggested size of hole is 6 (diameter) × 45 (depth) mm.
5.
Fix the gang box with 4 expansion bolts.
Figure 2-25 Fix the Gang Box
6.
Fill the gap between the gang box and the wall with concrete. Remove the
mounng ears with tool aer concrete is dry.
Module Door
Staon User Manual
28
Figure 2-26 Remove the Mounng Ears
7.
Connect cables and insert the modules.
1) Connect Cable 1 and one end of Cable 2 to the corresponding interfaces of
the main unit, then insert the main unit into the upper grid.
2) Connect the other end of Cable 2 to the input interface of the sub module.
Insert it into the lower grid.
Figure 2-27 Connect Cables and Insert the Modules
Module Door
Staon User Manual
29
Note
Cable 1 refers to the cables pulled out from the wall that connected to the main
unit. Cable 2 refers to the module-connecng line in the accessory package.
8.
Fix the cover with 2 socket head cap screws by using a hexagon wrench
(supplied).
Figure 2-28 Fix the Cover
2.4 Three-Module
Installaon
2.4.1 Three-Module Surface Installaon
Before You Start
Figure 2-29 Mounng Frame
Module Door Staon User Manual
30
Note
•
The dimension of two-module mounng frame (W × H × D) is: 320.8 mm × 107
mm × 32.7 mm.
•
The dimensions above are for reference only. The actual size can be slightly
dierent from the theorecal dimension.
Steps
1.
Paste the installaon scker 1 onto the wall. Make sure the scker is placed
horizontally via measuring with the gradienter.
2.
Drill 4 holes according to the screw holes on the scker.The suggested size of
hole is 6 (diameter) × 25 (depth) mm. The suggested length of cables le outside
is 270 mm.
Figure 2-30 Drill Screw Holes
3.
Remove the scker and insert the expansion sleeves into the screw holes.
4.
Fix the mounng frame onto the wall with 4 expansion bolts.
Module Door
Staon User Manual
31
Figure 2-31 Fix the Mounng Frame
Note
The mounng frame should be placed exactly as shown below for this step. The
tamper plate should be at the low right of the rst grid.
Figure 2-32 Mounng Frame
5.
Thread the module-connecng line across the thread holes of the frame. Pass
the main unit connecng line across the thread hole to the top grid.
Module Door
Staon User Manual
32
Figure 2-33 Placement of Lines
6.
Connect the cables.
1) Connect the lines and
module-connecng line 1 to the corresponding
interfaces of the main unit, then place the main unit into the upper grid.
2) Connect the other end of the module-connecng line 1 to the input interface
of the sub module. Connect two sub modules via module-connecng line 2.
3) Organize the cables with cable e in the package. The suggested cable
connecon picture as shown below.
Figure 2-34 Line Connecon Eect Picture
7.
Insert the modules into the frame aer wiring. The main unit must be placed in
the top grid.
Module Door
Staon User Manual
33
Figure 2-35 Insert the Modules into the Frame
8.
Use the hexagon wrench in the package to x the cover onto the frame.
Figure 2-36 Fix the Cover
2.4.2 Three-Module Flush Mounng
Module Door Staon User Manual
34
Before You Start
Figure 2-37 Gang Box
Note
•
The dimension of one-module gang box is: 338.8(W)×134(H)×56(D) mm.
•
The dimensions above are for reference only. The actual size can be slightly
dierent from the theorecal dimension.
Steps
1.
Cave the
installaon hole, and pull the cable out.The suggested dimension of
installaon hole is 321.8(W)×108(H)×45.5(D) mm. The suggested length of cables
le outside is 270 mm.
Module Door
Staon User Manual
35
Figure 2-38 Cave the Installaon Hole
2.
Select a cable entry and remove the plasc sheet.
3.
Mark the gang box screw holes on the wall.
1) Route the cables through the gang box hole.
2) Insert the gang box into the installaon hole.
3) Mark the gang box screw holes'
posion with a marker, and take out the
gang box.
Figure 2-39 Mark the Screw Holes
4.
Drill 4 holes according to marks on the wall, and insert the expansion sleeves
into the screw holes. The suggested size of hole is 6 (diameter) × 45 (depth) mm.
5.
Fix the gang box with 4 expansion bolts.
Module Door
Staon User Manual
36
Figure 2-40 Fix the Gang Box
6.
Fill the gap between the gang box and wall with concrete. Remove the mounng
ears with tool aer concrete is dry.
Figure 2-41 Remove the Mounng Ears
7.
Connect cables and insert the modules.
1) Connect Cable 1 and one end of Cable 2 to the corresponding interfaces of
the main unit, then insert the main unit into the upper grid.
2) Connect the other end of Cable 2 to the input interface of Sub Module 1.
Connect one end of Cable 3 to the output interface of Sub Module 1 and
insert it into the middle grid.
3) Connect the other end of Cable 3 to the input interface of Sub Module 2.
Insert it into the boom grid.
Module Door
Staon User Manual
37
Figure 2-42 Connect Cables and Insert Modules
Note
Cable 1 refers to the cables pulled out from the wall that connected to the main
unit. Cable 2 and Cable 3 refer to the module-connecng line in the accessory
package.
8.
Fix the cover and the main unit with 2 socket head cap screws by using a
hexagon wrench (supplied).
Figure 2-43 Fix the Cover
2.5 More-Than-Three Module Installaon
2.5.1 More-than-Three Module Surface Mounng
Module Door Staon User Manual
38
Before You Start
Figure 2-44 Mounng Frame
Note
•
It takes two three-module mounng frames. The dimension of three-module
mounng frame (W × H × D) is: 320.8 mm × 107 mm × 32.7 mm.
•
The dimensions above are for reference only. The actual size can be slightly
dierent from the theorecal dimension.
Steps
1.
Paste two
Scker 1 onto the wall. Make sure the sckers are placed horizontally
via measuring with the gradienter.
2.
Drill 8 holes according to the screw holes on the scker.
Note
•
The suggested size of hole is 6 (diameter) × 25 (depth) mm.
•
The suggested length of cables le outside is 270 mm.
3.
Pull out the cable through the cable hole of the le scker.
Module Door
Staon User Manual
39
Figure 2-45 Drill Screw Holes
4.
Remove the sckers and insert the expansion sleeves into the screw holes.
5.
Thread the module-connecng line (400 mm) and grounding line across the
thread hole of both frames.
Figure 2-46 Place the Grounding Line and Module-Connecng Line
Module Door
Staon User Manual
40
Note
•
There are 6 module-connecng lines in the package: 190 mm × 4 and 400
mm × 2.
•
Take the 400 mm module-connecng line for this step.
•
The green-yellow line in the package is for grounding.
6.
Fix the mounng frame onto the wall with 8 expansion bolts.
Figure 2-47 Fix the Mounng Frame
7.
Pass the main unit connecng line across the thread hole to the top grid of the
le frame. Thread the module-connecng line (190 mm) across the thread hole
of the frame. The lines should be placed as shown below.
Figure 2-48 Placement of Lines
8.
Connect the cables.
Module Door
Staon User Manual
41
1) Connect the cables from the wall and module-connecng line 1 to the
corresponding interfaces of the main unit, then place the main unit into the
upper grid.
2) Connect the other end of the module-connecng line 1 to the input interface
of the sub module. Connect all sub modules via module-connecng lines.
3) Organize the cable with cable e in the package. The suggested cable
connecon picture as shown below.
Figure 2-49 Line Connecon Eect Picture
9.
Insert the modules into the frame aer wiring. The main unit must be placed in
the top grid on the le.
Module Door
Staon User Manual
42
Figure 2-50 Insert the Modules
10.
Pull the grounding line out and xed its two end to the screw on the cover.
Figure 2-51 Connect the Grounding Line to the Cover
11.
Use the hexagon wrench in the package to x the cover onto the frame.
Module Door
Staon User Manual
43
Figure 2-52 Fix the Cover
2.5.2 More-Than-Three Module Flush
Mounng
Module Door Staon User Manual
44
Before You Start
Figure 2-53 Gang Box
Note
It takes two three-module gang boxes. The dimension of the gang box is: 338.8 (W) ×
134 (H) × 56 (D) mm. The dimension is for reference only.
Module Door Staon User Manual
45
Steps
1.
Drill the installaon hole, and pull the cable out.The suggested dimension of
installaon hole is 321.8 (W) × 315 (H) × 45.5 (D) mm. The suggested length of
cables le outside is 270 mm.
Figure 2-54 Cave the
Installaon Hole
2.
Connect two gang boxes as below.
Figure 2-55 Connect Two Gang Boxes
3.
Select a cable entry and remove the plasc sheet.
Module Door
Staon User Manual
46
4.
Remove the plasc sheets on the side of the gang boxes (shown as 1 and 2)
below:
Figure 2-56 Remove the Plasc Sheets
5.
Mark the gang box screw holes on the wall.
1) Route the cables through the gang box hole.
2) Insert the gang box into the
installaon hole.
3) Mark the gang box screw holes' posion with a marker, and take out the
gang box.
Figure 2-57 Mark the Screw Holes
Module Door
Staon User Manual
47
6.
Drill 8 holes according to the marks on the wall, and insert the expansion sleeves
into the screw holes. The suggested size of hole is 6 (diameter) × 45 (depth) mm.
7.
Fix the gang boxes with 8 expansion bolts.
Figure 2-58 Fix the Gang Boxes
8.
Fill the gap between the gang box and wall with concrete. Remove the mounng
ears with tool aer concrete is dry. Route the grounding line through the cable
entries.
Figure 2-59 Remove the Mounng Ears
Note
The green-yellow line in the package is for grounding.
9.
Connect cables and insert the modules.
Module Door
Staon User Manual
48
1) Connect Cable 1 and one end of Cable 2 to the corresponding interfaces of
the Main Unit, then place the Main Unit into the upper grid of the le gang
box.
2) Connect the other end of Cable 2 to the input interface of Sub Module 1.
Connect one end of Cable 3 to the output interface of Sub Module 1 and
insert it into the middle grid of the le gang box.
3) Finish the wiring and inserng according to the cable number and the
posion shown as below.
Figure 2-60 Install Mounng Frame
The cables connect to each module shown as below.
Figure 2-61 Cables Connecon
Module Door
Staon User Manual
49
Note
•
Cable 2,3,5 and 6 are the module-connecng lines (190 mm) in the package.
•
Cable 4 is the module-connecng line (400 mm) in the package.
•
Main unit must be put in the top grid.
10.
Pull the grounding line out and xed its two end to the screw on the cover.
Figure 2-62 Connect the Grounding Line to the Cover
11.
Fix the cover with 2 socket head cap screws by using a hexagon wrench
(supplied).
Module Door
Staon User Manual
50
Figure 2-63 Fix the Cover
Module Door
Staon User Manual
51
3 Acvaon
3.1 Acvate Device via Web
You are required to acvate the device rst by seng a strong password for it before
you can use the device.
Default parameters of the door staon are as follows:
•
Default IP Address: 192.0.0.65.
•
Default Port No.: 8000.
•
Default User Name: admin
Steps
1.
Power on the device, and connect the device to the network.
2.
Enter the IP address into the address bar of the web browser, and click Enter to
enter the
acvaon page.
Note
The computer and the device should belong to the same subnet.
3.
Create and enter a password into the password eld.
4.
Conrm the password.
5.
Click OK to acvate the device.
3.2
Acvate Device via Client Soware
You can only congure and operate the door staon aer creang a password for
the device acvaon.
Default parameters of door staon are as follows:
•
Default IP Address: 192.0.0.65.
•
Default Port No.: 8000.
•
Default User Name: admin.
Steps
1.
Run the client
soware, click Maintenance and Management → Device
Management → Device to enter the page.
2.
Click Online Device.
Module Door
Staon User Manual
52
3.
Select an inacvated device and click Acvate.
4.
Create a password, and conrm the password.
Note
We highly recommend you to create a strong password of your own choosing
(using a minimum of 8 characters, including at least three kinds of following
categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we
recommend you change your password regularly, especially in the high security
system, changing the password monthly or weekly can
beer protect your
product.
5.
Click OK to
acvate the device.
Note
•
When the device is not acvated, the basic operaon and remote operaon
of device cannot be performed.
•
You can hold the Ctrl or Shi key to select mulple devices in the online
devices, and click the Acvate buon to acvate devices in batch.
3.3 Edit Network Parameters
To operate and congure the device via LAN (Local Area Network), you need connect
the device in the same subnet with your PC. You can edit network parameters via
iVMS-4200 client soware.
Steps
1.
Select an online
acvated device and click the Modify Nenfo.
2.
Edit the device IP address and gateway address to the same subnet with your
computer.
3.
Enter the password and click OK to save the network parameters modicaon.
Note
•
The default port No. is 8000.
•
The default IP address of the door staon is 192.0.0.65.
•
Aer eding the network parameters of device, you should add the devices
to the device list again.
Module Door Staon User Manual
53
4 Remote Conguraon via Web
4.1 Live View
In the browser address bar, enter the IP address of the device, and press the Enter
key to enter the login page.
Enter the user name and password and click Login to enter the Live View page. Or
you can click Live View to enter the page.
Figure 4-1 Live View
•
You can start/stop live view, capture, record, audio on/o, two-way audio, etc.
•
The stream type can be set as main stream or sub stream.
•
For IE (Internet Explorer) users, the device support two-way audio
communicaon.
4.2 User Management
You can add, delete or search the informaon of the user.
Click User to enter the sengs page.
•
Click Add and enter the Name, Floor No. and Room No. to add.
•
Click Edit to modify the
informaon of the user.
•
Check the box of the user and click Delete to delete the selected user.
•
Enter the keyword and click search icon. The informaon will display in the list.
Module Door
Staon User Manual
54
Note
User management funcon may vary with dierent models. Please refer to the
actual product.
4.3 Number Sengs
Link the room No. and SIP numbers.
Click Number
Sengs to enter the page.
Click Add, set the Room No. and SIP numbers in the pop-up dialog box.
4.4 Device Management
You can manage the linked device on the page.
Click Device List to enter the sengs page.
Add Device
•
Click Add to add the indoor staon or sub door staon. Enter the
parameters and click OK to add.
•
Click Import. Enter the informaon of the device in the template to
import devices in batch.
Export
Click Export to export the informaon to the PC.
Synchronize
Click Synchronize to synchronize the informaon.
4.5 Parameters
Sengs
Click Conguraon to set the parameters of the device.
Remote conguraon in iVMS-4200 and Batch Conguraon Tool is the same as that
in Web. Here takes the conguraon in web for example.
Module Door
Staon User Manual
55
Note
Run the browser, click → Internet Opons → Security to disable the Protected
Mode.
4.5.1 Local Parameters Sengs
You can congure the parameters of the live view, record les and captured pictures.
The record
les and captured pictures are the ones you record and capture by using
the web browser. You can also set and view the saving paths of the captured pictures
and recorded videos on the PC that running the web browser.
Live View Parameters
Stream Type
Set the stream type as Main Stream or Sub-stream.
Play Performance
Set the live view performance to Shortest Delay, Balanced or Fluent.
Auto Start Live View
Check Yes to enable the
funcon.
Image Format
Select the image format for picture capture.
Click Save to enable the
sengs.
Record File Parameters
Record File Size
Select the packed size of the manually recorded and downloaded video
les to 256M, 512M or 1G. Aer the selecon, the maximum record le
size is the value you selected.
Save record
les to
Set the saving path for the manually recorded video les.
Click Save to enable the sengs.
Picture and Clip
Sengs
Save snapshots in live view to
Module Door
Staon User Manual
56
Set the saving path of the manually captured pictures in live view mode.
Note
You can click Browse to change the directory for saving the clips and
pictures, and click Open to open the set folder of clips and picture saving.
Click Save to enable the sengs.
4.5.2 System Sengs
Follow the instrucons below to congure the system sengs, include System
Sengs, Maintenance, Security, and User Management, etc.
Click System to enter the
sengs page.
Basic Informaon
Click System Sengs → Basic Informaon to enter the sengs page. On
the page, you can edit Device Name and Device No. Set the Language and
System Type according to your needs.
Click Save to enable the
sengs.
Time Sengs
Click System Sengs → Time Sengs to enter the sengs page. Select the
Time Zone of your locaon from the drop-down list.
•
Enable NTP, set the Server Address, NTP Port and Interval.
•
Enable Manual Time Sync., set the me manually or check the Sync.
with computer me.
Click Save to enable the sengs.
DST
Click System Sengs → DST to check Enable DST. Set the parameters
according to your needs and click Save to enable the sengs.
Maintenance
Click Maintenance → Upgrade & Maintenance to enter the sengs page.
Module Door
Staon User Manual
57
Figure 4-2 Maintenance
•
Reboot: Click Reboot to reboot the device.
•
Restore
Click Restore to reset all the parameters, except the IP parameters
and user informaon, to the default sengs.
Default
Click Default to restore all parameters to default sengs.
•
Export parameters:
1. Select Device Parameters, and click Export to pop up the dialog box.
2. Set and conrm the encrypon password.
3. Click OK to export parameters.
•
Import Cong. File:
1. Click browse icon to select the conguraon le.
2. Click Import and enter the encrypon password to import.
•
Upgrade: Click browse icon to select the upgrade le.
Note
The upgrading process will last 1 to 10 minutes, do not power o during
the upgrading. The device reboots automacally aer upgrading.
Authencaon
Click Security → Authencaon to enter the sengs page. On the page,
you can select RTSP Authencaonaccording to your actual needs.
Click Save to enable the
sengs.
Module Door
Staon User Manual
58
Security Service
Click Security → Security Service to enter the sengs page. On the page,
you can enable SSH according to your actual needs.
Click Save to enable the sengs.
User Management
Click User Management to enter the sengs page.
Administrator can edit the permission for the users.
Note
We highly recommend you to create a strong password of your own
choosing (using a minimum of 8 characters, including at least three kinds of
following categories: upper case leers, lower case leers, numbers, and
special characters) in order to increase the security of your product. And we
recommend you change your password regularly, especially in the high
security system, changing the password monthly or weekly can beer
protect your product.
Online Users
Click
User Management → Online Users to enter the page.
Figure 4-3 Online Users
Click Refresh to get the present informaon.
Arming/Disarming
Informaon
Click User Management → Arming/Disarming Informaon to view the
informaon. Click Refresh to get the present informaon.
Module Door
Staon User Manual
59
4.5.3 Network Sengs
TCP/IP Sengs
TCP/IP sengs must be properly congured before you operate the device over
network. The device supports IPv4.
Steps
1.
Click Network → Basic Sengs → TCP/IP to enter the sengs page.
Figure 4-4 TCP/IP Sengs
2.
Congure the network parameters.
-
Check DHCP, the device will get the parameters automacally.
-
Set the IPv4 Address, IPv4 Subnet Mask and IPv4 Default Gateway
manually.
3.
Congure the corresponding DNS server parameters.
Module Door
Staon User Manual
60
4.
Click Save to enable the sengs.
Port Sengs
Steps
1.
Click Network → Basic
Sengs → Port to enter the sengs page.
Figure 4-5 Port Sengs
2.
Set the ports of the device.
HTTP Port
The default port number is 80, and it can be changed to any port No. which
is not occupied.
HTTPS Port
The default port number is 443, and it can be changed to any port No. which
is not occupied.
RTSP Port
The default port number is 554.
Server Port
The default server port number is 8000, and it can be changed to any port
No. ranges from 2000 to 65535.
3.
Click Save to enable the
sengs.
Wi-Fi
Sengs
Steps
1.
Go to Network → Basic
Sengs → Wi-Fi to enter the sengs page.
2.
Enable Wi-Fi.
Module Door
Staon User Manual
61
3.
Click Add, and set corresponding parameters. and Password of the Wi-Fi.
1) Enter the SSID.
2) Select Working Mode.
3) Select Encrypon Type.
4) Click OK.
5)
Oponal: Click Refresh to get the present informaon.
4.
Click Network
Sengs, and set corresponding parameters.
5.
Select Security Mode.
6.
Click Connect.
SIP Seng
Steps
1.
Click Network → Basic Sengs → SIP to enter the sengs page.
Figure 4-6 SIP Sengs
2.
Check Enable VOIP Gateway.
3.
Congure the SIP parameters.
4.
Click Save to enable the sengs.
FTP
Sengs
Module Door Staon User Manual
62
Steps
1.
Click Network → Advanced → FTP to enter the sengs page.
Figure 4-7 FTP Sengs
2.
Check Enable FTP.
3.
Select Server Type.
4.
Input the Server IP Address and Port.
5.
Congure the FTP Sengs, and the user name and password are required for the
server login.
6.
Set the Directory Structure, Parent Directory and Child Directory.
Module Door
Staon User Manual
63
7.
Set the picture naming rules.
8.
Click Save to enable the sengs.
Plaorm Access
Plaorm access provides you an opon to manage the devices via plaorm.
Steps
1.
Click Network → Advanced
Sengs → Plaorm Access to enter the sengs
page.
2.
Check the checkbox of Enable to enable the
funcon.
3.
Select the
Plaorm Access Mode.
Note
Hik-Connect is an applicaon for mobile devices. With the App, you can view live
image of the device, receive alarm nocaon and so on.
4.
Create a Stream Encrypon/Encrypon for the device.
Note
6 to 12 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are
recommended to use a combinaon of no less than 8 leers or numbers.
5.
Click Save to enable the
sengs.
4.5.4 Video & Audio
Sengs
Video Parameters
Steps
1.
Click Video/Audio → Video to enter the sengs page.
Module Door
Staon User Manual
64
Figure 4-8 Video Parameters
2.
Select the Stream Type.
3.
Congure the video parameters.
Stream Type
Select the stream type to main stream or sub stream.
Video Type
Select the stream type to video stream, or video & audio composite stream.
The audio signal will be recorded only when the Video Type is Video &
Audio.
Resoluon
Select the resoluon of the video output.
Bitrate Type
Select the bitrate type to constant or variable.
Video Quality
When bitrate type is selected as Variable, 6 levels of video quality are
selectable.
Frame Rate
Set the frame rate. The frame rate is to describe the frequency at which the
video stream is updated and it is measured by frames per second (fps). A
higher frame rate is advantageous when there is movement in the video
stream, as it maintains image quality throughout.
Module Door
Staon User Manual
65
Max. Bitrate
Set the max. bitrate from 32 to 16384 Kbps. The higher value corresponds to
the higher video quality, but the beer bandwidth is required.
Video Encoding
The device supports H.264.
I Frame Interval
Set I Frame Interval from 1 to 400.
4.
Click Save to save the sengs.
Audio Parameters
Steps
1.
Click Video/Audio → Audio to enter the sengs page.
Figure 4-9 Audio Sengs
2.
Congure the stream type and the audio encoding type.
Stream Type
Select the stream type to main stream or sub stream.
Audio Encoding
The device support G.711ulaw and G.711 alaw.
3.
Adjust the Input Volume, Output Volume and Speak Volume.
Note
Available range of volume: 0 to 10.
4.
Click Save to save the
sengs.
Module Door
Staon User Manual
66
4.5.5 Image Sengs
Display Sengs
Congure the image adjustment, backlight sengs and other parameters in display
sengs.
Steps
1.
Click Image → Display Sengs to enter the display sengs page.
Figure 4-10 Display Sengs
2.
Select the Format.
3.
Set the display parameters.
WDR
Wide Dynamic Range can be used when there is a high contrast of the bright
area and the dark area of the scene.
Brightness
Brightness describes bright of the image, which ranges from 1 to 100.
Contrast
Contrast describes the contrast of the image, which ranges from 1 to 100.
Saturaon
Saturaon describes the colorfulness of the image color, which ranges from 1
to 100.
Sharpness
Sharpness describes the edge contrast of the image, which ranges from 1 to
100.
Module Door
Staon User Manual
67
4.
Set the Day/Night Mode.
Figure 4-11 Day/Night Mode
-
Set Day Mode or Night Mode manually.
-
Set the mode as Auto and edit the sensivity according to your needs.
-
Set the mode as Scheduled-Switch. Set the start
me and end me.
Note
Dayme is from congured start me to congured me. The rest of the me is
set as night by default.
5.
Set the backlight parameters.
Module Door
Staon User Manual
68
Figure 4-12 Backlight
1) Check the checkbox to enable BLC.
2) Select BLC Area.
6.
Click Save to enable the
sengs.
OSD Sengs
You can customize the camera name, me/date format, display mode, and OSD size
displayed on the live view.
Steps
1.
Click Image → OSD Sengs to enter the sengs page.
2.
Check the corresponding checkbox to select the display of camera name, date or
week if required.
3.
Edit the Camera Name.
4.
Select from the drop-down list to set the Time Format and Date Format.
5.
Adjust the OSD
posion.
6.
Click Save to enable the sengs.
Target Cropping
Module Door Staon User Manual
69
Steps
1.
Click Image.
2.
Enable target cropping.
3.
Click " " to crop photo.
4.
Click " " to crop video.
5.
Select Cropping Resoluon.
6.
Click Save.
4.5.6 Event Sengs
Moon Detecon
Moon detecon detects the moving objects in the congured surveillance area,
and a series of acons can be taken when the alarm is triggered.
Steps
1.
Click Event → Moon to enter the sengs page.
Module Door
Staon User Manual
70
Figure 4-13 Moon Detecon
2.
Check Enable Moon Detecon to enable the funcon.
3.
Click Draw Area. Click and drag the mouse on the live video to draw a moon
detecon area. Click Stop Drawing to nish drawing one area. Click Save to save
the
sengs.
Clear Area
Click Clear All to clear all of the areas.
Adjust Sensivity Move the slider to set the sensivity of the detecon.
4.
Click Arming Schedule to edit the arming schedule.
5.
Click on the me bar and drag the mouse to select the me period. Click Save to
save the sengs.
Delete Schedule
Click Delete to delete the current arming schedule.
6.
Click Linkage Method to enable the linkages.
Nofy Surveillance Center
Module Door
Staon User Manual
71
Send an excepon or alarm signal to the remote management soware
when an event occurs.
7.
Click Save to enable the sengs.
Event Linkage
Steps
1.
Click Event → Basic Event → Event Linkage to enter the sengs page.
Figure 4-14 Event Linkage
2.
Select the Major Type as Device Event or Door Event.
Module Door
Staon User Manual
72
3.
Select the type of the Normal Linkage for the event.
4.
Click Save to enable the sengs.
4.5.7 Schedule Sengs
You can create call schedule, or else the device will call indoor staon all day by
default.
Steps
1.
Click Schedule → Video Intercom .
2.
Click the next row below Enable Indoor Staon All Day by Default.
3.
Enter Schedule Name.
4.
Select Call Type.
5.
Set Weekly Schedule.
1) Click Weekly Schedule.
2) Drag mouse to set the schedule according to the actual needs.
3)
Oponal: Click the copy icon to copy the schedule to other days according to
the actual needs.
4) Click Save.
6.
Set Holiday Schedule.
1) Click Holiday Schedule.
2) Click Add.
3) Set Start Time and End Time.
4) Select Call Type.
5) Drag mouse to set the schedule according to the actual needs.
6) Click OK.
7) You can edit or delete the schedule according to the actual needs.
8) Click Save.
Note
The holiday schedule have higher priority than weekly schedule when you
set the two schedule at the same me.
4.5.8 Intercom Sengs
Module Door Staon User Manual
73
Device ID Conguraon
Steps
1.
Click Device ID Sengs to enter the page.
Figure 4-15 Device ID Sengs
2.
Select the device type from the drop-down list, and set the corresponding
informaon.
3.
Click Save to enable the device number conguraon.
Note
•
For main door staon (D series or V series), the serial No. is 0.
•
For sub door staon (D series or V series), the serial No. cannot be 0. Serial
No. ranges from 1 to 99.
•
For each villa or building, at least one main door staon (D series or V series)
should be
congured, and one sub door staons (D series or V series) can be
customized.
•
For one main door staon (D series or V series), up to 8 sub door staons
can be congured.
Linked Network Sengs
Steps
1.
Go to Intercom → Session
Sengs to enter the sengs page.
2.
Set Register Number and
Registraon Password.
3.
Set Main Staon IP and VideoIntercom Server IP.
Module Door
Staon User Manual
74
4.
Enable Protocol 1.0.
5.
Click Save to enable the sengs.
Time Parameters
Go to Intercom → Time Parameters to enter the page.
Congure Max. Call Duraon, Max. Message Duraon, Max. Ring Duraon, and
click Save.
Ring-Back Tone Sengs
Click Intercom → Ringbacktone Sengs to enter the sengs page.
Click Add to select the ring tone from PC.
Note
Available Audio Format: WAV、AAC, Size: Less than 600 KB, Sample Rate: 8000Hz,
Mono.
Press Buon to Call
Steps
1.
Go to Intercom → Press
Buon to Call to enter the sengs page.
2.
Check Call Indoor Staon or Call Management Center as the buon call target.
Note
If you check Call Indoor Staon, you should enter the call indoor staon No.
3.
Click Save.
Input and Output
Go to Intercom → I/O Sengs to enter the sengs page.
Module Door
Staon User Manual
75
Figure 4-16 IO Input and Output
Select I/O Input No., Input, I/O Output No. and Output.
Click Save to enable the sengs.
4.5.9 Access Control Sengs
Door Parameters
Steps
1.
Click Access Control → Door Parameters to enter the sengs page.
Figure 4-17 Door Parameters
2.
Select the door and edit the door name.
3.
Set door contact status.
4.
Set lock
acon me.
5.
Click Save to enable the
sengs.
Card Security
Module Door Staon User Manual
76
Go to Access Control → Card Security to enter the sengs page.
Slide to enable card encrypon parameters and CPU card reading content. Click Save
to enable the sengs.
Elevator Control
Before You Start
•
Make sure your door staon is in the mode of main door staon. Only the main
door staon support elevator control funcon.
•
Make sure your door staon has been connected to the elevator controller via
RS-485 wire if you want to use RS-485 interface.
Steps
1.
Click Access Control → Elevator Control to enter the corresponding
conguraon page.
Figure 4-18 Elevator Control
2.
Check to enable elevator control funcon.
3.
Select an Elevator No., and select an elevator controller type for the elevator.
Module Door
Staon User Manual
77
4.
Set the Negave Floor.
5.
Select the Interface Type as RS-485 or Network Interface. And enable the
elevator control.
-
If you select RS-485, make sure you have connected the door
staon to the
elevator controller with RS-485 wire.
-
If you select Network interface, enter the elevator controller's IP address,
port No., user name, and password.
6.
Click Save to enable the sengs.
Note
•
Up to 4 elevator controllers can be connected to one door staon.
•
Up to 10 negave oors can be added.
•
Make sure the interface types of elevator controllers, which are connected
to the same door staon are consistent.
Module Door Staon User Manual
78
5 Conguraon via Client Soware
5.1 Device Management
Device management includes device acvaon, adding device, eding device, and
deleng device, and so on.
Aer running the iVMS-4200, video intercom devices should be added to the client
soware for remote conguraon and management.
5.1.1 Add Online Device
Before You Start
Make sure the device to be added is in the same subnet with your computer.
Otherwise, please edit network parameters rst.
Steps
1.
Click Online Device to select an acve online device.
2.
Click Add.
3.
Enter corresponding informaon, and click Add.
Module Door
Staon User Manual
79
Figure 5-1 Add to the Client
5.1.2 Add Device by IP Address
Steps
1.
Click +Add to pop up the adding devices dialog box.
2.
Select IP/Domain as Adding Mode.
3.
Enter corresponding
informaon.
4.
Click Add.
5.1.3 Add Device by IP Segment
Module Door Staon User Manual
80
You can add many devices at once whose IP addresses are among the IP segment.
Steps
1.
Click +Add to pop up the dialog box.
2.
Select IP Segment as Adding Mode.
3.
Enter corresponding informaon, and click Add.
5.2 Live View via Door Staon
Steps
1.
On the main page of the client soware, click Main View to enter the Live View
page.
2.
In the
le list of the window, double-click the device IP or click the play icon to
live view.
3.
Oponal: On the Live View page, control-click and select Capture to get the
picture of the live view.
5.3 Video Intercom
Sengs
The Video Intercom Management module provides the funcon of video intercom,
checking call logs and managing noce via the iVMS-4200 Client Soware.
Note
For the user with access control module permissions, the user can enter the Access
Control module and manage video intercom and search informaon.
You should add the device to the soware and congure the person to link the
device in Access Control module before your conguraon remotely.
On the main page, click AccessControlInfo → Video Intercom → Video
Intercom on the
le bar to enter the Video Intercom page.
5.3.1 Receive Call from Door
Staon
Steps
1.
Select the client
soware in the page to start calling the client and an incoming
call dialog will pop up in the client soware.
2.
Click Answer to answer the call. Or click Hang Up to decline the call.
Module Door
Staon User Manual
81
3.
Aer you answer the call, you will enter the In Call page.
Adjust the Volume of
Loudspeaker
Click to adjust the volume of loudspeaker.
Hang Up Click Hang Up to hang up.
Adjust the Volume of
Microphone
Click to adjust the volume of microphone.
Unlock Remotely
For door staon, you can click to open the
door remotely.
Note
•
One video intercom device can only connect with one client soware.
•
The maximum ring duraon can be set from 15s to 60s via the Remote
Conguraon of the video intercom device.
•
The maximum speaking duraon between indoor staon and iVMS-4200 can
be set from 120s to 600s via the Remote
Conguraon of indoor staon.
•
The maximum speaking duraon between door staon and iVMS-4200 can
be set from 90s to 120s via the Remote Conguraon of door staon.
5.3.2 Search Call Logs
Steps
1.
On the Video Intercom page, click Call Log to enter the page.
Figure 5-2 Search Call Logs
Module Door
Staon User Manual
82
2.
Set the search condions, including call status, device type, start me and end
me.
Call Status
Click ˅ to unfold the drop-down list and select the call status as Dialed,
Received or Missed. Or select All to search logs with all statuses.
Device Type
Click ˅ to unfold the drop-down list and select the device type as Indoor
Staon, Door Staon, Outer Door Staon or Analog Indoor Staon. Or
select All Devices to search logs with all device types.
Start Time/End Time
Click the
me icon to specify the start me and end me of a me period to
search the logs.
Reset the
Sengs Click Reset to reset all the congured search
condions.
3.
Click Search and all the matched call logs will display on this page.
4.
Oponal: Check the detailed informaon of searched call logs, such as call
status, ring/speaking
duraon, device name, resident organizaon, etc.
5.
Oponal: Input keywords in the Search eld to lter the desired log.
6.
Oponal: Click Export to export the call logs to your PC.
5.3.3 Upload Armed Informaon
Steps
1.
On the main page, click upper right
→ Tool → DeviceGuard to enter the page.
2.
Enable to arm or disarm the device.
Note
•
While device has been added to the client soware, the device armed by
default.
•
When the device is armed, the alarm logs upload to the client soware
automacally.
•
Click Alarm Applicaon → Event Search to search the alarm logs.
3.
Oponal: Click Arm All or Disarm All to arm or disarm all the device.
Module Door
Staon User Manual
83
A. Communicaon Matrix and Device
Command
Communicaon Matrix
Scan the following QR code to get the device communicaon matrix.
Note that the matrix contains all communicaon ports of Hikvision access
control and video intercom devices.
Figure A-1 QR Code of Communicaon Matrix
Device Command
Scan the following QR code to get the device common serial port
commands.
Note that the command list contains all commonly used serial ports
commands for all Hikvision access control and video intercom devices.
Figure A-2 Device Command
Module Door Staon User Manual
84
UD20209B
