1
Health Grill & Panini Press
Model No. SDA1574
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
*Please refer to the warranty section for terms of your extended guarantee.
*
2
Health Grill & Panini Press
Model No. SDA1574
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this grill.
• Before plugging your unit into the mains, visually check
that it is intact and has not suffered any transit damage.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• DO NOT use this product with a programmer, timer,
separate remote-control system or any other such
device.
• DO NOT immerse this appliance in water or any other
liquids.
• Cooking appliances should be positioned in a stable
situation with the handles (if any) positioned to avoid
spillage of liquids.
• DO NOT touch hot surfaces. Accessible surfaces are
liable to get hot during use. Always use the handle.
• Oven gloves should be used whilst using the health grill.
• Close supervision is required when using this appliance
3
Health Grill & Panini Press
Model No. SDA1574
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
near children.
• Never leave this appliance within reach of children.
• This appliance shall not be used by children from 0 to 8
years.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.
• Children shall not play with the appliance.
• Keep the appliance and its cord out of reach of children
less than 8 years.
• Cleaning and user maintenance shall not be made by
children.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst
connected to the mains supply.
• Always use this appliance on a solid, level, non-
flammable surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Regular, periodic checks should be carried out on the
supply cord to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• If the supply cord is damaged it is to be replaced by
qualified personnel in order to avoid a hazard.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
4
Health Grill & Panini Press
Model No. SDA1574
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• Allow the unit to cool before storage.
• DO NOT place the appliance near to flammable material
or high-pressure containers.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Ensure appliance is situated in an open area, do not allow
it to come in contact with cupboards, curtains, wall
coverings, clothing or other flammable materials.
• Unplug after each use. Grasp the plug, not the cord.
• DO NOT cover this appliance.
• Never place this appliance on an electric, gas, or any
other type of hob.
• Ensure adequate ventilation whilst cooking foods that are
prone to giving off smoke.
• WARNING! DO NOT attempt to move the panini grill
whilst it is hot.
• Clean the cooking plates with clean damp soft cloth – do
not use harsh abrasives or chemicals.
THIS APPLIANCE MUST BE EARTHED
5
Health Grill & Panini Press
Model No. SDA1574
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, click on “bank locator” and enter your
postcode to find out your nearest recycling site.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This symbol indicates that the surface gets hot and care must be
taken.
WARNING!
This designates a hazard with moderate risk, which may
result in severe injury if not adhered to.
6
Health Grill & Panini Press
Model No. SDA1574
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Before the first time you use your Grill
Remove all packing materials including in between the plates inside the grill and
dispose of responsibly.
Before using the grill for the first time, open the grill and wipe over both cooking
plates using a soft, clean damp cloth and dry with a cloth or paper towel.
For best results, lightly coat the cooking plates with a little cooking oil or cooking
oil spray.
If using your grill for the very first time it may emit a little smoke and odour
which will soon pass. This is the protective coating applied to elements
during transit and does not affect your appliance.
DO NOT use metal cooking tools with this appliance as damage may occur to
the non-stick coating. Only use wooden or plastic (nylon) tools.
1
3
1. Hinged Lid
2. Handle
3. Cooking Plates
4. Ready Indicator
2
4
5
6
7
5. Power Indicator
6. Drip Tray
7. 180° Catch
7
Health Grill & Panini Press
Model No. SDA1574
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Instructions for use
Place the grill on a solid, level, non-flammable surface away from wall cupboards,
curtains, etc.
1. Insert the mains plug (with dry
hands) into the mains socket.
2. The red Power Indicator (5) will
illuminate and the grill will begin
to heat.
3. Once the plates are at the
cooking temperature, the red
Power Indicator (5) and the
green Ready Indicator (4) will
both illuminated.
4. The grill is now ready to cook.
Using oven gloves, raise the lid by
the Handle (2) until it is in the
upright position. Place the food
to be cooked on the bottom
cooking plate.
5. Lower the top plate down using
the handle onto the food to cook.
Once the food has cooked, raise
the top plate using the handle
and remove the cooked food.
Ready Indicator (4)
Power Indicator (5)
8
Health Grill & Panini Press
Model No. SDA1574
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cooking times will vary according to food types and personal taste.
The lid adjusts and allows for the height of the food placed in the grill as it
has a floating lid and so maintains even contact with the food for best results.
During cooking, the green Ready Indicator (4) will cycle on and off to show
that the temperature is being maintained at the correct cooking
temperature.
Using Your Health Grill as an open Grill
• Place the grill on a solid, level, non-flammable surface away from wall
cupboards, curtains, etc.
• Ensure there is ample room for the grill to fully open out.
1. Press and hold the 180° Catch
button (7) then lift open the grill
all the way by the Handle (2) until
it lies flat on the work surface.
2. When the grill is ready to cook,
place the food to be cooked on
both cooking plates.
3. Once the food has cooked, remove
the food using wooden or plastic
cooking utensils to prevent
damage to the non-stick surfaces.
9
Health Grill & Panini Press
Model No. SDA1574
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cleaning your Panini Grill
• Always unplug the grill from the mains power supply before cleaning.
• Allow the unit to cool before cleaning.
• Do not clean any part of your panini grill in a dishwasher.
• Do not submerge any part of the main body of the grill or mains cable in water
or any other liquids.
• Wipe any excess oil from the cooking plates with kitchen roll or similar.
• Wipe clean the outside of the main body and the cooking plates with a soft
damp cloth.
• Never clean any part of the panini grill with harsh or abrasive cleaners.
Storing your Panini Grill
After cleaning and during storage, carefully close the grill plates and push the
Handle Lock closed.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse
cover missing. If in doubt, consult a qualified electrician.
If you need to remove the plug -DISCONNECT FROM THE MAINS - and then cut
it off the mains lead and immediately dispose of it safely. Never attempt to
reuse the plug or insert it into a socket outlet as there is a danger of electric
shock.
Technical Data
Model Number
SDA1574
Rated Voltage
220V-240V~ 50/60Hz
Rated power
750W
Protection Class
I (This appliance must be earthed)
10
Health Grill & Panini Press
Model No. SDA1574
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Disposal of the packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or Visit
www.recycle-more.co.uk, click on “bank locator” and enter your
postcode to find out your nearest recycling site.
11
Health Grill & Panini Press
Model No. SDA1574
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Daewoo is a registered trademark.
Produced and imported under license by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
