Network Trac Camera (for Trac Flow
Camera)
User Manual
Legal Informaon
©2021 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
Network Trac Camera (for Trac Flow Camera) User Manual
i
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.
Network Trac Camera (for Trac Flow Camera) User Manual
ii
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instrucon manual, may cause harmful
interference to radio communicaons. Operaon of this equipment in a residenal area is likely to
cause harmful interference in which case the user will be required to correct the interference at his
own expense.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the EMC Direcve 2014/30/EU, the LVD Direcve 2014/35/EU, the RoHS
Direcve 2011/65/EU.
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the European Union. For proper
recycling, return this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated collecon points. For
more informaon see: www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the baery to your supplier or to a
designated collecon point. For more informaon see: www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.
Network Trac Camera (for Trac Flow Camera) User Manual
iii
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
Network Trac Camera (for Trac Flow Camera) User Manual
iv
Safety Instrucon
Regulatory Informaon
This is a class A product and may cause radio interference in which case the user may be required
to take adequate measures.
Laws and Regulaons
Use of the product must be in strict compliance with the local laws and regulaons. Please shut
down the device in prohibited area.
Power Supply
• Use of the product must be in strict compliance with the local electrical safety regulaons.
• Use the power adapter provided by qualied manufacturer. Refer to the product specicaon for
detailed power requirements.
• It is recommended to provide independent power adapter for each device as adapter overload
may cause over-heang or a re hazard.
• Make sure that the power has been disconnected before you wire, install, or disassemble the
device in the authorized way according to the descripon in the manual.
• To avoid electric shock, DO NOT directly touch exposed contacts and components once the
device is powered up.
• DO NOT use damaged power supply devices (e.g., cable, power adapter, etc.) to avoid electric
shock, re hazard, and explosion.
• DO NOT directly cut the power supply to shut down the device. Please shut down the device
normally and then unplug the power cord to avoid data loss.
• The socket-outlet shall be installed near the equipment and shall be easily accessible.
• Make sure the power supply has been disconnected if the power adapter is idle.
• Connect to earth before connecng to the power supply.
Transportaon, Use, and Storage
• To avoid heat accumulaon, good venlaon is required for a proper operang environment.
• Store the device in dry, well-venlated, corrosive-gas-free, no direct sunlight, and no heang
source environment.
• Avoid re, water, and explosive environment when using the device.
• Install the device in such a way that lightning strikes can be avoided. Provide a surge suppressor
at the inlet opening of the equipment under special condions such as the mountain top, iron
tower, and forest.
• Keep the device away from magnec interference.
• Avoid device installaon on vibratory surfaces or places. Failure to comply with this may cause
device damage.
• DO NOT touch the heat dissipaon component to avoid burns.
Network Trac Camera (for Trac Flow Camera) User Manual
v
• DO NOT expose the device to extremely hot, cold, or humidity environments. For temperature
and humidity requirements, see device specicaon.
• No naked ame sources, such as lighted candles, should be placed on the equipment.
• DO NOT touch the sharp edges or corners.
• To prevent possible hearing damage, DO NOT listen at high volume levels for long periods.
Maintenance
• If smoke, odor, or noise arises from the device, immediately turn o the power, unplug the
power cable, and contact the service center.
• If the device cannot work properly, contact the store you purchased it or the nearest service
center. DO NOT disassemble or modify the device in the unauthorized way (For the problems
caused by unauthorized modicaon or maintenance, the company shall not take any
responsibility).
• Keep all packaging aer unpacking them for future use. In case of any failure occurred, you need
to return the device to the factory with the original packaging. Transportaon without the
original packaging may result in damage to the device and the company shall not take any
responsibility.
Network
• Please enforce the protecon for the personal informaon and the data security as the device
may be confronted with the network security problems when it is connected to the Internet.
Contact us if network security risks occur.
• Please understand that you have the responsibility to congure all the passwords and other
security sengs about the device, and keep your user name and password.
Lens
• DO NOT touch the lens with ngers directly in case the acidic sweat of the ngers erodes the
surface coang of the lens.
• DO NOT aim the lens at the strong light such as sun or incandescent lamp. The strong light can
cause fatal damage to the device.
Data
DO NOT disconnect the power during formang, uploading, and downloading. Or les may be
damaged.
Network Trac Camera (for Trac Flow Camera) User Manual
vi
Contents
Chapter 1 Acvaon and Login ................................................................................................... 1
1.1 Acvaon ............................................................................................................................... 1
1.1.1 Default Informaon ...................................................................................................... 1
1.1.2 Acvate via SADP .......................................................................................................... 1
1.1.3 Acvate via Web Browser ............................................................................................. 2
1.2 Login ...................................................................................................................................... 3
Chapter 2 Capture Conguraon ................................................................................................ 4
2.1 Set Data Collecon ................................................................................................................. 4
2.2 Set Capture Parameters ......................................................................................................... 6
2.2.1 Set Supplement Light Parameters ................................................................................. 6
2.2.2 Set Capture Overlay ...................................................................................................... 7
2.2.3 Set Image Encoding Parameters .................................................................................... 8
2.2.4 Set Construcon Parameters ........................................................................................ 9
2.3 Search Trac Flow Stascs Data .......................................................................................... 9
2.4 Search Picture ........................................................................................................................ 9
Chapter 3 Live View and Local Conguraon ............................................................................ 11
3.1 Live View .............................................................................................................................. 11
3.1.1 Start/Stop Live View .................................................................................................... 11
3.1.2 Select Image Display Mode ......................................................................................... 11
3.1.3 Select Stream Type ...................................................................................................... 11
3.1.4 Capture Picture Manually ........................................................................................... 11
3.1.5 Record Manually ......................................................................................................... 11
3.1.6 Start/Stop Two-Way Audio .......................................................................................... 12
3.1.7 Enable/Disable Audio .................................................................................................. 12
3.1.8 Enable Digital Zoom .................................................................................................... 12
3.1.9 Enable Regional Focus ................................................................................................. 12
Network Trac Camera (for Trac Flow Camera) User Manual
vii
3.1.10 Enable Regional Exposure ......................................................................................... 13
3.1.11 Enable Wiper ............................................................................................................ 13
3.2 Local Conguraon .............................................................................................................. 13
Chapter 4 Record and Capture .................................................................................................. 15
4.1 Set Storage Path ................................................................................................................... 15
4.1.1 Set Storage Card .......................................................................................................... 15
4.1.2 Set FTP ........................................................................................................................ 15
4.1.3 Set Listening Host ........................................................................................................ 16
4.1.4 Set Cloud Storage ........................................................................................................ 17
4.2 Set Quota ............................................................................................................................. 18
4.3 Set Record Schedule ............................................................................................................ 18
Chapter 5 Encoding and Display ................................................................................................ 20
5.1 Set Video Encoding Parameters ........................................................................................... 20
5.2 Set Image Parameters .......................................................................................................... 21
5.3 Set ICR .................................................................................................................................. 23
5.4 Set ROI ................................................................................................................................. 24
5.5 Set OSD ................................................................................................................................ 25
Chapter 6 Network Conguraon ............................................................................................. 27
6.1 Set IP Address ...................................................................................................................... 27
6.2 Connect to ISUP Plaorm .................................................................................................... 28
6.3 Set DDNS .............................................................................................................................. 29
6.4 Set IEEE 802.1X .................................................................................................................... 30
6.5 Set SNMP ............................................................................................................................. 31
6.6 Set Image and Video Library ................................................................................................ 31
6.7 Set Port ................................................................................................................................ 32
Chapter 7 Serial Port Conguraon ........................................................................................... 34
7.1 Set RS-485 ............................................................................................................................ 34
7.2 Set RS-232 ............................................................................................................................ 34
Network Trac Camera (for Trac Flow Camera) User Manual
viii
Chapter 8 Excepon Alarm ....................................................................................................... 36
Chapter 9 Safety Management ................................................................................................. 37
9.1 Manage User ........................................................................................................................ 37
9.2 Enable User Lock .................................................................................................................. 37
9.3 Set HTTPS ............................................................................................................................. 38
9.3.1 Create and Install Self-signed Cercate .................................................................... 38
9.3.2 Install Authorized Cercate ....................................................................................... 38
9.4 Set SSH ................................................................................................................................. 39
Chapter 10 Maintenance .......................................................................................................... 40
10.1 View Device Informaon .................................................................................................... 40
10.2 Log ..................................................................................................................................... 40
10.2.1 Enable System Log Service ........................................................................................ 40
10.2.2 Search Log ................................................................................................................. 40
10.3 Upgrade ............................................................................................................................. 41
10.4 Reboot ............................................................................................................................... 41
10.5 Restore Parameters ............................................................................................................ 41
10.6 Synchronize Time ............................................................................................................... 42
10.7 Set DST ............................................................................................................................... 42
10.8 Debug ................................................................................................................................. 43
10.8.1 Enable Informaon Overlay ...................................................................................... 43
10.8.2 Enable Non-Motor Vehicle Flow Stascs ................................................................ 43
10.8.3 Set Image Format ...................................................................................................... 43
10.9 Export Parameters ............................................................................................................. 44
10.10 Import Conguraon File ................................................................................................. 44
10.11 Export Debug File ............................................................................................................. 45
Appendix A. Communicaon Matrix and Device Command ...................................................... 46
Network Trac Camera (for Trac Flow Camera) User Manual
ix
Chapter 1 Acvaon and Login
1.1 Acvaon
For the rst-me access, you need to acvate the device by seng an admin password. No
operaon is allowed before acvaon. The device supports mulple acvaon methods, such as
acvaon via SADP soware, web browser, and client soware.
Note
Refer to the user manual of client soware for the acvaon via client soware.
1.1.1 Default Informaon
The device default informaon is shown as below.
• Default IP address: 192.168.1.64
• Default user name: admin
1.1.2 Acvate via SADP
SADP is a tool to detect, acvate, and modify the IP address of the device over the LAN.
Before You Start
• Get the SADP soware from the supplied disk or the ocial website ( hp://
www.hikvision.com/ ), and install it according to the prompts.
• The device and the computer that runs the SADP tool should belong to the same network
segment.
The following steps show how to acvate one device and modify its IP address. For batch acvaon
and IP address modicaon, refer to User Manual of SADP for details.
Steps
1. Run the SADP soware and search the online devices.
2. Find and select your device in online device list.
3. Enter a new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
Network Trac Camera (for Trac Flow Camera) User Manual
1
4. Click Acvate to start acvaon.
Figure 1-1 Acvate via SADP
Status of the device becomes Acve aer successful acvaon.
5. Modify IP address of the device.
1) Select the device.
2) Change the device IP address to the same network segment as your computer by either
modifying the IP address manually or checking Enable DHCP.
3) Enter the admin password and click Modify to acvate your IP address modicaon.
1.1.3 Acvate via Web Browser
Use web browser to acvate the device. For the device with the DHCP enabled by default, use
SADP soware or client soware to acvate the device.
Before You Start
Ensure the device and the computer connect to the same LAN.
Steps
1. Change the IP address of your computer to the same network segment as the device.
2. Open the web browser, and enter the default IP address of the device to enter the acvaon
interface.
3. Create and conrm the admin password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
Network Trac Camera (for Trac Flow Camera) User Manual
2
4. Click OK to complete acvaon.
5. Go to the network sengs interface to modify IP address of the device.
1.2 Login
You can log in to the device via web browser for further operaons such as live view and local
conguraon.
Before You Start
Connect the device to the network directly, or via a switch or a router.
Steps
1. Open the web browser, and enter the IP address of the device to enter the login interface.
2. Enter User Name and Password.
3. Click Login.
4. Download and install appropriate plug-in for your web browser. Follow the installaon prompts
to install the plug-in.
5. Reopen the web browser aer the installaon of the plug-in and repeat steps 1 to 3 to login.
6. Oponal: Click Logout on the upper right corner of the interface to log out of the device.
Network Trac Camera (for Trac Flow Camera) User Manual
3
Chapter 2 Capture Conguraon
2.1 Set Data Collecon
You can set the vehicle data collecon and analysis parameters.
Steps
1. Go to Conguraon → Device Conguraon → Applicaon Mode → Trigger Mode .
2. Select Trigger Mode as Data Collecon.
Figure 2-1 Set Data Collecon
3. Select Linked Lane Amount.
4. Select data upload mode.
Upload Real-Time Data
The device will upload the collected data to the server in real me.
Upload Stascs Data
The device will upload the collected data to the server according to the set interval.
5. Select Protocol Type.
Unicoil
Network Trac Camera (for Trac Flow Camera) User Manual
4
One coil for each lane.
Double Coil
Two coils for each lane.
6. Enable POS informaon.
1) Check Enable POS Informaon.
2) Enter X-Coord. and Y-Coord. of the POS informaon overlaid on the live view image.
3) Check the POS informaon to overlay on the live view image.
4) Oponal: Click Quick Clear to refresh the POS informaon on the live view image.
7. Set the lane data collecon parameters.
1) Click the lane No.
2) Check Enable POS of Lane to enable the POS informaon collecon of the lane.
3) Enter Linked Lane No.
4) Select Lane Direcon Type.
5) Oponal: Check lane(s) to copy the parameters of the current lane to other lane(s).
8. Draw lane lines and virtual coil areas.
1) Click Draw Area.
2) Select the lane.
3) Select the default lane lines and right border line, and drag the two end points of the line or
drag the whole line to adjust its posion according to the actual scene.
4) Oponal: Click Draw Lane Line to restore to the default drawing.
5) Click Draw Virtual Coil A to draw the virtual coil areas.
Note
• Click the le buon of the mouse to locate the vertexes of the virtual coil area on the live
view image, and click the right buon of the mouse to nish the drawing.
• It is recommended to draw the virtual coil A at the posion the distance from which to the
image lower edge is the length of two vehicles.
6) Click OK.
Network Trac Camera (for Trac Flow Camera) User Manual
5
Figure 2-2 Draw Lane Lines and Virtual Coil Areas
9. Click Save.
2.2 Set Capture Parameters
2.2.1 Set Supplement Light Parameters
Supplement light can enhance the image stabilizaon and adjust the brightness and color
temperature. You can use supplement light to supplement light at night or when the light is dim.
Steps
Note
Only when the solid light is connected, can the set parameters take eect.
1. Go to Conguraon → Device Conguraon → Capture Parameters → Supplement Light
Parameters .
Figure 2-3 Set Supplement Light Parameters
Network Trac Camera (for Trac Flow Camera) User Manual
6
2. Set Brightness of the solid light.
3. Set the solid light output mode.
-
Check Enable Solid Light by Auto Brightness Detecon when you want the solid light to be
controlled by detecng the surroundings brightness automacally. Set the brightness
threshold. The higher the threshold is, the harder the solid light can be enabled.
-
Check Enable Solid Light by Time when you want the solid light to be enabled during a xed
me period. Set the start me and end me.
Note
Enabling solid light by brightness and me are conicted with each other. You can only enable
one funcon.
4. Oponal: Check other I/O to copy the same parameters.
5. Click Save.
2.2.2 Set Capture Overlay
If you want to overlay informaon on the captured pictures, set capture overlay.
Steps
1. Go to Conguraon → Device Conguraon → Text Overlay → Capture Overlay
Conguraon .
2. Check Text Overlay on Capture.
Figure 2-4 Set Capture Overlay
3. Set the percentage, front size, color, overlay posion, etc.
Percentage
It is the percentage that the overlaid informaon occupies on the picture. For example, if you
set the percentage to 50, the overlaid informaon in a row will occupy up to half of the
image width, and the excess content will be overlaid from a new line.
Overlay Number to Zeroize
Network Trac Camera (for Trac Flow Camera) User Manual
7
When the overlaid number digits are smaller than the xed digits, 0 will be overlaid before
the overlaid number. E.g., the xed digits for lane No. is 2. If the lane No. is 1, 01 will be
overlaid on the picture.
Overlay Plate Close-up
Check it to overlay license plate close-up pictures on the captured pictures.
4. Select the overlay informaon from the list.
Note
The overlay informaon varies with dierent models. The actual device prevails.
5. Set the overlay informaon.
Set Type You can edit the type.
Set Overlay
Informaon
For some informaon type, you can edit the detailed informaon.
Set Overlay Posion If you check it, the current informaon will be displayed from a
new line.
Set Space Number Edit the number of space between the current informaon and the
next one from 0 to 255. 0 means there is no space.
Set Line Break
Characters
Edit the number of characters from 0 to 100 between the current
informaon line and the previous informaon line. 0 means no
line break.
Adjust overlay
sequence
Click
/ to adjust the display sequence of the overlay
informaon.
6. Click Save.
2.2.3 Set Image Encoding Parameters
If the captured pictures are not clear, set the resoluon of the captured pictures and the picture
size.
Steps
1. Go to Conguraon → Device Conguraon → Encoding and Storage → Image Encoding .
Figure 2-5 Set Image Encoding Parameters
2. Select Capture Resoluon.
3. Enter the picture size.
JPEG Picture Size
The size of the captured picture.
Network Trac Camera (for Trac Flow Camera) User Manual
8
4. Click Save.
2.2.4 Set Construcon Parameters
Set construcon parameters according to the actual installaon when applying the video speed
detecon.
Steps
1. Go to Conguraon → Device Conguraon → System → Construcon Parameters .
Figure 2-6 Set Construcon Parameters
2. Set construcon parameters according to the actual scene.
3. Click Save.
2.3 Search Trac Flow Stascs Data
You can search the trac ow stascs data and export the data you need.
Before You Start
Install the storage card, and ensure the storage status is normal.
Steps
1. Click Trac Flow Stascs Data.
2. Set Start Time and End Time.
3. Click Search.
The searched data will be displayed in the list.
4. Oponal: Export the stascs data.
-
Select an item or several items and click Export Selected Data.
-
Click Export All Data to export all the data.
2.4 Search Picture
You can search the captured pictures stored in the storage card and export the pictures you need.
Before You Start
Install the storage card, and ensure the storage status is normal.
Network Trac Camera (for Trac Flow Camera) User Manual
9
Steps
1. Click Picture.
2. Set the search condions such as Lane No., Vehicle Type, etc.
3. Click Search.
The searched pictures informaon will be displayed in the picture list.
Note
You can go to Conguraon → Local Conguraon to get the saving path.
4. Oponal: Click to preview the selected picture.
You can view the captured picture and the related informaon such as the capture me, lane
No., license plate number, etc.
5. Oponal: Check a picture or several pictures and click Export Picture to export it/them to the
saving path you have set.
The downloaded picture(s) will be marked as "Downloaded". You can go to Conguraon →
Local Conguraon to get the saving path of downloaded pictures.
Network Trac Camera (for Trac Flow Camera) User Manual
10
Chapter 3 Live View and Local Conguraon
3.1 Live View
3.1.1 Start/Stop Live View
Click to start live view. Click to stop live view.
3.1.2 Select Image Display Mode
Click to display the image in 4:3/16:9/self-adapve display mode.
3.1.3 Select Stream Type
Click / / to select the stream type. It is recommended to select the main
stream to get the high-quality image when the network condion is good, and select the sub-
stream to get the uent image when the network condion is not good enough. The third stream is
custom.
3.1.4 Capture Picture Manually
You can capture pictures manually on the live view image and save them to the computer.
Steps
1. Click
to start live view.
2. Click to capture a picture.
3. Oponal: Click Conguraon → Local Conguraon to view the saving path of snapshots in live
view.
3.1.5 Record Manually
You can record videos manually on the live view image and save them to the computer.
Steps
1. Click to start live view.
2. Click to start recording.
3. Click to stop recording.
4. Oponal: Click Conguraon → Local Conguraon to view the saving path of record les.
Network Trac Camera (for Trac Flow Camera) User Manual
11
3.1.6 Start/Stop Two-Way Audio
The device supports two-way audio with terminals, such as computers.
Before You Start
The device is equipped with an audio input interface and audio output interface, which support
connecng with the corresponding devices, such as microphones and loudspeakers.
Steps
1. Click to start live view.
2. Click to start two-way audio.
When speaking at the PC end, you can hear the voice at the device end and vice versa.
3. Click to stop two-way audio.
3.1.7 Enable/Disable Audio
Enable the audio if necessary aer connecng an audio input device under the audio & video
stream. Click to enable and adjust it. Click the icon again to disable this funcon.
3.1.8 Enable Digital Zoom
You can enable digital zoom to zoom in a certain part of the live view image.
Steps
1. Click to start live view.
2. Click to enable digital zoom.
3. Place the cursor on the live view image posion which needs to be zoomed in. Drag the mouse
rightwards and downwards to draw an area.
The area will be zoomed in.
4. Click any posion of the image to restore to normal image.
5. Click to disable digital zoom.
3.1.9 Enable Regional Focus
Steps
1. Click .
2. Drag the cursor from the upper le corner to the lower right corner to select the area that
needs to be focused.
Result
The selected area is focused.
Network Trac Camera (for Trac Flow Camera) User Manual
12
3.1.10 Enable Regional Exposure
Enable regional exposure to expose paral area of the live view image.
Steps
1. Click .
2. Drag the cursor downwards and rightwards to select an area in the live view image.
The selected area can be exposed.
3. Click to disable regional exposure.
3.1.11 Enable Wiper
is a reserved funcon.
3.2 Local Conguraon
Go to Conguraon → Local Conguraon to set the live view parameters and change the saving
paths of videos, captured pictures, scene pictures, etc.
Figure 3-1 Local Conguraon
Protocol
Select the network transmission protocol according to the actual needs.
TCP
Ensures complete delivery of streaming data and beer video quality, yet the real-me
transmission will be aected.
Network Trac Camera (for Trac Flow Camera) User Manual
13
UDP
Provides real-me audio and video streams.
Live View Performance
Real Time
The video is real-me, but the video uency may be aected.
Balanced
Balanced mode considers both the real me and uency of the video.
Fluent
When the network condion is good, the video is uent.
Rule Informaon
If you enable the rule informaon, tracking frames will be displayed on the live view interface
when there are vehicles passing.
Feature Informaon
If you enable the feature informaon, informaon of the lane, trac ow, speed, etc. will be
displayed on the live view interface.
Record File Size
Select the packed size of the manually recorded video les. Aer the selecon, the max. record
le size is the value you selected.
Save record les to
Set the saving path for the manually recorded video les.
Save snapshots in live view to
Set the saving path of the manually captured pictures in live view mode.
Save downloaded pictures to
Set the saving path for the downloaded pictures.
Save scene picture to
Set the saving path of the captured pictures on Trac Flow Stascs Data interface.
Note
The parameters vary with dierent models. The actual device prevails.
Network Trac Camera (for Trac Flow Camera) User Manual
14
Chapter 4 Record and Capture
4.1 Set Storage Path
4.1.1 Set Storage Card
If you want to store the les to the storage card, make sure you insert and format the storage card
in advance.
Before You Start
Insert the storage card to the device.
Steps
1. Go to Conguraon → Device Conguraon → Encoding and Storage → Storage
Management .
Figure 4-1 Set Storage Card
2. Format the storage card in two ways.
-
Check the storage card, and click Format to format it manually.
Note
For the newly installed storage card, you need to format it manually before using it normally.
-
If you want to format the storage card automacally when the card is abnormal, check
Format Backup Storage Automacally.
3. Oponal: If the device has been connected to the plaorm, and you want to upload the storage
card informaon automacally, check Upload Backup Storage Informaon Automacally.
4. Click Save.
4.1.2 Set FTP
Set FTP parameters if you want to upload the captured pictures to the FTP server.
Before You Start
Set the FTP server, and ensure the device can communicate normally with the server.
Steps
1. Go to Conguraon → Device Conguraon → Encoding and Storage → FTP .
Network Trac Camera (for Trac Flow Camera) User Manual
15
Figure 4-2 Set FTP
2. Enable the FTP server.
3. Oponal: Check Upload Addional Informaon, and then the related informaon can be
aached when uploading.
4. Set FTP parameters.
1) Enter Server Address and Port.
2) Enter User Name and Password, and conrm the password.
3) Select Directory Structure.
Note
If mulple directories are needed, you can customize the directory name.
5. Oponal: Check Not Upload Plate Close-up if the license plate close-up pictures are not needed
to upload.
6. Oponal: Click FTP Test to test the server connecon.
7. Set the name rule and separator according to the actual needs.
8. Oponal: Edit OSD informaon which can be uploaded to the FTP server with the pictures to
make it convenient to view and disnguish the data.
9. Click Save.
4.1.3 Set Listening Host
The listening host can be used to receive the uploaded informaon and pictures of the device
arming alarm.
Before You Start
The listening service has been enabled for the listening host, and the network communicaon with
the device is normal.
Steps
1. Go to Conguraon → Device Conguraon → System → Network Interface Parameters .
Network Trac Camera (for Trac Flow Camera) User Manual
16
Figure 4-3 Set Listening Host
2. Set ANPR IP Address/Domain and ANPR Port if you need to upload the alarm informaon.
3. Set Listening Host IP Address/Domain and Listening Host Port, and check Enable Picture
Uploading Listening if you need to upload pictures.
Note
ANPR and listening conict with each other. When you enable listening host, pictures will be
uploaded via listening host in priority. When you disable listening and have set ANPR IP address
and port, pictures will be uploaded via ANPR protocol.
4. Click Save.
4.1.4 Set Cloud Storage
Cloud storage is a kind of network storage. It can be used as the extended storage to save the
captured pictures.
Before You Start
Arrange the cloud storage server.
Steps
1. Go to Conguraon → Device Conguraon → Encoding and Storage → Cloud Storage .
Figure 4-4 Set Cloud Storage
2. Check Enable.
3. Select Version.
4. Set the server parameters.
1) Enter Server IP Address and Port No.
Network Trac Camera (for Trac Flow Camera) User Manual
17
2) If you select V2.0, enter accessKey and secretKey of the resource pool.
Note
If you select V1.0, enter User Name and Password.
3) Enter the ID according to the storage area No. of the server.
5. Click Save.
4.2 Set Quota
Set the video and picture rao in the storage.
Before You Start
Install the storage card.
Steps
1. Go to Conguraon → Device Conguraon → Encoding and Storage → Storage
Management .
2. Set Picture Quota and Record Quota according to the actual needs.
Note
The percentage sum of the picture and record quota rao should be 100%.
3. Click Save.
What to do next
Format the storage card aer the sengs.
4.3 Set Record Schedule
Set record schedule to record video automacally during congured me periods.
Before You Start
Install the storage card, and the video quota rao is not 0.
Steps
1. Go to Conguraon → Device Conguraon → Encoding and Storage → Record Schedule .
Network Trac Camera (for Trac Flow Camera) User Manual
18
Figure 4-5 Set Record Schedule
2. Oponal: Check Enable Overwrien Recording.
When the storage is full, the earliest videos will be overwrien.
3. Check Enable Record Schedule.
4. Click Edit to edit the record schedule.
1) Select Customize.
2) Set the start me and end me.
3) Oponal: Select the other days and click Copy to copy the sengs to other days.
4) Click OK.
5. Click Save.
Network Trac Camera (for Trac Flow Camera) User Manual
19
Chapter 5 Encoding and Display
5.1 Set Video Encoding Parameters
Set video encoding parameters to adjust the live view and recording eect.
• When the network signal is good and the speed is fast, you can set high resoluon and bitrate to
raise the image quality.
• When the network signal is bad and the speed is slow, you can set low resoluon, bitrate, and
frame rate to guarantee the image uency.
• When the network signal is bad, but the resoluon should be guaranteed, you can set low
bitrate and frame rate to guarantee the image uency.
• Main stream stands for the best stream performance the device supports. It usually oers the
best resoluon and frame rate the device can do. But high resoluon and frame rate usually
means larger storage space and higher bandwidth requirements in transmission. Sub-stream
usually oers comparavely low resoluon opons, which consumes less bandwidth and storage
space. Third stream is oered for customized usage.
Steps
1. Go to Conguraon → Device Conguraon → Encoding and Storage → Video Encoding .
2. Set the parameters for dierent streams.
Stream Type
Video stream and video & audio stream are selectable.
Bitrate
Select relavely large bitrate if you need good image quality and eect, but more storage
spaces will be consumed. Select relavely small bitrate if storage requirement is in priority.
Frame Rate
It is to describe the frequency at which the video stream is updated and it is measured by
frames per second (fps). A higher frame rate is advantageous when there is movement in the
video stream, as it maintains image quality throughout.
Resoluon
The higher the resoluon is, the clearer the image will be. Meanwhile, the network
bandwidth requirement is higher.
SVC
Scalable Video Coding (SVC) is an extension of the H.264/AVC and H.265 standard. Enable the
funcon and the device will automacally extract frames from the original video when the
network bandwidth is insucient.
Bitrate Type
Select the bitrate type to constant or variable.
Network Trac Camera (for Trac Flow Camera) User Manual
20
Image Quality
When bitrate type is variable, 6 levels of image quality are selectable. The higher the image
quality is, the higher requirements of the network bandwidth.
Prole
When you select H.264 or H.265 as video encoding, you can set the prole. Selectable
proles vary according to device models.
I Frame Interval
It refers to the number of frames between two key frames. The larger the I frame interval is,
the smaller the stream uctuaon will be, but the image quality is not that good.
Video Encoding
The device supports mulple video encoding types, such as H.264, H.265, and MJPEG.
Supported encoding types for dierent stream types may dier. H.265 is a new encoding
technology. Compared with H.264, it reduces the transmission bitrate under the same
resoluon, frame rate, and image quality.
3. Click Save.
5.2 Set Image Parameters
You can adjust the image parameters to get clear image.
Steps
Note
The supported parameters may vary with dierent models. The actual device prevails.
1. Go to Conguraon → Device Conguraon → Image Parameters → General Parameters /
Conguraon → Device Conguraon → Image Parameters → Video .
Figure 5-1 Set General Parameters
Network Trac Camera (for Trac Flow Camera) User Manual
21
Figure 5-2 Set Video Image Parameters
2. Adjust the parameters.
Saturaon
It refers to the colorfulness of the image color.
Sharpness
It refers to the edge contrast of the image.
White Balance
It is the white rendion funcon of the device used to adjust the color temperature
according to the environment.
WDR Mode
Wide Dynamic Range (WDR) can be used when there is a high contrast of the bright area and
the dark area of the scene.
Select WDR Switch Mode and set corresponding parameters according to your needs.
Enable
Set WDR Level. The higher the level is, the higher the WDR strength is.
Enable by Time
Enable WDR according to the me.
Enable by Brightness
Set Brightness Threshold. When the brightness reaches the threshold, WDR will be
enabled.
Lens Type
In Manual mode, you need to adjust the lens manually.
Brightness Enhancement at Night
The scene brightness will be enhanced at night automacally.
Enable Defog
Enable defog to get a clear image in foggy days.
Enable Gamma Correcon
Network Trac Camera (for Trac Flow Camera) User Manual
22
The higher the gamma correcon value is, the stronger the correcon strength is.
Brightness
It refers to the max. brightness of the image.
Contrast
It refers to the contrast of the image. Set it to adjust the levels and permeability of the
image.
Shuer
If the shuer speed is quick, the details of the moving objects can be displayed beer. If the
shuer speed is slow, the outline of the moving objects will be fuzzy and trailing will appear.
Gain
It refers to the upper limit value of liming image signal amplicaon. It is recommended to
set a high gain if the illuminaon is not enough, and set a low gain if the illuminaon is
enough.
3D Noise Reducon Mode
Digital Noise Reducon (DNR) reduces the noise in the video stream.
In Normal Mode, the higher the Noise Reducon Level is, the stronger the noise will be
reduced. But if it is too high, the image may become fuzzy.
In Expert Mode, set Space Domain Intensity and Time Domain Intensity. If the space
domain intensity is too high, the outline of the image may become fuzzy and the details may
lose. If the me domain intensity is too high, trailing may appear.
2D DNR
The higher the 2D DNR Level is, the stronger the noise will be reduced. But if it is too high,
the image may become fuzzy.
Enable Slow Shuer
You can enable slow shuer to increase the exposure me and raise the photosensivity.
Then the image brightness can be raised in low illuminaon condions.
Video Standard
Select the video standard according to the actual power supply frequency.
5.3 Set ICR
ICR adopts mechanical IR lter to lter IR in the day to guarantee the image eect, and to remove
the IR lter at night to guarantee full-spectrum rays can get through the device.
Steps
1. Go to Conguraon → Device Conguraon → Image Parameters → ICR .
2. Select ICR Mode.
Auto-Switch Switches to ICR mode automacally at night or in dark light condions.
Network Trac Camera (for Trac Flow Camera) User Manual
23
Manual Switch Select Day/Night Mode to switch to the day or night manually.
Scheduled Mode Set day/night mode, start me, and end me to switch to ICR mode only
during the set me period.
No Switch Disable the ICR mode.
3. Click Save.
5.4 Set ROI
ROI (Region of Interest) encoding helps to assign more encoding resources to the region of
interest, thus to increase the quality of the ROI whereas the background informaon is less
focused.
Before You Start
Please check the video encoding type. ROI is supported when the video encoding type is H.264 or
H.265.
Steps
1. Go to Conguraon → Device Conguraon → Encoding and Storage → ROI .
Figure 5-3 Set ROI
2. Select Stream Type.
3. Set ROI region.
1) Check Enable.
2) Select Area No.
3) Click Draw Area.
4) Drag the mouse on the live view image to draw a xed area.
Network Trac Camera (for Trac Flow Camera) User Manual
24
5) Select the xed area that needs to be adjusted and drag the mouse to adjust its posion.
6) Click Stop Drawing.
4. Select Area No. and ROI Level and enter Area Name.
Note
The higher the ROI level is, the clearer the image of the detected area is.
5. Click Save.
6. Oponal: Select other area codes and repeat the steps above if you need to draw mulple xed
areas.
5.5 Set OSD
You can customize OSD informaon on the live view.
Steps
1. Go to Conguraon → Device Conguraon → Text Overlay → OSD Sengs .
Figure 5-4 Set OSD
2. Set the display mode, size, color, etc.
Note
The supported funcons vary with dierent models. The actual device prevails.
3. Set the display content.
1) Check Display Name and enter the name.
2) Check Display Date, and set the me and date format.
3) Check Display Week or Millisecond according to your needs.
Network Trac Camera (for Trac Flow Camera) User Manual
25
4. Oponal: Check the display item(s) and enter informaon in the text eld(s).
5. Drag the red frames on the live view image to adjust the OSD posions.
6. Click Save.
Result
The set OSD will be displayed in live view image and recorded videos.
Network Trac Camera (for Trac Flow Camera) User Manual
26
Chapter 6 Network Conguraon
6.1 Set IP Address
IP address must be properly congured before you operate the device over network. IPv4 and IPv6
are both supported. Both versions can be congured simultaneously without conicng to each
other.
Go to Conguraon → Device Conguraon → System → Network Interface Parameters .
Figure 6-1 Set IP Address
NIC Type
Select a NIC (Network Interface Card) type according to your network condion.
IPv4
Two IPv4 modes are available.
DHCP
The device automacally gets the IPv4 parameters from the network if you check DHCP. The
device IP address is changed aer enabling the funcon. You can use SADP to get the device IP
address.
Note
The network that the device is connected to should support DHCP (Dynamic Host
Conguraon Protocol).
Manual
Network Trac Camera (for Trac Flow Camera) User Manual
27
You can set the device IPv4 parameters manually. Enter IPv4 Address, IPv4 Subnet Mask, and
IPv4 Default Gateway.
IPv6
Three IPv6 modes are available.
Route Adversement
The IPv6 address is generated by combining the route adversement and the device Mac
address.
Note
Route adversement mode requires the support from the router that the device is connected
to.
DHCP
The IPv6 address is assigned by the server, router, or gateway.
Manual
Enter IPv6 Address, IPv6 Subnet Mask, and IPv6 Default Gateway. Consult the network
administrator for required informaon.
MTU
It stands for maximum transmission unit. It is the size of the largest protocol data unit that can
be communicated in a single network layer transacon.
The valid value range of MTU is 1280 to 1500.
Mulcast
Mulcast is group communicaon where data transmission is addressed to a group of
desnaon devices simultaneously. Aer seng the IP address of the mulcast host, you can
send the source data eciently to mulple receivers.
DNS
It stands for domain name server. It is required if you need to visit the device with domain
name. And it is also required for some applicaons (e.g., sending email). Set Preferred DNS
Server properly if needed.
6.2 Connect to ISUP Plaorm
ISUP (EHome) is a plaorm access protocol. The device can be remotely accessed via this plaorm.
Before You Start
• Create the device ID on ISUP plaorm.
• Ensure the device can communicate with the plaorm normally.
Steps
1. Go to Conguraon → Device Conguraon → System → ISUP Protocol .
Network Trac Camera (for Trac Flow Camera) User Manual
28
Figure 6-2 Connect to ISUP Plaorm
2. Check Enable.
3. Select Protocol Version.
4. Enter Plaorm IP Address, Plaorm Port, and Camera No.
Note
The camera No. should be the same with the added one on the ISUP plaorm.
5. Oponal: Enter Encrypon Key if you select v5.0.
6. Click Save.
7. Oponal: View Registraon Status.
Note
When the registraon status shows online, you can add or manage the device via the plaorm
soware. Refer to its corresponding manual for details.
6.3 Set DDNS
You can use the Dynamic DNS (DDNS) for network access. The dynamic IP address of the device can
be mapped to a domain name resoluon server to realize the network access via domain name.
Before You Start
• Register the domain name on the DDNS server.
• Set the LAN IP address, subnet mask, gateway, and DNS server parameters. Refer to "Set IP
Address" for details.
• Complete port mapping. The default port is 80, 8000, and 554.
Steps
1. Go to Conguraon → Device Conguraon → System → DDNS .
Network Trac Camera (for Trac Flow Camera) User Manual
29
Figure 6-3 Set DDNS
2. Check Enable DDNS.
3. Enter the server address and other informaon.
4. Click Save.
5. Access the device.
By Browsers Enter the domain name in the browser address bar to access the
device.
By Client Soware Add domain name to the client soware. Refer to the client soware
manual for specic adding methods.
6.4 Set IEEE 802.1X
IEEE 802.1X is a port-based network access control. It enhances the security level of the LAN/
WLAN. When devices connect to the network with IEEE 802.1X standard, the authencaon is
needed.
Steps
1. Go to Conguraon → Device Conguraon → System → 802.1X .
Figure 6-4 Set IEEE 802.1X
2. Check Enable EEE 802.1X.
3. Select Protocol Type and EAPOL Version.
Protocol Type
Network Trac Camera (for Trac Flow Camera) User Manual
30
If you use EAP-MD5, the authencaon server must be congured. Register a user name and
password for 802.1X in the server in advance. Enter the user name and password for
authencaon.
EAPOL Version
The EAPOL version must be idencal with that of the router or the switch.
4. Enter User Name and Password registered in the server.
5. Conrm the password.
6. Click Save.
6.5 Set SNMP
You can set the SNMP network management protocol to get the alarm event and excepon
messages in network transmission.
Before You Start
Download the SNMP soware and manage to receive the device informaon via SNMP port.
Steps
1. Go to Conguraon → Device Conguraon → System → SNMP .
2. Check Enable SNMPv1, Enable SNMP v2c or Enable SNMPv3.
Note
• The SNMP version you select should be the same as that of the SNMP soware.
• Use dierent versions according to the security levels required. SNMP v1 is not secure and
SNMP v2 requires password for access. SNMP v3 provides encrypon and if you use the third
version, HTTPS protocol must be enabled.
3. Set the SNMP parameters.
4. Click Save.
6.6 Set Image and Video Library
Set the interacon parameters of the device consistent with those of the image and video library
plaorm via the image and video library (1400) protocol, and register the device on the plaorm.
When the device generates alarm signals, the alarm informaon will be sent to the plaorm.
Steps
Note
The funcon varies with dierent models. The actual device prevails.
1. Go to Conguraon → Device Conguraon → System → Image and Video Library .
2. Check Enable.
3. Set the parameters such as the device ID, user name, password, etc.
Network Trac Camera (for Trac Flow Camera) User Manual
31
Note
The parameters should be consistent with those on the image and video library plaorm.
4. Set other parameters.
Heartbeat Cycle
The connecon me between the device and the image and video library plaorm.
Max. Times of Heartbeat Timeout
The max. mes of heartbeat meout when the device connects to the image and video
library plaorm.
5. View Registraon Status.
6. Set Camera ID of the channel.
7. Click Save.
6.7 Set Port
The device port can be modied when the device cannot access the network due to port conicts.
Go to Conguraon → Device Conguraon → System → Port for port sengs.
Figure 6-5 Set Port
HTTP Port
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.168.1.64:81 in the browser for login.
RTSP Port
It refers to the port of real-me streaming protocol.
SDK Port
It refers to the port through which the client adds the device.
SADP Port
It refers to the port through which the SADP soware searches the device.
Network Trac Camera (for Trac Flow Camera) User Manual
32
Note
• Aer eding the port, access to the device via new port.
• Reboot the device to take the new sengs into eect.
• The supported ports vary with dierent models. The actual device prevails.
Network Trac Camera (for Trac Flow Camera) User Manual
33
Chapter 7 Serial Port Conguraon
7.1 Set RS-485
Set RS-485 parameters if the device needs to be connected to other peripheral devices controlled
by RS-485 serial port.
Before You Start
The corresponding device has been connected via the RS-485 serial port.
Steps
1. Go to Conguraon → Device Conguraon → System → Serial Port Parameters .
Figure 7-1 Set RS-485
2. Set Baud Rate, Data Bit, Stop Bit, etc.
Note
The parameters should be same with those of the connected device.
3. Click Save.
7.2 Set RS-232
Set RS-232 parameters if you need to debug the device via RS-232 serial port.
Before You Start
The debugging device has been connected via the RS-232 serial port.
Steps
1. Go to Conguraon → Device Conguraon → System → Serial Port Parameters .
2. Click Advanced Sengs.
Figure 7-2 Set RS-232
Network Trac Camera (for Trac Flow Camera) User Manual
34
3. Set Baud Rate, Data Bit, Stop Bit, etc.
Note
The parameters should be same with those of the connected device.
4. Select Working Mode.
Console
Select it when you need to debug the device via RS-232 serial port.
Transparent Channel
Select it, and the network command can be transmied to RS-232 control command via the
RS-232 serial port.
Narrow Band Transmission
Reserved.
5. Click Save.
Network Trac Camera (for Trac Flow Camera) User Manual
35
Chapter 8 Excepon Alarm
Set excepon alarm when the network is disconnected, the IP address is conicted, etc.
Steps
Note
The supported excepon types vary with dierent models. The actual device prevails.
1. Go to Conguraon → Device Conguraon → Events → Excepon Event .
2. Select the excepon type(s) and the linkage method.
3. Click Save.
Network Trac Camera (for Trac Flow Camera) User Manual
36
Chapter 9 Safety Management
9.1 Manage User
The administrator can add, modify, or delete other accounts, and grant dierent permissions to
dierent user levels.
Steps
1. Go to Conguraon → Device Conguraon → User Management .
2. Add a user.
1) Click Add.
2) Enter User Name and select Level.
3) Enter Admin Password, Password, and conrm the password.
Cauon
To increase security of using the device on the network, please change the password of your
account regularly. Changing the password every 3 months is recommended. If the device is
used in high-risk environment, it is recommended that the password should be changed
every month or week.
4) Assign remote permission to users based on needs.
User
Users can be assigned permission of viewing live video and changing their own passwords,
but no permission for other operaons.
Operator
Operators can be assigned all permission except for operaons on the administrator and
creang accounts.
5) Click OK.
Note
The administrator can add up to 31 user accounts.
3. You can do the following operaons.
-
Select a user and click Modify to change the password and permission.
-
Select a user and click Delete to delete the user.
9.2 Enable User Lock
To raise the data security, you are recommended to lock the current IP address.
Steps
1. Go to Conguraon → Device Conguraon → System → Service .
2. Check Enable User Lock.
Network Trac Camera (for Trac Flow Camera) User Manual
37
3. Click Save.
Result
When the mes you entered incorrect passwords have reached the limit, the current IP address
will be locked automacally.
9.3 Set HTTPS
9.3.1 Create and Install Self-signed Cercate
HTTPS is a network protocol that enables encrypted transmission and identy authencaon,
which improves the security of remote access.
Steps
1. Go to Conguraon → Device Conguraon → System → HTTPS .
2. Select Create Self-Signed Cercate.
3. Click Create.
4. Follow the prompt to enter Country/Region, IP Address, Valid Date (Day), and other
parameters.
5. Click OK.
Result
The device will install the self-signed cercate by default.
9.3.2 Install Authorized Cercate
If the demand for external access security is high, you can create and install authorized cercate
via HTTPS protocol to ensure the data transmission security.
Steps
1. Go to Conguraon → Device Conguraon → System → HTTPS .
2. Select Create the cercate request rst and connue the installaon.
3. Click Create.
4. Follow the prompt to enter Country/Region, IP Address, and other parameters.
5. Click Download to download the cercate request and submit it to the trusted authority for
signature.
6. Import cercate to the device.
-
Select Signed cercate is available. Start the installaon directly. Click Browse and Install
to import the cercate to the device.
-
Select Create the cercate request rst and connue the installaon. Click Browse and
Install to import the cercate to the device.
7. Click Save.
Network Trac Camera (for Trac Flow Camera) User Manual
38
9.4 Set SSH
To raise network security, disable SSH service. The conguraon is only used to debug the device
for the professionals.
Steps
1. Go to Conguraon → Device Conguraon → System → Service .
2. Uncheck Enable SSH Service.
3. Click Save.
Network Trac Camera (for Trac Flow Camera) User Manual
39
Chapter 10 Maintenance
10.1 View Device Informaon
Basic Informaon and Algorithms Library Version
Go to Conguraon → Device Conguraon → System → Device Informaon to view the basic
informaon and algorithms library version of the device.
You can edit Device Name and Device No. The device No. is used to control the device. It is
recommended to reserve the default value.
Device Status
Go to Conguraon → Device Status to view the device status.
10.2 Log
10.2.1 Enable System Log Service
The security audit logs refer to the security operaon logs. You can search and analyze the security
log les of the device so as to nd out the illegal intrusion and troubleshoot the security events.
Security audit logs can be saved on device internal storage. The log will be saved every half hour
aer device boong. Due to limited storage space, you are recommended to save the logs on a log
server.
Steps
1. Go to Conguraon → Device Conguraon → System → Service .
2. Check Enable Syslog Service.
3. Enter IP Address and Port of the log server.
4. Click Save.
Result
The device will upload the security audit logs to the log server regularly.
10.2.2 Search Log
Log helps to locate and troubleshoot problems.
Steps
1. Click Log.
2. Set search condions.
3. Click Search.
Network Trac Camera (for Trac Flow Camera) User Manual
40
The matched log les will be displayed on the log list.
4. Oponal: Click Save Log to save the log les to your computer.
10.3 Upgrade
Upgrade the system when you need to update the device version.
Before You Start
Prepare the upgrade le.
Steps
1. Go to Conguraon → Device Conguraon → System Maintenance → Upgrade .
2. Click Browse to select the upgrade le.
3. Click Upgrade.
4. Click OK in the popup window.
Note
The upgrade process will take 1 to 10 minutes. Do not cut o the power supply.
Result
The device will reboot automacally aer upgrade.
10.4 Reboot
When the device needs to be rebooted, reboot it via the soware instead of cung o the power
directly.
Steps
1. Go to Conguraon → Device Conguraon → System Maintenance → Reboot .
2. Click Reboot.
3. Click OK to reboot the device.
10.5 Restore Parameters
When the device is abnormal caused by the incorrect set parameters, you can restore the
parameters.
Steps
1. Go to Conguraon → Device Conguraon → System Maintenance → Default .
2. Select the restoraon mode.
-
Click Restore to restore the parameters except the IP parameters and user parameters to the
default sengs.
-
Click Restore Factory Sengs to restore all the parameters to the factory sengs.
Network Trac Camera (for Trac Flow Camera) User Manual
41
3. Click OK.
10.6 Synchronize Time
Synchronize the device me when it is inconsistent with the actual me.
Steps
1. Go to Conguraon → Device Conguraon → System → Time Sengs .
2. Select Time Zone.
3. Select Time Sync. Mode.
NTP Time Sync.
Select it to synchronize the device me with that of the NTP server. Set Server Address, NTP
Port, and Interval. Click NTP Test to test if the connecon between the device and the server
is normal.
Manual Time Sync.
Select it to synchronize the device me with that of the computer. Set me manually, or
check Sync. with computer me.
SDK
If the remote host has been set for the device, select it to synchronize me via the remote
host.
ONVIF
Select it to synchronize me via the third-party device.
No
Select it to disable me synchronizaon.
All
Select it, and you can select any mode above.
Note
The me synchronizaon modes vary with dierent models. The actual device prevails.
4. Click Save.
10.7 Set DST
If the region where the device is located adopts Daylight Saving Time (DST), you can set this
funcon.
Steps
1. Go to Conguraon → Device Conguraon → System → DST .
2. Check Enable DST.
3. Set Start Time, End Time, and DST Bias.
Network Trac Camera (for Trac Flow Camera) User Manual
42
4. Click Save.
10.8 Debug
Note
The debug conguraons below are only provided to debug the device by the professionals.
10.8.1 Enable Informaon Overlay
You can overlay the algorithm POS informaon and posioning frames on the captured pictures or
playback images.
Steps
1. Go to Conguraon → Device Conguraon → Advanced Sengs → System Service .
2. Check the debug informaon according to your needs.
Enable Algorithm POS Informaon Debug
The algorithm POS informaon will be overlaid on the playback image when you play back
the video with the dedicated tool.
Enable Posioning Frame Debug
The posioning frames of vehicle bodies and license plates will be overlaid on the captured
pictures.
3. Click Save.
10.8.2 Enable Non-Motor Vehicle Flow Stascs
If you want to count the trac ow of the non-motor vehicles, you can enable non-motor vehicle
ow stascs.
Steps
1. Go to Conguraon → Device Conguraon → Advanced Sengs → Vehicle Capture and
Recognion Service .
2. Check Enable Non-Motor Vehicle Flow Stascs.
3. Click Save.
10.8.3 Set Image Format
You can enable smartJPEG which can save the storage space without inuencing the resoluon.
Steps
1. Go to Conguraon → Device Conguraon → Advanced Sengs → Image Service .
2. Check smartJPEG.
Network Trac Camera (for Trac Flow Camera) User Manual
43
3. Click Save.
10.9 Export Parameters
You can export the parameters of one device, and import them to another device to set the two
devices with the same parameters.
Steps
1. Go to Conguraon → Device Conguraon → System Maintenance → Export Parameters .
2. Click Export Parameters.
3. Set a password, and click OK.
Note
The password is used for imporng the conguraon le of the current device to other devices.
4. Select the saving path, and enter the le name.
5. Click Save.
10.10 Import Conguraon File
Import the conguraon le of another device to the current device to set the same parameters.
Before You Start
Save the conguraon le to the computer.
Steps
Cauon
Imporng conguraon le is only available to the devices of the same model and same version.
1. Go to Conguraon → Device Conguraon → System Maintenance → Import Cong. File .
2. Select Imporng Method.
Note
If you select Import Part, check the parameters to be imported.
3. Click Browse to select the conguraon le.
4. Enter the password which is set when the conguraon le is exported, and click OK.
5. Click Import.
6. Click OK on the popup window..
Result
The parameters will be imported, and the device will reboot.
Network Trac Camera (for Trac Flow Camera) User Manual
44
10.11 Export Debug File
The technicians can export the debug le to troubleshoot and maintain the device.
Steps
1. Go to Conguraon → Device Conguraon → System Maintenance → Export Debug File .
2. Click Export Debug.
3. Select the saving path, and enter the le name.
4. Click Save.
Network Trac Camera (for Trac Flow Camera) User Manual
45
Appendix A. Communicaon Matrix and Device
Command
Scan the QR code below to get the communicaon matrix of the device.
Scan the QR code below to get the device command.
Network Trac Camera (for Trac Flow Camera) User Manual
46
UD23096B
