Warning: Keep ventilation openings in the appliance enclosure or in the built-in structure,
clear of obstruction.
Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliance inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
This appliance is not intended for use by persons(including children)with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by
a person responsible for their safety.
If the supply cord is damaged, it must replaced by a special cord or assembly available
from the manufacturer or its service agent.
Children should be supervised to ensure that they do not play with the appliance.
This product is not suitable for disabled children to use, except under the
guidance help and instructions.
Children should be take care, make sure leave the product away.
FLS-80U-BLACK
Product Information
·Voltage: 110V
·Rated current: 0.92A
·Defrosting: Manual Defrosting
·Frequency: 60Hz
1
6
Please read the following instruction carefully before using your freezer.
- Do not put hot food inside the freezer.
- Wrap all food items with a plastic protection film to avoid dehydration and lose
food flavor.
- If you do not use the freezer for a long period of time, disconnect power, clean
the inside parts, put the freezer in a dry area and leave the door slightly open.
. GENERAL
It is extensively used in places such as hotels, offices, houses and student dormitories.
It is mostly suitable for freezing and conserving foods such as meat etc. it enjoys the
advantage of small size. Light weight, high efficiency and low energy consumption.
USER MANUAL
UPRIGHT FREEZER
freezer, it is not unusual.
You may just wipe it up yourself.
1
2
3
4
5
6
2
5
1. Adjustable Feet
2. Case
3. Evaporator
4. Thermostat Knob
5. Door seal gasket
6. Door
. UNPACKING.REPACKING AND MOVING
1. Unpacking
Just cut off the packing band, then pull the carton up.
2. Repacking
Please remember to put the original foamed pads in place.
3. Moving
Be sure freezer stays in upright position during moving it.
Do not tilt it for more than 45o from upright. Never upset it.
Do not apply force on any external part such as pipe, door and its handle for moving,
freezer must be well packed and secured in long distance transportation to avoid
damage from impacting and or great rocking.
INSTALLATION
The freezer should be placed on a flat and solid-top surface. It should be kept away
from sunlight, heat source, humid or mess place. The freezer should be kept away
from the wall for a proper space for good air circulation. When the freezer is placed
in a cupboard, the rear of the cupboard must be removed out for good circulation.
. OPERATION
1. Before the freezer is plugged in, check the following:
- There must not be any damage on all electrical wire.
- Earthing screw must be well fixed.
- Wall outlet must be properly earthed.
Be sure that everything is in normal condition and the freezer can be plugged in.
2. When operating for the first time
When operating is in normal condition and the freezer without any load until it auto
The appliance must be positioned so that the plug is accessible.
VIII. SPECIFICAIONS
1. Refrigerant: R600a/3
8g
2. Input power: 160W
3. Rated voltage: 110-120V
4. Rated frequency: 60HZ
5. Capacity: 80L
6. Net weight: 20kg
Note: Specifications subject to change without notice.
IX. SERVICE
If the freezer is not functioning properly, chek that:
1. When the freezer dose not operate:
- the power plug is firmly in the wall outlet
- the mains power switch is off
- the fuse is not burned out
2. When the freezer does not cool enough:
- the thermostat is at the correct setting, there are too frequent and too long door
openings.
3. When the foods are not frozen:
- the thermostat is at the correct setting
4. When the freezer operates too noisily:
- the freezer is not touching furniture that can transmit or amplify a noise or a
vibration
- the freezer is not properly leveled
- the containers or solid packages stored inside are not touching each other.
- the mains supply is stable.
If your freezer is still not functioning properly after making the above checks, please
contact the sale dealer immediately.
Note: During the period of high humidity, moisture may form on the outside of the
1
2
3
OFF
3
4
stops at the desired temperature, usually it takes 2 or 3 hours. Then set the thermostat
to the required setting and place foods in.
3.Temperature control
Freezer's temperature can be adjusted by turning the knob of the thermostat. The
closer to “3” position the knob is set, the lower the temperature becomes. A medium
setting is the most suitable for general operation. The position “3” is cooler than the
position “1”. Freezer's temperature will vary depending on the quantity of foods
stored and frequency of the door opening. In order to maintain good cooling
efficiency and save energy, we recommend you not to store too much foods and not
to open the door too frequently.
CAUTION: When the thermostat has been turned clockwise to “3” position, do not
attempt to turn it more over. Otherwise it will be damaged.
V. DEFROSTING
For the most efficient operation and minimum energy consumption, defrost the
freezer when the frost on the evaporator is excessive 3 to 4 mm thick. To start
defrosting, turn the temperature control to “OFF”, u nplug the freezer, remove the
food and drawers. After the frost or ice has melted, discard the melted water and dry
up the interior of freezer. Then the freezer can be restarted by a turning its thermostat
to the desired setting.
CAUTION: Never use any sharp of metallic instruments (e.g. knives) to remove
frost/ice from the evaporator as this will damage the evaporator. A punctured
evaporator will cause serious problems.
VI. CLEANING AND MAINTENANCE
1. To clean the freezer, disconnect power supply and remove foods, drawers etc.Use
a solution mixed with 2 spoons of baking soda per litre of warm water to clean
the interior. Then wipe it clean with fresh water.
Never use acids, chemical thinner, gasoline, benzene or the like for cleaning
any part of the freezer.
Never use oiling water and venzene to clean plastic parts because they may
deform or damage the plastic parts.
2. Too much foods or a too large container in the freezer will affect cold air
circulation, so some free space must be left. It is recommended that about 70%
storage volume is loaded.
Do not store volatile and or explosive materials such as ethers, gasoline, liquefied
petroleum gas, adhesives etc. in the freezer. Otherwise there will be a danger of
explosion caused by electric sparks.
VII. SAFETY INSTRUCTIONS
Before plugging your freezer in check that the electric supply in your house must
comply with the rating (voltage, frequency) of the freezer, the rating plate is usually
on the back of the freezer. The freezer should always be plugged in its o wn individual
electrical outlet to prevent overload, which could cause a possible fire hazard from
overheating wires. Do not splash water on the freezer as this will cause electrical
leakage or failure. If the power cord becomes damaged, ask on electrician to replace it
immediately. The freezer must be properly earthed.
Our corporation is not responsible for any accident caused by improper earthing or
improper operaton.
Any repairs and work on the appliance should only be carried out by the customer
service department, as unauthorized work could prove highly dangerous for the user.
Do not store explosives or sprays using combustible propellants such as butane,
propane, pentane etc. in the appliance. Electrical components might cause leaking
gas to ignite. You may identify such sprays by the printed contents or a lame symbol.
Do not allow naked flames or ignition sources to enter the appliance.
Do not use steam cleaners for defrosting and cleaning.
Do not use mechanical devices or the other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliance inside the food storage compartments of appliance,
unless they are of type recommended by the manufacturer.
If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
