MOT TOOL BOARD WITH TOOLS
MODEL NO: MOTBKIT.V1, MOTB.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. INTRODUCTION
9 Shadow board for MOT approved and compliant tools. Keeps tools organised and in one location. Wall mounting and supplied with tting
kit.
9 MOTBKIT: Shadow board complete with tools (see list below).
9 MOTB: Shadow board (size: 812 x404mm) supplied without tools. Wall mounting and tting kit supplied.
2. SPECIFICATION
Model No: ......................................................... MOTBKIT.V2
Nett Weight: ................................................................ 5.01kg
Size (W x H): .......................................................... 812 x 404
3. TOOLS
4. INSTALLATION
4.1. Using a 4mm drill, drill through the board at all the marked centres.
4.2. Before xing the clips, hold the board in position against the wall and mark through the six xing holes.
4.3. Drill the wall at the six marked locations and insert the wall plugs.
4.4. Attach the xings as shown in the list using 4mm bolts, washers and nuts.
4.5. The tape measure clip (item 6) is held on by 2 x 4mm bolts, washers and nuts.
4.6. When all the clips, hooks etc. have been secured, x the board to the wall by screwing into the wall plugs installed in section 3.3.
Refer to
instruction
manual
MOTB.V2, MOTKIT.V1 Issue1 16/10/24
Original Language Version
© Jack Sealey Limited
MOTBKIT TOOLS
Part No. Description
AK989 Rubber Measuring Tape 5mtr
H1MOT Corrosion Assessment Hammer
S0837 Heelbar 400mm
TST/DG Tyre Tread Depth Gauge
TSTPG8 Tyre Pressure Gauge with Pocket Clip 6-50psi
TST22 13-Pin Towing Socket Tester 12V
VS0210 Brake & Fuel Pipe Inspection Tool
VSTL760 Tyre Lever 760mm
WB02 Wire Brush
5. ASSEMBLED BOARD
.
MOTB.V2, MOTKIT.V1 Issue1 16/10/24
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
REGISTER YOUR
PURCHASE HERE
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component
parts without prior notice. Please note that other versions of this product are available. If you require documentation for alternative
versions, please email or call our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
3
1
2
4
5
3
3
1
6
5
5
2
2
4
3
3
Item No: Description: Size: Quantity:
1 Spring Clip 10mm 2
2 Spring Clip 12mm 3
3 Spring Clip 25mm 5
4 Spring Clip 28mm 2
5 Hook 35mm 3
6 Tape measure Mounting
clip with xings.
1
7 M4 screw/washer/nut 12
8 4mm Wall xings (rawl
plug, screw, washer)
6 ea.
MOTBC - FITTING KIT
