PRESSURE WASHER 25LTR 12V
MODEL NO: PW2512
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! DO NOT use the washer if any part of the unit, gun, nozzle, detergent bottle, hose or cables is damaged. Replace or
repair using genuine parts only. Unauthorised parts may be dangerous and will invalidate your warranty.
9 Always check connections are correctly secured and not cracked or damaged in any way before using the machine.
9 Always be aware of the potential hazards that may occur during use. Study the applications and limitations of the washer before use.
9 Keep the washer in good condition. Use an authorised agent to service the unit.
9 Wear adequate protective clothing, goggles and anti-slip rubber soled footwear.
9 Use where air can freely circulate around the washer to avoid the machine over-heating.
WARNING! Ensure all persons and animals keep at a minimum distance of 15m from the washer when in use.
WARNING! The pressure washer must only be used with clean water. Non-filtered water or corrosive chemicals must not be used as
they will damage the cleaner.
9 Release residual pressure before disconnecting hose.
9 Ensure the nozzle is aimed correctly at the working surface before activating the jet.
WARNING! DO NOT use the washer on any material containing asbestos as this may release hazardous asbestos particles
into the atmosphere.
8 DO NOT direct jet against yourself, other persons or animals, electrical equipment or the machine itself.
8 DO NOT use washer if you are tired or under the influence of alcohol, drugs or intoxicating medication.
8 DO NOT use the washer with flammable or toxic liquids or any other product. Only use recommended detergent. (Sealey
Detergent Model No’s SCS001 - SCS006) Non-recommended detergents may corrode the machine cover and accessories.
8 DO NOT connect other appliances to the machine inlet or outlet.
8 DO NOT move the unit by pulling the hoses or electrical cables. Use handle.
9 When not in use store in a frost proof, dry childproof location.
NOTE: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
2. INTRODUCTION
Lightweight, portable pressure washer which can hold up to 25 litres of water. Ideal for washing many applications, especially where a mains
power or water supply is not available, such as car shows, track days, window cleaning or even garden use. Unit is powered using a 3m
cable tted with a 12V vehicle accessory socket plug. Supplied with 8m hose, variable nozzle lance, detergent bottle and a long xed brush.
Detergent can also be added to the main tank which will allow a very good distribution of foam, making washing the car extremely simple and
effective. Fitted with a strong carry handle.
3. SPECIFICATION
Model No: ............................PW2512
Capacity: ................................ 25ltr
Hose Length: .............................. 8m
Maximum Pressure: ................. 9bar/131psi
Motor Power: .............................36W
Power Supply: .............................12V
Water Flow Rate: ....................... 180ltr/hr
Nett Weight: ............................. 3.1kg
PW2512 | Issue 1 12/12/18
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear eye
protection
4. OPERATION
4.1. FILLING
4.1.1. Either ll tank (g.3) with water and detergent or just water and use detergent bottle (g.8),
4.1.2. supplied.
9 Only use recommended detergent. (Sealey Detergent Model No’s SCS001 - SCS006)
Non-recommended detergents may damage the machine.
4.2. POWER SUPPLY
4.2.1. The washer is powered directly from the vehicle’s 12V accessory socket.
4.2.2. Insert the accessory connector plug (g.1) into the 12V accessory socket in the vehicle.
9 It is advisable to leave the vehicle engine running whilst using the washer.
4.2.3. Close hose valve (g.7) and disconnect the plug from the accessory socket when not in use.
4.3. PRESSURE WASHING
WARNING! Ensure the hose valve is closed before connecting the hose.
4.3.1. Connect the 8m hose to the outlet hose situated inside the tank via a push on coupling (g.2).
4.3.2. To disconnect the hose, pull or push the connector ring in the direction of the arrows (g.4)
and pull the hose out.
4.3.3. To connect the spray gun, ensure the hose valve is closed (g.7), then push the hose
connector onto the gun (g.5).
4.3.4. When connected, open the hose valve (g.6) and the pump will start and build up
initial pressure, then stop, until the trigger is pulled on the spray gun, to release the
pressurised water. Release the trigger to stop the ow of water.
4.3.5. The spray pattern may be adjusted by rotating the collar (g 5).
4.3.6. The unit is tted with an automatic stop switch that will turn the pump off when the trigger
is released.
4.3.7. Always close the hose valve (g.7) before removing tools.
4.4. DETERGENT DISPENSER
4.4.1. To attach the detergent bottle, ensure the hose valve is closed (g.7) and the detergent
bottle switch is set to off (g.9). Connect the hose onto the detergent bottle (g.8).
4.4.2. The detergent bottle (g.8) can be removed by unscrewing from the nozzle body.
4.4.3. When lled with appropriate detergent, (Sealey Detergent Model No’s SCS001 - SCS006)
screw the bottle in place.
4.4.4. The detergent ow is started by opening the hose valve (g.6), then moving the control
lever on the bottle (g.9) either to the spray setting or the jet setting.
4.4.5. When the detergent has been exhausted, set control lever on the bottle to the off position,
close the hose valve, remove the bottle, and rell with neat detergent.
4.5. BRUSH ATTACHMENT
4.5.1. Screw the brush handle onto the brush (g.10). Ensure the hose valve is closed.
4.5.2. Attach the brush by pushing the hose connector onto the brush handle (g.10).
4.5.3. Open the hose valve (g.6) and pull the trigger on the brush, water will ow into the brush head.
5. MAINTENANCE
5.1. The pump unit does not require any regular maintenance.
5.2. The 12V connector plug is tted with an 8A fast blow cartridge fuse. If blown,
replace with identical fuse.
5.3. Should the nozzle become blocked, close the valve on the hose and disconnect the gun,
the nozzle can be back-ushed with either water or air to dislodge any blockage.
5.4. When not in use drain the machine, remove hoses and store in a cool yet frostproof
location beyond the reach of children.
PW2512 | Issue 1 12/12/18
Original Language Version
© Jack Sealey Limited
g.1
g.2
g.4
g.5
g.6 g.7
g.9
g.10
g.3
g.8
PW2512 | Issue 1 12/12/18
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Parts support is available for this product. Please log on to www.sealey.co.uk, email sales@sealey.co.uk or telephone 01284 757500
