A
CarpetXpert Tank
B
Dirty Water Tank
C
StainStriker Tank
D
Crevice Tool
E
Tough Stain Tool
F
Hose Cleaning Tool
G
2x Reversible Bristles
H
177ml Deep Clean Pro Formula
I
355ml OXY Multiplier Formula
J
Spray Trigger
K
Power Button
L
Detach Button
M
Wide Tough Stain Tool*
N
Pet Stain Trapping Tool*
PX200 SERIES
IMPORTANT SAFETY INSTRUCTIONS – FOR HOUSEHOLD USE ONLY
READ CAREFULLY BEFORE USE – SAVE THESE INSTRUCTIONS. FOR HOUSEHOLD USE ONLY;
READ ALL INSTRUCTIONS BEFORE USING THIS SPOT CARPET/UPHOLSTERY CLEANER
PARTS
NOTE: Not all accessories come with all units. Tools may vary by model.
For additional accessories available, please visit sharkaccessories.co.uk
GETTING STARTED
2. Add water to the
CarpetXpert Tank up to
the Water fill line. Then
add CarpetXpert formula
to the Concentrate fill line.
2
WET STAIN CLEANING DRY STAIN CLEANING
5. Replace the cap and
reinstall the tank until it
clicks into place.
5 64
Note: For hard to reach areas, tool can be used without a hand tool attachment using only the crevice tool set up.
Tip: Choosing the bristles - The rubber bristles are best suited for more delicate surfaces and upholstery.
The tough bristles are ideal for stubborn agitation on hard wearing surfaces.
1.
For Wet Stains, follow the Stain Guide located on
the hand tool. Turn ON using the power button
and vacuum up the liquid mess. Spray the stain
area. Scrub with the bristles, then tilt hand tool
forward and drag across the stain area to extract
liquid. Repeat if needed. To avoid longer dry times,
do not over spray.
2.
For Dry stains, follow the Stain Guide located
on the hand tool. Turn ON using the power
button. spray the stain area. Scrub stain again,
then tilt hand tool forwards and drag across the
stain area to extract liquid. Repeat if needed. To
avoid longer dry times, do not over spray.
3
IMPORTANT: Vacuum with traditional vacuum cleaner first before using Stain Striker.
Use ONLY Shark branded cleaning solutions, CarpetXpert/Oxy Multiplier.
1. Detach the CarpetXpert
Tank from the unit. Turn
the tank over, unscrew cap
and remove.
1
6. Unwrap the power cable
and plug into a power
socket. Turn ON unit to
begin cleaning.
3. Replace the cap, then
reinstall the tank until it
clicks into place.
4.
Detach the StainStriker
tank from the unit and
turn over. Unscrew the cap
and pour the StainStriker
formula into the tank.
21
PET STAIN TRAPPING TOOL
Scan QR to view
HOW-TO VIDEOS
and more.
The Shark Pet Stain Trapping Tool is included with select models. This extracts unhygienic messes,
preventing the mess from reaching the hose and the interior of the unit. DO NOT use the tool to remove
pet hair. To use, spray the wet mess, then extract it as advised above. To avoid oversaturating, do not
over spray. DO NOT exceed the MAX FILL line on the Pet Tool Cup.
Keep the tool level, without tipping to prevent the mess from reaching the hose. After use, turn off the
power of the main unit and empty the tool cup where appropriate. Wash the cup, filter, and the rest of
the tool thoroughly with soap and water after each use.
G
B
K
C
H I
D
E
F
A
J
L
M N
1
2
Filter
WARNING
To reduce the risk of fire, electric shock, Injury, or property damage:
1.
Improper connection of the equipment grounding conductor can result in a risk of electric shock. Check with a qualified electrician or
service person if you are in doubt as to whether the socket is properly grounded.
2.
DO NOT modify the plug provided with the appliance.
3.
DO NOT force into socket or try to modify it.
4.
DO NOT pull, close door, or wrap around sharp edges or corners on the cord. To unplug, grasp the plug, not the cord. Keep cord away
from heated surfaces.
5.
To reduce the risk of fire or electric shock due to internal component damage, use ONLY Shark CarpetXpert/StainStriker formula in the
correct tanks, as intended for use with this appliance. See instructions within this guide.
6.
The areas around where you are cleaning may become wet, use care to avoid slipping and falling.
7.
Use care when removing and reattaching the hand tool to the Spot Cleaner to avoid accidental activation of the cleaning solution.
8.
DO NOT spray solution on your skin or in your eyes.
9.
DO NOT fill solution tanks while installed on the appliance. Remove before filling.
10.
DO NOT operate if there is any wetting of the exterior surfaces of the appliance. If the appliance is wet, dry with a cloth before use.
11.
To reduce the risk of shock and unintended operation, turn off and unplug Spot Cleaner before any adjustment, cleaning,
maintenance, or troubleshooting.
12.
Before each use, carefully inspect each part for damage or wear. If a part is damaged or worn out, immediately discontinue use.
DO NOT use if any part is damaged or if Spot Cleaner is not working as it should, has been dropped, left outdoors, or dropped into
water.
13.
DO NOT immerse or spray water on the body of the Spot Cleaner. To clean the surface, wipe with a dry cloth.
14.
DO NOT allow to be used by children or as a toy. Close supervision is necessary when used near children.
15.
DO NOT handle plug or Spot Cleaner with wet hands.
16.
DO NOT use without the dirty water tank, clean solution tank, or filter in place.
17.
Use only a identical Shark® replacement parts. Only use Shark® branded filters and accessories.
18.
If plugging unit into extension cord, ensure cord is no more than 15m to prevent damage to the motor.
19.
DO NOT place Spot Cleaner on uneven surfaces.
20.
DO NOT use to pick up:
a)
Large objects
b)
Hard or sharp objects (glass, nails, screws, or coins)
c)
Large quantities of dust (e.g., drywall dust).
d)
Smoking or burning objects (hot coals, cigarette butts, or matches)
e)
Flammable or combustible materials (lighter fluid, petrol, or kerosene)
f)
Toxic materials (chlorine bleach, ammonia, or drain cleaner)
21.
DO NOT use in the following areas:
a)
Poorly lit areas
b)
Outdoor areas
c)
Spaces that are enclosed and may contain explosive or toxic fumes or vapors (lighter fluid, petrol, kerosene, paint, paint thinners,
mothproofing substances, or flammable dust).
DO NOT: Engage spray trigger unless pointing at the affected area. WARNING: May still spray when the unit is powered off.
* Tools sold with the Pet model PX200UKT (or sold separately)
