DS-K1T320 Series Face Recognion Terminal
User Manual
Legal Informaon
About this Document
●
This Document includes instrucons for using and managing the Product. Pictures, charts,
images and all other informaon hereinaer are for descripon and explanaon only.
●
The informaon contained in the Document is subject to change, without noce, due to
rmware updates or other reasons. Please nd the latest version of the Document at the
Hikvision website ( hps://www.hikvision.com ). Unless otherwise agreed, Hangzhou Hikvision
Digital Technology Co., Ltd. or its aliates (hereinaer referred to as "Hikvision") makes no
warranes, express or implied.
●
Please use the Document with the guidance and assistance of professionals trained in
supporng the Product.
About this Product
●
This product can only enjoy the aer-sales service support in the country or region where the
purchase is made.
●
If the product you choose is a video product, please scan the following QR code to obtain the
"Iniaves on the Use of Video Products", and read it carefully.
Acknowledgment of Intellectual Property Rights
●
Hikvision owns the copyrights and/or patents related to the technology embodied in the
Products described in this Document, which may include licenses obtained from third pares.
●
Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part
of this Document may be excerpted, copied, translated, or modied in whole or in part by any
means without wrien permission.
●
and other Hikvision's trademarks and logos are the properes of Hikvision in
various jurisdicons.
●
Other trademarks and logos menoned are the properes of their respecve owners.
LEGAL DISCLAIMER
●
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS DOCUMENT AND THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS
IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR
DS-K1T320 Series Face Recognion Terminal User Manual
i
IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK.
IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,
INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR
LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING
NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSS.
●
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
●
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY
RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT
RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF
HUMAN RIGHTS ABUSES.
●
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE
LATTER PREVAILS.
Data Protecon
●
To protect data, the development of Hikvision Products incorporates privacy by design
principles. For example, for Products with facial recognion features, biometrics data is stored in
your Products with encrypon method; for ngerprint Products, only ngerprint template will be
saved, which is impossible to reconstruct a ngerprint image.
●
As a data controller/processor, you may process personal data, including collecon, storage, use,
processing, disclosure, deleon, etc. You are advised to pay aenon to and comply with
applicable laws and regulaons related to the protecon of personal data, including without
limitaon, conducng security controls to safeguard personal data, such as, implemenng
reasonable administrave and physical security controls, conduct periodic reviews and the
assessments of the eecveness of your security controls.
© Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
DS-K1T320 Series Face Recognion Terminal User Manual
ii
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
DS-K1T320 Series Face Recognion Terminal User Manual
iii
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference in a residenal installaon. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instrucons, may cause harmful interference to radio communicaons. However, there is
no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television recepon, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
DS-K1T320 Series Face Recognion Terminal User Manual
iv
under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve
2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to
the following two condions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence. L'exploitaon est autorisée aux deux condions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est suscepble d'en compromere le fonconnement.
DS-K1T320 Series Face Recognion Terminal User Manual
v
Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
The precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury or death.
Cauons: Neglecng any of the cauons may cause injury or equipment damage.
Dangers: Follow these safeguards to prevent
serious injury or death.
Cauons: Follow these precauons to prevent
potenal injury or material damage.
Danger:
●
In the use of the product, you must be in strict compliance with the electrical safety regulaons
of the naon and region.
●
Do not connect several devices to one power adapter as adapter overload may cause over-heat
or re hazard.
●
If smoke, odors or noise rise from the device, turn o the power at once and unplug the power
cable, and then please contact the service center.
●
The socket-outlet shall be installed near the equipment and shall be easily accessible.
●
1. Do not ingest baery. Chemical burn hazard!
2. This product contains a coin/buon cell baery. If the coin/buon cell baery is swallowed, it
can cause severe internal burns in just 2 hours and can lead to death.
3. Keep new and used baeries away from children.
4. If the baery compartment does not close securely, stop using the product and keep it away
from children.
5. If you think baeries might have been swallowed or placed inside any part of the body, seek
immediate medical aenon.
6. CAUTION: Risk of explosion if the baery is replaced by an incorrect type.
7. Improper replacement of the baery with an incorrect type may defeat a safeguard (for
example, in the case of some lithium baery types).
8. Do not dispose of the baery into re or a hot oven, or mechanically crush or cut the baery,
which may result in an explosion.
9. Do not leave the baery in an extremely high temperature surrounding environment, which
may result in an explosion or the leakage of ammable liquid or gas.
10. Do not subject the baery to extremely low air pressure, which may result in an explosion or
the leakage of ammable liquid or gas.
11. Dispose of used baeries according to the instrucons.
DS-K1T320 Series Face Recognion Terminal User Manual
vi
Cauons:
●
Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
●
Do not place the device in extremely hot (refer to the specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
●
Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
●
The device cover for indoor use shall be kept from rain and moisture.
●
Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
●
Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
●
Biometric recognion products are not completely applicable to an-spoong environments. If
you require a higher security level, use mulple authencaon modes.
●
The serial port of the equipment is used for debugging only.
●
Install the equipment according to the instrucons in this manual. To prevent injury, this
equipment must be securely aached to the oor/wall in accordance with the installaon
instrucons.
●
Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the baery manufacturer.
●
This bracket is intended for use only with equipped devices. Use with other equipment may
result in instability causing injury.
●
This equipment is for use only with equipped bracket. Use with other (carts, stands, or carriers)
may result in instability causing injury.
DS-K1T320 Series Face Recognion Terminal User Manual
vii
Available Models
Product Name Model Wireless
Face Recognion Terminal DS-K1T320MFWX 13.56 MHz Card Presenng
Frequency, Wi-Fi, 2.4G
DS-K1T320MFX 13.56 MHz Card Presenng
Frequency
DS-K1T320MWX 13.56 MHz Card Presenng
Frequency, Wi-Fi, 2.4G
DS-K1T320MX 13.56 MHz Card Presenng
Frequency
DS-K1T320EFWX 125 KHz Card Presenng
Frequency, Wi-Fi, 2.4G
DS-K1T320EFX 125 KHz Card Presenng
Frequency
DS-K1T320EWX 125 KHz Card Presenng
Frequency, Wi-Fi, 2.4G
DS-K1T320EX 125 KHz Card Presenng
Frequency
Use only power supplies listed in the user instrucons:
Model Manufacturer Standard
TS-A012-120100E2 05K000C00 Shenzhen Transin Technologies
Co., Ltd
CE
DS-K1T320 Series Face Recognion Terminal User Manual
viii
Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Overview ................................................................................................................................ 1
1.2 Features ................................................................................................................................. 1
Chapter 2 Appearance ................................................................................................................ 2
Chapter 3 Installaon ................................................................................................................. 5
3.1 Installaon Environment ........................................................................................................ 5
3.2 Install with Gang Box ............................................................................................................. 5
3.3 Surface Mounng .................................................................................................................. 8
3.4 Base Mounng ..................................................................................................................... 11
Chapter 4 Wiring ...................................................................................................................... 13
4.1 Terminal Descripon ............................................................................................................ 13
4.2 Wire Normal Device ............................................................................................................. 14
Chapter 5 Acvaon ................................................................................................................. 15
5.1 Acvate via Device ............................................................................................................... 15
5.2 Acvate via Mobile Web ...................................................................................................... 16
5.3 Acvate via Web Browser .................................................................................................... 17
5.4 Acvate via SADP ................................................................................................................. 17
5.5 Acvate Device via iVMS-4200 Client Soware ................................................................... 19
Chapter 6 Quick Operaon ....................................................................................................... 20
6.1 Select Language ................................................................................................................... 20
6.2 Set Password Change Type ................................................................................................... 20
6.3 Set Network Parameters ...................................................................................................... 21
6.4 Access to Plaorm ............................................................................................................... 22
6.5 Privacy Sengs .................................................................................................................... 22
6.6 Set Administrator ................................................................................................................. 23
Chapter 7 Basic Operaon ........................................................................................................ 25
DS-K1T320 Series Face Recognion Terminal User Manual
ix
7.1 Login .................................................................................................................................... 25
7.1.1 Login by Acvaon Password ...................................................................................... 25
7.1.2 Login by Administrator ................................................................................................ 25
7.1.3 Forgot Password .......................................................................................................... 26
7.2 Communicaon Sengs ...................................................................................................... 26
7.2.1 Set Wired Network Parameters .................................................................................. 27
7.2.2 Set Wi-Fi Parameters ................................................................................................... 27
7.2.3 Set ISUP Parameters .................................................................................................... 28
7.2.4 Plaorm Access ........................................................................................................... 30
7.2.5 Set AP Mode ............................................................................................................... 30
7.3 User Management ............................................................................................................... 30
7.3.1 Add Administrator ....................................................................................................... 30
7.3.2 Add Face Picture ......................................................................................................... 32
7.3.3 Add Fingerprint ........................................................................................................... 33
7.3.4 Add Card ..................................................................................................................... 34
7.3.5 View PIN code ............................................................................................................. 36
7.3.6 Set Authencaon Mode ............................................................................................ 36
7.3.7 Edit User ...................................................................................................................... 37
7.4 Local Time and Aendance .................................................................................................. 37
7.4.1 Aendance Process Descripon ................................................................................. 37
7.4.2 Department Management .......................................................................................... 38
7.4.3 Enable Local T&A ........................................................................................................ 39
7.4.4 Shi Management ...................................................................................................... 39
7.4.5 Shi Schedule ............................................................................................................. 41
7.5 Plaorm Aendance ............................................................................................................ 42
7.5.1 Disable Aendance Mode via Device ......................................................................... 42
7.5.2 Set Manual Aendance via Device ............................................................................. 43
7.5.3 Set Auto Aendance via Device .................................................................................. 44
DS-K1T320 Series Face Recognion Terminal User Manual
x
7.5.4 Set Manual and Auto Aendance via Device .............................................................. 46
7.6 Aendance Report ............................................................................................................... 47
7.7 Data Management ............................................................................................................... 47
7.7.1 Delete Data ................................................................................................................. 47
7.7.2 Import Data ................................................................................................................. 47
7.7.3 Export Data ................................................................................................................. 48
7.8 Identy Authencaon ........................................................................................................ 49
7.8.1 Authencate via Single Credenal .............................................................................. 49
7.8.2 Authencate via Mulple Credenal .......................................................................... 49
7.9 Basic Sengs ....................................................................................................................... 50
7.10 Password Management ..................................................................................................... 51
7.11 Set Biometric Parameters .................................................................................................. 51
7.12 Set Access Control Parameters .......................................................................................... 52
7.13 Preference Sengs ............................................................................................................ 54
7.14 System Maintenance .......................................................................................................... 55
Chapter 8 Congure the Device via the Mobile Browser ........................................................... 57
8.1 Login .................................................................................................................................... 57
8.2 Overview .............................................................................................................................. 57
8.3 Forget Password ................................................................................................................... 58
8.4 Conguraon ....................................................................................................................... 58
8.4.1 View Device Informaon ............................................................................................. 58
8.4.2 Time Sengs ............................................................................................................... 58
8.4.3 Set DST ........................................................................................................................ 59
8.4.4 User Management ...................................................................................................... 60
8.4.5 Network Sengs ......................................................................................................... 60
8.4.6 User Management ...................................................................................................... 64
8.4.7 Search Event ................................................................................................................ 65
8.4.8 Access Control Sengs ............................................................................................... 65
DS-K1T320 Series Face Recognion Terminal User Manual
xi
8.4.9 Face Parameters Sengs ............................................................................................ 69
8.4.10 Set Time and Aendance via Mobile Web Browser .................................................. 70
8.4.11 Set Privacy Parameters .............................................................................................. 74
8.4.12 Password Mode ........................................................................................................ 74
8.4.13 Upgrade and Maintenance ....................................................................................... 75
8.4.14 View Online Document ............................................................................................. 75
8.4.15 View Open Source Soware License ......................................................................... 75
Chapter 9 Quick Operaon via Web Browser ............................................................................ 76
9.1 Select Language ................................................................................................................... 76
9.2 Time Sengs ........................................................................................................................ 76
9.3 Privacy Sengs .................................................................................................................... 76
9.4 Administrator Sengs ......................................................................................................... 77
9.5 No. and System Network ..................................................................................................... 78
Chapter 10 Operaon via Web Browser .................................................................................... 79
10.1 Login .................................................................................................................................. 79
10.2 Forget Password ................................................................................................................. 79
10.3 Live View ............................................................................................................................ 79
10.4 Person Management .......................................................................................................... 81
10.5 Search Event ...................................................................................................................... 82
10.6 Conguraon ..................................................................................................................... 83
10.6.1 Set Local Parameters ................................................................................................. 83
10.6.2 View Device Informaon ........................................................................................... 83
10.6.3 Set Time .................................................................................................................... 83
10.6.4 Set DST ...................................................................................................................... 84
10.6.5 Change Administrator's Password ............................................................................. 84
10.6.6 Account Security Sengs .......................................................................................... 85
10.6.7 View Device Arming/Disarming Informaon ............................................................ 85
10.6.8 Network Sengs ....................................................................................................... 85
DS-K1T320 Series Face Recognion Terminal User Manual
xii
10.6.9 Set Video Parameters ................................................................................................ 89
10.6.10 Set Image Parameters ............................................................................................. 90
10.6.11 Access Control Sengs ........................................................................................... 90
10.6.12 Card Sengs ........................................................................................................... 93
10.6.13 Time and Aendance Sengs ................................................................................ 94
10.6.14 Local Time and Aendance Sengs ....................................................................... 97
10.6.15 Set Privacy Parameters .......................................................................................... 100
10.6.16 Set Password Mode .............................................................................................. 101
10.6.17 Set Biometric Parameters ..................................................................................... 102
10.6.18 Set Preference ....................................................................................................... 104
10.6.19 Upgrade and Maintenance ................................................................................... 104
10.6.20 Device Debugging ................................................................................................. 105
10.6.21 Log Query .............................................................................................................. 106
10.6.22 Security Mode Sengs ......................................................................................... 106
10.6.23 Cercate Management ....................................................................................... 106
Chapter 11 Other Plaorms to Congure ................................................................................ 109
Appendix A. Tips for Scanning Fingerprint ............................................................................... 110
Appendix B. Tips When Collecng/Comparing Face Picture .................................................... 112
Appendix C. Tips for Installaon Environment ........................................................................ 114
Appendix D. Dimension .......................................................................................................... 115
DS-K1T320 Series Face Recognion Terminal User Manual
xiii
Chapter 1 Overview
1.1 Overview
Face recognion terminal is a kind of access control device for face recognion, which is mainly
applied in security access control systems, such as logisc centers, airports, university campuses,
alarm centrals, dwellings, etc.
1.2 Features
●
2.4-inch LCD screen, 2 MP lens
●
Mulple authencaon methods, including face, ngerprint, card, and PIN, etc
●
Supports M1 card or EM card according to dierent models
●
Max. 500 faces, 1,000 cards, 1,000 ngerprints and 100,000 events
●
Face recognion duraon < 0.2 s/User
●
Supports ISAPI and ISUP 5.0 protocols
●
Conguraon via the PC web browser and mobile web browser
●
Supports AP mode
DS-K1T320 Series Face Recognion Terminal User Manual
1
Chapter 2 Appearance
The appearance of the device with ngerprint is as follows:
Figure 2-1 Appearance（With Fingerprint)
The appearance of the device without ngerprint is as follows:
DS-K1T320 Series Face Recognion Terminal User Manual
2
Figure 2-2 Appearance（Without Fingerprint)
Table 2-1 Appearance Descripon
No. Name
1 Screen
2 Keypad
3 Fingerprint Module
Note
Only devices that support the ngerprint funcon contain a
ngerprint module.
4 Card Swiping Area
5 Camera
6 Supplement Light
7 USB Interface
8 Network Interface
9 Tamper
DS-K1T320 Series Face Recognion Terminal User Manual
3
No. Name
10 Wiring Terminal (Including Power Supply Interface)
11 Debugging Port (For Debugging Only)
DS-K1T320 Series Face Recognion Terminal User Manual
4
Chapter 3 Installaon
3.1 Installaon Environment
●
Indoor use only.
●
Avoid backlight, direct sunlight, and indirect sunlight.
●
For beer recognion, there should be light source in or near the installaon environment.
●
The minimum bearing weight of the wall or other places should be 3 mes heavier than the
device weight.
3.2 Install with Gang Box
Steps
1.
Make sure the gang box is installed on the wall.
Note
You should purchase the gang box separately.
Figure 3-1 Install Gang Box
2.
Secure the mounng plate on the gang box with two supplied screws (SC-KA4X22).
DS-K1T320 Series Face Recognion Terminal User Manual
5
Figure 3-2 Install Mounng Plate
3.
Route the cable through the cable hole, wire the cables and insert the cables in the gang box.
DS-K1T320 Series Face Recognion Terminal User Manual
6
Figure 3-3 Apply Silicone Sealant
4.
Align the device with the mounng plate, and secure the device on the mounng plate with 1
supplied screw (SC-CM4X14-5T10-SUSS).
DS-K1T320 Series Face Recognion Terminal User Manual
7
Figure 3-4 Secure Device
3.3 Surface Mounng
Steps
Note
The addional force shall be equal to three mes the weight of the equipment. The equipment ad
its associated mounng means shall remain secure during the installaon. Aer the installaon,
the equipment, including any associated mounng plate, shall not be damaged.
1.
Secure the mounng plate on the wall with the 4 supplied screws (SC-KA4X22).
DS-K1T320 Series Face Recognion Terminal User Manual
8
Figure 3-5 Install Mounng Plate
2.
Route the cable through the cable hole of the mounng plate, and connect to corresponding
peripherals cables.
Note
If the device is installed outdoor, you should apply silicone sealant to the wiring exit to avoid
water from entering.
DS-K1T320 Series Face Recognion Terminal User Manual
9
Figure 3-6 Apply Silicone Sealant
3.
Align the device with the mounng plate and hang the device on the mounng plate. Use 1
supplied screw (SC-CM4X14_5T10-SUSS) to secure the device and the mounng plate.
DS-K1T320 Series Face Recognion Terminal User Manual
10
Figure 3-7 Hang Device
4.
Aer installaon, for the proper use of the device (outdoor use), sck the protecon lm (parts
of models supplied) on the screen.
3.4 Base Mounng
Steps
1.
Route the cables through the cable hole of the bracket, and connect the terminals with
peripherals cables. Place the bracket close to the back side of the device.
Figure 3-8 Place Bracket Close to Device Back Side
2.
Press the bracket with both hands, and make sure that the buckle of the bracket ts with the
back side of the device. Fasten the bracket in the direcon of the arrow.
DS-K1T320 Series Face Recognion Terminal User Manual
11
Figure 3-9 Fasten Bracket
3.
Buckle into the bracket to the end to complete the installaon.
Figure 3-10 Complete Installaon
DS-K1T320 Series Face Recognion Terminal User Manual
12
Chapter 4 Wiring
You can connect the NC/NO and COM terminal with the door lock, connect the SEN and GND
terminal with the door contact and the BTN/GND terminal with the exit buon.
Note
●
If cable size is 18 AWG, you should use a 12 V power supply. And the distance between the
power supply and the device should be no more than 20 m.
●
If the cable size is 15 AWG, you should use a 12 V power supply. And the distance between the
power supply and the device should be no more than 30 m.
●
If the cable size is 12 AWG, you should use a 12 V power supply. And the distance between the
power supply and the device should be no more than 40 m.
●
The external card reader, door lock, exit buon, and door magnec need individual power
supply.
4.1 Terminal Descripon
The terminals contains power input and door lock.
The descripons of the terminals are as follows:
Table 4-1 Terminal Descripons
Group No. Funcon Color Name Descripon
Group A A1 Power Input Red +12 V 12 VDC Power
Supply
A2 Black GND Ground
Group B B1 Door Lock White/Purple NC Lock Wiring
(NC)
B2 White/Yellow COM Common
B3 White/Red NO Lock Wiring
(NO)
B4 Yellow/Green SENSOR Door Contact
B5 Black GND Ground
B6 Yellow/Grey BUTTON Exit Door
Wiring
DS-K1T320 Series Face Recognion Terminal User Manual
13
4.2 Wire Normal Device
You can connect the terminal with normal peripherals.
Figure 4-1 Device Wiring
Note
●
Do not wire the device to the electric supply directly.
●
When connecng door contact and exit buon, the device should use the same common ground
connecon.
●
The suggested external power supply for door lock is 12 V, 1 A
DS-K1T320 Series Face Recognion Terminal User Manual
14
Chapter 5 Acvaon
You should acvate the device before the rst login. Aer powering on the device, the system will
switch to Device Acvaon page.
Acvaon via the device, SADP tool and the client soware are supported.
The default values of the device are as follows:
●
The default IP address: 192.0.0.64
●
The default port No.: 8000
●
The default user name: admin
5.1 Acvate via Device
If the device is not acvated, you can acvate the device aer it is powered on.
On the Acvate Device page, create a password and conrm the password. Tap Acvate and the
device will acvated.
Figure 5-1 Acvaon Page
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change your
DS-K1T320 Series Face Recognion Terminal User Manual
15
password regularly, especially in the high security system, changing the password monthly or
weekly can beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
5.2 Acvate via Mobile Web
You can acvate the device via mobile web.
Steps
Note
●
Aer powering on the device for the rst me, the hotspot funcon is enabled by default.
●
Only the device with Wi-Fi funcon supports acvaon via AP mode.
1.
Connect to the device hotspot with your mobile phone by entering the hotspot password. The
acvaon page will pop up.
Note
●
If automac pop-up failed. Enter the device default IP or enter www.acsvis.com in the browser
to enter the acvaon page.
●
For inacve devices, the device hotspot name is AP_Serial Number, and the hotspot password
is the device serial number.
●
The device is in the AP mode by default. The AP mode will be disabled aer 30 min. Hold key 3
for 5 s to enter the AP mode again.
●
Aer device acvaon, the hotspot password will be changed to the device acvaon
password.
2.
Create a new password (admin password) and conrm the password.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
3.
Tap Acvate.
DS-K1T320 Series Face Recognion Terminal User Manual
16
4.
Select Conguraon → Communicaon Sengs → Wi-Fi and connect to a Wi-Fi. Or edit the IP
address via the mobile web, PC web browser and the client soware. Edit the device IP address.
You can edit the IP address via the SADP tool, PC web browser and the client soware.
What to do next
Login the mobile web to congure parameters. For details, see Login .
5.3 Acvate via Web Browser
You can acvate the device via the web browser.
Steps
1.
Enter the device default IP address (192.0.0.64) in the address bar of the web browser, and press
Enter.
Note
Make sure the device IP address and the computer's should be in the same IP segment.
2.
Create a new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
3.
Click Acvate.
4.
Edit the device IP address. You can edit the IP address via the SADP tool, the device, and the
client soware.
5.4 Acvate via SADP
SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.
Before You Start
●
Get the SADP soware from the supplied disk or the ocial website hp://
www.hikvision.com/en/ , and install the SADP according to the prompts.
●
The device and the PC that runs the SADP tool should be within the same subnet.
The following steps show how to acvate a device and modify its IP address. For batch acvaon
and IP addresses modicaon, refer to User Manual of SADP for details.
DS-K1T320 Series Face Recognion Terminal User Manual
17
Steps
1.
Run the SADP soware and search the online devices.
2.
Find and select your device in online device list.
3.
Input new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
4.
Click Acvate to start acvaon.
Status of the device becomes Acve aer successful acvaon.
5.
Modify IP address of the device.
1) Select the device.
2) Change the device IP address to the same subnet as your computer by either modifying the IP
address manually or checking Enable DHCP.
3) Input the admin password and click Modify to acvate your IP address modicaon.
DS-K1T320 Series Face Recognion Terminal User Manual
18
5.5 Acvate Device via iVMS-4200 Client Soware
For some devices, you are required to create the password to acvate them before they can be
added to the iVMS-4200 soware and work properly.
Steps
Note
This funcon should be supported by the device.
1.
Enter the Device Management page.
2.
Click on the right of Device Management and select Device.
3.
Click Online Device to show the online device area.
The searched online devices are displayed in the list.
4.
Check the device status (shown on Security Level column) and select an inacve device.
5.
Click Acvate to open the Acvaon dialog.
6.
Create a password in the password eld, and conrm the password.
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
7.
Click OK to acvate the device.
DS-K1T320 Series Face Recognion Terminal User Manual
19
Chapter 6 Quick Operaon
6.1 Select Language
You can select a language for the device system.
Aer the device acvaon, you can select a language for the device system.
Figure 6-1 Select System Language
By default, the system language is English.
Note
Aer you change the system language, the device will reboot automacally.
6.2 Set Password Change Type
Aer acvang the device, you can set the password change type as reserved email address or
security quesons. Once you forgot the device password, you can change the password via the
selected change type.
Change Password via Email Address
If you need to change password via reserved email, you can enter an email address, and press OK.
DS-K1T320 Series Face Recognion Terminal User Manual
20
Change via Security Quesons
If you need to change password via security quesons, you can set security quesons on Web.
Press ESC.
Note
You can only select one type to change password. If you need, you can enter the web page to set
both of the changing types.
6.3 Set Network Parameters
Aer acvaon and select applicaon mode, you can set the network for the device
Steps
1.
When you enter the Select Network page, select Wired Network or Wi-Fi for your actual needs.
Figure 6-2 Select Network
Note
Disconnect the wired network before connecng a Wi-Fi.
2.
Select Next.
Wired Network
Note
Make sure the device has connected to a network.
If enable DHCP, the system will assign the IP address and other parameters automacally.
DS-K1T320 Series Face Recognion Terminal User Manual
21
If disable DHCP, you should set the IP address, the subnet mask, and the gateway.
Wi-Fi
Select a Wi-Fi and enter the Wi-Fi's password to get connected.
Or select Add Wi-Fi and enter the Wi-Fi's name and the password to get connected.
3.
Oponal: Select Back to skip network sengs.
6.4 Access to Plaorm
Enable the funcon and the device can communicate via Hik-Connect. You can add the device to
Hik-Connect modile client and so on.
Steps
1.
Enable Access to Hik-Connect, and set the Server IP and Vericaon Code.
2.
Press OK.
6.5 Privacy Sengs
Aer acvaon, selecng network, you should set the privacy parameters, including the picture
uploading and storage.
Select parameters according to your actual needs.
Figure 6-3 Privacy
Upload Pic. When Auth. (Upload Picture When Authencang)
Upload the pictures captured when authencang to the plaorm automacally.
Save Pic. When Auth. (Save Picture When Authencang)
DS-K1T320 Series Face Recognion Terminal User Manual
22
If you enable this funcon, you can save the picture when Authencang to the device.
Save Registered Pic. (Save Registered Picture)
The registered face picture will be saved to the system if you enable the funcon.
Upload Pic. Aer Linked Capture (Upload Picture Aer Linked Capture)
Upload the pictures captured by linked camera to the plaorm automacally.
Save Pic. Aer Linked Capture (Save Pictures Aer Linked Capture)
If you enable this funcon, you can save the picture captured by linked camera to the device.
Select OK to complete the sengs.
6.6 Set Administrator
Aer device acvaon, you can add an administrator to manage the device parameters.
Before You Start
Acvate the device.
Steps
1.
Enter the employee ID, name and press OK.
Figure 6-4 Add Administrator Page
2.
Select a credenal to add.
Note
Up to one credenal should be added.
-
: Face forward at the camera. Make sure the face is in the face recognion area. Press OK
to capture and press OK to conrm.
DS-K1T320 Series Face Recognion Terminal User Manual
23
-
: Press your nger according to the instrucons on the device screen. Press OK to conrm.
-
: Enter the card No. or present card on the card presenng area. Press OK to conrm.
3.
Press OK.
DS-K1T320 Series Face Recognion Terminal User Manual
24
Chapter 7 Basic Operaon
7.1 Login
Login the device to set the device basic parameters.
7.1.1 Login by Acvaon Password
You should login the system before other device operaons. If you do not congure an
administrator, you should follow the instrucons below to login.
Steps
1.
Long press OK to enter Authencate via Admin page.
2.
Press to enter the password.
-
If you have added an administrator for the device, press OK and enter the password.
-
If you haven't added an administrator for the device, enter the password.
3.
Press OK to enter the home page.
Note
The device will be locked for 30 minutes aer 5 failed password aempts.
7.1.2 Login by Administrator
If you have added an administrator for the device, only the administrator can login the device for
device operaon.
Steps
1.
Long press OK to enter the admin login page.
DS-K1T320 Series Face Recognion Terminal User Manual
25
Figure 7-1 Admin Login
2.
Authencate the administrator's face, ngerprint or card to enter the home page.
Note
The device will be locked for 30 minutes aer 5 failed ngerprint or card aempts.
3.
Oponal: Press OK and you can enter the device acvaon password for login.
4.
Oponal: Press ESC and you can exit the admin login page.
7.1.3 Forgot Password
If you forget the password during authencaon, you can change the password.
Steps
1.
Long press OK to enter Authencate via Administrator page.
2.
Press to enter the password entering page, and then press ESC.
3.
Select Forgot Password.
4.
Answer the security quesons that congured when acvaon.
5.
Create a new password and conrm it.
6.
Press OK.
7.2 Communicaon Sengs
You can set the wired network, the Wi-Fi parameter, the RS-485 parameters, the Wiegand
parameters, ISUP and access to Hik-Connect on the communicaon sengs page.
DS-K1T320 Series Face Recognion Terminal User Manual
26
7.2.1 Set Wired Network Parameters
You can set the device wired network parameters, including the IP address, the subnet mask, the
gateway, and DNS parameters.
Steps
1.
Select System Sengs → Comm. (Communicaon) to enter the Communicaon sengs page.
2.
On the Communicaon page, select Wired Network.
Figure 7-2 Wired Network Sengs
3.
Set IP Address, Subnet Mask, and Gateway.
-
Enable DHCP, and the system will assign IP address, subnet mask, and gateway automacally.
-
Disable DHCP, and you should set the IP address, subnet mask, and gateway manually.
Note
The device's IP address and the computer IP address should be in the same IP segment.
4.
Set the DNS parameters. You can enable Auto Obtain DNS, set the preferred DNS server and the
alternate DNS server.
7.2.2 Set Wi-Fi Parameters
You can enable the Wi-Fi funcon and set the Wi-Fi related parameters.
Steps
Note
The funcon should be supported by the device.
DS-K1T320 Series Face Recognion Terminal User Manual
27
1.
Select System Sengs → Comm. (Communicaon) to enter the Communicaon sengs page.
2.
On the Communicaon sengs page, select Wi-Fi.
Figure 7-3 Wi-Fi Sengs
3.
Enable the Wi-Fi funcon.
4.
Select a Wi-Fi from the list, and enter the Wi-Fi's password. Tap OK.
Note
Only digits, leers, and special characters are allowed in the password.
5.
Set the Wi-Fi's parameters.
-
By default, DHCP is enable. The system will allocate the IP address, the subnet mask, and the
gateway automacally.
-
If disable DHCP, you should enter the IP address, the subnet mask, and the gateway manually.
6.
Press OK to save the sengs and go back to the Wi-Fi tab.
7.
Press ESC to save the network parameters.
7.2.3 Set ISUP Parameters
Set ISUP parameters and the device can upload data via ISUP protocol.
Before You Start
Make sure your device has connect to a network.
Steps
1.
Select System Sengs → Comm. → ISUP .
DS-K1T320 Series Face Recognion Terminal User Manual
28
Figure 7-4 ISUP Sengs
2.
Enable the ISUP funcon and set the ISUP server parameters.
ISUP Version
Set the ISUP version according to your actual needs.
Central Group
Enable central group and the data will be uploaded to the center group.
Main Channel
Support N1 or None.
ISUP
Enable ISUP funcon and the data will be uploaded via ISUP protocol.
Address Type
Select an address type according to your actual needs.
IP
Set the ISUP server's IP address.
Port
Set the ISUP server's port No.
Note
Port No. Range: 1 to 65535.
Device ID
Set device serial no.
ISUP Key
DS-K1T320 Series Face Recognion Terminal User Manual
29
If you choose V5.0, you should create an account and ISUP key. If you choose other version,
you should create an ISUP account only.
Note
●
Remember the ISUP account and ISUP key. You should enter the account name or the key
when the device should communicate with other plaorms via ISUP protocol.
●
ISUP key range: 8 to 16 characters.
7.2.4 Plaorm Access
You can change the device vericaon code and set the server address before you add the device
to the Hik-Connect mobile client.
Before You Start
Make sure your device has connected to a network.
Steps
1.
Select Comm. (Communicaon) on the Home page to enter the Communicaon sengs page.
2.
On the Communicaon sengs page, select Hik-Connect.
3.
Enable Hik-Connect
4.
Enter Server IP.
5.
Create the Vericaon Code, and you need to enter the vericaon code when you manage the
devices via Hik-Connect.
7.2.5 Set AP Mode
You can enable AP mode, and add the device to Hik-Connect to set network.
Steps
1.
Select System Sengs → Comm. (Communicaon Sengs) on the Home page to enter the
Communicaon Sengs page.
2.
On the Communicaon Sengs page, select AP Mode to enter the sengs page.
3.
Enable AP mode.
4.
Select Device QR Code, scan the QR code in Hik-Connect to add the device to set network.
7.3 User Management
On the user management interface, you can add, edit, delete and search the user.
7.3.1 Add Administrator
The administrator can log in the device backend and congure the device parameters.
DS-K1T320 Series Face Recognion Terminal User Manual
30
Steps
1.
Long press OK to enter the admin login page.
2.
Select User → Add User to enter the Add User page.
3.
Edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Select the Name eld and input the user name on the keyboard.
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
Up to 128 characters are allowed in the user name.
5.
Select the Department.
6.
Oponal: Add a face picture, ngerprints, cards, or PIN for the user.
Note
●
For details about adding a face picture, see Add Face Picture .
●
Note
For details about adding a ngerprint, see Add Fingerprint .
●
For details about adding a card, see Add Card .
●
For details about adding a password, see View PIN code .
7.
Oponal: Set the user's authencaon type.
DS-K1T320 Series Face Recognion Terminal User Manual
31
Note
For details about seng the authencaon type, see Set Authencaon Mode .
8.
Set the user role.
Administrator
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
9.
Press ESC and then press OK to save the sengs.
7.3.2 Add Face Picture
Add user's face picture to the device. And the user can use the face picture to authencate.
Steps
Note
Up to 500 face pictures can be added.
1.
Long press OK and login the device.
2.
Select User → Add User to enter the Add User page.
3.
Edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Select the Name eld and input the user name on the keyboard.
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 128 characters.
5.
Select the Face eld to enter the face picture adding page.
DS-K1T320 Series Face Recognion Terminal User Manual
32
Figure 7-5 Add Face Picture
6.
Look at the camera.
Note
●
Make sure your face picture is in the face picture outline when adding the face picture.
●
Make sure the captured face picture is in good quality and is accurate.
●
For details about the instrucons of adding face pictures, see Tips When Collecng/
Comparing Face Picture .
Aer completely adding the face picture, a captured face picture will be displayed at the center
of the page.
7.
Press OK to save the face picture.
8.
Oponal: Press ESC to select Retake and adjust your face posion to add the face picture again.
9.
Set the user role.
Administrator
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
10.
Press ESC and then press OK to save the sengs.
7.3.3 Add Fingerprint
Add a ngerprint for the user and the user can authencate via the added ngerprint.
DS-K1T320 Series Face Recognion Terminal User Manual
33
Steps
Note
●
The funcon should be supported by the device.
●
Up to 1000 ngerprints can be added.
1.
Long press OK and login the device.
2.
Press User → Add User to enter the Add User page.
3.
Select the Employee ID eld and edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not start with 0 and should not be duplicated.
4.
Select the Name eld and input the user name on the keyboard.
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 128 characters.
5.
Select the Fingerprint eld to enter the Fingerprint page.
6.
Follow the instrucons to add a ngerprint.
Note
●
The same ngerprint cannot be repeatedly added.
●
Up to 10 ngerprints can be added for one user.
●
You can also use the client soware or the ngerprint recorder to record ngerprints.
For details about the instrucons of scanning ngerprints, see Tips for Scanning Fingerprint .
7.
Set the user role.
Administrator
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
8.
Press ESC and then press OK to save the sengs.
7.3.4 Add Card
Add a card for the user and the user can authencate via the added card.
DS-K1T320 Series Face Recognion Terminal User Manual
34
Steps
Note
The device supports EM card or M1 card. The supported card type varies between dierent
models.
1.
Long press OK and login the device.
2.
Select User → Add User to enter the Add User page.
3.
Select the Employee ID eld and edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Select the Name eld and input the user name on the keyboard.
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 128 characters.
5.
Select the Card eld and press OK to enter the Add Card page.
6.
Congure the card No.
-
Enter the card No. manually.
-
Present the card over the card swiping area to get the card No.
Note
●
The card No. cannot be empty.
●
Up to 20 characters are allowed in the card No.
●
The card No. cannot be duplicated.
7.
Congure the card type.
8.
Set the user role.
Administrator
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
9.
Press ESC and then press OK to save the sengs.
DS-K1T320 Series Face Recognion Terminal User Manual
35
7.3.5 View PIN code
Add a PIN code for the user and the user can authencate via the PIN code.
Steps
1.
Long press OK and login the device.
2.
Select User → Add User to enter the Add User page.
3.
Edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Select the Name eld and input the user name on the keyboard.
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 128 characters.
5.
Select the PIN code and create a PIN for the user.
Note
Make sure the password mode is Local Password, or the PIN area cannot be eded.
6.
Set the user role.
Administrator
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
7.
Press ESC and then press OK to save the sengs.
7.3.6 Set Authencaon Mode
Aer adding the user's face picture, password, or other credenals, you should set the
authencaon mode and the user can authencate his/her identy via the congured
authencaon mode.
Steps
1.
Long press OK and login the device.
2.
Select User → Add User → Auth. Sengs .
DS-K1T320 Series Face Recognion Terminal User Manual
36
3.
Select Device or Custom as the authencaon mode.
Device
If you want to select device mode, you should set the terminal authencaon mode in Access
Control Sengs page rst. For details see Seng Access Control Parameters.
Custom
You can combine dierent authencaon modes together according to your actual needs.
4.
Press ESC to save the sengs.
7.3.7 Edit User
Aer adding the user, you can edit it.
Edit User
On the User Management page, select a user from the User List to enter the User Informaon
page. Follow the steps in User Management to edit the user parameters. Press ESC to save the
sengs.
Note
The employee ID cannot be edited.
7.4 Local Time and Aendance
Manage department, shi, schedule, and report.
You can add, edit, delete department/shi/schedule. You can also export the aendance report.
7.4.1 Aendance Process Descripon
Figure 7-6 Aendance Process Descripon
DS-K1T320 Series Face Recognion Terminal User Manual
37
7.4.2 Department Management
You can add, edit and delete the department.
Tap Dept. on the Home page to enter the sengs page.
Add Department
Tap +, enter the department name, and tap OK.
Figure 7-7 Add Department
Note
●
The department name supports uppercase English, lowercase English, numbers and symbols.
●
Up to 32 characters can be entered in department name.
●
There are 7 departments in the department management by default.
Edit Department
Tap the department that needs to be edited, to edit the sengs.
You can edit the department name, and view employee informaon according to your actual
needs.
Delete Department
Tap the department that needs to be deleted.
Tap , and tap OK to delete the department.
DS-K1T320 Series Face Recognion Terminal User Manual
38
7.4.3 Enable Local T&A
You can enable Local T&A, and set aendance rules, shi and schedule.
Steps
1.
Long press OK to enter the admin login page.
2.
Select Local T&A, and enable Local T&A.
7.4.4 Shi Management
Set Aendance Rule for Shi
Set aendance rule before seng shi.
Select Local T&A → T&A → Shi Management → Aendance Rule to enter the page.
Figure 7-8 Aendance Rule
Set the aendance rule, including Mark as Later if Checks in Late For and Mark as Early Leave if
Checks out Early For. Aer entering the duraon, Select OK to save the sengs.
Take the following picture as an example to describe the rules.
DS-K1T320 Series Face Recognion Terminal User Manual
39
Figure 7-9 Aendance Rule Example
Mark as Early Leave if Checks out Early For
Set the Mark as Early Leave if Checks out Early For me. For example, set the o work me as
17:30 and set the parameter as 10 min, the earliest check out me will be 17:20. Checking out
at or earlier than 17:19 will be marked as invalid.
Mark as Later if Checks in Late For
Set the Mark as Later if Checks in Late For me. For example, set the o work me as 17:30 and
set the parameter as 30 min, the latest check out me will be 18:00. Checking out at or later
than 18:01 will be marked as invalid.
Note
By default, if set as 0 min, the valid check out me ends at 23:59:59.
Note
●
The unit is min.
●
The available me is from 0 to 1440 min.
Set Shi
Edit or add the shi aendance informaon, including the shi name, the shi period, and the
overme shi period. You can also reset the normal shi aer eding.
Before You Start
Set the aendance rule. For details, see
Set Aendance Rule for Shi .
Steps
1.
Select Local T&A → T&A → Shi Management to enter the page.
DS-K1T320 Series Face Recognion Terminal User Manual
40
Figure 7-10 Shi Management
2.
Set the shi name and period in order and set the overme shi period according to your
needs.
Note
●
If the aendance rules conict with the normal shi period, the device will prompt "Incorrect
Time Duraon". Delete all congured me duraons and reset aer exing.
●
The shi name supports numbers, uppercase leers, lowercase leers, Chinese characters
and symbols.
●
Up to 32 characters are allowed in the shi name.
3.
Select OK to save the sengs.
7.4.5 Shi Schedule
Combine shi and holiday according to your actual needs. Scheduling shi by department and
scheduling shi by individual are supported.
Schedule Shi by Department: All persons in the department use the same shi schedule to take
aendance.
Schedule Shi by Individual: Take aendance according to individual's condions.
Shi Schedule by Department
All persons in the department use the same shi schedule to take aendance.
DS-K1T320 Series Face Recognion Terminal User Manual
41
Before You Start
●
Edit department. For details, see Department Management .
●
Set shi. For details, see Set Shi .
Steps
1.
Select Local T&A → T&A → Schedule to enter the Shi Schedule by Department page.
2.
Select Add Shi Schedule.
3.
Select the Department/Person, select a department. For details, see Department
Management .
4.
Set Shi according to your actual needs.
5.
Select OK.
6.
Oponal: You can edit the schedule informaon in Shi Schedule List.
Shi Schedule by Person
Take aendance according to individual's condions.
Before You Start
●
Add user before seng shi schedule by individual. For details, see User Management .
●
Set shi. For details, see Set Shi .
Steps
1.
Select Local T&A → T&A → Schedule to enter the Shi Schedule by Department page.
2.
Select Add Shi Schedule.
3.
Select the Department/Person, select the person. For details, see
User Management .
4.
Set Shi according to your actual needs.
5.
Select OK.
6.
Oponal: You can edit the schedule informaon in Shi Schedule List.
7.5 Plaorm Aendance
You can set the aendance mode as check in, check out, break out, break in, overme in, and
overme out according to your actual situaon.
Note
The funcon should be used cooperavely with me and aendance funcon on the client
soware.
7.5.1 Disable Aendance Mode via Device
Disable the aendance mode and the system will not display the aendance status on the inial
page.
DS-K1T320 Series Face Recognion Terminal User Manual
42
Select Plaorm Aendance to enter the sengs page.
Figure 7-11 Disable Aendance Mode
Set the Aendance Mode as Disable.
You will not view or congure the aendance status on the inial page. And the system will follow
the aendance rule that congured on the plaorm.
7.5.2 Set Manual Aendance via Device
Set the aendance mode as manual, and you should select a status manually when you take
aendance.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Select Plaorm Aendance to enter the sengs page.
2.
Set the Aendance Mode as Manual.
DS-K1T320 Series Face Recognion Terminal User Manual
43
Figure 7-12 Manual Aendance Mode
3.
Enable the Aendance Status Required.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
The name will be displayed on the T & A Status page and the authencaon result page.
Result
You should select an aendance status manually aer authencaon.
Note
If you do not select a status, the authencaon will be failed and it will not be marked as a valid
aendance.
7.5.3 Set Auto Aendance via Device
Set the aendance mode as auto, and you can set the aendance status and its available schedule.
The system will automacally change the aendance status according to the congured schedule.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Select Plaorm Aendance to enter the sengs page.
2.
Set the Aendance Mode as Auto.
DS-K1T320 Series Face Recognion Terminal User Manual
44
Figure 7-13 Auto Aendance Mode
3.
Enable the Aendance Status Required funcon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
The name will be displayed on the T & A Status page and the authencaon result page.
6.
Set the status' schedule.
1) Select Aendance Schedule.
2) Select Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, or Sunday.
3) Set the selected aendance status's start me of the day.
4) Press OK.
5) Repeat step 1 to 4 according to your actual needs.
Note
The aendance status will be valid within the congured schedule.
Result
When you authencate on the inial page, the authencaon will be marked as the congured
aendance status according to the congured schedule.
Example
If set the Break Out as Monday 11:00, and Break In as Monday 12:00, the valid user's
authencaon from Monday 11:00 to 12:00 will be marked as break.
DS-K1T320 Series Face Recognion Terminal User Manual
45
7.5.4 Set Manual and Auto Aendance via Device
Set the aendance mode as Manual and Auto, and the system will automacally change the
aendance status according to the congured schedule. At the same me you can manually
change the aendance status aer the authencaon.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Select Plaorm Aendance to enter the sengs page.
2.
Set the Aendance Mode as Manual and Auto.
Figure 7-14 Manual and Auto Mode
3.
Enable the Aendance Status Required funcon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
The name will be displayed on the T & A Status page and the authencaon result page.
6.
Set the status' schedule.
1) Select Aendance Schedule.
2) Select Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, or Sunday.
3) Set the selected aendance status's start me of the day.
4) Press OK.
5) Repeat step 1 to 4 according to your actual needs.
DS-K1T320 Series Face Recognion Terminal User Manual
46
Note
The aendance status will be valid within the congured schedule.
Result
On the inial page and authencate. The authencaon will be marked as the congured
aendance status according to the schedule. If you tap the edit icon on the result tab, you can
select a status to take aendance manually, the authencaon will be marked as the edited
aendance status.
Example
If set the Break Out as Monday 11:00, and Break In as Monday 12:00, the valid user's
authencaon from Monday 11:00 to 12:00 will be marked as break.
7.6 Aendance Report
You can export Total Reports, Aendance Record, Summary Report, Abnormal Aendance, Shi
Schedule and Aendance Card.
Select Aendance Report, plug a USB ash drive, and you can select to export Total Reports,
Aendance Record, Summary Report, Abnormal Aendance, Shi Schedule and Aendance Card.
7.7 Data Management
You can delete data, import data, and export data.
7.7.1 Delete Data
Delete user data.
On the Home page, select Data → Delete Data → User Data . All user data added in the device will
be deleted.
7.7.2 Import Data
Steps
1.
Plug a USB ash drive in the device.
2.
On the Home page, select Data → Import Data .
3.
Select User Data, Face Data or Access Control Parameters .
Note
The imported access control parameters are conguraon les of the device.
DS-K1T320 Series Face Recognion Terminal User Manual
47
4.
Enter the created password when you exported the data. If you do not create a password when
you exported the data, leave a blank in the input box and select OK immediately.
Note
●
If you want to transfer all user informaon from one device (Device A) to another (Device B),
you should export the informaon from Device A to the USB ash drive and then import from
the USB ash drive to Device B. In this case, you should import the user data before imporng
the prole photo.
●
The supported USB ash drive format is FAT32.
●
The imported pictures should be saved in the folder (named enroll_pic) of the root directory
and the picture's name should be follow the rule below:
Card No._Name_Department_Employee ID_Gender.jpg
●
If the folder enroll_pic cannot save all imported pictures, you can create another folders,
named enroll_pic1, enroll_pic2, enroll_pic3, enroll_pic4, under the root directory.
●
The employee ID should be less than 32 characters. It can be a combinaon of lower leers,
upper leers, and numbers. It should not be duplicated, and should not start with 0.
●
Requirements of face picture should follow the rules below: It should be taken in full-face
view, directly facing the camera. Do not wear a hat or head covering when taking the face
picture. The format should be JPEG or JPG.
7.7.3 Export Data
Steps
1.
Plug a USB ash drive in the device.
2.
On the Home page, select Data → Export Data .
3.
Select Face Data, Event Data, User Data, or Access Control Parameters.
Note
The exported access control parameters are conguraon les of the device.
4.
Oponal: Create a password for exporng. When you import those data to another device, you
should enter the password.
Note
●
The supported USB ash drive format is DB.
●
The system supports the USB ash drive with the storage of 1G to 32G. Make sure the free
space of the USB ash drive is more than 512M.
●
The exported user data is a DB le, which cannot be edited.
DS-K1T320 Series Face Recognion Terminal User Manual
48
7.8 Identy Authencaon
Aer network conguraon, system parameters conguraon and user conguraon, you can go
back to the inial page for identy authencaon. The system will authencate person according
to the congured authencaon mode.
7.8.1 Authencate via Single Credenal
Set the user authencaon type before authencaon. For details, see Set Authencaon Mode .
Authencate face, ngerprint, card or PIN.
Face
Face forward at the camera and start authencaon via face.
Fingerprint
Place the enrolled ngerprint on the ngerprint module and start authencaon via ngerprint.
Card
Present the card on the card swiping area and start authencaon via card.
Note
The card can be normal IC card, or encrypted card.
PIN Code
Enter the pin code to authencate via PIN code.
If authencaon completed, a prompt "Authencated" will pop up.
7.8.2 Authencate via Mulple Credenal
Before You Start
Set the user authencaon type before authencaon. For details, see Set Authencaon Mode .
Steps
1.
If the authencaon mode is Card and Face, Password and Face, Card and Password, Card and
Face and Fingerprint, authencate any credenal according to the instrucons on the live view
page.
Note
●
The card can be normal IC card, or encrypted card.
2.
Aer the previous credenal is authencated, connue authencate other credenals.
DS-K1T320 Series Face Recognion Terminal User Manual
49
Note
●
For detailed informaon about scanning ngerprint, see Tips for Scanning Fingerprint.
●
For detailed informaon about authencang face, see Tips When Collecng/Comparing Face
Picture.
If authencaon succeeded, the prompt "Authencated" will pop up.
7.9 Basic Sengs
You can set the voice, me, sleeping (s), language, supplement light and video standard.
Long press OK and login the device. Select System Sengs → Basic to enter Basic Sengs page.
Figure 7-15 Basic Sengs Page
Voice Sengs
You can enable/disable the voice funcon.
Time Sengs
Set the me zone, the device me and the DST.
Sleeping (s)
Set the device sleeping waing me (s). For example, when you are on the inial page and if
you set the sleeping me to 30 s, the device will sleep aer 30 s without any operaon.
Note
20 s to 999 s are available to congure.
Select Language
DS-K1T320 Series Face Recognion Terminal User Manual
50
Select the language according to actual needs.
Supplement Light
Set the white light mode, brightness, start me and end me.
Video Standard
PAL
25 frames per second. Suitable for mainland China, Hong Kong (China), the Middle East
countries, Europe countries, etc.
NTSC
30 frames per second. Suitable for the USA, Canada, Japan, Taiwan (China), Korea, the
Philippines, etc.
7.10 Password Management
You can change device password.
Steps
1.
Long press OK and login the device. Select System Sengs → Basic → Password .
2.
Select Change Password. Enter the old password.
3.
Enter the new password and conrm it.
4.
Select OK.
Note
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
two kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
service provider and/or end-user.
7.11 Set Biometric Parameters
You can customize the face parameters to improve the face recognion performance. The
congurable parameters includes face liveness level, face recognion distance, face recognion
interval, face 1:N security level, face 1:1 security level and face with mask detecon.
Long press OK and login the device. Select System Sengsto enter System Sengs page. Then
select Biometrics to enter Biometrics sengs page.
DS-K1T320 Series Face Recognion Terminal User Manual
51
Table 7-1 Face Picture Parameters
Parameter Descripon
Face Liveness Level Aer enabling face an-spoong funcon, you can set the matching
security level when performing live face authencaon.
Face Recognion
Distance
Set the valid distance between the user and the camera when
authencang.
Face Recognion
Interval
The me interval between two connuous face recognions when
authencang.
Note
You can input the number from 1 to 10.
Face 1:N Security Level Set the matching threshold when authencang via 1:N matching mode.
The larger the value, the smaller the false accept rate and the larger the
false rejecon rate.
Face 1:1 Security Level Set the matching threshold when authencang via 1:1 matching mode.
The larger the value, the smaller the false accept rate and the larger the
false rejecon rate.
Face with Mask
Detecon
Aer enabling the face with mask detecon, the system will recognize
the captured face with mask picture. You can set face with mask & face
1:1 level and 1:N level and the strategy.
Reminder of Wearing
If the person do not wear a face mask when authencang, the
device prompts a nocaon and the door will open.
Must Wear
If the person do not wear a face mask when authencang, the
device prompts a nocaon and the door keeps closed.
None
If the person do not wear a face mask when authencang, the
device will not prompt a nocaon.
7.12 Set Access Control Parameters
You can set the access control permissions, including the funcons of authencaon mode, enable
NFC card, enable M1 card, door contact, open duraon (s) and authencaon interval (s).
On the home page, select ACS (Access Control Sengs) to enter the Access Control Sengs page.
Edit the access control parameters on this page.
DS-K1T320 Series Face Recognion Terminal User Manual
52
Figure 7-16 Access Control Parameters
The available parameters descripons are as follows:
Table 7-2 Access Control Parameters Descripons
Parameter Descripon
Terminal Authencaon Mode Select the face recognion terminal's authencaon mode. You
can also customize the authencaon mode.
Note
●
Only the device with the ngerprint module supports the
ngerprint related funcon.
●
Biometric recognion products are not completely applicable
to an-spoong environments. If you require a higher
security level, use mulple authencaon modes.
●
If you adopt mulple authencaon modes, you should
authencate other methods before authencang face.
Card Reader Authencaon
Mode
Select the card reader's authencaon mode.
Enable NFC Card Enable the funcon and you can present the NFC card to
authencate.
Enable M1 Card Enable the funcon and you can present the M1 card to
authencate.
DS-K1T320 Series Face Recognion Terminal User Manual
53
Parameter Descripon
M1 Card Encrypon Enabling the M1 card encrypon funcon can improve the card
security level. The card will not be copied easily.
Door Contact You can select "Remain Open" or "Remain Closed" according to
your actual needs. By default, it is "Remain Closed".
Open Duraon Set the door unlocking duraon. If the door is not opened for
the set me, the door will be locked. Available door locked me
range: 1 to 255s.
Authencaon Interval Set the device authencang interval. Available authencaon
interval range: 0 to 65535.
Authencaon Result Display
Duraon (s)
Set the authencaon result displaying me duraon aer
authencaon.
Password Mode Plaorm-Applied Personal PIN
The PIN is managed and distributed by the plaorm. You
cannot set the PIN on the device or Web.
Device-Set Personal PIN
The PIN is set on the device or Web. You cannot set the PIN
on other plaorm.
7.13 Preference Sengs
You can congure preference sengs parameters.
Steps
1.
Select System Sengs → Preference to enter the preference sengs page.
Theme
You can set the theme of the prompt window on the authencaon page. You can select
Theme as Authencaon/Simple.
Authencaon
The device authencaon page will display the live view page. And the person's name,
employee ID, face pictures will all be displayed aer authencaon.
Simple
Aer selecng this mode, the live view of the authencaon page will be disabled, and in
the meanwhile, the person's name, employee ID, face pictures will all be hidden.
Show Aendance Record During Check
You can enable Show Aendance Record During Check, aer enabling, aendance record
will display during check.
DS-K1T320 Series Face Recognion Terminal User Manual
54
2.
Select OK .
7.14 System Maintenance
You can view the device system informaon and capacity. You can also upgrade device, view the
user manual, restore the system to factory sengs, default sengs, and reboot the system.
Long press OK and login the device. Select Maint. to enter System Maintenance page.
Figure 7-17 Maintenance Page
System Informaon
You can view the device informaon including device model, serial No., rmware version, MAC
address, producon data and open source code license.
Note
The page may vary according to dierent device models. Refers to the actual page for details.
Capacity
You can view the number of user, face picture, card, ngerprint and event.
Note
Parts of the device models support displaying the ngerprint number. Refers to the actual page
for details.
Device Upgrade
Online Update
DS-K1T320 Series Face Recognion Terminal User Manual
55
If the device has been connected to Hik-Connect and network, when there is a new
installaon package in Hik-Connect, you can select Device Upgrade → Online Update to
upgrade the device system.
Update via USB
Plug the USB ash drive in the device USB interface. Select Device Upgrade → Update via
USB , and the device will read the digicap.dav le in the USB ash drive to start upgrading.
User Manual
You can scan the QR code to view the user manual.
Restore to Factory Sengs
All parameters will be restored to the factory sengs. The system will reboot to take eect.
Restore to Default Sengs
All parameters, except for the communicaon sengs, remotely imported user informaon, will
be restored to the default sengs. The system will reboot to take eect.
Reboot
The device will reboot aer the conrmaon.
Select System Informaon → , long press OK, and enter admin password to set the face
Face Parameter
Custom An-Spoong Detecon
Face Liveness Level
Aer enabling face an-spoong funcon, you can set the matching security level
when performing live face authencaon.
An-Spoong Detecon Threshold
The larger the value, the smaller the false accept rate and the larger the false rejecon
rate. The smaller the value, the larger the false accept rate and the smaller the false
rejecon rate.
Lock Face for An-Spoong Protecon
Aer enabling this funcon, the device will lock automacally when an-spoong
detecon failed.
Lock Duraon
The lock duraon aer enabling Lock Face for An-Spoong Protecon when an-
spoong detecon failed.
Version Informaon
You can view the device informaon.
DS-K1T320 Series Face Recognion Terminal User Manual
56
Chapter 8 Congure the Device via the Mobile
Browser
8.1 Login
You can login via mobile browser.
Note
●
Parts of the model supports Wi-Fi sengs.
●
Make sure the device is acvated.
●
Make sure the device and the mobile phone are in the same Wi-Fi.
Enter the device IP address in the address bar of the mobile browser and press Enter to enter the
login page.
Enter the device user name and the password. Tap Login.
8.2 Overview
You can view the door status, network status and basic informaon, and set person management,
smart sengs, authencaon sengs, and door parameters via shortcut entry.
Funcon Descripons:
Door Status
/ / /
The door status is open/closed/remaining open/remaining closed. You can tap to select
open/closed/remaining open/remaining closed status according to your actual needs.
Shortcut Entry
You can set person management, smart sengs, authencaon sengs, and door parameters
via shortcut entry.
Network Status
You can view the connected and registered status of wired network, wireless network,
bluetooth, ISUP and Hik-Connect.
Basic Informaon
You can view the model, serial No. and rmware version.
DS-K1T320 Series Face Recognion Terminal User Manual
57
8.3 Forget Password
If you forget the password when logging in, you can change the password by email address or
security quesons.
On the login page, tap Forget Password.
Select Vericaon Mode.
Security Queson Vericaon
Answer the security quesons.
E-mail Vericaon
1. Export the QR code and send it to pw_rec[email protected] as aachment.
2. You will receive a vericaon code within 5 minutes in your reserved email.
3. Enter the vericaon code into the vericaon code eld to verify your idencaon.
Click Next, create a new password and conrm it.
8.4 Conguraon
8.4.1 View Device Informaon
View the device name, language, model, serial No., version, number of channels, IO input number,
number of alarm input and output, Mac address, factory informaon and device capacity, etc.
Tap → System Sengs → Basic Informaon to enter the conguraon page.
You can view the device name, language, model, serial No., version, number of channels, IO input
number, number of alarm input and output, Mac address, factory informaon and device capacity,
etc.
8.4.2 Time Sengs
Set the me zone, me sync. mode, and displayed me.
Tap → System Sengs → Time Sengs to enter the sengs page.
DS-K1T320 Series Face Recognion Terminal User Manual
58
Figure 8-1 Time Sengs
Tap Save to save the sengs.
Time Zone
Select the me zone where the device is located from the drop-down list.
Time Sync. Mode
Manual
By default, the device me should be synchronized manually. You can set the device me
manually.
NTP
Set the NTP server's IP address, port No., and interval.
8.4.3 Set DST
Steps
1.
Tap
→ System Sengs → Time Sengs , to enter the sengs page.
DS-K1T320 Series Face Recognion Terminal User Manual
59
Figure 8-2 DST
2.
Tap Enable DST.
3.
Set the start me, end me, and DST bias.
4.
Tap Save.
8.4.4 User Management
Steps
1.
Tap → User Management → User Management → admin to enter the seng page.
2.
Enter the old password and create a new password.
3.
Conrm the new password.
4.
Tap Save.
Note
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using 8-16 characters, including at least two kinds
of following categories: upper case leers, lower case leers, numbers, and special characters)
in order to increase the security of your product. And we recommend you change your password
regularly, especially in the high security system, changing the password monthly or weekly can
beer protect your product.
8.4.5 Network Sengs
You can set the wired network, Wi-Fi parameters and device port.
Wired Network
Set wired network.
DS-K1T320 Series Face Recognion Terminal User Manual
60
Tap → Communicaon Sengs → Wired Network to enter the conguraon page.
DHCP
If you disable the funcon, you should set the IPv4 address, IPv4 subnet mask, IPv4 default
gateway, Mac address, and MTU, Mac address, MTU.
If you enable the funcon, the system will allocate the IPv4 address, IPv4 subnet mask, the IPv4
default gateway automacally.
DNS Server
Set the preferred DNS server and the Alternate DNS server according to your actual need.
Set Wi-Fi Parameters
Set the Wi-Fi parameters for device wireless connecon.
Steps
Note
The funcon should be supported by the device.
1.
Tap → Communicaon Sengs → Wi-Fi to enter the sengs page.
2.
Enable Wi-Fi.
DS-K1T320 Series Face Recognion Terminal User Manual
61
Figure 8-3 Wi-Fi
DS-K1T320 Series Face Recognion Terminal User Manual
62
3.
Add Wi-Fi.
1) Tap Add Wi-Fi.
2) Enter Wi-Fi Name and Wi-Fi Password, and select Encrypon Type.
3) Tap Save.
4.
Select the Wi-Fi name, and tap Connect.
5.
Enter the password and tap Save.
Set Device Hotspot
Set the device hotspot, and mobile phone can connect to the device to enter the mobile browser.
Steps
1.
Tap → Communicaon Sengs → Device Hotspot .
2.
You can enable device hotspot and view the hotspot name.
Note
By default, the hotspot name is the AP_Device Serial No.
3.
Tap Save.
Set Port Parameters
You can set the HTTP and HTTPS according to actual needs when accessing the device via network.
Tap → Network Service → HTTP(S) , to enter the seng page.
HTTP
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.0.0.65:81 in the browser for login.
HTTPS
Set the HTTPS for accessing the browser. Cercate is required when accessing.
Plaorm Access
Plaorm access provides you an opon to manage the devices via plaorm.
Steps
1.
Tap → Device Access → Hik-Connect to enter the sengs page.
Note
Hik-Connect is an applicaon for mobile devices. With the App, you can view live image of the
device, receive alarm nocaon and so on.
2.
Check Enable to enable the funcon.
3.
You can enable Custom to enter the server address.
DS-K1T320 Series Face Recognion Terminal User Manual
63
Note
●
6 to 12 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are recommended to use
a combinaon of no less than 8 leers or numbers.
●
The vericaon code cannot be 123456 or abcdef (case non-sensive0).
4.
You can view Register Status and Binding Status.
5.
Enable Video Encrypon, and create the password and conrm it.
Note
Aer adding the device to APP, you need to enter the video encrypon password to live view the
device.
6.
You can tap Bind An Account → View QR Code , scan the QR code to bind an acount.
7.
Tap Save to enable the sengs.
Set ISUP Parameters
Set the ISUP parameters for accessing device via ISUP protocol.
Steps
Note
The funcon should be supported by the device.
1.
Tap → Device Access → ISUP to enter the sengs page.
2.
Enable ISUP.
3.
Set the ISUP version, server Address, port, device ID and encrypon key.
Note
If you select 5.0 as the version, you should set the encrypon key as well.
4.
Tap Save to save the sengs.
8.4.6 User Management
You can add, edit, delete, and search users via mobile Web browser.
Steps
1.
Tap → Person Management to enter the sengs page.
2.
Add user.
1) Tap+.
2) Set the following parameters.
Employee ID
Enter the employee ID. The Employee ID cannot be 0 or exceed 32 characters. It can be a
combinaon of uppercase, lowercase leers and numbers.
DS-K1T320 Series Face Recognion Terminal User Manual
64
Name
Enter your name. The name supports numbers, uppercase and lowercase English, and
characters. The name is recommended to be within 32 characters.
Long-Term Eecve User
Set the user permission as long-term eecve.
Start Date/End Date
Set Start Date and End Date of user permission.
Administrator
If the user needs to be set as administrator, you can enable Administrator.
User Role
Select your user role.
Face
Add Face picture. Tap Face, then tap Camera to add face or tap Choose from Album to
import the face.
Fingerprint
Add ngerprint. Tap Fingerprint, then tap +, and add ngerprint via the ngerprint module.
Card
Add card. Tap Card, then tap +, enter the card No. and select card type.
3) Tap Save.
3.
Tap the user that needs to be edited in the user list to edit the informaon.
4.
Tap the user that needs to be deleted in the user list, and tap
to delete the user.
5.
You can search the user by entering the employee ID or name in the search bar.
8.4.7 Search Event
Tap Search to enter the Search page.
Enter the search condions, including the employee ID, the name, the card No., the start me, and
the end me, and tap Search.
Note
Support searching for names within 32 digits.
8.4.8 Access Control Sengs
Set Authencaon Parameters
Set Authencaon Parameters.
DS-K1T320 Series Face Recognion Terminal User Manual
65
Steps
1.
Tap → Access Control → Authencaon Sengs .
2.
Tap Save.
Terminal
Select terminal for sengs.
Terminal Type/Terminal Model
Get terminal descripon. They are read-only.
Enable Authencaon Device
Enable the authencaon funcon.
Authencaon
Select an authencaon mode according to your actual needs from the drop-down list.
Connuous Face Recognion Interval (s)
You can set the interval between 2 connuous recognion of a same person during the
authencaon. In the congured interval, Person A can only recognized once. If another
person (Person B) has recognized during the interval, Person A can recognized again.
Authencaon Interval
You can set the authencaon interval of the same person when authencang. The same
person can only authencate once in the congured interval. A second authencaon will be
failed.
Alarm of Max. Failed Aempts
Enable to report alarm when the card reading aempts reach the set value.
Main Interface Mode
You can set the Main Interface Mode as Authencaon Mode or Simple.
Enable Tampering Detecon
Enable the an-tamper detecon for the card reader.
Enable Card No. Reversing
The card No. will be in reverse sequence aer enabling the funcon.
Set Door Parameters
Tap → Access Control → Door Parameters .
DS-K1T320 Series Face Recognion Terminal User Manual
66
Figure 8-4 Door Parameters Sengs Page
Tap Save to save the sengs aer the conguraon.
Name
You can create a name for the door.
Open Duraon
Set the door unlocking duraon. If the door is not opened for the set me, the door will be
locked.
Exit Buon Type
DS-K1T320 Series Face Recognion Terminal User Manual
67
You can set the exit buon as Remain Open or Remain Closed according to your actual needs.
By default, it is Remain Open.
Door Remain Open Duraon with First Person (min)
Set the door open duraon when rst person is in. Aer the rst person is authorized, it allows
mulple persons access the door or other authencaon acons.
Door Open Timeout Alarm
An alarm will be triggered if the door has not been closed within the congured me duraon.
Door Contact
You can set the door contact as Remain Open or Remain Closed according to your actual needs.
By default, it is Remain Closed.
Extended Open Duraon
The door contact can be enabled with appropriate delay aer person with extended access
needs swipes her/his card.
Duress Code
The door can open by inpung the duress code when there is duress. At the same me, the
client can report the duress event.
Super Password
The specic person can open the door by inpung the super password.
Unlock Password
The specic person can open the door by inpung the unlock password.
Note
The duress code and the super code should be dierent. And the digit ranges from 4 to 8.
Terminal Parameters
You can set terminal parameters for accessing.
Tap → Access Control → Terminal Parameters .
You can set Working Mode as Access Control Mode. The access control mode is the device normal
mode. You should authencate your credenal for accessing.
Tap Save to save the sengs aer the conguraon.
Set Card Security
Tap
→ Access Control → Card Security to enter the conguraon page.
Set the parameters and tap Save.
Enable NFC Card
DS-K1T320 Series Face Recognion Terminal User Manual
68
In order to prevent the mobile phone from geng the data of the access control, you can
enable NFC card to increase the security level of the data.
Enable M1 Card
Enable M1 card and authencang by presenng M1 card is available.
M1 Card Encrypon
M1 card encrypon can improve the security level of authencaon.
Sector
Enable the funcon and set the encrypon sector. By default, Sector 13 is encrypted. It is
recommended to encrypt sector 13.
Enable CPU Card
Enable CPU card and authencang by presenng CPU card is available.
8.4.9 Face Parameters Sengs
Set Face Parameters.
Face Parameters Sengs
Tap → Smart → Face Recognion Parameters .
Face An-spoong
Enable or disable the live face detecon funcon. If enabling the funcon, the device can
recognize whether the person is a live one or not.
Live Face Detecon Security Level
Aer enabling the face an-spoong funcon, you can set the matching security level when
performing live face authencaon.
1:1 Matching Threshold
Set the matching threshold when authencang via 1:1 matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate.
1:N Matching Threshold
Set the matching threshold when authencang via 1:N matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate. The maximum value is
100.
Face Recognion Timeout Value (s)
Congure the meout period for face recognion. If the face recognion me exceeds the
congured value, the device will prompt the face recognion meout.
Fingerprint Parameters
Tap → Smart → Fingerprint Parameters .
DS-K1T320 Series Face Recognion Terminal User Manual
69
Fingerprint Security Level
You can set the security level of ngerprint. The higher the security level you set, the lower the
False Acceptance Rate (FAR) will be. The higher the security level you set, the lower the False
Rejecon Rate (FRR) will be.
Face Mask Detecon Parameters
Face with Mask Detecon
Aer enabling the face with mask detecon, the system will recognize the captured face with
mask picture. You can set face with mask1:N matching threshold, its ECO mode, and the
strategy.
None
If the person do not wear a face mask when authencang, the device will not prompt a
nocaon.
Reminder of Wearing
If the person do not wear a face mask when authencang, the device prompts a
nocaon and the door will open.
Must Wear
If the person do not wear a face mask when authencang, the device prompts a
nocaon and the door keeps closed.
Face with Mask & Face (1:1)
Set the matching value when authencang with face mask via 1:1 matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate.
Face with Mask 1:N Matching Threshold
Set the matching threshold when authencang with face mask via 1:N matching mode. The
larger the value, the smaller the false accept rate and the larger the false rejecon rate.
Note
The funcons vary according to dierent models. Refers to the actual device for details.
Tap Save to save the sengs.
8.4.10 Set Time and Aendance via Mobile Web Browser
You can set me and aendance by managing department, user, shi, holiday, and shi schedule.
You can add, edit, and delete aendance department, user, shi, holiday, and shi schedule.
Manage Department via Mobile Web Browser
You can add, edit and delete the department.
DS-K1T320 Series Face Recognion Terminal User Manual
70
Steps
1.
Tap → Department Management to enter the sengs page.
2.
Add the department.
1) Tap +.
2) Enter the department name, and tap OK.
Note
●
The department name supports uppercase English, lowercase English, numbers and symbols.
●
Up to 32 characters can be entered in department name.
●
There are 7 departments in the department management by default.
3.
Oponal: You can view employee according to your actual needs.
4.
Delete the department.
1) Tap the department that needs to be deleted.
2) Tap , and tap OK to delete the department.
Set Aendance Rule for Shi
Set aendance rule before seng shi.
Tap → Time and Aendance → Aendance Rule to enter the page.
Set the aendance rule, including Mark as Later if Checks in Late For and Mark as Early Leave if
Checks out Early For. Aer entering the duraon, tap Save to save the sengs.
Take the following picture as an example to describe the rules.
Figure 8-5 Aendance Rule Example
Mark as Early Leave if Checks out Early For
Set the Mark as Early Leave if Checks out Early For me. For example, set the o work me as
17:30 and set the parameter as 10 min, the earliest check out me will be 17:20. Checking out
at or earlier than 17:19 will be marked as invalid.
Mark as Later if Checks in Late For
Set the Mark as Later if Checks in Late For me. For example, set the o work me as 17:30 and
set the parameter as 30 min, the latest check out me will be 18:00. Checking out at or later
than 18:01 will be marked as invalid.
DS-K1T320 Series Face Recognion Terminal User Manual
71
Note
By default, if set as 0 min, the valid check out me ends at 23:59:59.
Note
●
The unit is min.
●
The available me is from 0 to 1440 min.
Manage Shi via Mobile Web Browser
You can set the normal shi and man-hour shi. Normal shi can be applied in aendance
scenarios of regular aendance, and you can set the aendance rules and the aendance number.
Man-hour shi can be applied in the aendance scenarios of exible working system.
Manage Shi via Mobile Web Browser
You can edit and add shi aendance informaon, including shi name and aendance duraon.
Steps
1.
Set aendance rules.
1) Tap
→ Time and Aendance → Shi Management .
2.
Set shi.
1) Tap a normal shi to enter the sengs page.
2) Set the Shi Name, On-Work Time, and O-Work Time.
Note
●
If the aendance rules conict with the normal shi duraons, the device will prompt
"Duraon error". Please delete all duraons and recongure the sengs aer exing.
●
The shi name supports Chinese, uppercase English, lowercase English, numbers and
symbols.
●
Up to 32 characters can be entered in shi name.
3) You can enable Set Overme, and set the start me and end me.
3.
Tap Save.
Manage Shi Schedule via Mobile Web Browser
You can combine the shi and holiday according to your actual needs. Shi schedule by
department and shi schedule by individual are supported.
DS-K1T320 Series Face Recognion Terminal User Manual
72
Manage Shi Schedule by Department via Mobile Web Browser
All persons in the department use the same shi schedule to take aendance.
Before You Start
●
Edit the department. You can refer to Manage Department via Mobile Web Browser for details.
●
Set the shi. You can refer to Manage Shi via Mobile Web Browser for details.
Steps
1.
Tap → Time and Aendance → Schedule to enter the Shi Schedule page.
2.
Tap Add Schedule.
3.
Set Schedule Name.
4.
Select the Department. For details, see User Management .
5.
Tap Next to set Week and Shi according to your actual needs. You can also click Add Rule to
add new rules.
6.
Tap Complete.
Shi Schedule by Person
Take aendance according to individual's condions.
Before You Start
●
Edit person. For details, see User Management .
●
Set the shi. You can refer to Manage Shi via Mobile Web Browser for details.
Steps
1.
Tap → Time and Aendance → Schedule to enter the Shi Schedule page.
2.
Tap Add Schedule.
3.
Set Schedule Name.
4.
Select the Person. For details, see User Management .
5.
Tap Next to set Week and Shi according to your actual needs. You can also click Add Rule to
add new rules.
6.
Tap Complete.
View Aendance Stascs
You can view Aendance Stascs by day or month.
You can view aendance stascs by the following ways.
1. Tap Aendance Stascs.
2. Tap
→ Aendance Stascs .
You can tap Day or Month to view aendance stascs.
DS-K1T320 Series Face Recognion Terminal User Manual
73
8.4.11 Set Privacy Parameters
Set the display sengs, picture upload and storage parameters.
Tap → Conguraon → Security → Privacy Sengs .
Authencaon Sengs
Picture Display/Name Display/Employee ID
You can tap to enable Picture, Name, or Employee ID to display. When authencaon is
completed, the system will display the selected contents in the result.
Name De-idencaon
The name informaon is desensized with an asterisk.
Picture Uploading and Storage
You can upload and store pictures.
Save Registered Picture
The registered face picture will be saved to the system if you enable the funcon.
Save Picture When Auth.
If you enable this funcon, you can save the picture when authencang to the device.
Upload Captured Picture When Auth.
Upload the pictures captured when authencang to the plaorm automacally.
Save Pictures Aer Linked Capture
If you enable this funcon, you can save the picture captured by linked camera to the device.
Upload Picture Aer Linked Capture
Upload the pictures captured by linked camera to the plaorm automacally.
8.4.12 Password Mode
Before conguring passwords, it is necessary to clarify whether the password is a device-set
personal PIN or a plaorm-applied personal PIN. If it is a device-set personal PIN, it can be created
or edited on the device or on the web, and cannot be set on other plaorms; If it is a plaorm-
applied personal PIN, it can be created or edited on the plaorm, and issued to the device before it
can be used. It cannot be set on the device or on the web.
Steps
1.
Tap
→ Conguraon → Security → Password Mode
Device-Set Personal PIN
It can be created or edited on the device or on the web, and cannot be set on other
plaorms.
DS-K1T320 Series Face Recognion Terminal User Manual
74
Plaorm-Applied Personal PIN
It can be created or edited on the plaorm, and issued to the device before it can be used. It
cannot be set on the device or on the web.
2.
Tap Save.
8.4.13 Upgrade and Maintenance
Restart device, restore device parameters, and upgrade device version.
Restart Device
Tap → Restart Device .
Tap Restart to restart the device.
Upgrade
Tap → Upgrade .
Tap Upgrade to upgrade the device.
Note
Do not power o during the upgrading.
Restore Parameters
Tap → Default .
Restore to Default Sengs
The device will restore to the default sengs, except for the device IP address and the user
informaon.
Restore to Factory Sengs
All parameters will be restored to the factory sengs. You should acvate the device before
usage.
8.4.14 View Online Document
Tap → View Online Document . Tap View Online Document, you can scan the QR code with
your mobile phone for details.
8.4.15 View Open Source Soware License
Tap Conguraon → System → System Sengs → About , and tap View Licenses to view the
device license.
DS-K1T320 Series Face Recognion Terminal User Manual
75
Chapter 9 Quick Operaon via Web Browser
9.1 Select Language
You can select a language for the device system.
Click in the top right of the web page to enter the Device Language Sengs page. You can
select a language for the device system from the drop-down list.
By default, the system language is English.
Note
Aer you change the system language, the device will reboot automacally.
9.2 Time Sengs
Click in the top right of the web page to enter the wizard page. Aer seng device language,
you can click Next to enter the Time Sengs page.
Time Zone
Select the device located me zone from the drop-down list.
Time Sync.
NTP
You should set the NTP server's IP address, port No., and interval.
Manual
By default, the device me should be synchronized manually. You can set the device me
manually or check Sync. with Computer Time to synchronize the device me with the
computer's me.
Server Address/NTP Port/Interval
You can set the server address, NTP port, and interval.
DST
You can view the DST start me, end me and bias me.
Click Next to save the sengs and go to the next parameter. Or click Skip to skip me sengs.
9.3 Privacy Sengs
Set the picture uploading and storage parameters.
Click in the top right of the web page to enter the wizard page.
DS-K1T320 Series Face Recognion Terminal User Manual
76
Picture Uploading and Storage
Save Picture When Authencang
Save picture when authencang automacally.
Upload Picture When Authencang
Upload the pictures when authencang to the plaorm automacally.
Save Registered Picture
The registered face picture will be saved to the system if you enable the funcon.
Upload Picture Aer Linked Capture
Upload the pictures captured by linked camera to the plaorm automacally.
Save Pictures Aer Linked Capture
If you enable this funcon, you can save the picture captured by linked camera to the device.
Click Next to save the sengs and go to the next parameter. Or click Skip to skip privacy sengs.
9.4 Administrator Sengs
Steps
1.
Click in the top right of the web page to enter the wizard page.
2.
Enter the employee ID and name of the administrator.
3.
Select a credenal to add.
Note
You should select at least one credenal.
1) Click Add Face to upload a face picture from local storage.
Note
The uploaded picture should be within 200 K, in JPG、JPEG、PNG format.
2) Click Add Card to enter the Card No. and select the property of the card.
Note
Up to 5 cards can be supported.
3) Click Add Fingerprint to add ngerprints.
Note
Up to 10 ngerprints are allowed.
Click Complete to complete the sengs.
DS-K1T320 Series Face Recognion Terminal User Manual
77
9.5 No. and System Network
Steps
1.
Click in the top right of the web page to enter the wizard page. Aer previous sengs, you
can click Next to enter the No. and System Network sengs page.
2.
Set the device type.
If set the device type as Door Staon or Access Control Device, you can set the oor No., door
staon No., and click More to set Community No., Building No., and Unit No.
If set the device type as Outer Door Staon, you can set outer door staon No., and community
No.
3.
Click Complete to save the sengs aer the conguraon.
Device Type
The device can be used as a door staon or outer door staon. Select a device type from the
drop-down list.
Floor No.
Set the device installed oor No.
Door Staon No.
Set the device installed oor No.
Note
The main door staon No. is 0, and the sub door staon No. ranges from 1 to 16.
Community No.
Set the device community No.
Building No.
Set the device building No.
Unit No.
Set the device unit No.
DS-K1T320 Series Face Recognion Terminal User Manual
78
Chapter 10 Operaon via Web Browser
10.1 Login
You can login via the web browser.
Note
Make sure the device is acvated. For detailed informaon about acvaon, see Acvaon .
Login via Web Browser
Enter the device IP address in the address bar of the web browser and press Enter to enter the
login page.
Enter the device user name and the password. Click Login.
10.2 Forget Password
If you forget the password when logging in, you can change the password by email address or
security quesons.
On the login page, click Forget Password.
Select Vericaon Mode.
Security Queson Vericaon
Answer the security quesons.
E-mail Vericaon
1. Export the QR code and send it to pw_rec[email protected] as aachment.
2. You will receive a vericaon code within 5 minutes in your reserved email.
3. Enter the vericaon code into the vericaon code eld to verify your idencaon.
Click Next, create a new password and conrm it.
10.3 Live View
You can view the live video of the device, real-me event, person informaon, network status,
basic informaon, and device capacity.
DS-K1T320 Series Face Recognion Terminal User Manual
79
Figure 10-1 Live View Page
Funcon Descripons:
Door Status
Click to view the device live view.
Set the volume when starng live view.
Note
If you adjust the volume when starng two-way audio, you may hear a repeated sounds.
You can capture image when starng live view.
Select the streaming type when starng live view.
Full screen view.
/ / /
The door status is open/closed/remaining open/remaining closed.
Controlled Status
You can select open/closed/remaining open/remaining closed status according to your actual
needs.
Real-Time Event
DS-K1T320 Series Face Recognion Terminal User Manual
80
You can view the event Employee ID, Name, Card No., Event Type, Time, and Operaon. You can
also click View More to enter the search condions, including the event type, employee ID, the
name, the card No., the start me, and the end me, and click Search. The results will be
displayed on the right panel.
Person Informaon
You can view the added and not added informaon of person face, card, and ngerprint.
Network Status
You can view the connected and registered status of wired network, wireless network, ISUP and
Hik-Connect.
Basic Informaon
You can view the model, serial No. and rmware version.
Device Capacity
You can view the person, face, card, ngerprint and event capacity.
10.4 Person Management
Click Add to add the person's informaon, including the basic informaon, cercate,
authencaon and sengs.
Add Basic Informaon
Click Person Management → Add to enter the Add Person page.
Add the person's basic informaon, including the employee ID, the person's name, person type,
department, etc.
If you select Visitor as the person type, you can set the visit mes.
Click Save to save the sengs.
Set Permission Time
Click Person Management → Add to enter the Add Person page.
Enable Long-Term Eecve User, or set Start Time and End Time and the person can only has the
permission within the congured me period according to your actual needs.
Click Save to save the sengs.
Authencaon Sengs
Click Person Management → Add to enter the Add Person page.
Set the authencaon type.
Click Save to save the sengs.
Add Card
Click Person Management → Add to enter the Add Person page.
Click Add Card, enter the Card No. and select the Property, and click OK to add the card.
Click Save to save the sengs.
DS-K1T320 Series Face Recognion Terminal User Manual
81
Add Face Picture
Click Person Management → Add to enter the Add Person page.
Click + Upload to upload a face picture from the local PC.
Note
The picture format should be JPG or JPEG or PNG, and the size should be less than 200 kb.
Click Save to save the sengs.
Add Password
Before conguring passwords, it is necessary to clarify whether the password is a device-set
personal PIN or a plaorm-applied personal PIN. If it is a device-set personal PIN, it can be created
or edited on the device or on the web, and cannot be set on other plaorms; If it is a plaorm-
applied personal PIN, it can be created or edited on the plaorm, and issued to the device before it
can be used. It cannot be set on the device or on the web.
Click Conguraon → Security → Password Mode , select Password Mode as Device-Set Personal
PIN.
Click Person Management → Add to enter the Add Person page.
Set the password.
Click Save to save the sengs.
10.5 Search Event
Click Event Search to enter the Search page.
Figure 10-2 Search Event
Enter the search condions, including the event type, the employee ID, the name, the card No., the
start me, and the end me, and click Search.
The results will be displayed on the right panel.
DS-K1T320 Series Face Recognion Terminal User Manual
82
10.6 Conguraon
10.6.1 Set Local Parameters
Set the live view parameters, picture and clip sengs.
Set Live View Parameters
Click Conguraon → Local to enter the Local page. Congure the stream type, the play
performance, auto start Live View and click Save.
Record File Sengs
Click Conguraon → Local to enter the Local page. Select a record le size and select a saving
path from your local computer and click Save.
You can also click Open to open the le folder to view details.
Picture and Clip Sengs
Click Conguraon → Local to enter the Local page. Select image format, saving path and click
Save.
You can also click Open to open the le folder to view details.
10.6.2 View Device Informaon
View the device name, language, model, serial No., version, number of channels, IO input, IO
output, lock, alarm input, alarm output, and device capacity, etc.
Click Conguraon → System → System Sengs → Basic Informaon to enter the conguraon
page.
You can view the device name, language, model, serial No., version, number of channels, IO input,
IO output, lock, alarm input, alarm output, and device capacity, etc.
10.6.3 Set Time
Set the device's me, me zone, synchronizaon mode, server address, NTP port, and interval.
Click Conguraon → System → System Sengs → Time Sengs .
Click Save to save the sengs aer the conguraon.
Time Zone
Select the device located me zone from the drop-down list.
Time Sync.
NTP
DS-K1T320 Series Face Recognion Terminal User Manual
83
You should set the NTP server's IP address, port No., and interval.
Manual
By default, the device me should be synchronized manually. You can set the device me
manually or check Sync. with Computer Time to synchronize the device me with the
computer's me.
Server Address Type/Server Address/NTP Port/Interval
You can set the server address type, server address, NTP port, and interval.
10.6.4 Set DST
Steps
1.
Click Conguraon → System → System Sengs → Time Sengs .
Figure 10-3 DST Page
2.
Enable DST.
3.
Set the DST start me, end me and bias me.
4.
Click Save to save the sengs.
10.6.5 Change Administrator's Password
Steps
1.
Click Conguraon → System → User Management .
2.
Click .
3.
Enter the old password and create a new password.
4.
Conrm the new password.
5.
Click Save.
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
DS-K1T320 Series Face Recognion Terminal User Manual
84
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
10.6.6 Account Security Sengs
You can change the security quesons and answers, or the email address for the device. Aer
change the sengs, once you forgot the device password, you should answer the new quesons or
use the new email address to reset the device password.
Steps
1.
Click Conguraon → System → User Management → Account Security Sengs .
2.
Change the security quesons or email address according your actual needs.
3.
Enter the device password and click OK to conrm changing.
10.6.7 View Device Arming/Disarming Informaon
View device arming type and arming IP address.
Click Conguraon → System → User Management → Arming/Disarming Informaon .
You can view the device arming/disarming informaon. Click Refresh to refresh the page.
10.6.8 Network Sengs
Set TCP/IP, port, Wi-Fi parameters, ISUP, and plaorm access.
Note
Some device models do not support Wi-Fi or mobile data sengs. Refer to the actual products
when conguraon.
Set Basic Network Parameters
Click Conguraon → Network → Network Sengs → TCP/IP .
DS-K1T320 Series Face Recognion Terminal User Manual
85
Figure 10-4 TCP/IP Sengs Page
Set the parameters and click Save to save the sengs.
NIC Type
Select a NIC type from the drop-down list. By default, it is Auto.
DHCP
If uncheck the funcon, you should set the IPv4 address, IPv4 subnet mask, IPv4 default
gateway, Mac address, and MTU.
If you check the funcon, the system will allocate the IPv4 address, IPv4 subnet mask, the IPv4
default gateway automacally.
DNS Server
Set the preferred DNS server and the Alternate DNS server according to your actual need.
Set Wi-Fi Parameters
Set the Wi-Fi parameters for device wireless connecon.
Steps
Note
The funcon should be supported by the device.
1.
Click Conguraon → Network → Network Sengs → Wi-Fi .
DS-K1T320 Series Face Recognion Terminal User Manual
86
Figure 10-5 Wi-Fi Sengs Page
2.
Check Wi-Fi.
3.
Select a Wi-Fi
-
Click Connect of a Wi-Fi in the list and enter the Wi-Fi password.
-
Click Manual Add and enter a Wi-Fi's SSID, working mode, security mode, and password. Click
OK.
4.
Set the WLAN parameters.
1) Set the IP address, subnet mask, and default gateway. Or enable DHCP and the system will
allocate the IP address, subnet mask, and default gateway automacally.
5.
Set the DNS server. Set the preferred DNS server and alternate DNS server. Or enable DHCP and
the system will allocate the preferred DNS server and alternate DNS server automacally.
6.
Click Save.
Set Device Hotspot
Set the device hotspot, and mobile phone can connect to the device to enter the mobile browser.
Steps
1.
Click Conguraon → Network → Network Sengs → Device Hotspot .
2.
You can enable device hotspot, and click Save.
Set Port Parameters
Set the HTTP, HTTPS, HTTP Listening, RTSP and Server port parameters.
Click Conguraon → Network → Network Service → HTTP(S) .
DS-K1T320 Series Face Recognion Terminal User Manual
87
HTTP
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.0.0.65:81 in the browser for login.
HTTPS
Set the HTTPS for accessing the browser. Cercate is required when accessing.
HTTP Listening
The device can send alarm informaon to the event alarm IP address or domain name via HTTP
protocol/HTTPS protocol. Edit the event alarm IP address or domain name, URL, port, and
protocol.
Note
The event alarm IP address or domain name should support the HTTP protocol/HTTPS protocol
to receive the alarm informaon.
Click Conguraon → Network → Network Service → RTSP .
RTSP
It refers to the port of real-me streaming protocol.
Click Conguraon → Network → Device Access → SDK Server .
SDK Server
It refers to the port through which the client adds the device.
Plaorm Access
Plaorm access provides you an opon to manage the devices via plaorm.
Steps
1.
Click Conguraon → Network → Device Access → Hik-Connect to enter the sengs page.
Note
Hik-Connect is an applicaon for mobile devices. With the App, you can view live image of the
device, receive alarm nocaon and so on.
2.
Check Enable to enable the funcon.
3.
Oponal: Check the checkbox of Custom, and you can set the server address by yourself.
4.
Enter the server IP address, and vericaon code.
Note
6 to 12 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are recommended to use a
combinaon of no less than 8 leers or numbers.
5.
Enable Video Encrypon, and create the password and conrm it.
DS-K1T320 Series Face Recognion Terminal User Manual
88
Note
Aer adding the device to APP, you need to enter the video encrypon password to live view the
device.
6.
Oponal: Click View to view the device QR code. Scan the QR code to account.
Note
Scan the QR code before it loses ecacy.
7.
Oponal: Click More to set the network connecon priority.
1) Enable WLAN or Wired Network according to your actual needs.
1) Hold and drag to adjust the access priority.
8.
Click Save to enable the sengs.
Set ISUP Parameters
Set the ISUP parameters for accessing device via ISUP protocol.
Steps
Note
The funcon should be supported by the device.
1.
Click Conguraon → Network → Device Access → ISUP .
2.
Check Enable.
3.
Set the ISUP version, server address, device ID, and the ISUP status.
Note
If you select 5.0 as the version, you should set the Encrypon Key.
4.
Set the Network Connecon Priority. You can enable Allow Access, and click the network and
drag it to adjust the network priority.
5.
Set the ISUP listening parameters, including ISUP alarm center IP address/domain name, ISUP
alarm center URL, and ISUP alarm center port.
6.
Click Save.
10.6.9 Set Video Parameters
Set the image quality, and resoluon.
Set Video Parameters
Click Conguraon → Video/Audio → Video .
Set the camera name, stream type, the video type, the bitrate type, the frame rate, the Max.
bitrate, the video encoding, and I Frame Interval.
Click Save to save the sengs.
DS-K1T320 Series Face Recognion Terminal User Manual
89
Note
The funcons vary according to dierent models. Refers to the actual device for details.
10.6.10 Set Image Parameters
You can adjust the image parameters, video parameters, supplement parameters and capture
interval.
Steps
1.
Click Conguraon → Image .
2.
Congure the parameters to adjust the image.
Video Adjust(Video Standard)
Set the video frame rate when performing live view remotely. Aer changing the standard,
you should reboot the device to take eect.
PAL
25 frames per second. Suitable for mainland China, Hong Kong (China), the Middle East
countries, Europe countries, etc.
NTSC
30 frames per second. Suitable for the USA, Canada, Japan, Taiwan (China), Korea, the
Philippines, etc.
Image Adjustment
Drag the block or enter the value to adjust the live video's brightness and contrast.
Supplement Light Parameters
Set the supplement light type, mode, start me and end me. You can also set the
brightness.
Capture Interval
You can select the capture interval according to your actual needs.
3.
Click Default to restore the parameters to the default sengs.
10.6.11 Access Control Sengs
Set Authencaon Parameters
Click Conguraon → Access Control → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
DS-K1T320 Series Face Recognion Terminal User Manual
90
Click Save to save the sengs aer the conguraon.
Terminal Type/Terminal Model
Select terminal and get the terminal descripon. They are read-only.
Enable Authencaon Device
Enable the authencaon funcon.
Authencaon
Select an authencaon mode according to your actual needs from the drop-down list.
Recognion Interval
You can set the interval between 2 connuous recognion of a same person during the
authencaon. In the congured interval, Person A can only recognized once. If another person
(Person B) has recognized during the interval, Person A can recognized again.
Authencaon Interval
You can set the authencaon interval of the same person when authencang. The same
person can only authencate once in the congured interval. A second authencaon will be
failed.
Alarm of Max. Failed Aempts
Enable to report alarm when the card reading aempts reach the set value.
Tampering Detecon
Enable the an-tamper detecon for the card reader.
Card No. Reversing
The read card No. will be in reverse sequence aer enabling the funcon.
Set Door Parameters
Click Conguraon → Access Control → Door Parameters .
DS-K1T320 Series Face Recognion Terminal User Manual
91
Figure 10-7 Door Parameters Sengs Page
Click Save to save the sengs aer the conguraon.
Door No.
Select the device corresponded door No.
Name
You can create a name for the door.
Open Duraon
Set the door unlocking duraon. If the door is not opened for the set me, the door will be
locked.
Door Open Timeout Alarm
An alarm will be triggered if the door has not been closed within the congured me duraon.
Door Contact
You can set the door contact as Remain Open or Remain Closed according to your actual needs.
By default, it is Remain Closed.
Exit Buon Type
You can set the exit buon as Remain Open or Remain Closed according to your actual needs.
By default, it is Remain Open.
Door Lock Powering O Status
You can set the door lock status when the door lock is powering o. By default, it is Remain
Closed.
Extended Open Duraon
DS-K1T320 Series Face Recognion Terminal User Manual
92
The door contact can be enabled with appropriate delay aer person with extended access
needs swipes her/his card.
Door Remain Open Duraon with First Person
Set the door open duraon when rst person is in. Aer the rst person is authorized, it allows
mulple persons access the door or other authencaon acons.
Duress Code
The door can open by inpung the duress code when there is duress. At the same me, the
client can report the duress event.
Super Password
The specic person can open the door by inpung the super password.
Note
The duress code and the super code should be dierent.
Set Terminal Parameters
You can set terminal parameters for accessing.
Click Conguraon → Access Control → Terminal Parameters .
You can set Working Mode as Access Control Mode. The access control mode is the device normal
mode. You should authencate your credenal for accessing.
Click Save to save the sengs aer the conguraon.
10.6.12 Card Sengs
Set Card Security
Click Conguraon → Card Sengs → Card Type to enter the sengs page.
Set the parameters and click Save.
Enable NFC Card
In order to prevent the mobile phone from geng the data of the access control, you can
enable NFC card to increase the security level of the data.
Enable M1 Card
Enable M1 card and authencang by presenng M1 card is available.
M1 Card Encrypon
Sector
M1 card encrypon can improve the security level of authencaon.
DS-K1T320 Series Face Recognion Terminal User Manual
93
Enable the funcon and set the encrypon sector. By default, Sector 13 is encrypted. It is
recommended to encrypt sector 13.
Enable CPU Card
Enable CPU card and authencang by presenng CPU card is available.
Set Card No. Authencaon Parameters
Set the card reading content when authencate via card on the device.
Go to Conguraon → Card Sengs → Card No. Authencaon Sengs .
Select a card authencaon mode and click Save.
Full Card No.
All card No. will be read.
Wiegand 26 (3 bytes)
The device will read card via Wiegand 26 protocol (read 3 bytes).
Wiegand 34 (4 bytes)
The device will read card via Wiegand 34 protocol (read 4 bytes).
10.6.13 Time and Aendance Sengs
If you want to record the person's working hour, late arrivals, early departures, breaks,
absenteeism, etc., you can add the person to the shi group and assign a shi schedule (a rule for
the aendance dening how the schedule repeats, the shi type, break sengs, and the card
swiping rule.) to the shi group to dene the aendance parameters for the persons in the shi
group.
Disable Aendance Mode via Web
Disable the aendance mode and the system will not display the aendance status on the inial
page.
Steps
1.
Click Conguraon → Plaorm Aendance to enter the sengs page.
2.
Disable the Time and Aendance.
Result
You will not view or congure the aendance status on the inial page. And the system will follow
the aendance rule that congured on the plaorm.
DS-K1T320 Series Face Recognion Terminal User Manual
94
Time Sengs
Steps
1.
Click Conguraon → Plaorm Aendance to enter the sengs page.
2.
Select Schedule Template.
3.
Drag mouse to set the schedule.
Note
Set the schedule from Monday to Sunday according to the actual needs.
4.
You can enable On/o Work, Break, Overme according to your actual needs and set the
custom name.
5.
Oponal: Select a meline and click Delete. Or click Delete All to clear the sengs.
6.
Click Save.
Set Manual Aendance via Web
Set the aendance mode as manual, and you should select a status manually when you take
aendance.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Click Conguraon → Plaorm Aendance to enter the sengs page.
2.
Set the Aendance Mode as Manual.
3.
Enable the Aendance Status Required and set the aendance status lasts duraon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
Result
You should select an aendance status manually aer authencaon.
Note
If you do not select a status, the authencaon will be failed and it will not be marked as a valid
aendance.
DS-K1T320 Series Face Recognion Terminal User Manual
95
Set Auto Aendance via Web
Set the aendance mode as auto, and you can set the aendance status and its available schedule.
The system will automacally change the aendance status according to the congured schedule.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Click Conguraon → Plaorm Aendance to enter the sengs page.
2.
Set the Aendance Mode as Auto.
3.
Enable the Aendance Status Required funcon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
6.
Set the status' schedule. Refers to Time Sengs for details.
Set Manual and Auto Aendance via Web
Set the aendance mode as Manual and Auto, and the system will automacally change the
aendance status according to the congured schedule. At the same me you can manually
change the aendance status aer the authencaon.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Click Conguraon → Plaorm Aendance to enter the sengs page.
2.
Set the Aendance Mode as Manual and Auto.
3.
Enable the Aendance Status Required funcon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
6.
Set the status' schedule. Refers to Time Sengs for details.
Result
On the inial page and authencate. The authencaon will be marked as the congured
aendance status according to the schedule. If you tap the edit icon on the result tab, you can
select a status to take aendance manually, the authencaon will be marked as the edited
aendance status.
DS-K1T320 Series Face Recognion Terminal User Manual
96
Example
If set the Break Out as Monday 11:00, and Break In as Monday 12:00, the valid user's
authencaon from Monday 11:00 to 12:00 will be marked as break.
10.6.14 Local Time and Aendance Sengs
Manage Department via Web
You can add, edit and delete department informaon via Web.
Steps
1.
Click Person Management.
2.
Click Add Department to add department.
1) Enter Department Name.
2) Click OK to save the sengs.
3.
Oponal: Manage department informaon.
Edit Department Informaon Click
to edit department informaon.
Delete Department Informaon Click
to delete department informaon.
Enable Local T&A
You can enable Local T&A, and set aendance rules, shi and schedule.
Steps
1.
Click Conguraon → Aendance → Basic Informaon .
2.
Enable Local T&A.
Set Aendance Rule for Shi
Set aendance rule before seng shi.
Click Time and Aendance → Schedule → Aendance Rule to enter the Shi Schedule page.
Set the aendance rule, including Mark as Later if Checks in Late For and Mark as Early Leave if
Checks out Early For. Aer entering the duraon, click Save to save the sengs.
Take the following picture as an example to describe the rules.
DS-K1T320 Series Face Recognion Terminal User Manual
97
Figure 10-8 Aendance Rule Example
Mark as Early Leave if Checks out Early For
Set the Mark as Early Leave if Checks out Early For me. For example, set the o work me as
17:30 and set the parameter as 10 min, the earliest check out me will be 17:20. Checking out
at or earlier than 17:19 will be marked as invalid.
Mark as Later if Checks in Late For
Set the Mark as Later if Checks in Late For me. For example, set the o work me as 17:30 and
set the parameter as 30 min, the latest check out me will be 18:00. Checking out at or later
than 18:01 will be marked as invalid.
Note
By default, if set as 0 min, the valid check out me ends at 23:59:59.
Note
●
The unit is min.
●
The available me is from 0 to 1440 min.
Manage Shi
Manage Normal Shi via Web
You can set xed on-work and o-work me of person for aendance check.
Steps
1.
Click Conguraon → Time and Aendance → Schedule → Shi Management .
2.
Click a shi to edit informaon.
1) Enter the shi name.
2) Select Normal Shi.
3) Set the me and aendance duraon.
4) Oponal: Enable Overme, and set the start me and end me of overme.
3.
Click Save.
DS-K1T320 Series Face Recognion Terminal User Manual
98
Manage Flexible Shi via Web
You can set xed work duraon and exible on-work and o-work me of person for aendance
check..
Steps
1.
Click Conguraon → Time and Aendance → Schedule → Shi Management .
2.
Click a shi to edit informaon.
1) Enter the shi name.
2) Select Flexible Shi.
3) Set the Work Duraon and Latest On-Work Time.
4) You can enable Break, and set Break Duraon.
3.
Click Save.
Manage Schedule
Shi Schedule by Department
All persons in the department use the same shi schedule to take aendance.
Before You Start
●
Edit department. For details, see Manage Department via Web .
●
Set shi. For details, see Manage Normal Shi via Web and Manage Flexible Shi via Web .
Steps
1.
Click Time and Aendance → Schedule to enter the Shi Schedule by Department page.
2.
Click Add Schedule.
3.
Set Schedule Name.
4.
Click Add to select the Department/Person, and select a department. For details, see Manage
Department via Web .
5.
Click Next to set Week and Shi according to your actual needs. You can also click Add Rule to
add new rules.
6.
Click Complete.
Shi Schedule by Person
Take aendance according to individual's condions.
Before You Start
●
Edit person. For details, see
Person Management .
●
Set shi. For details, see Manage Normal Shi via Web and Manage Flexible Shi via Web .
DS-K1T320 Series Face Recognion Terminal User Manual
99
Steps
1.
Click Time and Aendance → Schedule to enter the Shi Schedule page.
2.
Click Add Schedule.
3.
Set Schedule Name.
4.
Click Add to select the Department/Person, and select the person. For details, see Person
Management .
5.
Click Next to set Week and Shi according to your actual needs. You can also click Add Rule to
add new rules.
6.
Click Complete.
View Aendance Report
View Aendance Stascs Informaon
You can view aendance stascs informaon
Note
You need to enable Local T&A. For details, see Enable Local T&A .
Click Aendance Report → Aendance Stascs , and you can view aendance stascs
informaon.
Export Aendance Report
Enter a short descripon of your concept here (oponal).
Click Aendance Report → Aendance Report , select the report, and you can view the
Aendance Report and click Export Excel to export it.
10.6.15 Set Privacy Parameters
Set the event storage type, picture upload and storage parameters, and the picture clearing
parameters.
Go to Conguraon → Security → Privacy Sengs
Event Storage Sengs
Select a method to delete the event. You can select from Delete Old Events Periodically, Delete
Old Events by Specied Time, or Overwring.
Delete Old Events Periodically
DS-K1T320 Series Face Recognion Terminal User Manual
100
Drag the block or enter number to set the period for event deleng. All events will be deleted
according to the congured me duraon.
Delete Old Events by Specied Time
Set a me and all events will be deleted on the congured me.
Overwring
The earliest 5% events will be deleted when the system detects the stored events has been over
95% of the full space.
Authencaon Sengs
Display Authencaon Result
You can check Face Picture, Name, and Employee ID, to display the authencaon result.
Name De-idencaon
You can check Name De-idencaon, and the whole name will not be displayed.
Authencaon Result Display Duraon
You can set the authencaon result display duraon.
Picture Uploading and Storage
Save Picture When Authencang
Save picture when authencang automacally.
Save Registered Picture
The registered face picture will be saved to the system if you enable the funcon.
Save Pictures Aer Linked Capture
If you enable this funcon, you can save the picture captured by linked camera to the device.
Clear All Pictures in Device
Note
All pictures cannot be restored once they are deleted.
Clear Registered Face Pictures
All registered pictures in the device will be deleted.
Clear Captured Pictures
All captured pictures in the device will be deleted.
10.6.16 Set Password Mode
Before conguring passwords, it is necessary to clarify whether the password is a device-set
personal PIN or a plaorm-applied personal PIN. If it is a device-set personal PIN, it can be created
DS-K1T320 Series Face Recognion Terminal User Manual
101
or edited on the device or on the web, and cannot be set on other plaorms; If it is a plaorm-
applied personal PIN, it can be created or edited on the plaorm, and issued to the device before it
can be used. It cannot be set on the device or on the web.
Steps
1.
Click Conguraon → Security → Password Mode
Device-Set Personal PIN
It can be created or edited on the device or on the web, and cannot be set on other
plaorms.
Plaorm-Applied Personal PIN
It can be created or edited on the plaorm, and issued to the device before it can be used. It
cannot be set on the device or on the web.
2.
Click Save.
10.6.17 Set Biometric Parameters
Set Basic Parameters
Click Conguraon → Smart → Smart .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
Click Save to save the sengs aer the conguraon.
Face An-spoong
Enable or disable the live face detecon funcon. If enabling the funcon, the device can
recognize whether the person is a live one or not.
Note
Biometric recognion products are not completely applicable to an-spoong environments. If
you require a higher security level, use mulple authencaon modes.
Live Face Detecon Security Level
Aer enabling the face an-spoong funcon, you can set the matching security level when
performing live face authencaon.
Recognion Distance
Select the distance between the authencang user and the device camera.
Pitch Angle
The maximum pitch angle when starng face authencaon.
Yaw Angle
The maximum yaw angle when starng face authencaon.
DS-K1T320 Series Face Recognion Terminal User Manual
102
1:1 Matching Threshold
Set the matching threshold when authencang via 1:1 matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate.
1:N Matching Threshold
Set the matching threshold when authencang via 1:N matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate.
Face Recognion Timeout Value
Set the meout value when face recognizing. If the face recognion me is longer than the
congured value, the system will pop up a prompt.
Face without Mask Detecon
Aer enabling the face without mask detecon, the system will recognize the captured face
with mask picture or not. You can set face with mask1:N matching threshold, it's ECO mode, and
the strategy.
None
The funcon is disabled. The device will not detect whether a person is wearing a face mask
or not.
Reminder of Wearing Face Mask
If the person do not wear the face mask when authencang, the device will pop up a
prompt and the door will open.
Must Wear Face Mask
If the person do not wear the face mask when authencang, the device will pop up a
prompt and the door will keep closed.
Face with Mask & Face (1:1)
Set the matching value when authencang with face mask via 1:1 matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate.
Face with Mask 1:N Matching Threshold
Set the matching threshold when authencang with face mask via 1:N matching mode. The
larger the value, the smaller the false accept rate and the larger the false rejecon rate.
Fingerprint Security Level
Select the ngerprint security level.
The higher is the security level, the lower is the false acceptance rate (FAR).
The higher is the security level, the higher is the false rejecon rate (FRR).
Set Recognion Area
Click Conguraon → Smart → Area Conguraon .
Drag the yellow frame in the live video to adjust the recognion area. Only the face within the area
can be recognized by the system.
Click Save to save the sengs.
DS-K1T320 Series Face Recognion Terminal User Manual
103
Click or to record videos or capture pictures.
10.6.18 Set Preference
You can set the display theme and the sleep me for the device.
Set Theme
Click Conguraon → Preference → Screen Display .
Sleep
Enable Sleep and the device will enter the sleep mode when no operaon within the congured
sleep me.
Display Mode
You can select display theme for device authencaon. You can select Display Mode as
Authencaon or Simple. When you select Simple, the informaon of name, ID, face picture
will be not displayed.
10.6.19 Upgrade and Maintenance
Reboot device, restore device parameters, and upgrade device version.
Reboot Device
Click Maintenance and Security → Maintenance → Restart .
Click Restart to reboot the device.
Upgrade
Click Maintenance and Security → Maintenance → Upgrade .
Select an upgrade type from the drop-down list. Click and select the upgrade le from your
local PC. Click Upgrade to start upgrading.
If the device has been connected to Hik-Connect and network, when there is a new installaon
package in Hik-Connect, you can click Upgrade aer Online Update to upgrade the device system.
Note
Do not power o during the upgrading.
Restore Parameters
Click Maintenance and Security → Maintenance → Backup and Reset .
Restore All
All parameters will be restored to the factory sengs. You should acvate the device before
usage.
Restore
DS-K1T320 Series Face Recognion Terminal User Manual
104
The device will restore to the default sengs, except for the device IP address and the user
informaon.
Import and Export Parameters
Click Maintenance and Security → Maintenance → Backup and Reset .
Export
Click Export to export the device parameters.
Note
You can import the exported device parameters to another device.
Import
Click and select the le to import. Click Import to start import conguraon le.
Click Advanced Sengs, and enter the admin password.
Face Parameter
Custom An-Spoong Detecon
Face Liveness Level
Aer enabling face an-spoong funcon, you can set the matching security level when
performing live face authencaon.
An-Spoong Detecon Threshold
The larger the value, the smaller the false accept rate and the larger the false rejecon
rate. The smaller the value, the larger the false accept rate and the smaller the false
rejecon rate.
Lock Face for An-Spoong Protecon
Aer enabling this funcon, the device will lock automacally when an-spoong detecon
failed.
Lock Duraon
The lock duraon aer enabling Lock Face for An-Spoong Protecon when an-spoong
detecon failed.
Unlock
You can click Unlock according to your needs.
Version Informaon
You can view the device informaon.
10.6.20 Device Debugging
You can set device debugging parameters.
DS-K1T320 Series Face Recognion Terminal User Manual
105
Steps
1.
Click Maintenance and Security → Maintenance → Device Debugging .
2.
You can set the following parameters.
Enable SSH
To raise network security, disable SSH service. The conguraon is only used to debug the
device for the professionals.
Print Log
You can click Export to export log.
Capture Network Packet
You can set the Capture Packet Duraon, Capture Packet Size, and click Start to capture.
10.6.21 Log Query
You can search and view the device logs.
Go to Maintenance and Security → Maintenance → Log .
Set the major and minor type of the log type. Set the start me and end me for searching, and
click Search.
The results will be displayed below, which including the No., me, the major type the minor type,
the channel No., the local/remote user informaon, the remote host IP, etc.
10.6.22 Security Mode Sengs
Set the security mode for logging in the client soware.
On the Device for Management page, click Maintenance and Security → Security → Security
Service .
Select a security mode, and click Save.
Security Mode
High security level for user informaon vericaon when logging in the client soware.
Compable Mode
The user informaon vericaon is compable with the old client soware version when
logging in.
10.6.23 Cercate Management
It helps to manage the server/client cercates and CA cercate.
DS-K1T320 Series Face Recognion Terminal User Manual
106
Note
The funcon is only supported by certain device models.
Create and Install Self-signed Cercate
Steps
1.
Go to Maintenance and Security → Security → Cercate Management .
2.
In the Cercate Files area, select a Cercate Type from the drop-down list.
3.
Click Create.
4.
Input cercate informaon.
5.
Click OK to save and install the cercate.
The created cercate is displayed in the Cercate Details area.
The cercate will be saved automacally.
6.
Download the cercate and save it to an asking le in the local computer.
7.
Send the asking le to a cercaon authority for signature.
8.
Import the signed cercate.
1) Select a cercate type in the Import Passwords area, and select a cercate from the local,
and click Install.
2) Select a cercate type in the Import Communicaon Cercate area, and select a cercate
from the local, and click Install.
Install Other Authorized Cercate
If you already has an authorized cercate (not created by the device), you can import it to the
device directly.
Steps
1.
Go to Maintenance and Security → Security → Cercate Management .
2.
In the Import Passwords and Import Communicaon Cercate areas, select cercate type
and upload cercate.
3.
Click Install.
Install CA Cercate
Before You Start
Prepare a CA cercate in advance.
Steps
1.
Go to Maintenance and Security → Security → Cercate Management .
2.
Create an ID in the Import CA Cercate area.
DS-K1T320 Series Face Recognion Terminal User Manual
107
Note
The input cercate ID cannot be the same as the exisng ones.
3.
Upload a cercate le from the local.
4.
Click Install.
DS-K1T320 Series Face Recognion Terminal User Manual
108
Chapter 11 Other Plaorms to Congure
You can also congure the device via iVMS-4200 Client Soware or HikCentral Access Control. For
details, see the plaorms' user manual.
iVMS-4200 Client Soware
Click/tap the link to view the client soware's user manual.
hp://enpinfodata.hikvision.com/analysisQR/showQR/ca930247
HikCentral Access Control (HCAC)
Click/tap the link to view the HCAC's user manual.
hp://enpinfodata.hikvision.com/analysisQR/showQR/f2f6cf42
DS-K1T320 Series Face Recognion Terminal User Manual
109
Appendix A. Tips for Scanning Fingerprint
Recommended Finger
Forenger, middle nger or the third nger.
Correct Scanning
The gure displayed below is the correct way to scan your nger:
You should press your nger on the scanner horizontally. The center of your scanned nger should
align with the scanner center.
Incorrect Scanning
The gures of scanning ngerprint displayed below are incorrect:
DS-K1T320 Series Face Recognion Terminal User Manual
110
Environment
The scanner should avoid direct sun light, high temperature, humid condions and rain.
When it is dry, the scanner may not recognize your ngerprint successfully. You can blow your
nger and scan again.
Others
If your ngerprint is shallow, or it is hard to scan your ngerprint, we recommend you to use other
authencaon methods.
If you have injuries on the scanned nger, the scanner may not recognize. You can change another
nger and try again.
DS-K1T320 Series Face Recognion Terminal User Manual
111
Appendix B. Tips When Collecng/Comparing Face
The posion when collecng or comparing face picture is as below:
Posions (Recommended Distance: 0.5 m)
Expression
●
Keep your expression naturally when collecng or comparing face pictures, just like the
expression in the picture below.
●
Do not wear hat, sunglasses, or other accessories that can aect the facial recognion funcon.
●
Do not make your hair cover your eyes, ears, etc. and heavy makeup is not allowed.
Posture
In order to get a good quality and accurate face picture, posion your face looking at the camera
when collecng or comparing face pictures.
DS-K1T320 Series Face Recognion Terminal User Manual
112
Size
Make sure your face is in the middle of the collecng window.
DS-K1T320 Series Face Recognion Terminal User Manual
113
Appendix C. Tips for Installaon Environment
1. Light Source Illuminaon Reference Value
Candle: 10Lux
Bulb: 100~850Lux
Sunlight: More than 1200Lux
2. Avoid backlight, direct and indirect sunlight
DS-K1T320 Series Face Recognion Terminal User Manual
114
Appendix D. Dimension
Figure D-1 Dimension
DS-K1T320 Series Face Recognion Terminal User Manual
115
UD28901B-C
