aeg.com/register
HRX64360C
EN User Manual | Hob
aeg.com\register
Welcome to AEG! Thank you for choosing our appliance.
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Subject to change without notice.
CONTENTS
1. SAFETY INFORMATION................................................................................ 2
2. SAFETY INSTRUCTIONS.............................................................................. 4
3. INSTALLATION...............................................................................................6
4. PRODUCT DESCRIPTION............................................................................. 8
5. DAILY USE....................................................................................................10
6. HINTS AND TIPS.......................................................................................... 12
7. CARE AND CLEANING................................................................................ 13
8. TROUBLESHOOTING.................................................................................. 13
9. TECHNICAL DATA....................................................................................... 15
10. ENERGY EFFICIENCY...............................................................................15
11. ENVIRONMENTAL CONCERNS................................................................16
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved. Children of less than 8 years of age and
persons with very extensive and complex disabilities shall
be kept away from the appliance unless continuously
supervised.
• Children should be supervised to ensure that they do not
play with the appliance.
2 ENGLISH
• Keep all packaging away from children and dispose of it
appropriately.
• WARNING: The appliance and its accessible parts become
hot during use. Keep children and pets away from the
appliance when in use and when cooling down.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
1.2 General Safety
• This appliance is for cooking purposes only.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
• WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements.
• WARNING: Unattended cooking on a hob with fat or oil can
be dangerous and may result in fire.
• Smoke is an indication of overheating. Never use water to
extinguish the cooking fire. Switch off the appliance and
cover flames with e.g. a fire blanket or lid.
• WARNING: The appliance must not be supplied through an
external switching device, such as a timer, or connected to
a circuit that is regularly switched on and off by a utility.
• CAUTION: The cooking process has to be supervised. A
short term cooking process has to be supervised
continuously.
• WARNING: Danger of fire: Do not store items on the
cooking surfaces.
ENGLISH 3
• Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they can get
hot.
• Do not use the appliance before installing it in the built-in
structure.
• Do not use a steam cleaner to clean the appliance.
• If the glass ceramic surface / glass surface is cracked,
switch off the appliance and unplug it from the mains. In
case the appliance is connected to the mains directly using
junction box, remove the fuse to disconnect the appliance
from power supply. In either case contact the Authorised
Service Centre.
• If the supply cord is damaged, it must be replaced by the
manufacturer, an authorized Service or similarly qualified
persons in order to avoid a hazard.
• WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance or indicated by the
manufacturer of the appliance in the instructions for use as
suitable or hob guards incorporated in the appliance. The
use of inappropriate guards can cause accidents.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must install this
appliance.
WARNING!
Risk of injury or damage to the appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions supplied
with the appliance.
• Keep the minimum distance from other
appliances and units.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Seal the cut surfaces of the cabinet with a
sealant to prevent moisture from causing
swelling.
• Protect the bottom of the appliance from
steam and moisture.
• Do not install the appliance next to a door
or under a window. This prevents hot
cookware from falling from the appliance
when the door or the window is opened.
• If the appliance is installed above drawers
make sure that the space, between the
bottom of the appliance and the upper
drawer is sufficient for air circulation.
• The bottom of the appliance can get hot.
Make sure to install a separation panel
made from plywood, kitchen carcass
material or other non-flammable materials
under the appliance to prevent access to
the bottom.
4 ENGLISH
• The separation panel has to cover the
area under the hob completely.
2.2 Electrical Connection
WARNING!
Risk of fire and electric shock.
• All electrical connections should be made
by a qualified electrician.
• The appliance must be earthed.
• Before carrying out any operation make
sure that the appliance is disconnected
from the power supply.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Make sure the appliance is installed
correctly. Loose and incorrect electricity
mains cable or plug (if applicable) can
make the terminal become too hot.
• Use the correct electricity mains cable.
• Do not let the electricity mains cable
tangle.
• Make sure that a shock protection is
installed.
• Use the strain relief clamp on the cable.
• Make sure the mains cable or plug (if
applicable) does not touch the hot
appliance or hot cookware, when you
connect the appliance to a socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug (if applicable) or to the mains
cable. Contact our Authorised Service
Centre or an electrician to change a
damaged mains cable.
• The shock protection of live and insulated
parts must be fastened in such a way that
it cannot be removed without tools.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you disconnect
the appliance from the mains at all poles.
The isolation device must have a contact
opening width of minimum 3 mm.
2.3 Use
WARNING!
Risk of injury, burns and electric shock.
• Do not change the specification of this
appliance.
• Remove all the packaging, labelling and
protective film (if applicable) before first
use.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay unattended
during operation.
• Set the cooking zone to “off” after each
use.
• Do not put cutlery or saucepan lids on the
cooking zones. They can become hot.
• Do not operate the appliance with wet
hands or when it has contact with water.
• Do not use the appliance as a work
surface or as a storage surface.
• If the surface of the appliance is cracked,
disconnect immediately the appliance from
the power supply. This to prevent an
electrical shock.
• When you place food into hot oil, it may
splash.
• Do not use aluminum foil or other
materials between the cooking surface
and the cookware, unless otherwise
specified by the manufacturer of this
appliance.
• Use only accessories recommended for
this appliance by the manufacturer.
WARNING!
Risk of fire and explosion.
• Fats and oil when heated can release
flammable vapours. Keep flames or
heated objects away from fats and oils
when you cook with them.
• The vapours that very hot oil releases can
cause spontaneous combustion.
ENGLISH 5
• Used oil, that can contain food remnants,
can cause fire at a lower temperature than
oil used for the first time.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
WARNING!
Risk of damage to the appliance.
• Do not keep hot cookware on the control
panel.
• Do not put a hot pan cover on the glass
surface of the hob.
• Do not let cookware boil dry.
• Be careful not to let objects or cookware
fall on the appliance. The surface can be
damaged.
• Do not activate the cooking zones with
empty cookware or without cookware.
• Cookware made of cast iron, aluminium or
with a damaged bottom can cause
scratches on the glass / glass ceramic.
Always lift these objects up when you
have to move them on the cooking
surface.
2.4 Care and cleaning
• Clean the appliance regularly to prevent
the deterioration of the surface material.
• Switch off the appliance and let it cool
down before cleaning.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do not
use abrasive products, abrasive cleaning
pads, solvents or metal objects, unless
otherwise specified.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Contact your local authority for information
on how to dispose of the appliance.
• Disconnect the appliance from the mains
supply.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
3. INSTALLATION
WARNING!
Refer to Safety chapters.
3.1 Before the installation
Before you install the hob, write down the
information below from the rating plate. The
rating plate is on the bottom of the hob.
Serial number ...........................
3.2 Built-in hobs
Only use the built-in hobs after you assemble
the hob into correct built-in units and work
surfaces that align to the standards.
3.3 Connection cable
• For a single phase or two phase
connection, use the cable type: H03V2V2-
F or H05BB-F which withstands a
temperature of 90 °C or higher.
• To replace the damaged mains cable, use
the cable: H03V2V2-F or H05BB-F which
withstands a temperature of 90 °C or
higher. Contact an Authorised Service
6 ENGLISH
Centre. The connection cable may only be
replaced by a qualified electrician.
3.4 Assembly
If you install the hob under a hood, please
see the installation instructions of the hood
for the minimum distance between the
appliances.
min.
50mm
min.
500mm
Combination with standard oven
min.
12
min.
28
min.
12 mm
min.
60 mm
Combination with double oven
A = min. 6 mm, for double ovens from AEG,
Electrolux and Zanussi.
A = min. 12 mm, for double ovens from other
brands.
Find the video tutorial "How to install your
AEG Radiant Hob - Worktop installation" by
typing out the full name indicated in the
graphic below.
www.youtube.com/electrolux
www.youtube.com/aeg
How to install your AEG
Radiant Hob - Worktop installation
ENGLISH 7
3.5 Protection box
If you use a protection box (an additional
accessory), the protective floor directly below
the hob is not necessary. The protection box
accessory may not be available in some
countries. Contact Customer Support
Service.
You cannot use the protection box if you
install the hob above an oven.
4. PRODUCT DESCRIPTION
4.1 Cooking surface layout
120/210
mm
120/210
mm
145 mm
145 mm
170 mm
265 mm
170 mm
265 mm
1
1
1 1
2
1
Cooking zone
2
Control panel
4.2 Control panel layout
1 2 54 863 7
1011 9
8 ENGLISH
Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which
functions operate.
Sensor
field
Function Comment
1
On / Off To activate and deactivate the hob.
2
Lock / Child Safety Device To lock / unlock the control panel.
3
Pause To activate and deactivate the function.
4
- To activate and deactivate the outer ring.
5
- Heat setting display To show the heat setting.
6
- Timer indicators of cooking
zones
To show for which zone you set the time.
7
- Timer display To show the time in minutes.
8
- To activate and deactivate the outer ring.
9
- To select the cooking zone.
10
/
- To increase or decrease the time.
11
/
- To set a heat setting.
4.3 Heat setting displays
Display Description
The cooking zone is deactivated.
- / -
The cooking zone operates.
The dot means a change by half of a heating level.
Pause operates.
Automatic Heat Up operates.
+ digit
There is a malfunction.
A cooking zone is still hot (residual heat).
Lock / Child Safety Device operates.
Automatic Switch Off operates.
ENGLISH 9
5. DAILY USE
WARNING!
Refer to Safety chapters.
5.1 Activating and deactivating
Touch for 1 second to activate or
deactivate the hob.
5.2 Automatic Switch Off
The function deactivates the hob
automatically if:
• all cooking zones are deactivated,
• you do not set the heat setting after you
activate the hob,
• you spill something or put something on
the control panel for more than 10
seconds (a pan, a cloth, etc.). An acoustic
signal sounds and the hob deactivates.
Remove the object or clean the control
panel.
• you do not deactivate a cooking zone or
change the heat setting. After some time
comes on and the hob deactivates.
The relation between the heat setting and
the time after which the hob deactivates:
Heat setting The hob deactivates
after
, 1 - 2
6 hours
3 - 4 5 hours
5 4 hours
6 - 9 1.5 hour
5.3 The heat setting
Touch to increase the heat setting. Touch
to decrease the heat setting. Touch
and at the same time to deactivate the
cooking zone.
5.4 Residual heat indicator
WARNING!
As long as the indicator is visible,
there is a risk of burns from residual heat.
The indicator appears when a cooking
zone is hot.
The indicator may also appear:
• for the neighbouring cooking zones even if
you are not using them,
• when hot cookware is placed on cold
cooking zone,
• when the hob is deactivated but the
cooking zone is still hot.
The indicator disappears when the cooking
zone has cooled down.
5.5 Activating and deactivating the
outer rings
You can manually adjust the cooking surface
to the dimensions of the cookware.
Set a heat setting for the cooking zone.
Choose the symbol dedicated to the cooking
zone: .
To activate the outer ring: touch the
symbol. The indicator appears.
To deactivate the outer ring: touch the
symbol until the indicator disappears.
5.6 Automatic Heat Up
If you activate this function you can get a
necessary heat setting in a shorter time. The
function sets the highest heat setting for
some time and then decreases to the correct
heat setting.
To activate the function the cooking zone
must be cold.
To activate the function for a cooking
zone: touch until the correct heat setting
comes on. After 3 seconds comes on.
10 ENGLISH
To deactivate the function: touch .
5.7 Timer
• Count Down Timer
You can use this function to set the length of
a single cooking session.
First set the heat setting for the cooking zone,
then set the function.
To set the cooking zone: touch
repeatedly until the indicator of a cooking
zone appears.
To activate the function or change the
time: touch or of the timer to set the
time (00 - 99 minutes). When the indicator of
the cooking zone starts to flash, the time
counts down.
To see the remaining time: touch
to set
the cooking zone. The indicator of the
cooking zone starts to flash. The display
shows the remaining time.
To deactivate the function: touch to set
the cooking zone and then touch . The
remaining time counts down to 00. The
indicator of the cooking zone disappears.
When the countdown ends, an acoustic
signal sounds and 00 flashes. The
cooking zone deactivates.
To stop the sound: touch .
• Minute Minder
You can use this function when the hob is
activated and the cooking zones do not
operate. The heat setting display shows .
To activate the function: touch and then
touch or of the timer to set the time.
When the time finishes, an acoustic signal
sounds and 00 flashes.
To stop the sound: touch .
To deactivate the function: touch and
then touch . The remaining time counts
down to 00.
The function has no effect on the
operation of the cooking zones.
5.8 Pause
This function sets all operating cooking zones
to the lowest heat setting.
When the function operates, all other symbols
on the control panels are locked.
The function does not stop the timer
functions.
1. To activate the function: press .
comes on. The heat setting is lowered to
1.
2. To deactivate the function: press .
The previous heat setting appears.
5.9 Lock
You can lock the control panel while cooking
zones operate. It prevents an accidental
change of the heat setting.
Set the heat setting first.
To activate the function: touch .
comes on for 4 seconds. The Timer stays on.
To deactivate the function: touch . The
previous heat setting comes on.
When you deactivate the hob, you also
deactivate this function.
5.10 Child Safety Device
This function prevents an accidental
operation of the hob.
To activate the function: activate the hob
with . Do not set any heat setting. Touch
for 4 seconds. comes on. Deactivate
the hob with .
To deactivate the function: activate the hob
with . Do not set any heat setting. Touch
for 4 seconds. comes on. Deactivate
the hob with .
ENGLISH 11
To override the function for only one
cooking time: activate the hob with .
comes on. Touch for 4 seconds. Set the
heat setting in 10 seconds. You can
operate the hob. When you deactivate the
hob with the function operates again.
6. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
6.1 Cookware
• To prevent overheating and improve the
performance of the zones, the cookware
must be as thick and flat as possible.
• Ensure cookware bases are clean and dry
before placing on the hob surface.
• Always be careful no to slide or rub the
cookware on the edges and corners of the
glass as it may chip or damage the glass
surface.
Cookware made of enamelled steel and
with aluminium or copper bottoms can
cause a colour change on the glass-
ceramic surface.
6.2 Simplified cooking guide
The data in the table is for guidance only.
Heat setting Use to: Time
(min)
Hints
- 1
Keep cooked food warm. as neces‐
sary
Put a lid on the cookware.
1 - 2. Hollandaise sauce; melt: butter, choco‐
late, gelatine.
5 - 25 Mix from time to time.
2. Solidify: fluffy omelettes, baked eggs. 10 - 40 Cook with a lid on.
2. - 3. Simmer rice and milk-based dishes,
heat up ready-cooked meals.
25 - 50 Add at least twice as much liquid as
rice, mix milk dishes halfway through
the procedure.
3. - 4. Stew vegetables, fish, meat. 20 - 45 Add a few tablespoons of water.
Check the water amount during the
process.
4. - 5. Steam potatoes and other vegetables. 20 - 60 Cover the bottom of the pot with 1-2
cm of water. Check the water level
during the process. Keep the lid on the
pot.
4. - 5. Cook larger quantities of food, stews
and soups.
60 - 150 Up to 3 l of liquid plus ingredients.
5. - 7 Gentle fry: escalope, veal cordon bleu,
cutlets, rissoles, sausages, liver, roux,
eggs, pancakes, doughnuts.
as neces‐
sary
Turn over when needed.
7 - 8 Heavy fry, hash browns, loin steaks,
steaks.
5 - 15 Turn over when needed.
9 Boil water, cook pasta, sear meat (goulash, pot roast), deep-fry chips.
12 ENGLISH
7. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
7.1 General information
• Clean the hob after each use.
• Always use cookware with a clean base.
• Scratches or dark stains on the surface
have no effect on how the hob operates.
• Use a special cleaning agent suitable for
the surface of the hob.
• Always use a scraper recommended for
hobs with a glass surface. Use the scraper
only as an additional tool for cleaning the
glass after the standard cleaning
procedure.
WARNING!
Do not use knives or any other sharp,
metal tools to clean the glass surface.
7.2 Cleaning the hob
• Remove immediately: melted plastic,
plastic foil, salt, sugar and food with sugar,
otherwise, the dirt can cause damage to
the hob. Take care to avoid burns. Use a
special hob scraper on the glass surface
at an acute angle and move the blade on
the surface.
• Remove when the hob is sufficiently
cool: limescale rings, water rings, fat
stains, shiny metallic discoloration. Clean
the hob with a moist cloth and a non-
abrasive detergent. After cleaning, wipe
the hob dry with a soft cloth.
• Remove shiny metallic discoloration:
use a solution of water with vinegar and
clean the glass surface with a cloth.
8. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
8.1 What to do if...
Problem Possible cause Remedy
You cannot activate or operate
the hob.
The hob is not connected to an elec‐
trical supply or it is connected incor‐
rectly.
Check if the hob is correctly connected
to the electrical supply.
The fuse is blown. Make sure that the fuse is the cause of
the malfunction. If the fuse is blown
again and again, contact a qualified
electrician.
You did not set the heat setting for
10 seconds.
Activate the hob again and set the
heat setting in less than 10 seconds.
You touched 2 or more sensor fields
at the same time.
Touch only one sensor field.
Pause operates. Refer to "Pause".
There is water or fat stains on the
control panel.
Clean the control panel.
ENGLISH 13
Problem Possible cause Remedy
You can hear a constant beep
noise.
The electrical connection is incor‐
rect.
Disconnect the hob from the electrical
supply. Ask a qualified electrician to
check the installation.
An acoustic signal sounds and
the hob deactivates.
An acoustic signal sounds when
the hob is deactivated.
You put something on one or more
sensor fields.
Remove the object from the sensor
fields.
The hob deactivates. You put something on the sensor
field .
Remove the object from the sensor
field.
Residual heat indicator does not
come on.
The zone is not hot because it oper‐
ated only for a short time or the sen‐
sor is damaged.
If the zone operated sufficiently long to
be hot, speak to an Authorised Service
Centre.
Automatic Heat Up does not op‐
erate.
The highest heat setting is set. The highest heat setting has the same
power as the function.
The zone is hot. Let the zone become sufficiently cool.
You decreased the heat setting to 0. Start from 0 and increase the heat set‐
ting.
There is a dark area on
the multiple zone.
It is normal that there is a dark area
on the multiple zone.
The control panel becomes hot to
the touch.
The cookware is too large or you put
it too close to the control panel.
Put large cookware on the rear zones,
if possible.
comes on.
Child Safety Device or Lock oper‐
ates.
Refer to "Daily use".
and a number come on.
There is an error in the hob. Deactivate the hob and activate it
again after 30 seconds. If comes
on again, disconnect the hob from the
electrical supply. After 30 seconds,
connect the hob again. If the problem
continues, speak to an Authorised
Service Centre.
comes on.
The second phase of the power sup‐
ply is missing.
Check if the hob is correctly connected
to the electrical supply. Remove the
fuse, wait one minute, and insert the
fuse again.
8.2 If you cannot find a solution...
If you cannot find a solution to the problem
yourself, contact your dealer or an Authorised
Service Centre. Give the data from the rating
plate. Give also three digit letter code for the
glass ceramic (it is in the corner of the glass
surface) and an error message that comes
on. Make sure, you operated the hob
correctly. If not the servicing by a service
technician or dealer will not be free of charge,
also during the warranty period. The
information about guarantee period and
Authorised Service Centres are in the
guarantee booklet.
14 ENGLISH
9. TECHNICAL DATA
9.1 Rating plate
Model HRX64360C PNC 949 492 759 00
Typ 60 HAD 47 AO 220 - 240 V / 400 V 2N, 50 - 60 Hz
Made in: Romania
Ser.Nr. ................. 7.0 kW
AEG
9.2 Cooking zones specification
Cooking zone Nominal Power (Max heat set‐
ting) [W]
Cooking zone diameter [mm]
Left front 750 / 2200 120 / 210
Left rear 1200 145
Right front 1200 145
Right rear 1500 / 2400 170 / 265
For optimal cooking results use cookware no
larger than the diameter of the cooking zone.
10. ENERGY EFFICIENCY
10.1 Product Information according to EU and UK Ecodesign Regulations
Model identification HRX64360C
Type of hob Built-In Hob
Number of cooking zones 4
Heating technology Radiant Heater
Diameter of circular cooking zones (Ø) Left front
Left rear
Right front
21.0 cm
14.5 cm
14.5 cm
Length (L) and width (W) of non circular cooking
zone
Right rear L 26.5 cm
W 17.0 cm
Energy consumption per cooking zone (EC electric
cooking)
Left front
Left rear
Right front
Right rear
194.9 Wh/kg
188.0 Wh/kg
188.0 Wh/kg
191.6 Wh/kg
Energy consumption of the hob (EC electric hob) 190.6 Wh/kg
IEC / EN 60350-2, BS EN 60350-2 -
Household electric cooking appliances - Part
2: Hobs - Methods for measuring
performance.
ENGLISH 15
10.2 Energy saving
You can save energy during everyday
cooking if you follow the hints below.
• When you heat up water, use only the
amount you need.
• If it is possible, always put the lids on the
cookware.
• Before you activate the cooking zone put
the cookware on it.
• The cookware bottom should have the
same diameter as the cooking zone.
• Put the smaller cookware on the smaller
cooking zones.
• Put the cookware directly in the centre of
the cooking zone.
• Use the residual heat to keep the food
warm or to melt it.
11. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put the
packaging in relevant containers to recycle it.
Help protect the environment and human
health by recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol with
the household waste. Return the product to
your local recycling facility or contact your
municipal office.
16 ENGLISH
*
867384673-A-492023
