2 COB + 1 RECHARGEABLE SLIM FOLDING
POCKET LIGHT
MODEL NO: LED01 SERIES
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL
9 It is important to ensure that the lamp is fully charged before initial use.
8 DO NOT turn the lamp on when it is being charged.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the lamp.
8 DO NOT leave battery in a discharged state. Recharge battery immediately.
Recharge the battery at least once every six months of non-use.
9 There are no user serviceable components. DO NOT dismantle.
8 DO NOT pull the charger plug from the mains socket by the lead.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT Attempt to open, disassemble, modify or service the battery pack.
8 DO NOT Crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT Expose to temperatures above 60°C (140°F).
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention
2. INTRODUCTION
Slimline pocket lamp for use in conned spaces. Inspection arm can be folded 180º for hands-free use. Super bright COB and SMD LED, 6000-
7000k, 80+CRI. High impact plastic housing with aluminium light and a strong magnet on the bottom. Rechargeable high quality 3.7V 700mAh
Li-ion battery with a charging time of 2.5 hours. Flashing warning light when battery is low. Includes 1 LED indicator - ashes green for charging,
continuous green for full charge. Charges via a USB Type-C lead. (Supplied with USB Type-C Cable).
3. SPECIFICATION
Model No ......................................................... LED01 Series
Battery ....................................................3.7V 700mAh Li-ion
LED Quantity................................................ 2 COB + 1 SMD
Lumen Output:
Top spotlight .................................................................. 80lm,
Front (High/Low) ................................................200lm/100lm
Rear ............................................................................. 180lm
Operating time:
Top spotlight ...................................................................... 3hr
Front .....................................................................3.5hr/1.5hr
Rear ..................................................................................2hr
Charging time:................................................................2.5hr
Length:
Folded ......................................................... 165 x 20 x 28mm
Extended .....................................................300 x 20 x 28mm
4. CHARGING
4.1. The battery fitted to this lamp is considered to be a consumable item and its ability to accept charge will reduce over time. We will
warranty it against mechanical and electrical defect for a period of one year, this does not cover fair wear and tear. If the battery is not
properly charged before first use, or regularly conditioned, its capacity will diminish. Under these circumstances we will not replace the
battery even if it is less than one year old.
4.2. Connect the charger into the charge port on the lamp, see fig.1. Plug into power supply and turn on, the green charge indicator LED on
the lamp will flash as the battery charges. When fully charged the LED turns to continuous green.
4.3. Charge the battery for 4-5 hours for its initial charge. Normal charge time is approx 2.5hrs. Disconnect from mains supply.
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
LED01 Series Issue:2 (2) 27/05/20
NOTE: The Lithium battery does not suffer from memory effect and once fully charged may be stored for up to six months without another
charge.
5. OPERATION
Refer to g.2 On/O switch
5.1. First press: top light on.
5.2. Second press: front light, half power.
5.3. Third press: front light, full power.
5.4. Fourth press: Rear light full power.
5.5. Fifth press: o.
5.6. Fully charge the lamp before storage.
6. MAINTENANCE
6.1. Keep lamp clean with a damp cloth (do not use solvents) and check for damage before every use.
6.2. The battery is not designed to be removed.
Original Language Version
© Jack Sealey Limited
Fig.1 Fig.2
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
On/O
Charge port
Charge indicator
Parts support is available for this product. Please email sales@sealey.co.uk or telephone 01284 757500
