VTS16HD
3
size:105x148mm
DC +12V RED
(GND)Black
Monitor
3.Installation
The installation and position of the camera
Signal Wire
Encase with insulating tape
It is advisable to disconnect the negative battery cable for 3
minutes before beginning installation, to avoid unintended
air bag deployment. Note and record any anti-theft radio
codes prior to disconnecting.
Caution:
!
Tailgate door handle camera for Toyota Tundra 2007~2013
21
Item Description
Camera
Technical term Technical Parameters
SONY HD CCD
DC 9V-16V
57 mA
0.7 W
768(H)X494(V)NTSC, 752(H)X582(V)PAL
1/60 (NTSC)1/50(PAL)-100000s
0.1 Lux
48 dB
600 TVL
NTSC / PAL
D=130°± 10° H=90°±5° V=68°±5°
1.0Vp-p 75ohm
IP 67
AUTO
AUTO
AUTO
-31°F～167°F
Image Sensor
Power Supply(DCV)
Current Consumption
Power
Effective pixels
Electionic shutter
Minimum illumination
Resolution(TV Lines)
TV System
Lens Angle(Deg.)
Video output
IP rating (Waterproof)
White Balance AUTO
AGC
BLC
Operating Temperature(°F)
S/N Ratio
1.Specification
Signal Wire (32.8ft)
Power Line (9.84ft)
User`s manual
①
②
③
④
⑤
⑥
①
②
③
⑨ ⑩
Warranty Card
Registration Card
④
⑤
⑥
⑦
⑧
⑦
⑧
⑨
⑩
Tie straps
Convoluted tubing(3.28ft)
Pad
T-Taps
2. Parts Identification
T-Taps
