VTS18HD
3
size:105x148mm
DC +12V RED
(GND)Black
Monitor
3.Installation
The installation and position of the camera
The effect of camera's installation
Signal Wire
Encase with insulating tape
2.Accessories
21
Sequence Number Name
Camera
Technical term Technical Parameters
HD CCD
DC 9V-16V
57 mA
0.7 W
768(H)X494(V)NTSC, 752(H)X582(V)PAL
1/60 (NTSC)1/50(PAL)-100000s
0.1 Lux
48 dB
600 TVL
NTSC / PAL
D=130°± 10° H=90°±5° V=68°±5°
1.0Vp-p 75ohm
IP 67
AUTO
AUTO
AUTO
-31°F～167°F
Image Sensor
Power Supply(DCV)
Current Consumption
Power
Effective pixels
Electionic shutter
Minimum illumination
Resolution(TV Lines)
TV System
Lens Angle(Deg.)
Video output
IP rating (Waterproof)
White Balance AUTO
AGC
BLC
Operating Temperature(°F)
S/N Ratio
1.Specification
Signal Wire (26ft)
Power Line (10ft)
User`s manual
VTS10
①
②
③
④
⑤
⑥
①
②
③
④ ⑤ ⑥
Warranty Card
Registration Card
