1
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Bullet Blender
Model no: SDA2634
User Manual
2
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Bullet Blender
Model no: SDA2634
User Manual
Contents
Page No.
2 Contents
3
3
Reading and Storing the User Manual
Important Safety Instructions for Proper Use
6 Explanation of Symbols
7 Description of Parts
7 Preparing for use
8 Charging Your Bullet Blender
8 Using Your Bullet Blender
8 Battery life during use
8 Indicator lights
8 Battery life during use
9 Charging Indicators
9 Overloading Indication
9 Care and Maintenance
9 Cleaning Tips
9 To store
10 Technical specification
10 Customer support
11 Recycling information
Back Page Warranty information
3
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Bullet Blender
Model no: SDA2634
User Manual
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Read and familiarise yourself with all operating
instructions before using this Bullet Blender.
Before plugging your unit into the mains, visually check
that it is intact and has not suffered any transit damage.
Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
Do not use this product with a programmer, timer,
separate remote-control system or any other such device.
Do not immerse this appliance in water or any other
liquids.
Close supervision is required when using this appliance
near children.
Never leave this appliance within reach of children.
This appliance shall not be used by children from 0 to 8
years.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.
Children shall not play with the appliance.
Keep the appliance and its USB charging cable out of reach
4
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Bullet Blender
Model no: SDA2634
User Manual
of children less than 8 years.
Cleaning and user maintenance shall not be made by
children.
Do not leave the appliance unattended during use.
Do not leave the appliance unattended whilst connected
to the mains supply.
Always use this appliance on a solid, level, non-flammable
surface.
Do not use this appliance outdoors.
It is imperative to unplug the USB power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
Regular, periodic checks should be carried out on the
supply cord to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
If the USB power cable is damaged it is to be replaced by a
qualified person in order to avoid a hazard.
Do not operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
Do not allow the mains cable to hang over sharp edges or
come in contact with hot surfaces.
This appliance is intended for household use only and
should not be used for industrial purposes.
Do not use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
Do not use this appliance for anything other than its
intended use.
Do not push objects into any openings as damage to the
appliance and/or electric shock may occur.
CAUTION: The blade assembly is sharp, handle with care.
When handling the blade assembly always hold by the
base.
DO NOT ATTEMPT TO SHARPEN THE BLADES
5
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Bullet Blender
Model no: SDA2634
User Manual
DO NOT use the appliance if the blade assembly is bent or
damaged.
To avoid the risk of injury or damage never place the
blade assembly onto the base without the proper
attachment.
Only use attachments and accessories intended for use
with this product.
Do not remove the cup from the motor base while the
motor is running.
CAUTION: DO NOT PROCESS HOT FOODS OR LIQUIDS.
DO NOT overfill
DO NOT operate the appliance while it is empty.
If the appliance overheats a thermal switch will activate
and shut off the motor. To reset, unplug the appliance and
allow it to cool for 30 minutes before using again.
This product is intended for household use only. Do not
use this appliance for anything other than its intended
use.
WARNING: Exercise caution when attaching or removing
attachments from the Hand Blender and ensure the
appliance is turned off and unplugged whilst fitting
attachments.
NOTE: The Hand Blender should not be used for more
than 1 minute intervals. Ensure you allow a 10 minute rest
period offer every 1 minute cycle.
CAUTION: Always remove the USB cable from the Hand
Blender before use.
6
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Bullet Blender
Model no: SDA2634
User Manual
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste. Please ensure it is
taken to a suitable facility for disposal. Check with your Local
Authority or retailer for recycling advice or visit www.recycle-
more.co.uk to find your nearest recycling point.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
WARNING!
This designates a hazard with moderate risk, which may
result in severe injury if not adhered to.
7
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Bullet Blender
Model no: SDA2634
User Manual
Description of Parts
Preparing For Use
Carefully unpack the motor housing unit and all parts. Remove any tape, labels
or packaging materials.
Wash all product attachments carefully except for the motor housing unit with
warm, soapy water. Rinse and dry thoroughly.
Wipe exterior surfaces of the motor housing with a soft, moist cloth to remove
dust particles collected during packing and handling.
NEVER IMMERSE THE MOTOR HOUSING, USB CHARGING CABLE IN WATER
OR ANY OTHER LIQUID.
Ensure all parts are properly assembled and in place before use.
7
7
4
3
1
2
6
1. Blending Cup (450ml)
2. Blade Assembly
3. Motor Housing
4. On/Off Button
5. Power Indicator Lights
6. USB Charging Port
7. USB Charging Cable
5
8
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Bullet Blender
Model no: SDA2634
User Manual
Charging Your Bullet Blender
1. Open the USB Charging Port (6) on the Motor Housing Unit (3). Attach micro
end of USB Charging Cable (13) to the motor housing.
2. Attach the USB connector (larger end) into a suitable USB charger rated to at
least 1 Amp. (NB most USB chargers are rated 1 Amp or above). The internal
battery will begin to charge.
3. The Power Indicator Lights (4) will flash while charging. The lights will stop
flashing once the unit is fully charged. See indicator Light section for details.
NB: The unit is shipped with approximately 30% charge in the batteries. One or
two lights will be illuminated during use. It is recommended to fully charge before
first use for best performance.
4. It will approximately 2.5 hours to fully charge the unit.
Using Your Bullet Blender
1. Put food ingredients into the Blending Cup (1), and then attach the Blade
Assembly (2).
2. With the base unit stable, place the assembled blending cup onto the base and
turn clockwise to lock into place.
3. Press the On/Off Button (4) on front of the Motor Housing (3) to start blending.
4. When blending has finished, release the On/Off Button (4) and the unit will
stop.
5. Remove the Blending Cup (1) from the Motor Housing (3) by turning anti-
clockwise.
6. Turn the Blending Cup (1) right-side up and remove the Blade Assembly (2) by
turning anti-clockwise.
Do not use the blender for longer than 1 minute continuously. After 1 minute of
continuous use, the unit may become over-heated. Allow the unit to rest for at
least 5 minutes before resuming use.
Indicator Lights
The motor housing indicator lights provide feedback for different situations:
Battery Life During Use:
As the Hand Blender is used and the battery begins to drain during performance,
the indicator lights will extinguish in sequence from the top to the bottom to
indicate how much battery capacity is left.
66% to 100% of capacity: Lights 1, 2 and 3 will illuminate.
33% to 65% of capacity: Light 1 & 2 will illuminate.
20% to 30% of capacity: Light 1 will illuminate.
If less than 20% of capacity: Light 1 flashes and the unit needs to be charged.
9
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Bullet Blender
Model no: SDA2634
User Manual
Charging Indicators:
Indicator lights will also provide feedback during the charging process:
If battery capacity is less than 33%, Lights 1, 2 and 3 will flash while charging.
If battery capacity is within 33%-65%, Light 1 will illuminate and Lights 2 and
3 will flash.
If battery capacity is within 66%-99%, Lights 1 and 2 will illuminate and only
Light 3 will flash.
If battery capacity is greater than 99%, Lights 1, 2 and 3 will illuminate.
Overloading Indication:
Note: The motor housing has an automatic protection system that will not allow
overloading. If the load is too large, the unit will automatically shut off. If the unit
senses an overload situation, all 3 lights will flash 5 times and the unit will turn Off.
Release the speed button and the lights will turn off. Reduce the load on the
blender or the chopper, allow it to rest for more than 15 minutes and then resume
use.
Do not expose a battery pack or appliance to fire or excessive heat. Exposure to
fire or temperatures above 130℃ may cause an explosion.
Care and Maintenance
CAUTION:
Unplug
the USB Charging Cable (7) from the Bullet Blender before
cleaning.
Wash the attachments in warm soapy water and dry thoroughly.
Clean the outside of the motor housing with a clean damp cloth. Never clean
with harsh or abrasive cleaners.
Do not submerge the Motor Housing Unit in water or any other liquids.
WARNING! DO NOT CLEAN ANY PART OF YOUR HAND BLENDER IN A
DISHWASHER. WASH IN WARM SOAPY WATER AND DRY THOROUGHLY.
Cleaning Tips
To ease washing it is advised to rinse parts immediately after mixing.
Use a small brush (not supplied) to remove particles lodged in the
attachments.
To Store:
Be sure all parts are clean and dry before storing. Never store it while it is wet.
The unit can be stored for up to 3 months with a fully charged state. If storing for
longer than 3 months the unit should be charged before next use.
Store in a dry area in an ambient temperature of 5⁰C - 35⁰C.
10
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Bullet Blender
Model no: SDA2634
User Manual
Technical Specification
Model no.
SDA
263
4
Battery
2
0
00mAh Li
-
Ion
Rated Power
200W
11
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Bullet Blender
Model no: SDA2634
User Manual
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for recycling
advice visit www.recycle-more.co.uk enter your postcode to find your
nearest recycling site.
This symbol means batteries and rechargeable batteries may not
be disposed of with household waste!
As the end user you are required by law to bring all batteries and
rechargeable batteries to a collection point run by the Local
Authority or to a retailer, so that they can be disposed of in an
environmentally friendly manner.
12
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Bullet Blender
Model no: SDA2634
User Manual
WARRANTY
Thank you for purchasing your Cordless Pro Bullet Blender
As part of our commitment to quality, we are offering you an extra 2 years warranty in addition
to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof of
purchase or receipt. If any defect should occur due to faulty workmanship or material, your faulty
vacuum should be returned to the place of purchase, replacement or refund is at the discretion of the
retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the requirements
contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and covers
the main body and housing). If you do not register your product within 28 days of the original
purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28 days
of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
