1
1.7L Easy Fill Glass Kettle
Model No. SDA2102
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
1.7L Easy Fill Glass Kettle
Model No. SDA2102
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should always
be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Kettle.
• Before plugging your kettle into the mains, visually check
that the kettle is intact and has not suffered any transit
damage.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• This kettle is only to be used with the stand provided.
• Close supervision is required when using this appliance
near children.
• Never leave this appliance within reach of children.
• This appliance can be used by children aged from 8 years
and above if they have been given supervision or
instruction concerning use if the appliance in a safe way
and if they understand the hazards involved. Cleaning and
user maintenance shall not be made by children unless
they are older than 8 and supervised. Keep the appliance
and its cord out of reach of children aged less than 8
years. This appliance can be used by persons with
reduced physical, sensory or mental capabilities or lack of
3
1.7L Easy Fill Glass Kettle
Model No. SDA2102
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
experience and knowledge if they have been given
supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
to the mains supply.
• Always use this appliance on a solid, level, non-flammable
surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• If the supply cord is damaged, it must be replaced by the
manufacturer, service agent or similarly qualified person
in order to avoid hazard.
• Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place user at
serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• DO NOT run the mains cable under carpets, rugs, etc.
• Allow the unit to cool before storage.
• Never place the appliance near to flammable material or
high-pressure containers.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
4
1.7L Easy Fill Glass Kettle
Model No. SDA2102
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
supplier.
• DO NOT immerse the appliance, base or its cord in water
or any other liquids.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Ensure appliance is situated in an open area, do not allow
it to come in contact with cupboards, curtains, wall
coverings, clothing or other flammable materials.
• Unplug after each use. Grasp the plug, not the cord.
• DO NOT cover this appliance.
• Never place this appliance on an electric, gas, or any other
type of hob.
• WARNING: DO NOT open lid whilst the water is boiling.
• Never fill the kettle more than its capacity – ensure the
water level is between the min and max marks. If the
kettle is overfilled, boiling water may be ejected.
• Always close the lid during use and do not open the lid
whilst the water is boiling.
• CAUTION: The outside surface of the kettle will get hot
during use.
• Ensure the kettle has switched off before removing it from
the base.
• Please note, due to this being a rapid boil kettle it is
recommended that you don’t use this in conjunction with
any other appliances on a multi socket extension lead.
THIS APPLIANCE MUST BE EARTHED
5
1.7L Easy Fill Glass Kettle
Model No. SDA2102
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
WARNING!
This designates a hazard with moderate risk, which may result
in severe injury or damage to the product if not adhered to.
6
1.7L Easy Fill Glass Kettle
Model No. SDA2102
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Before first use of Your kettle
Please read these operating instructions thoroughly and keep them in a safe place
for future reference.
Before using the kettle for the first time, fill to the max mark and allow the water
to boil. Pour away the boiled water and then repeat the process. If a slight taste or
odour remains repeat the above process once more.
Using Your Easy Fill Glass Kettle
2
1
1. Spout
2. Water Gauge
3. Internal LED’s
4. Base
5. Switch
6. Handle
7. Lid Handle
8. Lid
9. Easy Fill Shute
10. Filter (Inside Spout)
1
Place the kettle Base (4) on a
flat, level, non-flammable
surface.
Ensure that the kettle is
disconnected from the
mains supply.
2
3
4
9
8
7
6
5
10
7
1.7L Easy Fill Glass Kettle
Model No. SDA2102
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Fill the Kettle through the Easy
Fill Shute (9) as shown left.
•
Alternatively, remove the Lid (8)
using the Lid Handle (7). Press
the lid back onto the kettle after
filling.
Fill the kettle to the desired
level on the Water Gauge (2)
ensuring that it is above the
MIN mark and below the MAX
mark.
WARNING! Do not overfill
the kettle above the MAX mark
as this will risk boil over and
may damage the appliance.
•
Insert the mains plug (with dry
hands) into the mains socket.
•
3
4
5
8
1.7L Easy Fill Glass Kettle
Model No. SDA2102
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Boil dry protection
Should you accidentally let the appliance operate without water; the boil-dry
protection will automatically switch off the power. If this occurs, allow the
appliance to cool and reset before use.
Important – Descaling your Glass Kettle/Reducing Limescale Build up
• To prolong the life of your kettle it is imperative that it is descaled regularly.
• The frequency of the descaling depends on the hardness of the water in your
area and how often the appliance is used.
• In extreme hard water areas, descaling your kettle at least once a month is
highly recommended also the use of filtered water in your kettle will increase
the life expectancy and help prevent excessive lime scale build up.
• If the kettle switches off before it boils or has a white deposit building up inside
then it will need to be descaled.
• Do not use vinegar but a commercially available descaling agent; carefully follow
the quantities recommended in the instructions of the agent:
2
1
Push the Switch (5) down and the Internal
LED’s (3) will illuminate blue and the water
will begin to boil.
At the end of the boiling cycle the Switch (5)
will automatically switch off (pop up) and the
Internal LED’s (3) will go out.
Wait until the water has finished boiling
before removing the kettle from the Base (4).
6
Fill your kettle to the ‘MAX’
mark on the body or the water
quantity recommended by the
descaling product.
Add a descaling agent to the kettle
according to the descaling products
instructions.
9
1.7L Easy Fill Glass Kettle
Model No. SDA2102
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Replacing the Filter (10)
Care and Use of Your Kettle
• Ensure the mains plug is removed from the socket outlet before cleaning.
• Do not immerse the kettle or the base in water or any other liquids.
• Wipe the kettle clean with a clean damp cloth.
• Do not use harsh or abrasive scouring pads, powders or cleaners.
• Do not clean in a dishwasher.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse needed replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse
cover missing. If in doubt, consult a qualified electrician.
If you need to remove the plug -DISCONNECT FROM THE MAINS- and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
4
3
Allow the kettle to boil, switch off and then
stand to allow the kettle to soak for
approximately 15 – 20 minutes, (if
necessary, adjust the standing time to the
descaling products instructions).
Finally, empty the kettle and refill with fresh clean water and
allow to come to the boil and switch off once more, then again
pour the water away. Your kettle is now descaled and cleaned.
The Filter (10) is located behind
the Spout (1) and is accessible
from inside the kettle.
Remove the Lid (8) using the Lid
Handle (7). Pull out the Filter (10)
as shown left.
Replace the Filter by pushing it
back inside the kettle behind the
Spout (1).
Filter
10
1.7L Easy Fill Glass Kettle
Model No. SDA2102
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Specification
Model Number
SDA2102
Rated Voltage
220-240V~ 50-60Hz
Rated Power
2520-3000W
Protection Class
I (This appliance must be Earthed)
Capacity
1.7 Litre
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
11
1.7L Easy Fill Glass Kettle
Model No. SDA2102
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Notes
12
1.7L Easy Fill Glass Kettle
Model No. SDA2102
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
