User Manual
+
E3005
Safety Information .................................................................................................................................................1-3
Introduction / What’s Included ...................................................................................................................... 4
Components ................................................................................................................................................................5
Operation Instructions .........................................................................................................................................................6-10
How to Setup your ChargeHub X5+ Elite ................................................................................... 6
How to Charge Using a Standard USB Cable .........................................................................7-8
How to Charge Using a Type-C Cable ......................................................................................... 9
How to Charge Wirelessly..................................................................................................................10
Overdraw Protection .................................................................................................................................... 11
Certification ............................................................................................................................................................... 12
Notice to International Users .............................................................................................................................. 13
Recommended Accessories ................................................................................................................................14
Technical Specifications...........................................................................................................................................................15
Limited Warranty ........................................................................................................................................ 16-23
Consumer Rights & Arbitration Agreement.......................................................................................... 24-28
Copyright Notice .................................................................................................................................................... 29
FCC Notice................................................................................................................................................................30
Table of Contents
© Limitless Innovations, Inc.
1
+
By using the ChargeHub X5+ Elite, you hereby agree that Limitless Innovations,
Inc., an Illinois corporation and its aliates (“Limitless”) shall have no liability
for any losses associated with property damage, personal injury or loss of life
that are incurred by you or by any third party in connection with or relating
in any manner whatsoever to your use of the ChargeHub X5+ Elite. By using
the ChargeHub X5+ Elite, you hereby agree at all times to comply fully with
all safety warnings, operating instructions and general safety information
in this user manual. By using the ChargeHub X5+ Elite, you further agree to
hold harmless Limitless, (and Limitless’ ocers, directors, shareholders and
employees) in connection with any losses sustained by you (including, without
limitation, losses arising in whole or in part from property damage, personal
injury or loss of life) relating in any manner whatsoever to your use of the
ChargeHub X5+ Elite.
Safety Information
© Limitless Innovations, Inc.
2
+
SAFETY WARNINGS
• The ChargeHub X5+ Elite is NOT a toy and should be kept away from children.
• Do NOT expose the ChargeHub X5+ Elite to extreme heat, moisture, water, rain,
or snow.
• Do NOT use the ChargeHub X5+ Elite if it has been damaged and/or
modified.
• Do NOT stick foreign objects in any port or opening of the ChargeHub X5+
Elite. Doing so may cause electric shock.
• Do NOT attempt to disassemble or repair the ChargeHub X5+ Elite.
Contact customer service for technical assistance at 855-843-4828.
• Do NOT use third party power supplies or non-approved adapters with the
ChargeHub X5+ Elite.
Safety Information cont’d
© Limitless Innovations, Inc.
3
+
• Do NOT attempt to open the outer casing of the ChargeHub X5+ Elite.
• Do NOT clean the ChargeHub X5+ Elite with harsh chemicals and keep it
away from liquids.
• Do NOT paint or apply coatings to the ChargeHub X5+ Elite, as you might
aect moving parts or damage internal components.
• Do NOT force a connector into a port of the ChargeHub X5+ Elite. Always
check for obstructions in the port.
• Do NOT place devices that are not compatible with wireless charging on top
of the wireless charging pad. Doing so may cause your device to over-charge.
• If this device is accessible to or may be used by a minor, purchasing adult
agrees to be solely responsible for providing supervision, instruction,
and warnings. Purchaser agrees to defend, indemnify, and hold Limitless
Innovations harmless for any claims or damages arising from unintended use
or misuse by a minor.
Safety Information cont’d
© Limitless Innovations, Inc.
4
+
The ChargeHub X5+ Elite provides the highest of charging technology and is
universally compatible with virtually any mobile device – even a laptop! Get the
fastest charge for up to 6 devices by plugging into the standard USB port, the
evolving Type-C Power Delivery Port, or by utilizing the wireless charging pad! The
ChargeHub X5+ Elite is high-powered and equipped with patented SmartSpeed®
Technology to provide an optimal charge for each connected device! This
luxurious, soft touch multi-port charger is perfect for the home + oce!
Note: The ChargeHub may not be compatible with all USB chargeable devices.
WHAT’S INCLUDED:
1x ChargeHub X5+ Elite
1x AC Power Cord
1x User Manual
Introduction
ChargeHub X5+ Elite AC Power Cord User Manual
User Manual
+
E3005
* May include USB Charging cables or accessories
© Limitless Innovations, Inc.
5
+
Components
1. Wireless Charging Pad
2. Wireless Charger Indicator Light
3. USB Charging Ports (Output)
4. Type-C Port
5. LED Power Indicator Light
6. AC Power (Input)
1
2
3
5
6
4
* Bottom Of Unit Shown
© Limitless Innovations, Inc.
6
+
Operation Instructions
HOW TO SETUP YOUR CHARGEHUB X5+ ELITE
Plug the AC Power Cord into the AC Power
Input of the ChargeHub X5+ Elite.
Plug the opposite end of the AC Power
Cord into the Wall Outlet. The LED Power
Indicator Light will illuminate.
1
2
© Limitless Innovations, Inc.
7
+
Operation Instructions cont’d
Plug the USB connector of your cable into
one of the USB Charging Ports.
Plug the opposite end of the cable into your
device.
1
2
HOW TO CHARGE USING A STANDARD USB CABLE
© Limitless Innovations, Inc.
8
+
Operation Instructions cont’d
Repeat steps 3-4 to add additional devices
to the ChargeHub X5+ Elite.
NOTE:
Charging times may vary by device. The
ChargeHub X5+ Elite has a max total output
of 5V / 4.4A (54W). Exceeding these limits
may cause the ChargeHub X5+ Elite to go
into overdraw protection. Refer to page 11
for additional information.
3
© Limitless Innovations, Inc.
9
+
Operation Instructions cont’d
Plug the other end of the Type-C cable into
your device or laptop.
NOTE:
Not all devices and laptops are compatible
with Type-C Power delivery. Please refer to
your devices user manual for instructions on
the proper way to charge your device.
2
Plug the Type-C connector of your cable
into the Type-C Charging Port.
1
HOW TO CHARGE USING A TYPE-C CABLE
© Limitless Innovations, Inc.
10
+
Place your compatible device on top of
the Wireless Charging Pad. The Wireless
Charging Indicator Light will illuminate when
successful. Once device is fully charged the
Wireless Charging Indicator Light will turn o.
NOTE:
If the device does not immediately
begin to charge you may need to adjust the
positioning on top of the Wireless Charging
Pad until there is a successful connection.
1
Operation Instructions cont’d
HOW TO CHARGE WIRELESSLY
© Limitless Innovations, Inc.
11
+
When multiple devices are connected, the ChargeHub X5+ Elite may, at times,
reach its maximum charge capacity. Once this occurs, the unit will start blinking
and connected devices should be temporarily disconnected one by one until
the blinking stops. Once the connected devices consume less power and
the blinking stops, the user should wait a short period of time and begin to
reconnect the devices one by one to resume charging.
Overdraw Protection
© Limitless Innovations, Inc.
12
+
Certification
ChargeHub X5+ Elite is UL/cUL certified and tested to comply with FCC
Standard Part 15 for safety and reliability under the United States and Canadian
standards. ChargeHub X5+ Elite is compliant with requirements for Energy
Eciency Level VI.
Unauthorized changes or modifications to this device may impair the user’s
ability to operate this device and will void the warranty.
UL/cUL and FCC Notice to Users
Users are not permitted to make changes or modify this device or any of its
companion products or components in any way. Changes or modifications are
considered a safety hazard/risk and will void the warranty.
© Limitless Innovations, Inc.
13
+
Prior to traveling outside of North America, please make sure to have a
compatible ChargeHub-branded plug adapter to use in the country being
traveled to. International plug adapters can be purchased separately by visiting
our website at:
LimitlessInnovations.com/Shop
Notice to International Users
© Limitless Innovations, Inc.
14
+
- CableLinx USB Cables
- Travel Case
- International Travel Adapters
It is critical to use ChargeHub branded power supplies and approved adapters,
only. Use of non-approved ChargeHub products may cause safety hazards and
damage your personal electronic devices under charge. For a list of approved
ChargeHub Elite accessories, visit our website at:
LimitlessInnovations.com/Shop
Recommended Accessories
© Limitless Innovations, Inc.
15
+
Technical Specifications
Specifications E3005 Units
Input 100-240V / 60Hz Volts / Hertz
USB Output 5V / 4.4A Volts / Amps
Max Output 2.4A Max Per Port Amps
Type-C Power Delivery Output 5V / 3A | 9V / 3A | 12V / 2.25A Volts / Amps
Wireless Output 5V / 1A Volts / Amps
Total Power 54W Watts
© Limitless Innovations, Inc.
16
+
Limited Warranty
Your use of the product shall at all times require you to comply with all terms,
conditions of use, instructions and recommendations set forth within the User
Manual and the ChargeHub Terms and Conditions found at:
Manual: LimitlessInnovations.com/Manual/ChargeHub-Elite.pdf
Warranty Terms and Conditions: LimitlessInnovations.com/Warranty-Terms-
and-Conditions/ChargeHub-Elite
Are you having issues with your ChargeHub product?
Contact our support team today at:
LimitlessInnovations.com/Support or call us at 855-843-4828
© Limitless Innovations, Inc.
17
+
Limited Warranty cont’d
Subject to the exclusions contained below, Limitless Innovations, Inc.
(“Limitless”) warrants the ChargeHub product to be free from defects in
materials and workmanship under normal consumer usage for a period of
one (1) year from the date of original purchase, (the “ChargeHub Limited
Warranty”). As utilized herein, the term “ChargeHub” (or the singular,
ChargeHub product) shall include all products set forth above in the what’s
included section of this User Manual that may be sold by Limitless now or in
the future.
This ChargeHub Limited Warranty is a consumer’s sole and exclusive remedy
regarding any express warranty claim by a consumer and is subject to the
exclusions on the following pages:
© Limitless Innovations, Inc.
18
+
Exclusions: The ChargeHub Limited Warranty shall not apply in the event of the
occurrence of any of the following:
1. Normal Wear and Tear. The ChargeHub Limited Warranty shall not apply to
cover the maintenance, repair and/or replacement of parts or the ChargeHub
Product due to normal wear and tear by the consumer.
2. Abuse and Misuse. The ChargeHub Limited Warranty shall not cover defects
or damage that result in whole or in part from: (a) improper operation, storage,
misuse or abuse, accident or neglect by the consumer (including, without
limitation, physical damage, cracks and scratches to the surface of the ChargeHub
product); (b) contact with liquid, water, rain, extreme humidity or heavy
perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the ChargeHub
Product for commercial purposes; (d) subjecting the ChargeHub Product to
abnormal usage or conditions; and/or (e) other acts which are not the sole and
absolute fault of ChargeHub.
Limited Warranty cont’d
© Limitless Innovations, Inc.
19
+
Limited Warranty cont’d
3. Unauthorized Service or Modification. The ChargeHub Limited Warranty shall
not cover defects or damages resulting in whole or in part from service, testing,
adjustment, installation, maintenance, alteration, or modification in any way by
someone other than ChargeHub or its authorized service centers.
4. Altered Products. The ChargeHub Limited Warranty shall not cover defects or
damages to a ChargeHub Product with (a) serial numbers or date tags that have,
at any time, been removed, altered, or obliterated; (b) broken seals or evidence of
tampering; (c) mismatched board serial numbers; and/or (d) non-conforming or
non-ChargeHub housings, or components.
5. Communication Services. Defects, damage, or the failure of the ChargeHub
Products or software due to any communication service or signal you may
subscribe to or use with the ChargeHub Product or software.
© Limitless Innovations, Inc.
20
+
WHO IS COVERED?
This warranty extends only to the first consumer purchaser and is not
transferable to any third party nor applicable to any subsequent owner other
than the first consumer purchaser.
WHAT WILL CHARGEHUB DO?
If Limitless determines, in its sole and absolute discretion, that a claim is
subject to the ChargeHub Limited Warranty, it will, at its sole option, repair or
replace the ChargeHub product or alternatively, it will, in its discretion, refund
the purchase price of any ChargeHub products or software. The ChargeHub
product replacement will be with a functionally equivalent reconditioned /
refurbished / pre-owned or new ChargeHub product or part.
For additional information, visit us at:
LimitlessInnovations.com/Support or call us at 855-843-4828
Limited Warranty cont’d
© Limitless Innovations, Inc.
21
+
Limited Warranty cont’d
WHO DO I CONTACT TO MAKE A CLAIM?
In the event of any warranty claim under the ChargeHub Limited Warranty, you
can contact the telephone number below or provide a written correspondence
to the address below at which time and in response thereto, you will receive
instructions on how to ship any ChargeHub product at your expense, to a
Limitless authorized repair center. To obtain service, you must include: (a) a
copy of your receipt, bill of sale or other comparable proof of purchase; (b)
a written description of the problem; (c) the name if your service provider, if
applicable; and (d) your mailing address, email address and telephone number.
Mailing Address (Please call 855-843-4828 first to obtain RMA #)
Limitless Innovations, Inc. | 4800 Metalmaster Way | McHenry, IL 60050
WHAT OTHER LIMITATIONS ARE THERE?
ANY WARRANTY CLAIM SHALL BE LIMITED TO LIMITLESS COST OF
MATERIAL ON THE CHARGEHUB PRODUCT DETERMINED TO HAVE A
© Limitless Innovations, Inc.
22
+
MANUFACTURER’S DEFECT. IN NO EVENT SHALL LIMITLESS BE LIABLE TO
ANY PARTY FOR ANY LABOR COSTS OR ANY OTHER DIRECT, INDIRECT,
CONSEQUENTIAL, INCIDENTAL OR SPECIAL DAMAGES, WHETHER IN
CONTRACT OR TORT AND LIMITLESS EXPRESSLY DISCLAIMS LIABILITY
FOR ANY DAMAGES OF ANY KIND ARISING UNDER ANY THEORY OF
LAW WHATSOEVER. THE PERFORMANCE OF THE CHARGEHUB PRODUCT
DEPENDS ON THE PURCHASER’S ADHERENCE TO MANUFACTURER
PRODUCT INSTRUCTIONS AND LIMITLESS WILL NOT BE RESPONSIBLE
TO PURCHASER FOR ANY DEVIATIONS THEREFROM. SOME STATES
DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION
REGARDING INCIDENTAL OR CONSEQUENTIAL DAMAGES MAY NOT APPLY
TO YOU. ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION,
THE IMPLIED WARRANTY OF MERCHANTABILITY AND THE IMPLIED
WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE SHALL EXPIRE ON
THE DATE WHICH IS 1 YEAR FROM THE DATE OF FIRST PURCHASE OF THE
CHARGEHUB PRODUCT BY THE CONSUMER. SOME STATES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN
Limited Warranty cont’d
© Limitless Innovations, Inc.
23
+
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO
YOU. WITH RESPECT TO THAT PERIOD OF TIME BEYOND THE CHARGEHUB
1 YEAR LIMITED WARRANTY PERIOD, LIMITLESS DISCLAIMS AND FURTHER
MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING
BUT NOT LIMITED TO, ANY WARRANTY OF MERCHANTABILITY OR
WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE.
PLEASE NOTE THIS CHARGEHUB LIMITED WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHT, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY
FROM STATE TO STATE.
NATIONAL STATUTORY RIGHTS
CONSUMERS IN SOME JURISDICTIONS MAY HAVE LEGAL RIGHTS UNDER
APPLICABLE NATIONAL LEGISLATION GOVERNING THE SALE OF
CONSUMER GOODS, INCLUDING, WITHOUT LIMITATION, NATIONAL LAWS
IMPLEMENTING EC DIRECTIVE 99/44. THESE RIGHTS ARE NOT AFFECTED BY
THE WARRANTIES IN THIS LIMITED WARRANTY.
Limited Warranty cont’d
© Limitless Innovations, Inc.
24
+
YOUR USE OF THE CHANGE PRODUCT NAME SHALL BE GOVERNED BY
THIS CONSUMER RIGHTS AND ARBITRATION AGREEMENT, (“AGREEMENT”).
THIS AGREEMENT AFFECTS YOUR LEGAL RIGHTS AND REMEDIES BY
PROVIDING THAT DISPUTES BETWEEN YOU AND THE MANUFACTURER OF
THIS PRODUCT, LIMITLESS INNOVATIONS, INC., AN ILLINOIS CORPORATION
(“LIMITLESS”), MUST BE RESOLVED THROUGH BINDING ARBITRATION,
RATHER THAN IN A COURT. PLEASE READ THIS AGREEMENT CAREFULLY
AS YOU ACCEPT THE TERMS OF THIS AGREEMENT BY RETAINING THE
PRODUCT(S) PURCHASED IN CONNECTION WITH THIS AGREEMENT
(“PRODUCT”) FOR MORE THAN FOURTEEN (14) DAYS. IF YOU DO NOT AGREE
TO THE TERMS OF THIS AGREEMENT AND YOU PURCHASED THE PRODUCT
DIRECT FROM LIMITLESS (VIA WEB OR TELEPHONE), CALL 855-843-4828 TO
COORDINATE THE RETURN THE PRODUCT TO LIMITLESS WITHIN FOURTEEN
(14) DAYS OF RECEIPT AT NO COST TO YOU. IF YOU PURCHASED THE
PRODUCT ELSEWHERE, WITHIN FOURTEEN (14) DAYS OF PURCHASE YOU
MUST CALL 855-843-4828 AND THEN, ALSO WITHIN THIS SAME FOURTEEN
(14) DAY PERIOD, RETURN THE PRODUCT TO THE POINT OF PURCHASE. FOR
ANY QUESTIONS RELATED TO THE ABOVE, PLEASE CALL 855-843-4828.
Consumer Rights & Arbitration Agreement
© Limitless Innovations, Inc.
25
+
RESOLUTION OF CLAIMS OR DISPUTES
Any claim or dispute between you and Limitless arising out of or relating in any
way to the Product or this Agreement shall be resolved through final, binding
arbitration. This arbitration obligation applies regardless of whether the claim
or dispute involves a tort, fraud, misrepresentation, product liability, negligence,
violation of a statute, or any other legal theory. Both you and Limitless
specifically acknowledge and agree that you waive your right to bring a lawsuit
based on such claims or disputes and to have such lawsuit resolved by a judge
or jury.
LIMITATION OF LEGAL REMEDIES
All arbitrations under this Agreement shall be conducted only on an individual
(and not a class-wide) basis and an arbitrator shall have no authority to award
class-wide relief. You acknowledge and agree that this Agreement specifically
prohibits you from commencing arbitration proceedings as a representative of
others or joining in any arbitration proceedings brought by any other person.
Consumer Rights & Arbitration Agreement cont’d
© Limitless Innovations, Inc.
26
+
ARBITRATION PROCEDURES
Before commencing any arbitration proceedings under this Agreement, you
must first present the claim/dispute to Limitless by calling 855-843-4828,
providing requested contact information and allowing Limitless the opportunity
to resolve it. If your claim or dispute is not resolved within sixty (60) days, you
may commence arbitration proceedings in accordance with the terms of this
Agreement. The arbitration of claim(s)/dispute(s) under this Agreement shall
be pursuant to the American Arbitration Association’s (“AAA”) United States
Commercial Dispute Resolution Procedures and Supplementary Procedures for
Consumer-Related Disputes (see www.adr.org for their rules and procedures).
The arbitration of any claim/dispute under this Agreement shall be in the
State of Illinois or the location in which you received this Agreement. All
administrative expenses of arbitration proceedings under this Agreement shall
be divided equally between you and Limitless, except that: (a) if the claim/
dispute subject to the arbitration proceedings is less than ten thousand dollars
(US $10,000), you will be responsible for no more than one hundred twenty-
five dollars (US $125) in administrative expenses;
Consumer Rights & Arbitration Agreement cont’d
© Limitless Innovations, Inc.
27
+
(b) if the claim or dispute subject to the arbitration proceedings is more than
ten thousand dollars (US $10,000), but less than seventy-five thousand dollars
(US $75,000), you will be responsible for no more than three hundred seventy-
five dollars (US $375) in administrative expenses; and(c) if the claim/dispute
subject to the arbitration proceedings is more than seventy-five thousand
dollars (US $75,000), then you will be responsible for administrative expenses
in accordance with the Commercial Fee Schedule provided by the AAA. You
acknowledge and agree that each party shall pay the fees and costs of its own
counsel, experts and witnesses.
CHOICE OF LAW & SEVERABILITY
This Agreement shall be governed by the United States Federal Arbitration
Act and the laws of the state of Illinois. If any provision of this Consumer
Rights and Arbitration Agreement is declared or found to be unlawful,
unenforceable or void, such provision will be ineective only to the extent that
it is found unlawful, unenforceable or void and the remainder shall remain fully
enforceable.
Consumer Rights & Arbitration Agreement cont’d
© Limitless Innovations, Inc.
28
+
Consumer Rights & Arbitration Agreement cont’d
EXPORT LAW ASSURANCES
This product is controlled under the export regulations of the United States
of America. The Government of the United States of America may restrict the
exportation or re-exportation of this product to certain destinations. For further
information contact the U.S. Department of Commerce and International Trade
Commission.
© Limitless Innovations, Inc.
29
+
All ChargeHub products and information shared in this manual are protected
by copyright. Copying, reproducing, reverse engineering or distributing any
information of ChargeHub-related products hardware or software without a
formal and written authorization and license from Limitless Innovations, Inc. is
prohibited and may result in legal action to the full extent of the law.
Copyright Notice
© Limitless Innovations, Inc.
30
+
“This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.”
“WARNING: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.”
“NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications.”
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected. Consult the dealer or an experienced radio/TV technician for help.
FCC Notice
All rights reserved. ChargeHub is a trademark of Limitless Innovations,
Inc. Design and specifications subject to change without notice. All other
trademarks included herein are property of their respective owners. Cable
adapters sold separately. Electronic devices not included.
Innovated in USA | Made in China
Phone: (855) 843-4828
Email: Sales@LimitlessInnovations.com
Website: LimitlessInnovations.com
© Limitless Innovations, Inc.
+
E3005
