AUTOOL BT760 battery tester adopts the world’s most advanced
conductance testing technology, it is designed with built-in printer.
BT760 can quickly and accurately measure the actual cold
starting current of the starting batteries of automobiles and motor-
cycles, the health condition of the batteries, and it can quickly
detect common failures of the starting systems and charging
systems of cars and motorcycles, which is convenient for the rapid
maintenance of cars and motorcycles.
1. PRODUCT SUMMARY
1.1
Product
profile
BT760 can do tests on automotive and motor batteries such as
battery test, cranking test, charging test and maximum load
test.
Test all automotive cranking lead acid battery, including
ordinary lead acid battery, AGM flat plate battery, AGM spiral
battery, and Gel battery, etc.
Directly detect bad cell battery.
Polarity reverse connection protection, reverse connection will
not damage the tester or affect the vehicle and battery.
Directly test the battery with power shortage, no need to fully
charge it before testing.
Testing standards include currently the world’s majority of
battery standards, CCA, JIS, DIN, IEC, EN, SAE, GB.
Support multiple languages, customer can select different
language package, which including English, French, Deutsch-
land, España, Português, Italien, Russia, etc. Other custom-
ized language version are also provided.
●
●
●
●
●
●
●
Battery test is mainly targeted to analyze the battery healthy
status to calculate the actual cold cranking capability of the
battery and the aging extent, which provide reliable analysis
evidence for the test and maintenance of the battery. It notifies
the user to replace battery in advance when the battery getting
aged.
Cranking test is mainly to test and analyze the starting motor.
Through testing the actual required cranking current and
cranking voltage of the starting motor, it can find out whether
the starting motor works fine. There are several reasons why
the starting motor is abnormal: lubricating system fault causing
the starting loaded torque increasing or rotor friction of the
starting motor causing the increasing friction of the starting
motor itself.
Charging test is to check and analyze the charging system,
including generator, rectifier, rectifier diode, etc., thus to find
out whether the output voltage of the generator is normal, the
rectifier diode works fine and the charging current is normal.
Suppose one of the above mentioned parts is not in normal
situation, it will lead to over charge or incomplete charge of the
battery, thus the battery will be quickly damaged and also
greatly shorten the using life of other loaded electrical
appliance.
Load test is the test of battery pack, DC power supply, UPS
backup battery maintenance and capacity detection.
Additional functions include: language setting, voltmeter
and screen brightness adjustment.
3
2. PRODUCT FUNCTION
●
●
●
●
●
4
3. TECHNICAL PARAMETERS
Cold cranking amps measure range
CCA
DIN
IEC
EN
GB
30-2000
30-2500
30-2500
30-3000
4-300AH
JIS
26A17-245H52
Voltage Measure Range
Current Measure Range
Working temperature
Shell material
6~30V DC
4AH~240AH
-20°C~50°C
Acid resistant ABS material
It is applicable for automotive manufacturers, automotive mainte-
nance and repair workshops, automotive battery factories, automo-
tive battery distributors, and educational organizations, etc.
* When the measured battery voltage is lower than 6.0V, the
normal test cannot be performed. Press OK to continue.
Shake the clamps back and forth to make sure they are well
connected.
Tester requires the two clamps well connected with the battery
poles, otherwise, the test can not go on.
The red to the positive and the black to the negative, then the
tester display will show the starting interface.
4.1
Pre-test
5
4. WORKING STEPS
4.1.1 Connect tester
4.1.2 Key description
●
●
●
Up / Down / Left / Right / Key (B, G, D, F) - Select upwards or
downwards via white UP and DOWN keys.
Return key (A) - Return to previous menu via return key.
OK key (E) - Confirm the selection via green OK key
Print key (C)
●
●
●
●
A
B
D
E
F
G
C
According to the tester’s prompt, press the up and down keys to
select in sequence:
① – Battery system test
② – Starting system test
③ – Charging system test
④ – Load test
⑤ – Language setting
⑥ – Help
Press UP / DOWN key to select the Language, include English,
French, Deutschland, España, Português, Italien, Russia, etc.
4.2
Start tester
4.3
Select
language
6
Battery Test Cranking Test
Charging Test Load Test
Languages Help
Battery Test
Cranking Test
Charging Test
Load Test
Languages Help
Language Selection
English
Português
España
French
Deutschland
Italien
Russia
Turki ye
日本語
ไทย
Language Selection
繁体中文
한국어
1) After entering battery test program,tester will show the battery
types for you to choose.
2) After choosing right battery type, the tester will display the
following content.
3) Press OK key to Start Testing.
Regarding internal resistance, for the same battery, the smaller
the internal resistance, the better the health status (except for
short circuit). The internal resistance value can be used as a
reference for the state judgment standard of a certain range of
battery performance.
4.4
Battery test
7
Battery Test Cranking Test
Charging Test Load Test
Languages
Help
Batte Test
SELECT BATTERY TYPE
REGULAR FLOODED
GEL
AG M FL AT PL ATE
AGM SPIRAL
EFB
OTHER TYPE
Batte Test
SELECT STANDARD
CCA (USA)
IEC (International)
EN (Europe)
DIN (Germany)
JIS (Japan)
Other Species
Batte Species
Set Rated Value
Press <OK> To Start
500 A (CCA)
Batte Test
Voltage:
Current:
Resistance:
Batt. Energy
Life:
Result:
12.77 V
500 A(CCA)
5.27 mΩ
96%
99%
Good
PRINT
After the battery test is completed, press the up and down keys to
select the starter system test, and press the OK key to enter the
test state.
4.5
Cranking
test
8
NOTE:
When the battery voltage is lower than the normal test voltage,
the test value cannot correctly determine the battery usage
status, and the test result will display “Charge Retest”. At this
time, you need to charge the battery before testing.
When the battery voltage is too high or the vehicle is running,
the test cannot be performed normally, it will prompt “The
voltage is too high, please stop the fire! Turn on the headlights
for 3 minutes before measuring”.
For batteries that are deeply in deficit (such as when the
vehicle is not in use for a long time and the battery is not
charged in time; the lights and car doors are forgotten to be
closed, causing the battery to fail due to severe battery failure
and cannot start the vehicle, etc.), the actual detection process
may also prompt “Please replace the battery”. Such a battery,
please consult the battery manufacturer first, and perform the
test after charging and restoring according to the charging
method provided by the manufacturer.
Battery Test Cranking Test
Charging Test Load Test
Languages
Help
Staer System Test
Current voltage:
Minimum voltage:
Start
Min Value >
>> Please start the engine
and wait 15 seconds.
12.20V
12 .18V
9.6V
PRINT
Staer System Test
Current voltage:
Minimum voltage:
Start
Min Value >
12.20V
12 .18V
9.6V
PRINT
In the main menu, press the up and down keys to select the
charging system test. Press the OK key to enter the test. At this
time, start the engine. After waiting for stable operation, press the
OK key to display the test status.
4.6
Charging
test
9
The charging voltage of the charging system is insufficient.
Please check the generator drive belt for slippage or discon-
nection, and check whether the line connection between the
generator and the battery is normal.
If the transmission belt and line are well connected, please
follow the suggestions of automobile and motorcycle manufac-
turers to eliminate the generator fault.
The generator output voltage is too high.
Since most car generators use built-in regulators, you need to
replace the generator assembly (some older cars use external
regulators, please replace the regulators directly).
NOTE:
Please do not shut down the engine during the test. Other electri-
cal equipment should be turned off. If any electrical appliances in
the car are switched on or off during the test, it can affect the
accuracy of the test results.
* Under different engine operating conditions, the battery
voltage will be different. Under normal conditions, the charging
voltage will not be lower than the minimum value of 13.3V, and it
should not be higher than 15.0V at high speeds.
* Charging voltage is too low:
* Charging voltage is too high:
Battery Test
Cranking Test
Charging Test
Load Test
Languages Help
Charging System
>> Please start the engine
and wait 15 seconds.
>> Press <OK> to continue!
Charging System
Maximum voltage:
14.35V <15.0V Normal
Current voltage:
14.34V
Minimum voltage:
14.27V >13.3V Normal
PRINT
In the main menu, press the up and down keys to select the load
test, and press the OK key to enter the test, notice:
Start the engine at this time, wait for the operation to stabilize, and
then press OK to display the test status.
When all electrical appliances are turned on, under normal
circumstances, the power supply capacity of the generator is
sufficient, and the charging voltage will be greater than 12.8V. If it
is lower than this voltage value, the reason may be that the gener-
ator output current is insufficient, the generating power is
reduced, or the appliance excessive load or leakage occurs; if the
electric appliances on the car are artificially increased, the
voltage will also decrease.
4.7
Maximum
load test
10
The usual high voltage limit for automotive regulators is 14.7V.
Excessive charging voltage can overcharge the battery, which
shortens the battery life and causes it to malfunction.
Battery Test Cranking Test
Charging Test Load Test
Languages Help
Maximum Load Testing
Current voltage:
Minimum voltage:
ON
Min Value >
14.06V
14.09V
12.89V
PRINT
Maximum Load Testing
>> Please start the engine
and wait 15 seconds.
>> Please turn on all electric.
>> Press <OK> to continue!
11
After the battery system test is completed, there is a “print” item in
the lower right corner of the screen. At this time, press the short-
cut key of “select print function”, the printer of the tester will start
to work, and the test result data of the battery system will be
displayed on the print paper.
Start test result, charge test result and maximum load test result
printing, all of which are printed in the same way as battery test
result printing.
5.1
Printing data
5.2
5. PRINTING DATA
If you want to print four data items on the printing paper at the
same time, please do not tear off the printing paper until the
four data items are printed.
NOTE:
12
Be careful not to rub the product against rough surfaces or
wear the product, especially the sheet metal housing.
Please regularly check the product parts that need to be
tightened and connected. If found loose, please tighten it in
time to ensure the safe operation of the equipment. The exter-
nal and internal parts of the equipment in contact with various
chemical media should be frequently treated with anti-corrosion
treatment such as rust removal and painting to improve the
corrosion resistance of the equipment and extend its service
life.
Comply with the safe operating procedures and do not
overload the equipment. The safety guards of the products
are complete and reliable.
Unsafe factors are to be eliminated in time. The circuit part
should be checked thoroughly and the aging wires should be
replaced in time.
Regularly clean and replace consumable parts such as oil
pump and oil filter; adjust the clearance of various parts and
replace worn (broken) parts. Avoid contact with corrosive
liquids.
When not in use, please store the product in a dry place. Do
not store the product in hot, humid, or non-ventilated places.
Our products are made of long-lasting and durable materials, and
we insist on perfect production process. Each product leaves the
factory after 35 procedures and 12 times of testing and inspec-
tion work, which ensures that each product has excellent quality
and performance.
To maintain the performance and appearance of the product, it is
recommended that the following product care guidelines be read
carefully：
●
●
●
●
●
●
6. MAINTENANCE SERVICE
Maintenance
13
7. WARRANTY
The repair or replacement of products is determined by the
actual breakdown situation of product.
It is guaranteed that AUTOOL will use brand new component,
accessory or device in terms of repair or replacement.
If the product fails within 90 days after the customer receives
it, the buyer should provide both video and picture, and we will
bear the shipping cost and provide the accessories for the
customer to replace it free of charge. While the product is
received for more than 90 days, the customer will bear the
appropriate cost and we will provide the parts to the customer
for replacement free of charge.
The product is not purchased through official or authorized
channels.
The product breakdown because the user does not follow
product instructions to use or maintain the product.
From the date of receipt, we provide a three-year warranty for the
main unit and all the accessories included are covered by a
one-year warranty.
We AUTOOL pride ourselves on superb design and excellent
service. It would be our pleasure to provide you with any further
support or services.
All information, illustrations, and specifications contained in this
manual, AUTOOL resumes the right of modify this manual and the
machine itself with no prior notice. The physical appearance and
color may differ from what is shown in the manual, please refer to
the actual product. Every effort has been made to make all
descriptions in the book accurate, but inevitably there are still
inaccuracies, if in doubt, please contact your dealer or AUTOOL
after-service centre, we are not responsible for any consequences
arising from misunderstandings.
●
●
●
●
●
Warranty
access
Disclaimer
14
China
Oversea Zone
E-mail
Facebook
YouTube
400-032-0988
+86 0755 23304822
aftersale@autooltech.com
https://www.facebook.com/autool.vip
https://www.youtube.com/c/autooltech
If you are an AUTOOL user and are not satisfied with the
AUTOOL products purchased from the online authorized
shopping platform and offline authorized dealers, you can
return the products within seven days from the date of receipt;
or you may exchange it for another product of the same value
within 30 days from the date of delivery.
Returned and exchanged products must be in fully saleable
condition with documentation of the relevant bill of sale, all
relevant accessories and original packaging.
AUTOOL will inspect the returned items to ensure that they
are in good condition and eligible. Any item that does not pass
inspection will be returned to you and you will not receive a
refund for the item.
You can exchange the product through the customer service
center or AUTOOL authorized distributors; the policy of return
and exchange is to return the product from where it was
purchased. If there are difficulties or problems with your return
or exchange, please contact AUTOOL Customer Service.
●
●
●
●
8. RETURN & EXCHANGE SERVICE
Return &
Exchange
声明
退换货服务
退换货
15
目 录
版权信息.............................................................................................................. 17
版权................................................................................................................. 17
注册商标.......................................................................................................... 17
注意事项............................................................................................................. 18
警告................................................................................................................. 18
产品简介.............................................................................................................. 19
概述................................................................................................................. 19
功能................................................................................................................. 19
特点 ................................................................................................................. 19
参数................................................................................................................. 20
产品结构 ............................................................................................................. 21
结构图............................................................................................................. 21
操作方法 ............................................................................................................. 22
预测试 ............................................................................................................. 22
测试仪启动 ...................................................................................................... 22
选择语言.......................................................................................................... 22
电池测试.......................................................................................................... 23
启动测试.......................................................................................................... 24
充电测试.......................................................................................................... 24
最大负荷测试.................................................................................................. 25
打印测试数据/帮助............................................................................................ 26
电池测试打印 .................................................................................................. 26
其它测试打印.................................................................................................. 26
帮助................................................................................................................. 26
维修保养服务..................................................................................................... 27
维修保养.......................................................................................................... 27
保修服务............................................................................................................. 28
保修访问.......................................................................................................... 28
16
声明................................................................................................................. 28
退换货服务......................................................................................................... 29
退换货............................................................................................................. 29
目 录
版权信息
版权
注册商标
注意事项
警告
产品简介
概述
功能
特点
参数
产品结构
结构图
操作方法
预测试
测试仪启动
选择语言
电池测试
启动测试
充电测试
最大负荷测试
打印测试数据/帮助
电池测试打印
其它测试打印
帮助
维修保养服务
维修保养
保修服务
保修访问
17
版权信息
偶然公司已在中国及海外若干国家进行了商标注册，其标志为
。本手册所提及之偶然公司其它商标、服务标志、域名、图
标、公司名称均属偶然及其下属公司之产权。在偶然公司之商标、服
务标志、域名、图标、公司名称还未注册之国家，偶然公司声明其对
未注册商标、服务标志、域名、图标、公司名称之所有权。本手册所
提及之其它产品及公司名称的商标仍属于原注册公司所有。在未得
到拥有人的书面同意之前，任何人不得使用偶然公司或所提及的其
它公司之商标、服务标志、域名、图标、公司名称。
您可以访问偶然网址:www.autooltech.com，或发送邮件至：
aftersale@autooltech.com，与偶然公司进行联系，征得其手册使
用权之书面同意。
版权所有!未征得深圳市偶然科技有限公司的书面同意，任何公
司或个人不得以任何形式（电子、机械、影印、录制或其他形式）
对本说明书进行复制和备份。本手册专为偶然公司产品的使用
而计，对于将之用于指导其他设备操作而导致的各种后果，本公
司不承担任何责任。
因使用者个人或第三方的意外事故，滥用、误用该设备，擅自更
改，或修理该设备，或未按偶然公司的操作与保养要求而导致设
备损坏、遗失所产生的费用及开支等，偶然公司及其分支机构不
承担任何责任。
正式声明: 本说明书所提及之其他产品名称，目的在于说明该设
备如何使用，其注册商标所有权仍属原公司。
本设备供专业技术人员或维修人员使用。
●
●
●
●
版权
注册商标
18
注意事项
非技术人员不得私自改造，拆卸或维修本产品。
请勿刺划、弯折、扭曲、拉伸电线，且勿将电线置于高温处。
请勿将钉子、针等其他细小杂物置于线路接口，以免损坏。
请勿将产品置于斜面、支架等不稳的位置使用。
使用本产品请仔细阅读本说明书。
本产品通电使用，请勿让儿童当玩具使用。
请勿把本产品浸入水或其他液体中，可能发生短路。
请勿自行拆卸修理本产品，否则会带来保修损失的风险。
请尽量使用本产品标配连接线。
使用仪器前，请仔细阅读本手册以正确操作。
警告
19
产品简介
概述
功能
特点
BT760蓄电池检测仪，采用目前世界上最先进的电导测试技术，可
以方便、快速、准确地测量汽车启动电池的实际冷启动电流能力，电
池本身的健康程度，以及快速检测汽车启动系统和充电系统的常见
故障，有利于维修人员快速准确判断汽车的故障位置，便于汽车的
快速维修。
●
●
●
●
●
●
●
●
●
BT760电池测试仪的主要功能包括：电池测试、启动测试、充电
测试和其他附加功能。
测试所有汽车启动式铅酸电池，包括普通铅酸电池、AGM平板电
池、AGM螺旋电池和凝胶电池等。
直接检测出坏电池。
极性反接保护，反接不会损坏测试仪或影响车辆和电池。
直接测试电池是否断电，测试前无需充满电。
测试标准包括当前世界上大多数的电池标准: CCA、JIS、DIN、
IEC、EN、SAE、GB。
支持多国语言，客户可以选择不同的语言包，包括：英语、葡萄牙
语、西班牙语、法语、德语、意大利语、 俄语、土耳其语等。其他语
言也可以根据用户需要定制。
快速测试摩托车、汽车12V/24V蓄电池冷启动电流、内阻、电池
寿命及剩余电量，判定蓄电池是否需要更换。
检测12V/24V汽车启动系统和充电系统，可通过电压负荷测试检
测发电机供电能力，并打印出测试结果。
●
●
●
●
●
快速、准确地显示蓄电池测试结果。
显示蓄电池目前的健康状况，直接检测出坏格电池。
直接打印检测结果。
可以直接测试亏电的蓄电池。
不发热、无火花、无操作危险。
20
参数
测量标准与测量范围
CCA
DIN
IEC
EN
GB
30-2000
30-2500
30-2500
30-3000
4-300AH
JIS 26A17-245H52
工作温度
外壳材料
测量电池范围
测量电压范围
-20℃ ~ 50℃
耐酸 ABS 塑料
4AH-240AH
6~30V
21
产品结构
结构图
打印端口
电夹
A
C
3.2寸高清彩屏
功能按键
B
D
ESC键
E
打印按钮
F
B
C
D
F
A
E
22
操作方法
前后摇动夹子，以确保它们连接牢固。
测试仪要求两个夹子与电池两极连接良好，否则测试将无法进
行。
当进入电池测试程序时，屏幕提示按任意键继续。
测试仪具有反向连接保护功能。反向连接夹具时，测试仪的屏幕
不会亮起，也不会损坏测试仪或汽车负载。
预测试
测试仪启动
选择语言
连接测试仪
●
●
●
●
注意
对于并联电池，请先断开阴极连接，然后对每个电池进行一次测
试。假设未断开阴极连接，则测试结果会有误差。
正确连接夹具后，测试仪会自动启动，并显示功能主界面，见下图。
按上/下/左/右键选择语言，包括英语、葡萄牙语、西班牙语、法语、
德语、意大利语、俄语、土耳其语、泰语、日本语、繁体中文、韩语
等，见下图。
電瓶測試
Battery Test Cranking Test
Charging Test Load Test
Languages
Help
23
电池测试
输入正确的测试标准和等级，按[OK]键，测试仪开始测试，并提示
“测试中，请稍后”，2秒后，测试仪将显示电池测试结果，见下图。
进入电池测试程序后，测试仪将显示电池类型选择，见下图。
输入电池规格，见下图。
語言設置
繁体中文
한국어
語言設置
Battery Test
Cranking Test
Charging Test Load Test
Languages Help
語言設置
English
Português
España
French
Deutschland
Italien
Russia
Turki ye
日本語
ไทย
電瓶測試
電池類型選擇
普通電池
GEL膠體電池
AGM平板電池
AGM卷式電池
EFB卷式電池
其他類型電池
電瓶測試
測試標準選擇
CCA 冷啟動電流
IEC 國際電子協會
EN 歐洲標準
DIN 德國標準
JIS 日本工業標準
其他規格
電瓶規格輸入
設定
按 <OK> 開始分析
500A（CCA)
電瓶測試結果
電池電壓
測量值
內阻
充電量
壽命
測試結果
12.77 V
500 A(CCA)
5.27 m Ω
96%
99%
好
打印
24
启动测试
充电测试
进入启动测试程序后，测试仪将显示启动系统检测，并提示“启动
发动机，等待15秒！”见下图。
启动发动机，等待15秒后，测试仪将显示启动系统检测结果，见下
图。
进入充电测试程序后，测试仪将提示“启动发动机，等待15秒！”按
[OK]键开始检测，见下图。
啟動系統檢 測
目前
最低
啟動時
最低應大於
12.20V
12.18V
9.6V
打印
啟 動系統 測試
Battery Test Cranking Test
Charging Test Load Test
Languages
Help
啟動系統檢 測
目前
最低
啟動時
最低應大於
啟動發動機， 等待15秒！
12.20V
12.18V
9.6V
打印
充電系統測試
Battery Test Cranking Test
Charging Test Load Test
Languages Help
充電系統檢測
啟動發動機， 等待15秒！
按 <OK> 键开始检测
25
最大负荷测试
启动发动机，等待15秒后，测试仪将显示充电系统检测结果，见下
图。
进入最大负荷测试程序后，测试仪将提示“请开启全部用电设备，启
动发动机，等待15秒！”按[OK]键开始检测，见下图。
开启全部用电设备后，启动发动机，等待15秒！按[OK]键开始检测
后，测试仪将显示最大负荷测试结果，见下图。
充電系統檢測
最高
14.35V<15.0V正常值
目前
14.34V
最低
14.27V>13.3V正常值
打印
最大負荷測試
目前
最低
全開時
最低應大於
14.0 6V
14.09V
12.89V
打印
最大負荷測試
Battery Test
Cranking Test
Charging Test Load Test
Languages
Help
最大負荷測試
啟動發動機， 等待15秒！
請開放全部用電設備
按 <OK> 键开始检测
26
打印测试数据/帮助
电池测试打印
其它测试打印
帮助
电池系统测试完成后，屏幕右下角有一项“打印”，此时可按[选打
印功能]快捷键，测试仪自带的打印机开始工作，打印纸上将显示电
池系统检测结果数据。
进入帮助程序后，测试仪显示电池表格。此表格有三页，可按[左/右]
键选择。
启动测试打印，充电测试打印，最大负荷测试打印，这三项数据打
印都与电池测试打印方式相同。
27
维修保养服务
●
●
●
●
●
注意不要将产品与粗糙表面摩擦或揉搓产品，特别是钣金外壳。
对产品中需要紧固和连接的部位经常进行检查，如发现松动应及
时紧固，以保证产品的安全运行。对与各种化学介质接触的产品
外部和内部零件要经常进行除锈、喷漆等防腐处理，以提高产品
的抗腐蚀能力，延长产品的使用寿命。
遵守安全操作规程，不超负荷使用产品。产品的安全防护装置齐
全可靠，及时消除不安全因素。电路部分彻底检查，老化电线要
及时更换。
调整各部位配合间隙和更换磨损（已坏）部件清洁时，避免产品
接触带腐蚀性的液态物品。
不使用时，请将产品存放于干燥的位置。不要将产品存放在高温、
潮湿或不通风的地方。
您所拥有的AUTOOL产品选用持久耐用的材料，AUTOOL坚持精益求
精的生产工艺，每一件产品出厂都经过35道工序及12次质检工作，从
而确保每一件产品都拥有卓越的品质及性能。所以您的AUTOOL产
品值得您定期维护保养，使其产品将能够长期稳定地工作。
维护保养是为了保持产品性能和外观，我们建议您仔细阅读以下产
品保养 指南：
维修保养
28
保修服务
保养方式
声明
●
●
●
●
●
根据具体的故障情况对产品进行免费修理或更换；
我方保证所有更换的部件、附件或产品都是全新；
在客户收到产品90天内出现故障同时提供视频和图片，我方承
担运费并免费提供相应配件给客户更换。收到产品超过90天，客
户承担相应的费用，我方免费提供配件给客户更换；
非正规 渠道 购买AUTOOL的产品；
未按产品说明书要求使用和维护造成的损坏；
在AUTOOL，我们为精湛的设计和卓越的服务感到自豪。我们很乐
意为您提供更多的支持或服务。
偶然公司保留更改产品设计与规格的权利，届时恕不另行通知。实
物外观与颜色可能与说明书中显示的有差别，请以实物为准。我们
已尽最大努力力求使书中所有描述准确，但仍难免有不妥之处。如
有疑问，请联系经销商或偶然售后服务中心。本公司对产品拥有最
终解释权，不承担任何因误解而产生的后果。
以下情况不在免费保修范围：
AUTOOL主机自客户签收日起享有3年保修期。其所含附件自客户签
收日起享有1年保修期。
29
退换货服务
●
●
●
●
●
如果您对从线上授权购物平台和线下授权经销商所购买的
AUTOOL产品不满意，根据《AUTOOL全球销售条款》，您可以自
收到产品之日起七日内退货；或者在产品交付之日起的30日内调
换等值的其他产品。
退回及调换的产品必须处于完全可销售状态，并附上相关销售单
单据，所有相关配件、纸质发票（如有）。
AUTOOL将会对寄回退货的商品进行检查，以确保其处于完好无
损的状态并且符合条件，相关条件详情请参阅《AUTOOL全球销
售条款》。任何未通过检查的商品将退还给您，您将不会获得商
品退款。
您可以通过客户服务中心或AUTOOL授权经销商调换产品；退换
货原则为从哪里购买，就从哪里退换货。如果您退换货遇见困难
或者阻碍，请联系AUTOOL客户服务中心。通过客户服务中心退
换货时，我们建议您通过下面的方式进行：
如您的退换货得到确认，您将收到确认信息和邮件。
中国区域致电
售后微信号
海外区域致电
E-mail
Facebook
YouTube
400-032-0988 / 18929303778
18929303778
+86 0755 23304822
aftersale@autooltech.com
https://www.facebook.com/autool.vip
https://www.youtube.com/c/autooltech
退换货
