ETB4600B
EN Refrigeration
User manual
A12081681-A-302021
CONTENTS
1. SAFETY INFORMATION ............................................................................................................... 3
2. SAFETY INSTRUCTION .............................................................................................................. 4
3. DESCRIPTION OF THE APPLIANCE ...................................................................................... 6
4.
TEMPERATURE CONTROL ......................................................................................................... 8
5.
INSTALLING YOUR NEW REFRIGERATOR ......................................................................... 11
6.
USING YOUR REFRIGERATOR ................................................................................................ 1
2
7.
CLEANING THE REFREIGERATOR FOOD ......................................................................... 14
8.
FOOD STORAGE GUIDE ........................................................................................................... 15
9.
TROUBLESHOOTING .................................................................................................................. 16
10.
NOISES ............................................................................................................................................... 19
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings
with it decades of professional experience and innovation. Ingenious and stylish, it
has been designed with you in mind. So whenever you use it, you can be safe in the
knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website to:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Register your product for better service:
www.electrolux.com/productregistration
Buy Accessories, Consumables and Original spare parts for your
appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available. The
information can be found on the rating plate. Model, PNC, Serial Number
Warning / Caution-Safety information.
General information and tips
Environmental information.
Subject to change without notice.
2 www.electrolux.com
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read the
supplied instructions. The manufacturer is not responsible if an
incorrect installation and use causes injuries and damages. Always
keep the instructions with the appliance for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Cleaning and user maintenance shall not be made by
children without supervision.
1.2 General Safety
• This appliance is intended to be used in household and
similar applications such as:
– Farm houses; staff kitchen areas in shops, offices and
other working environments
– By clients in hotels, motels, bed and breakfast and other
residential type environments
• Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
• Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
• Do not use water spray and steam to clean the appliance.
• Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
• Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
English 3
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons
in order to avoid a hazard.
• If the appliance is equipped with an Ice maker or a water
dispenser, ll them with potable water only.
• If the appliance requires a water connection, connect it to
potable water supply only.
• The inlet water pressure (minimum and maximum)must be
between 1 bar (0,1 MPa) and 10 bar (1 MPa)
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualied person must install
this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Obey the installation instruction
supplied with the appliance.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Make sure the air can circulate around
the appliance.
• Wait at least 4 hours before connecting
the appliance to the power supply. This
is to allow the oil to ow back in the
compressor.
• Do not install the appliance close to
radiators or cookers, oven or hobs.
• The rear of the appliance must stand
against the wall.
• Do not install the appliance where there
is direct sunlight.
• Do not install this appliance in areas
that are too humid or too colds, such
as the construction appendices,
garages or wine cellars.
• When you move the appliance, lift it by
the front edge to avoid scratching the
oor.
2.2 Electrical connection
WARNING!
Risk of re and electrical shock.
• The appliance must be earthed.
• All electrical connections should be
made by a qualied electrician.
• Make sure that the electrical information
on the rating plate agrees with the
power supply. If not, contact an
electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
electrical components (e.g. mains plug,
mains cable, compressor). Contact the
Service or an electrician to change the
electrical components.
• The mains cable must stay below the
level of the mains plug.
• Connect the mains plug to the
mains socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
4 www.electrolux.com
2.3 Use
WARNING!
Risk of injury, burns, electrical
shock or re.
• Do not change the specication of this
appliance.
• Do not put electrical appliances (e.g.
ice cream makers) in the appliance
unless they are stated applicable by the
manufacturer.
• Be careful not to cause damage to the
refrigerant circuit. It contains isobutane
(R600a), a natural gas with a high level
of environmental compatibility. This gas
is ammable.
• If damage occurs to the refrigerant
circuit, make sure that there are no
ames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the plastic
parts of the appliance.
• Do not put soft drinks in the freezer
compartment. This will create pressure
on the drink container.
• Do not store ammable gas and liquid
in the appliance.
• Do not put ammable products or items
that are wet with ammable products
in, near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
• Do not remove or touch items from the
freezer compartment if your hands are
wet or damp.
• Do not freeze again food that has been
thawed.
• Obey the storage instructions on the
packaging of frozen food.
2.4 Internal light
• The type of lamp used for this appliance
is not suitable for household room
illumination.
2.5 Care and cleaning
WARNING!
Risk of injury or damage to the
appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• This appliance contains hydrocarbons
in the cooling unit. Only a qualied
person must do the maintenance and
the recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If
the drain is blocked, defrosted water
collects in the bottom of the appliance.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children
and pets to be closed inside of the
appliance.
• The refrigerant circuit and the insulation
materials of this appliance are ozone-
friendly.
• The insulation foam contains ammable
gas. Contact your municipal authority
for information on how to discard the
appliance correctly.
• Do not cause damage to the part of
the cooling unit that is near the heat
exchanger.
English 5
Features may vary depending on model. Not all models will have features listed.
Refrigerator/freezer
control panel
From this panel you can control the temperature of the
refrigerator and freezer compartments as well as setting
the Boost function, controlling the Ice Maker or resetting
the door alarm.
For further information on how to use this feature refer
to the section “About the User Interface”.
Bottle storage bin
Use the bottle bin for tall
bottle storage. The bottle
bin can be removed by
lifting it up over the
support lugs. To replace,
push down over the
support lugs to lock in
place.
Door storage bin
The door bin can be
removed by lifting it up
over the support lugs.
To replace, push down
over the support lugs to
lock in place.
Freezer temperature
control
Refer to the section
“Temperature Control”
for details on using this
feature.
Twist & Serve Ice
Refer to the section
“Using your
Refrigerator” for details
on removing,
relocating and using
this feature.
Chiller drawer
Use the chiller drawer
to store foods like small
goods, fresh or cooked
meat and cheese, or as
an additional crisper.
The drawer will prevent
strong food odours
from impacting the rest
of the refrigerator. To
remove the chiller
drawer, pull it forward,
then lift it up and pull it
further forward.
TasteGuard Deodoriser
NutriPlus
TM
Anti-Oxidant Filter
Crisper
Use the crisper to store
vegetables, fruit or small
goods.
FlexStor® door bins
Slide the bins to meet
different storage needs.
To remove, lift and tilt.
To replace, tilt the top
and push down until
locked in place.
Egg tray
Removable egg tray
provided for your
convenience.
TOP MOUNT REFRIGERATOR FEATURES
Temp
Less
Cold
Mid
Colder
Quick
Chill
Quick Chill
Hold 3sec
EMT85610X
illustrated
ETB4600B
6 www.electrolux.com
TEMPERATURE CONTROL
If you want to change the temperature, follow the instructions in the section About the User Interface for your model.
Ensure that you make only small adjustments and wait 24 hours to see if it’s to your liking.
IMPORTANT
NOTE : When you set a temperature, you set an average temperature for the whole refrigerator cabinet.
Checking the softness of ice cream is a good indication that your freezer is the right temperature, while checking the
temperature of water kept in the refrigerator is a good way of checking the temperature of the food compartment.
Temperatures inside each compartment may vary, depending on how much food you store and where you place it.
High or low room temperature may also affect the actual temperature inside the refrigerator.
Top mount freezer temperature adjustment
1. Select the freezer control.
2. Slide the control to the right (as per image below).
3. Slide the control to the left (as per image below).
FREEZER TEMPERATURE SETTING RECOMMEDATION
Set to less cold
Summer (>35°c)
Normal
Winter (<15°c) Set to colder
Freezer Temp
Freezer Temp
Freezer Temp
Less
Cold
Less
Cold
Less
Cold
Colder
Colder
Colder
English 7
ABOUT THE USER INTERFACE
Control – ETB4600B Model
Quick chill on/off icon
Temperature
adjust/quick chill
on/off button
Refrigerator
temperature
scale icons
Quick
Chill
Colder
Less
Cold
Mid
Temp
IMPORTANT
The factory default settings for the refrigerator is “Mid”. If you
want to change the temperature, remember to make only
small adjustments and wait 24 hours to see if it’s correct.
Quick Chill
Hold 3sec
DESCRIPTION OPERATION / PRIMARY FUNCTION
Refrigerator temperature scale icons • Indicates the temperature setting of the refrigerator compartment.
Quick Chill On/ Off icon • Indicates the status of the Quick Chill function
Temperature adjust/ quick chill on/ off
button
Temperature Control
•
Touch the ‘Temp’ button to awaken control.
• Touch the ‘Temp’ button to decrease the refrigerator temperature.
Once the coldest temperature is reached the display will return to the
warmest setting with the next press.
Quick Chill
•
Use the quick chill function when you add a large amount of food to the
refrigerator compartment.
•
Press and hold the ‘Temp’ button for 3 seconds. The Quick Chill icon will
flash indicating that the Quick Chill is active.
•
Your refrigerator will run at 2°C for 90 minutes, then automatically return
to normal mode.
•
The Quick Chill function can be cancelled anytime by pressing the
‘Temp’ button again.
8 www.electrolux.com
INSTALLING YOUR NEW
REFRIGERATOR
Unpacking
ENVIRONMENT
Most of the packing materials are recyclable. Please dispose
of those materials through your local recycling depot or by
placing them in appropriate collection containers.
Important – check for any damages or marks. If you find the
refrigerator is damaged or marked, you must report it within 7
days should you wish to claim for damage/ marks under the
manufacturers warranty. This does not affect your statutory
rights.
Clean your refrigerator thoroughly following the instructions
in the “Cleaning” section and wipe off any dust that has
accumulated during shipping.
Locating the refrigerator
CAUTION
Automatic aerosol systems (such as insect control) should
not be located adjacent to the product as the spray may
cause long term damage to the external plastics of the
appliance.
Do not put the refrigerator in a location that is too
cold or is unprotected, for example in a garage or on a
veranda. The ambient temperature should be above 10°C.
Put the refrigerator in a dry place avoiding areas of high
moisture or humidity.
Ensure the refrigerator is located on an even surface.
Adequate ventilation around your refrigerator
The diagram below shows the recommended airspace to
allow for ventilation of your refrigerator.
If you have a cupboard above the refrigerator with a rear
gap of less than 100 mm (Y), recommended clearance at the
top of the refrigerator increases from 50mm to 90mm (X)
minimum.
When positioned in a corner area, spacing of at least
350mm (300mm for multi-door models) on the hinge side will
allow the doors to open enough to enable the removal of
bins and shelves.
NOTE: Doors are designed to sit proud of cabinetry
(not flush). The clearances shown above are the
recommended minimum clearances.
The clearance at the rear must not exceed 75mm.
Installing your refrigerator
1. Roll the refrigerator into place. The rollers are designed
for forward or backward movement only. They are not
astors. Moving the refrigerator sideways may damage
your floor and the rollers. Before moving your
refrigerator ensure height adjusting nut and the stability
foot are fully wound up off the floor.
2. Wind the large height adjusting nut under door hinge
down until the refrigerator is tilted back by 10mm
(see diagram).
3. Wind the large height adjusting nut on the handle side
down until the refrigerator is level and stable. If you
have difficulty winding the nut or height adjusting foot
down, have someone tilt the refrigerator back so you
have better access.
4. Check the alignment of the refrigerator to the
surrounding cupboards to see if it is level. You can
adjust the level as detailed in step 2 and 3.
50mm
30mm
350mm
30mm
Recommended
air space
Height adjusting nut
Fixed rear rollers
stabilty foot
wound up
top of refrigerator is
level ie. horizontal
aligned to
cupboards
ie. even gap
adjust front feet for
uneveness of floor
eg. wind this foot
down or up
10 -15mm
CABINET DOOR
English 9
INSTALLING YOUR NEW REFRIGERATOR
5. If you find your refrigerator rocks from corner to
corner, it means your floor is uneven. Find a piece of
plastic or hardboard etc. and pack it firmly under the
roller.
6. You may now need to fine-tune the installation by
repeating steps 3, 4 and 5.
7. When you have the appliance in its final position, it
needs to be stabilised. Wind the stability foot under the
door hinge down to the floor until it just makes contact
with the floor. Lift the front of the appliance to take the
weZight off the stability foot, then turn it half a turn
further to ensure firm contact with the floor. Wind the
large height adjusting nut back up to ensure all the
weight is now on the front stability foot.
8. Repeat step 7 for the stability foot on the handle side.
Whenever you need to move the appliance, be sure to
wind the feet back up so that the appliance can roll
freely and be sure to reset it when reinstalling.
9. Plug your refrigerator straight into its own power point
and never use a double adapter. If you need to roll the
refrigerator to get to the plug, remember to raise the
stability foot first.
10. Before you put any food in your refrigerator, it’s
recommended you leave it on for 2 or 3 hours to check
it is running properly.
Fitting the handles
The handles are supplied prepackaged inside your
refrigerator and will require fitting.
Refer to the instructions provided in the pack.
Congratulations! You have successfully installed your new
refrigerator.
USING YOUR REFRIGERATOR
Refrigerators work by transferring heat from the food inside
to the outside air. This operation makes the back and sides
of the refrigerator feel warm or even hot particularly at
start-up and on warm days – this is normal.
Avoid placing food against the air vents in the refrigerator
as it affects efficient circulation. If the door is opened
frequently, a light frosting will occasionally occur on the
freezer’s interior. This is normal and will clear after a few
days. If the freezer door is accidentally kept open, a heavy
frost will coat the inside walls and should be removed.
Your new refrigerator uses a high-speed compressor, along
with other energy-efficient components, which may make
unusual sounds and be more noticeable at night and
quieter times. These sounds simply indicate your refrigerator
is working how it should. They include:
•
Compressor running noises;
• Air movement noise from the small fan motor;
• A gurgling sound, similar to water boiling;
• A popping noise, heard during automatic defrosting;
and
•
A clicking noise, prior to compressor start-up. Further
details can be found in the Troubleshooting Guide.
IMPORTANT
For top mount refrigerators (where the freezer is on top of
the fresh food compartment).
• Don’t place food forward of the ribs on the freezer
floor, as it will keep the door open.
Large height
adjusting nut
wound up
stability foot
wound
down
Ribs
10 www.electrolux.com
REMOVING FEATURES
Removal of Crisper
Drawer:
1. Empty food from the crisper. On some models it will be
necessary to remove the bottle storage bins.
2. Remove the crisper by pulling forward, then up and
forward again.
3. For top mount models, remove the crisper shelf by lifting
the catches on the left and right underside of the shelf
and pulling the shelf forward.
NutriPlus
TM
(Anti-Oxidant Filter)
Installing Filter Cartridge
Your filter can be found in the crisper. To enjoy the full
benefit of
NutriPlus
TM
, it is important to install it after
turning on the refrigerator. For installation, please follow
the following instruction.
1. Remove plastic wrap
2. Hook the filter to the back of the crisper bin.
Replacing Filter Cartridge
The filter is located at the back of the crisper.
Hold the filter, move upwards to release from the hooks.
Glass shelves
To remove the shelves, gently
pull them forward until the shelf
comes clear of the shelf guides.
To return the shelf, make sure
there is nothing behind that
may obstruct movement. Gently
push the shelf, into the cabinet
and back into position.
Freezer shelf
Remove the freezer shelf
by lifting the catches on the
right and left underside of
the shelf to release the shelf
then pull the shelf toward you.
Drawers fitted with telescopic slides
To remove the drawer for cleaning.
1. Empty food from the drawer.
2. Remove the drawer by pulling it forward and lifting the
front to unhook it from the slides. Once you have
removed the drawer, ensure the slides are pushed back
so they are fully closed.
WARNING
Never close the door while the telescopic slides are
extended. This may damage the slide and/or refrigerator or
cause the slide to become disengaged from the refrigerator.
To replace the drawer:
1. Ensure the telescopic slides are pushed in all the way.
2. Slide the drawer into place over the slides and push
the bin in until it stops.
3. Drop drawer into position.
CATCH
CATCH
English 11
CLEANING YOUR REFRIGERATOR
WARNING
BEFORE CLEANING: Turn the refrigerator off at the power
point and unplug the cord to prevent any chance of
electrocuting yourself.
Doors and exterior (white and silver):
You should only clean the doors with lukewarm soapy
water and a soft cloth.
Stainless Steel:
Your stainless steel refrigerator is manufactured from
mark-resistant stainless steel. This stainless steel has a
special advanced protective coating
that eases the
removal of marks such as fingerprints and water spots. To
keep its appearance, clean it regularly with lukewarm
soapy water and a soft cloth.
CAUTION
Never use stainless steel cleaners, abrasive pads or other
cleaners that will scratch the surface. Damage to
the
appliance after delivery is not covered by your warranty.
Interior
Clean the inside of your refrigerator regularly with a soft
cloth, unscented mild soap and lukewarm water.
Thoroughly dry all surfaces and removable parts and avoid
getting water on the controls. Replace removable parts,
plug power cord in and switch the power on before
returning the food.
Door seals
Always keep door seals clean by washing them with a mild
detergent and warm water, followed by a thorough drying.
Sticky food and drink can cause seals to stick to the cabinet
and tear when you open the door.
CAUTION
Never use hot water, solvents, commercial kitchen cleaners,
aerosol cleaners, metal polishes, caustic or abrasive
cleaners, or scourers to clean your refrigerator. Many
commercially available cleaning products and detergents
contain solvents that will damage your refrigerator. Use
only a soft cloth with an unscented mild soap and
lukewarm water.
To clean a crisper or freezer bin with
telescopic extension
slides, simply wipe with a damp cloth and warm soapy
water. Never immerse the cover in water, as this could
affect the operation of the slide.
Switching off your refrigerator
If you switch off your refrigerator for an extended period,
follow these steps to reduce the chances of mould:
1. Remove all food.
2. Remove the power plug from the power point.
3. Thoroughly clean and dry the Interior.
4. En
sure that all the doors are wedged open slightly
for air circulation.
CAUTION
Never close the door while the telescopic slides are
extended. It may damage the slide and/or the refrigerator
or cause the slide to become disengaged from the
refrigerator.
Twist and Serve Ice
Mounting the twist & serve dispenser to the other side of
the freezer.
Note : This is only possible on top mount models.
1. Remove the ice
bin and ice cube
tray. If the ice tray
assembly is frozen to
the carriage, simply
squeeze the tray
and shelf together to
break the ice.
2. Before you remove the ice carriage, remember to
disengage it from the glass shelf as it may result in
damage to the assembly.
3. Remove the centre runner by disengaging it at the front
of the shelf, and removing it from the rear.
4. Refit the runner into the rear of the shelf on the right
hand side and then engage the front.
5. Fit the carriage by sliding it into the runners until the
front if the carriage engages with the shelf.
6. Refit the ice tray and ice bin.
WARNING
Fill the ice tube tray with potable water only.
CAUTION
LED lighting
Your appliance is fitted with long life LED lighting. In the
unlikely event the LED lights should fail, then the LED lights
should be serviced by the manufacturer.
Refer to the warranty page for contact details.
Insert Into the slot at the rear
of the shelf
Then engage Into the front
of the shelf
12 www.electrolux.com
FOOD STORAGE GUIDE
CATEGORY PRODUCT REFRIGERATOR FREEZER STORAGE TIPS
MEAT
Sausages and Mince 1-2 Days 2-3 Months
Keep cold meat at the back of the
refrigerator where it is coldest.
Plastic can cause meat to sweat if
stored in refrigerator for more than
a day.
Roast can take up to 48 hours to
defrost properly, transfer frozen
roast to the refrigerator 2 days
before use.
Chops and Steak 3-4 Days 4-6 Months
Cold Meats 3-5 Days 4-6 Months
Roasts 3-5 Days 12 Months
POULTRY
Chicken 1-2 Days 2 Months
If poultry takes on a smell or colour
you are unsure about it is best to
throw it out.
Whole eggs are not suitable for
freezing, slightly beaten eggs may
be frozen for four months.
Roast Chicken 3-5 Days 12 Months
Eggs 6 Weeks Not Suitable
SEAFOOD Whole fish and fillets 2-3 Days 2 Months Store in an air tight container or foil.
Never freeze prawns in salty water as
this will dehydrate the flesh.
Lobster and crabs 1-2 Days 2 Months
Prawns 1-2 Days 2 Months
DAIRY Milk Until Expiry Date Not Suitable If dairy takes on a smell or colour and
you are unsure about it, it is best to
throw it out.
Depending on the variety hard
cheese can last from 2 weeks to
2 months.
Yoghurt 7- 10 Days Not Suitable
Hard Cheeses 2 Weeks – 2 Months 2 Months (Grated)
Soft Cheeses 1-2 Weeks Not Suitable
Butter 8 Weeks 12 Months
FRUIT &
VEGETABLES
Every fruit and vegetable has a
different shelf life. Some stay fresh for
a couple of days e.g beans, others
can last for a couple of months e.g.
onions.
8-12 Months
When freezing
chop and blanch
in small portions.
Keep vegetables in the crisper and
away from the air vents to avoid
freezing.
Don’t wash fruit and vegetables
before storing them in the refrigerator
as this can make them susceptible to
rotting.
LEFT OVERS Homemade meals 3-4 Days 2-6 Months Store in sealed container.
Freeze meals in small portion sizes
to limit wastage.
IMPORTANT
Please note, use this information as a guide only, actual storage
times will vary depending on how you use your refrigerator, climatic
conditions and the freshness of the food.
English 13
TROUBLESHOOTING
Appliance does not operate at desired temperature
In a modern frost free refrigerator / freezer, cold air is circulated around the various compartments through air
vents using a high efficiency fan.
CONCERN WHAT TO DO
Refrigerator is too warm
Ensure food is allowed to cool before placing inside the refrigerator.
Ensure the appliance is set up as per instructions on page 11.
Ensure that contents are not obstructing the cooling vents.
Ensure the door is not held open or is being opened too frequently.
Freezer is too warm
Adjust temperature to a colder setting.
Ensure food is allowed to cool before placing inside the freezer.
Ensure the appliance is set up as per instructions on page 11.
Ensure that contents are not obstructing the cooling vents.
Ensure the door is not held open or is being opened too frequently.
Food is freezing in the refrigerator Adjust temperature to a warmer setting.
Ensure that fruit and vegetables are stored in the crisper. Items with a high water
content should not be placed near the cooling vents.
Unable to change temperature settings Refer to function guide in Controlling Your Refirgerator.
Ensure that user interface is in “awake” mode before trying to adjust temperature
settings.
Appliance noise
Your new refrigerator may make sounds that your old one didn’t make. Because the sounds are new to you, you might be
concerned about them. Most of the new sounds are normal. Hard surfaces, like the floor, walls and cabinets, can make the
sounds seem louder than they actually are. The following describes the kinds of sounds and what may be making them.
CONCERN WHAT TO DO
Motor noise
(compressor)
Nothing. This is normal as your new refrigerator uses a high-speed compressor
which switches on and off during operation.
Note that the compressor noise may seem louder at the start of the on cycle.
A clicking noise heard just before
the compressor starts.
Nothing. This is normal as your new refrigerator has an automatic switching action
of the temperature control, turning the compressor on and off.
Occasional gurgling, similar
to water boiling.
Nothing. As each cycle ends, you may hear a gurgling sound due to the
refrigerant flowing in your refrigerator system.
Airflow noise. Nothing, this is normal as your new refrigerator uses high efficiency fans to circulate air.
Rattling and
other noises.
Ensure that the cabinet is level and stable, refer to
Installation Instructions on page 6.
Check the surrounds of the appliance to ensure there is nothing
touching or placed on top of the appliance.
Ensure that contents of the appliance are not placed in such a way
that they are vibrating (such as bottles).
Crisper Operation
CONCERN WHAT TO DO
Excess moisture build up in crisper
It is normal for there to be some moisture
and humidity in the crisper bin.
Ensure that the crisper is not over packed.
Crisper bin can not be removed If crisper bin interferes with the door bins, remove door bins before removing
crisper.
Position cabinet so that the door can be fully opened.
Freezing items in the crisper Adjust temperature to a warmer setting.
14 www.electrolux.com
CONCERN WHAT TO DO
Refrigerator is too warm
Ensure food is allowed to cool before placing inside the refrigerator.
Ensure the appliance is set up as per instructions on page 11.
Ensure that contents are not obstructing the cooling vents.
Ensure the door is not held open or is being opened too frequently.
Freezer is too warm
Adjust temperature to a colder setting.
Ensure food is allowed to cool before placing inside the freezer.
Ensure the appliance is set up as per instructions on page 11.
Ensure that contents are not obstructing the cooling vents.
Ensure the door is not held open or is being opened too frequently.
Food is freezing in the refrigerator Adjust temperature to a warmer setting.
Ensure that fruit and vegetables are stored in the crisper. Items with a high water
content should not be placed near the cooling vents.
Unable to change temperature settings Refer to function guide in Controlling Your Refirgerator.
Ensure that user interface is in “awake” mode before trying to adjust temperature
settings.
Appliance noise
Your new refrigerator may make sounds that your old one didn’t make. Because the sounds are new to you, you might be
concerned about them. Most of the new sounds are normal. Hard surfaces, like the floor, walls and cabinets, can make the
sounds seem louder than they actually are. The following describes the kinds of sounds and what may be making them.
CONCERN WHAT TO DO
Motor noise
(compressor)
Nothing. This is normal as your new refrigerator uses a high-speed compressor
which switches on and off during operation.
Note that the compressor noise may seem louder at the start of the on cycle.
A clicking noise heard just before
the compressor starts.
Nothing. This is normal as your new refrigerator has an automatic switching action
of the temperature control, turning the compressor on and off.
Occasional gurgling, similar
to water boiling.
Nothing. As each cycle ends, you may hear a gurgling sound due to the
refrigerant flowing in your refrigerator system.
Airflow noise. Nothing, this is normal as your new refrigerator uses high efficiency fans to circulate air.
Rattling and
other noises.
Ensure that the cabinet is level and stable, refer to
Installation Instructions on page 6.
Check the surrounds of the appliance to ensure there is nothing
touching or placed on top of the appliance.
Ensure that contents of the appliance are not placed in such a way
that they are vibrating (such as bottles).
Crisper Operation
CONCERN WHAT TO DO
Excess moisture build up in crisper
It is normal for there to be some moisture
and humidity in the crisper bin.
Ensure that the crisper is not over packed.
Crisper bin can not be removed If crisper bin interferes with the door bins, remove door bins before removing
crisper.
Position cabinet so that the door can be fully opened.
Freezing items in the crisper Adjust temperature to a warmer setting.
Refrigerator operation
CONCERN WHAT TO DO
Appliance will not run
It is normal for the freezer fan not to
operate during the automatic defrost cycle,
or for a short time after the appliance is
switched on.
Ensure that the cord is plugged into a live power outlet and outlet is switched on.
Ensure that the household circuit breaker has not tripped or that the fuse has not
blown.
The appliance maybe in defrost mode, check again in half an hour.
Compressor motor seems to run too long
At normal room temperatures, expect your
motor to run about 40% to 80% of the time.
Under warmer conditions, expect it to run
even more often.
Ensure that the doors are not held open
Check that large amounts of warm food have not just been placed inside the
appliance.
Note that the appliance will run more than normal just after you install it or when
adjusting to temperature setting changes.
The exterior of the appliance is warm or hot
to touch
This is normal because the appliance
transfers heat from the inside out through
the outer panels and the divider between
the doors.
Ensure the appliance has the external clearances recommended in the section
“Installing your new appliance”.
The exterior of the cabinet will be much warmer on warmer days it may even feel
hot to touch, as the appliance is working harder.
User interface will not respond
To ensure settings are not accidentally
changed the user interface will go into
sleep mode when not in use. Press any
button to wake user interface
Check that the user interface is in awake mode, refer to section “About the user
interface”.
Check that the user interface is not locked, refer to section “About the user
interface”.
If the user interface is frozen turn the appliance off for five minutes for the memory to
clear, then turn back on.
Check that the user interface is not in Sabbath Mode, refer to control instructions.
(I&W models only).
Alarms Sounding
Check that all doors are fully closed.
Ensure that the over temperature alarm is not being activated by hot food placed in
the freezer.
Check if the drinks timer has ended, refer control instructions.
Check if the Filter Replacement alert is activated, refer control instructions.
(I&W models only)
Frost build up Check that all doors are fully closed.
Ensure that the doors are not opened too often.
Ensure that the return air vents are not blocked with packaging.
Ensure the seals are clean and not obstructed.
Odours The interior may need cleaning, refer to cleaning guide.
Ensure that food is stored correctly as some food, containers and wrapping can
produce odours.
Check appliance for old or unusual food.
Lights not working
The LED lighting is designed to dim
automatically if the door is left opened
for more than 5 minutes and turn off
completely if the door is open for more
than 7 minutes. Closing the door will reset
the timer.
The LED lighting is also designed to turn
on gradually.
Ensure that the cord is plugged into a live power outlet and outlet is switched on.
Ensure that the household circuit breaker has not tripped or that the fuse has not
blown.
Check that the user interface is not in Sabbath Mode, refer to control instructions.
Check the appliance features section to determine lighting configuration for your
model. Check that the doors are closed completely
English 15
TROUBLESHOOTING
Door operation
CONCERN WHAT TO DO
Freezer door pops open.
This is normal and should re-close. This happens when the refrigerator door is
closed too quickly.
If the freezer door stays open, it indicates that the appliance needs to be tilted
backwards a little further. Refer to section “Installing your new appliance”.
Self close not working. Check if your appliance has self closing hinges as not all models do.
It indicates that the appliance needs to be tilted backwards a little further. Refer
to section “Installing your new appliance”.
Door not sealing properly Ensure there is nothing that is preventing the door from closing such as appliance
contents or items placed near the appliance.
Ensure that the crisper/freezer bin is closed completely. Refit if required as
referred to in the section “Using your refrigerator”.
Ensure the appliance is set up as per recommendations.
Door difficult to open and close If the door is difficult to open just after you have closed it this is due to the
pressure equalising, the door will open normally after a few minutes.
If you still require service
If you have a problem, and the problem persists after you have made the checks mentioned, contact your nearest
Electrolux approved Service Centre or the dealer you bought the refrigerator from. Be ready to quote the model
number, the 9-digit PNC and 8-digit serial number, which is stated on the label inside the refrigerator
compartment.
16 www.electrolux.com
CONCERN WHAT TO DO
Freezer door pops open.
This is normal and should re-close. This happens when the refrigerator door is
closed too quickly.
If the freezer door stays open, it indicates that the appliance needs to be tilted
backwards a little further. Refer to section “Installing your new appliance”.
Self close not working. Check if your appliance has self closing hinges as not all models do.
It indicates that the appliance needs to be tilted backwards a little further. Refer
to section “Installing your new appliance”.
Door not sealing properly Ensure there is nothing that is preventing the door from closing such as appliance
contents or items placed near the appliance.
Ensure that the crisper/freezer bin is closed completely. Refit if required as
referred to in the section “Using your refrigerator”.
Ensure the appliance is set up as per recommendations.
Door difficult to open and close If the door is difficult to open just after you have closed it this is due to the
pressure equalising, the door will open normally after a few minutes.
If you still require service
If you have a problem, and the problem persists after you have made the checks mentioned, contact your nearest
Electrolux approved Service Centre or the dealer you bought the refrigerator from. Be ready to quote the model
number, the 9-digit PNC and 8-digit serial number, which is stated on the label inside the refrigerator
compartment.
NOISES
There are some sounds during normal running (compressor, refrigerant circulation).
English 17
BRRR!
HISSS!
CLICK!
BLUBB!
CRACK!
SSSRR
R!
OK
CLICK!
CLICK!
SSSRRR!
SSSRRR!
BRRR!
BRRR!
HISSS!
HISSS!
BLUBB!
BLUBB!
CRACK!CRACK!
Notes
Notes
.
17 www.electrolux.com
BRRR!
HISSS!
CLICK!
BLUBB!
CRACK!
SSSRR
R!
OK
CLICK!
CLICK!
SSSRRR!
SSSRRR!
BRRR!
BRRR!
HISSS!
HISSS!
BLUBB!
BLUBB!
CRACK!CRACK!
.
. .
. .
. .
. .
.
.
/
.
.
.
8 9
.
.
16
ﺔﯾﺑرﻌﻟا
.
.
.
.
. 80% 40%
.
.
.
.
.
.
.
.
.
.
.
. I&W .
.
.
.
.
I&W
.
.
.
.
. .
.
.
LED
5
. . 7
.
LED
.
.
.
.
.
15 www.electrolux.com
. /
.
.11
.
.
.
.
.11
.
.
.
.
.
.
.
. .
.
. .
.
.
.
.
.
.
.
.
.
. .
.
.6
.
.
.
.
.
.
.
ﺔﯾﺑرﻌﻟا
14
.
1-2 2-3
.
.
48
.
3-4 4-6
3-5
4-6
3-5
12
1-2
.
.
3-5
12
6
2-3
.
.
1-2
1-2
.
.
7-10
-
1-2
8
12
.
.
8
-12
.
.
.
3-4 2-6.
.
13 www.electrolux.com
.
.
.
. :
.
.1
.
.2
.
.3
.
: .4
.
.5
.
. .6
.
LED
, LED . LED
. LED
.
:
. .1
. .2
. .3
.
.4
:
.
:
.
:
.
.
.
. .
.
.
.
.
.
.
. .
.
.
ﺔﯾﺑرﻌﻟا
12
.
.
.
.
.
.1
. .2
.
.
.
:
.
.1
. .2
.
.3
:
.
.1
.
.2
.
.3
.
NutriPlus
TM
.
. .
NutriPlus
TM
.1
.
.2
.
.
11 www.electrolux.com
.
. -
.
.
.
.
.
: .
•
•
•
•
.
•
.
.
•
.
. .5
.
.5 4 3
.6
.
.7
.
.
.
. 7
.8
.
.
.9
.
3
.10
.
.
.
. !
ﺔﯾﺑرﻌﻟا
1
0
. .
.1
. .
.
.2
. 10
.3
.
.
.
.4
.3 2
7
10
100
9050
300350
75
10-15
50
30
350
30
9 www.electrolux.com
ا مﻟا ﺔﮭﺟاو نﻋ ةذﺑﻧ
ETB4600B زارطﻟا - مﻛﺣﺗﻟ
.
. 24
/
. •
. •
. ”Temp
•
. ”Temp
•
.
.
•
. 3 Temp
•
.
.
90 2
•
Temp
•
.
Quick
Chill
Colder
Less
Cold
Mid
Temp
Quick Chill
Hold 3sec
ﺔﯾﺑرﻌﻟا
8
24 .
.
. :
.
.
.
. .1
. .2
.
.3
Freezer Temp
Freezer Temp
Freezer Temp
Less
Cold
Less
Cold
Less
Cold
Colder
Colder
Colder
35
15
7
www.electrolux.com
ETB4600B
. .
Boost
.
.
Temp
Less
Cold
Mid
Colder
Quick
Chill
Quick Chill
Hold 3sec
EMT856
10X
.
.
.
.
.
.
”
.
.
.
.
NutriPlus
TM
.
FlexStor™
.
.
.
.
6
ﺔﯾﺑرﻌﻟا
2.3
!
.
.
•
•
.
.
•
R600a
.
.
•
. .
•
.
.
•
.
.
•
•
.
. .
•
•
.
.
•
•
.
2.4
•
.
2.5
!
.
•
.
•
.
.
•
.
.
2.6
!
.
.
•
.
•
•
.
•
.
.
•
.
.
•
5 www.electrolux.com
•
.
.
•
. •
1
•
1 10 0,1
.2
2.1
!
.
. •
.
•
.
•
.
•
.
.
•
4
•
.
.
•
.
.
•
•
.
•
.
•
.
2.2
!
.
. •
•
.
•
.
.
•
.
.
•
•
.
.
•
.
•
.
.
.
•
.
4
ﺔﯾﺑرﻌﻟا
.1
.
1.1
8
•
,
. •
.
•
•
.
1.2
: •
–
–
•
.
•
.
.
•
.
.
. . •
.
•
.
3 www.electrolux.com
3
........................................................................................................................................ .1
4
...................................................................................................................................... .2
6
......................................................................................................................................... .3
8
............................................................................................................................... .4
11
.............................................................................................................................. .5
12
....................................................................................................................................... .6
14
................................................................................................................................. .7
15
................................................................................................................................... .8
16
.................................................................................................................... .9
19 .......................................................................................................................................
.10
.
.Electrolux
.
.
.Electrolux
:
:
www.electrolux.com
:
www.electrolux.com/productregistration
www.electrolux.com/shop :
.
CNP . :
. /
.
.
2
ﺔﯾﺑرﻌﻟا
ETB4600B
AR
دﯾرﺑﺗﻟا
ةزﮭﺟأ
مدﺧﺗﺳﻣﻟا لﯾﻟد
