NS-19LD120A13
User Guide
19" LCD TV/DVD Combo
ii
www.insigniaproducts.com
Contents
CHILD SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
CAUTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installing the stand or wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . .4
Installing the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing a wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
TV/DVD combo components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Making connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
What connection should I use? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connecting power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting a cable or satellite box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting an antenna or cable TV (no box) . . . . . . . . . . . . . . . . . . . . . 12
Connecting a DVD or Blu-ray player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connecting a VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Connecting a camcorder or game console . . . . . . . . . . . . . . . . . . . . . . . 15
Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Connecting a USB flash drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Connecting headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Connecting a basic home theater system . . . . . . . . . . . . . . . . . . . . . . . . 17
Connecting a home theater system with multiple devices . . . . . . . . 18
Using the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Installing remote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Aiming the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Turning on your TV/DVD combo for the first time . . . . . . . . . . . . . . . 19
Understanding the basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Turning your TV/DVD combo on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
iii
Contents
www.insigniaproducts.com
Selecting the video input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
On-screen menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Navigating the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Selecting a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Viewing channel information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Adjusting the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Adjusting the TV picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Adjusting the computer image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Setting the power-on picture mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Displaying a banner at power on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Adjusting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Adjusting sound settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Playing TV audio only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Changing channel settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Automatically scanning for channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Hiding channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Setting up a favorite channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Viewing a favorite channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Checking the digital signal strength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Setting parental controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Setting or changing the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Locking control buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Blocking unrated TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Setting parental control levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Downloading rating information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Using closed captioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Turning closed captioning on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Selecting the analog closed captioning mode . . . . . . . . . . . . . . . . . . . 34
Customizing digital closed captioning styles . . . . . . . . . . . . . . . . . . . . . 34
Adjusting time settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Adjusting menu settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Selecting the menu language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Restoring settings to the defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Using a USB flash drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Switching to USB mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Browsing photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
iv
Contents
www.insigniaproducts.com
Viewing favorite photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Viewing photos in a slideshow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Customizing slideshow settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Using the DVD player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Playing a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Controlling disc playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Ejecting a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Creating a playback loop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Repeating a disc title, chapter, or track . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Changing DVD settings: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
On-screen DVD menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Cleaning the TV cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Cleaning the TV screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Care and handling of discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Video and audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Disc playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
USB photo display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Programming universal remote controls . . . . . . . . . . . . . . . . . . . . . . . . 47
Programming a different universal remote control . . . . . . . . . . . . . . . 47
Common universal remote control codes . . . . . . . . . . . . . . . . . . . . . . . . 47
Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
One-year limited warranty - Insignia Televisions . . . . . . . . . . . . . . . . . 49
Definitions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
How long does the coverage last? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
What does this warranty cover? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
How to obtain warranty service? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Where is the warranty valid? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
What does the warranty not cover? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
1
www.insigniaproducts.com
As you enjoy your new product, keep these
safety tips in mind
The issue
The home theater entertainment experience is a growing trend, and larger TVs are popular
purchases. However, TVs are not always supported on the proper stands or installed
according to the manufacturer’s recommendations. We and the consumer electronics
industry are committed to making home entertainment enjoyable and safe.
TVs that are inappropriately placed on dressers, bookcases, shelves, desks, speakers, chests, or
carts may fall over and cause injury.
Tune into safety
•
One size of TV stand does not fit all. Use only a TV stand
rated for the weight of your TV.
•
Carefully read and understand all enclosed instructions
for proper use of this product.
•
Don’t let children climb on or play with entertainment
system furniture and TVs.
•
Don’t place TVs on furniture that can easily be used as
steps, such as a crate or chest of drawers.
•
Remember that children can become excited while
watching a program, especially on a “larger-than-life” TV.
Make sure that you place or install the TV where it cannot
be pushed, pulled over, or knocked down.
•
Make sure that you route all cords and cables so that they
cannot be pulled or grabbed by curious children.
Wall mounting
If you decide to wall mount your TV, always remember:
•
One size of wall mount does not fit all. Use only a wall mount rated for the weight of
your TV and that has been recommended by this TV manufacturer, listed in this
manual, or otherwise listed by an independent laboratory as suitable for your TV.
•
Follow all instructions supplied by the TV and wall mount manufacturers.
•
If you have any doubts about your ability to safely wall mount your TV, get help from a
professional installer.
•
Make sure that the wall where you are mounting the TV is
appropriate. Some wall mounts are not designed to be
mounted to walls backed with steel studs or cinder blocks. If
you are unsure, ask a professional installer.
TVs can be heavy. At least two people are required for safe wall mount installation.
f
CHILD SAFETY
It makes a difference how and where you use
your flat panel display
2
NS-19LD120A13
www.insigniaproducts.com
Important Safety
Instructions
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in
accordance with the manufacturer's
instructions.
8 Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9 Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade or
the third prong are provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10 Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11 Only use attachments/accessories specified by
the manufacturer.
12 Use only with the cart, stand,
tripod, bracket, or table specified
by the manufacturer, or sold with
the apparatus. When a cart is used,
use caution when moving the
cart/apparatus combination to avoid injury from
tip-over.
13 Unplug this apparatus during lightning storms
or when unused for long periods of time.
14 Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as
power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
15 The wall plug is the disconnecting device. The
plug must remain readily operable.
16 An apparatus with three-prong, grounding-type
plug is a Class I apparatus which needs to be
grounded to prevent possible electric shock.
Make sure that you connect the Class I
apparatus to a grounding-type, three-prong
outlet.
17 Remote control batteries should not be exposed
to excessive heat such as sunshine, fire, or the
like.
18 The apparatus should not be exposed to
dripping or splashing and no objects filled with
liquids, such as vases, should be placed on the
apparatus.
WARNING
Electric shock hazard
To reduce the risk of fire or electric shock, do not
remove any cover or expose the device to rain or
moisture. No user-serviceable parts are inside. Refer
servicing to qualified service technicians.
Lightning
For added protection for your device receiver
during a lightning storm, or when it is left
unattended and unused for long periods of time,
unplug it from the power outlet and disconnect any
antenna or cable system. This helps prevent
property damage and personal injury from
lightning and power line surges.
Power lines
An outside antenna system should not be located in
the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall
into such power lines or circuits. When installing an
outside antenna system, extreme care should be
taken to keep from touching such power lines or
circuits as contact with them might be fatal.
Handling the LCD panel
• Your TV/DVD combo’s screen is made of glass. Do
not drop your TV/DVD combo or hit, jolt, or press
hard against the LCD panel. If the screen breaks,
be careful of broken glass.
• If the LCD panel is broken, make absolutely sure
that you do not touch the liquid in the panel. This
may cause skin inflammation.
• If the liquid gets in your mouth, immediately
gargle, rinse, and consult with your doctor. Also, if
the liquid gets in your eyes or touches your skin,
consult with your doctor after rinsing for at least
15 minutes or longer in clean water.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within your TV/DVD
combo. This label is located on the
back of your TV/DVD combo.
This symbol indicates that there are
important operating and maintenance
instructions in the literature
accompanying your TV/DVD combo.
3
www.insigniaproducts.com
Replacement parts
When replacement parts are required, make sure
that the service technician uses replacement parts
specified by the manufacturer that have the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock,
personal injury, or other hazards.
Safety check
After completing any service or repair to this device,
ask the service technician to perform routine safety
checks to determine that your TV/DVD combo is in
correct operating condition.
Power source
Operate your TV/DVD combo only from the type of
power source indicated on the marking label. If you
are not sure of the type of power supplied to your
home, consult an electrician or your local power
company.
Servicing
These servicing instructions are for use by qualified
service personnel only. To reduce the risk of electric
shock, do not perform any servicing other than that
contained in the operating instructions unless you
are qualified to do so.
CAUTION
Damage requiring service
Unplug this TV/DVD combo from the power outlet
and refer servicing to qualified service personnel
under the following conditions:
• When the power supply cord or plug is damaged
or frayed.
• If liquid has been spilled or objects have fallen
into your TV/DVD combo.
• If your TV/DVD combo has been exposed to rain
or water.
• If your TV/DVD combo does not operate normally
by following the operating instructions. Adjust
only those controls that are covered by the
operating instructions because incorrect
adjustment of other controls may result in
damage and will often require extensive work by
a qualified technician to restore your TV/DVD
combo to its normal operation.
• If your TV/DVD combo has been dropped or
damaged in any way.
• When your TV/DVD combo exhibits a distinct
change in performance.
Outdoor antenna grounding
If an outside antenna or cable system is connected
to your TV/DVD combo, make sure that the antenna
or cable system is grounded to provide some
protection against voltage surges and built-up
static charges. Article 810 of the National Electrical
Code, ANSI/NFPA No. 70, provides information with
respect to correct grounding of the mast and
supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding
conductors, location of the antenna-discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode.
Note to CATV system installer
Article 820 of the National Electrical Code,
ANSI/NFPA No. 40 provides guidance for correct
grounding. Specifically, it states that the cable
ground must be connected to the grounding
system of the building as close to the point of cable
entry as practical.
Condensation
Moisture will form on the TV/DVD combo if the
TV/DVD combo is brought from cool surroundings
into a warm room or if the temperature of the room
rises suddenly. When this happens, the TV/DVD
combo's performance may be impaired. To prevent
this, let the TV/DVD combo stand in its new
surroundings for about an hour before switching it
on, or make sure that the room temperature rises
gradually.
Condensation may also form during the summer if
the TV/DVD combo is exposed to the breeze from
an air conditioner. In such cases, change the
location of the TV/DVD combo.
Mobile telephone warning
To avoid interference with your TV picture and
sound, operating problems, or even damage, keep
your cordless and cellular telephones away from
the TV/DVD combo.
End of life directives
Your TV/DVD combo contains tin-lead solder and a
fluorescent lamp containing a small amount of
mercury. Disposal of these materials may be
regulated for environmental reasons. Your TV/DVD
combo also contains material that can be recycled
and reused. For disposal or recycling information,
contact your local authorities to find a recycler in
your area.
Non-active pixels
The LCD panel contains almost 3 million thin film
transistors, which provide exceptionally sharp video
quality. Occasionally, a few non-active pixels may
appear on the screen as a fixed blue, green, or red
point. These non-active pixels do not adversely
affect the performance of your TV/DVD combo, and
are not considered defects.
Antenna lead-in wire
Grounding clamp
Antenna discharge unit
Grounding conductors
Ground clamps
Power service grounding electrode system
Electric service equipment
2
1
3
4
5
6
7
1
2
3
4
5
6
7
4
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Insignia 19" LCD TV/DVD Combo
Introduction
Congratulations on your purchase of a high-quality
Insignia product. Your NS-19LD120A13 represents
the state of the art in LCD TV/DVD combo design
and is designed for reliable and trouble-free
performance.
Installing the stand or
wall-mount bracket
Installing the stand
To install the stand:
1 Carefully place your TV screen face-down on a
cushioned, clean surface to protect the screen
from damages and scratches.
2 Secure the stand to the screen with the two
provided screws.
Installing a wall-mount bracket
To attach your TV/DVD combo to a wall-mount
bracket:
1 Carefully place your TV screen face-down on a
cushioned, clean surface to protect the screen
from damages and scratches.
2 If the stand is attached, remove the two screws
that secure the stand to the TV screen, then
remove the stand.
3 Attach the wall-mount bracket to your
TV/DVD combo using the mounting holes on
the back of your TV/DVD combo. See the
instructions that came with the wall-mount
bracket for information about how to correctly
hang your TV/DVD combo.
Notes
• If you plan to wall-mount your TV/DVD combo,
do not install the stand.
• Store the stand and stand screws in case you
decide to use the stand in the future.
Screw type Screw length # of screws
M4 18 mm 2
Warning
This TV/DVD combo is intended to be supported by a
UL Listed wall mount bracket with suitable
weight/load. (See “Miscellaneous” on page 46.)
Note
• The length of the wall-mount screws vary
depending on the wall-mount bracket you
purchased. See the instructions that came with
the wall-mount bracket for screw lengths.
• The mounting holes on the back of your
TV/DVD combo take type M4 screws.
3.94 in. (100 mm)
3.94 in. (100 mm)
Wall-mount brackets
5
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
TV/DVD combo components
Package contents
• Remote control and batteries (2 AAA)
• Stand and screws (2)
• Power cord
• Quick Setup Guide
• Important Information
Front
9
10
1
3 42 5
6
7
8
# Item Description
Disc slot
Insert a disc (DVD or CD) into this slot to change modes
and begin playback.
INPUT
Press to open the Input Source list, press CH or
CH to select a video input source, then wait a few
seconds for the video input source to change. For more
information, see “Selecting the video input source” on
page 21.
In menu mode, press to confirm selections.
(Power)
Press to turn your TV/DVD combo on or off (standby
mode). When your TV/DVD combo is off, power still
flows through it. To completely disconnect power,
unplug the power cord.
VOL+/VOL– Press to increase or decrease the volume.
(play/pause)/
CH
In TV mode, press to go to the next channel in the
channel list. For more information, see “Selecting a
channel” on page 22.
In DVD mode, press to begin, pause, or resume
playback.
(stop)/CH
Press to go to the previous channel in the channel list.
For more information, see “Selecting a channel” on
page 22.
In DVD mode, press to stop playback.
/EJECT
Press to eject the disc from the disc slot.
MENU
Press to open the on-screen menu. For more
information, see “Navigating the menus” on page 22.
Remote control sensor
Receives signals from the remote control. Do not block.
Power indicator
Turns off when your TV is turned on. Lights red when
your TV is in standby mode.
1
2
3
4
5
6
7
8
9
10
6
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Back Side
# Item Description
DIGITAL OUT
Connect a digital audio amplifier or home theater
system to this jack to listen to TV audio through the
amplifier speakers. For more information, see “Using
digital audio” on page 17.
COMPONENT IN
Y/P
B
/P
R
Connect the video for a component video device to
these jacks. For more information, see “Using
component video (better)” on pages 10 or 13.
USB
Connect a USB flash drive to this jack to view
compatible JPEG picture files. For more information,
see “Connecting a USB flash drive” on page 16 and
“Using a USB flash drive” on page 37.
1
2 3
1
2
3
# Item Description
Connect headphones to this jack. For more
information, see “Connecting headphones” on
page 17.
VGA/DVI IN (audio)
Connect the audio for a computer to this jack. For more
information, see “Connecting a computer” on page 15.
OR
Connect the audio for a DVI device to this jack. For
more information, see “Using DVI (same as HDMI but
requires a sound connection)” on page 10 or page 13.
ANT/CABLE IN
Connect an antenna or cable TV to this jack. For more
information, see “Connecting an antenna or cable TV
(no box)” on page12.
VGA
Connect the video for a computer to this jack. For more
information, see “Connecting a computer” on page 15.
VIDEO IN/AV
Connect the video for a composite video device to this
jack. For more information, see “Using composite
video (good)” on page 11 or 14, “Connecting a VCR” on
page 14, or “Connecting a camcorder or game
console” on page 15.
L/R (audio)
The component video jacks
(COMPONENT IN Y/P
B
/P
R
) share these audio jacks
with the composite video jack (VIDEO IN/AV).
Connect the audio for a component video device to
these jacks. For more information, see “Using
component video (better)” on page 10 or 13.
OR
Connect the audio for a composite video device to
these jacks. For more information, see “Using
composite video (good)” on page 11 or 14,
“Connecting a VCR” on page 14, or “Connecting a
camcorder or game console” on page 15.
HDMI
Connect an HDMI device to this jack. For more
information see “Using HDMI (best)” on page 9 or 12.
OR
Connect the video for a DVI device to this jack. For
more information, see “Using DVI (same as HDMI but
requires a sound connection)” on page 10 or 13.
1
2
3
4
6
5
7
1
2
3
4
5
6
7
7
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Remote control
# Button Description
(power)
Press to turn your TV/DVD combo on or off (standby
mode). When your TV/DVD combo is off, power still
flows through it. To disconnect power, unplug the
power cord.
Numbers
Press to enter channel numbers and the parental
control password.
—
Press to enter a digital sub-channel number. For more
information, see “Selecting a channel” on page 22.
HOME
In DVD mode, press to open the DVD setup menu. For
more information, see “Changing DVD settings:” on
page 40.
VOL+/–
Press to increase or decrease the volume.
ENTER/
Press to confirm selections or changes.
Press to navigate in on-screen menus and to adjust
settings.
MENU Press to open the on-screen menu.
AUDIO
Press to select the sound mode. You can select
Standard, Theater, Music, News, or Custom. For
more information, see “Sound Mode” in “Adjusting
sound settings” on page 25.
HOME
TOP MENU
NS-RC07A-13
1
2
3
4
5
6
7
8
9
PICT
Press to select the picture mode. You can select Vivid,
Standard, Energy Savings, Theater, or Custom.
For more information, see “Picture Mode” in
“Adjusting the TV picture” on page 23.
FAV
Press to open the Favorite channel list. For more
information, see “Setting up a favorite channel list” on
page 28 and “Viewing a favorite channel” on page 29.
SLEEP/
Press to set the sleep timer. You can select OFF, 5, 10,
15, 30, 60, 90, 120, 180, or 240 minutes. For more
information, see “Setting the sleep timer” on page 36.
DVD playback controls
Press TOP MENU to open a DVD top menu (title
menu), if available.
Press DVD MENU to open a DVD menu (root menu), if
available.
Press (eject) to eject the disc from the disc slot.
Press (play/pause) once to begin playback. Press
again to pause playback. Press once again to resume
playback.
Press (skip back) to skip back to the previous title
or track on a DVD or CD.
Press (fast reverse) to fast reverse on a DVD or CD.
Press REPEAT to select the repeat mode on a DVD or
CD. You can select Chapter, Title, or All for a DVD, or
Track or All for a CD.
Press A-B to create a playback loop for a disc.
Press SUBTITLE to change the subtitle language.
Press (stop) to stop playback on a DVD or CD.
Press (skip forward) to skip forward to the next
title or track on a DVD or CD.
Press (fast forward) to fast forward on a DVD or
CD.
For more information, see “Using the DVD player” on
page 40.
(mute)
Press to mute the sound. Press again to restore the
sound.
RECALL/
In TV mode, press to return to the previous channel.
INFO/
Press to display TV status information, such as the
channel number, channel name (if available), or signal
source. For more information, see “Viewing channel
information” on page 22.
CH
/CH
Press to change TV channels. For more information,
see “Selecting a channel” on page 22.
EXIT
Press to close the on-screen menu.
SAP
In digital TV mode, press to select the audio track
(language).
In analog TV mode, press to select Stereo, Mono, or
SAP.
For more information, see “Adjusting sound settings”
on page 25.
INPUT
Press to open the Input Source list, press
or
on
the remote control to select the video input source,
then press ENTER/ . For more information, see
“Selecting the video input source” on page 21.
CCD
Press to turn closed captioning on or off. You can select
CC Off, CC On, or CC On When Mute. For more
information, see “Turning closed captioning on or off”
on page 33.
ZOOM/
Press to change how the picture looks on the screen
(aspect ratio). For more information, see “Aspect ratio
options” on page 23.
# Button Description
10
11
12
13
14
15
16
17
18
19
20
21
22
8
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Making connections
What connection should I use?
Your TV/DVD combo has several connection types
for connecting devices to your TV/DVD combo.
For the best video quality, you should connect a
device to the best available connection.
Use the following tables to identify cables:
You can use the HDMI jack on your TV/DVD combo
to connect a DVI device to your TV/DVD combo.
You need to attach an HDMI-to-DVI adapter to the
end of the HDMI cable that connects to the DVI
device.
Connection type
and jack
Video quality Cable connector
HDMI
video/audio
Best (use this
if your devices
have HDMI)
Component
video (requires
an audio
connection)
Better than
composite or
coaxial
Composite video
(requires an
audio
connection)
Better than
coaxial
Coaxial
video/audio
Good
Connection type
and jack
Cable connectors
Digital coaxial
audio
Analog audio
VGA (computer)
video and audio
Cautions
• Check the jacks for position and type before
making any connections.
• Loose connections can result in image or color
problems. Make sure that all connections are
tight and secure.
• The external audio/video equipment shown
may be different from your equipment. If you
have questions, refer to the documentation that
came with your equipment.
• Always unplug the power cord when
connecting external equipment.
9
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Connecting power
To connect the power:
• Connect the AC power cord to the AC jack on the
back of your TV/DVD combo, then connect the
other end to a power outlet.
Connecting a cable or satellite box
Many cable or satellite TV boxes have more than
one connection type. To get the best video, you
should use the best connection type available. For
more information, see “What connection should I
use?” on page 8.
Using HDMI (best)
To connect a cable or satellite box using HDMI:
1 Make sure that your TV/DVD combo’s power
cord is unplugged, and all connected
equipment is turned off.
2 Connect the incoming cable from the cable wall
jack to the cable-in jack on the cable or satellite
box.
3 Connect an HDMI cable (not provided) to the
HDMI jack on the side of your TV/DVD combo
and to the HDMI OUT jack on the cable or
satellite box.
4 Plug your TV/DVD combo’s power cord into a
power outlet, turn on your TV/DVD combo, then
turn on the cable or satellite box.
5 Go through the Setup Wizard on page 19.
Cautions
• Your TV/DVD combo should only be operated
from the power source indicated on the label.
• Always unplug the AC power cord from the
power outlet when you will not be using your
TV/DVD combo for an extended period of time.
Note
An HDMI cable carries both audio and video. You do
not need to use any audio cables.
HDMI cable
Cable or satellite box
Side of TV
10
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Using DVI (same as HDMI but requires a sound
connection)
To connect a cable or satellite box using DVI:
1 Make sure that your TV/DVD combo’s power
cord is unplugged, and all connected
equipment is turned off.
2 Connect the incoming cable from the cable wall
jack to the cable-in jack on the cable or satellite
box.
3 Connect an HDMI-DVI adapter (not provided) to
one end of an HDMI cable (not provided), then
connect the adapter to the DVI OUT jack on the
cable or satellite box.
4 Connect the other end of the cable to the HDMI
jack on the side of your TV/DVD combo.
5 Connect a 3.5mm audio cable (not provided) to
the VGA/DVI IN jack on the side of your TV/DVD
combo and to the AUDIO OUT jacks on the
cable or satellite box.
6 Plug your TV/DVD combo’s power cord into a
power outlet, turn on your TV/DVD combo, then
turn on the cable or satellite box.
7 Go through the Setup Wizard on page 19.
Using component video (better)
To connect a cable or satellite box using
component video:
1 Make sure that your TV/DVD combo’s power
cord is unplugged, and all connected
equipment is turned off.
2 Connect the incoming cable from the cable wall
jack to the cable-in jack on the cable or satellite
box.
3 Connect a component video cable (not
provided) to the COMPONENT IN Y/P
B
/P
R
video jacks on the back of your TV/DVD combo
and the component video out jacks on the cable
or satellite box.
4 Connect an audio cable (not provided) to the
L and R audio jacks on the side of your TV/DVD
combo and to the audio out jacks on the cable
or satellite TV box.
5 Plug your TV/DVD combo’s power cord into a
power outlet, turn on your TV/DVD combo, then
turn on the cable or satellite box.
6 Go through the Setup Wizard on page 19.
Note
When you connect the audio using the VGA/DVI IN
jack, the audio output is analog.
Cable or satellite box
HDMI cable with HDMI-DVI adapter
Audio cable
Side of TV
Note
• The COMPONENT IN video jacks share the
audio jacks with the VIDEO IN/AV video jack.
• When you connect the audio using the L and R
audio jacks, the audio output is analog.
Audio cable
Cable or satellite box
Cables are often
color-coded to match
color-coded jacks.
Component video cable
Back of TV
11
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Using composite video (good)
To connect a cable or satellite box using
composite video:
1 Make sure that your TV/DVD combo’s power
cord is unplugged, and all connected
equipment is turned off.
2 Connect the incoming cable from the cable wall
jack to the cable-in jack on the cable or satellite
box.
3 Connect an A/V cable (not provided) to the
VIDEO IN/AV jack and L and R audio jacks on
the side of your TV/DVD combo and to the
composite video and audio out jacks on the
cable or satellite box.
4 Plug your TV/DVD combo’s power cord into a
power outlet, turn on your TV/DVD combo, then
turn on the cable or satellite box.
5 Go through the Setup Wizard on page 19.
Using coaxial (good)
To connect a cable or satellite box using coaxial:
1 Make sure that your TV/DVD combo’s power
cord is unplugged, and all connected
equipment is turned off.
2 Connect the incoming cable from the cable wall
jack to the cable-in jack on the cable or satellite
box.
3 Connect a coaxial cable (not provided) to the
ANT/CABLE IN jack on the side of your TV/DVD
combo and to the coaxial out jack on the cable
or satellite box.
4 Plug your TV/DVD combo’s power cord into a
power outlet, turn on your TV/DVD combo, then
turn on the cable or satellite box.
5 Go through the Setup Wizard on page 19.
Note
• The VIDEO IN/AV jack shares the audio jacks
with the COMPONENT IN video jacks.
• When you connect the audio using the L and R
audio jacks, the audio output is analog.
Cable or satellite box
A/V cable
Cables are often color-coded
to match color-coded jacks.
Side of TV
Notes
• Use a coaxial cable to eliminate interference and
noise from radio waves.
• Do not bundle the coaxial cable with the power
cord or other cables.
Cable or satellite box
Coaxial cable
Side of TV
12
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Connecting an antenna or cable TV (no box)
To connect an antenna or cable TV (no box):
1 Make sure that your TV/DVD combo’s power
cord is unplugged, and all connected
equipment is turned off.
2 Connect a coaxial cable to the ANT/CABLE IN
jack on the side of your TV/DVD combo and to
the antenna or cable TV wall jack.
3 Plug your TV/DVD combo’s power cord into a
power outlet, then turn on your TV/DVD combo.
4 Go through the Setup Wizard on page 19.
Connecting a DVD or Blu-ray player
Using HDMI (best)
To connect a DVD or Blu-ray player using HDMI:
1 Make sure that your TV/DVD combo’s power
cord is unplugged and the DVD or Blu-ray player
is turned off.
2 Connect an HDMI cable (not provided) to the
HDMI jack on the side of your TV/DVD combo
and to the HDMI OUT jack on the DVD or
Blu-ray player.
3 Plug your TV/DVD combo’s power cord into a
power outlet, then turn on your TV/DVD combo.
4 Turn on the DVD or Blu-ray player, then set it to
the correct output mode. For more information,
see the documentation that came with the
player.
5 Press INPUT to open the Input Source list.
6 Press INPUT repeatedly or press
or
to
highlight HDMI, then press ENTER
/
.
Notes
• Use a coaxial cable to eliminate interference and
noise from radio waves.
• Do not bundle the coaxial cable with the power
cord or other cables.
• If the antenna is not installed correctly, contact
qualified service personnel to correct the
problem.
• If the signal level for a channel is weak, the
picture may be distorted. Adjust the antenna or
use a highly directional outdoor or set-top
antenna with a built-in amplifier.
• If the picture quality is good on some channels
and poor on others, the problem may be caused
by a poor or weak signal from the broadcaster
or cable TV provider.
• If you connect to cable or satellite TV without a
set-top box and experience poor picture quality,
you may need to install a set-top box to improve
signal reception and picture quality. Contact
your cable or satellite TV provider about
upgrading to a set-top box.
• Many high-definition (HD) channels upscale
standard-definition (SD) content. The picture
displayed on your TV/DVD combo is still
displayed as SD, thus the picture quality will not
be as clear or crisp as it would be if the content
was originally recorded in HD.
Coaxial cable
Antenna or
cable TV (no box)
Side of TV
DVD or Blu-ray player
HDMI cable
Side of TV
13
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Using DVI (same as HDMI but requires a sound
connection)
To connect a DVD or Blu-ray player using DVI:
1 Make sure that your TV/DVD combo’s power
cord is unplugged and the DVD or Blu-ray player
is turned off.
2 Connect an HDMI-DVI adapter (not provided) to
one end of an HDMI cable (not provided), then
connect the adapter to the DVI OUT jack on the
DVD or Blu-ray player.
3 Connect the other end of the cable to the HDMI
jack on the side of your TV/DVD combo.
4 Connect a 3.5mm audio cable (not provided) to
the VGA/DVI IN jack on the side your TV/DVD
combo and to the AUDIO OUT jacks on the DVD
or Blu-ray player.
5 Plug your TV/DVD combo’s power cord into a
power outlet, then turn on your TV/DVD combo.
6 Turn on the DVD or Blu-ray player, then set it to
the correct output mode. For more information,
see the documentation that came with the
player.
7 Press INPUT to open the Input Source list.
8 Press INPUT repeatedly or press
or
to
highlight HDMI, then press ENTER
/
.
Using component video (better)
To connect a DVD or Blu-ray player using
component video:
1 Make sure that your TV/DVD combo’s power
cord is unplugged and the DVD or Blu-ray player
is turned off.
2 Connect a component video cable (not
provided) to the COMPONENT IN Y/P
B
/P
R
jacks
on the back of your TV/DVD combo and to the
COMPONENT OUT jacks on the component
video device.
3 Connect an audio cable to the L and R audio
jacks on the side of your TV/DVD combo and to
the L and R AUDIO OUT jacks on the DVD or
Blu-ray player.
4 Plug your TV/DVD combo’s power cord into a
power outlet, then turn on your TV/DVD combo.
5 Turn on the DVD or Blu-ray player, then set it to
the correct output mode. For more information,
see the documentation that came with the
player.
6 Press INPUT to open the Input Source list.
7 Press INPUT repeatedly or press
or
to
highlight Component, then press ENTER
/
.
DVD or Blu-ray player
HDMI cable with HDMI-DVI adapter
Audio
cable
Side of TV
Notes
• The COMPONENT IN video jacks share the
audio jacks with the VIDEO IN/AV video jack.
• When you connect the audio using the L and R
audio jacks, the audio output is analog.
Component video cable
Audio cable
Cables are often color-coded
to match color-coded jacks.
DVD or Blu-ray player
Back of TV
14
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Using composite video (good)
To connect a DVD or Blu-ray player using
composite video:
1 Make sure that your TV/DVD combo’s power
cord is unplugged and the DVD or Blu-ray player
is turned off.
2 Connect an AV cable (not provided) to the
VIDEO IN/AV video jack and L and R audio jacks
on the side of your TV/DVD combo and to the
AV OUT jacks on the DVD or Blu-ray player.
3 Plug your TV/DVD combo’s power cord into a
power outlet, then turn on your TV/DVD combo.
4 Turn on the DVD or Blu-ray player, then set it to
the correct output mode. For more information,
see the documentation that came with the
player.
5 Press INPUT to open the Input Source list.
6 Press INPUT repeatedly or press
or
to
highlight A/V, then press ENTER
/
.
Connecting a VCR
To connect a VCR:
1 Make sure that your TV/DVD combo’s power
cord is unplugged and the VCR is turned off.
2 Connect an AV cable (not provided) to the
VIDEO IN/AV video and L and R audio jacks on
the side of your TV/DVD combo and to the AV
OUT jacks on the VCR.
3 Plug your TV/DVD combo’s power cord into a
power outlet, then turn on your TV/DVD combo
and the VCR.
4 Press INPUT to open the Input Source list.
5 Press INPUT repeatedly or press
or
to
highlight A/V, then press ENTER
/
.
6 Insert a videotape in the VCR, then press PLAY
on the VCR.
Note
• The VIDEO IN/AV video jack shares the audio
jacks with the COMPONENT IN video jacks.
• When you connect the audio using the L and R
audio jacks, the audio output is analog.
DVD or Blu-ray player
Cables are often color-coded to match
color-coded jacks.
AV cable
Side of TV
Note
• The VIDEO IN/AV video jack shares the audio
jacks with the COMPONENT IN video jacks.
• When you connect the audio using the L and R
audio jacks, the audio output is analog.
VCR
Cables are often color-coded to
match color-coded jacks.
AV cable
Side of TV
15
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Connecting a camcorder or game console
To connect a camcorder or game console:
1 Make sure that your TV/DVD combo’s power
cord is unplugged and the camcorder or game
console is turned off.
2 Connect an AV cable (not provided) to the
VIDEO IN/AV video jack and L and R audio jacks
on the side of your TV/DVD combo and to the
AV OUT jacks on the camcorder or game
console.
3 Plug your TV/DVD combo’s power cord into a
power outlet, then turn on your TV/DVD combo.
4 Turn on the camcorder or game console, then
set it to the correct output mode. For more
information, see the documentation that came
with the camcorder or game console.
5 Press INPUT to open the Input Source list.
6 Press INPUT repeatedly or press
or
to
highlight A/V, then press ENTER/ .
Connecting a computer
Using VGA
To connect a computer using VGA:
1 Make sure that your TV/DVD combo’s power
cord is unplugged and the computer is turned
off.
2 Connect a VGA cable (not provided) to the VGA
jack on the side of your TV/DVD combo and to
the VGA jack on the computer.
3 Connect an audio cable with stereo mini plugs
(not included) to the VGA/DVI in audio jack on
the side of your TV/DVD combo and to the
LINE OUT or AUDIO OUT jack on the computer.
4 Plug your TV/DVD combo’s power cord into a
power outlet, then turn on your TV/DVD combo
and the computer.
5 Press INPUT to open the Input Source list.
6 Press INPUT repeatedly or press
or
to
highlight VGA, then press ENTER
/
.
7 Adjust the display properties on the computer,
if necessary.
Note
If your camcorder or game console has an HDMI
connection, we recommend that you use the HDMI
connection to get the best quality possible.
Note
• The VIDEO IN/AV video jack shares the audio
jacks with the COMPONENT IN video jacks.
• When you connect the audio using the L and
R audio jacks, the audio output is analog.
Cables are often color-coded to
match color-coded jacks.
Camcorder or
game console
AV cable
Side of TV
Audio cable
with stereo mini plug
VGA cable
Side of TV
16
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Using HDMI
To connect a computer using HDMI:
1 Make sure that your TV/DVD combo’s power
cord is unplugged and the computer is turned
off.
2 Connect an HDMI cable (not provided) to the
HDMI jack on the side of your TV/DVD combo
and to the HDMI OUT jack on the computer.
3 Plug your TV/DVD combo’s power cord into a
power outlet, then turn on your TV/DVD combo
and the computer.
4 Press INPUT to open the Input Source list.
5 Press INPUT repeatedly or press
or
to
highlight HDMI, then press ENTER
/
.
6 Adjust the display properties on the computer,
if necessary.
Connecting a USB flash drive
To connect a USB flash drive:
1 Plug a USB flash drive into the USB port on the
back of your TV/DVD combo.
2 Turn on your TV/DVD combo.
3 Press INPUT to open the Input Source list.
4 Press INPUT repeatedly or press
or
to
highlight USB (Photos), then press ENTER
/
.
HDMI cable
Side of TV
Caution
• Do not remove the USB flash drive or turn off
your TV/DVD combo while using the USB flash
drive. You may lose data or damage the USB
flash drive.
• The USB flash drive must be less than 2.2 inches
(55 mm) in length. A longer flash drive will not
fit.
Note
The Photos viewer only supports JPEG format
images (with “.jpg” file extensions) and not all JPEG
files are compatible with your TV/DVD combo.
For more information, see “Using a USB flash drive”
on page 37.
USB flash
drive
Back of TV
17
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Connecting headphones
The TV/DVD combo speakers are muted when
headphones are attached.
To connect headphones:
• Connect the headphones to the
(headphone) jack on the side of your
TV/DVD combo.
Connecting a basic home theater system
Using digital audio
To connect a basic home theater system using
digital audio:
1 Make sure that your TV/DVD combo’s power
cord is unplugged and the home theater system
is turned off.
2 Connect a digital coaxial audio cable (not
provided) to the DIGITAL OUTPUT jack on the
back of your TV/DVD combo and to the coaxial
AUDIO IN jack on the digital home theater
system.
Warning
Loud noise can damage your hearing. When using
headphones, use the lowest volume setting on your
headphones that still lets you hear the sound.
Side of TV
Digital coaxial audio cable
Home theater system
Back of TV
18
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Connecting a home theater system with
multiple devices
The connections you make depend on the video
and audio jacks available on your devices. Refer to
the documentation that came with your devices for
connection information.
Just remember to use the best connection types
available for the best picture and sound. For
information about connection types, see “What
connection should I use?” on page 8.
Using the remote control
Installing remote control batteries
To install remote control batteries:
1 While pressing the release latch on the back of
the remote control, lift the battery
compartment cover off the remote control.
2 Insert two AAA batteries into the battery
compartment. Make sure that you match the +
and – symbols on the batteries with the + and –
symbols in the battery compartment.
3 Replace the battery compartment cover.
Aiming the remote control
To aim the remote control:
• Point the remote control towards the remote
sensor on the front of your TV/DVD combo.
See “Front” on page 5 for the location of the remote
sensor.
Blu-ray player/DVD player/VCR
Cable/satellite box
AV receiver
Camcorder/game console
USB flash drive
Computer
Antenna or cable
TV connected
directly to the
wall jack
Cautions
• Batteries should not be exposed to excessive
heat, such as sunshine, heat registers, or fire.
• Battery chemicals can cause a rash. If the
batteries leak, clean the battery compartment
with a cloth. If chemicals touch your skin, wash
immediately.
• Make sure that batteries are disposed of
correctly. Do not burn or incinerate.
Notes
• Do not mix batteries of different types.
• Do not mix old and new batteries.
• Remove batteries when the charge is depleted.
• If the remote control is not going to be used for
an extended period of time, remove the
batteries.
19
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Turning on your TV/DVD
combo for the first time
The first time you turn on your TV/DVD combo, the
Setup Wizard opens. The Setup Wizard guides you
through setting up basic settings including the
menu language, time setting, picture mode, and TV
signal source.
To set up your TV/DVD combo:
1 Make sure that you have:
• Installed the remote control batteries. (See
page 18 for details).
• Connected an antenna, cable TV, or satellite
TV. (See page 9 through 12 for details.)
• Connected the power cord. (See page 9 for
details.)
2 Press (power) to turn on your TV/DVD combo.
The Choose Your Menu Language screen opens.
3 Press
or
to highlight the language you
want, then press ENTER
/
. The Choose Your
Time Setting screen opens.
4 Press
or
to highlight Mode, then press
or
to select Manual (to set the date and
time manually) or Auto (to set the date and time
automatically from a TV signal source based on
the time zone you select).
5 Press
or
to highlight Time Zone, then press
or
to select your time zone. You can select
Eastern, Central, Mountain, Pacific, Alaska,
Hawaii, Atlantic, or Newfoundland.
6 Press
or
to highlight Daylight Savings,
then press
or
to select On (if your viewing
area observes Daylight Savings Time) or Off (if
your viewing area does not observe Daylight
Savings Time).
7 If you selected Manual for Mode, set the date
by pressing
or
to highlight Year, Month, or
Day, then pressing
or
to adjust the setting.
8 If you selected Manual for Mode, set the time
by pressing
or
to highlight Time, then
pressing
or
to select the hour, minute, or
AM/PM field. Press
or
to adjust the setting.
9 Press ENTER
/
. The Choose your Picture Mode
screen opens.
10 Press
or
to highlight Home Mode or Retail
Mode, then press ENTER
/
.
If you selected Retail Mode, the message “If you
select Retail Mode, then Energy Saving is not
realized. Are you sure?” appears. Select Yes to
continue using Retail Mode, or select No to
change your selection, then press ENTER
/
.
The Choose Your TV source screen opens.
Note
If you select Auto, the displayed time will be
incorrect until your TV/DVD combo gets the correct
time from a TV signal source.
English
Fran ais
ç
Espa
ñ
ol
Choose Your Menu Language
MOVE
OK
ENTER
MENU
PREVIOUS
SELECT
Set menu language to English, Français, or Español.
EXIT
EXIT
MOVE
OK
ENTER
MENU
PREVIOUS
SELECT
Choose Your Time Setting
EXIT
EXIT
Mode Auto
Time Zone Atlantic
Daylight Savings On
Year 2011
Month October
Day 28
Time 08:07 AM
If Automatic, options are automatically set by TV source.
MOVE
OK
ENTER
MENU
PREVIOUS
SELECT
Choose Your Picture Mode
Reduces total power consumption.
Home Mode
Retail Mode
EXIT
EXIT
Antenna
Cable
Satellite Box
Choose Your TV source
MOVE
OK
ENTER
MENU
PREVIOUS
EXIT
EXIT
SELECT
Select if using an antenna for standard or HD TV.
20
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
11 Press
or
to highlight Antenna, Cable, or
Satellite Box (if your cable TV using a box,
select Satellite Box), then press ENTER
/
.
A If you select Antenna, your TV scans for
available channels. The scan may take
several minutes.
During scanning, your TV searches for
digital channels first. When the digital
channel search is complete, a message
appears asking if you want to search for
analog channels. Select YES to continue
searching for analog channels, or select
NO to stop searching for channels.
B If you select Cable, a message asks if you
have a cable box.
• Select No, then press ENTER if no cable
box is connected. Your TV scans for
available channels. The scan may take
several minutes.
• Select Yes, then press ENTER if a cable box
is connected. A message asks how you
connected the cable box to your TV:
• Select AV, Component, or HDMI, then
press ENTER if you connected a cable
box to your TV using one of these
cables. Read the message, then press
ENTER to close the wizard.
• Select Coaxial, then press ENTER if you
connected a cable box to your TV using
a coaxial cable. Read the message, then
press ENTER to start the channel scan.
C If you select Satellite Box, a message asks
how you connected the satellite box to
your TV:
• Select AV, Component, or HDMI, then
press ENTER if you connected a satellite
box to your TV using one of these cables.
Read the message, then press ENTER to
close the wizard.
• Select Coaxial, then press ENTER if you
connected a satellite box to your TV using
a coaxial cable. Read the message, then
press ENTER to start the channel scan.
12 To watch TV, press INPUT, press
or
to
highlight TV or the video input source you
connected your cable or satellite box to in the
Input Source list, then press ENTER
/
.
• If your TV/DVD combo is connected to an
antenna, cable TV (no box), or cable or satellite
TV box using a coaxial cable, select TV.
• If your TV/DVD combo is connected to a cable
or satellite box using an HDMI cable or HDMI
cable with a DVI adapter, select HDMI.
• If your TV/DVD combo is connected to a cable
or satellite box using a component video
cable, select Component.
• If your TV/DVD combo is connected to a cable
or satellite box using a composite video cable,
select A/V.
Note
You can press EXIT to stop the auto channel search,
but you will need to run the auto channel search
again to create a channel list.
Note
You can press EXIT to stop the auto channel search,
but you will need to run the auto channel search
again to create a channel list.
Scanning for Channels
Analog Channels: 0
Digital Channels: 0
15%
Do you have a Cable Box?
No
Yes
Move
OK
ENTER
MENU
EXIT
ExitPrevious
Select
Channel scan may take 20+ minutes
How did you connect the
AV, Component, or HDMI
Coaxial
Move
OK
ENTER
MENU EXIT
ExitPrevious
Select
cable box to the TV?
Note
You can press EXIT to stop the auto channel search,
but you will need to run the auto channel search
again to create a channel list.
Note
You can press EXIT to stop the auto channel search,
but you will need to run the auto channel search
again to create a channel list.
How did you connect the
AV, Component, or HDMI
Coaxial
Move
OK
ENTER
MENU
EXIT
ExitPrevious
Select
satellite box to the TV?
21
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Understanding the basics
Turning your TV/DVD combo on or off
To turn your TV/DVD combo on or off:
1 Make sure that the power cord is connected to a
power outlet.
2 Press (power) to turn on your TV/DVD combo.
The power indicator turns off.
3 Press (power) again to turn off your TV/DVD
combo. Your TV/DVD combo enters standby
mode, and the power indicator LED turns red.
Selecting the video input source
To select the video input source:
1 Turn on your TV/DVD combo, then press INPUT.
The Input Source list opens.
2 Press INPUT repeatedly or press
or
to
highlight a video input source, then press
ENTER
/
.
On-screen menu overview
Picture menu (TV mode)
Audio menu (TV mode)
Channels menu (TV mode)
Warning
When your TV/DVD combo is in standby mode, it is
still receiving power. To completely disconnect
power, unplug the power cord.
Note
If your TV/DVD combo does not receive an input
signal for several minutes, it automatically goes into
standby mode.
Input Source
TV
A/V
Component
VGA
USB (Photos)
HDMI
DVD
Notes
• Depending on the signal source selected, you
may see different options on your screen. The
following menus are shown in TV mode (except
the Photos menu).
• Menu items that are not selectable are grayed
out.
• Menus in this manual are described in TV mode,
unless otherwise indicated.
• The screens shown in this manual are for
explanation purposes and may vary from the
actual screens on your TV/DVD combo.
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Audio
Sound Mode
Balance
Advanced Audio
Reset Audio Settings
Standard
0
Adjust settings to affect sound quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
CHANNELS
SETTINGS
PHOTOS
AUDIO
Channels
Auto Channel Search
Add/Skip Channels
Favorites
Channel Strength
Audio Only Off
Auto Zoom Off
Adjust channel options.
P
H
O
T
OS
22
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Settings menu (TV mode)
Photos menu (USB mode)
Navigating the menus
Selecting a channel
To select a channel:
• Press CH
or CH
to go to the next or previous
channel on the memorized channel list.
• Press the number buttons to enter the analog or
main digital channel number you want, then wait
for the channel to change or press ENTER
/
to
immediately change the channel.
• To select a digital sub-channel, press the number
buttons to select the main digital channel, press
— (dash), then press the number button for the
sub-channel. Wait for the channel to change, or
press ENTER
/
to immediately change the
channel. For example, to tune to channel 5.1,
press 5, — (dot), then 1.
• Press RECALL/ to go to the last viewed channel.
• Press FAV to open the favorite channel list, press
or
to highlight a channel, then press
ENTER
/
.
Adjusting the volume
To adjust the volume:
• Press VOL+ or VOL– to increase or decrease the
volume.
• Press (mute) to turn off the sound. Press
(mute) again to turn the sound back on.
Viewing channel information
To view channel information:
• Press INFO/ to view an information banner. The
information banner shows the current program
information such as channel number, video input
source, and resolution.
• Digital channel information—Displays the
channel number, station name, broadcast
program name, TV rating, signal type, audio
information, resolution, CC mode, current
time, and current program start and end
times.
• Analog channel information—Displays
channel number, signal type, audio
information, and resolution.
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Set various TV options.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
View files from a USB device that is connected to the TV.
CHANNELS
SETTINGS
PHOTOS
AUDIO
Photos
Browse Photos
Favorite Photos
View Slideshow
Settings
C
HANNEL
S
Press MENU to open the on-screen menu.
Press the right or left arrow to move the
cursor on the screen or to adjust a selected
item.
Press the up or down arrow to select menu
options.
Press ENTER
/
to confirm a selection or
enter a sub-menu.
Press MENU to return to the previous menu.
Press EXIT to close the menu.
Note
Button presses must be within three seconds of each
other.
Note
If a list has more than one page, press
or
to
scroll through the pages.
23
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Adjusting the picture
Adjusting the TV picture
To adjust the TV picture:
1 Press MENU. The on-screen menu opens with
the Picture menu displayed.
2 Press
or ENTER
/
to access the menu.
3 Press
or
to highlight an option, then press
ENTER
/
to access the option. You can select:
• Picture Mode—Selects the picture mode. You
can select:
• Vivid—(a bright and vivid picture).
Significantly increases the contrast,
brightness, and sharpness. This selection is
good for video games, animation, and in
bright light environments.
• Standard—(a standard picture).
Moderately increases the contrast,
brightness, and sharpness. This selection is
good for standard TV broadcasts.
• Energy Savings—(the backlight
brightness is decreased). Your TV/DVD
combo has a backlight that provides light
for displaying a picture. By reducing the
amount of light, your TV/DVD combo uses
less energy.
• Theater—(a finely detailed picture).
Adjusts the brightness and contrast and
lowers the sharpness for a more realistic
picture. This selection is good for watching
the highest quality video such as Blu-ray
Discs, DVDs, and HDTV.
• Custom—(customized picture). Lets you
manually adjust picture settings such as
brightness, contrast, and color.
• Brightness—Adjusts the brightness of the
dark areas of the picture.
• Contrast—Adjusts the brightness of the light
areas of the picture.
• Color—Adjusts the color intensity of the
picture. A low setting may make the color look
faded. A high setting may make the color look
artificial.
• Advanced Video—Opens the
Picture-Advanced Video menu where you can
adjust additional video options.
• Dynamic Backlight (DCR)—Enhances the
contrast ratio between light and dark areas
of the picture. You can select High, Low, or
Off.
• Backlight—Sets the overall brilliance of
the screen. When Dynamic Backlight
(DCR) is turned on, you cannot change the
Backlight setting.
• Aspect Ratio—Selects the aspect ratio of
the picture.
Note
You can also press PICT to select the picture mode.
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
Aspect ratio options Example
Normal:
Displays the original 4:3 aspect
ratio with vertical black bars on
the left and right of the image.
Zoom:
Expands the image to fill the
screen. The top and bottom of
the image may be cropped.
Wide:
Use this option to view content
recorded in a 16:9
(wide-screen) aspect ratio.
Cinema:
Stretches the image at the
edges, but keeps a clear image
in the center.
Auto:
Automatically adjusts the
image based on the screen size
and the TV program.
Note: Auto is only available
when Auto Zoom in the
Channels menu is set to On.
Note
You can also press ZOOM/ to select the aspect
ratio.
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
Advanced Video
Dynamic Backlight (DCR)
Backlight
Aspect Ratio
Color Temperature
Overscan
Noise Reduction
Tint
Sharpness
Adaptive Contrast
Low
100
Auto
Cool
On
Middle
0
50
On
Enhance contrast ratio between light and dark areas of picture.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
O
S
24
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
• Color Temperature—Selects the color
temperature. You can select Cool (to
enhance the blues), Normal, or Warm (to
enhance the reds).
• Overscan—Adjusts the picture’s
reproduction rate. You can select On or
Off.
• Noise Reduction—Selects the noise
reduction mode to reduce picture noise
(snow). You can select Low, Middle, High,
or Off.
• Tint—Adjusts the color balance of the
picture. Use this control to make skin tones
look more natural.
• Sharpness—Adjusts the color detail of
images. If you set this control too high,
dark images may appear with light or
white edges.
• Adaptive Contrast—Automatically
adjusts picture detail and brightness. You
can select On or Off.
• Reset Picture Settings—Resets all picture
settings to factory mode.
4 Press
or
to adjust the option, or press
or
to select a setting, then press ENTER
/
.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Adjusting the computer image
To adjust the computer image:
1 Make sure that your TV/DVD combo is in VGA
mode. For more information, see “Selecting the
video input source” on page 21.
2 Press MENU. The on-screen menu opens.
3 Press
or
to highlight SETTINGS, then press
or ENTER
/
. The Settings menu opens.
4 Press
or
to highlight Computer Settings,
then press ENTER
/
. The Settings · Computer
Settings menu opens.
5 Press
or
to highlight an option, then press
ENTER
/
to access the option. You can select:
• Auto Adjust—Automatically adjusts the
image settings such as position and phase.
• H. Position—Moves the image right or left.
• V. Position—Moves the image up or down.
• Clock—Adjusts the sample frequency.
• Phase—Adjusts the focus of stable images.
• Reset Computer Settings—Resets all
computer settings to factory mode.
6 Press
or
to adjust the option, or press
or
to select a setting, then press ENTER
/
.
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Setting the power-on picture mode
You can set Vivid picture mode as your power-on
default, regardless of the picture mode your
TV/DVD combo is in when you turn it off.
To set the power-on picture mode:
1 Press MENU. The on-screen menu opens.
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
C
HANNEL
S
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Set options for when a computer is connected to the TV.
CHANNELS
SETTINGS
PHOTOS
AUDIO
PH
O
T
OS
C
HANNEL
S
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Computer Settings
Auto Adjust
H. Position
V. Position
Clock
Phase
Reset Computer Settings
Adjust to the PC signal timing automatically when ON.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
C
HANNEL
S
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
25
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
2 Press
or
to highlight SETTINGS, then press
or ENTER
/
. The Settings menu opens.
3 Press
or
to highlight Reset to Default, then
press ENTER
/
. The Settings · Reset to Default
menu opens.
4 Press
or
to highlight Power on in Vivid
Mode, then press ENTER
/
. A menu opens.
5 Press
or
to highlight On (when you turn on
your TV/DVD combo, it will be in Vivid picture
mode) or Off (when you turn on your TV/DVD
combo, it will be in the picture mode it was in
when you turned it off ), then press ENTER
/
.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Displaying a banner at power on
Your TV/DVD combo can display a retail banner that
displays your TV/DVD combo’s features.
To display a banner at power on:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight SETTINGS, then press
or ENTER
/
. The Settings menu opens.
3 Press
or
to highlight Reset to Default, then
press ENTER
/
. The Settings · Reset to Default
menu opens.
4 Press
or
to highlight Retail Banner, then
press ENTER
/
. A menu opens.
5 Press
or
to select On (displays the banner)
or Off (does not display the banner), then press
ENTER
/
.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Adjusting the sound
Adjusting sound settings
To adjust sound settings:
1 Press MENU. The on-screen menu opens.
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
CHANNELS
SETTINGS
PHOTOS
AUDIO
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Change power on options or reset TV to factory default
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Reset to Default
CHANNELS
SETTINGS
PHOTOS
AUDIO
Power on in Vivid Mode
Retail Banner
Reset to Default
Adjust power on options when TV is in Vivid Mode
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
CHANNELS
SETTINGS
PHOTOS
AUDIO
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Change power on options or reset TV to factory default
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
Settings
Reset to Default
CHANNELS
SETTINGS
PHOTOS
AUDIO
Power on in Vivid Mode
Retail Banner
Reset to Default
Display an electronic banner on the screen.
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
26
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
2 Press
or
to highlight AUDIO, then press
or
ENTER
/
. The Audio menu opens.
3 Press
or
to highlight an option, then press
ENTER
/
to access the option. You can select:
• Sound Mode—Selects the sound mode. You
can select:
• Standard—Balances treble and bass. This
setting is good for watching standard TV
broadcasts.
• Theater—Moderately decreases and
enhances treble and bass for a rich sound
experience.
• Music—Increases the treble and bass and
preserves the original sound. This setting is
good for listening to a musical program.
• News—Moderately decreases treble and
bass.
• Custom—Lets you manually adjust sound
settings.
• Balance—Adjusts the balance between the
left and right audio channels.
• Advanced Audio—Opens the Audio ·
Advanced Audio menu where you can adjust
additional audio options.
• Bass—Adjusts the low sounds.
• Treble—Adjusts the high sounds.
• Digital Audio/SPDIF—Sends digital audio
to an external audio system. You can select
PCM (to output audio in 2-channel stereo),
or RAW (to pass through the original
digital audio sound).
• MTS/SAP—(Analog channels only) Selects
the audio mode. You can select:
• Mono—Select this option if there is
noise or static on weak stereo
broadcasts.
• Stereo—Select this option for
programs broadcast in stereo.
• SAP—Select this option to listen to a
secondary audio program, if available.
• Audio Language—(Digital channels only)
Selects an alternate audio language, if
available.
• Reset Audio Settings—Reset all audio
settings to factory defaults.
4 Press
or
to adjust the option, or press
or
to select a setting, then press ENTER/ .
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Playing TV audio only
You can turn off the picture on your TV/DVD combo
and listen to the program audio only.
To play TV audio only:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight CHANNELS, then press
or ENTER
/
. The Channels menu opens.
3 Press
or
to highlight Audio Only, then
press ENTER
/
.
4 Press
or
to select On, then press
ENTER
/
.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Audio
Sound Mode
Balance
Advanced Audio
Reset Audio Settings
Standard
0
Adjust settings to affect sound quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
Audio
Advanced Audio
Bass
Treble
Digital Audio/SPDIF
MTS/SAP Stereo
Audio Language
0
0
Raw
Adjust low frequency sound.
CHANNELS
SETTINGS
PHOTOS
AUDIO
English
P
H
O
T
OS
Note
You can also press SAP one or more
times to select the audio mode.
Notes
• Audio Only works only when the input source is
TV, and your TV/DVD combo is receiving a
broadcast signal.
• To exit audio only mode, press any button.
When you exit audio only mode, the Audio
Only option is automatically reset to Off.
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
CHANNELS
SETTINGS
PHOTOS
AUDIO
Channels
Auto Channel Search
Add/Skip Channels
Favorites
Channel Strength
Audio Only On
Auto Zoom Off
Play the audio with the picture off
P
H
O
T
OS
27
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Changing channel settings
Automatically scanning for channels
When you scan for channels, your TV/DVD combo
searches for channels with signals and stores the
channel information in the channel list. When you
press CH
or CH
, your TV/DVD combo goes to
the next or previous channel in the channel list.
If the TV signal source changes, for example you
change from an outdoor antenna to cable TV (no
box), you need to scan for channels.
To automatically scan for channels:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight CHANNELS, then press
or ENTER
/
. The Channels menu opens.
3 Press
or
to highlight Auto Channel Search,
then press ENTER
/
. The Channels · Auto
Channel Search screen opens.
4 Press
or
to highlight Antenna, Cable, or
Satellite Box, then press ENTER
/
.
A If you select Antenna, your TV scans for
available channels. The scan may take
several minutes.
During scanning, your TV searches for
digital channels first. When the digital
channel search is complete, a message
appears asking if you want to search for
analog channels. Select YES to continue
searching for analog channels, or select No
to stop searching for channels.
B If you select Cable, a message asks if you
have a cable box.
• Select No, then press ENTER if no cable
box is connected. Your TV scans for
available channels. The scan may take
several minutes.
• Select Yes, then press ENTER if a cable box
is connected. A message asks how you
connected the cable box to your TV:
• Select AV, Component, or HDMI, then
press ENTER if you connected a cable
box to your TV using one of these
cables. Read the message, then press
ENTER to close the wizard.
• Select Coaxial, then press ENTER if you
connected a cable box to your TV using
a coaxial cable. Read the message, then
press ENTER to start the channel scan.
C If you select Satellite Box, a message asks
how you connected the satellite box to
your TV:
• Select AV, Component, or HDMI, then
press ENTER if you connected a satellite
box to your TV using one of these cables.
Read the message, then press ENTER to
close the wizard.
• Select Coaxial, then press ENTER if you
connected a satellite box to your TV using
a coaxial cable. Read the message, then
press ENTER to start the channel scan.
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
CHANNELS
SETTINGS
PHOTOS
AUDIO
Channels
Auto Channel Search
Add/Skip Channels
Favorites
Channel Strength
Audio Only On
Auto Zoom Off
Automatically search for channels, press ENTER key to submenu
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Cable
Choose Your TV Source
Satellite Box
Antenna
CHANNELS
SETTINGS
PHOTOS
AUDIO
Channels
Auto Channel Search
Select if using an antenna for standard or HD TV.
P
H
O
T
OS
Note
You can press EXIT to stop the auto channel search,
but you will need to run the auto channel search
again to create a channel list.
Note
You can press EXIT to stop the auto channel search,
but you will need to run the auto channel search
again to create a channel list.
Note
You can press EXIT to stop the auto channel search,
but you will need to run the auto channel search
again to create a channel list.
Note
You can press EXIT to stop the auto channel search,
but you will need to run the auto channel search
again to create a channel list.
28
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Hiding channels
You can hide channels in the channel list. When you
press CH
or CH
, your TV/DVD combo skips the
hidden channels. You can still tune to a hidden
channel by pressing the number buttons for the
channel.
To hide channels:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight CHANNELS, then press
or ENTER
/
. The Channels menu opens.
3 Press
or
to highlight Add/Skip Channels,
then press ENTER
/
. The Channels · Add/Skip
Channels screen opens.
4 Press
or
to highlight the channel you
want to hide, then press ENTER
/
. The check
mark disappears.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Setting up a favorite channel list
You can create a favorite channel list so you can
quickly browse through your favorite channels by
pressing FAV, then selecting a channel from the
favorite channel list.
To set up a favorite channel list:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight CHANNELS, then press
or ENTER
/
. The Channels menu opens.
3 Press
or
to highlight Favorites, then press
ENTER
/
. The Channels · Favorites screen
opens.
Notes
• A channel with a check mark is not hidden. A
channel with no check mark is hidden.
• If the list has more than one page, press
or
to scroll through the pages.
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
Channels
Auto Channel Search
Add/Skip Channels
Favorites
Channel Strength
Audio Only Off
Auto Zoom Off
Manually add and skip channels in your program list.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Manually add and skip channels in your program list.
Channels
Add/Skip Channels
2-1 WGBH-SD
2-10 WGBH-DX
6 Analog
8 Analog
9 Analog
10 Analog
1-1 Ch1
12-2 PBS-HD
13 Analog
17 Analog
18 Analog
21 Analog
11-2 Sencore
Page 1/1
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
CHANNELS
SETTINGS
PHOTOS
AUDIO
Channels
Auto Channel Search
Add/Skip Channels
Favorites
Channel Strength
Audio Only Off
Auto Zoom Off
Add channels to create a favorite list.
S
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Add channels to create a favorite list.
Channels
Favorites
2-1 WGBH-SD
2-10 WGBH-DX
6 Analog
8 Analog
9 Analog
10 Analog
1-1 Ch1
12-2 PBS-HD
13 Analog
17 Analog
18 Analog
21 Analog
11-2 Sencore
Page 1/1
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
29
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
4 Press
or
to highlight the channel you
want to add to the favorites list, then press
ENTER
/
. A check mark appears next to the
channel.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Viewing a favorite channel
To view a favorite channel:
1 Press FAV. The favorite channel list opens.
2 Press
or
to highlight a channel, then press
ENTER
/
.
Checking the digital signal strength
You can check the digital signal strength to
determine if you need to adjust your antenna or
digital cable input. The higher the signal strength,
the less likely you are to experience picture
degradation.
To check the digital signal strength:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight CHANNELS, then press
or ENTER
/
. The Channels menu opens.
3 Press
or
to highlight Channel Strength,
then press ENTER
/
. The signal strength
meter is displayed.
4 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Setting parental controls
Parental controls let you prevent your children from
watching inappropriate material on TV. When set,
parental controls read the rating of the program
(with some exceptions, such as news and sports)
and deny access to programs that exceed the
ratings level you select. To watch programs that
exceed the selected rating, you must enter a
password.
Setting or changing the password
To set or change the password:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight SETTINGS, then press
or ENTER
/
. The Settings menu opens with
Parental Controls highlighted.
3 Press ENTER
/
. The Enter password screen
opens.
Notes
• To remove a channel from the favorites list,
highlight the channel, then press
ENTER
/
. The check mark disappears and
the channel is removed from the list.
• If the list has more than one page, press
or
to scroll through the pages.
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
CHANNELS
SETTINGS
PHOTOS
AUDIO
Channels
Auto Channel Search
Add/Skip Channels
Favorites
Channel Strength
Audio Only Off
Auto Zoom Off
Display signal strength of selected digital channels.
P
H
O
T
OS
Channel Strength
Now 67 %
0
100
CH 2-1
Peak 67 %
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Set TV parental controls.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
CHANNELS
SETTINGS
PHOTOS
AUDIO
Enter your 4-digit password. Default is 0000.Please change your password
Enter password
P
H
O
T
OS
30
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
4 Press the number buttons to enter the four-digit
password. The default password is 0000. You
should change the password to a number you
can remember. The Settings · Parental Controls
menu opens.
5 Press
or
to highlight Change Password,
then press ENTER
/
. The Settings · Parental
Controls · Change Password screen opens.
6 Press the number buttons to enter a password,
then enter the password again.
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Locking control buttons
When the button lock is turned On, the buttons on
the top of your TV/DVD combo are locked, and you
can only operate your TV/DVD combo using the
remote control.
To lock control buttons:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight SETTINGS, then press
or ENTER
/
. The Settings menu opens with
Parental Controls highlighted.
3 Press ENTER
/
. The Enter password screen
opens.
4 Press the number buttons to enter the four-digit
password. The Settings · Parental Controls menu
opens with Button Lock highlighted.
5 Press ENTER
/
.
6 Press
or
to select On (locks the buttons) or
Off (unlocks the buttons), then press
ENTER/ .
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Note
If you forget your password, enter 9999.
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Settings
• Parental Controls
Button Lock
Block Unrated TV
USA Parental Locks
Canadian Parental Locks
Change Password
RRT5
Enter a new 4-digit password then re-enter it for confirmation.
Off
Off
Reset RRT5
CHANNELS
SETTINGS
PHOTOS
AUDIO
PH
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls Change Password
CHANNELS
SETTINGS
PHOTOS
AUDIO
Enter a new 4-digit password then re-enter it to confirm.
Enter new password
Confirm new password
PH
O
T
O
S
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Set TV parental controls.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
CHANNELS
SETTINGS
PHOTOS
AUDIO
Enter your 4-digit password. Default is 0000.Please change your password
Enter password
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
CHANNELS
SETTINGS
PHOTOS
AUDIO
Button Lock
Block Unrated TV
USA Parental Locks
Canadian Parental Locks
Change Password
RRT5
Lock or unlock the buttons on the TV
Off
Off
Reset RRT5
P
H
O
T
OS
31
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Blocking unrated TV
To block unrated TV:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight SETTINGS, then press
or ENTER
/
. The Settings menu opens with
Parental Controls highlighted.
3 Press ENTER
/
. The Enter password screen
opens.
4 Press the number buttons to enter the four-digit
password. The Settings · Parental Controls menu
opens.
5 Press
or
to highlight Block Unrated TV,
then press ENTER
/
.
6 Press
or
to select On (to block unrated TV)
or Off (to unblock unrated TV), then press
ENTER
/
.
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Setting parental control levels
You can set parental controls for the U.S. and
Canada.
U.S. rating levels
Some of the age-based TV Parental Guidelines
ratings also have content-based ratings.
Canadian rating levels
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Set TV parental controls.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
CHANNELS
SETTINGS
PHOTOS
AUDIO
Enter your 4-digit password. Default is 0000.Please change your password
Enter password
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
CHANNELS
SETTINGS
PHOTOS
AUDIO
Button Lock
Block Unrated TV
USA Parental Locks
Canadian Parental Locks
Change Password
RRT5
Block TV programs that do not have a rating.
Off
Off
Reset RRT5
P
H
O
T
OS
U.S. TV ratings
NONE Not rated
TV-Y All children
TV-Y7 Suitable for children 7 and older
TV-G General audiences
TV-PG Parental guidance suggested
TV-14 Parental guidance strongly suggested
TV-MA Mature audiences only
U.S. TV content ratings
All All ratings are blocked
FV Fantasy violence
L Strong language
S Sexual situations
V Violence
D Suggestive dialog
U.S. movie (MPAA) ratings
None Movie not rated
G General audiences
PG Parental guidance suggested
PG-13 Suitable for children 13 and older
R Parental guidance suggested for
children under 17
NC-17 Not suitable for children under 17
X Adults only
Canadian English ratings
E Exempt programming
C Suitable for all children
C8+ Suitable for children 8 and older
G General audiences
PG Parental guidance suggested
14+ Suitable for children 14 and older
18+ Adult only
32
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
To set parental control levels:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight SETTINGS, then press
or ENTER
/
. The Settings menu opens with
Parental Controls highlighted.
3 Press ENTER
/
. The Enter password screen
opens.
4 Press the number buttons to enter the four-digit
password. The Settings · Parental Controls menu
opens.
5 Press
or
to highlight USA Parental Locks,
then press ENTER
/
. (To set Canadian ratings,
select Canadian Parental Locks.)
USA Parental Locks
Canadian Parental Locks
6 Press
or
to highlight:
• Movie Rating or TV Rating for USA ratings.
• Canadian English or Canadian French for
Canadian ratings.
7 Press
or
to select the rating. If a rating has
sub-ratings, press
or
to highlight a
sub-rating.
8 Press ENTER
/
to confirm. A lock symbol
appears when a rating is blocked.
9 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Canadian French ratings
E Exempt programming
G General audiences
8ans+ Suitable for children 8 and older
13ans+ Suitable for children 13 and older
16ans+ Suitable for children 16 and older
18ans+ Adult only
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Set TV parental controls.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
CHANNELS
SETTINGS
PHOTOS
AUDIO
Enter your 4-digit password. Default is 0000.Please change your password
Enter password
P
H
O
T
OS
Note
When you block a rating, that rating and all higher
ratings are blocked.
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
CHANNELS
SETTINGS
PHOTOS
AUDIO
Button Lock
Block Unrated TV
USA Parental Locks
Canadian Parental Locks
Change Password
RRT5
Restrict movie and TV programs by US Ratings.
Off
Off
Reset RRT5
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
CHANNELS
SETTINGS
PHOTOS
AUDIO
Settings
Parental Controls
USA Parental Locks
USA Parental Locks
Movie Ratings
TV Ratings
None
G
PG
PG-13
R
NC-17
X
None
TV-Y
TV-Y7
TV-G
TV-PG
TV14
TV-MA
All FV L S V D
Restrict movie and TV programs by US Ratings.
P
H
O
T
O
S
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
Settings
Parental Controls
Canadian Parental Locks
Canadian Parental Locks
Canadian English
E
C
C8+
G
PG
14+
18+
Canadian French
E
G
8 ans+
13 ans+
16 ans+
18 ans+
Restrict movie and TV programs by Canadian Ratings.
CHANNELS
SETTINGS
PHOTOS
AUDIO
PH
O
T
O
S
33
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Downloading rating information
You can download rating information to use when
setting parental controls.
To download rating information:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight SETTINGS, then press
or ENTER
/
. The Settings menu opens with
Parental Controls highlighted.
3 Press ENTER
/
. The Enter password screen
opens.
4 Press the number buttons to enter the four-digit
password. The Settings · Parental Controls menu
opens.
5 Press
or
to highlight RRT5, then press
ENTER
/
.
If the program is broadcast with RRT5 rating
information, the information is downloaded
automatically and can be used for parental
controls.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Using closed captioning
Turning closed captioning on or off
To turn closed captioning on or off:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight SETTINGS, then press
or ENTER
/
. The Settings menu opens.
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Set TV parental controls.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
Settings
Parental Controls
CHANNELS
SETTINGS
PHOTOS
AUDIO
Enter your 4-digit password. Default is 0000.Please change your password
Enter password
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
Settings
Parental Controls
CHANNELS
SETTINGS
PHOTOS
AUDIO
Button Lock
Block Unrated TV
USA Parental Locks
Canadian Parental Locks
Change Password
RRT5
Display an advanced V-Chip ratings table for digital channels.
Off
Off
Reset RRT5
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Adjust Closed Captioning settings.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
34
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
3 Press
or
to highlight Closed Caption, then
press ENTER
/
. The Settings · Closed Caption
menu opens.
4 Press
or
to highlight Caption Control, then
press ENTER
/
. A menu opens.
5 Press
or
to select CC Off (turns off closed
captioning), CC On (turns on closed captioning),
or CC On When Mute (turns on closed
captioning when the sound is muted), then
press ENTER
/
.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Selecting the analog closed captioning mode
To select the analog closed captioning mode:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight SETTINGS, then press
or ENTER
/
. The Settings menu opens.
3 Press
or
to highlight Closed Caption, then
press ENTER
/
. The Settings · Closed Caption
menu opens.
4 Press
or
to highlight Analog Caption, then
press ENTER
/
. A menu opens.
5 Press
or
to select an analog caption setting,
then press ENTER
/
. You can select:
• CC1 through CC4—Closed captioning
appears in a small banner across the bottom
of the screen. CC1 is usually the “printed”
version of the audio. CC2 through CC4 display
content provided by the broadcaster.
• Text1 through Text4—Closed captioning
covers half or all of the screen. Text1 through
Text4 display content provided by the
broadcaster.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Customizing digital closed captioning styles
To customize digital closed captioning styles:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight SETTINGS, then press
or ENTER
/
. The Settings menu opens.
Note
You can also press CCD to turn closed captioning on
or off.
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Closed Caption
CHANNELS
SETTINGS
PHOTOS
AUDIO
CC Off
CC 1
CS 1
Caption Control
Analog Caption
Digital Caption
Digital CC Settings
Adjust Closed Captioning settings.
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Adjust Closed Captioning settings.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Settings
Closed Caption
CHANNELS
SETTINGS
PHOTOS
AUDIO
Caption Control
Analog Caption
Digital Caption
CC Off
CC1
CS1
Digital CC Settings
Set Closed Caption for standard (analog) programs.
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Adjust Closed Captioning settings.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
35
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
3 Press
or
to highlight Closed Caption, then
press ENTER
/
. The Settings · Closed Caption
menu opens.
4 Press
or
to highlight Digital Caption, then
press ENTER
/
. A menu opens.
5 Press
or
to highlight a digital caption
setting, then press ENTER
/
. You can select
CS1 through CS6 and CC1 through CC4.
6 Press
or
to highlight Digital CC Settings,
then press ENTER
/
. The Settings · Closed
Caption · Digital CC Settings menu opens with
Style highlighted.
7 Press ENTER
/
, press
or
to select
Custom, then press ENTER
/
again.
8 Press
or
to highlight an option, then press
ENTER
/
. You can select:
• Size—Selects the font size.
• Font—Selects the font style.
• Text Color—Selects the color for the words.
• Text Opacity—Selects the opacity level for
the words.
• Background Color—Selects the color for the
background.
• Background Opacity—Selects the opacity
level for the background.
9 Press
or
to select a setting, then press
ENTER
/
. Repeat this step to adjust other
options.
10 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Adjusting time settings
Setting the clock
To set the clock:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight SETTINGS, then press
or ENTER
/
. The Settings menu opens.
3 Press
or
to highlight Time, then press
ENTER
/
. The Settings · Time menu opens.
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Closed Caption
CHANNELS
SETTINGS
PHOTOS
AUDIO
Caption Control
Analog Caption
Digital Caption
CC Off
CC1
CS1
Digital CC Settings
Set Closed Caption for digital programs.
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
Settings
Closed Caption Digital CC Settings
CHANNELS
SETTINGS
PHOTOS
AUDIO
Style
Size
Font
Text Color
Text Opacity
Background Color
Background Opacity
Custom
Normal
Default
White
Solid
Black
Solid
Set the look of digital CC. Automatic uses broadcaster’s style.
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Set Date/Time and Sleep Timer.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Time
Date/Time
ffOp TimereelS
Adjust the date and time to get the correct program times.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
36
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
4 Press
or
to highlight Date/Time, then press
ENTER
/
. The Settings · Time · Date/Time
menu opens.
5 Press
or
to highlight Mode, then press
ENTER
/
. A menu opens.
6 Press
or
to highlight Manual (to set the
options manually) or Auto (the options are
automatically set by the TV signal source).
7 Press ENTER
/
to close the menu.
8 Press
or
to highlight Time Zone, then press
ENTER
/
.
9 Press
or
to select your time zone, then press
ENTER
/
. You can select Eastern, Central,
Mountain, Pacific, Alaska, Hawaii, Atlantic or
Newfoundland.
10 If your viewing area observes daylight savings
time, press
or
to highlight Daylight
Savings, then press ENTER
/
.
11 Press
or
to select On or Off, then press
ENTER
/
to close the menu.
12 If you selected Manual for Mode:
• Press
or
to highlight Year, Month, or Day,
then press
or
to adjust the setting, then
press ENTER
/
.
• Press
or
to highlight Time, press
or
to
highlight the hour, minute, or AM/PM field,
then press
or
to adjust the setting. When
you are finished, press ENTER
/
.
13 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Setting the sleep timer
You can specify the amount of time before your
TV/DVD combo automatically turns off.
To set the sleep timer:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight SETTINGS, then press
or ENTER
/
. The Settings menu opens.
3 Press
or
to highlight Time, then press
ENTER
/
. The Settings · Time menu opens.
4 Press
or
to highlight Sleep Timer, then
press ENTER
/
.
5 Press
or
to select the amount of time before
your TV/DVD combo turns off automatically,
then press ENTER
/
. You can select Off, 5, 10,
15, 30, 60, 90, 120, 180, or 240 minutes.
To turn off the sleep timer, select Off.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Adjusting menu settings
Selecting the menu language
To select the menu language:
1 Press MENU. The on-screen menu opens.
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Settings
Time Date/Time
Mode
TIme Zone
Daylight Savings
Year
Month
Day
Time
Auto
Pacific
On
2012
January
1
12:50 AM
If Automatic, options are automatically set by TV source.
CHANNELS
SETTINGS
PHOTOS
AUDIO
PH
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
Note
You can also press SLEEP/ to set the sleep timer.
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Set Date/Time and Sleep Timer.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
Settings
Time
CHANNELS
SETTINGS
PHOTOS
AUDIO
Date/Time
Sleep Timer Off
Set a time for the TV to turn off automatically.
P
H
O
T
OS
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
37
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
2 Press
or
to highlight SETTINGS, then press
or ENTER
/
. The Settings menu opens.
3 Press
or
to highlight Menu Language, then
press ENTER
/
.
4 Press
or
to highlight a language, then press
ENTER
/
. You can select English, Français, or
Español.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Restoring settings to the defaults
When you restore default settings, all the settings
you have customized (except the password and
parental rating) are reset.
To restore settings to the defaults:
1 Press MENU. The on-screen menu opens.
2 Press
or
to highlight SETTINGS, then press
or ENTER
/
. The Settings menu opens.
3 Press
or
to highlight Reset to Default, then
press ENTER
/
. The Settings · Reset to Default
menu opens.
4 Press
or
to highlight Reset to Default, then
press ENTER
/
. A menu opens.
5 Press
or
to select YES (to reset) or NO (to
not reset), then press ENTER
/
.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Using a USB flash drive
You can connect a USB flash drive to your TV/DVD
combo to view compatible JPEG pictures.
Switching to USB mode
To switch to USB mode:
1 Make sure that you have connected the USB
flash drive to the USB port on your TV/DVD
combo.
2 Press INPUT. The Input Source list opens.
3 Press
or
to highlight USB (Photos), then
press ENTER
/
.
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
CHANNELS
SETTINGS
PHOTOS
AUDIO
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Set menu language to English, Francais, or Español
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
Picture Mode Vivid
Brightness 73
Contrast 72
Color 62
Advanced Video
Reset Picture Settings
Adjust settings to affect picture quality.
CHANNELS
SETTINGS
PHOTOS
AUDIO
P
H
O
T
OS
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
CHANNELS
SETTINGS
PHOTOS
AUDIO
Settings
Parental Controls
Closed Caption
Time
Menu Language English
Computer Settings
System Info
Reset to Default
Change power on options or reset TV to factory default
P
H
O
T
OS
Notes
• Never remove the USB flash drive or turn off
your TV/DVD combo while viewing JPEG
pictures.
• The JPEG picture viewer only supports JPEG
format images (with “.jpg” file extensions) and
not all JPEG files are compatible with your
TV/DVD combo.
• The USB flash drive must less than 2.2 inches
(55 mm) in length. A longer flash drive will not
fit.
Note
To exit USB mode, press INPUT to open the Input
Source list, then select another input source.
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Settings
Reset to Default
CHANNELS
SETTINGS
PHOTOS
AUDIO
Power on In Vivid Mode
Retail Banner
Reset to Default
Reset to Default
P
H
O
T
OS
38
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Browsing photos
To browse photos:
1 Switch to USB mode. See “Switching to USB
mode” on page 37. The on-screen menu opens
with the Photos menu displayed.
2 Press
or
to highlight Browse Photos, then
press ENTER
/
. The screen displays folder
names and photo files stored on the USB flash
drive in a thumbnail index with the first photo
or folder highlighted. A control bar appears at
the bottom of the screen.
3 To navigate the thumbnail index screen, press:
•
or
to browse through the files and
folders.
• ENTER
/
to view a highlighted photo
full-screen or open a highlighted folder.
• MENU to open the Photos menu.
• FAV to add or remove a photo from the
favorite photo list. A heart appears on a photo
that has been added to the favorite photo list.
When a photo is displayed full-screen, a control
bar appears at the bottom of the photo. The file
name, picture resolution, size, and date are
displayed on the bottom of the control bar. If
you do not press a button within 10 seconds,
the control bar closes. Press INFO/ to open the
control bar again.
4 To navigate on the photo screen, press:
•
to go to the previous photo.
•
to go to the next photo.
• ENTER
/
to rotate the photo clockwise.
• ZOOM/ one or more times to enlarge the
image by 2×, or 4× or select Fill (to fill the
screen). You can press
or
to pan the
photo.
• EXIT to return to the thumbnail index.
• MENU to return to the Photos menu.
Viewing favorite photos
After you created your favorite photo list, you can
browse among your favorite photos quickly.
To view favorite photos:
1 Switch to USB mode. See “Switching to USB
mode” on page 37. The on-screen menu opens
with the Photos menu displayed.
Note
You can also press MENU to open the Photos menu.
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
CHANNELS
SETTINGS
PHOTOS
AUDIO
Photos
Browse Photos
Favorite Photos
View Slideshow
Settings
Find photos that are on the USB flash drive.
C
HANNEL
S
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
Note
You can also press MENU to open the Photos menu.
Picture 6081
800 x 600 163.2KB 01/08/2012 Fill
OK
ENTER
MENU EXIT
EXITPREVIOUS
ROTATE
MOVE
ZOOM
ZOOM
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
CHANNELS
SETTINGS
PHOTOS
AUDIO
Photos
Browse Photos
Favorite Photos
View Slideshow
Settings
View only the photos you selected as your favorites
C
HANNEL
S
39
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
2 Press
or
to highlight Favorite Photos, then
press ENTER
/
. A thumbnail index of your
favorite photos opens with a control bar at the
bottom of the screen.
You select photos and navigate on the photo
screen in the same way you do when you are
browsing through photos. For more
information, see “Browsing photos” on page 38.
Viewing photos in a slideshow
You can view your photos in a slideshow.
To view photos in a slideshow:
1 Switch to USB mode. See “Switching to USB
mode” on page 37. The on-screen menu opens
with the Photos menu displayed.
2 Press
or
to highlight View Slideshow, then
press ENTER
/
. A slideshow starts with the
first photo in the current folder.
3 To control the slideshow, press:
• ENTER
/
to pause or start the slideshow.
• EXIT to exit the slideshow and return to
thumbnail index.
• MENU to go to the Photos menu.
Customizing slideshow settings
You can customize the slideshow settings,
including Repeat, Shuffle, Speed, and Transition.
To customize slideshow settings:
1 Switch to USB mode. See “Switching to USB
mode” on page 37. The on-screen menu opens
with the Photos menu displayed.
2 Press
or
to highlight SETTINGS, then press
ENTER
/
. The Photos · Settings menu opens.
3 Press
or
to highlight an option, then press
ENTER
/
. You can select:
• Repeat—Repeats the slideshow when it
reaches the end. You can select On or Off.
• Shuffle—Displays the slideshow photos in
random order. You can select On or Off.
• Speed—Sets the amount of time a photo is
displayed before the slideshow moves to the
next photo. You can select 4 sec, 6 sec, or
8 sec.
• Transition—Selects the way photos transition
when moving to the next file in the slideshow.
You can select:
• None—No transition effect.
• Fade to Black—Fades the screen to black
between photos.
• Vertical Wipe—Wipes the screen from left
to right between photos.
• Horizontal Wipe—Wipes the screen from
top to bottom between photos.
• Random—Randomly selects a transition
effect.
4 Press EXIT to close the menu.
Note
You can also press MENU to open the Photos menu.
MOVE
OK
ENTER
MENU
EXIT
EXIT
PREVIOUS
SELECT
MOVE
OK
ENTER
MENU EXIT
EXIT
PREVIOUS
SELECT
CHANNELS
SETTINGS
PHOTOS
AUDIO
Photos
Browse Photos
Favorite Photos
View Slideshow
Settings
View your photos in a slideshow
C
HANNEL
S
Note
You can also press MENU to open the Photos menu.
MOVE
OK
ENTER
MENU EXIT
EXITPREVIOUS
SELECT
CHANNELS
SETTINGS
PHOTOS
AUDIO
Photos
Browse Photos
Favorite Photos
View Slideshow
Settings
Change slideshow settings
C
HANNEL
S
MOVE
OK
ENTER
MENU
EXIT
EXITPREVIOUS
SELECT
CHANNELS
SETTINGS
PHOTOS
AUDIO
Repeat
Shuffle
Speed
Transition
Off
Off
6sec
None
Repeat the slideshow when it reaches the end
Photos
Settings
C
HANNEL
S
40
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Using the DVD player
Most DVDs and your TV/DVD combo have region
codes that help control illegal distribution of DVDs.
The region code for your TV/DVD combo is 1. You
can only play DVDs with a region code of 1 or ALL.
The region code for a DVD is printed on the DVD or
the DVD packaging. See “DVD player” on page 46
for a list of compatible disc formats.
Playing a disc
To play a disc:
1 Press (power) to turn on your TV/DVD combo.
2 Insert a disc into the disc slot with the label
facing forward.
Your TV/DVD combo automatically switches to
DVD mode and displays the Loading screen for a
few seconds.
If you inserted a DVD or video CD and the disc
has a root menu, this menu is displayed. Use
to select menu options. If the disc does
not have a root menu, playback starts
automatically.
OR
If you inserted an audio CD, a file browser screen
is displayed and playback starts automatically.
Controlling disc playback
To control disc playback:
• Press VOL+ or VOL– to adjust the volume.
• Press (play/pause) to pause playback. Press
again to resume playback.
• Press (skip back) to go to the previous chapter
or track. Press (skip forward) to go to the next
chapter or track.
• Press (fast reverse) to quickly move backward
on a disc. Press (fast forward) to quickly move
forward on a disc. Each time you press one of
these buttons, the speed changes. Speeds are 2×,
4×, 8×, 16×, and 32×. Press (play/pause) to
resume normal playback.
• Press (stop) once to stop playback. Press
(play/pause) to resume playback from the
stopping point.
• Press (stop) twice to completely stop playback.
When you press (play/pause), playback starts
at the beginning of the disc.
Ejecting a disc
To eject a disc:
• Press (eject). When your TV/DVD combo ejects
the disc, remove the disc from the disc slot.
Creating a playback loop
To create a playback loop:
1 Play the disc until you reach the point where
you want the playback loop to start, then press
A-B.
2 Continue playing the disc until you reach the
point where you want the playback loop to end,
then press A-B. Your TV/DVD combo plays the
loop repeatedly.
3 Press A-B to cancel the playback loop and
resume normal playback.
Repeating a disc title, chapter, or track
To repeat a disc title, chapter, or track:
• Press REPEAT one or more times.
• For a DVD, you can select Chapter, Title, or
All.
• For a CD, you can select Track or All.
Changing DVD settings:
To change DVD settings:
1 In DVD mode, press HOME. The on-screen menu
opens.
2 Press
or
to select a menu, then press
ENTER
/
or
. The menu opens.
3 Press
or
to select an option, then press
ENTER
/
or
to access the settings.
Warning
Keep your fingers clear of the disc slot when loading
or unloading a disc. Neglecting to do so may cause
serious personal injury.
Loading...
41
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
4 Press
or
to select a setting, then press
ENTER
/
.
5 To close the on-screen menu, press
or
to
select Exit Setup Mode, then press ENTER
/
.
On-screen DVD menus
Language setup menu
Language setup menu options:
• OSD—Selects menu language of DVD mode.
You can select English, French, or Spanish.
• Menu—Selects the menu language for the
DVD disc. You can select English, French, or
Spanish. (The supported languages depends
on the DVD.)
• Audio—Selects the DVD audio language. You
can select English, French, or Spanish. (The
supported languages depends on the DVD.)
• Subtitle—Selects the DVD subtitle language.
You can select English, French, Spanish, or
Off. (The supported languages depends on
the DVD.)
Screen setup menu
Screen setup menu options:
• TV Type—Selects the aspect ratio of the DVD
playback. You can select:
• 4:3 PS—Displays at 4:3 pan scan. Black
bars appear on the top and bottom of the
image.
• 4:3 LB—Displays at 4:3 letter box. The
image is stretched to fill the screen.
• 16:9—Displays at 16:9 aspect ratio. Select
this option to view DVDs that were
recorded in wide-screen format.
• Screen Saver—Sets the TV to energy saving
mode when there is no operation or no DVD
disc is inserted in DVD mode. You can select
On or Off. If you select On, a screen saver
appears on the screen.
• Last Memory—Lets DVD playback resume at
the point where you stopped playback and
turned your TV/DVD combo off. You can select
On or Off.
Audio setup menu
Audio setup menu option:
• Downmix—Selects the audio downmix mode
for external speakers. You can select:
• Lo/Ro—Provides a stereo mix of sound
from the center, front left, and front right
speakers.
• Lt/Rt—Provides a surround-sound mix of
sound from the center, front left, front
right, rear left, and rear right speakers.
Custom setup menu
Custom setup menu options:
• Parental Ctrl—Sets viewing restrictions
based on disc content. You can select KidSafe,
G, PG, PG-13, PG-R, R, NC-17, Adult, or Off.
Hightlight Parental Ctrl, then press
ENTER/ You are prompted to enter your
password. Enter your password, then press
ENTER/ to access the menu options.
Language Setup
Menu
Audio
Subtitle
: Select
OSD
Screen Setup
Screen Saver
Last Memory
: Select
TV Type
Tip
If you try to watch a DVD that is restricted, you are
prompted to enter your password to bypass the
parental controls. Enter your password.
Parental controls are reset when you:
• Turn off your TV/DVD combo
• Remove the disc
• Switch to another video input source
Audio Setup
: Select
Downmix
Custom Setup
: Select
Parental Ctrl
Password ...
Style
Angle Mark
42
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
• Password—Sets the password for the
parental control setting.
To change the password, enter the old
(default) password, then enter the new
password twice. The default password is 0000.
• Style—Selects the background color of the
on-screen menu in DVD mode. You can
choose one of four styles: Style1, Style2,
Style3, Style4.
• Angle Mark—This option is not available on
this model.
• Default—Resets DVD settings to factory
default.
Maintaining
• Do not use your TV/DVD combo in areas that are
too hot or too cold, because the cabinet may warp
or the screen may malfunction. Your TV/DVD
combo works best in temperatures that are
comfortable to you.
• Storage temperatures are 32° to 122°F (0° to 50°C).
• Working temperatures are 41° to 104°F
(5° to 40°C).
• Do not place your TV/DVD combo in direct
sunlight or near a heat source.
Cleaning the TV cabinet
Clean the cabinet with a soft, lint-free cloth. If the
cabinet is especially dirty, moisten a soft, lint-free
cloth in a weak detergent solution, squeeze the
excess moisture from the cloth, then wipe the
cabinet with the cloth. Use a clean cloth to dry the
cabinet.
Cleaning the TV screen
Clean the screen with a soft, lint-free cloth.
Care and handling of discs
Handling discs
Do not touch the playback side of the disc. Hold the
disc by the edges so that fingerprints do not get on
the surface. Never stick paper or tape on the disc.
Storing discs
After playing, store the disc in its case. Do not
expose the disc to direct sunlight or sources of heat
and never leave it in a parked car exposed to direct
sunlight.
Cleaning discs
Fingerprints and dust on the disc can cause poor
picture quality and sound distortion. Before
playing, clean the disc with a clean cloth. Wipe the
disc from the center out.
Troubleshooting
Video and audio
Note
If you forget your password, enter 9922.
Warning
Do not try to repair your TV/DVD combo yourself.
Contact authorized service personnel.
Problem Solution
Picture does not fill the
screen. There are black bars
around the picture.
• Change the aspect ratio. An increasing amount
of digital TV and movies are presented in wide
screen (16:9). See “Aspect ratio options” on
page 23.
No picture (screen is not lit)
and no sound.
• Press on the TV/DVD combo or the remote
control.
• Make sure that the video cables are connected
securely to your TV/DVD combo.
• Adjust the contrast and brightness. See
“Adjusting the TV picture” on page23.
• Make sure that the power cord is plugged in.
• Make sure that the correct video input source is
selected. See “Selecting the video input source”
on page 21.
• Try another channel. The station may be
experiencing problems.
• Make sure that the incoming signal is
compatible.
• Make sure that the antenna or cable TV is
connected correctly and securely. See
“Connecting a cable or satellite box” on page 9
or “Connecting an antenna or cable TV (no box)”
on page 12.
• Check the closed caption settings. Some TEXT
modes can block the screen.
43
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Dark, poor, or no picture
(screen is lit), but sound is
good.
• Try another channel. The station may be
experiencing problems.
• Make sure that the Audio Only option is set to
Off. See “Playing TV audio only” on page 26.
• Make sure that the antenna or cable TV is
connected correctly and securely. See
“Connecting a cable or satellite box” on page 9
or “Connecting an antenna or cable TV (no box)”
on page 12.
• Adjust the brightness. See “Adjusting the TV
picture” on page 23.
• Make sure that the correct picture mode is
selected. See “Adjusting the TV picture” on
page 23.
• If you are using an antenna, the digital channel
signal may be low. To check the digital channel
signal strength, see “Checking the digital signal
strength” on page 29.
• If you are using an antenna and the signal
strength is low, adjust the antenna or use a
highly directional outdoor antenna or set-top
antenna with a built-in amplifier.
• Make sure that the video cables are connected
securely to your TV/DVD combo.
• The video cable(s) you are using may be bad. Try
a new set.
• Try another channel. The station may be
experiencing problems.
No color, dark picture, or
color is not correct.
• Try another channel. The station may be
experiencing problems.
• Adjust the color settings. See “Adjusting the TV
picture” on page 23.
• Make sure that the video cables are connected
correctly and securely to your TV/DVD combo.
• Make sure that the antenna or cable TV/DVD
combo is connected correctly and securely. See
“Connecting a cable or satellite box” on page 9
or “Connecting an antenna or cable TV (no box)”
on page 12.
• If you are using an antenna, the digital channel
signal may be low. To check the digital channel
signal strength, see “Checking the digital signal
strength” on page 29.
• If you are using an antenna and the signal
strength is low, adjust the antenna or use a
highly directional outdoor antenna or set-top
antenna with a built-in amplifier.
Only snow (noise) appears
on the screen.
• Try another channel. The station may be
experiencing problems.
• Make sure that the antenna or cable TV/DVD
combo is connected correctly and securely. See
“Connecting a cable or satellite box” on page 9
or “Connecting an antenna or cable TV (no box)”
on page 12.
• If you are using an antenna, the digital channel
signal may be low. To check the digital channel
signal strength, see “Checking the digital signal
strength” on page 29.
• If you are using an antenna and the signal
strength is low, adjust the antenna or use a
highly directional outdoor antenna or set-top
antenna with a built-in amplifier.
Picture quality is good on
some channels and poor on
others. Sound is good.
• The problem may be caused by a poor or weak
signal from the broadcaster or cable TV provider.
• If you connect to cable or satellite TV without a
set-top box and experience poor picture quality,
you may need to install a set-top box to improve
signal reception and picture quality. Contact
your cable or satellite TV provider about
upgrading to a set-top box.
Problem Solution
Dotted lines or stripes
appear on the screen.
• Make sure that the antenna or cable TV is
connected correctly and securely. See
“Connecting a cable or satellite box” on page 9
or “Connecting an antenna or cable TV (no box)”
on page 12.
• If you are using an antenna, the digital channel
signal may be low. To check the digital channel
signal strength, see “Checking the digital signal
strength” on page 29.
• If you are using an antenna and the signal
strength is low, adjust the antenna or use a
highly directional outdoor antenna or set-top
antenna with a built-in amplifier.
• Make sure that the video cables are connected
securely to your TV/DVD combo.
• The video cable(s) you are using may be bad. Try
a new set.
• Other devices (for example, a surround sound
receiver, external speakers, fans, or hair dryers)
may be interfering with your TV/DVD combo. Try
turning off one device at a time to determine
which device is causing interference. After you
have determined which device is causing
interference, move it further from the TV/DVD
combo to eliminate the interference.
Double images.
• Use a highly directional outdoor antenna, cable
TV, or satellite TV.
The picture has a few bright
or dark spots.
• A few bright or dark spots on an LCD screen is
normal. It does not affect the operation of
your TV/DVD combo.
Good picture, but no sound.
• Increase the volume.
• Make sure that the sound is not muted.
• Make sure you do not have headphones
connected. When headphones are connected,
no sound comes from the TV/DVD combo
speakers.
• Make sure that the correct audio mode is
selected.
• Make sure that the audio cables are connected
correctly and securely to your TV/DVD combo.
• Make sure that the antenna or cable TV is
connected correctly and securely. See
“Connecting a cable or satellite box” on page 9
or “Connecting an antenna or cable TV (no box)”
on page 12.
• If you are using an antenna, the digital channel
signal may be low. To check the digital channel
signal strength, see “Checking the digital signal
strength” on page 29.
• The audio cable(s) you are using may be bad. Try
a new set.
Poor picture.
• Make sure that the room is not too bright. Light
reflecting off the screen can make the picture
difficult to see.
• If an S-VHS camera or a camcorder is connected
while another connected device is turned on,
the picture may be poor. Turn off one or more
devices.
Good sound but poor color.
• Adjust the contrast, color, and brightness
settings. See “Adjusting the TV picture” on
page 23.
Audio noise.
• Other devices (for example, a surround sound
receiver, external speakers, fans, or hair dryers)
may be interfering with your TV/DVD combo. Try
turning off one device at a time to determine
which device is causing interference. After you
have determined which device is causing
interference, move it further from the TV/DVD
combo to eliminate the interference.
Problem Solution
44
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Remote control
General
No output from one of the
speakers.
• Adjust the audio balance. See “Adjusting sound
settings” on page 25.
• Make sure that the audio cables are connected
correctly and securely to your TV/DVD combo.
After images appear.
• Do not display a still image, such as a logo,
game, or computer image, for an extended
period of time. This can cause a permanent
after-image to be burned into the screen. This
type of damage is not covered by your warranty.
Problem Solution
Remote control does not
work.
• Make sure that the power cord is correctly
connected to your TV/DVD combo and a power
outlet.
• Make sure that there are no obstructions
between the remote control and the remote
control sensor on the front of the TV/DVD
combo.
• Point the remote control directly at the remote
control sensor on your TV/DVD combo. For the
location of the remote control sensor, see
“Aiming the remote control” on page 18.
• The supplied batteries are wrapped tightly in
clear plastic. Make sure that you have removed
this plastic from the batteries.
• Make sure that the batteries are installed
correctly. See “Installing remote control
batteries” on page 18.
• Replace dead batteries with new batteries. See
“Installing remote control batteries” on page 18.
Trouble programming your
existing universal remote
control.
• See instructions and a table of common codes in
“Programming a different universal remote
control” on page 47.
• Codes are subject to change. For up-to-date
codes, go to
www.insigniaproducts.com/remotecodes
• Replace dead batteries with new batteries. See
“Installing remote control batteries” on page 18.
• Refer to the User Guide that accompanied your
universal remote control and contact the
manufacturer if problems persist.
Problem Solution
No power.
• Make sure that the power cord is correctly
connected to your TV/DVD combo and a power
outlet.
• Unplug the power cord, wait 60 seconds, then
plug the cord back in and turn on your TV/DVD
combo.
• Other devices (for example, a surround sound
receiver, external speakers, fans, or hair dryers)
may be interfering with your TV/DVD combo. Try
turning off one device at a time to determine
which device is causing interference. After you
have determined which device is causing
interference, move it further from the TV/DVD
combo to eliminate the interference.
Problem Solution
“No signal” error
message is displayed.
• Press INPUT and make sure that you have
selected the correct input for the device or
service you are trying to use.
• If you are using a cable or satellite box, use the
remote that came with that box to change
channels.
• Make sure that you have the correct input
selected to view channels from the cable or
satellite box.
After Auto Channel
Search, there are no
channels.
• Reception can vary by channel depending on the
broadcast power level of a given station. Contact
your cable or satellite TV provider.
• Make sure the antenna or cable/satellite TV is
connected securely to your TV/DVD combo.
• Try replacing the cable between the
antenna/cable or cable/satellite box and your
TV/DVD combo.
One or more channels
do not display.
• Make sure that the channels are not blocked. See
“Setting parental control levels” on page 31.
• Make sure that the channels are not hidden. The
channel may have been deleted from the
channel list. You can tune to the channel by
pressing the number buttons or you can add the
channel back to the channel list. See “Hiding
channels” on page 28.
• If you are using a cable or satellite box, use the
remote that came with that box to change
channels.
• Make sure that you have the correct input
selected to view channels from the cable or
satellite box.
• If you are using an antenna, the digital channel
signal may be low. To check the digital channel
signal strength, see “Checking the digital signal
strength” on page 29.
Password is lost.
• Enter 9999 to access parental controls, then set
a new password. See “Setting or changing the
password” on page 29.
Some settings cannot be
accessed.
• If a setting is grayed, the setting is not available
in the current video input mode.
TV/DVD combo cabinet
creaks.
• When the TV/DVD combo is in use, the
temperature rises naturally and may cause the
cabinet to expand or contract which can cause a
creaking noise. This is not a malfunction.
Control buttons do not
work.
• Make sure that the Button Lock option is set to
Off. See “Locking control buttons” on page 30.
• Unplug the power cord, wait a few seconds, then
plug the cord back in and turn on your TV/DVD
combo.
TV keeps turning off.
• Make sure that the sleep timer is not turned on.
See “Setting the sleep timer” on page 36.
Problem Solution
45
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Disc playback USB photo display
Problem Solution
Playback does not start
• Make sure that a disc is inserted in the disc slot.
• The disc may be dirty. Clean the disc. See
“Cleaning discs” on page 42.
• The disc format may not be supported. For more
information, see “DVD player” on page 46.
No picture
• Press INPUT and make sure that DVD is
selected. For more information, see “Selecting
the video input source” on page 21.
No sound
• Make sure that headphones are not connected
to your TV/DVD combo. When headphones are
connected the internal speakers are muted.
• If your TV is connected to a sound system, make
sure that the volume on the sound system is
turned up.
Picture is distorted
during fast forwarding
or reversing
• This is not a malfunction. When you resume
normal playback the distortion should
disappear.
Some playback features
do not work
• Depending on the disc, some playback features
such as stopping, skipping, or repeat playback
may not work.
The audio language or
subtitle language
cannot be changed
• Not all discs have multiple languages. Check the
disc menu or disc packaging.
No subtitles
• Press SUBTITLE and make sure that subtitles are
set to on.
Problem Solution
Photos are not displayed
• Make sure that your USB flash drive is connected
securely to the USB jack on the back of yourTV.
See “Connecting a USB flash drive” on page 16.
• Press INPUT and make sure that USB (Photos)
is selected. See “Selecting the video input
source” on page 21.
• Make sure that the photos on the USB flash drive
are JPEG image files with “.jpg” as the file
extension.
Slideshow does not start
• Make sure that you select slideshow when you
are in thumbnail mode. See “Viewing photos in
a slideshow” on page 39.
Note
If the problem is not solved by using these
troubleshooting instructions, turn off your TV/DVD
combo, then turn it on again.
46
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Specifications
Specifications are subject to change without notice.
Dimensions and weight
Screen
Display resolutions
Tuner
Inputs
Outputs
Audio
Power
Miscellaneous
DVD player
Without stand
18.5 × 12.74 × 2.8 in. (47 × 32.4 × 7.2 cm)
8.8 lbs. (4.0 kg)
With stand
18.5 × 14.4 × 7.2 in. (47 × 36.6 × 18.3 cm)
9.5 lbs. (4.3 kg)
Screen size measured
diagonally
18.5 in.
Display type LCD
Panel 60 Hz vs.120 Hz 60Hz
Display resolution 720p
Panel resolution 1366 (H) × 768 (V)
Aspect ratio 16:9
Contrast ratio (typical)–panel 1000:1
Dynamic contrast ratio–
list value
2000:1
Brightness (center typical)
cd/m2
250 nits
Comb filter 3d y/c digital
Response time 5 ms
Horizontal viewing angle 150
Vertical viewing angle 140
HDMI 1.3 1080p, 1080i, 720p, 480p, 480i
Component video 1080p, 1080i, 720p, 480p, 480i
Analog NTSC
Digital ATSC, 8-VSB, Clear-QAM
HDMI/DVI
1 (side)
E-EDID compliant
HDCP compliant
Component video 1 (back)
Composite video 1 (side)
Shared audio (component
and composite)
Yes
S-Video No
PC/VGA 1 (side)
3.5mm PC audio input 1 (side)
USB
1 (back)
Supports JPEG and firmware upgrade
Video No
Analog audio No
Digital audio 1 coaxial (back)
WiFi No
Ethernet No
Headphone 1 (side)
Speakers
Number: 2
Watts per channel: 2.7W
Power consumption
On: 53W
Standby: <1W
Power input 120V/60Hz
OSD languages English, French, Spanish (all models)
INlink No
Game Mode No
ENERGY STAR qualified No
Internet connectable No
TV base screws M4 type (18 mm length) (2 pcs)
V-Chip (version 2.0) Yes
Sleep timer Yes
Channel labeling No
VESA mount (mm)
(horizontal × vertical)
100 × 100
Note
The length of the wall-mount screws vary depending
on the wall-mount bracket you purchased. See the
instructions that came with the wall-mount bracket
for screw lengths.
Tray vs. slot load Slot load
Disc capacity 1
Progressive scan No
Skip protection
No audio skipping during CD playback under
typical usage conditions
Optical disc support
Supports: CD Digital Audio 12 cm, CD-R, CD-RW,
DVD-Video 12 cm, DVD-R, DVD-RW, DVD+R,
DVD+RW, DVD-R DL Dual Layer, DVD+R Dual Layer
Does not support: CD Digital Audio 8 cm,
DVD-Video 8 cm, DVD-RW Dual Layer, DVD+RW
Dual Layer
Audio decoder
Supports: CD Digital Audio, Dolby Digital
Does not support: Simulated Surround (e.g. SRS),
MP3, WMA, WMA Lossless
Digital audio output formats
supported via HDMI output
No
Digital audio output formats
supported via coaxial output
Supports: Linear PCM 2 channel, Dolby Digital
Does not support: DTS, DTS HD Master Audio
Digital audio decode
capability (HDMI Output)
No
Digital audio decode
capability (digital coaxial
output)
Supports: Dolby Digital to 2-channel downmix
PCM
Does not support: DTS to 2-channel downmix
PCM
Video decoder
Supports: DVD Video
Does not support: JPEG, WMV (Window Media
Video) 9.1, VCD 1.1, VCD 2.0, SVCD, DivX, or XviD
47
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Programming universal
remote controls
Programming a different universal remote
control
You can operate your Insignia TV/DVD combo with
a new or existing universal remote control.
To program a different universal remote control:
1 See the table below for common codes. If you
have problems programming your remote or
need a different remote control code, visit
www.insigniaproducts.com/remotecodes for
the latest remote control code information.
2 Follow your universal remote control’s
instructions to enter the TV code you found in
Step 1.
For additional help and information:
• Visit:
http://www.insigniaproducts.com/remotecodes
• Call technical support for the universal remote
control or cable/satellite company of the
remote/set-top box you are trying to program.
• Call the Insignia Customer Care Center
1-877-467-4289.
Common universal remote control codes
The following is a list of the most common remote
control codes. Codes for other remote controls are
available online at:
http://www.insigniaproducts.com/remotecodes
or check with your cable or satellite TV provider for
the remote control code.
Insignia TV codes for universal remote controls (for all
Insignia TVs manufactured after Jan. 1, 2007)
Tips
• If your universal remote control has a code
search feature, run a code search to identify a
code that matches your TV/DVD combo. See
your universal remote control’s instructions for
details.
• If your universal remote control has a “Learn”
feature, you can manually program it using the
Insignia TV remote to “teach” the commands
one at a time. See your universal remote
control’s instructions for details.
Universal remote control makes and models
One for All 0054
Phillips 0198, 0490
RCA 135
Sony
068, 069, 078, 096, 100, 164, 168, 229,
026
Set-top box makes and models
Cablevision
068, 069, 078, 096, 100, 164, 168, 229,
026
Charter
2002, 1204, 1423, 1517, 0171, 1963,
0463, 1463, 0842, 1326, 167, 415, 424,
450, 456, 461, 507, 523, 567, 577, 586
Comcast
10171, 11204, 11326, 11463, 11517,
11641, 11780, 11785, 11892, 11963,
12002
Cox 1326, 1463
DirectTV
10171, 11204, 11326, 11517, 11564,
11641, 11963, 12002
Dish Network 720
Time Warner 400, 450, 461, 456, 10463, 1463, 0463
TiVo 0091
Verizon 0198, 0490
Tips
• The brand name is often visible on the front of
the universal remote control, and the model
number is often visible on the back.
• If your universal remote control isn’t listed on
the chart, refer to your universal remote
control’s instructions and try codes for the
brands Orion, Emerson, Memorex, Sansui,
Sylvania, or Zenith. You may need to try several
codes before finding a match.
48
NS-19LD120A13 Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
Legal notices
FCC Part 15
This device complies with Part 15 of the FCC Rules. Operation of
this product is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply within the
limits for a class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
FCC warning
Changes or modifications not expressly approved by the party
responsible for compliance with the FCC Rules could void the
user’s authority to operate this equipment.
Cables
Connections to this device must be made with shielded cables
with metallic RF/EMI connector hoods to maintain compliance
with FCC Rules and Regulations.
Canada ICES-003 statement
This Class B digital apparatus complies with Canadian ICES-003.
Standard Television Receiving Apparatus — Appareil de
réception télévision ordinaire, Canada BETS-7 / NTMR-7
HDMI
HDMI, the HDMI logo, and High-Definition
Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
49
Insignia 19" LCD TV/DVD Combo
www.insigniaproducts.com
One-year limited warranty -
Insignia Televisions
Definitions:
Insignia Products (“Insignia”) warrants to you, the original
purchaser of this new Insignia-branded television (“Product”),
that the Product shall be free of defects in the original
manufacturer of the material or workmanship for a period of one
(1) year from the date of your purchase of the Product (“Warranty
Period”). For this warranty to apply, your Product must be
purchased in the United States or Canada from a Best Buy or
Future Shop authorized dealer of Insignia brand products only
that are packaged with this warranty statement.
How long does the coverage last?
The Warranty Period lasts for 1 year (365 days) from the date you
purchased the Product. Your purchase date is printed on the
receipt you received with the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the
material or workmanship of the Product is determined to be
defective by an authorized Insignia repair center or store
personnel, Insignia will (at its sole option): (1) repair the Product
with new or rebuilt parts; or (2) replace the Product at no charge
with new or rebuilt comparable products or parts. Products and
parts replaced under this warranty become the property of
Insignia and are not returned to you. If service of Products or
parts are required after the Warranty Period expires, you must
pay all labor and parts charges. This warranty lasts as long as you
own your Insignia Product during the Warranty Period. Warranty
coverage terminates if you sell or otherwise transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy or Future Shop retail
store location and your television Product has a screen size of
less than 42 inches, please take your original receipt and the
Product to any Best Buy or Future Shop store. Make sure that you
place the Product in its original packaging or packaging that
provides the same amount of protection as the original
packaging. If you purchased the Product from a Best Buy or
Future Shop online web site, mail your original receipt and the
Product to the address listed on the web site. Make sure that you
put the Product in its original packaging or packaging that
provides the same amount of protection as the original
packaging.
To obtain in-home warranty service for a television with a screen
42 inches or larger, in the United States call 1-888-BESTBUY,
Canada call 1-866-BESTBUY for Future Shop call 1-800-663-2275.
Call agents will diagnose and correct the issue over the phone or
will have a Insignia-approved repair technician dispatched to
your home.
Where is the warranty valid?
This warranty is valid only in the United States and Canada at
Best Buy or Future Shop branded retail stores or websites to the
original purchaser of the product in the county where the
original purchase was made.
What does the warranty not cover?
This warranty does not cover:
• Customer instruction/education
• Installation
• Set up adjustments
• Cosmetic damage
• Damage due to acts of God, such as power surges
• Accident(s)
• Misuse
• Abuse
• Negligence
• Commercial purposes/use, including but not limited to use
in a place of business or in communal areas of a multiple
dwelling condominium or apartment complex, or
otherwise used in a place of other than a private home.
• Modification of any part of the Product, including the
antenna
• Plasma display panel damaged by static (non-moving)
images applied for lengthy periods (burn-in).
• Damage due to incorrect operation or maintenance
• Connection to an incorrect voltage or power supply
• Attempted repair by any person not authorized by Insignia
to service the Product
• Products sold “as is” or “with all faults”
• Consumables, including but not limited to batteries (i.e. AA,
AAA, C etc.)
• Products where the factory applied serial number has been
altered or removed
• Loss or Theft of this product or any part of the product
• Up to three (3) pixel failures (dots that are dark or
incorrectly illuminated) grouped in an area smaller than
one tenth (1/10) of the display size or up to five (5) pixel
failures throughout the display. (Pixel based displays may
contain a limited number of pixels that may not function
normally.)
• Failures or Damage caused by any contact including but
not limited to liquids, gels or pastes.
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS
YOUR EXCLUSIVE REMEDY FOR BREACH OF WARRANTY. INSIGNIA
SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS
OR IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT
NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT,
LOST BUSINESS OR LOST PROFITS. INSIGNIA PRODUCTS MAKES
NO OTHER EXPRESS WARRANTIES WITH RESPECT TO THE
PRODUCT, ALL EXPRESS AND IMPLIED WARRANTIES FOR THE
PRODUCT, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN
DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY
AFTER THE WARRANTY PERIOD. SOME STATES, PROVINCES AND
JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT
APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY
FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Contact Insignia:
For customer service please call 1-877-467-4289
www.insigniaproducts.com
Distributed by Best Buy Purchasing, LLC
7601 Penn Avenue South, Richfield, Minnesota, U.S.A.
55423-3645
© 2012 BBY Solutions, Inc.
All rights reserved. INSIGNIA is a trademark of BBY Solutions, Inc.
Registered in some countries. All other products and brand
names are trademarks of their respective owners.
www.insigniaproducts.com (877) 467-4289
Distributed by Best Buy Purchasing, LLC
7601 Penn Avenue South, Richfield, MN 55423-3645 USA
© 2012 BBY Solutions, Inc.
All rights reserved. INSIGNIA is a trademark of BBY Solutions, Inc. Registered in some countries.
All other products and brand names are trademarks of their respective owners.
ENGLISH
11-1329
